Parking and manoeuvring

235

Trailer Assist

Automatic brake operation

The trailer manoeuvre assistant helps the driver
by automatically operating the brakes in cer-
tain situations.
The driver is responsible for braking on
time

›››

.

The brakes may be applied automatically and
the function deactivated in the following situa-
tions:

A certain speed is exceeded.

The steering wheel is grabbed. The vehicle

brakes automatically until it stops.

If the button   is pressed during the manoeu-

vre or the driver’s door opens.

WARNING

The quickly turning steering wheel can cause
serious injuries.

Do not hold the steering wheel during the

manoeuvre until the system requests it.

Exception: If a dangerous situation occurs,

intervene and take over the steering.

WARNING

Never allow the automatic operation of
brakes to lead you to take any risk that com-
promises safety. The system is not a replace-
ment for driver awareness.

 The manoeuvre assist system is subject

to certain limitations inherent to the system.
In certain situations, the automatic braking
intervention may only work in a limited way
or not work at all.

Always be ready to use the brakes your-

self!

Automatic brake operation ends after 1.5

seconds approx. if the vehicle is stopped. Af-
ter this, brake the vehicle yourself.

Note

The exterior mirrors cannot be adjusted while
the assistant is active. The saved setting
for the passenger’s mirror can be activated

›››

page 130

.

Troubleshooting

Camera with no visibility, fault message, the
system disconnects

 Clean the camera or remove possible adhe-

sives or accessories from it

›››

page 371

.

Check for visible damage.

The system behaves differently than expec-
ted

There can be several causes:

The camera is dirty

›››

page 371

. In addi-

tion to dirt and snow, camera visibility can be
reduced by detergent residue or any type of
coating.

The system requirements must be met

›››

page 233

.

The camera is covered with water.

The vehicle has some type of damage in the

camera area, e.g. due to a parking impact.

The field of view of the camera is blocked by

an accessory, e.g. a bicycle carrier system.

Changes have been made to the paint in the

camera area and structural modifications have
been made, e.g. to the front part of the vehicle
and the running gear.

Solution for all cases

 Temporarily disconnect the system.

Check if one of the causes indicated above

has occurred.

Once the source of the problem has been

eliminated, the system may be reconnected.

If the system still behaves unpredictably,

have it checked by a specialised workshop.

CarManuals2.com

236

Parking and manoeuvring

1)

It is only displayed if the vehicle is equipped with a parking system.

Rear cross traffic alert
(RCTA)

How it works

Fig. 174

Diagram of the parking assistant:

detected area around the vehicle that is driving
off.

Park Assist uses the radar sensors on the rear
bumper

›››

page 183

 to monitor traffic cross-

ing behind the vehicle as it reverses out of a
parking bay, or as it is being manoeuvred, for
example in very low visibility conditions.
When the system detects a relevant vehicle on
the road that is approaching the rear of the ve-
hicle

›››

Fig. 174

, an acoustic alarm may sound

if the relevance so requires it.
In addition to the acoustic alarm, the driver is
also informed by means of a visual signal on
infotainment system display. This signal is dis-

played in the form of a red strip at the back
of the image of the vehicle on the infotainment
system screen. This strip displays the side of the
vehicle towards which traffic is approaching in
transverse direction

1)

.

Automatic braking to reduce damages

›››

page 212

.

Connecting and disconnecting

The rear cross traffic alert can be switched on
and off by accessing the

Assistants

 menu on

the dash panel display using the steering wheel
controls. If the vehicle is equipped with a multi-
function camera, it can also be accessed by
means of the assistants systems key located on
the main beam headlight lever.
When the vehicle is restarted, the last adjust-
ment in the system will remain active.

Trailer mode

The rear cross traffic alert will be automatically
deactivated and it will be impossible to activate
them if the tow hitch is electrically connected
to a trailer or other similar object. As soon as
the driver starts driving, a message appears on
the instrument cluster screen indicating that the
assistant is deactivated.

Once the trailer is uncoupled from the vehicle,
the assistant will return to its initial state prior
to the moment when the trailer was electrically
connected.
If the tow hitch is not factory fitted, then the rear
cross traffic alert will have to be deactivated
manually when driving with a trailer.

WARNING

The smart technology incorporated into the
rear cross traffic alert cannot overcome the
limits imposed by the laws of physics; it only
works within the limits of the system. The
parking assistant function should not tempt
you into taking any risks. The system is not a
replacement for driver awareness.

The system should never be used in limi-

ted visibility conditions or complicated traf-
fic, e.g., in high-traffic areas or when crossing
multiple lanes.

Be sure to always be aware of the vehicle's

surroundings, since the system often fails
to detect things such as bicycles or pedes-
trians.

The rear cross traffic alert itself will not

brake the vehicle to a complete stop.

CarManuals2.com

Practical equipment

237

Storage compartment

Practical equipment

Storage compartment

Introduction

Use the storage compartments only for small or
light items.

WARNING

Objects inside the vehicle that are not se-
cured could be thrown across the cabin in
the event of sudden braking or manoeuvring.
This may cause severe injuries as well as loss
of control of the vehicle.

Do not carry animals or sharp, hard or

heavy items in open storage compartments
of the vehicle, on the dashboard or on the
cover behind the rear seats, or inside pieces
of clothing or bags inside the vehicle.

Keep the storage compartments closed at

all times while the vehicle is in motion.

Do not hang garments weighing more than

2.5 kg (approx. 5.5 lb) on the vehicle’s coat
hooks. Never leave heavy, hard or sharp ob-
jects in the pockets of these pieces of cloth-
ing.

WARNING

If you leave lighters inside the vehicle, they
might be damaged or lit inadvertently. This
could lead to severe burns and damage to
the vehicle.

Before moving a seat, make sure there are

no lighters in the moving part area of the ve-
hicle.

Before closing a storage compartment,

make sure there are no lighters in the closing
area.

Never leave a lighter inside a storage com-

partment or any other surface of the vehicle
as it could ignite due to the high tempera-
tures on such surfaces, particularly during
the summer.

NOTICE

Do not store heat- or cold-sensitive ob-

jects, food or medicines in the cabin. Heat
and cold could damage them or render them
useless.

Objects made from transparent materials

left inside the vehicle, such as glasses, mag-
nifying glasses or transparent suction pads
stuck to the windows can concentrate sun-
light and damage the vehicle.

storage compartment on the driver's
side

Fig. 175

On the driver side: storage

compartment.

Opening:

 Pull the handl

›››

Fig. 175

.

Closing:

 Press the cover upwards until it clicks

into place.

CarManuals2.com

238

Practical equipment

1

2

1

2

Glove compartment

Fig. 176

On the passenger side: glove

compartment.

Fig. 177

On the passenger side: glove

compartment open.

Key t

›››

Fig. 176

Glove compartment
Storage net

Key t

›››

Fig. 177

Air diffuser regulator
On-board documentation

Opening and closing the glove compart-
ment

Opening:

Pull the handl

›››

Fig. 176

 and open

the glove compartment.

Closing:

 Press the glove compartment up-

wards.

Glove compartment cooling

With the AC on, cool air can be directed to-
wards the inside of the compartment. Turn the
air vent to open and close it.

WARNING

If the glove compartment is left open, the risk
of causing severe injuries in the event of an
accident, sudden braking or manoeuvring in-
creases.

Always keep the glove compartment

closed while the vehicle is in motion.

NOTICE

For structural reasons, some vehicle versions
will have gaps behind the glove compart-
ment (for instance, behind the compartment
for on-board documentation) into which
small objects may fall. This could lead to
strange noises and damage to the vehicle.
You should therefore not keep very small ob-
jects in the glove compartment.

CarManuals2.com

Practical equipment

239

Storage compartment

Drink holder

Fig. 178

In the front part of the centre console:

 cup holder (variant 1);   cup holder (variant

2).

Fig. 179

In the rear central armrest: drink

holder.

The storage compartments of the driver and
passenger doors contain a bottle holder.
Depending on the equipment, there are two
drink holders in the front part of the centre con-
sol

›››

Fig. 178

.

Drinks holder (variant 1).

Opening:

 Move the lid backwards.

Closing:

 Move the lid forwards.

To adapt the drink holder to the size of
the container, press the corresponding button

›››

Fig. 178



1

 . The securing ring

2

 opens.

When you are not using the drink holder any
more, press the corresponding ring 2 in the op-
posite direction to the arrow until it locks.

