DETECTION OF ROAD SIGNS (2/4)

- press the 4 or 5 control repeatedly

to reach the “Settings” menu and

press 6 OK;

- press the 4 or 5 control repeatedly to

reach the “DRIVING ASSIST” menu

and press 6 OK;

- press the 4 or 5 control repeatedly

to reach the “Speed alert” menu and

press 6 OK;

- press the 6 OK switch to activate or

deactivate the function:

function activated

function deactivated

Activating/deactivating the

With the function activated, depend-

ing on local regulations, you can acti-

system

vate the “Risk area display” option. The

Vehicles fitted with a multimedia

system will notify you of the distance

screen 2

separating you from this zone, and

while you are travelling in the zone.

To activate or deactivate the function,

refer to the multimedia instructions.

Vehicles not fitted with a multimedia

Select “ON” or “OFF”.

screen

- With the vehicle stopped, press the

switch 3 as many times as required

to reach the “Vehicle” tab;

2.60

CarManuals2.co

DETECTION OF ROAD SIGNS (3/4)

If the speed limit is exceeded, the circle

around the panel flashes (7 warning

light) along with a sound signal to warn

the driver.

Operation

Varying the limit speed

If the speed limit notification differs from

Warning lights

the detected speed value, press and

The function displays the following

hold the following switches:

warning lights:

- 9 (RES/+) to increase the notification

7 Speed limit road signs.

speed to the detected speed;

8 Additional road signs (start or end

- 10 (SET/-) to reduce the notification

of “No overtaking” zone, slip road

speed to the detected speed.

speed limit, speed in case of a cara-

van, speed limit with length of appli-

cation etc.)

2.61

CarManuals2.co

DETECTION OF ROAD SIGNS (4/4)

Operating faults

The system cannot detect the speed

limit if:

- the windscreen is not clean;

- the camera is blinded by the sun;

- there is insufficient visibility (night,

fog etc.);

- the signs are not legible (snow, etc.)

or are hidden (by another vehicle or

by trees);

- the information taken from the navi-

gation system is not up to date.

This function is an additional driving aid. This function is not under any

circumstances intended to replace the due care and attention of the

driver, who should at all times be in control of the vehicle.

The driver should always adapt their speed to the traffic conditions, re-

gardless of the system indications.

The system detects speed limit signs and does not detect other signs (e.g. entry/

exit to/from urban areas, etc.).

The system may not detect all speed limit signs or may interpret them incorrectly.

The driver should not ignore signs that are not detected by the system and should,

as a priority, comply with the traffic signage and the highway code.

In the event of poor visibility (fog, snow, frost, etc.), it is possible that the system

may not indicate the correct speed to the driver.

The driver should always adapt their speed to the traffic conditions, regardless of

the system indications.

2.62

CarManuals2.co

SPEED LIMITER (1/4)

The speed limiter function helps you

stay within the driving speed limit that

you choose, known as the limit speed.

The speed limiter is linked with the “Hill

Descent Control” function, enabling use

of the braking system to optimise down-

hill speed limitation.

Temporarily not available

The system controls accelera-

tion and deceleration of your vehi-

cle using the engine and braking

system. The system activates the

brakes in order to maintain the set

speed, the system applies limited

braking. In the event of a steep de-

Controls

scent, for example in a mountainous

Speed limiter On/Off switch.

area, you must select a lower gear

Cruise control On/Off switch.

to benefit from engine braking.

Switch to activate and decrease the

To reduce the load imposed on the

limit speed (SET/-).

braking system and to prevent the

brakes from overheating, the speed

Switch to activate and increase the

limiter function may be temporar-

limit speed or to set the stored limit

ily interrupted and the message

speed (RES/+).

“Check Speed Limiter” may appear.

Speed limiter function standby (with

The message disappears when the

limited speed memory) (0).

function becomes available again.

If the message remains, contact an

approved dealer.

You can link the speed limiter to

the “Road sign detection” function.

➥ 2.59.

2.63

CarManuals2.co

SPEED LIMITER (2/4)

Driving

Switching on

To store the current speed, press the 4

switch (RES/+) or the 3 switch (SET/-

When a limit speed has been set but

Press the switch 1. The 6 warning light

): the limit speed replaces the dashes

not yet reached, driving is similar to

appears in grey. The “Speed limiter ON”

and, depending on the vehicle, the 6

driving a vehicle without the speed lim-

message appears on the instrument

warning light appears in white.

iter function.

panel accompanied by dashes to indi-

cate that the speed limiter function is in

The minimum stored speed is 19 mph

Once you have reached the stored

operation, waiting to store a limit speed.

(30 km/h).

speed, no effort on the accelera-

tor pedal will allow you to exceed

the programmed speed except in an

emergency (refer to information on

“Exceeding the limit speed”).

2.64

CarManuals2.co

SPEED LIMITER (3/4)

Exceeding the limit speed

It is possible to exceed the limit speed

at any time. To do this: press the accel-

erator pedal firmly and fully (beyond

the resistance point).

While the speed is being exceeded, the

speed limiter flashes red on the instru-

ment panel. Then, release the accelera-

tor pedal: the speed limiter function will

return as soon as you reach a speed

lower than the memorised speed.

Varying the limit speed

The limit speed may be changed by

pressing repeatedly or holding down:

- switch 4 (RES/+) to increase speed;

- switch 3 (SET/-) to reduce speed.

You must keep your feet

near the pedals to be

ready to react in an emer-

gency.

If the speed limiter is not

available (after several at-

tempts to activate), contact

an approved dealer.

2.65

CarManuals2.co

SPEED LIMITER (4/4)

Putting the function on

Switching off the function

standby

The speed limiter function is inter-

The speed limiter function is suspended

rupted:

when you press switch 5 (0). The limit

- when you press the 1 switch. In this

speed is stored and displayed in grey

case, the speed is no longer stored;

on the instrument panel.

- when you press the 2 switch. In this

case the cruise control is selected

Recalling the limit speed

and there is no stored speed.

If a speed has been stored, it can be re-

The warning light 6 disappears from the

called by pressing the 4 switch.

instrument panel and the Limiter OFF

message appears to confirm that the

When the speed limiter is set to

function is disabled.

standby, pressing the

3 switch

re-activates the function without

taking into account the memorised

speed: the speed at which the vehi-

cle is moving is taken into account.

2.66

CarManuals2.co

CRUISE CONTROL (1/5)

The cruise control function helps you to

maintain your driving speed at a speed

that you choose, called the cruising

speed.

This cruising speed may be set at any

speed above 19 mph (30 km/h).

