ENGINE OIL LEVEL : topping up, filling (2/2)

Exceeding the maximum

engine oil level

Under no circumstances

should the maximum fill-

ing level be exceeded: this could

Consult your approved Dealer at

Filling and/or checking

damage the engine and the emis-

once if you notice an abnormal or

the oil level: when topping

sion control system.

repeated drop in any of the fluid

up or checking the oil level,

levels.

ensure that no oil leaks onto

If the oil level exceeds the maximum

level, do not start your vehicle and

the engine components.

contact an approved dealer.

Do not forget to properly close the

Never run the engine in an

enclosed space as exhaust

cap and refit the dipstick to prevent

gases are poisonous.

any oil spatter on hot engine com-

ponents.

Fire hazard.

Before carrying out any

action in the engine com-

partment, you must switch

Please note when work-

off the ignition. ➥ 2.3.

ing close to the engine that

it may be hot. In addition,

the engine cooling fan may

When working in the engine

start at any moment. The 

compartment, ensure that

Engine oil change: if you

warning light in the engine compart-

the windscreen wiper stalk

are changing the oil when

ment reminds you of this.

is in the park position.

the engine is hot, be careful

Risk of injury.

not to scald yourself if the

Risk of injury.

oil overflows.

4.7

CarManuals2.co

LEVELS, FILTERS (1/3)

Level 1

It is normal for the level to drop as the

brake shoes become worn, but it must

never drop lower than the “MINI” warn-

ing line.

If you wish to check the disc and drum

wear yourself, you should obtain the

When working in the engine

document explaining the checking pro-

compartment, ensure that

cedure from our network or from the

the windscreen wiper stalk

manufacturer’s website.

is in the park position.

Filling

Risk of injury.

After any operation on the hydraulic cir-

cuit, a specialist must replace the fluid.

Only use fluids approved by our

Please note when work-

Technical Department (and taken from

ing close to the engine that

a sealed container).



Brake fluid

it may be hot. In addition,

Replacement intervals

the engine cooling fan may

This should be checked frequently,

and immediately if you notice even the

Refer to the Maintenance Document for

start at any moment. The 

slightest loss in braking efficiency.

your vehicle.

warning light in the engine compart-

The level should be read with the engine

ment reminds you of this.

switched off and on level ground.

Risk of injury.

Before carrying out any

action in the engine com-

If there is an abnormal or repeated

partment, you must switch

drop in the fluid level, please consult

off the ignition. ➥ 2.3.

an authorised dealer.

4.8

CarManuals2.co

LEVELS, FILTERS (2/3)

Frequency of checking coolant level

Check the coolant level regularly

(very severe damage is likely to be

caused to the engine if it runs out of

coolant).

If the level needs to be topped up, only

use products approved by our Technical

Department which ensure:

- protection against freezing;

- anticorrosion protection of the cool-

ing system.

Replacement intervals

Refer to the Maintenance Document for

your vehicle.



Coolant



Windscreen washer

With the engine switched off and on

reservoir 4

level ground, the level when cold must

Filling

be between the “MINI” and “MAXI”

With the engine switched off, open

marks on the coolant reservoir 2.

cap 3, fill until you can see the fluid,

If there is an abnormal or repeated

Top this level up when cold before it

then refit the cap.

drop in the fluid level, please consult

reaches the “MINI” mark.

an authorised dealer.

Fluid

Special windscreen washer fluid (prod-

uct with antifreeze in winter).

No operations should be

carried out on the cooling

Before carrying out any

circuit when the engine is

action in the engine com-

hot.

partment, you must switch

Risk of burns.

off the ignition. ➥ 2.3.

4.9

CarManuals2.co

LEVELS, FILTERS (3/3)

Filters



Power-assisted steering

The replacement of filter elements (air

pump

filter, cabin filter, diesel filter etc.) is

scheduled in the maintenance opera-

Special feature on vehicles fitted

tions for your vehicle.

with a tank 5

Replacement intervals for filter el-

As it is not possible to access the tank

ements: refer to the Maintenance

filler cap 5, consult an approved dealer

Please note when work-

Document for your vehicle.

for topping-up or filling.

ing close to the engine that

it may be hot. In addition,

On equipped vehicles, if warning light 6

the engine cooling fan may

turns red, it indicates that the air filter

is clogged.

start at any moment. The 

Consult your approved dealer as soon

warning light in the engine compart-

as possible.

ment reminds you of this.

