WARNING LIGHTS (1/5)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
In some cases, the appearance of a
warning light is accompanied by a mes-
sage.
Side light warning light
š
A
Main beam headlight tell-
á
tale
Dipped beam headlight tell-
k
tale
1
Front fog light tell-tale
g
Rear fog light tell-tale
Automatic main beam head-
The instrument panel A lights up
light indicator light ➥ 1.120
when the ignition is switched on. Press
or lift the 1 switch as many times as re-
Left-hand direction indicator
quired to adjust the intensity.
c
tell-tale
Right-hand direction indica-
If no lights or sounds are ap-
b
tor tell-tale
parent, this indicates a fault
in the instrument panel. This
indicates that it is essential
to stop immediately (as soon as traf-
Warning light
means you
fic conditions allow). Ensure that the
should drive very carefully to an
vehicle is correctly immobilised and
authorised dealer as soon as
contact an approved Dealer.
possible. If you fail to follow this
recommendation, you risk damag-
ing your vehicle.
1.100
CarManuals2.co
WARNING LIGHTS (2/5)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Low fuel level warning light
Handbrake on and brake cir-
M
D
cuit incident warning light
This lights up when the ignition
is switched on and goes out after a few
This comes on when the ignition is
seconds.
switched on and goes out as soon as
A
the handbrake is released.
If it lights up when driving, fill up with
fuel as soon as possible. There is only
If it comes on during braking and is ac-
approximately 31 miles (50 km) worth
companied by the
®
warning light
of fuel left.
and a beep, it indicates that the fluid
level in the circuit is low or that there is
STOP light
®
a braking system fault.
This lights up when the ignition
Stop as soon as traffic conditions allow
is switched on and goes out as soon as
and contact an approved Dealer.
the engine is started. It comes on with
other warning lights and/or messages,
and is accompanied by a beep.
Indicator lightAirbag
It requires you to stop immediately, for
å
your own safety, as soon as traffic con-
It lights up when the ignition or
ditions allow. Switch off the engine and
the engine is switched on and goes off
do not restart it.
after a few seconds.
If it does not come on when the igni-
Contact an approved Dealer.
tion is switched on, or comes on when
the engine is running, there is a fault in
Warning light
®
re-
the system.
quires you to stop immedi-
ately, for your own safety,
Contact your approved Dealer as soon
as soon as traffic conditions
as possible.
allow. Switch off the engine and do
not restart it. Contact an approved
Dealer.
1.101
CarManuals2.co
WARNING LIGHTS (3/5)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Oil pressure warning light
Toxic Fume Filter System
À
Ä
Warning Light
This lights up when the ignition
is switched on and goes out after a few
For vehicles equipped with this option,
seconds.
the light comes on when the ignition is
A
switched on then goes out.
If it comes on on the road, accompa-
nied by the
®
warning light and a
- If it lights up continuously, consult
beep, stop immediately and cut the ig-
your approved dealer as soon as
nition.
possible;
Check the oil level. If the level is normal,
- If it flashes, reduce the engine speed
the indicator light is being lit by some-
until the light stops flashing. Contact
thing else. Contact an approved Dealer.
your approved Dealer as soon as
possible ➥ 2.24.
Warning light
Anti-lock braking warning
This lights up when the ignition
x
light
is switched on and goes out as soon as
Battery charge warning light
the engine is started. It can light up in
This lights up when the ignition is
Ú
conjunction with other indicator lights
switched on and goes out after a few
This lights up when the ignition
and/or messages on the instrument
seconds.
is switched on and goes out after a few
seconds.
panel.
If it lights up when you are driving, it in-
It means you should drive very care-
dicates a fault in the anti-lock braking
If it comes on on the road, accompa-
fully to an approved Dealer as soon as
system.
nied by the
®
warning light and a
possible. If you fail to follow this recom-
beep, this indicates an overload or dis-
Braking will then be as normal, without
mendation, you risk damaging your ve-
charge in the electrical circuit.
the ABS. Contact an approved Dealer
hicle.
as soon as possible.
Stop as soon as traffic conditions allow
and contact an approved Dealer.
1.102
CarManuals2.co
WARNING LIGHTS (4/5)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Particle filter system warn-
Engine standby warning
ing light ➥ 2.12
light ➥ 2.8
Warning light for reagent
Unavailability of engine
level and faults in the ex-
standby warning light ➥ 2.8
A
haust gas reduction system. ➥ 1.137
Tyre pressure loss warning
Coolant temperature warn-
➥ 2.26
Ô
ing light
Preheating warning light
It may light up in blue when the ignition
É
(Diesel version)
is switched on or if the engine is started
This should come on when the igni-
while the engine temperature is low.
tion is switched on. It indicates that the
If it appears in red, stop and leave the
heater plugs are in operation. It goes
engine idle for a minute or two.
out when preheating is complete. The
engine can be started.
The temperature should lower and the
warning light should disappear. If not,
Traction control warning
Warning light for the elec-
stop the engine. Let the engine cool
light ➥ 2.31
tronic stability program
down, then check the coolant level
(ESC) and traction control system
➥ 4.7.
This lights up when the ignition is
If the level is normal, the warning light
switched on and goes out after a few
is related to something else. Call an ap-
seconds.
proved Dealer.
The warning light may appear for sev-
eral reasons: ➥ 2.31.
1.103
CarManuals2.co
WARNING LIGHTS (5/5)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Gear change indicators
Š‰
This lights up to advise you to
change to a higher gear (arrow pointing
upwards) or lower gear (arrow pointing
A
downwards) ➥ 2.18.
Mode warning light ECO
This comes on when ECO
mode is activated ➥ 2.18.
Perfo Performance mode indicator
light
This comes on when performance
mode is activated ➥ 2.18.
Freewheel mode indicator
light
Brake pedal warning light
Ó
This comes on when freewheel mode is
This lights up when the brake
activated ➥ 2.18.
pedal should be depressed ➥ 2.99.
Front seat belt reminder
Speed limiter and cruise
ß
warning light ➥ 1.43
Φ
control indicator lights
➥ 2.67 and ➥ 2.63
Door status warning light
1.104
CarManuals2.co
DISPLAYS AND INDICATORS (1/4)
5
A
2
3
4
1
Engine oil level low warning
Instrument panel A
Rev counter 5
(graduations x 1000)
When the engine is started, the instru-
It lights up when the ignition is switched
ment panel display alerts you if the min-
on. In some cases, the appearance of a
imum oil level is reached. ➥ 4.4.
warning light is accompanied by a mes-
sage.
The first time the warning appears, it
can be cleared by pressing 1 "OK ".
Subsequent warnings will disappear
automatically after around 30 seconds.
1.105
CarManuals2.co
DISPLAYS AND INDICATORS (2/4)
9
7
6
8
Automatic gearbox display 7 ➥ 2.99
Speedometer 9
(km or miles per hour)
Fuel gauge 8
Control your speed according to the ap-
The number of squares lit shows the
proved speedometer only 9.
fuel level. When it is at minimum, the
The indicator 6 is provided as an indi-
squares disappear and the low fuel
cation.
level warning light comes on, depen-
ding on the vehicle.
