MANUAL AIR CONDITIONING (1/4)
Adjusting the ventilation fan
speed.
1
2
3
4
5
6
Turn control 3 from 0 to 4. The further
to the right the control is positioned, the
more air is blown into the passenger
compartment. If you want to shut off the
flow of air, set the 3 control to 0.
The system is deactivated: the ventila-
tion speed for the passenger compart-
ment air is zero (vehicle stationary),
you can however still feel a slight flow
of air when the vehicle is moving.
Note: prolonged use of this control in
position 0 may lead to condensation
forming on the side windows and wind-
Controls
Information
and
advice
on
use
screen as well as problems due to the
➥ 3.12
The controls will depend on the vehicle
presence of non-renewed air in the
equipment level.
passenger compartment.
Adjusting the air temperature
1 Distribution of air.
Turn control 5 to obtain the desired
2 De-icing/demisting of the door mir-
temperature. The further towards the
rors and, depending on the vehicle,
red the slide is, the higher the temper-
the rear screen.
ature will be.
3 Adjusting the ventilation fan speed.
4 Air recirculation.
5 Air temperature adjuster.
6 Air conditioning.
3.4
CarManuals2.co
MANUAL AIR CONDITIONING (2/4)
Rear screen de-icing/
demisting
1
2
3
4
5
6
With the engine running, press
button 2. The integrated indicator light
comes on.
This function allows rapid electric de-
misting of the rear screen and, depend-
ing on the vehicle, electric de-icing of
the rear view mirrors.
To exit this function, press button 2
again. Demisting automatically stops.
Rapid demisting
Passenger compartment isolation/air
recirculation deactivated (the warning
light on the 4 button is off):
Switching passenger
Air recirculation is used to:
- press the 2 button (the warning light
compartment isolation mode/
- isolating the vehicle from the exter-
comes on) and set the 1 control to
air recirculation mode on.
nal atmosphere (driving in polluted
areas, etc.);
the demisting position W;
Press button 4 (the warning light comes
- to bring the passenger compartment
- set the 3 and 5 controls to the follow-
on).
to the desired temperature as quickly
ing positions:
Under these conditions, air is taken
as possible.
- the fan speed in position 3 or 4;
from the passenger compartment and
- maximum temperature;
is recirculated, with no air being taken
- press button 6 (the warning light on
from outside the vehicle.
the button comes on): triggering the
air conditioning accelerates demist-
ing by drying out the air.
If the air conditioning is not activated (“A/C light on the 6 switch is off), prolonged
use of recirculated air may cause mist to form on the side windows and wind-
screen as well as other problems due to the presence of non-recirculated air in
the passenger compartment. To avoid this, air recirculation is disabled automati-
cally after a certain time.
3.5
CarManuals2.co
MANUAL AIR CONDITIONING (3/4)
1
Distribution of air in the
The air flow is mainly distrib-
F
uted between the front and
passenger compartment
rear footwells and the dashboard vents.
Turn control 1 to choose the distribution
Close the dashboard vents to direct all
option.
the air to the foot wells.
All the air flow is directed to the
The air flow is distributed be-
J
dashboard vents.
i
tween all the air vents, the
The air flow is directed towards
front side window demisting air vents,
G
the dashboard vents and the
the windscreen demisting vents and the
footwells.
footwells.
All the air is then directed to
W
the windscreen and front side
window demisting vents.
3.6
CarManuals2.co
MANUAL AIR CONDITIONING (4/4)
3
6
7
Switching air conditioning on
The air conditioning system is used
for:
or off
- lowering the temperature inside the
The air conditioning is switched on (in-
passenger compartment;
dicator light lit) or off (indicator light off)
- eliminate condensation more quickly.
using button 6.
The air conditioning does not operate
Activation is not possible if the 3 control
when the exterior temperature is low.
is set to “0”.
Using the air conditioning in hot
weather
To adjust the temperature quickly in hot
weather, switch on the air conditioning
using the 6 button.
Do not open the refriger-
Activate air recirculation by pressing
Vehicles fitted with ECO mode
ant fluid circuit. The fluid
the 3 button.
(switch 7): when activated, ECO
may damage eyes or skin.
mode can reduce the performance
of the heating and/or air condition-
ing ➥ 2.18.
3.7
CarManuals2.co
AUTOMATIC CLIMATE CONTROL (1/4)
4
Adjusting the ventilation
2
3
5
1
6
speed.
In automatic mode, the system uses
the most suitable amount of air to reach
and maintain the desired comfort level.
You can still adjust the ventilation
speed by turning control 1 to increase
or reduce the ventilation speed.