Risk of injury.

4.10

CarManuals2.co

TYRE PRESSURE (1/2)

Vehicle fitted with a tyre pressure

loss warning system

In the event of under-inflation (punc-

tures, under-inflation etc.), the 

warning light appears on the instrument

panel. ➥ 2.36.

For your safety, please re-

spect the speed limit.

When they need to be re-

placed, only tyres of the

same make, size, type and profile

should be used on a single axle.

Label A

They must either have a load ca-

pacity and speed rating at least

Open the driver’s door to read it.

equal to those of the original

Tyre pressures should be checked

tyres, or be recommended by an

when the tyres are cold.

authorised dealer.

If the tyre pressures cannot be checked

Failure to heed these instructions

when the tyres are cold, increase the

could endanger your safety and

pressures from 0.2 to 0.3 bar (or 3 PSI).

affect your vehicle’s roadworthi-

Never deflate a hot tyre.

ness.

Risk of loss of control of the ve-

hicle.

4.11

CarManuals2.co

TYRE PRESSURE (2/2)

Tyre safety and chain fitting: for infor-

mation on servicing conditions and, de-

pending on the vehicle version, the use

of chains. ➥ 5.18.

B C

Zone B: tyre pressures for the front

wheels (non-motorway).

Zone C: tyre pressures for the rear

wheels (non-motorway).

Zone D: tyre pressures for the front

wheels (motorway).

Vehicle used fully laden

Zone E: tyre pressures for the rear

(Maximum Permissible

wheels (motorway).

All-up Weight) and

towing a trailer

Zone F: tyre pressure for the emer-

gency spare wheel.

The maximum speed must be lim-

ited to 62 mph (100 km/h) and the

tyre pressure increased by 0.2 bar

(3 psi) ➥ 6.9.

Risk of tyre blowouts.

4.12

CarManuals2.co

BATTERY (1/2)

The charge status of the battery can

decrease, especially if you use your ve-

hicle:

- for short journeys;

- for driving in town;

- when the temperature drops;

- with the vehicle stopped and the

engine off.

This is located behind step A and does

Before carrying out any

not require maintenance. You should

action in the engine com-

not open it or add any fluid.

partment, you must switch

Depending on the vehicle, a system

off the ignition. ➥ 2.3.

continuously checks the battery charge

status.

When the ignition is off, some consum-

ers may also be switched off (dipped

Please note when work-

beam headlights, radio, ventilation,

ing close to the engine that

etc.). When the level is extremely

it may be hot. In addition,

low, the message “Battery Low Start

the engine cooling fan may

Engine” is displayed.

start at any moment. The 

warning light in the engine compart-

ment reminds you of this.

Risk of injury.

4.13

CarManuals2.co

BATTERY (2/2)

Replacing the battery

For your own safety and for

the proper operation of the

vehicle’s electrical equip-

ment

(lights, windscreen

wipers, ABS, etc.), any intervention

on the battery (removal, disconnec-

tion, etc.) must categorically be per-

formed by a specialist professional.

Risk of serious burns or electric

shocks.

You must respect the replacement

intervals (without exceeding them)

Label B

as stated in the maintenance docu-

Observe the indications on the battery:

ment.

- 1 naked flames and smoking are for-

The battery is a specific type:

bidden;

ensure that it is replaced by the

same type.

- 2 eye protection required;

Call an approved Dealer.

- 3 keep away from children;

- 4 explosive materials;

- 5 refer to the handbook;

- 6 corrosive materials.