Overspeed buzzer
Depending on the vehicle and coun-
try, the
warning light is dis-
played and a beep sounds. This beep
sounds as soon as the vehicle is trav-
elling at over 75 mph (120 km/h). This
warning light remains lit for as long as
the vehicle is travelling at over 74 mph
(120 km/h).
1.106
CarManuals2.co
DISPLAYS AND INDICATORS (3/4)
B
11
10
13
12
Instrument panel B
Vehicles not fitted with a multimedia
Rev counter 11
screen
(graduations x 1000)
It lights up when the ignition is switched
on. In some cases, the appearance of a
- With the ignition off, press the 2
Coolant temperature indicator 12
warning light is accompanied by a mes-
switch as many times as required to
reach the vehicle tab 10;
In normal use, the indicator 13 should
sage.
- press 3 or 4 repeatedly to access
be before the red zone 12. Under “in-
Depending on the vehicle, you can cus-
“Settings”, then press 1 “OK ";
tensive” operating conditions, the
tomise your instrument panel with col-
- repeat the same operation to access
needle may approach this zone. This
ours of your choice. For vehicles fitted
“DASHBOARD”, then “Units”.
is not serious unless the warning light
with a multimedia screen, refer to the
®
comes on accompanied by a
multimedia instructions.
message on the instrument panel and
a beep.
1.107
CarManuals2.co
DISPLAYS AND INDICATORS (4/4)
18
17
14
19
16
15
Trip computer 14 ➥ 1.109
Driving style indicator 17 ➥ 2.18
Speedometer 18
Estimated mileage with remaining
Overspeed buzzer
Fuel gauge 19
fuel 15
Depending on the vehicle and coun-
If the level is at the minimum, warn-
The value is displayed after driving
try, the
warning light is dis-
ing light M
integrated in the indica-
400 metres. ➥ 1.111.
played and a beep sounds. This beep
tor comes on orange, accompanied by
Total mileage recorder 16 ➥ 1.111
sounds as soon as the vehicle is trav-
a beep. Fill up as soon as possible.
elling at over 75 mph (120 km/h). This
warning light remains lit for as long as
the vehicle is travelling at over 74 mph
(120 km/h).
1.108
CarManuals2.co
ON-BOARD COMPUTER: general information (1/2)
Vehicle fitted with trip computer 1
1
Press the switch 2 as many times as re-
quired to reach the “Vehicle” tab.
Repeatedly press the 3 or 4 switches.
Selections
(the display depends on the vehicle
equipment and country)
2
a) Trip log, operating faults and infor-
mation message readout;
3
b) current fuel consumption and aver-
5
age fuel consumption;
4
c) trip mileage recorder and average
speed;
On-board computer 1
d) Reset the tyre pressure;
Depending on the vehicle, this includes
e) set the time;
the following functions:
f) distance before service;
- distance travelled;
- distance before service;
- journey settings;
- mileage before oil change.
- information messages;
g) Estimated range with remaining rea-
- operating fault messages
(con-
gent.
- warning messages (connected to the
®
warning light).
All these functions are described on the
following pages.
1.109
CarManuals2.co
ON-BOARD COMPUTER: general information (2/2)
Interpreting some of the
values displayed after
resetting
The values showing average fuel con-
sumption, range and average speed
will become more stable and reliable
the further you travel after pressing the
reset button.
For the first few miles after pressing the
reset key you will notice that the range
increases as you travel. This range
takes into account the average fuel con-
5
sumption since the last time the reset
button was pressed. However, average
consumption can decrease when:
Resetting the trip mileage
- the vehicle stops accelerating;
recorder and journey
- the engine reaches its operating
parameters (reset button)
temperature (if the engine was cold
With one of the trip parameters se-
when the reset key was pressed);
lected as the display, press and hold
- when driving from an urban area
the 5 switch “OK” until” the display
onto the open road.
resets to zero.
Automatic resetting of the
journey parameters
Resetting occurs automatically when
the maximum value of any of the pa-
rameters is exceeded.
1.110
CarManuals2.co
ON-BOARD COMPUTER: trip settings (1/4)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
101778 km
112.4 km
a) Total mileage and trip mileage recorder.
FUEL USED
b) Journey parameters.
8 L
Fuel used.
Fuel consumed since the last reset.
AVERAGE
c) Average fuel consumption since the last reset.
5.8 L/100
The value is displayed after having travelled at least 400 metres since the last
reset.
CURRENT
d) Current fuel consumption.
7.4 L/100
This value is displayed after a speed of approximately 20 mph (30 km/h) is
reached.
1.111
CarManuals2.co
ON-BOARD COMPUTER: trip settings (2/4)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
RANGE
541 km
e) Estimated range with remaining fuel.
The value is displayed after driving 400 metres.
DISTANCE
522 km
f) Distance travelled since last reset.
AVERAGE
89.4 km/h
g) Average speed since the last reset.
The value is displayed after driving 400 metres.
1.112
CarManuals2.co
ON-BOARD COMPUTER: trip settings (3/4)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
On-board computer with distance before
next service message (cntd.)
h) Mileage before service
With the ignition switched on and the engine not running,
SERVICE
OIL CHANGE IN
when the message “Service Intervals” is displayed, press
INTERVALS
button 2 or 3 for around 5 seconds to display the mileage before
30 000 km/24 months
the next service (distance or time remaining before the next oil
change). When the distance value approaches its limit, there are
several possible scenarios:
- If the range is less than 930 miles (1,500 km) or one month:
SERVICE DUE IN
the message “Service due” is displayed accompanied by the
300 km/24 days
nearest term (distance or time);
- range equal to 0 km/miles or service date reached: the
message “SERVICE REQUIRED” is displayed accompanied
SERVICE REQUIRED
The vehicle requires an oil change as soon as possible.
Depending on the vehicle, the mileage before an oil change varies according to the driving style (frequent driving at low speed,
door-to-door journeys, extensive use at idling speed, towing a trailer, etc.). The distance remaining until the next oil change can
therefore decrease more quickly in some cases than the actual distance travelled.
Resetting: to reset the mileage before the next oil change, display the remaining range (distance and time), then press and hold
button 2 or 3 for approximately 10 seconds until the display shows the mileage before oil change without flashing.
1.113
CarManuals2.co
ON-BOARD COMPUTER: trip settings (4/4)
The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.
Examples of selections
Interpreting the display selected
TYRE PRESSURE SET
<PRESS-HOLD>
i) Tyre pressure reset ➥ 2.26.
SPEED LIMITER
90 km/h
j) Cruise control, speed limiter programmed speed ➥ 2.63 and ➥ 2.67.
CRUISE CONTROL
90 km/h
13°C
16:30
k) Time and temperature ➥ 1.118.
l) Trip log.
NO MESSAGE
Successive display:
MEMORISED
- information messages (passenger airbag OFF etc.);
- operating fault messages (check the injection system, etc.).