The cruise control function is linked

with the “Hill Descent Control” function,

enabling use of the braking system to

optimise downhill cruise control.

This function is an addi-

tional driving aid.

It can under no circum-

stances replace the driver’s

Controls

responsibility to respect speed limits

or to be vigilant.

1 Cruise control On/Off switch.

The driver must always be in control

2 Switch to activate and decrease

of the vehicle.

cruising speed (SET/-).

Cruise control must not be used in

3 Switch to activate and increase

heavy traffic, on undulating or slip-

cruising speed or to recall the mem-

pery roads (black ice, aquaplan-

orised cruising speed (RES/+).

ing, gravel) and during bad weather

4 Switch the function to standby (with

(fog, rain, side winds etc.).

cruising speed saved) (0).

There is a risk of accidents.

5 Speed limiter On/Off switch.

2.67

CarManuals2.co

CRUISE CONTROL (2/5)

Switching on

Activating cruise control

Driving

Press the switch 1.

While the vehicle is moving a steady

Once a cruising speed is registered

speed above approximately 19 mph

and the cruise control function is active,

The 6 warning light appears in grey.

(30 km/h), press the 2 (SET/-) switch

you may lift your foot off the accelera-

The “Cruise control ON” message ap-

or the 3 (RES/+) switch : the function

tor pedal.

pears on the instrument panel accom-

is activated and the current speed is

panied by dashes to indicate that the

taken into account.

cruise control function is in operation

The cruising speed replaces the

and waiting to memorise a cruising

dashes. Cruise control is confirmed

speed.

when the memorised speed and warn-

ing light appear in green 6.

If you try to activate the function below

19 mph (30 km/h), the message “Invalid

Please note that you must

Speed” will be displayed and the func-

keep your feet close to the

tion will remain inactive.

pedals in order to react in

an emergency.

2.68

CarManuals2.co

CRUISE CONTROL (3/5)

Exceeding the cruising speed

The cruising speed may be exceeded

at any time by depressing the accelera-

tor pedal.

While it is being exceeded, the cruising

speed flashes in red on the instrument

panel. Then, release the accelerator

pedal: after a few seconds, the vehicle

Temporarily not available

will automatically return to its set cruis-

ing speed.

The system controls accelera-

tion and deceleration of your vehi-

cle using the engine and braking

system. The system activates the

brakes in order to maintain the set

speed, the system applies limited

braking. In the event of a steep de-

Adjusting the cruising speed

scent, for example in a mountainous

The cruising speed may be changed by

area, you must select a lower gear

pressing the following repeatedly:

to benefit from engine braking.

- the 2 switch (SET/-) to reduce the

To reduce the load imposed on the

speed;

braking system and to prevent the

You must keep your feet

- the 3 switch (RES/+) to increase the

brakes from overheating, the cruise

near the pedals to be

speed.

control function may be temporar-

ready to react in an emer-

ily interrupted and the message

Note: press and hold one of the

gency.

“Check Cruise Control” may appear.

switches to modify speed by succes-

The message disappears when the

sive increments.

function becomes available again.

If the message remains, contact an

If the cruise control is no

approved dealer.

longer available (after sev-

eral attempts to activate

it), contact an Approved

Dealer.

2.69

CarManuals2.co

CRUISE CONTROL (4/5)

Putting the function on

Returning to the cruising speed

Note: if the speed previously stored is

much higher than the current speed,

standby

If a speed is stored, it can be recalled,

the vehicle will accelerate more rapidly

once you are sure that the road condi-

The function is set to standby if you:

to reach this threshold.

tions are suitable (traffic, road surface,

- 4 switch (0);

weather conditions, etc.). Press the

When the cruise control is set to

- the brake pedal;

switch 3 (RES/+) if the vehicle speed is

standby, pressing switch 2 (SET/-) re-

above 19 mph (30 km/h).

activates the cruise control function

- the clutch pedal for a prolonged

without taking into account the stored

period or upon prolonged neutral po-

When the speed is stored, cruise con-

speed: it is the speed at which the vehi-

sition on vehicles equipped with a

trol activation is confirmed by the dis-

cle is moving that is taken into account.

manual gearbox;

play in green of the cruising speed and,

depending on the vehicle, the 6 warn-

- shifting to neutral position on ve-

ing light is displayed.

hicles equipped with an automatic

gearbox.

The cruising speed is stored and dis-

played in grey on the instrument panel.

2.70

CarManuals2.co

CRUISE CONTROL (5/5)

Switching off the function

Warning light

6 and the message

“Cruise control OFF” disappear from

The cruise control function is inter-

the instrument panel to confirm that the

rupted:

function has stopped.

- when you press the 1 switch. In this

case, there is no stored speed;

- when you press the 5 switch. In this

case, the speed limiter is selected

and there is no stored speed.

Putting the cruise control

on standby or switching it

off does not cause a rapid

reduction in speed: you

must brake by depressing the brake

pedal.

2.71

CarManuals2.co

ADAPTIVE CRUISE CONTROL (1/14)

Based on information from a radar or

The adaptive cruise control function is

Note:

camera, the adaptive cruise control

available between 18 mph (30 km/h)

- the driver must observe the maxi-

function gives you the option of main-

and 105 mph (170 km/h), depending

mum speed limit and safe distances

taining a selected speed, known as the

on the conditions on the road (traffic,

in the country where they are driving;

cruising speed, while keeping a safe

weather etc.).

distance from the vehicle in front in the

- the adaptive cruise control can brake

same lane.

The function is indicated by the 

the vehicle up to a third of the brak-

ing capacity. Depending on the situ-

symbol.

The system controls acceleration and

ation, the driver may need to brake

deceleration of your vehicle using the

harder.

engine and braking system.

The system’s maximum range is ap-

proximately

150 metres. This may

vary according to the road conditions

(ground relief, weather conditions, etc.)

This function is an additional driving aid. It can under no circumstances

replace the driver’s responsibility to respect speed limits or to be vigilant.

The driver should always keep control of their vehicle. The driver should

always adapt their speed according to the surroundings and the driving

conditions. The adaptive cruise control must only be used on a motorway (or mul-

ti-lane road separated by a barrier). The cruise control must not be used in heavy

traffic, on winding or slippery roads (black ice, aquaplaning, gravel) or during bad

weather (fog, rain, side winds etc.).

There is a risk of accidents.

The adaptive cruise control does

not trigger an emergency stop and

its braking capability is limited.

