Infotainment system

267

Voice control

The system scans the words spoken in the vehi-
cle after the wake word.

Connect and disconnect the wake word

 Press

HOME >   Settings > Voice control >

Activate / deactivate wake word

.

Wake word:

Hola Hola

Commands

To help the voice control recognise commands
reliably:

Pronounce clearly. Confusing commands are

not recognised. Speak in a normal tone of
voice. Speak a little louder if you are driving at
high speed.

Avoid outside noises. Open windows and

doors can interfere with voice control.

Avoid other secondary noises, such as con-

versations in the vehicle. Do not direct the air
flow from the outlets towards the microphone
or the interior lining of the roof.

Do not make long pauses.

Voice control is active and recognises
the words pronounced.

Note

When the activation word is disconnected,

the infotainment system cannot be activated
by means of the activation word. Voice con-
trol is still available via the   button on the
multifunction steering wheel.

Availability depends on country and equip-

ment.

Start and stop voice control

Depending on the equipment, you can start
voice control in different ways.

Start voice control



Voice control activation:

 say the word that

activates voice control.

Multifunction steering wheel:

 press the voice

control button  .
In some cases you can also start voice con-
trol of the connected mobile phone device, by
pressing and holding the voice control button.

Manually ending voice control

Voice control can be cancelled with the

Can-

cel

 command.



Multifunction steering wheel:

 press the voice

control button   twice in a row, or press and
hold.

The voice control ends automatically, if you use
infotainment functions, if the parking system is
activated or by incoming calls.

CarManuals2.com

268

Infotainment system

Radio mode

Introduction

Fig. 188

 Schematic diagram: Radio view.

In Radio mode you can tune in the available
radio stations in different frequency bands and
memorise your favourites on the preset buttons
to access them quickly.
The types of reception and frequency bands
available depend on the equipment and the
country. In certain countries, frequency bands
may stop broadcasting or not be available
again.

Access the RADIO menu

 Press

HOME >

›››

Fig. 188

.

Access the settings

 Press

HOME >   >

.

Online functions in Radio mode

Online functions in Radio mode are only availa-
ble under the following conditions:

 SEAT CONNECT or SEAT CONNECT Plus

equipment.

You have an active SEAT CONNECT user ac-

count.

The vehicle is assigned to your user account.

You have a corresponding data package ac-

quired from the In-Car store or have a data
volume for your own mobile phone device via
Wi-Fi access point.

Note

For streaming services you need to have an

account with the provider in question.

Radio stations are responsible for the con-

tent of the information they transmit. Elec-
trical equipment connected to the vehicle
may also cause interference in radio signal
reception and noise in the loudspeakers.

Foil or metal-coated stickers attached to

the windows may affect reception on vehi-
cles with a window aerial.

CarManuals2.com

Infotainment system

269

Radio mode

AM
FM/DAB

Internet radio

TP

Radio equipment and symbols

The functions, as well as the types of reception
and frequency bands available depend on the
equipment and the country.

AM tuner.

Dual FM receiver (diversity antenna).

Summarised FM station list.

Merger of DAB and FM stations into one list.

Fusion of all stations stored in preset buttons

into one list. Maximum 36 favourite stations.

Station logos.

DAB presentation (slideshow). Images that

are emitted sequentially.

Internet radio.

Universal symbols in Radio mode

To select the desired AM frequency band.

To select the desired FM/DAB fre-

quency band.

To select the type of Internet ra-

dio reception.
Next to the name of the station, monitoring
of active traffic information stations (TP).

Symbols on the FM/DAB frequency band

To display the frequency band for manual
selection of the FM frequency. Only possi-
ble when the summary station list is discon-
nected.

DAB not available.
DAB stations support presentations (slide-
show).

Symbols on the AM frequency band

Manually updating the station list.
To display the frequency band for manual
selection of the AM frequency.

Menus in Internet radio mode

Show station selection.
Open text search.
Show the last online radio stations heard.
Show the 100 most played radio stations
and podcasts.
Show available online radio podcasts.
Show online radio stations, grouped by
country.
Show online radio stations by the desired
language.
Show online radio stations whose pro-
gramme belongs to the desired musical
genre.

Selecting, tuning and saving a sta-
tion

Select the frequency band

Before selecting a station you have to select
a frequency band or a type of reception. Differ-
ent stations are available depending on the fre-
quency band selected or the type of reception.
The types of reception and frequency bands
available depend on the equipment and the
country.

Select the frequency band or type of recep-

tion: AM, FM/DAB, FM (for devices that do not
have DAB), Internet radio.

Search and select a station

You can select radio stations in different ways.
The options vary depending on the frequency
band and the type of reception.

Select via the frequency band (AM and FM)

1. Activate the frequency band.
2. Click on the cursor, scroll through the fre-

quency band and release it when you
reach the frequency band you want.

OR:

 press on a point on the frequency

band. The cursor will automatically jump to
the corresponding frequency.

The station of the set frequency is tuned.

CarManuals2.com

270

Infotainment system

Select from the station list (AM and FM/DAB)

The station list shows the stations that are cur-
rently tunable. In the AM frequency band, you
may have to update the station list if you are no
longer in the area where you last accessed the
station list. In the FM/DAB frequency band, the
station list is automatically updated.
1. Open the station list
2. Press the station you want.
The selected station is tuned. In the case of
FM/DAB and if the station is available, the best
quality reception is automatically selected.

Search and filter stations (Internet radio)

In Online Radio mode, stations can be filtered
by categories and can be searched by text.
1. Open the station list.
2. Select the category by which the stations

are to be filtered.

OR:

 press   to start the text search. The

input field is displayed.

3. Enter the name of the station you want. The

list of the stations found is updated while
entering the text.

4. Press the station you want.
The selected station is tuned.

Search in SCAN mode (AM and FM/DAB)

In SCAN mode the stations are automatically
tuned in a sequential manner and each of them
is played for approx. 5 seconds.

 To start the SCAN mode, under

Settings

press

SCAN

.

SCAN mode starts and the station currently
tuned in is shown on the screen. Next to it is a
SCAN function button.

To select a station press SCAN.

SCAN mode stops and the station is tuned. The
SCAN function button is hidden.

Storing the station on the preset buttons

You can store up to 36 stations of different fre-
quency bands and reception types as favour-
ites using the preset buttons.
1. Tune the station you want.
2. Access the preset buttons.
3. Press the preset button and keep it pressed

until the station is stored.

OR:

 press the station on the station list and

keep it pressed. The preset buttons are dis-
played.

4. Press the preset button.
The station is stored in the selected preset but-
ton.
If a station was already stored in the preset
button, it is overwritten with the new station.

Special functions in Radio mode

Traffic information (TP)

The TP function monitors the announcements
of a station with traffic information and auto-
matically reproduces them in the Radio mode
or in the multimedia playback that is active. To
do this, you have to be able to tune into a sta-
tion with traffic information.
Some stations without their own traffic informa-
tion support the TP function by broadcasting
traffic information from other stations (EON).
In the AM frequency band or in the Multimedia
mode, a station with traffic information in the
background is automatically tuned while it is
possible to tune into a station with traffic infor-
mation.
If no station with traffic information can be
tuned in, the device automatically searches for
stations with tunable traffic information.
Stations with traffic information are not availa-
ble in all countries.
Activating and deactivating the TP function

 In Radio mode or Multimedia mode, press

> Traffic programme (TP)

.

Presentations (SlideShow) in DAB

The slideshow function (SLS) is a feature of digi-
tal radio (DAB) stations, allowing a slideshow of
images, e.g. the station’s logo, to the user.

CarManuals2.com

Infotainment system

271

Radio mode

Activating and deactivating the SLS function
It is possible to deactivate the slideshow func-
tion on DAB radio stations:

 In the Radio Menu click on the area where

the station information is located, either in the
name or on the additional information (author
or information text).