ADBLUE 62%
m) Percentage volume of reagent left ➥ 1.137.
Top Up AdBlue
before 2400 km
g) Estimated range with remaining reagent.
1.114
CarManuals2.co
TRIP COMPUTER AND WARNING SYSTEM: information messages
These can help in the vehicle starting phase, or give information about a selection or a driving status.
Examples of information messages are given in the following pages.
Examples of messages
Interpreting the display selected
« PARKING BRAKE ON »
Indicates that the parking brake has been applied.
« BATTERY LOW
Indicates that the vehicle must be started to recharge the battery (e.g. after the engine has been
START ENGINE »
switched off for some time whilst listening to the radio).
« TOP UP OIL LEVEL »
Indicates that the oil level needs adjusting.
« AUTO DOOR
Indicates that the automatic door locking while driving is deactivated.
LOCK OFF »
« WARNING: Check
Indicates that the steering column has not been locked.
Power Steering »
1.115
CarManuals2.co
TRIP COMPUTER AND WARNING SYSTEM: operating fault messages
soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle.
They disappear when the display selection key is pressed or after several seconds and are stored in the computer log. The
warning light stays on. Examples of operating fault messages are given in the following pages.
Examples of messages
Interpreting the display selected
« CLEAN DIESEL FILTER »
Indicates the presence of water in the diesel filter; contact an approved Dealer
as soon as possible.
“CHECK VEHICLE”
Indicates a fault in one of the pedal sensors, battery management system or oil
level sensor.
“CHECK AIRBAG”
Indicates a fault in the restraint system in addition to the seat belts. In the event
of an accident, it is possible that they may not be triggered.
“Check antipollution system”
- Indicates a fault in the vehicle’s emission control system.
- Indicates a fault in the emissions reduction system when it is accompanied by
the
warning light ➥ 1.137.
1.116
CarManuals2.co
TRIP COMPUTER: warning messages
These appear with the® warning light and require you to stop immediately, for your own safety, as soon as traffic
conditions allow. Stop your engine and do not restart it. Call an approved Dealer.
Some examples of warning messages are given below. Note: the messages appear on the display either individually or alter-
nately (when there are several messages to be displayed), and may be accompanied by a warning light and/or a beep.
Examples of messages
Interpreting the display selected
“GEAR BOX RISK OF BREAKAGE“
Indicates an injection fault, the vehicle’s engine has overheated or there is a
serious engine fault.
“WARNING: Braking System”
Indicates a fault in the braking system.
“WARNING: Power Steering”
Indicates a fault in the steering system.
“Electric System Failure“
Indicates a fault in the vehicle battery charging circuit (alternator etc.).
“PUNCTURE”
Indicates that at least one wheel is punctured or severely underinflated.
1.117
CarManuals2.co
CLOCK AND EXTERIOR TEMPERATURE (1/2)
1
6
2
3
5
4
Vehicles fitted with a multimedia
Vehicles not fitted with a multimedia
Set the hour using control 3 or 4, then
screen
screen
press switch 5 “OK” to confirm.
The time and exterior temperature are
Press the switch 2 as many times as re-
Set the minutes using control 3 or 4,
displayed on the multimedia screen 1.
quired to reach the “Vehicle” tab.
then press switch 5 “OK” to confirm.
Refer to the multimedia instructions.
Repeatedly press control 3 or 4 to set
the 6 clock.
Press and hold switch 5 “OK” until the
time display flashes.
If the power supply is cut (battery
disconnected, supply wire cut, etc.),
the clock must be reset.
We recommend that you do not
adjust these settings while driving.
1.118
CarManuals2.co
CLOCK AND EXTERIOR TEMPERATURE (2/2)
External temperature
indicator
Special note:
When the external temperature is be-
tween -3°C and +3°C, the °C symbols
flash (indicates risk of ice).
External temperature in-
dicator
As ice formation is related
Depending on the vehicle, If the
to climatic exposure, local
electrical supply is cut (battery dis-
air humidity and temperature, the
connected, broken supply wire,
external temperature alone is not
etc.), the clock will automatically
sufficient to detect ice.
go back to the right time after a few
minutes once the system is capable
of receiving information GPS.
1.119
CarManuals2.co
EXTERIOR LIGHTING AND SIGNALS (1/6)
2
1
1
3
Side lights
Dipped beam
š
k
headlights
Turn ring 2 until the symbol is
opposite mark 3.
Manual operation
This indicator light on the instrument
Turn ring 2 until the symbol is opposite
panel comes on.
mark 3. This indicator light on the in-
strument panel comes on.
Before driving at night,
check that the electrical
Daytime running lights
Automatic operation
equipment is operating cor-
function
(depending on the vehicle)
rectly and adjust the head-
The daytime running lights come on
light beams (if your vehicle is not
Turn ring 2 until the AUTO symbol is op-
automatically with no action on stalk 1
carrying its normal load). As a gen-
posite mark 3: with the engine running,
when the engine is started, and they go
eral precaution, check that the lights
the dipped beam headlights switch on
off once the engine is switched off.
are not obscured
(by dirt, mud,
or off automatically depending on the
snow or objects being transported).
brightness of the light outside, without
any action on stalk 1.
1.120
CarManuals2.co
EXTERIOR LIGHTING AND SIGNALS (2/6)
During deactivation of the main beam
The main beam headlights come on au-
headlights, the dipped beam headlights
tomatically if:
return to their original position.
- exterior light is weak;
- no other vehicles or lighting are de-
2
tected;
1
Automatic main beam
- the vehicle speed is above approxi-
headlights
mately 25 mph (40 km/h).
Depending on the vehicle, this system
If any of the above conditions are not
switches the main beam headlights on
fulfilled, the system switches to dipped
and off automatically. It uses a camera
beam headlights.
located behind the interior rear-view
Note: make sure the windscreen is not
mirror to detect vehicles that are being
obscured (dirt, mud, snow, condensa-
followed and those coming in the oppo-
tion etc.).
3
site direction.
To activate automatic main beam
headlights:
Main beam headlights
á
turn ring 2 until the symbol AUTO is
With the engine running and
opposite mark 3 and push the stalk 1.
the dipped beam headlights lit, push
stalk 1. This indicator light on the instru-
Warning light
comes on the in-
ment panel comes on.
The system may encounter difficul-
strument panel.
To return to the dipped headlight posi-
ties under certain conditions, inclu-
tion, pull the stalk 1 towards you again.
ding:
- extreme weather conditions (rain,
snow, fog, etc.);
“Raise lights during driving”
- obstruction in front of the wind-
function
screen or camera;
When the main beam headlights are
- when a following or oncoming ve-
activated, the “Raise lights during driv-
hicle has weak or hidden lighting;
ing” function improves driver visibil-
- incorrect settings for the front
ity by automatically raising the dipped
headlights;
beam headlight and the main beam
- reflective systems;
headlights.
- ...
1.121
CarManuals2.co
EXTERIOR LIGHTING AND SIGNALS (3/6)
Operating faults
When the message “Check Automatic
Lighting” appears on the instrument
panel, the system is deactivated.