Adjusting the air temperature
Turn control 3 to obtain the desired
temperature.
8
7
Turning the control to the right in-
creases the temperature.
The controls
Automatic mode
(depending on the vehicle)
Special note: the highest and lowest
The automatic climate control system
settings enable the system to produce
1
Adjusting the ventilation fan speed.
guarantees comfort in the passen-
maximum hot or cold temperature
ger compartment and good visibility
2
“Clear View” function.
levels (“16.5°C” and “25.5°C”).
(except in the event of extreme condi-
3
Adjusting the air temperature.
tions), whilst optimising consumption.
4
Automatic mode.
The system controls the ventilation
speed, air distribution, air recirculation,
5
Air conditioning control.
and starting and stopping the air condi-
6
Distribution of air in the passenger
tioning and air temperature.
compartment.
AUTO: allows the selected comfort
7
Air recirculation.
level to be best attained, depending on
the exterior conditions. Press button 4.
8
De-icing/demisting of the rear screen
and, depending on the vehicle, the
rear view mirrors.
Any action on a button other than
the AUTO button triggers deactiva-
tion of automatic mode.
3.8
CarManuals2.co
AUTOMATIC CLIMATE CONTROL (2/4)
Clear View function
2
4
6
Press the 2 button: the integrated indi-
cator light comes on.
This function quickly demists and de-
ices the windscreen, the rear screen,
the front side windows, and the door
mirrors (depending on the vehicle). It
automatically activates the air condi-
tioning and rear screen de-icing func-
tions.
Press button 8 to stop the heated rear
screen operating, and the integrated in-
dicator goes out.
8
To exit this function, press button 2
or 4.
Adjusting the distribution
The air flow is directed towards
the dashboard air vents, the
of air in the passenger
front footwells and, depending on the
compartment
vehicle, the second row footwells.
Turn control 6. The integrated warning
The air flow is mainly directed
light in the button comes on.
to the dashboard air vents.
All the air is then directed to
The air flow is directed mainly
W
the windscreen and front side
towards the footwells.
window demisting vents.
The air flow is distributed be-
tween front side window de-
misting vents, the windscreen demist-
ing vents and the footwells.
Some buttons have an operating
tell-tale which indicates the operat-
ing status.
3.9
CarManuals2.co
AUTOMATIC CLIMATE CONTROL (3/4)
5
9
8
Rear screen de-icing/
Switching air conditioning on
demisting
or off
Press button 8 - the integrated indica-
In automatic mode, the system switches
tor light comes on. This function ena-
the air conditioning system on or off,
bles rapid demisting or de-icing of the
depending on the climate conditions.
rear screen and de-icing of the door
Press the button 5 to force the air con-
mirrors (on equipped vehicles).
ditioning to stop. The integrated warn-
To exit this function, press button 8
ing light will go out.
again. Demisting automatically stops.
Do not open the refriger-
Vehicles equipped with ECO
ant fluid circuit. The fluid
mode (switch 9): when activated,
may damage eyes or skin.
ECO mode may reduce the perfor-
mance of the automatic air condi-
tioning ➥ 2.18.
3.10
CarManuals2.co
AUTOMATIC CLIMATE CONTROL (4/4)
Stopping the system
1
4
Turn the control 1 to “OFF” to stop the
system. To start it, turn the control 1
again, then adjust the fan speed or
press the button 4.
7
Air recirculation (isolation of
Manual use
the passenger compartment)
Press the 7 button: the integrated indi-
cator light comes on.
This function is managed automatically
but you can also activate it manually. In
Prolonged use of this position may lead
this case, the operation is confirmed by
to odours, caused by non-renewal of
a warning light on the button 7.
air, and the formation of condensation
on the windows.
To avoid this, air recirculation is disa-
bled automatically after a certain time.
Fuel consumption increases when
the air conditioning is being used
Using the demisting/de-icing func-
(switch it off when it is not required).
tion will disable the air recirculation.
3.11
CarManuals2.co
AIR CONDITIONING: information and operating instructions (1/2)
Advice on use
Fuel consumption
Operating faults
In some situations (air conditioning off,
You will normally notice an increase in
As a general rule, contact your ap-
air recirculation activated, ventilation
fuel consumption (especially in town)
proved dealer in the event of an oper-
speed at zero or low etc.), you may
when the air conditioning is operating.
ating fault.
notice that condensation starts to form
For vehicles fitted with air conditioning
- Reduction in de-icing, demisting
on the windows and windscreen.
with no automatic mode, switch off the
or air conditioning performance.
system when it is not required.