2.72

CarManuals2.co

ADAPTIVE CRUISE CONTROL (2/14)

Location of the camera 1

Controls

Displays

Make sure the windscreen is not ob-

3 Safe distance settings

Adaptive cruise control warning

scured (by dirt, mud, snow, condensa-

light.

4 Switch the function to standby (with

tion etc.).

cruising speed saved) (0).

Vehicle in front.

5 Adaptive cruise control main stop/

Stored safe distance

Location of the radar 2

Stored cruising speed.

start switch 

Ensure that the radar area is not ob-

structed

(dirt, mud, snow, a badly

6 Cruising speed activation, storage

fitted/attached front number plate), im-

and decrease switch (SET/-).

pacted, modified (including paintwork)

7 Switch to activate and increase cruis-

or hidden by any accessory fitted on the

ing speed or to recall the memorised

The radar and camera

front of the vehicle (on the grille or logo

cruising speed (RES/+).

zones must be kept clean

etc.).

and free of any tampering in

order to ensure the proper

operation of the system.

2.73

CarManuals2.co

ADAPTIVE CRUISE CONTROL (3/14)

Switching on

The cruising speed 11 replaces the

dashes and cruise control is confirmed

Press switch 5.

by the appearance of the cruising speed

Warning light 

appears in grey,

in green and warning light 

and the message “Adaptive Cruise Ctl

If you try to activate the function above

ON” appears on the instrument panel,

105 mph (170 km/h) or below 18 mph

accompanied by dashes to indicate that

(30 km/h), the message “Invalid Speed”

the cruise control function is activated

is displayed and the function will remain

and waiting to store a cruising speed.

inactive.

The function cannot be used while the

Once a cruising speed is memorised

parking brake is applied.

and the cruise control function is active,

The message “Adaptive Cruise Ctl una-

you may lift your foot off the accelera-

vailable” is displayed on the instrument

tor pedal.

panel.

Activating cruise control

While the vehicle is moving at a steady

speed, press switch 6 (SET/-) or 7

(RES/+) to activate the function and

store the current speed. The minimum

cruising speed is 19 mph (30 km/h).

Important: you should keep

your feet near the pedals at

all times to prepare for any

event.

2.74

CarManuals2.co

ADAPTIVE CRUISE CONTROL (4/14)

Safe distance control

activation

As soon as cruise control is activated,

the default safe distance 10 is displayed

in green on the instrument panel. The

default safe distance corresponds to

approximately two seconds (see follow-

ing pages).

If the system detects a vehicle in your

lane, an outline of a vehicle 9 appears

above the distance gauge 10 on the in-

strument panel.

Your vehicle adapts its speed to that

of the vehicle in front and applies the

brakes if necessary (the brake lights

Setting the cruising speed

Adjusting the following

come on) in order to maintain the dis-

tance displayed on the instrument

You can vary the speed by repeatedly

distance

panel.

pressing (for a small variation) or press-

You can vary the safe distance from the

ing and holding (for a larger variation)

vehicle in front at any time by pressing

Note: the size of the 9 outline varies ac-

switch 6 or 7:

switch 3 repeatedly.

cording to the distance separating you

from the vehicle in front. The larger the

- use the (SET/-) switch 6 to reduce

The horizontal distance gauge on the

outline, the closer the vehicle in front.

the speed;

instrument panel indicates the various

- use the (RES/+) switch 7 to increase

available safe distances:

the speed.

- distance gauge A: long distance

(corresponding to approximately 2.4

seconds);

2.75

CarManuals2.co

ADAPTIVE CRUISE CONTROL (5/14)

- distance gauge B: intermediate dis-

Then, release the accelerator pedal:

tance 2 (corresponding to approxi-

the cruise control and safe distance

mately 2 seconds);

control will automatically resume the

speed and distance instructions that

- distance gauge C: intermediate dis-

you had previously selected.

tance 1 (corresponding to approxi-

mately 1.6 seconds);

The distance gauge flashes if the dis-

tance between your vehicle and the

- distance gauge D: short distance

vehicle in front is less than the safe

(corresponding to approximately

distance selected: the “safe distance

1.2 seconds).

control” function is no longer active.

The selected distance gauge appears

in green on the instrument panel. The

other gauges remain in grey.

Note: the distance must be set accord-

ing to the traffic level, local regulation

and weather conditions.

Exceeding the cruising speed

The cruising speed may be exceeded

at any time by applying the accelerator

pedal.

If it is exceeded, the cruising speed 11

appears in red.

The safe distance is adjusted by de-

fault on the distance gauge B.

2.76

CarManuals2.co

ADAPTIVE CRUISE CONTROL (6/14)

Overtaking manoeuvre

- you open one of the opening ele-

ments;

If you wish to overtake the vehicle in

front, activating the indicator will tem-

- you press the engine start/stop

porarily cancel the safe distance con-

button;

trol and enable an acceleration speed

- the slope is too steep;

sufficient to complete overtaking.

- the vehicle speed is above 112 mph

(180 km/h);

Putting the function on

- certain driving aids and correction

standby

devices are triggered (active emer-

You can set the function to standby

gency braking, ABS, ESC etc.) ;

when:

- when you press the clutch pedal for a

- you press switch 4 (0);

prolonged period or upon prolonged

neutral position on vehicles equipped

- you apply the brake pedal while the

with a manual gearbox.

vehicle is moving.

In all circumstances, the standby is con-

The function is deactivated by the

firmed when the warning lights appear

system if:

in grey and the message “Adaptive

Cruise Ctl Disconnected” appears on

- you set the automatic gearbox to P

the instrument panel.

or N;

- you engage the reverse gear;

– you unbuckle the driver’s seatbelt;

Putting the adaptive cruise

control in standby or switch-

ing it off does not cause a

rapid reduction in speed:

you must brake by applying the

brake pedal if necessary.

2.77

CarManuals2.co

ADAPTIVE CRUISE CONTROL (7/14)

Exit from standby

Based on the current speed

When the cruise control is set to

Based on the stored cruising speed

standby, pressing switch 6 (SET/-) re-

If a speed is stored, it can be recalled,

activates the cruise control function

once you are sure that the road condi-

without taking into account the stored

tions are suitable (traffic, road surface,

speed: it is the speed at which the vehi-

weather conditions, etc.).

cle is moving that is taken into account.

Press switch 7 (RES/+) in the range of

confirmed speeds.

When the stored speed is recalled, acti-

vation of the cruise control is confirmed

by the illumination of the cruising speed

in green.

Note: if the stored speed is higher than

the current speed, the vehicle will ac-

celerate to reach that speed.