Drinks holder in the rear central armrest

Use:

 Lower the central armrest

›››

Fig. 178

.

When the drink holder is no longer in use, lift the
armrest again.

WARNING

Incorrect use of the bottle holders may
cause injuries.

Never put hot drinks in the drink holders.

In the event of sudden braking or an acci-
dent while driving, hot beverages in the bot-
tle holders might spill and cause burns.

Ensure that no bottles or other objects are

dropped in the driver footwell while driving,
as they could get under the pedals and ob-
struct their working.

Never place glasses, food or other heavy

objects drink holders. These heavy objects
may be thrown across the cabin in the event
of an accident and cause serious injuries.

WARNING

Closed bottles may explode inside the vehi-
cle due to cold or heat.

Never leave closed bottles in the vehicle

if the temperature inside is very high or very
low.

NOTICE

Do not leave open cans in the drink holders
when the vehicle is in motion. If the drink is
spilled (e.g. due to sudden braking) it may
damage the vehicle and its electrical sys-
tem.

CarManuals2.com

240

Practical equipment

Note

The inside elements of the drink holders can
be extracted for cleaning.

Storage compartment in the roof
console (glasses case)

Fig. 180

On the roof console: compartment for

glasses.

Opening:

 Press and release the button

›››

Fig. 180

.

Closing:

 Press the cover upwards until it clicks

into place.

Note

For the interior monitoring to work correctly,
the storage compartments must be closed
when locking the vehicle.

Storage compartment under front
seats

Fig. 181

Storage compartment under the right

front passenger seat.

Opening:

 Press the tab on the drawer handle

and take the drawer out.

Closing:

 Push the drawer under the seat until it

engages.

WARNING

If the drawer is left open, it could prevent use
of the pedals. This may cause serious acci-
dents and injuries.

Always keep the drawer closed while the

vehicle is in motion. Otherwise, the drawer
and any objects in it could fall into the driv-
er's footwell and obstruct the pedals.

NOTICE

The drawer can contain 1.5 kg at most.

Other object holders

You will find more object holders, compart-
ments and supports in other parts of the vehi-
cle:

 In the centre console.

In the front central armrest.

Other storage compartments are found in the

rear seat, to the left and the right of the seats.

In the backrests of the front seats, storage

pockets.
The Apple® iPod adapter or the USB port may
be housed in the storage compartment of the
front centre armrest.

There are hangers on the struts of the doors
and the rear.

CarManuals2.com

Practical equipment

241

Power sockets

1

2

3

WARNING

Hanging clothes may decrease the driver's
visibility, which may cause serious accidents
and injuries.

 Always hang clothes from hangers in such

a way that the driver's visibility is not affec-
ted.

Only hang light pieces of clothing from the

hangers of the vehicle. Never leave heavy,
hard or sharp objects in the pockets of these
pieces of clothing.

Do not use clothes hangers to hang up the

clothing, as this could interfere with the func-
tion of the head-protection airbags.

NOTICE

Do not place overly large objects in the
pockets on the front seat backrests (e.g. bot-
tles) or objects with sharp edges. Risk of
damage to the pockets and the upholstery.

Power sockets

Introduction

Electrical equipment can be plugged in to the
vehicle's sockets.
The devices must be in a perfect state of repair.
Do not use defective devices.
The 12 volt power socket will only work with the
ignition on.

WARNING

Improper use of the sockets or electrical de-
vices could lead to a fire and cause serious
injuries.

Please ensure that children are never left

unsupervised inside the vehicle. The sockets
and the devices connected to them can be
used when the ignition is switched on.

If electrical devices overheat, switch them

off immediately and disconnect them from
the mains.

NOTICE

To avoid damaging the electrical system,

never connect electrical devices that sup-
ply power, such as solar panels or battery
chargers, to 12-volt sockets to charge the 12-
volt battery.

Only use electrical devices that comply

with the applicable electromagnetic com-
patibility directives.

To prevent voltage fluctuations from caus-

ing damage, unplug any connected electri-
cal devices before switching the ignition on
and off.

Never connect electrical devices that con-

sume more than the specified power to a 12
volt socket. Exceeding the maximum power
consumption could damage the vehicle's
electrical system.

Observe the instruction manuals of electri-

cal devices!

Note

The use of electrical appliances with the

engine switched off will cause the 12-volt
battery to discharge.

Uninsulated devices can interfere with the

radio, infotainment system and the vehicle’s
electronic system.

Vehicle power sockets

Fig. 182

Vehicle 12 volt socket.

›››

Fig. 182

12-volt sockets on the centre console.
12-volt sockets in the luggage compart-
ment.
12-volt USB sockets at the rear of the con-
sole, between the front seats.

CarManuals2.com

242

Practical equipment

Make sure that the maximum power of the
sockets is not exceeded. The power consump-
tion of the devices is shown on the type plate of
the devices.
The continuous output of all of the vehicle’s 12-
volt sockets is 120 watts in total.
When connecting two or more electrical devi-
ces at the same time, make sure that their total
consumption never exceeds 190 watts.

USB power sockets

Depending on the equipment and the country,
the vehicle may also have USB connections

ex-

clusively for charging or as a power socket



›››

Fig. 182



3

.

These USB ports are located at the rear of the
console, between the front seats . These con-
nectors can work at a maximum power of up to
10.5 W per port.

NOTICE

If the 12-volt socket is used at full power for
longer than the specified time, the fuse may
blow.

Never use the 12 volt socket at full power

for more than 10 minutes.

In the case of full power, use a single 12-

volt socket.

230 volt power socket

Fig. 183

In the left hand side of the luggage

compartment: 230 volt power socket.

With the engine running, the power socket acti-
vates automatically as soon as a connector is
plugged in. If there is enough power available,
the socket can still be used while the engine is
off

›››

.

Maximum power consumption is 150 watts (300
watts - maximum 2 minutes).

Connect an electrical device:

 Open the cover

and insert the plug into the power socket as far
as possible to unlock the built-in child lock. The
socket only supplies power once the child lock
is unlocked.

LED on the power socket

›››

Fig. 183

 (arrow)

Steady green light:

 The childproof lock is unlocked. The socket is

ready to operate.

Flashing green light:

 The ignition is switched off, but there is

enough power available to continue supplying
the socket with current for a maximum of 10
minutes. If the connector is unplugged before
this time elapses, the socket is disconnected
and cannot be used again until the ignition is
switched on again.

Flashing red light:

 There is an anomaly, e.g. disconnection due

to a current surge or overheating.

Disconnection due to overheating

When the temperature exceeds a certain value,
the 230 volt socket inverter is automatically dis-
connected. The disconnection prevents over-
heating when the power consumption of the
connected devices is excessive or the ambient
temperature is very high. The 230-volt power
supply can be used once again after a cool-
ing time. First unplug the connector of the con-
nected device and then plug it back in again.
This prevents the electrical device from being
switched on again if this is not wanted.

CarManuals2.com

Practical equipment

243

Power sockets

WARNING

The electrical system is under high voltage!

 Do not spill liquids onto the socket.

Do not plug adapters or extension cords

into the 230 volt power socket. Otherwise,
the integrated child lock will be unlocked
and the power socket will operate.

Do not insert conductive objects (a knitting

needle, for example) into the 230 volt power
socket.

NOTICE

230 volt power socket:

Do not leave devices or connectors that

are too heavy (e.g. a transformer) hanging
directly from the power socket.

Do not connect neon lamps.

Only connect devices to the socket if the

device and socket voltage match.

The built-in overload disconnect function

prevents any electrical devices that require
a high start-up current from turning on. In this
case, unplug the electrical device's power
supply and re-try the connection after about
10 seconds.

Note

Some appliances may not work properly
when connected to the 230 volt sockets due
to a lack of power (watts).

CarManuals2.com

244

Data transmissions

Data transmissions

SEAT CONNECT

Introduction

To use it, SEAT CONNECT must first be activa-
ted online by entering into a SEAT CONNECT
contract with SEAT, S.A. and is subject to a tem-
porary use limitation depending on the country.
Both the SEAT CONNECT service portfolios of-
fered by SEAT and individual services can be
modified, cancelled, deactivated, reactivated,
renamed and extended, even without prior noti-
fication.
In https://my.seat you can create the user ac-
count, see the description of services and more
information.
The execution and availability of the SEAT
CONNECT services and service portfolios may
vary depending on the country, as well as the
vehicle, its equipment and connectivity.
SEAT CONNECT's voice recognition or search
technology does not recognise or offer results
for all words.
There are SEAT CONNECT services for which
registration is mandatory and others for which it
is not mandatory.