2
Consult an approved dealer.
1
Using the portable naviga-
tion system at night in the
windscreen area below the
3
camera may disturb the op-
eration of the “automatic main beam
headlights” system (risk of reflection
Automatic main beam
on the windscreen).
headlights (continued)
To deactivate automatic main beam
headlights:
- turn ring 2 to a position other than
If the vehicle is parked
AUTO;
on the hard shoulder with
or
the tailgate open, the rear
- pull the stalk 1.
lights may be obscured.
The “automatic main beam
You should make other road users
Warning light
goes out on the in-
headlights” system should
aware of your vehicle by using a
strument panel.
under no circumstances be
warning triangle or other equipment
used to replace driver atten-
Note: the main beam headlights will be
specified by the road traffic regula-
tion and responsibility with regard
activated upon deactivation of the au-
tions of the country you are driving
to vehicle lighting and adapting to
tomatic main beam headlights function.
in.
light, visibility and traffic conditions.
1.122
CarManuals2.co
EXTERIOR LIGHTING AND SIGNALS (4/6)
Lights-on reminder buzzer
Welcome and goodbye
If the lights are on after the engine is
function
switched off, a warning beep sounds
(depending on the vehicle)
when the driver’s door is opened to
Once the function is activated, the day-
warn you that the lights are still on (to
time running lights and the rear side
2
avoid battery discharge or other prob-
lights will light up automatically upon
lems).
detection of the card or when the vehi-
cle is unlocked.
Operating faults
They switch off automatically:
When the message “WARNING: Check
- approximately one minute after light-
Lighting” with warning light
ing up;
- when starting the engine based on
is displayed and warning light k
the position of the lighting stalk;
flashes on the instrument panel, this in-
dicates that there is a lighting fault.
or
Switching off the lights
Consult an authorised dealer.
- upon locking the vehicle.
The lights will go out automatically
when the engine is switched off, the
driver’s door is opened or the vehicle
Activating/deactivating the
is locked. In this case, the next time
function
the engine is started the lights will be
To activate or deactivate the external
switched back on according to the posi-
welcome function, please see the multi-
tion of the ring 2.
media instructions.
Note: if the fog lights are lit, the lights
Select “ON” or “OFF”.
are not switched off automatically.
1.123
CarManuals2.co
EXTERIOR LIGHTING AND SIGNALS (5/6)
With the engine lights switched off,
the 2 ring in AUTO, pull the lever 1 to-
wards you: the side lights and dipped
beam headlights will switch on for ap-
2
proximately 30 seconds along with the
1
š
and k
warning lights on the
instrument panel.
To increase this duration, you may pull
the stalk up to four times (total time re-
stricted to approximately two minutes).
The message “Follow-me Home for
econds _ _ _” along with the time the
lights will be on for is displayed on the
instrument panel to confirm this action.
You can then lock your vehicle.
“See-me-home lighting”
To switch off the lights before they go
function
out automatically, turn ring 2 to any po-
sition, then return it to position AUTO.
This function enables you to briefly
switch on the side lights and dipped
beam headlights (e.g. to provide light
when opening a gate).
1.124
CarManuals2.co
EXTERIOR LIGHTING AND SIGNALS (6/6)
Rear fog lights
Cornering lights
(depending on vehicle)
Turn centre ring 4 on the stalk
until the symbol faces mark 3, then re-
When driving in forward gear, with
lease it.
the vehicle speed below approxi-
2
mately 25 mph (40 km/h), whenever
3
4
1
Operation of the fog lights depends on
the dipped beam headlights are on:
the exterior lighting selected, and an in-
under certain conditions (the steering
dicator light will light up on the instru-
wheel at an angle, the indicator lights
ment panel.
on etc.), when turning a corner one of
Do not forget to switch off the fog lights
the front fog lights will switch on to light
when they are no longer needed, to
the inside of the bend.
avoid inconveniencing other road
When reverse gear is engaged and
users.
the dipped beam headlights are on the
two front fog lights illuminate automati-
Switching off the lights
cally.
Front fog lights
Turn the centre ring 4 again until mark 3
Note: when shifting from reverse gear
g
Turn centre ring
4
on
the
is opposite the symbol for the fog lights
into forward gear (e.g. during a park-
stalk 1 until the symbol faces mark 3,
that you wish to switch off. The corre-
ing manoeuvre), the two front fog lights
then release it.
sponding indicator light on the instru-
remain lit until the vehicle speed ex-
ment panel goes out.
ceeds approximately 6 mph (10 km/h).
Operation of the fog lights depends on
the exterior lighting position selected,
The front and rear fog lights switch off
and an indicator light will light up on the
when the exterior lights are switched
instrument panel.
off.
When driving in fog or snow, or when transporting objects which are higher than the roof, the headlights do not come on au-
tomatically.
Switching on the fog lights remains the responsibility of the driver: the indicator lights on the instrument panel inform you
whether the fog lights are lit (indicator light on) or not (indicator light not on).
1.125
CarManuals2.co
HEADLIGHT BEAM ADJUSTMENT
Load status
Control position
Driver only or with passenger
0
All seats occupied
1
A
Driver with passengers and luggage
(or load) reaching the maximum
2
1
permissible all-up weight
Driver without a passenger and
with luggage (or load) reaching the
3 or 4
2
maximum authorised load weight
On vehicles fitted with this function,
control A allows you to adjust the height
The table below gives some examples. In all cases, adjust control A according to
of the beams according to the load.
the vehicle load so that the road can be seen and other drivers are not dazzled.
With the dipped beam headlights on,
press the top 1 of control A to raise
the headlight beam or on the bottom of
control 2 to lower the headlight beam.
1.126
CarManuals2.co
AUDIBLE AND VISUAL SIGNALS
Direction indicators
Move stalk 1 parallel to the steering
wheel and in the direction you are going
to turn it.
1
One-touch mode
Briefly shift the stalk
1 upwards or
downwards, not exceeding the point
A
of resistance, then release it: the stalk
will return to its original position and the
direction indicator light concerned will
flash three times.
2
Horn
Hazard warning lights
é
Press steering wheel boss A.
Press switch 2.
This switch activates all four direction
Headlight flasher
indicators and the side indicator lights
simultaneously. It must only be used in
Pull stalk 1 towards you to flash the
an emergency to warn drivers of other
headlights.
vehicles that you have had to stop in
an area where stopping is prohibited or
unexpected, or that you are obliged to
drive under special conditions.
1.127
CarManuals2.co
WINDSCREEN WASH, WIPE (1/4)
Special note
1
When driving, the wiping speed slows
down whenever the vehicle stops. For
example, fast wiping speed will slow to
normal wiping speed.
A
1
As soon as the vehicle moves off,
B
wiping will return to the speed originally
selected. If stalk 1 is operated, it over-
C
rides and cancels the automatic func-
D
tion.
E
With the ignition on, move the stalk 1.
-
A a single sweep of the wipers.