Online radio

Online radio is a type of reception for Internet
radio stations and podcasts that are independ-
ent of AM, FM and DAB. Thanks to Internet
transmission, reception is not limited to the re-
gion.

Online radio is only available through the Inter-
net connection of the active infotainment sys-
tem. The use of online radio can generate ex-
penses due to the transmission of data from the
Internet.

In Online radio mode, press and set the audio

quality to high or low to tune the online radio.

Station logos

In the case of some frequency bands, station
logos may already be pre-installed in the info-
tainment system.
If in the FM/DAB frequency band settings the

automatic selection of station logos

 is acti-

vated, station logos are automatically assigned
to the stations.

In the Online radio mode, the infotainment sys-
tem accesses the station logos of the online
database and automatically assigns them to
the stations.

Assign station logos manually

1. In FM/DAB mode, press

Station logos

.

2. Press on the   icon and then select the

station to which a station logo is to be as-
signed.

3. Select the station logo. If desired, repeat

the same process with other stations.

4.

OR:

 via the menu

 > Station logos

.

CarManuals2.com

272

Infotainment system

Media Mode

Introduction

Fig. 189

 Schematic diagram: Media view

In Media mode you can play multimedia
files from data media and streaming services
through the infotainment system.
Depending on the equipment, the following
data media can be used:

 USB storage support (for example, a USB

stick, a mobile phone connected via USB).

Bluetooth® device (for example, a mobile

phone or a tablet).
Depending on the equipment, the following
types of multimedia files can be played:

Audio files.

Video files (depends on the system).

You can also use streaming services. The avail-
ability of streaming services depends on the
equipment and the country.
To use streaming services you need to have
your own user account in the streaming service
in question.

Access the MEDIA menu

Press

HOME >



›››

Fig. 189

.

Access the settings

 Press

HOME >   >

.

Limitations and indications of data media

Data media may not work if they have been ex-
posed to high temperatures or have been dam-
aged. Please bear in mind the manufacturer’s
indications.
Quality differences between data media pro-
duced by different manufacturers can cause
multimedia playback malfunctions.
Incorrect configuration on a data media may
cause the data media to be unreadable.
Playlists only specify a playback order and re-
fer to the storage location of the multimedia
files within the folder structure. In a playlist
there are no multimedia files saved. To play a

CarManuals2.com

Infotainment system

273

Media Mode

playlist, multimedia files have to be found in the
storage places of the data media to which the
playlist refers.

Note

SEAT assumes no liability for any deteriora-
tion or loss of files on data storage devices.

Equipment features and media sym-
bols

Audio, multimedia and connectivity:

 Media playback and control via Bluetooth®.

Audio playback in these formats: AAC, ALAC,

AVI, FLAC, MP3, MP4, WMA.

Video playback in these formats: MPEG-1

and MPEG-2 (.mpg, .mpeg), ISO MPEG4, DivX
3, 4 and 5 Xvid (.avi), ISO MPEG4 H.264
(.mp4, .m4v, .mov), Windows Media Video 10
(.wmv, .asf).

Playlists on any type of device.

Multimedia streaming (online).

Multimedia search.

Universal symbols in Media mode

Start playback.
Pause playback.
Change to the previous track.
Change to the next track.

Repeat the track that is playing.
Repeat all titles.
Activate the shuffle playback order.
Display a list of favourites.
Add a media file as favourite.
Top right: select media source.
Access the settings.
Open the search.
Return to the top folder of the media
source.

Select and play a multimedia source

Select multimedia source

Before playing multimedia files you must first
connect a multimedia source.
To use streaming services you must be connec-
ted to the Internet.

Connect an external multimedia source.

Select the connected media source to be

used for playback.

Playing audio and video files

You can search and play multimedia files from
an available multimedia source in different
ways.

Search in the folder structure

Multimedia files can be catalogued by catego-
ries (for example, album, artist, title). In

My me-

dia

 this category view is always displayed. The

classic folder structure of individual USB data
media is also found in

My media

.

1. Activate the folder structure.

The folder structure of the selected multi-
media source is displayed. When

My media

is selected, the categories (music, videos,
playlists) and connected multimedia sour-
ces are displayed first.

2. Search for the title you want in the folder

structure.

OR:

 press   to start a text search The input

field is displayed.

3. Enter the name of the desired title. The list

of the titles found is updated while entering
the text.

4. Press the desired title.

If at the beginning of the playback your se-
lection is in a folder of a multimedia source,
the multimedia files that are in it are also
added to the playback.
If a playlist is played, all available titles in
the playlist are added to the playback.

5. Close your selection with  .

Select favourites

In favourites you can save titles, music genres,
artists and albums individually for playback.

CarManuals2.com

274

Infotainment system

Access favourites  .

Press the favourite you want.

Depending on your selection, all the titles be-
longing to the favourite are added to the play-
back.

Save favourites

Only multimedia files in

My media

 of the info-

tainment system can be saved as favourites.
You can save up to a maximum of 30 titles, al-
bums, artists and music genres individually as
favourites.

1. Start playback.
2. Access favourites.
3. Tap a favourite that is not assigned.

OR:

 press and hold on an existing favourite

for approx. 3 seconds.

4. Select from the selection list: Title, Album,

Artist, Genres, Playlist.

The selection is saved instead of the previously
selected favourite. If the favourite was already
assigned, the previously saved favourite is over-
written.
The selectable options in the selection list de-
pend on the data attached to the multimedia
file. If the music genre is not indicated in the
music files, for example, you cannot save the
music genre as favourite.
If a video file is playing, only that video can be
saved as favourite.

Configure streaming services

Depending on the equipment you can use
streaming services directly through the infotain-
ment system. For this you need to have a pre-
mium user account of the streaming service in
question and you have to log in with it in the
infotainment system. You also need to be con-
nected to the Internet.
1. Select

 Streaming

 as the multimedia

source.
A list of available streaming services is dis-
played.

2. Select the streaming service you want.
3. Follow the steps indicated by the infotain-

ment system.
The streaming service is added to the list
of multimedia sources as a new function
button.

Playing entertainment content in the
infotainment system

Depending on the infotainment system, videos
can be played.

Video mode

When in video mode, a video can be played
on the infotainment screen if this is stored on a
data media, in

My media

 or is sourced from a

streaming service. In this case, the video sound
is played through the vehicle's speakers.

The image is only displayed if the vehicle is
stopped. When the vehicle is in motion, the in-
fotainment screen turns off. The sound of the
video can still be heard.
A stable Internet connection is required for
playback from a streaming service. In this case,
telephony costs may be generated.

CarManuals2.com

Infotainment system

275

Navigation

Navigation

Introduction

Fig. 190

Schematic diagram: Navigation view.

A global satellite system determines the current
position of the vehicle and the sensors moun-
ted on the vehicle analyse the routes taken.
All measured values and possible traffic events
are compared with the available maps to allow
optimal navigation to the destination.
Navigation announcements and graphic repre-
sentations will guide you to your destination.
Navigation management is carried out on the
screen.
Depending on the country, some functions of
the infotainment system will not be available
on the screen when travelling above a certain
speed. It is not a malfunction, but is due to com-
pliance with legislation.

Navigation announcements

Navigation announcements are acoustic indi-
cations for driving referred to the current route.
The type and frequency of navigation an-
nouncements depend on the driving situation,
for example, starting the guide to the destina-
tion, driving on the motorway or on a round-
about and the settings.
If the exact destination cannot be reached be-
cause, for example, it is in a non-digitised area,
indications relating to the address and the dis-
tance to the destination are displayed on the
screen.