Description of services

Before running SEAT CONNECT services, read
and take into account the description of the
corresponding services. Descriptions are upda-
ted non-periodically and are available online at
https://my.seat.

Always use the most up-to-date version of

the corresponding service description.

WARNING

In areas with insufficient mobile phone and
GPS coverage, emergency calls and phone
calls will not be connected and data cannot
be transmitted.

Change location if possible.

NOTICE

The vehicle may be damaged by factors out-
side the control of SEAT, S.A. These damaged
can include:

Misuse of mobile terminals

Data loss during transmission.

Unsuitable or defective third party appli-

cations.

Malicious software on data storage devi-

ces, computers, tablets or mobile phones.

Services portfolio

The initial service assignment shown here rep-
resents the maximum possible volume. The
maximum possible volume is only available on
a few vehicle models. During the useful life of
the vehicle, you can change the assignment
shown here.
After activating the service management in the
infotainment system, you can check whether
services are available to the vehicle and what
services they are

›››

page 248

.

In some countries and in the event of a contract
renewal, the services offered may be combined
differently than indicated here. They may also
vary depending on the year of production of
the vehicle. The services mentioned correspond
to

SEAT CONNECT Gen3

 (third generation).

SEAT CONNECT services and functions that
do not require activation

The following services also work without the
activation of SEAT CONNECT:

Public emergency call service.

Privacy mode.

Legal.

SEAT CONNECT services

The SEAT CONNECT services are:

Public emergency call

 Roadside assistance call

CarManuals2.com

Data transmissions

245

SEAT CONNECT

 Customer support

Service appointment planning

Online system update

Customisation

Activating SEAT CONNECT

Private mode (deactivation of services)

Delete user / Reset factory settings

Remote independent heating

Remote opening

Horn and turn signals

Vehicle status incl. doors and lights

Driving data

Vehicle status report

Anti-theft alarm warning

Zone warning

 Speed warning

Online map update

Search for points of interest

Petrol stations

 Online traffic information

Parking lots

Online infotainment system update

Online route calculation

Information on risks

Dictation

Online radio

Online media

Online route import

Online destination import

Remote auxiliary ventilation

Parking position

Privacy mode

Legal

SEAT CONNECT services for hybrid vehicles

Available only in electric and hybrid vehicles.
The included services are all the SEAT CON-
NECT services in the previous section plus:

 Remote air conditioning

 Electrical power manager

 Departure times

SEAT CONNECT individual options

 In-Car Applications. These applications can

be purchased and installed directly in the info-
tainment system through the In-Car store.

Full Link.

Data package. Pay per use data rates for the

use of online functions, for example, 2 GB per
month.

Note

The public emergency call service is avail-

able regardless of whether the infotainment
system is logged in.

 Customisation and purchase of In-Car ap-

plications require logging into infotainment
system, but the activation of the vehicle in a
SEAT CONNECT account is not necessary.

Activation of SEAT CONNECT and S-
PIN

The following steps are necessary for the ac-
tivation of SEAT CONNECT (including registra-
tion):

 Create a user account at https://my.seat or

directly through the infotainment system in the
User Management menu.

Place the SEAT CONNECT order and activate

it.

 Add the vehicle to your user account.

Prove ownership.

Prove your identity. It is only necessary if you

are to run SEAT CONNECT services relevant to
security.

You can activate it at https://my.seat or di-

rectly through the infotainment system. To ac-
tivate it through the infotainment system, pro-
ceed as follows:
9.2”

HOME > Manage users > Become

primary user.

CarManuals2.com

246

Data transmissions

8.25”

MENU > Settings > SEAT Connect

> Register.

Follow the rest of the indications and the infor-
mation shown in the infotainment system. Dur-
ing activation, you may be asked to create an
S-PIN.

Update option

9.2” Infotainment

yes

8.25” Infotainment

yes

SEAT CONNECT portal

yes

SEAT CONNECT application

yes

More information at https://my.seat/faqs

S-PIN

The S-PIN is a sequence of several digits, which
can be selected when completed the SEAT
CONNECT registration.
When creating the S-PIN, avoid easy-to-guess
number sequences and known dates of birth.
You can change the S-PIN in the SEAT CON-
NECT user account in “Account settings”.
The S-PIN is necessary, for example, to protect
your user profile or to run a SEAT CONNECT
service relevant to the security of your vehicle.
You must manage this S-PIN with absolute con-
fidentiality.
If you reveal the S-PIN to third parties, for secur-
ity reasons you must change it immediately.

Ownership and identity accredita-
tion

Depending on the Infotainment system, the
ownership accreditation method will be the 2-
key method or the registration code method.

9.2” Infotainment system

To become a main user and thus prove own-
ership of the vehicle, you need both of the ve-
hicle’s physical keys. Ownership accreditation
takes place in the vehicle during registration or,
if you already have a SEAT CONNECT user ac-
count, you must log in through the infotainment
system and then go to

User management

.

Switch on the ignition and the infotainment

system.

In the infotainment system, register in SEAT

CONNECT.

Or:

 open the menu

Manage users > Settings

> Become primary user

 and follow the instruc-

tions.

Press the unlock button on the first vehicle

key.

 Press the unlock button on the second vehi-

cle key.

8.25” Infotainment system

To become the main user and therefore ac-
credit ownership of the vehicle, you will need
the registration code found on the SEAT website
and in the APP after linking the vehicle to your

account (

My Garage > Add Vehicle > Accept

terms and conditions and SEAT privacy pol-
icy

). Ownership is accredited inside the vehicle.

Go to

Vehicle settings > SEAT CONNECT >

Registration

 and enter the pairing code shown

on the website or in the App.
Once the infotainment system has processed
the orders by radiofrequency, the accreditation
of the ownership will have been completed. You
can control the current status in the SEAT CON-
NECT portal.

How is ownership accredited?

9.2” Infotainment

2-Key method.

8.25” Infotainment

Pairing code.

SEAT CONNECT portal

No, it is not possible

SEAT CONNECT appli-
cation

No, it is not possible

Identity accreditation (SEAT Ident)

Identity accreditation must be done before you
can use SEAT CONNECT services that are rele-
vant to security, such as the “Remote Opening”
service. Identity accreditation can be done in
two ways:

 In person at the SEAT dealership.

You can find more information about SEAT

Ident on the SEAT CONNECT portal at https://
my.seat.

CarManuals2.com

Data transmissions

247

SEAT CONNECT

Legal provisions

During the use of SEAT CONNECT services, in-
formation is transferred and processed online
through the vehicle. Such data can also provide
(at least indirectly) information about the driver
in question, for example, driving behaviour and
location. As a contracting party in the SEAT
CONNECT contract with SEAT, S.A., you must
ensure that when your vehicle is used by other
drivers (for example, family or friends), data
protection and personal rights are respected.
Therefore, you must inform drivers in advance
that the vehicle transfers and receives data on-
line, and that you can access such data.
Not taking into account this obligation to inform,
can infringe certain rights of the occupants.
Users can manage data sending and transfers
through the privacy mode at any time. More
information at: https://my.seat/faq.

Follow-up services: ask all occupants

The follow-up services need geographical and
vehicle data to determine whether the vehicle is
being used within defined speed ranges, where
it has been parked or if it is being used in an es-
tablished geographical area. This information is
displayed on the SEAT CONNECT portal and in
the SEAT CONNECT app.

Therefore, before moving off, ask all the vehi-
cle occupants if they agree with the activated
services. If they do not, deactivate the service in
question (if possible) or do not allow the occu-
pants to use the vehicle.

GPS tracking: marking

If the vehicle has a factory-assembled control
unit that transmits the its current geographical
position and speed, the vehicle usually has this
GPS marking (e.g., on the roof console). The
absence of the marking on the vehicle does not
guarantee that the control unit does not trans-
mit the vehicle’s current geographical position
and speed.

Personal information

SEAT protects your personal data and only
uses them, as long as the law allows it or you
have given your consent on the occasion of a
use. You will find detailed information on data
processing in relation to SEAT CONNECT serv-
ices in the Privacy Policy, which you can ac-
cess in its corresponding current version on the
SEAT website.