2.78

CarManuals2.co

ADAPTIVE CRUISE CONTROL (8/14)

Switching off the function

The adaptive cruise control function

is deactivated when you press the 6

switch.

disappears

The warning light 

from the instrument panel to confirm

that the function is no longer active.

Temporary unavailability

The radar is able to detect vehicles

in front of your vehicle. The system

cannot operate correctly if the radar de-

tection area is obscured or if its signal

is disrupted.

“Take control of the vehicle”

Depending on the situation, the system

sounds a beep associated with:

If the radar detection area is obstructed

warnings

or the radar signal is disrupted, the

- the orange alert E if the situation re-

In some situations (e.g. coming upon

message “Front radar no visibility” is

quires the driver’s attention;

a much slower vehicle, vehicle in

displayed on the instrument panel and

front changing lanes quickly etc.), the

the adaptive cruise control is inter-

system may not have time to react.

- the red alert F accompanied by the

rupted. The green warning light 

message “ Brake “ if the situation re-

disappears to confirm that the function

quires the driver’s immediate atten-

has been automatically deactivated.

tion.

In all situations, react accordingly

and perform the appropriate ma-

noeuvres.

2.79

CarManuals2.co

ADAPTIVE CRUISE CONTROL (9/14)

Ensure that the radar area is not ob-

Operating faults

structed

(dirt, mud, snow, a badly

If an operating fault is detected on one

fitted/attached front number plate), im-

or more components of the system, the

pacted, modified (including paintwork)

adaptive cruise control function is inter-

or hidden by any accessory fitted on the

rupted.

front of the vehicle (on the grille or logo

etc.).

The

warning light appears on

the instrument panel along with, de-

Conditions in certain geographical

pending on the malfunction, one of the

areas may hinder the function, for ex-

following messages:

ample:

The system controls accelera-

tion and deceleration of your vehi-

- “Front camera to check”;

- arid zones, tunnels, long bridges or

cle using the engine and braking

lightly used roads without road lines,

- “Front radar to check”;

system. The system activates the

without signs or trees nearby;

brakes in order to maintain the set

- “Camera/Radar to check”;

- a military or airport zone.

speed, the system applies limited

- “Check vehicle”.

You must leave such areas in order for

braking. In the event of a steep de-

Consult an approved dealer.

the function to work.

scent, for example in a mountainous

area, you must select a lower gear

In all cases, if the message is not

to benefit from engine braking.

erased after the engine is restarted,

please contact an authorised dealer.

To reduce the load imposed on the

braking system and to prevent the

brakes from overheating, the adap-

tive cruise control function may be

temporarily interrupted and the

message “Check Adaptive Cruise

control” may appear. The message

disappears when the function be-

comes available again.

If the message remains, contact an

approved dealer.

2.80

CarManuals2.co

ADAPTIVE CRUISE CONTROL (10/14)

Limitations of system

The system cannot detect:

Detection during cornering

operation

- vehicles arriving at intersections: slip

When entering a corner or bend, the

roads (e.g. H) ;

radar and/or camera may temporarily

Vehicle detection

not be able to detect the vehicle in front

- vehicles driving on the wrong side of

The system detects only vehicles (cars,

(e.g. J).

the road or reversing towards you.

trucks, motorbikes) that are moving in

The system may trigger an acceler-

the same direction as your vehicle.

ation.

A vehicle turning into the same lane

When exiting a bend, the system’s de-

(e.g. G) will be taken into account by

tection of the vehicle in front may be

the system only once it enters the

disrupted or delayed.

camera and radar detection areas.

The system may trigger abrupt or

delayed braking.

The adaptive cruise control must

only be used on a motorway (or mul-

ti-lane road separated by a barrier).

2.81

CarManuals2.co

ADAPTIVE CRUISE CONTROL (11/14)

Detection of vehicles in adjacent

Vehicles hidden due to variations in

- vehicles transporting long objects

lanes

ground relief

which exceed the line;

The system may detect vehicles driving

The system will not detect vehicles

- the actual length of tall vehicles

on an adjacent lane when:

hidden due to variations in ground relief

(e.g. L) outside the radar detection

or those located outside of the camera

area (construction machine, agricul-

- you drive into a bend (e.g. K);

and radar detection areas when driving

tural equipment towing vehicle, etc.)

- you are driving on a road with narrow

uphill or downhill.

;

lanes;

- vehicles insufficiently centred in the

Vehicles outside the camera and

- the speed of the vehicle on the ad-

lane;

radar detection areas.

jacent lane is slower and if one of

- narrow vehicles which are very close

these vehicles is located too close to

The system will react late or not at all

(e.g. M).

the lane of the other.

if the detected vehicles are outside the

camera and radar detection areas, par-

The system may incorrectly trigger

ticularly in the following cases:

vehicle slowing or braking.

2.82

CarManuals2.co

ADAPTIVE CRUISE CONTROL (12/14)

Stationary and slow moving

- vehicles in front12 which change

Non-detection of fixed obstacles

vehicles

lane, revealing a stationary vehi-

and objects of a small size

cle 13 (e.g. P).

When your speed is over approximately

The system cannot detect:

31 mph (50 km/h), the system does

- pedestrians, bikes, scooters, etc. ;

not detect:

- animals;

- stationary vehicles (e.g N);

- fixed obstacles (toll barriers, walls,

- very slow moving vehicles.

etc.) (e.g. Q).

When your speed is less than approxi-

These are not taken into account by the

mately 31 mph (50 km/h), the system

system. They do not trigger any alert or

may not react or may react very late

Always be ready to take control

reaction by the system.

to:

of your vehicle when you come

upon stationary or very slow

- stationary vehicles (e.g N);

moving vehicles (e.g. N).

- very slow moving vehicles;

The adaptive cruise control does

not trigger an emergency stop and

its braking capability is limited.

2.83

CarManuals2.co

ADAPTIVE CRUISE CONTROL (13/14)

This function is an additional driving aid. It can under no circumstances replace the driver’s responsibility to respect

speed limits and safe distances and to be vigilant.

The driver must always be in control of the vehicle.

The driver must always adapt their speed to the surroundings and driving conditions, regardless of system indications.

Except for lines delimiting lanes, traffic indicators (traffic lights, signs, pedestrian crossings etc.) are not recognised by the

system. These do not trigger any alert or reaction by the system.

The system should under no circumstances be taken to be an obstacle detector or an anti-collision system.

The adaptive cruise control must only be used on a motorway (or multi-lane road separated by a barrier).

System servicing/repairs

- In the event of an impact, the radar and/or camera alignment may be changed and its operation may consequently be af-

fected. Deactivate the system and consult an authorised dealer.