A short push will trigger one sweep
of the wipers.
-
B switching off.
–
C intermittent wiping.
The wipers will pause for several
seconds between sweeps. It is pos-
sible to change the time between
sweeps by turning ring 2.
-
D slow continuous wiping.
When working in the engine
–
E fast wiping speed.
compartment, ensure that
the windscreen wiper stalk
Positions C and D are accessible
is in position B (park).
with the ignition on. Position E is
Risk of injury.
accessible only when the engine is
running.
1.128
CarManuals2.co
WINDSCREEN WASH, WIPE (2/4)
Note:
-
the rain sensor is only intended as a
driving aid. In the event of reduced
1
visibility, the driver should manually
2
activate the wipers. In foggy weather
A
1
F
or during snowfalls, wiping is not au-
B
tomatically triggered and remains
under the driver’s control;
C
-
in the event of temperatures below
D
zero, automatic wiping is not acti-
vated when the vehicle is started. It
E
is automatically activated as soon as
G
the vehicle exceeds a certain speed
(approximately 5 mph (8 km/h));
-
do not activate automatic wiping in
Vehicles with automatic wiper
-
C automatic wiper function
dry weather;
When this position is selected, the
function
-
fully de-ice the windscreen before
system detects water on the wind-
With the engine running, press the
activating automatic wiping;
screen and triggers the wipers at a
stalk 1.
suitable wiping speed. It is possi-
-
when washing using a roller type car
- A a single sweep of the wipers.
ble to change the triggering thresh-
wash, return the ring 1 on the stalk B
A short push will trigger one sweep
old and the time sweeps by turning
to the stop position to deactivate au-
of the wipers.
ring 2:
tomatic wiping.
- F: minimum sensitivity;
– B switching off.
- G: maximum sensitivity.
The higher the sensitivity, the quicker
the wipers will react and the faster the
wipe.
Position D is accessible with the ig-
nition on. Positions C and E are ac-
cessible only with the engine run-
ning.
1.129
CarManuals2.co
WINDSCREEN WASH, WIPE (3/4)
- D slow continuous wiping.
Operating faults
- E fast wiping speed.
In the event of a malfunction of the au-
tomatic wiping, the wiper is set to inter-
Note: there is a maintenance position
mittent wiping. Call an approved Dealer.
for replacing wiper blades.
The operation of the rain sensor may
This position enables the blades to be
be interrupted in the event of:
lifted to remove them from the wind-
screen.
- damaged windscreen wipers; a film
of water or traces left by a blade in
It may be useful to:
the sensor’s detection zone may in-
- to clean the blades;
crease the response time of the au-
tomatic wiper, or increase the wiping
- to release the blades from the wind-
frequency;
screen in winter;
- replace the blades.
- a windscreen with any chip or crack
level with the sensor, or a windscreen
With the ignition on and the engine
covered in dust, dirt, insects, ice, the
off, fully lower (position E) the wind-
use of washing wax and water-repel-
screen wiper stalk 1. The wiper arms
lent chemicals; the windscreen wiper
stop in a position away from the bonnet.
will be less sensitive or may even not
➥ 5.33.
react at all.
1.130
CarManuals2.co
WINDSCREEN WASH, WIPE (4/4)
A
1
B
C
Efficiency of a wiper blade
D
Check the condition of the wiper blades. How long they last depends on you:
E
- it must remain clean: clean the blade and the screen regularly with soapy
water;
- do not use it when the screen is dry;
- free it from the screen when it has not been used for a long time.
Windscreen washer
In all cases, replace it as soon as it begins to lose efficiency: approximately once
With the ignition on, pull stalk 1 to-
a year ➥ 5.33.
wards you.
A brief pull will trigger a single sweep
Precautions for using the wipers
of the wipers, in addition to the wind-
screen washer.
In the event of obstacles on the windscreen (dirt, snow, ice etc.), clean the wind-
screen (including the central area located behind the interior rear view mirror)
A longer press will trigger three sweeps
before starting the wipers (risk of motor overheating).
of the wipers followed a few seconds
later by a fourth, in addition to the wind-
If an object is preventing a blade from moving, it may stop functioning. Remove
screen washer.
the obstacle and reactivate the wiper using the wiper stalk.
Before any action involving the windscreen (washing the vehicle, de-ic-
ing, cleaning the windscreen, etc.) return stalk 1 to position B (park).
Risk of injury and/or damage.
1.131
CarManuals2.co
REAR SCREEN WASHER, WIPER (1/2)
1
Efficiency of a wiper blade
2
3
Check the condition of the wiper
blades. How long they last depends
on you:
- it must remain clean: clean the
blade and the screen regularly
with soapy water;
- do not use it when the screen is
dry;
- free it from the screen when it has
Rear windscreen wiper
not been used for a long time.
Y
With the ignition on, turn the
In all cases, replace it as soon as
ring 3 on the stalk 1 until the symbol is
it begins to lose efficiency: approxi-
opposite the 2 mark.
mately once a year ➥ 5.33.
To stop operation, turn the ring 3 again
to the off position.
Do not use the wiper arm to open or
close the tailgate.
Precautions for using the
Note: when washing using a roller
wipers
type car wash, return the ring 3 on the
stalk 1 to the stop position to deactivate
- In freezing or snowy weather,
automatic wiping.
Before any action on the
clear the screen before starting
windscreen
(washing the
the wipers (risk of motor over-
Follow usage recommendations.
vehicle, de-icing, cleaning
heating);
the windscreen, etc.) return
- ensure that no objects are ob-
stalk 1 to the park position.
structing the travel of the blade.
Risk of injury and/or damage.
1.132
CarManuals2.co
REAR SCREEN WASHER, WIPER (2/2)
Activation/Deactivation of the rear
In the event of obstacles present on the
screen wiper
rear window (dirt, snow, etc.), the wiper
will try to sweep away all the obstacles.
Engaging reverse gear triggers inter-
mittent wiping (if the front wipers are in
If an obstacle prevents the blade from
1
operation). If your vehicle is equipped
moving, it can be stopped. Remove the
with a vehicle settings customisation
obstacle, wait for around 30 seconds
menu, you can opt to activate or deacti-
and reactivate the wiper using the wiper
vate this function. Refer to the multime-
stalk.
dia instructions.
Precautions
For vehicles not fitted with a settings
customisation menu, you can have this
- If the weather is icy, check that the
function deactivated by an authorised
blade is not stuck to the windscreen
dealer.
before operating the wipers. If you
activate the wiper while the blade is
blocked by ice, you risk damaging
both the blade and the wiping motor.
Rear screen wash/wipe
p
– Do not operate the wipers on a dry
With the ignition on, push and
screen. This will lead to the prema-
hold stalk 1, then release.
ture wear or damage to the blades.
Holding for longer will trigger three
sweeps of the wipers followed, a few
seconds later, by a fourth, in addition to
the windscreen washer.
When working in the engine
compartment, ensure that
the windscreen wiper stalk
is in the park position.
Risk of injury.