Permanent transfer of the vehicle

If another person has left you the vehicle for
permanent use (for example, if you buy a used
vehicle), SEAT CONNECT may already be acti-
vated and the previous user still has the possi-

bility of accessing the data registered through
SEAT CONNECT and control certain functions
of your vehicle.
In the infotainment system you can check if
your vehicle is assigned to a person as the
main user. In this case, you can register yourself
as the main user of the vehicle and thus auto-
matically delete the previous main user. Alter-
natively, through the infotainment system you
can directly and permanently delete the previ-
ous user as the main user, as well as put the
vehicle in offline mode and thus limit both the
communication of your vehicle with the SEAT,
S.A. data server and the processing of personal
and vehicle data.

Deactivating SEAT CONNECT serv-
ices

The following functions are available to acti-
vate and deactivate the SEAT CONNECT serv-
ices:

 Allow or prevent data transmissions through

the infotainment system

›››

page 248,

Privacy

mode

.

Whenever possible: individual deactivation or

activation

›››

page 248

.

You can run the relevant services again after
cancelling their deactivation.

CarManuals2.com

248

Data transmissions

Note

The services required by law and their data
transmission cannot be disconnected or de-
activated, for example, the emergency call
system (eCall).

Faults

Even if the prerequisites for the use of SEAT
CONNECT services are met, there may be fac-
tors beyond the control of SEAT, S.A. that inter-
fere with the execution of such services or pre-
vent them. These may be specifically:

Maintenance, repair, deactivation, software

update and technical expansion of telecommu-
nication equipment, satellites, servers and data
banks.

Change of the mobile telephony standard

for the transmission of mobile data by the tele-
communications service provider, for example,
from UMTS to EDGE or GPRS.

 Disconnection of an existing mobile phone

standard by the telecommunications service
provider.

 Interference, disturbance or interruption in

the reception of the mobile phone and GPS sig-
nal due to aspects such as high-speed driving,
solar storms, meteorological influences, topog-
raphy, blocking equipment and the intensive
use of mobile phones in the radio cells in ques-
tion.

 When in areas with zero or insufficient mobile

telephony or GPS signal. Also, for example, in
tunnels, confined areas between very tall build-
ings, garages, underpasses, mountains and val-
leys.

 External information from third party supplies

available with limitations, incomplete or incor-
rect, e.g. representations of maps.

Countries and regions where SEAT CONNECT

is not offered.

Service management

Open the settings in

Users

 and go to

Privacy

settings and services

. In vehicles fitted with

the 9.2” Infotainment, it is accessed from

Users

> Settings > Private Mode (deactivation of
services)

. In vehicles equipped with the 8.25”

Infotainment it is accessed from

Settings >

SEAT Connect > Privacy settings and serv-
ices

. You can do the following in the infotain-

ment system:

 Check which SEAT CONNECT services are

currently available in the vehicle.

 The number of SEAT CONNECT services that

are enabled or disabled.

 Activate or deactivate SEAT CONNECT serv-

ices.
More information at https://my.seat.

Note

If you deactivate all SEAT CONNECT serv-
ices, the vehicle can still transmit emergency
call (eCall) data.

Privacy mode

Introduction

With the “Privacy” function, data transmissions
between the vehicle and the Internet can be
allowed or blocked.
The desired mode can be set in vehicle settings
in the infotainment system.
Data transmission by external devices and their
communication with the vehicle

cannot

 be

blocked using the “Privacy” function.
The services required by law and their data
transmission cannot be disconnected or deac-
tivated, for example, the emergency call system
(eCall).

Note

Please note that all vehicle users can config-
ure individual settings in the “Privacy” func-
tion. These settings may not match those de-
sired by the vehicle owner.

CarManuals2.com

Data transmissions

249

WLAN access point

no icon

Privacy and services settings

SEAT CONNECT services can be activated and
deactivated individually. To do this, just check
the box corresponding to the service you want
to activate or deactivate. Use the privacy mode
option if you want to deactivate all of the serv-
ices at the same time.

Privacy mode

Allows you to deactivate or activate the serv-
ices depending on the selected privacy level.

Tracking

Share location.

 Main users and

co-users can view position data on
the SEAT CONNECT portal or app.

Location

Use location.

 Position, vehicle,

and user data are used for services.

Personal

No location.

 Only the vehicle

data and user data are used for
services.

Incognito

Maximum privacy.

 Your serv-

ices are disabled. Only services re-
quired for legal reasons use data.

Setting options are not available in all markets
or in all vehicle models.

Connectivity status indication

The following symbols indicate the respective
data transmission status in the infotainment
system.

Symbol white: full connectivity, all serv-
ices active
Symbol grey: limited connectivity, some
services may not be available.

No connectivity, no services available.

WLAN access point

Introduction

 Not available on vehicles without SEAT CONNECT

and without navigation

The infotainment system can be used to share
a WLAN connection with up to 8 devices

›››

page 249,

Configuration for sharing a con-

nection over WLAN

.

The infotainment system can also use the WLAN
hotspot of an external device to provide Inter-
net to the devices connected to the hotspot
(WLAN client)

›››

page 250

.

Note

 Data transmission may incur charges. Due

to the high volume of data exchanged, SEAT
recommends the use of a flat rate tariff for
data transmission. Mobile phone operators
can provide the relevant information.

Exchanging data packages and purchas-

ing them from third parties may generate
additional costs, depending on your mobile
phone rate, particularly if you are abroad
(for example, roaming rates).

Configuration for sharing a connec-
tion over WLAN

Establishing the connection with the wire-
less network (WLAN)

Press the

 HOME >

button.

Activate the wireless network. To do this, press

the function button

Wi-Fi > Infotainment sys-

tem as hotspot

.

Activate the wireless network (WLAN) on the

device that is to be connected. If necessary,
refer to the manufacturer’s instruction manual.

Activate the mobile device assignment in the

infotainment system. To do this, press the func-
tion button

Use as hotspot

 and check the

checkbox.

Enter and confirm the network key displayed

on the device.

CarManuals2.com

250

Data transmissions

The following adjustments can also be made in
the

Infotainment system as hotspot

 menu:

Security level:

 WPA2 encryption automati-

cally generates a network key.

Network key:

 Network key automatically

generated. Press the function button to man-
ually change the network key. The network key
must have a minimum of 8 characters and a
maximum of 63.

SSID:

 WLAN Network name (maximum of 32

characters).
The wireless (WLAN) connection is established.
To complete the connection, it may be neces-
sary to enter other data into the device.
Depending on the version, it is only possible to
connect in Hotspot mode to get AppConnect,
and a maximum of 5 devices can be connec-
ted.
Repeat this process to connect other devices.
There is also the option of scanning the QR
code by connecting the device directly to the
infotainment system’s Wi-Fi network without
having to enter the password: select

Settings

> Wi-Fi > Quick connection to infotainment
system

.

An additional feature is that the infotainment
system can provide data to any device over
WPS (Hotspot mode) in the same menu as the
QR code.

Wi-Fi Protected Setup (WPS)

 This depends on the equipment and the country

in question.

Wi-Fi Protected Setup

 allows an encoded local

wireless network to be created quickly and sim-
ply (

Settings > Wi-Fi > Wi-Fi > Quick

WPS connection

).

Establish the connection with the wireless

network (WLAN).

Press the WPS button on the WLAN router un-

til the warning light on the router starts flashing.
If the WLAN router does not support WPS the
network must be configured manually.

OR:

 Press and hold the WLAN button on the

WLAN router until the WLAN light on the router
starts flashing.

Press the WPS button on the WLAN device.

The wireless (WLAN) connection is established.
Repeat this process to connect other devices.

Configure Internet access

The infotainment system can use the WLAN hot-
spot of an external device to establish an Inter-
net connection.

Establishing the connection with the wire-
less network (WLAN)

Activate and share a wireless hotspot with In-

ternet on the external device. Refer to the man-
ufacturer’s instruction manual.

Press the

HOME >

 button.

Press the

Wi-Fi > Connect to Wi-Fi

 menu and

put a check in the checkbox.

Press the

Search for Wi-Fi

 button and select

the device you want from the list.

If necessary, enter the network key of the

device in the infotainment system and confirm
with

OK

.

Manual settings:

To manually enter the network settings of an

external (WLAN) device.
The wireless (WLAN) connection is established.
To complete the connection, it may be neces-
sary to enter other data into the device.

Note

Due to the large number of devices on the
market, it is not possible to guarantee fault-
free operation of all functions.

Full Link

Introduction

With Full Link it is possible to view and use
the contents and functions that are shown on
the mobile phone device on the infotainment
screen.