- Any work in the proximity of the radar and/or camera (replacements, repairs, windscreen modifications, paintwork etc.) must

be carried out by a qualified professional.

Only an authorised dealer is qualified to service the system.

Deactivating the function

You must disable the function if:

- the vehicle is travelling on a windy road;

- the vehicle is being towed (breakdowns);

- the vehicle is towing a trailer or a caravan;

- the vehicle is being driven in a tunnel or close to a metallic structure;

- the vehicle arrives at a toll point, a roadwork area or on a narrow lane;

- the vehicle is being driven up or down a very steep slope;

- the visibility is poor (glaring sun, fog etc.);

- the vehicle is being driven on a slippery road surface (rain, snow, gravel, etc.);

- the weather conditions are poor (rain, snow, side winds, etc.);

- the radar area has been damaged (impacts etc.) ;

- the area of the camera has been damaged (e.g. on the inside or outside of the windscreen);

- the windscreen is cracked or distorted.

In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.

2.84

CarManuals2.co

ADAPTIVE CRUISE CONTROL (14/14)

In the event of system disturbance

Some conditions can disturb or damage the operation of the system, such as:

- the windscreen or bumper is obscured in the area of the radar (by dirt, ice, snow, condensation, number plate etc.);

- a complex environment (tunnel etc.);

- poor weather conditions (snow, heavy rain, hail, black ice, etc.);

- poor visibility (night, fog etc.);

- poor contrast between the vehicle preceding it and the surrounding area (e.g. white vehicle in a snowy area etc.);

- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);

- narrow, winding or undulating road (tight bends etc.);

- a slower vehicle with a significant difference in speed;

- use of mats not adapted to the vehicle. On the driver’s side, only use mats suitable for the vehicle, attached with the pre-

fitted components, and check the fitting regularly. Do not lay one mat on top of another. There is a risk of wedging the

pedals.

In these cases, the system may wrongly intervene.

Risk of unwanted braking or acceleration.

Many unforeseen situations may affect the system operation. Certain objects or vehicles that can appear in the camera or

radar detection zone may be interpreted by the system incorrectly, possibly leading to inappropriate acceleration or braking.

You should always be attentive to sudden events that might occur while you are driving. Always keep your vehicle

under control by keeping your feet near the pedals, so that you are ready to act in any event.

2.85

CarManuals2.co

VEHICLE WITH OVERSPEED FUNCTION

Special case: if your vehicle is fitted

with the Cruise control/Speed limiter,

fully pressing the accelerator pedal

(beyond the kickdown point) will not

enable you to exceed the overspeed

function set speed ➥ 2.63.

The vehicle speed may be permanently

set at a fixed value depending on the

vehicle or on local legislation.

To adjust the value or activate/deacti-

In exceptional circumstances (e.g.

vate the function, consult an approved

steep gradient), the overspeed func-

dealer.

tion speed may be exceeded slightly

as the function does not affect the

In the event of statutory limits (depend-

braking system.

ing on the vehicle), this function may

not be deactivated.

Label 1 attached to the dashboard

The function does not take

shows the speed limit.

the place of the driver.

Under no circumstances

should it replace observa-

tion of speed limits nor vigilance

and responsibility on the part of the

driver.

2.86

CarManuals2.co

FAST IDLE SPEED

Switching off the function

The function is interrupted when:

- you depress the clutch pedal and/or

accelerator pedal;

- the vehicle speed is above 0 mph;

- the

indicator light is lit up on

the instrument panel;

- the

indicator light is lit up on

the instrument panel;

- the

indicator light is lit up on

the instrument panel.

Press control 1, and the function will be

activated after a few seconds.

Modifying fast idle speed

To increase or reduce the speed, con-

tact an approved dealer.

Special feature of the Stop and

Start function: activating the "Fast

Idle Speed" function prevents the

engine from going into standby.

➥ 2.8.

2.87

CarManuals2.co

PARKING DISTANCE CONTROL (1/8)

Depending on the vehicle, the system

detects obstacles to the front, the rear

and the sides of the vehicle.

The parking distance control system

is only activated when the vehicle is

driven at a speed below approximately

6 mph (10 km/h).

The function does not take into account

towing or carrying systems that are not

recognised by the system.

Location of the ultrasonic

sensors 1

Ensure that the ultrasonic sensors indi-

This function is an addi-

Operating principle

cated by the arrows 1 are not obscured

tional driving aid. Under no

(by dirt, mud, snow, a badly fitted/at-

circumstances should it re-

Ultrasonic sensors, indicated by

tached number plate), impacted, mod-

place the driver’s care or re-

arrows 1, are fitted in the bumpers to

ified (including paintwork) or obstructed

sponsibility whilst reversing.

measure the distance between the ve-

by any accessory fitted to the rear and/

hicle and an obstacle.

The driver should always be ready

or, depending on the vehicle, to the

for sudden incidents while driv-

This measurement is indicated by

front or sides of your vehicle.

ing: always ensure that there are

beeps which become more frequent the

no small, narrow moving obstacles

closer you come to the obstacle, until

(such as a child, animal, pushchair,

they become a continuous beep when

bicycle, stone, post, etc.) in the blind

the vehicle is approximately

20 to

spot when manoeuvring.

30 centimetres from the obstacle.

2.88

CarManuals2.co

PARKING DISTANCE CONTROL (2/8)

Note: in the event of a change in tra-

jectory during a manoeuvre, the risk of

collision with an obstacles may be sig-

nalled late.

Note: the display 2 shows the vehicle

Operation

surroundings and emits beeps.

Most objects located less near the

It is necessary to travel a few metres

front, rear and sides of the vehicle are

before the side detection is activated.

detected.

If all areas have a grey background, the

Depending on the distance of the ob-

An impact to the under-

whole area around the vehicle is being

stacle, the frequency of the beep will

side of the vehicle while

monitored:

be higher while approaching it, and will

manoeuvring

(e.g. strik-

become a continuous beep around 20

ing a post, raised kerb or

- A: analysis of the vehicle surround-

cm away for obstacles to the sides, and

other street furniture) may result in

ings in progress;

around 30 cm for obstacles to the front

damage to the vehicle (e.g. defor-

- B: analysis of the vehicle surround-

mation of an axle).

or rear.

ings carried out.

The green, orange (or yellow, depend-

To avoid any risk of accident, have

ing on the vehicle) and red zones will

your vehicle checked by an ap-

be shown on the C display.

proved dealer.