During dynamic route guidance, you will re-
ceive information about reported traffic con-
gestion on the route. An additional navigation
announcement is given if the route is recalcula-
ted due to traffic congestion.
While a navigation announcement is playing,
its volume can be adjusted. The following navi-
gation announcements provided will be played
with the newly adjusted volume.

Limitations during navigation

If the infotainment system cannot receive data
from GPS satellites, for example, in a tunnel or
in an underground garage, navigation contin-
ues using the vehicle's sensors.

CarManuals2.com

276

Infotainment system

In areas that are not digitised or are only parti-
ally digitised on the infotainment memory, the
infotainment system will still attempt to provide
route guidance.
In the case of missing or incomplete navigation
data, it may not be possible to determine the
exact position of the vehicle. This may mean
that navigation is not as precise as usual.
Roads and streets are subject to constant
change (e.g. new roads, road works, roads
closed to traffic, changes to street names and
building numbers). If the navigation data is ob-
solete, this may lead to errors or inaccuracies
during the route guidance.

Managing the navigation map

To allow an optimal view, you can also man-
age the navigation map with additional finger
movements.

Moving the map

Tip: use your index finger

Move the map with your finger.

Zoom in

Tip: use your index finger

To increase the view in a certain position,

double-click on the map.

Zoom out

Tip: use your index and middle fingers

Press on the map with both fingers at the

same time.

Change view

Tip: use your index finger

Press twice on the map and keep your finger

pressed on the screen.

To zoom out the view of the map, move your

finger upwards. To zoom in the view of the map,
move your finger downwards.

Change view

Tip: use your thumb and index finger

Press on the map with both fingers at the

same time and keep them pressed.

To zoom out the view of the map, move one

finger towards the other. To zoom in the view of
the map, move one finger away from the other.

Tilt the view

Tip: use your index and middle fingers

Press on the map with both fingers at the

same time and horizontal to each other, keep
them pressed.

To tilt the view of the map forward, move your

fingers upwards. To tilt the view of the map
backward, move your fingers downwards.

Rotate the map

Tip: use your thumb and index finger

Press on the map with both fingers at the

same time and keep them pressed.

To rotate the map view, turn your fingers

clockwise anticlockwise.

Saved data

The infotainment system saves certain data, for
example, frequent routes and position data, to
make the entry of the destination more agile
and optimise the route guidance.

Delete saved data

 Press

Settings > Basic function settings >

Delete

 and then

Accept

.

WARNING

Select the settings, enter the destination and
the modifications for navigation only with the
vehicle at a standstill.

Note

If a detour is passed during route guidance,

navigation may recalculate the route.

The quality of the navigation recommen-

dations given by the Infotainment system de-
pends on the navigation data available and
any reported traffic congestions.

Navigation announcements are not emit-

ted if the sound is muted in the infotainment
system.

CarManuals2.com

Infotainment system

277

Navigation

Navigation functions and symbols

Navigation

Navigation functions depend on the equipment
and country.

Functions

 Entering the destination and route calcula-

tion (offline and online).

Display of two navigation maps at the same

time (screen and instrument cluster).

Update of online maps.

Predictive navigation.

3D urban maps.

Online traffic information.

Dynamic POIs (points of interest).

Symbols on the map

The buttons and indications depend on the set-
tings and the current driving situation.
Symbols for traffic events and points of inter-
est (POIs) are displayed on the map, for exam-
ple, petrol stations, train stations or interesting
stopovers, provided navigation has such data

›››

page 280

.

Current position.
Search for destinations.
Destinations along the route.
Final destination.

Home address.
Work address.
Favourite destinations.
Additional window with more options.
Additional window with route options.

Centre the map on the current position.

Change view: 2D oriented to the north, or
2D oriented to the direction of travel, or
3D to the direction of travel.

Information about the current route guid-
ance.
Map scale.

Symbols in the additional window

 To open the additional window, press  .

Repeat the last navigation announcement.
Volume of navigation announcements.
Map lighting in Automatic, Day or Night
mode.
Offer new guidance routes.
360° electric range indicator (hybrid vehi-
cles)

Other symbols

Entering the detailed destination for an ad-
dress.
Search for destinations.

Frequent destinations.
Last destinations.
Favourite destinations.
Back

Symbols in the route details

Current position.
Destination of the current guidance.

POI symbols (points of interest)

POIs (points of interest) are shown on the map,
provided the navigation has said data.
Click on the desired POI (point of interest) to
start a route guidance

›››

page 278

.

Petrol station.
Parking lot.
Tourist information offices.
Train station.
Restaurant.

Traffic information.

POIs (points of interest) are shown on the
map, provided the navigation has said data

›››

page 280

.

Click on a traffic event to open an additional
window with further detail

›››

page 280

.

Slow traffic.

CarManuals2.com

278

Infotainment system

Traffic jam.

Accident.

Broken down vehicle.

Slippery surface (ice or snow).

Road closed to traffic.

Slippery road hazard.

Danger.

Road works.

Strong wind.

Reduced visibility.

Navigation data

The Infotainment system is equipped with a
built-in navigation data memory. Depending
on the country, the necessary navigation data
may already be pre-installed.
To provide correct route guidance and make
the most of the functions offered, the infotain-
ment system should be updated on a regular
basis.

Using obsolete data may lead to errors during
navigation. Current routes cannot be traced or
the route guidances will lead to mistaken desti-
nations.
Ensure navigation data is updated at all times.

Online updating of navigation data

The navigation data of the regions through
which you travel frequently is automatically up-
dated in the background if the Internet connec-
tion is established and the privacy settings are
valid.

 With the ignition switched on, the navigation

data is updated automatically.

Manual update of navigation data

Current navigation data for large regions, for
example Western Europe, can be downloaded
from www.seat.com and stored on USB data
devices.

Download the navigation data to a USB data

device.

Turn on the ignition of the vehicle.

Connect the USB data device to the infotain-

ment system. Navigation data is automatically
updated in the background.
The map version is displayed in

HOME >   >

System information

.

WARNING

If you update the navigation data manually
while driving, it may cause accidents with se-
rious injuries.

Update the navigation data only with the

vehicle at a standstill.

Note

Automatic update of the navigation data is
subject to the privacy settings. No update is
made in incognito mode.

Start route guidance

Depending on the country and equipment, dif-
ferent functions are available to enter destina-
tions.
The different functions for entering destinations
are found in the navigation main menu.

Opening the Navigation main menu

Press

HOME >

.

Select the destination and start navigation

1. Press  .
2. Select the desired destination. You can

chose from

 Frequent destinations,

Last destinations or   Favourite desti-
nations.

CarManuals2.com

Infotainment system

279

Navigation

OR:

 press   and enter the address in the

input screen.

OR:

 detailed address.

3. Press

Start

.

 Frequent destinations

The destination synopsis uses recorded data to
propose possible destinations.

Select the destination and start navigation:

1. Press   and then  .
2. Select the desired destination. The route

guidance starts automatically.

Quick start:

 for a quick start, press and hold

the desired destination for a few seconds.

 Recent destinations

Navigation saves the last destinations to make
them available for a route guidance.

Select the destination and start navigation:

1. Press   and then  .
2. Press the desired destination.
3. Press

Start

.

Quick start:

 for a quick start, press and hold

the desired destination for a few seconds.

 Favourite destinations

Save up to 20 destinations as favourites.

To save a destination as a favourite press   in
the split screen when entering the destination.

Select the destination and start navigation:

1. Press   and then  .
2. Press the desired destination.
3. Press

Start

.

Note

Enter the destination as accurately as possi-
ble. If you enter a destination incorrectly, the
route guidance will not be able to start or it
will guide you to an incorrect destination.

Start route guidance by selecting from the
map

The navigation map includes active areas at
many points that are suitable for entering the
destination. To do this, press the desired posi-
tion or place on the map. If there is map data at
this point, you can start a route guidance.
Whether it is possible to enter the destination
through the navigation map depends on the
state of the data and it is not possible for all
positions.
To start “offroad navigation”, press an empty
area without position data.