CarManuals2.com

Data transmissions

251

Full Link

To do this, the mobile phone device must
be connected with the infotainment system
through a USB interface.
Some technologies can also be used by Wire-
less Full Link through the Bluetooth® interface
and a Wi-Fi connection.

The following technologies may be availa-
ble:

Apple CarPlay™

 Apple CarPlay™ Wireless

Android Auto™

Android Auto™ Wireless

MirrorLink®

The availability of the technologies that Full Link
includes depends on the country and the mo-
bile phone device used.
You will find more information on the SEAT web-
site (www.seat.com).

Access the Full Link main menu

Browsing the Full Link main menu depends on
the infotainment system used.

Press

Home > Full Link

Configure Wireless Full Link

In order to use Wireless Full Link, you must first
pair the mobile phone device with the infotain-
ment system. To do this, proceed as follows:

Connect a mobile phone device for the first
time.

 Unlock the mobile phone device.

Enable Wi-Fi reception and Bluetooth® on the

mobile phone device.

Connect the mobile phone device to the info-

tainment system using a USB cable or via Blue-
tooth®.

Access the

Full Link

 main menu, if it is not

displayed automatically.

 Select the mobile phone device and the

technology you want.

Confirm authorisation inquiries on the mobile

phone device to grant the necessary authorisa-
tions to the infotainment system.

Disconnect the USB connection and connect

with the infotainment system again via Wi-Fi or
Bluetooth®. Wireless Full Link is now configured.
The pairing has concluded. The connected mo-
bile phone device can also use Wireless Full
Link from now on without the USB connection.
If pop-up menus are rejected during the con-
nection process, Wireless Full Link will not be
available. In this case, SEAT recommends delet-
ing the devices in both the telephone settings
and the infotainment system, and restarting the
connection process.

WARNING

The use of applications while driving can dis-
tract your attention from the traffic. Any dis-
traction affecting the driver in any way can
lead to an accident and cause injuries.

Always drive as carefully and responsibly

as possible.

WARNING

Any applications that are not suitable or ex-
ecute incorrectly may cause damage to the
vehicle, accidents and serious injuries.

Protect the mobile phone device and its

applications from inappropriate use.

Never carry out modifications to the appli-

cations.

Follow instructions in the instruction man-

ual for the mobile phone device.

NOTICE

SEAT cannot be held liable for any damage
caused to the vehicle as a result of the use
of applications that are of poor quality or
are defective, the inadequate programming
of the applications, the insufficient coverage
of the network, the loss of data during trans-
mission or the improper use of mobile phone
devices.

CarManuals2.com

252

Data transmissions

Note

Wireless Full Link may not be compatible

with all technologies.

When crossing the border into countries

with permitted radio frequencies different to
those in your own country, running the Full
Link Wireless function may be restricted or
even unavailable due to legal regulations.
This can also be indicated by a message in
the infotainment system. Running Full Link via
cable is not affected by this restriction and
can continue to be used.

Applications (apps)

With SEAT Full Link, the display of the contents
of SEAT applications and other providers instal-
led on mobile phone devices can be transferred
to the infotainment screen.
In the case of third-party applications, there
may be compatibility problems.
Applications, their use and the necessary mo-
bile phone connection may be pay per use.
The offer of applications can be varied and de-
signed for a vehicle or a specific country. The
content and volume of applications, as well as
the companies that offer them, may vary. Some
applications also depend on the availability of
third-party services.
It cannot be guaranteed that all the applica-
tions offered will work on all mobile phone devi-
ces or with all their operating systems.

The applications offered by SEAT can be modi-
fied, cancelled, deactivated, reactivated and
extended without prior notification.
To avoid distracting the driver while driving, only
certified applications can be used.

Full Link symbols and settings

To show more information.
To open the Full Link settings menu
To select Apple CarPlay technology.
To select Android Auto™ technology.
To select MirrorLink® technology.

Apple CarPlay™

In order to use Apple CarPlay, the following re-
quirements must be met:

The iPhone™

must

 be compatible with Apple

CarPlay™.

Voice control (Siri ™)

must

 be active on the

iPhone™.

Apple CarPlay™

must

 be active without limi-

tations in the iPhone™ settings.

If this is not possible via Apple CarPlay™ Wire-

less, the iPhone™

must

 be connected to the

infotainment system via a USB connection. Only
USB connections with data transmission are
suitable for the use of Apple CarPlay™.

The USB cable used

must

 be an original Ap-

ple™ cable.

Apple CarPlay™ Wireless

: Bluetooth® and Wi-Fi

must also be activated on the iPhone™.

Establish connection

When you first connect an iPhone™, follow the
instructions on the infotainment system screen
and on the iPhone ™.
The requirements must be met to use Apple
CarPlay™.
Launch Apple CarPlay™:

Press

HOME > Full Link

 to access the Full

Link main menu.

Press Apple CarPlay™ to establish a connec-

tion with the iPhone™.

Disconnecting

On the Apple CarPlay™ mode, press the

SEAT

icon to access the Full Link main menu.

 Press   to interrupt the active connection.

The representation of function buttons on the
screen may vary.

Special characteristics

During an active Apple CarPlay™ connection,
the following characteristics are applicable:

 Bluetooth® connections between the

iPhone™ and the infotainment system are

not

possible.

If there is an active Bluetooth® connection, it

is automatically interrupted.

CarManuals2.com

Data transmissions

253

Full Link

 The phone functions are only available

through Apple CarPlay™. The functions descri-
bed for the Infotainment system are not availa-
ble.

 The connected iPhone™

cannot

 be used as

a media device in the

Media

 main menu.

It is

not

 possible to use the built-in naviga-

tion system and the Apple CarPlay™ navigation
system at the same time. The last route started
interrupts the one that was previously active.

Depending on the infotainment system you

use, on the instrument panel screen you can
view data from the Telephone mode.

Depending on the infotainment system you

use, on the instrument panel screen you can
view data from the Media mode.

The instrument panel screen does not display

any indication to turn.

With the multifunction steering wheel you can

accept or reject incoming calls, as well as end
an ongoing telephone conversation.

Voice control

Press   briefly to start voice control using

the infotainment system.

Press this button for a long time to start voice

control (Siri™) of the connected iPhone™.

Note

The availability of technologies depends

on the country and may vary.

You will find information about technical

requirements, compatible iPhones, certified
applications and their availability on the
SEAT (www.seat.com) and Apple CarPlay ™
websites, or at SEAT dealerships.

Android Auto™

Requirements for Android Auto™

In order to use Android Auto™, the following re-
quirements must be met:

The mobile phone device, called smartphone

from here on,

must

 be compatible with Android

Auto™.

The smartphone

must

 have an Android Auto™

application installed.

If this is not possible via Android Auto Wireless,

the smartphone must be connected via the USB
connection with data transmission to the info-
tainment system.

The USB cable used

must

 be an original ca-

ble provided by the smartphone manufacturer.

Android Auto Wireless

: Bluetooth® and WLAN

(Wi-Fi) also have to be active on the smart-
phone.

Establish connection

When you first connect a smartphone, follow
the instructions on the infotainment system
screen and on the smartphone.
The requirements must be met to use Android
Auto™.
Launch Android Auto™:

 Press

HOME > Full Link

 to access the Full Link

main menu.

Press Android Auto™ to establish a connec-

tion with the smartphone.

Disconnecting

 In Android Auto™ mode, press the

 / Exit

icon to access the Full Link main menu.

Press   to interrupt the active connection.

Special characteristics

During an active Android Auto™ connection, the
following characteristics are applicable:

An active Android Auto™ device can be con-

nected at the same time via Bluetooth® (HFP
profile) with the infotainment system.

It is possible to use the phone’s functions

through Android Auto™. If the Android Auto™
device is connected at the same time via Blue-
tooth® with the infotainment system, the tele-
phone function of the infotainment can also be
used.

CarManuals2.com

254

Data transmissions

An active Android Auto™ device

cannot

 be

used as a media device in the

Media

 main

menu.

It is

not

 possible to use the built-in navigation

system and the Android Auto™ navigation sys-
tem at the same time. The last route started
interrupts the one that was previously active.

Telephone and Media data can be displayed

on the instrument cluster screen.

With the multifunction steering wheel you can

accept or reject incoming calls, as well as end
an ongoing telephone conversation.

Voice control

Press   briefly to start voice control using

the infotainment system.

Press and hold this button to start voice con-

trol (Google Assistant) on the connected smart-
phone.

Note

The availability of technologies depends

on the country and may vary.