4.14

CarManuals2.co

BODYWORK MAINTENANCE (1/3)

A well-maintained vehicle will last

You should

Respect local regulations about wash-

longer. It is therefore recommended to

ing vehicles (e.g. do not wash your ve-

Wash your car frequently, with the

maintain the exterior of the vehicle reg-

hicle on a public highway).

engine off, with cleaning products rec-

ularly.

ommended by the manufacturer (never

Observe the vehicle stopping distances

Your vehicle has been treated with very

use abrasive products). Rinse thor-

when driving on gravelled surfaces to

effective anti-corrosion products. It is

oughly beforehand with a jet:

prevent paint damage.

nevertheless subject to various outside

spots of tree resin and industrial pol-

Repair, or have repaired quickly, areas

influences.

lution;

where the paint has been damaged, to

mud in the wheel arches and under-

prevent corrosion spreading.

Corrosive agents in the

neath the body which forms damp

atmosphere:

Remember to visit the body shop pe-

patches;

riodically in order to maintain your an-

- atmospheric pollution (built-up and

bird droppings, which cause a

ti-corrosion warranty. Refer to the

industrial areas);

chemical reaction with the paint that

Maintenance Document.

rapidly discolours paintwork and

- saline atmospheres (near the sea,

may even cause the paint to peel

If it is necessary to clean mechani-

particularly in hot weather);

off;

cal components, hinges, etc., spray

- seasonal and damp weather condi-

Wash the vehicle immediately to

them with products approved by our

tions (e.g. road salt in winter, water

remove these marks since it is im-

Technical Department to protect them

from road cleaners, etc.).

possible to remove them by polish-

after they have been cleaned.

ing;

Minor impacts

salt, particularly in the wheel arches

and underneath the body after driv-

Abrasive action:

ing in areas where the roads have

Dust and sand in the air, mud, road grit

been gritted.

thrown up by other vehicles, etc.

Remove any plant matter (resin, leaves,

You should take a number of minor pre-

etc.) from the vehicle regularly.

cautions in order to safeguard your ve-

hicle against such risks.

We have selected special products

to care for your vehicle and you can

obtain these from the manufactur-

er’s accessory outlets.

4.15

CarManuals2.co

BODYWORK MAINTENANCE (2/3)

What you should not do

Wash the vehicle in bright sunlight or

freezing temperatures.

Degrease or clean using

high-pressure cleaning

Do not scrape off mud or dirt without

equipment or by spray-

pre-wetting.

ing on products not ap-

Allow dirt to accumulate on the exterior.

proved by our Technical

Department:

Allow rust to form following minor im-

mechanical components

(e.g.:

pacts.

engine compartment);

Do not use solvents not approved by

the wheels

(e.g. braking system

our Technical Department to remove

components such as brake calli-

stains as this could damage the paint-

pers);

work.

underbody;

Do not drive in snow or muddy condi-

tions without washing the vehicle, par-

parts with hinges (e.g.: inside the

ticularly under the wheel arches and

doors);

body.

painted plastic external fittings (e.g.:

bumpers).

Doing this could give rise to corrosion

or operational faults.

4.16

CarManuals2.co

BODYWORK MAINTENANCE (3/3)

Vehicles with a matte paint

Using a roller type car wash

Cleaning stickers, decorative

finish

Return the wiper stalk to the park po-

films, etc.

This type of paint requires certain pre-

sition. ➥ 1.109. Check the mounting of

You should do the following

cautions.

external accessories, additional lights

Use a soft cloth or cotton wool. Moisten

and rear view mirrors, and ensure that

it with soapy water, then always wipe

You should do the following

the wiper blades are secured with ad-

clean with a soft cloth or cotton wool.

hesive tape.

Wash the vehicle by hand using plenty

Finally, carefully dry off with a soft dry

of water, using a soft cloth or a gentle

Remove the radio aerial mast if your

cloth.

sponge.

vehicle is fitted with this equipment.

Do not do the following

Remember to remove the tape and refit

Do not do the following

the antenna after washing.

Use alcohol-based cleaning products.

Use wax-based products (polishing).

Use utensils (e.g.: scraper). Rub too

hard.

Rub too hard.

Cleaning the headlights,

Wash the vehicle in a roller-type car

sensors and cameras

wash.

Use a soft cloth or cotton wool. If this

Attach stickers to the paintwork (risk of

does not clean them properly, moisten

leaving marks).

the cloth with soapy water, then wipe

Wash the area using a

clean with a soft damp cloth or cotton

high-pressure clean-

wool.

ing device.