If there is condensation, use the “Clear
This may be caused by the passen-
View” function to remove it, then use
ger compartment filter cartridge be-
Advice for reducing consumption
the air conditioning in automatic mode
coming clogged.
and helping to preserve the
to stop it forming again.
environment
- No cold air is being produced.
Drive with the air vents open and the
Check that the controls are set cor-
windows closed. If the vehicle has been
rectly and that the fuses are sound.
parked in the sun, open the doors for a
Otherwise, switch off the system.
few moments to let the hot air escape
before starting the engine.
Presence of water under the
vehicle
Maintenance
After prolonged use of the air condi-
Refer to the Maintenance Document
tioning system, it is normal for water
Vehicles equipped with
for your vehicle for the inspection fre-
to be present under the vehicle. This is
modeECO
quency.
caused by condensation.
Once activated, ECO mode may
reduce air conditioning perfor-
mance ➥ 2.18.
Do not add anything to the
vehicle’s ventilation circuit
Do not open the refriger-
(for example, to remove
Use the air conditioning system reg-
ant fluid circuit. The fluid
bad odours).
ularly, even in cold weather, running
may damage eyes or skin.
There is a risk of damage or of
it at least once a month for approxi-
fire.
mately 5 minutes.
3.12
CarManuals2.co
AIR CONDITIONING: information and operating instructions (2/2)
Type of refrigerant fluid
Ñ
A
A
A
Type of oil in the air condi-
tioning circuit
Inflammable product
Consult the driver’s hand-
book
Maintenance
Quantity of refrigerant
x.xxx kg
fluid present in the ve-
hicle.
The refrigerant fluid circuit (of which
some components are hermetically
Global
Warming
sealed) may contain fluorinated green-
GWP xxxxx
Potential (CO2 equiv-
house gases.
alent).
Depending on the vehicle, you will find
the following information on label A af-
CO2 eq
Quantity in weight and
fixed inside the engine compartment.
x.xx t
in CO2 equivalent.
The presence and location of the infor-
mation on label A depends on the ve-
hicle.
Before carrying out any
Do not open the refriger-
action in the engine com-
ant fluid circuit. The fluid
partment, you must switch
may damage eyes or skin.
off the ignition ➥ 2.3.
3.13
CarManuals2.co
ADDITIONAL AIR CONDITIONING (1/2)
2
1
On equipped vehicles, there are four
Vehicle fitted with manual air
adjustable air vents and a control con-
conditioning
sole 1.
Make sure that the air conditioning is
These controls only affect the amount
operational (warning light on button 2
of air blown into the passenger com-
lit up).
partment:
Note: the button 2 has an operation
- one control for hot (air comes from
warning light:
lower vents);
- if the warning light is on, this indi-
- one control for cold (air comes from
cates that the function is in opera-
upper vents).
tion;
Note: avoid closing the four air vents
- indicator light off, the function is
at the same time (risk of damaging the
switched off.
system components).
3.14
CarManuals2.co
ADDITIONAL AIR CONDITIONING (2/2)
5
1
3
4
Vehicle fitted with automatic
Note: the switch 3 and the control con-
sole 1 are fitted with an operation warn-
air conditioning
ing light:
Make sure that the air conditioning is
- if switch 3 and warning light 5 are
operational (warning light on A/C OFF 4
illuminated, this indicates that con-
button illuminated).
trol 1 is not activated;
To activate the control console set-
- if switch 3 and warning light 5 are off,
tings 1, press the 3 switch. Switch 3
this indicates that control 1 is in op-
warning light and 5 control 1 warning
eration.
light are off.
3.15
CarManuals2.co
MULTIMEDIA EQUIPMENT (1/2)
1
3
4
5
2
6
The presence and location of this
Radio 3
Steering wheel controls 4
equipment depends on the vehicle’s
On those vehicles equipped, you can
multimedia equipment.
use the hands-free telephone con-
1 Multimedia touchscreen.
trols 5 and voice recognition 6.
2 Steering column control.
3 Radio.
To operate this equipment: please
refer to the driver’s handbook.
3.16
CarManuals2.co
MULTIMEDIA EQUIPMENT (2/2)
8
7
Microphone 7
Induction charger 8
(depending on the vehicle)
➥ 3.25
Using the telephone
We remind you of the need
to conform to the legislation
in force concerning the use
of such equipment.
3.17
CarManuals2.co
WINDOWS (1/3)
Avoid resting any objects against
3
a half-open window: there is a risk
1
that the electric window could be
damaged.