You will find information about technical

requirements, compatible mobile phone de-
vices, certified applications and their avail-
ability on the SEAT (www.seat.com) and An-
droid Auto™ websites, or at SEAT dealerships.

MirrorLink®

Requirements for MirrorLink®

In order to use MirrorLink®, the following re-
quirements must be met:

The mobile device

must

 be compatible with

MirrorLink®.

 The mobile phone device

must

 be connec-

ted to the infotainment system via a USB con-
nection that is suitable for data transmission.

The USB cable used

must

 be an original ca-

ble provided by the mobile phone device man-
ufacturer.

Depending on the mobile phone device used,

a Car-Mode application that is suitable for us-
ing MirrorLink®

must

 be installed.

Establish connection

When you first connect a mobile phone device,
follow the instructions on the infotainment sys-
tem screen and on the mobile phone device.
The requirements must be met to use Mirror-
Link®.
Start MirrorLink®:

Press

HOME > Full Link

 to access the

Full Link

 main menu.

Press

MirrorLink

 to connect to the mobile

device.

Disconnecting

 In MirrorLink® mode, press

APP

 to access

the Full Link main menu.

OR:

 press   to access the MirrorLink® main

menu.

Press   to interrupt the active connection.

Special characteristics

During an active MirrorLink® connection, the
following characteristics are applicable:

An active MirrorLink® device can be connec-

ted to the infotainment system at the same time
via Bluetooth®.

If the MirrorLink® device is connected to the

infotainment system via Bluetooth®, the tele-
phone function of the infotainment system can
be used.

You

cannot

 use an active MirrorLink® device

as a media device in the

Media

 main menu.

On the instrument panel screen you can view

data from the Telephone mode.

 The instrument panel screen does not dis-

play any indication to turn or the Media mode.

With the multifunction steering wheel you can

accept or reject incoming calls, as well as end
an ongoing telephone conversation.

Function buttons

Function buttons and their function:

CarManuals2.com

Data transmissions

255

Wired and wireless connections

APP

Return the Full Link main menu. Here

you can end the MirrorLink® connection,
connect another mobile phone device or
select another technology.
Press to close the open apps. Then press
the apps to be closed or the

Close

all

 function button to close all the open

applications.
Press to display the mobile phone device
screen on the infotainment system screen.
To open the MirrorLink® settings.

Press to return to the MirrorLink® main
menu.

Note

You will find information about technical re-
quirements, compatible mobile phone devi-
ces, certified applications and their availa-
bility on the SEAT (www.seat.com) and Mir-
rorLink® websites, or at SEAT dealerships.

Wired and wireless connec-
tions

USB connection

Fig. 184

Centre console: USB input.

Fig. 185

Rear centre console: USB connectors

with power socket function.

The USB port can be found in the storage
compartment area of the front centre console

›››

Fig. 184

.

Depending on the equipment and the country,
the vehicle may also have USB connections

ex-

clusively for charging or as a power socket

.

These USB ports are located at the rear of the
console, between the front seats

›››

Fig. 185

.

Note

Before switching the ignition on or off, unplug
the appliances from the USB ports to protect
them from any damage caused by fluctua-
tions in voltage.

CarManuals2.com

256

Infotainment system

Infotainment system

First steps

Introduction

Infotainment functions and settings depend on
the country and equipment.

Before first use

Before the first use, bear in mind the following
points, to take full advantage of the functions
and settings offered:

Observe the basic safety warnings

›››

page 256

.

Reset the Infotainment factory settings.

Search and store favourite radio stations

on the preset buttons so you can tune them
quickly.

Use only suitable audio sources and data me-

dia.

Pair a mobile phone to use phone manage-

ment through the Infotainment system.

Use current maps for navigation.

Register in SEAT CONNECT to run the corre-

sponding services.

Current documentation attached

For using infotainment and its components, take
into account, together with this instruction man-
ual, the following documentation:

Supplements to your vehicle’s on-board doc-

umentation.

Instruction Manual of the mobile phone de-

vice or audio sources.

Operating instructions for data media and ex-

ternal players.

Manuals for the Infotainment accessories

subsequently installed or used additionally.

Description of services when running SEAT

CONNECT services.

Safety instructions

Some function areas may include links to third-
party websites. SEAT, S.A. is not the owner of
the third-party websites accessible through the
links, and assumes no liability for their content.
Some function areas may include outside infor-
mation from third-party providers. SEAT, S.A. is
not responsible for such information being cor-
rect, up-to-date or complete, or for ensuring it
does not infringe the rights of third parties.
Radio stations and owners of data media and
audio sources are responsible for the informa-
tion they transmit.

Bear in mind that parking lots, tunnels, tall
buildings, mountains or due to the operation of
other electrical devices, such as chargers, can
also interfere with the reception of the radio
signal.
Foils or adhesives with metallic layers on the
antenna and on the window panes can inter-
fere with radio reception.

WARNING

The infotainment central computer is inter-
connected with the control units mounted
on the vehicle. Therefore, there is a serious
danger of accident and injury if the central
computer is repaired or disassembled and
reassembled incorrectly.

Never replace the central computer with

another used, recycled or from another vehi-
cle at the end of its useful life.

The repair or disassembly and reassembly

of the central computer should only be car-
ried out at specialised workshops. SEAT rec-
ommends visiting a SEAT dealership for this.

WARNING

Any distraction affecting the driver in any
way can lead to an accident and cause inju-
ries. Reading the information on the screen
and managing the infotainment system can
distract your attention from traffic and cause
an accident.

Always drive as carefully and responsibly

as possible.

CarManuals2.com

Infotainment system

257

First steps

WARNING

Connecting, inserting or removing an audio
source or data media while driving can dis-
tract your attention from the traffic and
cause an accident.

WARNING

Select volume settings that allow you to
easily hear signals from outside the vehicle
at all times (e.g. emergency services sirens).

Hearing may be impaired if using too high a

volume setting, even if only for short periods
of time.

WARNING

The following circumstances may result in an
emergency call, phone call or data transmis-
sion not being made or being interrupted:

When in areas with zero or insufficient mo-

bile telephony or GPS signal. Also in tunnels,
confined areas between very tall buildings,
garages, underpasses, mountains and val-
leys.

When in areas with sufficient mobile phone

or GPS signal, the telephony network of
the telecommunications provider has inter-
ference or is not available.

When the vehicle components necessary

to make emergency calls, phone calls and to
transmit data are damaged, do not work or
do not have sufficient electrical power.

When the battery of the mobile phone de-

vice is discharged or its charge level is insuf-
ficient.

WARNING

In some countries and some telephone net-
works it is only possible to make an emer-
gency call, if a mobile telephone device is
connected to the telephone interface of the
vehicle, inside it there is an “unlocked” SIM
card with sufficient balance to make calls
and with sufficient network signal coverage.

WARNING

Read and observe the operating instructions
provided by the manufacturer in question
when using mobile phone devices, data me-
dia, external devices, external audio and
multimedia sources.

WARNING

When changing or connecting an audio
or multimedia source may cause sudden
changes in the volume.

Lower the volume before connecting or

switching to audio or multimedia sources.

WARNING

If mobile phone and radiocommunication de-
vices are used without connection to an
external antenna, the maximum electromag-
netic radiation levels inside the vehicle might
be surpassed, thus posing a risk to the health
of the driver and passengers. This is also the
case if the external antenna has not been
correctly installed.

Keep a distance of at least 20 centimetres

between the antennas of the mobile phone
device and an active medical device, such as
a pacemaker, as mobile phones might alter
the functioning of these devices.

Do not carry a mobile phone switched

on very close or directly on top of an ac-
tive medical device, for instance in a chest
pocket.

Immediately turn off the mobile phone if

you suspect it is causing interferences in an
active medical device or any other medical
device.

WARNING

Mobile phones, external devices and acces-
sories that are loose or not properly secured
could move around the passenger compart-
ment during a sudden driving or braking ma-
noeuvre or an accident and cause damage
or injury.

Set mobile phone devices, external devices

and their accessories outside the airbag de-
ployment areas or store them securely.

CarManuals2.com

258

Infotainment system

Position the connection cables of the audio

sources and external devices so that they do
not interfere with the driver.

WARNING

The centre armrest may obstruct the driver's
arm movements, which could cause an acci-
dent and severe injuries.

Keep the storage compartments of the

centre armrest closed at all times while the
vehicle is in motion.

WARNING

If the light conditions are not good and the
screen is damaged or dirty, the indications
and information displayed on the screen may
not be read or be read incorrectly.