1.133
CarManuals2.co
TANK (1/3)
Filling with fuel
With the ignition off, insert the nozzle
and insert it fully before turning it on to
1
fill the fuel tank (risk of splashing).
To fill up with fuel, the
Keep the nozzle in this position through-
engine must be stopped
out the entire filling operation.
(and not only on standby
When the pump cuts out automatically
in the case of vehicles
at the end of the filling procedure, a
equipped with the Stop and Start
maximum of two further filling attempts
function): you must switch off the ig-
may be made, as there must be suffi-
nition ➥ 2.3, ➥ 2.8.
cient space in the fuel tank to allow for
2
Fire hazard.
A
expansion.
Make sure that no water enters the fuel
tank during filling. The cover A and its
Useful capacity
of tank: Approx.
surround must remain clean.
Do not mix even small
80 litres
amounts of petrol
(un-
Open the front left door to open the
leaded or E85) with diesel.
cover A.
Do not use ethanol-based
Use the cap holder 2 on the flap A
fuel if your vehicle is not compatible
during filling to hold the cap 1 in place.
with this fuel.
Do not add reagent to the fuel -
Fuel grade
otherwise you risk damaging the
engine ➥ 1.137.
Use high-grade fuel that complies with
the legislation in force in each country.
If you wish to add an additive to the
It must comply with the specifications
fuel, use a product approved by our
indicated on the label on the fuel tank
Technical Department.
cover A. ➥ 6.9.
Consult an approved dealer.
After filling, check that the cap and
cover are closed.
1.134
CarManuals2.co
TANK (2/3)
Running out of fuel on diesel
versions
Vehicles with key/remote control
-
Set the ignition key to “On” posi-
tion M ➥ 2.2 and wait a few minutes
before starting to enable the fuel cir-
Please note when work-
cuit to be primed;
ing close to the engine that
it may be hot. In addition,
-
turn the key to position D. If the
the engine cooling fan may
engine does not start, repeat the pro-
Fuel types that conform to European
cedure;
start at any moment. The
standards with which the engines of
-
if the engine does not start after sev-
warning light in the engine compart-
vehicles sold in Europe are compat-
eral attempts, please contact an au-
ment reminds you of this.
ible ➥ 6.9.
thorised dealer.
Risk of injury.
Do not mix even small
amounts of petrol
(un-
leaded or E85) with diesel.
Filler cap: this is specific.
Do not use ethanol-based
fuel if your vehicle is not compatible
If you have to replace it,
with this fuel.
make sure it is identical to
No modifications what-
the original cap. Contact an
Do not add reagent to the fuel -
soever are permitted on
approved Dealer.
otherwise you risk damaging the
any part of the fuel supply
Never place the cap near a source
engine ➥ 1.137.
system
(electronic units,
of heat or flame.
wiring, fuel circuit, injectors, pro-
If you wish to add an additive to the
tective covers, etc.) as this may be
Do not wash the filler area with a
fuel, use a product approved by our
dangerous (unless undertaken by
high-pressure washer.
Technical Department.
qualified Network personnel).
Consult an approved dealer.
1.135
CarManuals2.co
TANK (3/3)
3
Vehicles with card
Persistent fuel odour
With the card in the passenger com-
If you notice a persistent
partment, press the start button 3 with-
fuel odour you should:
out pressing any of the pedals. Wait a
few minutes before starting. This will
- stop the vehicle as soon as traf-
enable the fuel circuit to be primed. If
fic conditions allow and switch off
the engine does not start, repeat the
the ignition;
procedure.
- switch on the hazard warning
lights and ask your passengers to
leave the vehicle and stay clear
of the traffic;
- contact an approved Dealer.
1.136
CarManuals2.co
REAGENT TANK (1/4)
Please ensure that you comply with the
legislation of your country.
It is important to remember that failure
to respect regulations in force could
lead to legal action being taken against
1
the vehicle owner.
To fill up with reagent, the engine
must be stopped (not just on standby
Operating principle
in the case of vehicles with the Stop
The reagent is intended for Diesel en-
and Start function). You must switch
gines fitted with the SCR (selective cat-
off the ignition ➥ 2.3, ➥ 2.8.
alytic reduction) system. Using the re-
agent reduces the quantity of nitrogen
A
oxides in exhaust gases.
Consumption in real time depends on
If the
“XXX MILES (XXX
vehicle usage conditions, the equip-
KM) failure Top up AdBlue”
Filling
ment fitted and the user’s driving style.
warning message appears,
Useable capacity of the tank: be-
fill the reagent tank and
tween approximately 4.84 gal and
refer to the filling instructions.
Reagent quality
5.5 gal (22 litres and 25 litres) (de-
Risk of immobilisation of the ve-
pending on the vehicle).
Use only reagents which conform
hicle.
to standard ISO 22241 and in accord-
Ignition off, open the front left door to
ance with the mark on the tank filler
open the cover A. Unscrew the cap 1.
cap.
Note: ammonium hydroxide vapour
Filler cap: this is specific.
may escape from the cap opening
If you have to replace it,
when the tank temperature is high.
make sure it is identical to
the original cap. Contact
an approved Dealer. Do not wash
the filler area with a high pressure
washer.
1.137
CarManuals2.co
REAGENT TANK (2/4)
Precautions for use
Special cases
The tank can be filled at the pump. In
The reagent fluid freezes below ap-
other cases, it is essential to read the
proximately -10°C.
information shown on the reagent con-
In these conditions, do not attempt filling
tainer (e.g. the can or bottle).
when the fluid is frozen. In the event of
When filling, handle the reagent care-
needing to top up or fill the tank with re-
fully. They can damage clothes,
After filling the reagent tank, check
agent (
on), park the vehicle in a
shoes, bodywork components etc.
that the cap and cover are closed,
hotter location if possible so that the re-
start the engine and WAIT 10 sec-
If the reagent overflows, or contami-
agent becomes liquid again. Otherwise,
onds with the vehicle stationary,
nates any paintwork, clean the affected
have a qualified professional top up or
engine running before setting off
area quickly with plenty of cold water
fill up with reagent fluid.
again.
and a soft cloth.
If this operation is not carried out,
Note: if the reagent crystallises, use a
the filling of the tank will not be
soft sponge.
taken into account automatically
until after several dozens of minutes
In extreme cold weather conditions
of driving.
In frosty weather conditions, the rea-
The message “--- TOP UP AdBlue”
gent tank should be refilled when the
and/or the warning lights will con-
tinue to appear until the filling has
indicator and the message “TOP
been registered by the system.
UP AdBlue before 1200 km” appear on
the instrument panel.
No work whatsoever is
permitted on any part of
The reagent must not come
the system. To prevent
into contact with eyes or
damage, only qualified per-
skin. If it does, wash the af-
sonnel from our network may work
fected area with plenty of
on the system.
cold water. If necessary, consult a
doctor.
1.138
CarManuals2.co
REAGENT TANK (3/4)
Maintenance/Range
The information displayed on the instrument panel may be accompanied by a beep.
Indicator lights
Messages
What to do?