2
Driver’s responsibility
Never leave your vehicle
with the card or key inside
when there is a child, de-
Electric windows
From the front passenger seat
pendent adult or a pet in it, even for
Press switch 3.
a short while. They may pose a risk
With the ignition on:
to themselves or to others by start-
- press the switch for the window
ing the engine or activating equip-
concerned to lower it to the desired
ment (such as the gear lever or
height;
electric windows). If any part of the
- lift the switch for the window con-
body becomes trapped, reverse the
cerned to raise it to the desired
direction of the window immediately
height.
by pressing the relevant switch.
Risk of serious injury.
From the driver’s seat
Operate the switches as follows:
- 1 for the driver’s side;
- 2 for the front passenger side.
3.18
CarManuals2.co
WINDOWS (2/3)
Impossible to operate the
Operating faults
one-touch electric window
In case of a fault when closing a window,
The one-touch electric window is
the system reverts to normal mode:
equipped with heat protection: if you
pull the switch concerned up as often
press the switch for the window more
as necessary to fully close the window
than sixteen consecutive times it goes
(the window will close gradually), hold
into protection mode
(locking the
the switch (still on the closure side) for
window).
one second then lower and raise the
1
window fully to reinitialise the system.
You can:
If necessary, contact your authorised
- use the electric window switch briefly
dealer.
and with intervals of approximately
30 seconds;
- with the engine running, the window
will be unlocked after approximately
One-touch mode
20 minutes of inaction on the electric
window switch.
Depending on the vehicle, this mode
works in addition to the operation of the
Note: if the window detects resistance
electric windows described previously.
when closing (e.g.: branch of a tree,
It is only fitted to the driver’s window.
etc.) it stops and then lowers again by a
few centimetres.
Briefly press or pull switch 1 fully: the
window is fully lowered or raised.
Pressing the switch again stops the
window moving.
When closing the windows,
ensure that no part of the
body (arm, hand, etc.) is
protruding from the vehicle.
Risk of serious injury.
3.19
CarManuals2.co
WINDOWS (3/3)
4
Sliding rear windows
Move the handle 4 and slide the window
to the desired notch.
Sliding windows and
doors
Before moving them,
ensure that no passenger
has part of their body outside the
window or door.
3.20
CarManuals2.co
SUN VISOR
1
3
2
1
Sun visor
Wide angle rear view mirror 2
Courtesy mirror 3
(depending on the vehicle)
(depending on the vehicle)
Lower sun visor 1.
Lower the sun visor to access the
Lower the sun visor to access the cour-
The sun visor can be swung round
wide-angle rear view mirror.
tesy mirror.
against the window.
Special feature of the wide-angle
rear view mirror 1.98.
3.21
CarManuals2.co
INTERIOR LIGHTING (1/3)
1
4
3
1
2
Courtesy lights
Map reading light
(depending on the vehicle)
Using switches 1, 2 or 3 will activate:
Move switch 4.
- permanent lighting;
- intermittent lighting, which comes on
when a door is opened. It goes out
when the doors concerned are prop-
erly closed;
- immediate switching off.
When the doors are unlocked and
opened, the courtesy and footwell
lights come on temporarily.
3.22
CarManuals2.co
INTERIOR LIGHTING (2/3)
6
5
Glove box light 5
Luggage compartment light 6
This lights up when the glovebox is
It comes on when the boot is opened.
opened.
With the doors properly shut, lock-
ing or starting the engine make the
interior lights and the courtesy lights
go out.
3.23
CarManuals2.co
INTERIOR LIGHTING (3/3)
9
8
7
Light for rear seats 7
Rear light 8
Press the switch 7 to activate:
Turn the switch 9 to activate:
– permanent lighting;
- permanent lighting;
– lighting controlled by opening one of
- intermittent lighting, which comes
the doors.
on when a rear door is opened. The
light only goes out when the doors
are correctly closed;
- lighting switches off immediately.
3.24
CarManuals2.co
PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (1/10)
1
1
1
2
2
Cup holder 1
Passenger cup-holder 1
Right-hand driving position
storage compartments
This location can be used as a cup
holder, a storage compartment or as a
receptacle to fit the ashtray.
Open storage compartment 2
Nothing should be placed
on the floor (area in front of
driver) as such objects may
slide under the pedal during
braking manoeuvres, thus obstruct-
ing its use.
Do not place your card in the 2 stor-
age compartment as it may not be
detected.
3.25
CarManuals2.co
PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (2/10)
3
It is essential not to leave any ob-
jects (start-up card, USB drive, SD
card, credit card, jewellery, keys,
coins, etc.) in the induction charging
area 4 whilst charging your phone.
Remove all magnetic cards or credit
4
cards from the case before position-
ing your telephone in the induction
charging area 4.