2.89

CarManuals2.co

PARKING DISTANCE CONTROL (3/8)

If a side obstacle is detected:

- the beeps become faster and then

sound continuously as the obstacle

gets nearer. Green, orange and red

zones will be displayed on the D dis-

play;

- if there is no risk of collision, no beep

will sound when approaching the ob-

stacle. Green, orange and red zones

will be displayed interspersed on

the D display.

Note: in the event of a change in tra-

jectory during a manoeuvre, the risk of

collision with an obstacle may be sig-

nalled late.

Detection of obstacles to the side

Depending on the direction of the

wheels, the system determines the tra-

jectory of the vehicle and notifies the

driver of any risk or otherwise of a col-

lision with an obstacle 3 to the side of

the vehicle.

2.90

CarManuals2.co

PARKING DISTANCE CONTROL (4/8)

Adjustment

Depending on the vehicle, with the

engine running, some settings can be

adjusted from the multimedia screen 4.

Please refer to the multimedia instruc-

tions for further information.

Parking distance control audio

volume

Adjust the volume of the parking dis-

tance control by pressing + or -.

System sound

Enables the system sound to be

chosen.

Vehicles fitted with a

Deactivating the system sound

multimedia screen

Activate or deactivate the parking dis-

Activation/deactivation

tance control sound.

To use the multimedia screen 4 to ac-

Note: if you deactivate the sound, you

tivate or deactivate the different areas

will no longer be notified with beeps

covered by the ultrasonic sensors

when approaching an obstacle.

(front, side and/or rear), please refer to

the multimedia instructions.

Select “ON” or “OFF”.

When the vehicle is travelling at a

speed below approximately 6 mph

(10 km/h), some noises (motorcy-

When the engine is started, the

cle, lorry, pneumatic drill etc.) may

system recalls the last position

trigger the beeping sound of the

stored before the ignition was

parking distance control.

switched off.

2.91

CarManuals2.co

PARKING DISTANCE CONTROL (5/8)

- press the 8 or 9 control repeatedly

to reach the “PARKING ASSIST”

menu. Press the switch 10 OK;

- select “ON” or “OFF” to activate or

deactivate the function.

If the 6 button cannot be used to re-

activate Park Assist, check that the

function has not been deactivated

on the instrument panel. To reacti-

vate it, please refer to the paragraph

entitled “Special feature on vehicles

Vehicles not fitted with a

Adjusting the Park Assist functions

fitted with front, rear and side Park

using the instrument panel

multimedia screen

Assist”.

(available on vehicle with front and side

Activation/deactivation

Park Assist)

With the vehicle stopped, press the 6

- With the vehicle stationary, press

An impact to the under-

switch to deactivate parking distance

the 7 switch as many times as re-

side of the vehicle while

control. Warning light 5 in the switch

quired to reach the “Vehicle” tab;

manoeuvring

(e.g. strik-

lights up. Press again on the 6 switch to

- press the 8 or 9 control repeatedly to

ing a post, raised kerb or

activate the function. The indicator light

reach the “Settings” menu. Press the

other street furniture) may result in

built into the 5 switch goes out.

switch 10 OK;

damage to the vehicle (e.g. defor-

mation of an axle).

To avoid any risk of accident, have

your vehicle checked by an ap-

proved dealer.

When the engine is started, the

system recalls the last position

stored before the ignition was

switched off.

2.92

CarManuals2.co

PARKING DISTANCE CONTROL (6/8)

- select “BIP VOLUME” to adjust the

Deactivating the parking

volume of the parking distance con-

distance control manually

trol using the 8 or 9 control.

You must disable the function if:

- if towing, carrying or trailer equip-

Parking distance control

ment not recognised by the system

automatic deactivation

is positioned in front of the ultrasonic

The system deactivates:

sensors, you must deactivate the

system;

- when the vehicle speed is above ap-

proximately 6 mph (10 km/h);

- in the event of damage to the ultra-

sonic sensors.

- depending on the vehicle, when the

vehicle is stationary for more than

approximately three seconds and an

Operating faults

obstacle is detected (such as when

When the system detects an operating

in a traffic jam etc.);

fault, a beep sounds for approximately

Adjustment

- when the vehicle is in neutral on

three seconds each time reverse gear

- With the vehicle stopped, press the 7

manual gearboxes, or in position N

is selected and is accompanied by

switch as many times as required to

or P on automatic gearboxes;

the message “Check parking sensor”

reach the “Vehicle” tab;

shown on the instrument panel. Consult

- when an operating fault is detected.

- press the 8 or 9 control repeatedly to

an approved dealer.

Note: if the vehicle is fitted with a

reach the “Settings” menu. Press the

towbar recognised by the system, only

switch 10 OK;

the rear Park Assist is deactivated.

- press the 8 or 9 control repeatedly

to reach the “PARKING ASSIST”

menu. Press the switch 10 OK;

2.93

CarManuals2.co

PARKING DISTANCE CONTROL (7/8)

System servicing/repairs

- In the event of an impact, the alignment of the sensors may be altered and their operation may consequently be affected.

Deactivate the function and consult an authorised dealer.

- Any work in the area where the sensors are located (repairs, replacements, etc.) must be carried out by a qualified profes-

sional.

Only an authorised dealer is qualified to service the system.

System disturbance

Some conditions can disrupt or damage the operation of the system, for example:

- poor weather conditions (rain, snow, hail, black ice, etc.);

- in the event of exposure to strong electromagnetic waves (under high-voltage lines, etc.);

- some types of noise (motorcycle, lorry, pneumatic drill etc.);

- fitting a non-compatible towing ball or hook;

- ...

Risk of false alarms or absence of warnings

In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.

2.94

CarManuals2.co

PARKING DISTANCE CONTROL (8/8)

Limitation of the system operation

- The area around the sensors must be kept clean and free of any modifications in order to ensure the proper operation of the

system.

- Small objects moving close to the vehicle (motorcycles, bicycles, pedestrians, etc.) may not be recognised by the system.

- The system may not detect objects that are too close to the vehicle.

- The system may not provide a warning when the other vehicles or objects are travelling at a significantly different speed.

- When there is a change in trajectory during a manoeuvre, the system may be slow in reporting obstacles.

- When the vehicle is towing a trailer, the rear Park Assist system must be deactivated.

Deactivating the function

You must disable the function if:

- the area around the sensors has been damaged;

- the vehicle is equipped with a towing device that is not recognised by the system (ball, hook, adapter, etc.).