When the message is displayed when the ignition is switched
on, you have less than 1,488 miles (2,400 km) range.
-
“ Top Up AdBlue before 2400 km“
Refill, or have an Approved Dealer refill the reagent in the
tank.
When the message is displayed when the ignition is switched
on, you have between 744 miles (1,200 km) and 496 miles
“ TOP UP AdBlue before 1200 km“
(800 km) range.
appears.
Refill, or have an Approved Dealer refill the reagent in the
tank.
The message is displayed when the ignition is switched on
and is repeated:
- Approximately every 62 miles (100 km), you have between
about 496 miles (800 km) and 124 miles (200 km) range;
“XXX KM failure Top up AdBlue”
appears.
- Approximately every 31 miles (50 km), you have less than
124 miles (200 km) range.
In any event, fill or have an Approved Dealer fill the reagent
tank as soon as possible.
flashes or
The engine will not start.
comes on, de-
“0 KM failure Top up AdBlue”
To restart, you must fill the reagent tank yourself.
pending on the
vehicle.
1.139
CarManuals2.co
REAGENT TANK (4/4)
System faults
When the indicator lights light up, this may be accompanied by a beep.
Indicator lights
Messages
What to do?
“Check Anti- Pollution System”
Indicates a fault in the system. Contact your approved
and
“AdBlue quality to check”
Dealer as soon as possible.
come on.
“AdBlue injection to check”
This indicates a system fault and that less than 621 miles
(1,000 km) range remains or, depending on the vehicle,
less than 497 miles (800 km) range remains until it is no
longer possible to restart the vehicle.
These warnings are repeated:
- every 62 miles (100 km) until between approximately
and
“XXX KM failure antipollution”
621 miles (1000 km) and 124 miles (200 km) range re-
come on.
mains or, depending on the vehicle, between 497 miles
(800 km) and 124 miles (200 km) remains until it is no
longer possible to restart the vehicle;
- Every 31 miles (50 km) when there is less than 124 miles
(200 km) left before the vehicle cannot be restarted.
Contact your approved dealer as soon as possible.
Indicates that after the ignition is switched off the vehicle will
and
“0 KM failure antipollution”
not restart. Call an approved Dealer.
come on.
1.140
CarManuals2.co
Section 2: Driving
(Advice on use relating to fuel economy and the environment)
Running in
2.2
Ignition switch
2.2
Starting/stopping the engine: vehicle with key
2.3
Starting, stopping the engine: vehicle with card
2.4
Stop and Start function
2.8
Special features of Diesel versions
2.12
Gear lever/Handbrake
2.17
Driving advice, Eco-driving
2.18
Maintenance and antipollution advice
2.24
Environment
2.25
Tyre pressure monitoring system
2.26
Driver correction devices and aids
2.31
Lane departure warning
2.36
Blind spot warning
2.41
Safe distance alert
2.47
Active emergency braking
2.51
Detection of road signs
2.59
Speed limiter
2.63
Cruise control
2.67
Adaptive cruise control
2.72
Overspeed function
2.86
Fast idle speed
2.87
Parking distance control
2.88
Reversing camera
2.96
Automatic gearbox
2.99
Emergency call
2.103
2.1
CarManuals2.co
RUNNING IN, IGNITION SWITCH: vehicle with key
Diesel version
“Ignition” position ON 2
For the first 932 miles (1,500 km), do
The ignition is switched on: Any acces-
not exceed 80 mph (130 km/h) in the
sories (radio etc.) can be used.
highest gear, or 2,500 rpm. After com-
pleting this mileage you may drive
“Start” position START 3
faster, although you may only expect
top performance after approximately
If the engine fails to start at the first
3,600 miles (6,000 km).
attempt, the key must be turned back
before the starter can be activated
During the running in period, do not ac-
again. Release the key as soon as the
celerate hard while the engine is still
engine starts.
cold and do not let the engine over-rev.
Note: on diesel versions, several sec-
Service intervals: refer to the
onds may pass between turning the
Maintenance Document for your vehi-
key and the engine starting to allow for
cle.
engine preheating.
Note: for a new vehicle in the running-in
Off position LOCK 0 (steering
phase: the coolant level may be higher
lock applied)
than the “MAXI” mark on the tank, then
drop to between the levels “MINI” and
To lock: remove the key and turn the
“MAXI”. This does not present a risk.
steering wheel until the steering column
locks.
To unlock: turn the key and the steering
wheel slightly.
2.2
CarManuals2.co
STARTING, STOPPING THE ENGINE: vehicle with key
For all vehicles:
Stopping the engine
turn the key to the “START” position 3
With the engine idling, turn the key
without depressing the accelerator
back to the “LOCK” position 0.
pedal.
Release the key as soon as the engine
starts.
Driver’s responsibility
when parking or stopping
Starting the vehicle
the vehicle
On flat, level ground, with the vehi-
Never leave an animal,
cle unladen, you are recommended
child or adult who is not self-suffi-
to start in second gear.
cient alone in your vehicle, even for
a short time.
Starting the engine
Never start your vehicle
They may pose a risk to themselves
or to others by starting the engine,
while freewheeling on a
Turn the ignition key to the “ON” po-
activating equipment such as the
gradient. Risk of non-ac-
sition 2 and hold this position until the
electric windows or locking the
tivation of power-assisted
doors, for example.
engine preheating light goes off É
steering.
Also, in hot and/or sunny weather,
To start:
There is a risk of accidents.
please remember that the tempera-
on vehicles equipped with automatic
ture inside the passenger compart-
gearboxes, set the lever to position P
ment increases very quickly.
or N.
Never switch off the igni-
RISK OF DEATH OR SERIOUS
tion before the vehicle has
INJURY.
stopped completely. Once
the engine has stopped, the
brake servo, power-assisted steer-
ing, etc., and the passive safety de-
vices such as the airbags and pre-
tensioners will no longer operate.
2.3
CarManuals2.co
STARTING, STOPPING THE ENGINE: vehicle with card (1/4)
1
2
3
The card must be in detection zone 1
To start:
for the van version, and in detection
-
vehicles with an automatic gearbox,
zone 2 for the combi version.
place the lever in position P or N, de-
Press the button 3.
press the brake pedal and press
button 3;
Starting the vehicle
-
vehicles with a manual gearbox,
depress the brake or clutch pedal
On flat, level ground, with the vehi-
and press the button 3. If a gear is
cle unladen, you are recommended
engaged, the vehicle may only be
to start in second gear.
started by depressing the clutch
pedal.
Never start your vehicle
while freewheeling on a
gradient. Risk of non-ac-
tivation of power-assisted
steering.
There is a risk of accidents.