Sun blind storage
Centre console storage
Ensure that no hard, heavy
compartment 3
compartment/induction
or pointed objects are
placed in the “open” storage
charging zone 4
This can be used for storing motorway
compartments in such a
tickets, cards, etc.
For more information on the induction
way that they may fall onto passen-
charging zone, please refer to the mul-
gers during sudden turning, braking
timedia instructions.
or in the event of an accident.
Using a telephone and/or
multimedia tablet
Objects left in the induction charg-
We remind you of the need
ing area 4 may overheat. You are
to conform to the legislation
advised to place them in the areas
in force concerning the use of such
provided for this purpose (storage
equipment.
compartment, sun visor compart-
ment etc.).
3.26
CarManuals2.co
PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (3/10)
6
8
7
5
Storage compartment 5
Radio location 6
Dashboard storage
compartment 7 and 8
It can hold payment cards, money, A4-
sized documents etc.
Ensure that no hard, heavy
Nothing should be placed
or pointed objects are
on the floor (area in front of
placed in the “open” storage
driver) as such objects may
compartments in such a
slide under the pedal during
way that they may fall onto passen-
braking manoeuvres, thus obstruct-
gers during sudden turning, braking
ing its use.
or in the event of an accident.
3.27
CarManuals2.co
PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (4/10)
9
11
10
Dashboard storage 9
Dashboard passenger
storage compartment 10
and 11
Ensure that no hard, heavy
or pointed objects are
placed in the “open” storage
compartments in such a
way that they may fall onto passen-
gers during sudden turning, braking
or in the event of an accident.
3.28
CarManuals2.co
PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (5/10)
14
12
12
15
13
13
Glove compartment 12
Right-hand driving position
Passenger storage drawer 14
glovebox
To open, press the control 13.
To open, press control 15.
Depending on the vehicle, the glove
Depending on the vehicle, the glove
box may have ventilation and air con-
box may have ventilation and air con-
ditioning (one 1.5 litre bottle can be
ditioning (one 1.5 litre bottle can be
stored there).
stored there).
Maximum weight allowed in the
Maximum permitted load in the stor-
glove box 12: 4 kg evenly distrib-
age drawer 14: 4 kg, evenly distrib-
uted.
uted.
3.29
CarManuals2.co
PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (6/10)
17
16
A
18
Front door storage
Storage compartment 18
compartments 16
under the front seat
To access this, pull the tabs 17 and tilt
the seat base A forwards.
Always close the seat base
when driving:
- there is a risk of injury
when braking suddenly or in
the event of an accident;
- there is a risk of objects being
hurled through the passenger
compartment.
3.30
CarManuals2.co
PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (7/10)
24
21
22
20
21
24
23
19
Seatback in table position
Storage compartment 21
On equipped vehicles, lower the back
To open, press control 20.
of the centre seat by lifting the con-
The strap 24 inside can keep an item
trol 23. On the back of the centre seat
in position.
you will find:
With the storage 21 closed, the ap-
- a cup holder 19;
erture 24 allows you to plug a device
- storage 21;
charging cable into an accessories
socket.
- a shelf 22.
It is forbidden to sit in the
centre seat if its seatback is
folded down.
3.31
CarManuals2.co
PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (8/10)
28
22
25
22
20
27
29
30
26
Tray 22
You can attach it using the document
Rear seat storage pockets 30
grip 28.
To unlock the tray, press the control 20.
To remove the tray, press the con-
To install the tray, insert the end
trol 29.
pieces 25 of the tray into the slots 26
or 27.
Note: make sure you replace the tray
and remove any item from the cup
holder before raising the centre seat
back. Check that the back of the centre
Ensure that no hard, heavy
seat is properly locked.
When turning corners,
or pointed objects are
accelerating or braking,
placed in the open storage
ensure that the recepta-
compartments in such a
cle being held by the cup
way that they may fall on any pas-
holder is not dislodged.
sengers during sudden turning,
There is a risk of burning if hot
braking or in the event of an acci-
liquid escapes.
dent.
3.32
CarManuals2.co
PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (9/10)
33
32
31
Grab handle 31
Clothes hooks 32
Rear load area storage
compartment 33
This offers support and can be held
Depending on the vehicle, hooks may
when the vehicle is being driven.
be placed in the partition in the loading
Reserved for the transport of objects
space.
only.
For safety reasons, this hook may only
The total weight of the rear load area
be used to hang clothes.
storage compartment must not exceed
35 kg, evenly distributed.
Do not hang any heavy and/
or sharp objects which may
fall while you are driving.
Do not use the grab handle 31 for
Risk of injury.
getting into or out of the vehicle.