Finally, carefully dry off with a soft dry

Wash the vehicle

cloth.

using a high-pressure

cleaning device.

Do not use cleaning products con-

taining alcohol or utensils (e.g.: a

scraper).

4.17

CarManuals2.co

INTERIOR TRIM MAINTENANCE (1/2)

A well-maintained vehicle will last

Glass instrument panel

Textiles (seats, door trim, etc)

longer. It is therefore recommended to

(e.g. instrument panel, clock, exterior

Vacuum-clean the textiles regularly.

maintain the interior of the vehicle reg-

temperature display etc.)

ularly.

Use a soft cloth (or cotton wool).

Liquid stain

A stain should always be dealt with

If this does not clean them properly,

Use soapy water.

swiftly.

use a soft cloth (or cotton wool) slightly

Dab lightly (never rub) with a soft cloth,

moistened with soapy water and then

Whatever type of stain is on the trim,

rinse and remove the excess.

wipe clean with another soft damp cloth

use cold (or tepid) soapy water with

or cotton wool.

natural soap.

Solid or pasty stain

Finally, carefully dry off with a soft dry

Detergents (washing-up liquid, pow-

cloth.

Carefully remove the excess solid or

dered products, alcohol-based prod-

pasty material immediately using a

ucts) should not be used.

Do not use products containing alco-

spatula (working from the edges to the

hol and/or spray fluids on the area.

Use a soft cloth.

centre to avoid spreading the stain).

In the case of a liquid stain, clean as

Rinse and wipe up excess water.

Seat belts

indicated.

They must remain clean.

Special instructions for sweets or

Multimedia screen

Use products selected by our Technical

chewing gum

Maintenance of the screen may depend

Department

(approved outlets) or

on the type of multimedia equipment.

warm, soapy water and a sponge and

Fit an ice cube on the stain to solidify it,

Please refer to the multimedia instruc-

wipe with a dry cloth.

then proceed as for a solid stain.

tions for further information.

Detergents or dyes must not be used

under any circumstances.

For further recommendations for

maintaining the interior, and/or for

any unsatisfactory results, please

see an authorised dealer.

4.18

CarManuals2.co

INTERIOR TRIM MAINTENANCE (2/2)

Removal/replacing removable

You should not:

equipment originally fitted in

Position objects such as deodorants,

the vehicle

scents etc. near air vents as this could

damage your dashboard trim.

If you need to remove equipment in

order to clean the passenger com-

partment (for example, mats), always

ensure that they are correctly refitted

and are the right way around (the driv-

er’s mat should be fitted on the driver’s

Using high-pressure

side, etc.) and fit them with the compo-

cleaning equipment or

nents supplied with the equipment (for

sprays inside the pas-

example, the driver mat should always

senger compartment:

be fixed using the pre-fitted mounting

components).

without careful use, this equipment

With the vehicle stationary, always

could impair the correct functioning

ensure that nothing will impede driving

of the electrical or electronic compo-

(anything obstructing the pedals, heel

nents in the vehicle, or have other

wedged by the mat etc.).

detrimental effects.

4.19

CarManuals2.co

Section 5: Practical advice

Puncture

5.2

Emergency spare wheel

5.2

Tool kit

5.4

Tyre inflation kit

5.5

Wheel trims

5.11

Changing a wheel: hydraulic jack

5.13

Changing a wheel: jack

5.16

Tyres

5.18

Headlights (changing bulbs)

5.21

rear lights

5.23

side lights

5.25

interior lighting

5.26

Fuses

5.27

Battery: troubleshooting

5.32

Key, radio frequency remote control: battery

5.35

Hands-free access transmitter, receiver: battery

5.37

Replacing wiper blades

5.39

Towing

5.40

Fitting a radio

5.42

Accessories

5.43

Operating faults

5.44

5.1

CarManuals2.co

PUNCTURE, EMERGENCY SPARE WHEEL (1/2)

On equipped vehicles, the emergency

To remove the emergency spare

spare wheel is located underneath the

wheel

chassis.