Start navigation:

1. Press  .
2. Move the view on the map until the desired

position can be selected. The navigation
map can be used by means of additional
finger movements

›››

page 275

.

3. Press the desired destination on the map.
4. Press

Route

.

Offroad navigation

“Offroad navigation” calculates routes to se-
lected destination points using unknown data.
When a destination point is outside the known
roads or position data, navigation finds the
route to the next point of the known road and
completes the path to the next destination
point with a direct connection.

Start navigation:

1. Move the view on the map until the desired

position can be selected. The navigation
map can be used by means of additional
finger movements

›››

page 275

.

2. Press on any point on the map without posi-

tion data.

3. Press

Route

.

Start route guidance using contact details

Start route guidance with the saved address
data of a contact. Contacts saved without ad-
dress data cannot be used for route guidance.

CarManuals2.com

280

Infotainment system

Start navigation:

1. Press  .
2. Press on the contact you want.
3. Press

Route

.

Note

If the address details of a contact are ob-
solete, the route guidance will nevertheless
take you to the registered address. Check
that the contact address is updated.

Traffic information

The infotainment system receives detailed traf-
fic information automatically if the Internet con-
nection is established. This information is shown
with symbols and highlighting the road network
in colour on the map.

Traffic incidents

Traffic incidents, for example, traffic jams or
congested traffic, are shown on the navigation
map using symbols.
With an active route guidance, traffic incidents
that are on the current route are shown in the
route details. Such traffic incidents can be avoi-
ded

›››

page 280,

Function descriptions

.

Hazard information

Hazard information is shown on the navigation
map with symbols in the same way as traffic
incidents. In this case, the source of this infor-

mation is another vehicle that has detected the
hazard and has uploaded the information to the
service provider.
The hazards shown are: accident, broken down
vehicle and slippery road surface.

Traffic flow indication

The navigation map shows traffic flow accord-
ing to current traffic events, highlighting the
road network in colour.

Yellow:

 Slow traffic.

Red:

 Traffic jam.

Note

Traffic information receipt is subject to the
privacy settings. In maximum Privacy mode,
no traffic information is received. Tracking or
Location level setting is necessary.

Function descriptions

Route details

The route details contain information on all inci-
dents, for example, the starting point, stopovers,
traffic events, POIs and destination, provided
the navigation has such data.
If you press on an incident, an additional win-
dow opens providing more options. The avail-
able options depend on the incident and the
current settings.

Open and close the route details

To open them, press   or swipe it.

To close them, press   or swipe it.

Edit route guidance

To edit the route guidance, move the stopovers
to the destination in the TripView view.

 Hold the desired destination pressed until it is

visibly highlighted.

Move the destination to the desired position.

Remove your finger from the screen. The

route will recalculate.

Avoid traffic incidents

The details of the route show the current traf-
fic incidents if the navigation has such data.
Avoid traffic incidents by editing route details

›››

page 280

.

Press on a traffic event.

Press on

Avoid

. The route will recalculate.

Split screen

When handling navigation functions, an addi-
tional window with other options may open.
Possible options depend on the function being
used.

CarManuals2.com

Infotainment system

281

Navigation

Close the additional screen

 Press on an empty area outside the addi-

tional window.

OR:

 press  .

OR:

 press

Accept

.

Functions in the additional window:

Show on
map

Show what is selected on the map.

Add stop-
over desti-
nation

Add a stopover to the route guid-
ance.

Direct
route

Starts direct route guidance.

Delete

Delete a stopover from the route
guidance.

Avoid

Avoid traffic jam. The route will re-
calculate.

Stop route
guidance

Ends the current route guidance.

Close the additional window.

Add a destination to favourites.

Learn usage pattern

When the vehicle is in motion, navigation saves
routes and destinations used to automatically
generate destination proposals. Destinations
are learned based on the time of day and the
day of the week.

Navigation can propose up to 5 routes at the
same time. The proposed routes may be differ-
ent from the routes of the normal route guid-
ance.
If one of the proposed destinations is selected,
the guide to that destination is started.
The route guidance follows the selected route
until the vehicle deviates from it. In that case,
the route is recalculated and takes you back
along the most direct path to the initially selec-
ted destination.
Important traffic jams are taken into account
in the route guidance, and are avoided if alter-
native routes are available, provided navigation
has such data.
You can activate and deactivate the function
whenever you want.

Enable and disable learning usage pattern

The setting is in the corresponding navigation
menu

 > Basic function settings

.

 To activate the function, activate

Learn us-

age pattern

.

To disable the function, disable

Learn usage

pattern

.

To delete saved data, press

Delete usage

pattern

.

360° electric operating range display

Valid for: vehicles with plug-in hybrid drive

The 360° electric operating range display
shows the possible range with the current
charge level of the high voltage battery.
Switch on the 360° electric operating range
display

 Open the additional map window and press

the symbol  .

CarManuals2.com

282

Infotainment system

Telephone interface

Introduction

Fig. 191

Schematic diagram: Phone view.

You can use the telephone interface to connect
your mobile to the infotainment system and op-
erate phone functions through it. The sound is
played through the vehicle's speakers.
You can connect up to two mobile phone devi-
ces simultaneously to the infotainment system.
High speeds, poor weather or road conditions
and a noisy ambience (even outside of the ve-
hicle), as well as the quality of reception can all
affect the quality of a telephone conversation
in the vehicle.

Note

As a general rule, pairing a device (for ex-

ample, a mobile phone device) is only nec-
essary once. You can restore the device con-
nection via Bluetooth® or Wi-Fi with the info-
tainment system whenever you want without
having to pair the device again.

The availability of some telephone func-

tions will depend on the mobile phone con-
nected to the infotainment system.

Telephone interface equipment and
symbols

Equipment features

Hands-free function.

Use up to two phones at the same time.

Phone book with up to 5,000 contacts, de-

pending on the infotainment system.

SMS functions via Bluetooth®: SMS reading,

SMS writing (templates included), SMS play-
back, message history.

Email functions via Bluetooth®: reading email,

writing email.

CarManuals2.com

Infotainment system

283

Telephone interface

Connection to wireless charging option.

Connection to the microphone mounted on

the vehicle.

Symbols in the main menu

Contacts.
List of incoming and outgoing calls.
Enter telephone number.
Text messages (SMS and emails).
Telephone interface settings.

Symbols for calls

The symbols may be different depending on
the infotainment system.

Start a call or bringing it to the foreground.
End or reject a call.
Open contact list.
Enter telephone number.
Mute the sound of the hands-free
Hold call.
Continue call.
Start conference call.
Pass call to private mode.
Make an emergency call.
Voice mail.

Get help in case of breakdown.

Obtain information on the SEAT brand
and selected additional services related to
traffic and your travel.

Call list symbols

 To open the call lists, press  .

Incoming call.
Outgoing call.
Missed call.
Telephone number (company).
Telephone number (private).
Mobile telephone number (company).
Mobile telephone number (private).
Fax (private).
Fax.

Symbols for text messages

The symbols may be different depending on
the infotainment system.

 To open the text messages, press  .

Activate voice control input

›››

page 266

.

Templates for text messages.

Places with special regulations

Switch off the mobile telephone and the tel-
ephone interface in places with a risk of ex-
plosion. These places are not always clearly
marked. They include, for example:

 The vicinity of chemical pipelines and tanks.

The lower decks of boats and ferries.

In the proximity of vehicles that run on lique-

fied gas (such as propane or butane).

Places where the air is laden with chemicals

or particles such as flour, dust or metal powder.

All other places where the engine or tele-

phone must be switched off.

WARNING

Switch off the mobile phone in areas with a
risk of explosion!