3.33
CarManuals2.co
PASSENGER COMPARTMENT STORAGE SPACE AND FITTINGS (10/10)
36
35
B
37
34
36
Recess 34 and flap 36
Use the flap 36 to extend the load
length:
Depending on the length of the objects
being transported in the rear load area,
- pull the tab 35 to raise the seat B;
you can use recess 34.
- move the flap 36 towards the interior
Open the flap 36, held in place by mag-
of the seat by pulling the tab 37.
nets.
Nothing should be placed
When the flap 36 is open,
Ensure that no hard, heavy
on the floor (area in front
use of the front side pas-
or pointed objects are
of driver) as these objects
senger seat is prohibited.
placed in the “open” storage
may slide under the pedals
compartments in such a
Risk of serious injury
during sudden braking manoeuvres,
way that they may fall onto passen-
when braking sharply or in an
thus obstructing their use.
gers during sudden turning, braking
impact.
or in the event of an accident.
3.34
CarManuals2.co
ACCESSORIES SOCKETS (1/2)
2
3
1
Accessories sockets
The 1 socket and, depending on the
vehicle, the 2, 3 and 4 sockets are
designed for connecting accessories
which have been approved by our
Technical Department. Their power
Connect accessories
level should not exceed
120 Watts
with a maximum power of
(12 V).
120 Watts (12 V) only.
When several accessory
sockets are used at the same time,
the total power of the connected
Before leaving the vehicle, ensure
accessories must not exceed
that you always disconnect all de-
180 watts.
vices from the accessories sockets
Fire hazard.
to avoid possible malfunctions (dis-
charged battery, locking the opening
elements not possible etc.).
3.35
CarManuals2.co
ACCESSORIES SOCKETS (2/2)
4
5
5
6
Cup holders 5 and 6
This can be used to store a mobile ash-
tray, drink cans, etc.
If your vehicle is not fitted with a
cigar lighter and an ashtray, these
can be obtained from an approved
Dealer.
3.36
CarManuals2.co
REAR HEAD RESTS
2
1
To raise the headrest
To refit the headrest
Press button 1 and lift the headrest to
Insert the headrest rods into the holes
release it (tilt the seatback if neces-
(tilt the seatback if necessary). Lower
sary).
the headrest as far as it will go, then
lift until it locks into place. Check that
each rod 2 on the seatback is securely
locked.
The headrest is a safety
component, check that it is
fitted and in the correct po-
sition.
3.37
CarManuals2.co
REAR BENCH SEATS: functions (1/4)
1
2
A
3
4
5
Depending on the vehicle, there may
Bench seat 2
be two rear bench seats: bench seat 2
Insert the buckles 3 into the housings 4
(2nd row of seats) and bench seat 1
before moving the seatback(s).
(3rd row of seats).
To assist with access to the last row
(bench seat 1), move control 5 down-
wards (movement A) to tilt the bench
seat back 2.
Remember to lock the seat belt in place
once more when a passenger is occu-
pying the seat.
Ensure that the bench seats
are locked in place correctly
when refitting them.
For safety reasons, carry
Check that the side seat
out any adjustments when
belts are locked in their unit cor-
the vehicle is not being
rectly.
driven.
3.38
CarManuals2.co
REAR BENCH SEATS: functions (2/4)
1
C
7
C
6
B
8
Bench seat 1
To fold it down
To fold down
(depending on the vehicle)
This can be folded away and folded
- Pull seat back unlocking strap 6;
down.
- Hold the bars 7 and bring them to-
- fold down the seatback onto the seat
gether simultaneously
(move-
base.
ment B);
- tilt the seat unit forwards until it locks;
- press on the top of the seat (at C)
and lock the seat in position by
When moving the rear
pushing the locking levers 8;
bench seat, check that
- ensure it is correctly locked in place.
the bench seat anchor-
age points are clean (they
should be free from grit, cloths or
any other item which may prevent
the bench seat from locking se-
curely).
3.39
CarManuals2.co
REAR BENCH SEATS: functions (3/4)
1
2
H
9
9
E
C
G
D
F
Removal/refitting of bench
Removal
- move the bench seat towards the
rear of the vehicle to release the an-
seat 1 and 2
First, release the side seat belts by un-
chorage points (movement F);
(depending on the vehicle)
locking them from their unit.
- lift the bench seat (movement G);
These are removed and refitted in the
- Underneath the bench seat, press
same way.
on the latch 9, then pull it forwards
- move the bench seat towards the
(movements C and D);
rear again (movement H) to release
the front anchorage points;
- lift (movement E);
- remove the bench seat from the front
of the vehicle.