2.4
CarManuals2.co
STARTING, STOPPING THE ENGINE: vehicle with card (2/4)
Special note:
-
if one of the starting conditions is
not met, the message “Press Brake
+ START”, “Press Clutch + Start” or
“Select Gearbox Position “P”” is dis-
played on the instrument panel;
-
in some cases, it will be necessary
to move the steering wheel whilst
Driver’s responsibility
pressing the start button 3 to help
when parking or stopping
unlock the steering column; the
the vehicle
3
message “Turn Steering Wheel +
Never leave an animal,
START” will warn you of this;
child or adult who is not self-suffi-
-
when starting the engine in very low
cient alone in your vehicle, even for
exterior temperatures (below -10°C):
a short time.
hold down the clutch pedal or the
Accessories function
They may pose a risk to themselves
brake pedal until the engine starts.
(switching on the ignition)
or to others by starting the engine,
activating equipment such as the
Once you have gained access to your
electric windows or locking the
vehicle, you may use some of its func-
doors, for example.
tions (radio, navigation, wipers, etc.).
Also, in hot and/or sunny weather,
To use the other functions, with the
please remember that the tempera-
card in the passenger compartment,
ture inside the passenger compart-
press the 3 button without pressing the
ment increases very quickly.
pedals.
RISK OF DEATH OR SERIOUS
INJURY.
2.5
CarManuals2.co
STARTING, STOPPING THE ENGINE: vehicle with card (3/4)
1
2
3
Conditions for stopping the
If the card is no longer in the passen-
ger compartment or if the card’s bat-
engine
tery is flat, when the vehicle is station-
The vehicle must be at a standstill.
ary and you try to switch the engine off,
The vehicle must be stationary, with the
the message “Keycard absent: press/
lever positioned in P or N for vehicles
hold START” appears on the instrument
with an automatic gearbox.
panel: press button 3 for longer than
three seconds.
The card must be in detection zone 1
on the van version and in detection
With the engine switched off, any ac-
Never switch off the igni-
zone 2 on the combi version. Press
cessories being used (radio etc.) will
tion before the vehicle has
button 3: the engine stops. The steer-
continue to function for approximately
stopped completely. Once
ing column is locked when the driver’s
10 minutes.
the engine has stopped, the
door is opened or the vehicle is locked.
When the driver’s door is opened, the
brake servo, power-assisted steer-
accessories stop working.
ing, etc., and the passive safety de-
vices such as the airbags and pre-
tensioners will no longer operate.
2.6
CarManuals2.co
STARTING, STOPPING THE ENGINE: vehicle with card (4/4)
The message “Place card on zone +
When you leave your vehi-
START” appears on the instrument
cle, especially if you have
panel.
4
your card with you, check
Press the brake or clutch pedal, then
that the engine is com-
place the card 5 (button side facing
pletely switched off.
you) at the angle indicated on one of
5
the placement areas 4. Press the 3
button to start the vehicle. The mes-
Driver’s responsibility
sage goes out.
when parking or stopping
the vehicle
Never leave an animal,
child or adult who is not self-suffi-
cient alone in your vehicle, even for
a short time.
Operating faults
They may pose a risk to themselves
or to others by starting the engine,
In certain cases, the hands-free card
activating equipment such as the
may not work:
electric windows or locking the
- when the card battery is drained, flat
doors, for example.
battery etc.
Also, in hot and/or sunny weather,
- near to appliances operating on the
please remember that the tempera-
same frequency as the card (moni-
ture inside the passenger compart-
tor, mobile phone, video game, etc.);
ment increases very quickly.
- vehicle located in a high electromag-
RISK OF DEATH OR SERIOUS
netic radiation zone.
INJURY.
2.7
CarManuals2.co
FUNCTION STOP AND START (1/4)
This system enables a reduced fuel
and
For all vehicles:
consumption and lower greenhouse
- the speed is zero.
The warning light
on the instru-
gas emissions.
The engine remains on standby if posi-
ment panel is lit when the engine is on
The system is activated automati-
tion P is selected, or if position N is se-
standby. The vehicle equipment re-
cally when the vehicle is started. While
lected with the handbrake engaged and
mains operational while the engine is
driving, the system stops the engine
the brake pedal released.
stopped.
(standby) when the vehicle is at a
For manual gearboxes:
When the engine switches to standby,
standstill (traffic jam, traffic lights, etc).
- the gearbox is in neutral;
the steering assistance may no longer
and
be operational.
Conditions for engine
- the clutch pedal is released.
In this case it becomes operational
standby
Depending on the vehicle, if the
again when the engine is no longer on
The vehicle has set off from where it
standby or the speed exceeds approxi-
warning light flashes and the
was parked;
mately 0.62 mph (1 km/h) (downhill,
message “Release Clutch pedal” ap-
slope etc.).
For automatic gearboxes:
pears on the instrument panel, this
indicates that the clutch pedal is not
- gearbox is in position D, M or N;
sufficiently released;
and
and
- the brake pedal is pressed.
- the vehicle speed is zero.
Depending on the vehicle, if the
warning light flashes and the
The engine MUST be
message “Press brake pedal” ap-
stopped (not put in standby)
pears on the instrument panel, it in-
before leaving the vehicle.
dicates that the brake pedal is not
➥ 2.3.
sufficiently depressed;
and
- the accelerator pedal is not de-
Keep your vehicle station-
pressed;
ary when the engine is
on standby (shown by the
warning light
on the
instrument panel).
2.8
CarManuals2.co
FUNCTION STOP AND START (2/4)
Preventing the engine from
Conditions for coming out of
- the gearbox is in neutral and the
clutch pedal is slightly depressed;
standing by
engine standby
- the engine is in gear and the clutch
In certain situations, such as negotiat-
For automatic gearboxes:
pedal is pressed right down.
ing a crossroads for instance, it is pos-
-
when the driver’s door is opened;
sible (with the system activated) to keep
Special note: depending on the vehi-
the engine running so as to be ready to
–
when the driver’s seat belt is unfas-
cle, if you switch off the ignition when
move off quickly.
tened;
the engine is on standby, the warning
For vehicles equipped with auto-
-
in manual mode, the gear change
light Ä
is displayed for a few sec-
matic gearboxes:
paddles are activated;
onds on the instrument panel.
Keep the vehicle stationary without
-
the brake pedal is released, position
pressing too hard on the brake pedal.
D or M engaged;
For vehicles equipped with manual
-
the brake pedal is released in gear
gearboxes:
position N with the handbrake off;
Keep the clutch pedal pressed right
-
the brake pedal is pressed again in
down.
gear position P or N engaged with
the handbrake applied;
-
the vehicle is in gear position R;
–
the accelerator pedal is depressed.
For vehicles equipped with a
For manual gearboxes:
manual gearbox
- when opening the driver’s door, with-
The restart may be interrupted if the
out any gear engaged and the clutch
clutch pedal is released too quickly
To fill up with fuel, the
pedal released;
while a gear is engaged.
engine must be stopped
- when unfastening the driver’s seat
(and not only on standby
belt, without any gear engaged and
in the case of vehicles
the clutch pedal released;
equipped with the Stop and Start
function): you must switch off the ig-
nition ➥ 2.2, ➥ 1.134.
If the engine stalls while the system
is in operation, pressing the clutch
Fire hazard.
pedal right down will start it again.
2.9
CarManuals2.co