Note

In areas where special regulations apply or
the use of mobile phones is forbidden, it
must be switched off at all times. The radi-
ation produced by the mobile phone when
switched on may interfere with sensitive
technical and medical equipment, possibly
resulting in malfunction or damage to the
equipment.

Pair, connect and manage

Requirement for pairing:

 Bluetooth® is activated on the mobile phone

device.

Bluetooth® is activated on the infotainment

system.

CarManuals2.com

284

Infotainment system

Active

Passive

Depending on the mobile device, it will be

necessary to have the Bluetooth® menu open
or activate the

Visibility

 option so that the de-

vice is visible from the infotainment system.
Pair a mobile phone device suitable for teleph-
ony with the infotainment system to use the
telephone interface functions. On the first con-
nection, the mobile phone device is paired with
the infotainment system. Doing so saves a user
profile

›››

page 284,

User profiles

.

The pairing can take a few minutes. The func-
tions available depend on the mobile phone
device used and its operating system.

Pair a mobile phone device

1. Open the list of available Bluetooth® devi-

ces on the mobile phone device and select
the name of the infotainment system.

2. Please note and, if necessary, confirm the

messages that appear on the mobile phone
device and on the infotainment system. If
the pairing was successful, the phone data
is saved in the user profile.

3.

Optional:

 confirm the data transfer mes-

sage on the mobile phone device.

Active and passive connection

To use the functions of the telephone interface,
there must be at least one mobile phone device
connected to the infotainment system. If there
are several mobile phone devices connected
to the infotainment system, you can switch be-

tween active and passive connections. To use
the telephone interface with the desired mobile
phone device, establish the active connection
with the infotainment system.

Difference between connection types

The mobile phone device is paired and

connected. The functions of the telephone
interface are performed with the data of
said mobile phone device.

The mobile phone device is paired and

connected. Calls can be managed but the
phone book, messages or other functions
will not be active.

Paired mobile phone devices are stored in the
infotainment system, even if they are not cur-
rently connected.

Connect a mobile phone device

Requirement: the mobile phone device is paired
with the infotainment system.

Bluetooth® is activated on the mobile phone

device.

Establish an active connection

Requirement: several mobile phone devices are
connected to the infotainment system at the
same time.

Select the desired mobile phone device from

the drop-down menu. All other mobile phone
devices are automatically in the passive con-
nection.

User profiles

For each of the paired mobile phone devices an
individual user profile is automatically created.
In the user profile, data from the mobile phone
device is stored, for example, contact details or
settings. A maximum of four user profiles can be
saved in the infotainment system at the same
time.

WARNING

If you perform the pairing while driving, it
could cause an accident or injury.

Perform pairing only with the vehicle at a

standstill.

Note

While the infotainment system is in the

Known mobile phones menu, the wireless
charging function is disabled. When you exit
this menu, the wireless charging function is
activated again.

In the pairing of some mobile phone devi-

ces, a PIN number is shown on the screen of
the mobile phone device. Enter that number
in the infotainment system to complete the
pairing.

Basic and Comfort Telephony

Depending on the equipment, two types of tel-
ephone interface can be used:

CarManuals2.com

Infotainment system

285

Telephone interface

 Basic telephone interface.

 Comfort telephone interface.

Basic telephone interface

The Basic telephone interface uses the Blue-
tooth® HFP profile for transmission. This inter-
face allows the use of telephone functions
through the infotainment system and playback
through the vehicle's speakers.

Comfort telephone interface

Like the Basic telephone interface, the Comfort
telephone interface also uses the Bluetooth®
HFP profile.
The Comfort phone interface can be equip-
ped with the wireless charging function

›››

page 286

.

In order to use the functions of the wireless
charging function, you have to place a suitable
mobile phone device correctly in the storage
compartment. The mobile phone device will
then connect to the vehicle antenna. This im-
proves the reception and sound quality of calls.

Calling and sending messages

Open the telephone interface

Press

HOME >

.

Make a call

Select a phone number to start a call. Different
functions are available for selecting a phone
number:

 Contacts

If a contact has several registered phone num-
bers you have to select one.

Press   and press a number on the list to

start the call.

OR:

 press   and enter the contact name in the

input field to search for it. Press on the contact
to start the call.

OR:

 press a favourite in the telephone interface

main menu to start the call.

 Calls

The telephone interface shows the call list of
the mobile telephone device. Start a call from
the call list.

 Press

 > All

 and press a number on the list

to start the call.

OR:

 press   and filter the call list entries (for

example, missed calls or dialled numbers). In
filtered list, press a number to start the call.

 Dial number

Manually enter a phone number to start a call.
While entering the phone number, contacts that
match that number are shown on the infotain-
ment screen.

 Press   and enter the telephone number.

Press   to start the call.
The last call is dialled by pressing and hold-
ing the   button on the multifunction steering
wheel.

Send messages

Depending on the mobile phone device and the
infotainment system used, you can send and
receive SMS and e-mails through the telephone
interface.

Send an SMS:

1. Press

 > Text message > Enter new mes-

sage

 and enter the message on the screen.

2. Enter the contact you want in the search

bar.

3. To send the message press

OK

.

Send an email:

Press

 > E-mail > Enter new message

 and

enter the message on the screen.

Enter the contact you want in the search bar.

To send the message press

OK

.

CarManuals2.com

286

Infotainment system

1)

It only includes the wireless charge functionality.

2)

Qi technology allows you to charge your mobile phone wirelessly.

Phone book, favourites and speed
dial buttons

In the first connection of a telephone with the
infotainment system, the phone book is saved
in the infotainment system. It may be necessary
to confirm the data transmission on the mobile
phone.
Each time the phone is reconnected, the phone
book is updated.
If conference calls are supported, the phone
book can be accessed during a call. If there is a
saved image for a contact, it can be displayed
in the list next to the entry.

Favourites

A speed dial button can be assigned to a phone
book favourite up to a maximum of six. If there
is a registered photo saved to the contact, it is
shown on the speed dial button.
All speed dial buttons have to be manually
edited and will be assigned to a user profile

›››

page 283

.

Assign the speed dial button

 In the

Favourites

 menu, press the   button,

then open the phone book to select a contact
as a favourite. If the contact has several phone
numbers, press on the number in the list.

Edit the speed dial button

 To edit or delete a favourite contact press on

the icon   in the

Favourites

 menu screen. You

can delete one or more favourites.

Call a favourite

 Press the assigned speed dial button.

Note

Favourites are not updated automatically. If
you change a contact's phone number, you
have to reassign the speed dial button.

Connectivity Box

Fig. 192

Centre console: slot for mobile phone

connection.

The Connectivity Box includes different func-
tions that will help to use your mobile device.
These are:

Wireless Charger

1)

.

Signal amplifier / (

Mobile Signal Amplifier

)

Wireless charger

The Wireless Charger allows mobile devices
with Qi

2)

 technology to be charged without a

cable.
To charge your mobile phone wirelessly:

 Place your mobile device in the middle of

the pad with the screen facing up

›››

Fig. 192

 ,

›››

.

Make sure there are no objects between the
pad and the mobile phone.
The mobile phone will start charging automat-
ically. For further information about whether
your mobile device uses Qi technology, check
your phone's user manual or visit the SEAT
website

Mobile Signal Amplifier

It allows you to reduce radiation in the vehicle
and have better reception.

CarManuals2.com

Infotainment system

287

Telephone interface

For safety reasons, it is recommended that
you pair the system and the mobile using Blue-
tooth® and place it on the Connectivity Box
pad, for the best reception without having to
handle the mobile phone.
To establish a connection with the vehicle's ex-
ternal aerial:

 Place your mobile device in the middle of

the pad with the screen facing up

›››

Fig. 192

 ,

›››

.