- Insert the end of the unlocking key 3

extended (depending on the vehicle)

by the hexagonal extension piece 5

and the wheelbrace 6 in location 1

or 4 (the use of other tools could

damage the mechanism);

- lower the emergency spare wheel

fully;

In some cases (rear puncture, vehi-

- unclip the component 2 on the wheel

If the emergency spare

cle loaded with towing equipment),

rim;

wheel has been stored

it is necessary to raise the vehicle

for several years, have it

- thread the component 2 through the

(using the lifting point nearest the

checked by your dealer to

wheel rim (as shown in A) to release

wheel concerned) to access to the

ensure that it is safe to use.

the wheel.

emergency spare wheel. ➥ 5.16.

5.2

CarManuals2.co

PUNCTURE, EMERGENCY SPARE WHEEL (2/2)

To fit a wheel

- thread the cable and the compo-

nent 2 through the wheel rim;

Proceed in the reverse order.

- centre the component 2 in the middle

- place the wheel flat underneath

of the wheel and clip it to the wheel

the vehicle. The valve 7 must be

rim;

facing you. Risk of losing the wheel

if the correct direction for refitting the

- lift the retaining cable up as far as it

wheel is not observed;

will go and check the wheel is com-

pletely secure.

Note: do not place a punctured wheel

with aluminium wheel rims in the emer-

gency spare wheel winch. Ensure the

Place the punctured wheel

winch is refitted correctly.

flat on the ground. The

valve 7 must be facing

you.

Do not touch the exhaust

system.

Risk of losing the wheel.

Risk of burns.

5.3

CarManuals2.co

TOOL KIT

Location of the tool kit

Contents of the tool kit

- wheelbrace 5;

(depending on the vehicle)

- winch unlocking key 6;

Tool kit 1 is located under the driver’s

- hexagonal extension piece 7;

seat.

- hydraulic jack 2;

- extension pieces 8;

- towing hitch 3;

To remove the tools, move the seat

- jack 9.

- hubcap tool 4;

forward and fold down the seatback

➥ 1.20 .

Do not leave the tools unsecured inside the vehicle as they may come

loose under braking. After use, check that all the tools are correctly

Nothing should be placed

clipped into the tool kit, then position it correctly in its housing: risk of

on the floor area in front of

injury.

the driver as such objects

If bolts are supplied with the emergency spare wheel, it is imperative that they are

may slide under the pedal

used and that they are used for the emergency spare wheel only: refer to the label

during braking manoeuvres, thus

affixed to the emergency spare wheel.

obstructing its use.

The jack is designed for wheel changing purposes only. Under no circumstances

should it be used for carrying out repairs underneath the vehicle or to gain access

to the underside of the vehicle.

5.4

CarManuals2.co

TYRE INFLATION KIT (1/6)

Do not attempt to use the

The kit is only approved for

inflation kit if the tyre has

inflating the tyres of the ve-

been damaged as a result

hicle originally equipped

of driving with a puncture.

with the kit.

You should therefore carefully check

It must never be used to inflate

the condition of the tyre sidewalls

the tyres of another vehicle, or any

before any operation.

other inflatable object (rubber ring,

rubber boat, etc.).

Driving with underinflated, flat or

punctured tyres can be dangerous

Avoid spillage on skin when han-

and may make the tyre impossible

dling the repair product bottle. If

to repair.

droplets do leak out, rinse them off

with plenty of water.

This repair is temporary.

Keep the repair kit away from chil-

A tyre which has been punctured

dren.

should always be inspected (and

repaired, where possible) by a spe-

Do not dispose of the empty bottle

The kit repairs tyres when

cialist as soon as possible.

in the countryside. Return it to your

tread A has been dam-

approved dealer or to a recycling or-

aged by objects smaller

When taking a tyre which has been

ganisation.

than 4 mm. It cannot repair

repaired using this kit to be replaced,

all types of puncture, such as cuts

you must inform the specialist.

The bottle has a limited service

larger than 4 mm, or cuts in tyre

life which is indicated on its label.

When driving, vibration may be felt

sidewall B.