For safety reasons, carry
It is not permitted to swap
out any adjustments when
the vehicle is not being
Remove bench seat 2 before re-
bench seats 1 and 2
driven.
moving bench seat 1.
3.40
CarManuals2.co
REAR BENCH SEATS: functions (4/4)
9
Refitting
- position the bench seat over the front
anchorage points;
Ensure that the bench seats
- push the bench seat until it sits over
are locked in place correctly
the rear anchorage points;
when refitting them.
- Lower latches 9 and push them until
Check that the side seat
they lock in place;
belts are locked in their unit cor-
rectly.
- ensure the proper alignment of the
visual markers on the latches 9.
The rear bench seats must
be placed on their original
anchorage points.
Driving with the bench seat
in a rear-facing position is prohib-
ited.
3.41
CarManuals2.co
LUGGAGE COVER
A
1
A
B
The luggage cover is made up of one or
two rigid sections.
There are two possible positions:
- top position A;
- the lower position B.
Depending on the vehicle, you can lift
the section 1 to a vertical position to
make loading easier.
Do not place any objects,
especially heavy or solid
objects on the luggage
cover. These may pose a
risk to the vehicle occupants if the
driver has to brake suddenly or if the
vehicle is involved in an accident.
3.42
CarManuals2.co
LUGGAGE NET (1/2)
1
2
3
A
4
6
5
7
On equipped vehicles, the luggage
Fitting the luggage net
Lower mounting:
net A can be used, when transporting
behind the front seats
- attach the net strap hook 5 onto the
animals or luggage, to separate them
ring 7 at the base of the bench seat;
from the passenger section.
Inside the vehicle on each side:
- adjust the net strap so that it is taut.
It can be positioned:
Upper mounting:
- behind the front seats;
- lift and hold the cover 2, using a flat-
Removal
blade screwdriver, to access the
– behind a rear bench seat.
Loosen the strap by lifting adjustment
mounting hole;
device 6 upwards. Detach the belts.
- fully insert the top rod 1 of the net
into the largest section 3 of the hole;
- slide the rod into the lower section 4
of the hole.
Make sure that the rod
end 1 is supported by the
metal part and not the plas-
tic part of the cover.
3.43
CarManuals2.co
LUGGAGE NET (2/2)
1
2
A
3
4
8
5
Fitting the luggage net A
Lower mounting:
behind the rear seats
- fix the net belt hook 5 onto the ring 8;
Inside the vehicle on each side:
- adjust the net strap so that it is taut.
Upper mounting:
Removal
- lift and hold the cover 2, using a flat-
Loosen the strap. Detach the belts.
blade screwdriver, to access the
mounting hole;
- fully insert the top rod 1 of the net
into the largest section 3 of the hole;
- slide the rod into the lower section 4
of the hole.
Make sure that the rod
end 1 is supported by the
metal part and not the plas-
tic part of the cover.
3.44
CarManuals2.co
TRANSPORTING OBJECTS (1/2)
1
1
2
Always position the heav-
Transporting objects in the
Ensure that the objects being trans-
iest items directly on the
ported are evenly distributed through-
floor.
rear load area
out the loading area.
Use the lashing points on
Depending on the vehicle, secur-
the luggage compartment floor, if
ing rings 1 and 2 can be used to stop
these are fitted to the vehicle. The
transported objects from moving. The
load should be loaded in such a way
number of rings and their locations may
that no items will be thrown forward
vary depending on the vehicle.
and strike the occupants if the driver
has to brake suddenly or while driv-
ing on a steep gradient.
Fasten the rear seat belts, even if
the seats are not occupied.
The sole purpose of these rings 1 is
to prevent transported objects from
moving. The objects must be se-
cured to the mounting rings 2 on the
vehicle floor beforehand.
3.45
CarManuals2.co
TRANSPORTING OBJECTS (2/2)
Special note for van version
F max: 400 daN
While driving with the right
rear hinged door open,
always secure transported
loads.
The left-hand door, which remains
shut, should not be used to hold
transported loads in place. Using
the right rear hinged door open
while driving should only be done in
exceptional cases.
In any event, please refer to local
For your safety, check that
legislation.
all the vehicle’s doors are
properly closed before
Risk of loads falling on the road
starting the engine.
surface.
3.46
CarManuals2.co
TRANSPORTING OBJECTS: towing (1/2)
A
B
1
1
2
Fitting towing equipment
Fitting the towbar coupling
ball
A: 1093 mm (43.03”)
Position the ball within the range of
bolts 1 or 2, to respect the height B,
which must be between
350 and
420 mm, with the vehicle loaded (use
the illustration example below).
To assemble the towbar ball, please
consult the equipment assembly in-
structions.