The indications and information displayed

on the screen should never induce to take
any risk that compromises safety. The screen
is not a replacement for driver awareness.

WARNING

Radio stations can transmit disaster or haz-
ard announcements. The following condi-
tions prevent such notices from being re-
ceived or issued:

When in areas with zero or insufficient ra-

dio signal. Also in tunnels, confined areas
between very tall buildings, garages, under-
passes, mountains and valleys.

When the frequency bands of the radio

station have interference or are not available
in areas with sufficient radio signal recep-
tion.

When the speakers and the vehicle com-

ponents necessary for radio reception are
damaged, do not work or do not have suffi-
cient electrical power.

WARNING

Switch off mobile phone devices in areas
with a risk of explosion!

WARNING

The driving recommendations and traffic in-
dications shown on the navigation system
may differ from the current traffic situation.

Traffic signs, signalling systems, traffic

regulations and local circumstances prevail
over driving recommendations and naviga-
tion system indications.

Adapt your speed and driving style to

suit visibility, weather, road and traffic condi-
tions.

Certain circumstances can significantly in-

itially planned lengthen both the duration of
the trip and the route to the destination, or
even temporarily prevent navigation to it, for
example, if a road is closed to traffic.

NOTICE

In areas where special regulations apply or
the use of mobile phones is forbidden, the
mobile device in question must be switched
off at all times. The radiation produced by a
mobile phone device when switched on may
interfere with sensitive technical and medi-
cal equipment, possibly resulting in malfunc-
tion or damage to the equipment.

NOTICE

If the playback volume is excessive or distor-
ted, the speakers may be damaged.

CarManuals2.com

Infotainment system

259

Overview and controls

Overview and controls

Connect System

Fig. 186

Overview: control unit

1

Touch screen. The infotainment functions
can be used through the screen.

2

Navigation Menu

3

Full Link menu

4

Turn volume up

5

Turn volume down

6

Turn the infotainment on/off

7

HOME button.

: main menu with widget views.
: main menu in tile mode.

CarManuals2.com

260

Infotainment system

Media System

Fig. 187

Overview: control unit and indication in

the 8.25-inch version

1

Touch screen. The infotainment functions
can be used through the screen.

2

Rotary push button (to adjust the volume
and to switch the infotainment on/off)

3

Rotary push button (to search and select)

4

HOME button (to open the start page)

5

Radio/Multimedia

›››

page 268

6

Telephone

›››

page 282

7

Full Link

›››

page 250

8

Vehicle information

›››

page 36

9

Vehicle settings

›››

page 37

CarManuals2.com

Infotainment system

261

General instructions for use

General instructions for use

Operating indications

The infotainment needs a few seconds for

the complete start-up of the system and during
that time it does not react to inputs. Only the
image of the rear view camera system can be
displayed during system start-up.

The display of all indications and the execu-

tion of functions only takes place once the info-
tainment system has finished booting. The du-
ration of the system booting depends on the
number of infotainment functions and may take
longer than normal in the event of very high or
very low temperatures.

When using the infotainment system and

corresponding accessories, e.g., headphones,
bear in mind country-specific regulations and
legal provisions.

 Some functions of the infotainment system

require an active SEAT CONNECT user account
and an Internet connection for the vehicle. The
data transmission must not be limited to per-
form the functions.

To use the infotainment system, simply lightly

press a button or touch the screen.

For the correct operation of the infotainment

system it is important that it is switched on and
that, if necessary, the time and date of the vehi-
cle are set correctly.

If a function button is missing on the screen,

it is not a device defect, but corresponds to the
specific equipment of the country or version.

Some infotainment functions can only be se-

lected when the vehicle is at a standstill. In
some countries, the selector lever must also be
in the parking position

P

 or in neutral position

N

.

It is not a malfunction, but is due to compliance
with legal provisions.

Restrictions on the use of devices using Blue-

tooth® technology may apply in some coun-
tries. For further information, contact the local
authorities.

If you disconnect the 12 volt battery, turn on

the ignition before restarting the infotainment
system.

If the setup is changed, this may change the

display on the screen and in some cases, the
infotainment system may behave in a manner
different to that described in this instruction
manual.

In some countries, the infotainment system

automatically shuts off when the engine is
switched off and the vehicle's 12-volt battery
charge level is low.

 Ensure that any repairs or modifications that

need to be carried out on the infotainment sys-
tem are carried out by a specialised workshop.
SEAT recommends visiting a SEAT dealership
for this.

Using a mobile phone device inside the vehi-

cle may cause noise in the speakers.

On vehicles with park assist, the audio source

volume is automatically lowered when reverse
gear is selected, as well as when the doors are
opened. The volume reduction can be adjusted.

Information about the included software and

the license conditions can be found in

Set-

tings > Copyright

.

 When selling or lending the vehicle, make

sure that all saved data, files and settings have
been deleted and, if necessary, external audio
sources and data media have been removed.

Note

You will find more information and tips for
using the infotainment system in the

Help

menu.

HOME screen

In the control and display unit you can set
up the views and representation on the home
screen or use the factory setting templates.
If an icon is missing on the screen, it is not a
device defect, but corresponds to the specific
equipment of the country or version.
The following menus can be included as an
icon on the home screen:

Main menus on the home screen

Navigation

›››

page 275

CarManuals2.com

262

Infotainment system

Radio

›››

page 268

, Media

›››

page 272

Telephone

›››

page 282

Full Link

›››

page 250

Settings

›››

page 263

Vehicl

›››

page 37

Data

›››

page 36

Air conditioning

›››

page 132

Sound

Users

Store

Legal

Help

Managing the infotainment system

Execute the functions and settings with the info-
tainment controls.

Depending on the equipment, the infotainment
system has different controls:

Touch screen.

Touch zones outside the screen, for example,

Volume (+ -).

Function buttons, for example,

RADIO

 or

ME-

DIA

.

Open the Quick Guide

More information and operating tips can be
found in the Infotainment Quick Guide.

Press

HOME >   Help

.

Connecting and disconnecting the infotain-
ment system

The infotainment system turns on when the igni-
tion is switched on, unless it has been manually
turned off beforehand.
The infotainment system starts-up with the last
set volume, provided that this does not exceed
the preset maximum start-up volume.
The infotainment system automatically turns off
when the driver's door is opened, provided the
ignition has been switched off beforehand.

Moving objects and adjusting volume

Move objects on the screen to adapt settings,
for example, with scrollable buttons or to move
the areas of a menu.
Depending on the equipment, menus and dis-
plays can be customised.

Increasing and reducing images or map
sizes

Tip: use your thumb and index finger.

Press on the map with both fingers at the

same time and leave them on the screen.

To enlarge views, slowly separate one finger

from the other. To reduce views, slowly bring
one finger towards the other.

Note

If you turn on the infotainment system man-
ually with the ignition off, it will automati-
cally turn off after about 30 minutes.

Note

As with most state-of-the-art computer and
electronic equipment, in certain cases the
system may need to be rebooted to make
sure that it operates correctly. To do this, if
appropriate, press and hold the On/Off but-
ton of the infotainment system () for approx.
15 seconds until the SEAT logo appears on
the display.

Customising the infotainment sys-
tem

Customise the menus and infotainment views
to quickly access your favourite or most fre-
quently used functions.

CarManuals2.com

Infotainment system

263

General instructions for use

The main menu contains function buttons for
accessing all of the Infotainment apps.

Customise shortcuts

At the bottom of the screen you will find short-
cuts to customisable system functions. Use the
settings to delete or replace them, or change
their order.

 Press and hold one of the icons (or press +

of an empty position) to display an additional
window.

Select one of the icons from the apps bar.

Press   to delete an icon.

Click on an icon in the additional window to

replace the value.

Hold your finger on one of the icons and drag

it to the desired position.

To close the edit mode, press   in the addi-

tional window, or press  .

Settings (system and sound)

The selection of possible settings varies de-
pending on the country, the equipment in ques-
tion and the equipment of the vehicle.

Modifying settings

The meaning of the following symbols are valid
for all system and sound settings.
All changes are automatically applied when
the menus are closed.

 /

The setting is selected and activated
or connected.

 /

The setting is not selected, disabled or
disconnected.

To open a drop-down list.

To increase a setting value.

To reduce a setting value.

To go back step by step.

To go forward step by step.

To change a setting value with the
scrollable button without adjusting.

Sound settings

 Access the sound settings:

HOME >

.