Make sure there are no objects between the
pad and the mobile phone.
Your mobile phone will automatically be ready
to make use of the external aerial.

WARNING

Notifications on the screen of the mobile de-
vice can distract the driver’s attention and
increase the risk of a serious accident.

 Only place one suitable mobile device,

with Qi compatibility if applicable. To ensure
that it operates properly, place it without
the protective case and ensure that it has
maximum dimensions (width x length) of 80 x
140 mm (3.15 x 5.512 inches) on the base of
the Connectivity Box as indicated.

If the mobile device is not placed on the

base of the Connectivity Box, in the correct
position, or if its dimensions exceed those
specified, it may not be recognised or may
not charge correctly. Under certain circum-
stances, the infotainment system indicates

that there is a foreign object in the storage
compartment. Using a suitable mobile phone
device and correcting its position can elimi-
nate the fault.

If necessary, remove any objects that may

obstruct the cover’s closing function.

WARNING

 The mobile phone may heat up due to the

wireless charging. Think about this before
you pick it up, and take care when removing
it.

There must be no metallic or other objects

between the mobile phone and the housing,
to prevent the functionality of the Connectiv-
ity Box from being affected.

Note

Your mobile device must support the Qi

inductive charging interface standard for
proper operation.

The charging time and the temperature

vary in accordance with the device used.

The maximum charging capacity is 5 W.

Qi technology does not allow you to

charge more than one mobile device simul-
taneously.

No improvement in reception can be guar-

anteed if there is more than one mobile
phone on the pad.

You are advised to keep the engine running

to guarantee proper wireless charging.

When a telephone with Qi technology is

connected by USB, it will be charged by the
means specified by the manufacturer.

CarManuals2.com

288

Storing objects

Storing objects

Positioning the luggage
and cargo

General information

Placing luggage inside the vehicle safely

It is possible to carry objects and luggage in the
vehicle, in a trailer

›››

page 299

 and on the roof

›››

page 297

. When doing so, please consider

all legal provisions.

Distribute the load in the vehicle as evenly as

possible.

Always place luggage and heavy objects as

far forwards as possible in the luggage com-
partment

›››

.

Take into account the maximum authorised

weight per axle, as well as the maximum au-
thorised weight of the vehicle

›››

page 384

.

Secure the objects to the fastening rings

of the boot using appropriate chains or belts

›››

page 295

.

Also place small objects safely.

If required. raise the rear seat backrest and

lock it.

In vehicles with dynamic headlight range

control, the lights adapt automatically.

Adapt tyre pressure to the load. Take into

account the pressure sticker of the tyres

›››

page 352

.

In vehicles equipped with tyre pressure con-

trol system, adjust to the new load status if nec-
essary

›››

page 362

.

WARNING

Loose or unsecured objects can cause seri-
ous injury in case of sudden manoeuvring
or braking or in case of an accident. Partic-
ularly if the airbag hits them when deploying
and they are thrown across the inside of the
vehicle. Please observe the following rules to
minimise the risk of injury:

Place all objects inside the vehicle safely.

Secure all objects, little and large.

Place the objects in the cabin in such a

way that they can never reach the airbag de-
ployment areas while the vehicle is in motion.

Keep the storage compartments closed at

all times while the vehicle is in motion.

Place the objects in such a way that they

never force any occupant of the vehicle to sit
in an incorrect position.

When transporting objects that take up a

seat, never let anyone use that seat.

Never leave hard, sharp or heavy objects

loose in open storage compartment of the
vehicle, on the cover behind the rear seat or
on the instrument panel.

Remove all hard, sharp or heavy objects

from the fabrics and bags inside the cabin
and store them safely.

WARNING

The transport of heavy object changes vehi-
cle handling and increases braking distance.
Heavy objects that are not properly placed
or secured may cause loss of control of the
vehicle and thus severe injuries.

Never put too much load in the vehicle.

Both the carrying capacity as well as the
distribution of the load in the vehicle have
effects on the driving behaviour and braking
ability.

When transporting heavy objects, the driv-

ing behaviour of the vehicle varies due to the
displacement of the centre of gravity.

Always distribute the load in the vehicle as

evenly and horizontally as possible.

Always place heavy objects in the boot be-

fore the rear axle and as far away from it as
possible.

Objects in the luggage compartment that

are unsecured could move suddenly and
modify the handling of the vehicle.

Adapt your speed and driving style at all

times to suit visibility, weather, road and
traffic conditions.

Accelerate with particular care and cau-

tion.

CarManuals2.com

Storing objects

289

Luggage compartment

Avoid sudden braking and manoeuvres.

Brake earlier than usual.

NOTICE

Electrical wires or, depending on the fea-
tures, the antenna embedded into the rear
windows could be damaged, even irrepara-
bly, if they are in contact with objects.

Note

Straps for securing the load to the fasten-
ing rings are commercially available from
accessory shops.

Luggage compartment

Luggage compartment shelf

Fig. 193

In the boot: shelf of the boot closed.

Fig. 194

In the boot: removing the rear shelf.

Open the rear shelf

 Pull the cover backwards with the handle

›››

Fig. 193



1

 and remove it above the anchor

point (arrows). Move the cover forward care-
fully.

Close the rear shelf

 Pull the cover backwards with the handle

1

and secure it to the anchor point (arrows).

Remove the rear shelf

 If required, open the rear shelf.

Press the support of the cover

›››

Fig. 194



1

in the direction of the arrow and hold it in this
position.

Then lift the cover out.

Remove the cover support

›››

Fig. 194



1

.

Depending on the equipment, once the lug-
gage compartment shelf has been removed,
it can be stored under the boot's floor

›››

page 290

.

Fit the rear shelf

 Place the left side of the rear shelf in the

housing provided in the left side cover.

Press the support of the cover

›››

Fig. 194



1

in the direction of the arrow and hold it in this
position.

Place the cover in the housing provided in the

left side cover.

Remove the cover support

›››

Fig. 194



1

.

Check that the cover is correctly secured.

WARNING

Animals, loose or unsecured or objects car-
ried on the rear shelf can cause serious injury
in case of sudden manoeuvring or braking or
in case of an accident.

Do not leave hard, sharp or heavy objects

or in bags on the rear shelf.

Never transport animals on the rear shelf.

CarManuals2.com

290

Storing objects

WARNING

If the rear shelf is fitted in front of a rear
seat, it may cause severe injuries in the event
of sudden braking or in the event of an acci-
dent.

If the seats of the third row are occupied,

never fit the rear shelf before that row.

WARNING

If driving without the covers of the rear shelf
installed, serious injury may happen in case
of sudden manoeuvring or braking or in case
of an accident.

In vehicles with 7 seats, always place the

covers on the housings of the rear shelf when
it is not fitted.

Store the rear shelf

Fig. 195

Under the boot floor: store the rear

shelf.

Depending on the equipment, once the lug-
gage compartment shelf has been removed, it
can be stored under the boot floor.

Lift the luggage compartment floor

›››

page 292

.

Place the rear shelf in the corresponding

housing

›››

Fig. 195

.

Place the boot floor in its starting position.

If the 12-volt battery is fitted in the boot, do
not store the rear shelf under the luggage com-
partment floor

›››

. If you are going to use the

third row of seats, keep the cover at home.

WARNING

During a sudden driving or braking manoeu-
vre, or in the event of an accident, objects
could be flung though the interior and cause
serious or fatal injuries or damage to the ve-
hicle.

Never leave the rear shelf loose in the lug-

gage compartment.

NOTICE

If the rear shelf is stored incorrectly, it may
cause damages to the electrical system or
the cabin.

When storing the rear shelf, always make

sure it does not touch the 12-volt battery in
the boot.

Placing the third row of seats in the
cargo floor position

Fig. 196

Third row of seats: place the seat in

loading floor position.

Fig. 197

Third row of seats: lift the seat.