2.95

CarManuals2.co

REVERSING CAMERA (1/3)

Operation

Note: make sure that the reversing

Note: depending on the vehicle, you

camera is not obscured (by dirt, mud,

can adjust certain settings from the

When reverse gear is engaged, the

snow, condensation, etc.).

multimedia display

3. Refer to the

camera 1 located on the tailgate or,

handbook for the equipment.

depending on the vehicle, on the rear

hinged door, provides a view of the

area behind the vehicle on the rear

view mirror 2 or, depending on the ve-

hicle, on the multimedia display 3, ac-

companied by two moving or fixed

This function is an additional aid. It cannot, therefore, under any circum-

guide lines 4 and 5.

stances replace the vigilance or the responsibility of the driver.

The driver should always be ready for sudden incidents while driving:

always ensure that there are no small, narrow moving obstacles (such

as a child, animal, pushchair, bicycle, stone, post, etc.) in the blind spot when

manoeuvring.

2.96

CarManuals2.co

REVERSING CAMERA (2/3)

This gauge remains fixed and indicates

the vehicle trajectory if the wheels are

in line with the vehicle.

This system is initially used with the aid

of several gauges (mobile for trajectory

and fixed for distance). When the red

zone is reached, use the bumper image

to stop accurately.

The screen shows a reverse image.

Dynamic gauge 4 (depending on the

The frames are a representation

vehicle)

projected on a flat surface. This in-

This is shown in blue on the multimedia

formation is to not be taken into ac-

display 3. It indicates the vehicle tra-

count when superimposed on a

jectory according to the position of the

vertical object or an object on the

steering wheel.

ground.

Objects which appear on the edge

Static guide line 5:

of the screen may be deformed.

The fixed clearance gauge comprises

coloured markers A, B and C, indicat-

In very bright light (snow, vehicle in

ing the distance behind the vehicle:

sunshine etc.), the camera vision

may be adversely affected.

- A(red) approximately 30 centimetres

from the vehicle;

If the rear doors are open or poorly

- B(yellow) approximately 70 centime-

closed, the message “WARNING:

tres from the vehicle;

Boot Open” appears and, depend-

- C(green) approximately 150 centi-

ing on the vehicle, the camera dis-

metres from the vehicle.

play disappears.

2.97

CarManuals2.co

REVERSING CAMERA (3/3)

D E

H J K

D E

F G

Difference between the

Reversing towards a steep downhill

Reversing towards a protruding

slope

object

estimated distance and

actual distance

The fixed guidelines 6 show the dis-

Position H seems further than position J

tances as further than they actually are.

on the screen. However, position H is at

Reversing towards a steep uphill

the same distance as position K.

Therefore, the objects shown on the

slope

screen are actually closer on the slope.

The trajectory indicated by the fixed

The fixed guidelines 6 show the dis-

and mobile guidelines do not take into

For example, if the screen displays an

tances as closer than they actually are.

account the height of the object. So

object at G, the actual distance of the

there is a risk that the vehicle may col-

The objects shown on the screen are

object is at F.

lide with the object when reversing to-

actually further away on the slope.

wards position K.

For example, if the screen displays an

object at D, the actual distance of the

object is at E.

2.98

CarManuals2.co

AUTOMATIC TRANSMISSION (1/4)

Driving in automatic mode

Put lever 1 into position D.

In most road conditions you will en-

counter, you will not need to touch your

lever again: the gears will change au-

tomatically at the right time and at the

most suitable engine speed because

the automatic system takes into ac-

count the vehicle load and road contour

and adjusts itself to the particular driv-

ing style you have chosen.

Selector lever 1

Operation

P: park

With gear lever 1 in position P, start the

engine.

R: reverse

To move out of position P, you must de-

N: Neutral

press the brake pedal before pressing

D: automatic mode

the unlocking button 2.

M: manual mode

With your foot on the brake pedal (warn-

+: upper gear

ing light Ó

on the display goes out),

-: lower gear

move the lever out of position P.

The gear currently engaged is dis-

Only engage D or R when the vehi-

played on the instrument panel A.

cle is stopped, with your foot on the

brake, the accelerator pedal released

Note: press button 2 to go from posi-

In some cases (parked on a steep

and the engine running.

tion D or N to R or P.

slope etc.), a lot of the force may

be required to move the gear lever

from the P position to another posi-

tion.

2.99

CarManuals2.co

AUTOMATIC TRANSMISSION (2/4)

Driving in automatic mode

- to move up through the gears, push

the lever backwards.

(cont.)

The gear selected is displayed on the

Economical driving

instrument panel.

When driving, always leave the lever

in position D, keeping the accelerator

pedal lightly depressed to ensure auto-

Special cases

matic gear changes at a lower engine

In certain driving conditions

(result-

speed.

ing in, for example, engine protection,

operation of the Electronic Stability

Accelerating and overtaking

Control programme: ESC etc.) the au-

Depress the accelerator pedal firmly

tomated system may change the gear

and fully (so that it goes beyond the

automatically.

kickdown point).

Likewise, to prevent incorrect manoeu-

This will enable you to change down

vres, a gear change may be refused by

to the optimum gear within the

Driving in manual mode

the automatic system: in this case the

engine range.

gear display flashes for a few seconds

Move the selector lever 1 to position D,

as a warning.

then move the lever to the right into po-

sition M.

Shifting the lever repeatedly allows you

to change gears manually:

- to move down through the gears,

push the lever forwards;

Check that the indicator

light P on the instrument

panel is activated before

leaving the vehicle.

Risk of loss of immobilisation of

the vehicle

2.100

CarManuals2.co

AUTOMATIC TRANSMISSION (3/4)

Special circumstances

Parking the vehicle

Maintenance period

- If the bends and road surface do

When the vehicle is stopped, move

Refer to the maintenance document

not allow you to stay in automatic

the lever to position P while keeping

for your vehicle or consult an Approved

mode (e.g. in the mountains), we

your foot on the brake pedal: the drive

Dealer to check whether the automatic

recommend that you change to

wheels are mechanically locked by the

gearbox requires scheduled mainte-

manual mode. This will prevent the

driveshaft.

nance.

automatic gearbox from changing

Ensure that the electronic parking

If it does not need to be serviced, there

gears repeatedly when climbing, and

brake is engaged.

is no need to top up the oil.

permit engine braking on long de-

scents.

Note: if the vehicle is parked on a steep

slope with position P engaged, the

- In cold weather, start the engine

message "WARNING: Apply Parking

and wait a few seconds before

Brake" is displayed on the instrument

moving the selector lever from posi-

panel, accompanied by a beep.

tion P or N and engaging it in D or R

to prevent the engine stalling.