In the sound settings there may be the following
functions, information and setting options:

Equaliser.

Position.

Settings.

System settings

Access the system settings:

HOME >

.

In the system settings there may be the follow-
ing functions, information and setting options:

Screen.

Time and date.

Language.

Additional keypad languages.

Units.

Voice control.

Wi-Fi.

Data connection.

Manage mobile devices.

 Reset factory settings.

System information.

Copyright.

Configuration wizard.

Adjust the volume of external audio sources

If you need to increase the playback volume for
the external audio source, first lower the volume
on the infotainment system.
If the sound from the connected audio source
is

very low

, increase the

output volume

 on

the external audio source. If this is not enough,
change the

input volume

 to

medium

 or

high

.

If the sound from the connected external audio
source is

too loud or distorted

, lower the

out-

put volume

 on the external audio source. If this

is not enough, change the

input volume

 to

me-

dium

 or

low

.

CarManuals2.com

264

Infotainment system

1)

Equipment name: Media System.

Clean the screen

Remove persistent dirt carefully and without us-
ing aggressive cleaning products. To clean the
screen we recommend that:

The infotainment system is switched off.

Use a clean, soft cloth dampened with water

›››

page 370

.

In case of persistent dirt: soften the dirt by

moistening with a little water. Then carefully re-
move with a clean, soft cloth.

NOTICE

Cleaning the screen with inappropriate
cleaning products or when dry, may damage
it.

When cleaning, only press lightly.

Do not use aggressive cleaning products

or that contain solvents. Such products
may damage the equipment and darken the
screen.

Trademarks, licenses and copyrights

Registered trademarks and licenses

Certain terms in this manual bear the symbol
® or ™. These symbols indicate that they are
trademarks or registered trademarks. The ab-
sence of this symbol, however, does not neces-
sarily mean that the term in question can be
used freely.

Other product names are registered trade-
marks of the respective rights holders.

Manufactured under license from Dolby Lab-

oratories. Dolby and the double-D symbol are
trademarks of Dolby Laboratories.

Manufactured under license from Dolby Lab-

oratories. Dolby, Pro Logic and the double-D
symbol are trademarks of Dolby Laboratories.

Android Auto™ is a trademark of Google Inc.

Apple CarPlay™ is a trademark of Apple Inc.

Bluetooth® is a registered trademark of Blue-

tooth® SIG, Inc.

iPod®, iPad® and iPhone® are trademarks of

Apple Inc.

MirrorLink® and MirrorLink® Logo are certified

trademarks of Car Connectivity Consortium
LLC.

Windows® is a registered trademark of Micro-

soft Corporation, Redmond, USA.

MPEG-4 HE-AAC audio coding technology

and patents are licensed by Fraunhofer IIS.

This product is protected by certain Microsoft

Corporation industrial and intellectual property
rights. The use or commercialization of technol-
ogy of this type outside the configuration of this
product, without a licence from Microsoft or an
authorised Microsoft branch is prohibited.

Copyright

As a general rule, audio and video files stored
on data media and audio sources are subject to
intellectual property protection in accordance
with the national and international provisions
applicable in each case. Please bear in mind all
legal provisions!

Technical data

Radio with integrated hardware (8.25 ")

1)

The factory-mounted radio in the vehicle with
integrated hardware includes country-specific
components and software for connectivity and
for the execution of vehicle, comfort and info-
tainment functions.
The corresponding indications are displayed on
the radio screen and partly on the instrument
panel.

 Capacitive colour screen:

8.25 inch version, TFT, WVGA: 1082 x 480

pixels.

 Touch operation via the device screen, rotary

push-button, menu button and buttons on the
multifunction steering wheel.

CarManuals2.com

Infotainment system

265

General instructions for use

1)

Equipment name: Connect System

Central computer with control and display
unit

1)

The factory-mounted central computer in the
vehicle includes country-specific components
and software for connectivity and for the ex-
ecution of vehicle, comfort and infotainment
functions.
The corresponding indications are shown on
the control and display unit screen and partly
on the instrument panel.

 Capacitive colour screen

Using the equipment with:

Touch zones Touch operation.

Buttons on the multifunction steering wheel.

Proximity sensors and gesture control.

HOME >   Settings > Display.

Vehicle and comfort functions

Assistants system settings.

Heating and air conditioning settings.

Lights and visibility function settings.

Vehicle comfort settings.

Parking and manoeuvring settings.

Sound system (basic equipment):

The infotainment system that is supplied from
the factory is equipped as follows:

Speakers in different locations and with dif-

ferent power levels (watts).

Internal amplifier depending on the system:

8 speakers: 4 x 20 W

Setting options:

Equaliser, depending on the system:

8 speakers: 5 frequency bands and default

settings.

Sound distribution, depending on the system:

8 speakers: Balance + Fader (left / right /

front / rear).

Sound optimisation by zones (valid for the 8-

speaker system):

Manual (Driver and All)

Automatic depending on the seats occu-

pied.

Optional sound system

The infotainment system can be extended with
an optional sound system as follows:

10 speakers in different locations and with dif-

ferent power levels (watts).

External amplifier (400 W Ethernet), which

processes the audio signals sent by the central
computer.

Excitation of speaker channels through class

AB final stages.

Audio signal processing in digital internal sig-

nal processor (DSP).

Independent subwoofer in the luggage com-

partment.
Setting options:

User equaliser: 5 bands.

Sound distribution: Balance (left / right) +

Fader (front / rear).

Sound optimisation by zones:

Manual (Driver, Front and All)

Subwoofer volume.

Surround settings.

Wi-Fi

 Wi-Fi conforming to IEEE 802.11 b/g/n.

2.4 GHz and 5 GHz transfer (depending on

the country).

Apple Car Play™ and Android Auto™ over Wi-

Fi

Simultaneous connection of up to 8 Wi-Fi de-

vices.

Media System:

CarManuals2.com

266

Infotainment system

5GHz access point for Full Link Wireless

only

Connect System:

Access point

Tethering

Pairing process simplified by WPS or QR

code

Bluetooth® profiles

There can be a maximum of two mobile devices
connected to the Bluetooth® hands-free and a
third device connected to the Bluetooth® as a
music player.
When a mobile phone is connected to the tele-
phone management system, a data exchange
takes place via one of the Bluetooth® profiles.



Hands-free telephone profile (HFP):

 the

HFP can be used to manage calls through the
infotainment system.

Audio profile (A2DP):

 This profile allows au-

dio to be transmitted with stereo quality. It may
require connecting other profiles for managing
and controlling playback.

Phone book access profile (PBAP):

 Allows

phone book contents to be downloaded from
the mobile telephone.

Messaging profile (MAP):

 It allows short

messages (SMS) and emails to be downloaded
and synchronised.

Voice control

Introduction

Voice control works both online and offline, tak-
ing into account the aspects indicated in the
section “

Languages available depending on

the market

”. In online mode, commands are re-

corded more accurately, as more data is avail-
able.
Voice control understands questions and ex-
pressions without having to learn commands.
Commands can be formulated freely and can
be colloquial. Command proposals can be
found in the infotainment system, for example
in the

 Help > Voice control

 menu.

Functions are reduced in offline mode.
Loud noises inside or outside the vehicle can
cause malfunctions, as well as confusing phra-
ses and answers.

Languages available depending on the mar-
ket

Online and offline:

 German, American Eng-

lish, British English, French, Italian, Spanish,
Czech, Dutch, Polish, Portuguese, Swedish,
Danish and Norwegian. These languages have
advanced functions such as Online Com-
mands, natural interaction, etc.
The other languages of the infotainment system

do not

 offer natural interaction.

Requirements

Online and offline:

 voice control with the cor-

responding infotainment installed in the vehicle.

Online:

 current SEAT CONNECT Plus contract

active.

Note

Voice control only recognises commands

in the language that is set in the infotainment
system.

Test the voice control with the vehicle stop-

ped before starting to move to familiarise
yourself with its operation.

Online voice search will be faster and more

reliable if the “Use location” privacy setting
is selected.

Voice control can only control functions

that are available as part of the vehicle’s
equipment.

Wake word and commands

Voice control wake words

Voice control starts when the infotainment rec-
ognises the wake word.
If you have connected the voice control via the
wake word, the connected infotainment replies
with “

What would you like to do?

”.

OR:

 after the wake word, say the desired

command, for example: “

Hola Hola

” and then

heating

”.

CarManuals2.com















Content      ..     6      7      8      9     ..