The rear seats can be folded down separately
to extend the boot.

CarManuals2.com

Storing objects

291

Luggage compartment

Placing the third row of seats in loading floor
position

 Remove the luggage compartment shelf

›››

page 289

.

Push the head restraint down as far as it will

go

›››

page 113

.

Release the seat belt from both locks to pre-

vent damages to the seat and the seat belt.

Move the seats of the second row fully for-

war

›››

page 111

.

Open the rear lid.

Remove any objects located in the footwell in

front of and behind the seat

›››

.

Remove objects from the space below the

corresponding seat.

Pull the unlocking lever

›››

Fig. 196

 to its rear-

most position to unlock the seat backrest.

Move the backrest down with your hand un-

til it is completely against the frame of the
seat

›››

.

When the seat is in loading floor position,

do not let anyone travel in it (not even a
child)

›››

.

Close the tailgate.

Lifting the seats of the third row

Move the seats of the second row fully for-

ward.

Open the rear lid.

Pull the cord on the backrest of the seat

›››

Fig. 196

 to lift the backrest.

OR:

 lift the back-

rest with your hand from the vehicle interior.

The red mark on the unlock lever

›››

Fig. 196

must disappear.

Make sure that the seat backrest is correctly

engaged by pulling and pushing it.

If required, fit the rear shelf again.

Close the tailgate.

WARNING

Risk of suffering severe head injuries If peo-
ple taller than 1.60 m travel in the third row,
they may receive severe head injuries in the
event of an accident.

Never travel with anyone taller than 1.60 m

on the third row.

When closing the rear lid, always be mind-

ful of the passengers of the rearmost seats.

WARNING

If the rear seats are folded down or lifted
without paying attention or without control,
severe injuries might occur.

Never lower or lift the rear seat backrests

while driving.

Do no trap or damage the seat belt when

raising the rear seat backrests.

When moving the rear seat backrests up

and down, keep your hands, fingers, feet and
other body parts out of the operating area of
the hinges and the locking mechanism of the
seats.

Mats or other objects can be caught in

the hinges of the seat backrests or the seats
themselves. This would cause the backrests
not to be locked correctly in an upright posi-
tion.

For the rear seat belts to offer the neces-

sary protection, the rear backrests must be
properly engaged vertically. If someone is
seated in a seat whose backrest is not prop-
erly engaged they will be thrown forwards,
along with the backrest, during an accident
or a sudden driving or braking manoeuvre.

A red mark on unlock lever

›››

Fig. 196

 in-

dicates that backrest is not engaged. If the
back rest is locked correctly, the mark is not
visible.

When a rear seat or its backrest is folded

down or not correctly engaged, do not let
anyone use that seat (not even a child).

CarManuals2.com

292

Storing objects

NOTICE

Objects placed in the footwell in front of

and behind the rear seats can be damaged
when seats are folded down or lifted. Before
folding down or lifting the seats, remove the
objects.

Any objects located in the footwell behind

the third row of seats may be damaged on
folding or lifting the seats of this row. Before
folding down or lifting the seats, remove the
objects.

Adjustable luggage compartment
floor (5-seater vehicles)

Fig. 198

In the boot: lift the boot floor.

Fig. 199

In the boot: adjust the variable boot

floor.

Open boot floor

 Use the handle

›››

Fig. 198

 to lift the luggage

compartment floor upwards in the direction of
the arrow.

Close boot floor

 Move the floor down carefully and let it

go

›››

.

Adjust the height of the variable boot floor

Depending on the features, the height of the
boot floor can be adjusted.

If necessary, release the net bag and remove

the attachment or support straps if applicable.

Lift the boot floor and pull it backwards to

release it from the side guides of the luggage
compartment

›››

Fig. 199

  .

Place the floor on the guides of the desired

height and move it forwards as far as possible

›››

Fig. 199

  .

NOTICE

Do not tug the boot floor suddenly when

opening or let it fall down when closing. Oth-
erwise, the lining and the floor of the boot
could be damaged.

The maximum weight that can be loaded

on the luggage compartment variable floor
in the top position is 125 kg.

Note

Depending on the features, there are stor-

age compartments for small objects under
the boot floor.

SEAT recommends the use of fastening

straps to secure objects to retaining rings.

CarManuals2.com

Storing objects

293

Net partition

Luggage compartment floor (7-
seater vehicles)

Fig. 200

In the boot: lift the boot floor.

Open boot floor

Grab the boot floor by the cor

›››

Fig. 200

 and

lift it in the direction of the arrow and remove it.

Close boot floor

Place the boot floor on the support and care-

fully lower it.

NOTICE

Do not let the luggage compartment floor

fall when closing it. Always carefully guide
it downward in a controlled manner. Other-
wise, the lining and the floor of the boot
could be damaged.

The maximum weight that can be loaded

on the luggage compartment variable floor
in the top position is 125 kg.

Net partition

Unfolding and folding the net parti-
tion

Fig. 201

Deploying the net partition.

Fig. 202

Folding in the net partition.

Before fitting the net partition in the vehicle it
must be unfolded.

Fold out the net partition

 Take out the partition net from the corre-

sponding bag and unroll it.

Extend the cross rods

›››

Fig. 201



1

 and

2

of the net in the direction of the arrows until a
“clicks” is heard.

Folding in the net partition

 Press on the release button

›››

Fig. 202



1

and bend the cross rod in the direction of the
arrow with the button pressed.

Press on the release button

›››

Fig. 202



2

and bend the cross rod in the direction of the
arrow with the button pressed.

Fold in the net partition and store it in its bag.

Store the net partition safely in the vehicle.

CarManuals2.com

294

Storing objects

Using the net partition

Fig. 203

Net partition fitted.

The purpose of the net partition is to prevent
the items in the boot from moving into the cabin,
e.g. in the event of sudden braking.

Fitting the net partition

The partition net can be fitted behind the rear
seat or, depending on the features, behind the
front seats with the second row of seats low-
ered.

If required, remove the rear shelf

›››

page 289

.

Folding out the net partition.

Hook the net partition to the left-hand side

roof housing

›››

Fig. 203



A

.

Be sure to pull the cross rod down past the up-
per position.

 Hook in the net partition on the rear right-

hand side roof housing by pressing on the bar

›››

Fig. 203



A

.

 Secure two hooks of the partition net to the

fastening rings of the boot

›››

Fig. 203



B

 and

tighten the straps firmly.

Removing the net partition

 If required, remove the rear shelf.

Loosen the straps from the net partition.

Release the net hooks from the fastening

rings

›››

Fig. 203



B

.

Unhook the net partition on the right-hand

side roof support

›››

Fig. 203



A

 by pressing

on the cross rod.

Unhook the net partition from the left-hand

side roof housing.

Fold in the net partition.

If required, fit the rear shelf.

WARNING

In order to ensure the proper functioning of
the luggage restraint systems (backrests to-
gether with the net partition), place the sec-
ond row of seats in their rearmost position to
avoid the possibility of the load on top mov-
ing forward. Risk to vehicle occupants.

WARNING

During a sudden driving or braking manoeu-
vre, or in the event of an accident, objects
could be flung though the interior and cause
serious or fatal injuries.

Check whether the cross rods are cor-

rectly engaged.

Always secure objects, even when the net

partition is properly assembled.

There should be nobody behind the net

partition when the vehicle is moving.

NOTICE

If the net partition is secured incorrectly or
to incorrect points, this may damage the ve-
hicle.

CarManuals2.com

Storing objects

295

Luggage compartment equipment

Luggage compartment
equipment

Fastening rings

Fig. 204

In the luggage compartment:

fastening rings.

There are fastening rings

›››

Fig. 204

 on the

front and rear of the boot to secure loose
objects and luggage with fastening belts and
cords.