When facing uphill, to remain

For safety reasons, do not

stopped, do not keep your foot on

switch off the ignition before

the accelerator.

the vehicle has come to a

Risk of overheating the automatic

complete standstill.

gearbox.

2.101

CarManuals2.co

AUTOMATIC TRANSMISSION (4/4)

Operating faults

when driving, if the message

“Check auto gearbox” appears on

the instrument panel, it indicates

a failure. Contact your approved

Dealer as soon as possible;

when driving, if the message

“Gearbox overheating” appears on

the instrument panel, stop as soon

as possible to let the gearbox cool

down and wait for the message to

disappear;

Troubleshooting on a vehicle with

an automatic gearbox ➥ 5.36.

When activated, in the event that the

lever is stuck in P, depress the brake

paddle. It is possible to free the lever

manually. To do this, unclip the base of

the lever then place a tool (rigid shaft)

in the slot 3 (located to the right or left

An impact

to the under-

of the lever). Press simultaneously on

side of the vehicle while

the tool (rigid shaft) and the 2 button to

manoeuvring

(e.g. strik-

unlock the lever.

ing a post, raised kerb or

other street furniture) may result in

Contact your approved Dealer as soon

damage to the vehicle (e.g. defor-

as possible.

mation of an axle).

To avoid any risk of accident, have

your vehicle checked by an ap-

proved Dealer.

2.102

CarManuals2.co

EMERGENCY CALL (1/3)

If the vehicle is equipped, the emer-

gency call function can be used to

call the emergency services (without

charge) automatically or manually in

the event of an accident or illness, re-

ducing the time it takes for the emer-

gency services to arrive.

Note: the emergency call operates:

- in countries covered by the associ-

ated telematics emergency services

and infrastructure compatible with

the system;

- depending on the network coverage

in the geographical region where the

vehicle is being driven.

System operation warning light:

A call is always made as follows:

If you use the emergency call function

– green: operational

to report an accident which you have

- the call is set up with the emergency

(network available);

witnessed, this implies stopping where

services;

- off: non-operational

traffic conditions allow in order for the

- send data related to the incident (ve-

(network unavailable);

emergency services to locate your ve-

hicle identification plate, local time

- red: operating

hicle and therefore the location of the

of the call, last positions, direction of

fault;

reported accident.

the vehicle) ;

- green flashing: call in progress.

In all cases, comply with local legisla-

- voice communication with the emer-

Automatic mode warning light.

tion.

gency services;

SOS button.

- if necessary, emergency assistance

Microphone.

is called.

Speaker.

Emergency call has two modes:

- automatic mode;

Use the emergency call only in the

event of an emergency you are in-

- Manual mode.

volved in, if you witness an accident

or if you feel ill.

2.103

CarManuals2.co

EMERGENCY CALL (2/3)

Automatic mode

In the event of unintended operation, it

is possible to cancel the call by press-

If the automatic mode 2 warning light

ing the 3 button for around two sec-

appears in green this confirms that the

onds, before the call is connected to

automatic system is activated.

the call centre.

The emergency call starts automati-

Once a call is established, only the call

cally in the event of an accident that

centre can end the call.

has required the activation of the pro-

tective equipment (seat belt pretension-

Test mode

ers, airbag etc.).

(depending on local laws)

Test mode is reserved exclusively for

Approved Dealers to check that the

emergency call feature is working prop-

erly.

To activate test mode:

Manual mode

- briefly press the 3 button three times;

The emergency call is carried out by:

- wait approximately 15 seconds;

- pressing and holding the 3 button for

- briefly press the 3 button three times.

at least three seconds;

Exit from test mode is automatic.

- pressing the

3 button five times

within ten seconds.

In the event of an acci-

dent, if the location and traf-

fic conditions permit, stay

close to the vehicle in order

to be able answer the call centre

quickly if necessary.

2.104

CarManuals2.co

EMERGENCY CALL (3/3)

The system operates with a dedi-

cated battery. The battery service

life is approximately four years

(the

1 warning light lights up in

red to warn you when approaching

expiry).

Consult an approved dealer

Without the emergency call feature,

the system is not trackable and will

not be under constant surveillance.

Data is automatically and constantly

To guarantee your safety

erased, and the system stores only

and the proper operation of

the last three positions of the vehi-

the system, any operation

Operating faults

cle.

carried out on the battery

In some cases, the emergency call may

(removal, disconnection, etc.) must

According to local legislation, data

not work (e.g. low battery).

be carried out by a qualified special-

is only sent in the event of an emer-

When the system detects an operating

ist.

gency call. Data sent to the call

fault, the 1 warning light turns red for

centre is treated according to the

Risk of serious burns or electric

over 30 minutes; consult an Approved

personal data protection laws appli-

shocks.

Dealer as soon as possible.

cable in the country where you are

You must respect the replacement

located. The system stores activity

intervals (without exceeding them)

history data for 13 hours only.

as stated in the maintenance docu-

The vehicle owner has the right of

ment.

access to their data. They can re-

The battery is a specific type.

quest that the data be corrected,

Please ensure it is replaced with the

deleted or locked.

same type.

Call an approved Dealer.

2.105

CarManuals2.co

Section 3: Your comfort

Air Vents

3.2

Manual air conditioning, heating system

3.4

Automatic climate control

3.8

Air conditioning: information and advice on use

3.12

Additional heating and air conditioning

3.14

Multimedia equipment

3.16

Windows

3.18

Sun visor

3.21

Interior lighting

3.22

Passenger compartment storage, fittings

3.25

Accessories socket

3.35

Rear bench seat: functions

3.38

Luggage cover

3.42

Luggage net

3.43

Transporting objects

3.45

Transporting objects: towbar

3.47

Roof bars

3.49

3.1

CarManuals2.co

AIR VENTS, air outlets (2/2)

To remove bad odours from your ve-

hicles, only use the systems designed

for this purpose. Consult an approved

Dealer.

Centre air vents.

Side air vents

Air flow

To close the left-hand central air vent,

To close the left-hand side air vent,

slide the tab 9 fully to the left.

slide the tab 11 fully to the right.

To close the right-hand central air vent,

To close the right-hand side air vent,

slide the tab 10 fully to the right.

slide the tab 11 fully to the left.

Air flow direction

To direct the air flow, swivel the side air

To direct the air flow, swivel side air

vent 9 or 10.

vent 11.

Do not add anything to the

vehicle’s ventilation circuit

(for example, to remove

bad odours).

There is a risk of damage or of

fire.

3.3

CarManuals2.co

Renault Trafic (2023 year). Manual in english - page 5