3.47
CarManuals2.co
TRANSPORTING OBJECTS: towing (2/2)
Special note related to connecting/
disconnecting a trailer to/from the
towing system
On each first connection and when a
trailer is disconnected from the towing
system (caravan, trailer, etc.) or when a
defective bulb is replaced in your vehi-
Permissible nose weight, maxi-
cle ➥ 5.21, the vehicle and trailer light-
mum permissible towing weight
ing systems must be synchronised.
with or without braking ➥ 6.10.
To do this:
Choice and fitting of towing
– switch off all of the lights on your ve-
equipment
hicle (interior and exterior);
Maximum weight of towing equip-
- switch off the ignition;
ment:
- get out of your vehicle, then lock
all the doors using the key or the
- 9.5 kg on a vehicle with towing
“hands-free” card ➥ 1.5, ➥ 1.12;
pre-equipment;
– wait approximately 5 minutes before
- 31.5 kg on a vehicle without
accessing your vehicle again.
towing pre-equipment.
Before driving, check the lighting func-
It is not permitted to fit a mechanical
tions.
towing device (ball, hook, etc.) that
Note: when connecting/disconnecting
is removable without tools or retract-
Any towing device must not ob-
the trailer with the lights on, the trailer
able if it cannot be easily removed
struct any lighting component or
lights may flash.
or repositioned when not in use.
the number plate when not in use.
Mechanical towing devices (ball,
To assemble the towbar ball, please
hook, etc.) which can be removed
consult the equipment assembly in-
without tools and retractable objects
structions.
must be removed or repositioned
Please keep these instructions with
when they are not in use.
the rest of the vehicle documenta-
In all cases, you must comply with
tion.
the regulations of the particular
country you are in.
3.48
CarManuals2.co
ROOF BARS
Precautions during use
1
Handling the tailgate
1
Before handling the tailgate, check the
objects and/or accessories (bike rack,
roof box, etc.) fitted to the roof bars:
these must be correctly positioned and
secured, so as not to hinder the opera-
tion of the tailgate.
Accessing the mounting
points 1
For information on the range of
equipment adapted to your vehi-
cle, we advise you to consult an ap-
proved Dealer.
Refer to the manufacturer’s instruc-
tions for information on how to fit
If original roof bars, ap-
and use the roof rack bar.
proved by our Technical
Department, are supplied
Please keep these instructions with
with screws, only use these
the rest of the vehicle documenta-
screws for attaching the roof bars to
tion.
the vehicle.
Maximum permissible load on
roof rack ➥ 6.10.
3.49
CarManuals2.co
3.50
CarManuals2.co
Section 4: Maintenance
Bonnet
4.2
Engine oil level: general information
4.4
Engine oil level: topping up, filling, oil change
4.5
Oil change
4.6
Levels
4.7
engine coolant
4.7
brake fluid
4.8
windscreen washer reservoir
4.9
Filters
4.9
Tyre pressure
4.10
Battery
4.12
Bodywork maintenance
4.14
Interior trim maintenance
4.17
4.1
CarManuals2.co
BONNET (1/2)
Before carrying out any
action in the engine com-
partment, you must switch
off the ignition ➥ 2.3.
1
Do not press down on the
bonnet: there is a risk that
the bonnet may accidentally
Please note when work-
close.
ing close to the engine that
To open the bonnet, pull the handle 1.
it may be hot. In addition,
the engine cooling fan may
In the event of even a slight
impact involving the radi-
start at any moment. The
ator grille or bonnet, have
warning light in the engine compart-
the bonnet lock checked by
ment reminds you of this.
an approved dealer as soon as pos-
Risk of injury.
sible.
After any procedure in the
engine compartment, make
When working in the engine
sure that you do not forget
compartment, ensure that
anything (cloth, tools, etc.).
the windscreen wiper stalk
These may damage the engine or
is in the park position.
cause a fire.
Risk of injury.
4.2
CarManuals2.co
BONNET (2/2)
Closing the bonnet
Check that nothing has been left in the
engine compartment.
To close the bonnet again, hold the
bonnet in the middle and lower it to
30 cm above the closed position, then
release it. It will latch automatically
under its own weight.
2
Unlocking the bonnet catch
To unlock, push the tab 2 to the left as
you open the bonnet.
Opening the bonnet
Lift the bonnet, helping it up, and it will
rest in position with the help of struts.
Ensure that the bonnet is
properly locked.
Check that nothing is pre-
venting the catch from lock-
ing (gravel, cloth, etc.).
4.3
CarManuals2.co















Content      ..     4      5      6      7     ..