WARNING

If unsuitable or damaged belts or retaining
straps are used, they could break in the
event of braking or an accident. Objects
could then be launched across the passen-
ger compartment and cause serious or fatal
injuries.

Always use belts or straps that are suitable

and in good condition.

Tighten the belts and straps in a cross

layout over the load placed on the boot
floor and secure them to the fastening rings
safely.

Never exceed the maximum tensile load of

the fastening rings when securing objects.

Make sure that, particularly for flat ob-

jects, the upper edge of the load is higher
than the fastening rings.

Depending on the features, take into ac-

count the instruction panels on the boot on
how to place the load.

Never secure a child seat to the fastening

rings.

Note

The maximum tensile load that the fasten-

ing rings can support is approx. 3.5 kN.

Belts, straps and securing systems for the

appropriate load can be obtained from spe-
cialised dealerships. SEAT recommends visit-
ing a SEAT dealership for this.

Net bag

Fig. 205

In the boot: net bag hooked up at

floor level.

The luggage compartment prevents light lug-
gage from moving. The net bag has a zip and
can be used to store small objects.

Hooking the net bag into the luggage com-
partment floor

If necessary, the front eyes must be unfolded
first

›››

page 295

.

Secure the net hooks to the fastening rings

›››

Fig. 205

 ,

›››

. The bag zip should be

facing upwards.

Removing the net bag

The hooked up net bag is taut

›››

.

 Release the net bag from the fastening rings.

Store the net bag in the luggage compart-

ment.

CarManuals2.com

296

Storing objects

WARNING

To secure the elastic net bag on the fasten-
ing rings of the boot it must be stretched out.
Once hooked up it is taut. If the net bag is
hooked up or unhooked incorrectly the hooks
could cause injuries.

 Always secure the bag hooks properly so

that they do not suddenly release from the
fastening rings when hooking or unhooking
them.

On hooking or unhooking them, protect

your eyes and face in case the hooks are
released suddenly.

Always hook up the net bag hooks in the

described order. If a hook comes loose

Bag hooks

Fig. 206

In the boot: retaining hooks.

There may be hooks for hanging bags on both
sides of the luggage compartment

›››

Fig. 206

.

The retaining hooks have been designed to se-
cure light shopping bags.

WARNING

Never use the hooks to hang luggage or
other objects. In case of sudden braking or
an accident, the hooks could break.

NOTICE

Each hook is designed for a maximum load of
2.5 kg.

Trapdoor for transporting long ob-
jects

Fig. 207

Rear seat backrest: opening the

tailboard for long objects.

Depending on the features, on the rear seat,
behind the central armrest, there is a tailboard
for transporting long items in the interior, such
as skis.

Opening the tailboard for long items

Press the unlocking button

›››

Fig. 207



1

 and

fold the tailboard forwards

›››

.

Open the rear lid.

Insert the long objects through the tailboard

from the luggage compartment.

Secure the objects with the seat belt firmly.

Close the tailgate.

Closing the tailboard for long items

Lift the seat back and press it firmly into the

lock until it engages correctly.

WARNING

Serious injuries can be caused if the tail-
board for long items is lowered or lifted with-
out due care and attention.

Never lower or lift the tailboard while driv-

ing.

Do no trap or damage the seat belt when

raising the tailboard.

When lowering or lifting the tailboard, keep

your hands, fingers, feet and other body
parts out of its path.

CarManuals2.com

Storing objects

297

Roof carrier

When the tailboard is lowered or is not

properly engaged nobody else can travel
in the corresponding seats, particularly chil-
dren.

Roof carrier

Introduction

The vehicle roof has been designed to optimise
aerodynamics. For this reason, cross bars or
conventional roof carrier systems cannot be
secured to the roof water drains.
As the roof water drains are integrated in the
roof to reduce air resistance, only SEAT-ap-
proved cross bars and roof carrier systems can
be used.

Cases in which cross bars and the roof car-
rier system should be disassembled.

 When they are not used.

When the vehicle is washed in a car wash.

When the vehicle height exceeds the maxi-

mum height, for example, in some garages.

WARNING

 Always secure the load properly using

belts or retaining straps that are suitable and
in a good condition.

Bulky, heavy, long or flat loads have a neg-

ative effect on aerodynamics, the centre of
gravity and driving performance.

Avoid sudden braking and manoeuvres.

Adapt your speed and driving style at all

times to suit visibility, weather, road and
traffic conditions.

NOTICE

 Remove the cross bars and the roof carrier

system before entering a car wash.

Vehicle height is increased by the installa-

tion of cross bars or a roof carrier system
and the load secured on them. For this pur-
pose, check that your vehicle's height does
not surpass the headspace limit, for exam-
ple, for underpasses or for entering garage
doors.

Cross bars, the roof carrier system and the

load secured on them should not interfere
with the roof aerial or hamper the path of the
panoramic sun roof and the rear lid.

On opening the rear lid make sure that it

does not knock into the roof load.

For the sake of the environment

When cross bars and a roof carrier system
are installed, the increased air resistance
means that the vehicle uses more fuel.

Securing the crossbars and the roof
carrier system

Fig. 208

Attachment points for the roof

railings for the roof carrier

The crossbars are the basis of a series of spe-
cial roof carrier systems. For safety reasons,
special fixtures must be used to safely transport
luggage, bicycles, skis, surf boards or boats on
the roof. Suitable accessories can be acquired
at SEAT dealerships.

CarManuals2.com

298

Storing objects

Always secure the crossbars and the roof car-
rier system properly. Always take the assembly
instructions that come with the crossbars and
the roof carrier system in question into account.

Installing the bars

The crossbars are assembled on the roof
railings. The distance between crossbars

›››

Fig. 208



A

 should be between 75 and

90 cm and the distance between the crossbars
and the brackets of the roof railings

B

 must be

15 cm.

WARNING

Incorrect attachment and use of the cross-
bars and the roof carrier system may cause
the whole system to detach from the roof
and cause an accident and injuries.

 Always take the manufacturer assembly

instructions into account.

Check threaded joints and attachments

travelling and if necessary tighten them after
you have travelled a short distance. When
making long trips, check the threaded joints
whenever you stop for a rest.

Do not modify or repair the crossbars or

roof carrier system.

Note

Always read the assembly instructions that
come with the crossbars and the roof carrier
system carefully and keep them in the vehi-
cle.

Loading the roof carrier system

The load can only be secured if the crossbars
and the roof carrier system are properly instal-
led

›››

.

Maximum authorised cargo on the roof

The maximum permissible roof load is

75 kg

.

This figure comes from the combined weight
of the roof carrier, the cross bars and the load
itself on the roof

›››

.

Always check the weight of the roof carrier
system, the cross bars and the weight of the
load to be transported and weigh them if nec-
essary. Never exceed the maximum authorised
roof load.
If you are using cross bars and a roof carrier
with a lower weight rating, you will not be able
to carry the maximum authorised roof load. In
this case, do not exceed the maximum weight
limit for the roof carrier which is listed in the
fitting instructions.

Distributing a load

Distribute loads uniformly and secure them cor-
rectly

›››

.

Check attachments

Once the cross bars and roof carrier system
have been installed, check the bolted connec-
tions and attachments after a short journey and
subsequently with a certain frequency.

WARNING

 Never exceed the maximum authorised

load on the roof and on the axles or the ve-
hicle's maximum authorised weight.

Never exceed the load capacity of the

cross bars and the roof carrier system, even
if the maximum authorised roof load has not
been reached.

Secure heavy items as far forward as

possible and distribute the vehicle load uni-
formly.

WARNING

If the load is loose or not secured, it could
fall from the roof carrier system or cause ac-
cidents and injuries.

Always use belts or retaining straps that

are suitable and in a good condition.

CarManuals2.com















Content      ..     7      8      9      10     ..