Check the expiry date.

due to the presence of the repair

Ensure also that the wheel rim is in

product injected into the tyre.

Contact an approved dealer to re-

good condition.

place the inflation tube and repair

product bottle.

Do not pull out the foreign body

causing the puncture if it is still in

the tyre.

5.5

CarManuals2.co

TYRE INFLATION KIT (2/6)

Before using this kit, park

the vehicle at a sufficient

distance from traffic, switch

on the hazard warning

lights, apply the handbrake, ask all

passengers to leave the vehicle and

keep them away from traffic.

If the vehicle is parked on

the hard shoulder, you must

Inflation kit C

Move the driver’s seat forward and fold

warn other road users of

down the seatback to access the infla-

your vehicle’s presence

Depending on the vehicle, in the event

tion kit.

with a warning triangle or with other

of a puncture, use inflation kit 1 located

Open it.

devices as per the legislation apply-

underneath the driver’s seat.

ing to the country you are in.

Vehicle fitted with a tyre pressure

Screw compressor adapter 3 to con-

loss warning system

tainer 2 and clip onto compressor D.

In the event of under-inflation (punc-

The bottle must remain in an upright

position.

tures, under-inflation etc.), the 

Unscrew the valve cap on the tyre con-

warning light appears on the instrument

cerned.

panel.➥ 2.36.

Screw inflation adapter 4 onto the

valve.

Do not pull out the foreign

body causing the puncture

if it is still in the tyre.

5.6

CarManuals2.co

TYRE INFLATION KIT (3/6)

To connect the compressor, open the

With the engine running, press switch 7

If the correct pressure cannot be

bonnet and connect the black clamp 10

to start inflating.

achieved, repair is impossible. Do

to earth 5 ➥ 5.32.

not drive the vehicle. Consult an ap-

After a maximum of 15 minutes, stop in-

proved dealer.

Then connect red clamp 11 to termi-

flating and read the pressure on pres-

nal 6.

sure gauge 9.

If the pressure is too high, press

button 8 to lower the pressure.

A pressure of at least 4.7 bar must be

reached.

Note: while the bottle is emptying (ap-

proximately 30 seconds), the pressure

gauge 9 will indicate briefly a pressure

of up to 6 bars, then the pressure drops.

Before starting the engine,

check that the handbrake is

applied and the gear lever

is in neutral or in position N

for sequential gearboxes.

5.7

CarManuals2.co

TYRE INFLATION KIT (4/6)

Affix the driving recommendation label

Precautions when using the

to the dashboard where it can easily be

kit

seen by the driver;

The kit should not be operated for more

Store the kit underneath the driver’s

than 15 consecutive minutes.

seat.

The container must be replaced after

Start the vehicle immediately in order

the first use even if liquid remains

to the distribute the product in the tyre

inside.

and, after 6 miles (10 km) or 10 min-

utes driving, stop to check the pres-

When driving, vibration may be felt due

sure. To do this, fit adapter

3 onto

to the presence of the product injected

the tyre’s valve. If the pressure is

into the tyre.

less than recommended, readjust it.

➥ 4.11Otherwise, contact an approved

dealer: the tyre cannot be repaired.

Once the tyre is correctly inflated,

remove the kit: slowly unscrew the in-

flation adapter 3 to prevent any prod-

uct spatter and screw the tyre inflation

Following repair with the kit,

hose 4 to the bottle opening 2 to pre-

do not travel further than

vent the product from escaping.

120 miles (200 km). In addi-

tion, reduce your speed and

under no circumstances exceed

Please be aware that a

48 mph

(80 km/h). The sticker,

poorly tightened or miss-

which you must affix in a prominent

ing valve cap can make the

position on the dashboard, reminds

tyres less airtight and lead

you of this.

to pressure loss.

Nothing should be placed

around the driver’s feet

Always use valve caps identical to

Depending on the country or local

as such objects may slide

those fitted originally and tighten

legislation, a tyre repaired with the

under the pedals during

them fully.

inflation kit may need to be replaced.

sudden braking manoeuvres and

obstruct their use.

5.8

CarManuals2.co

TYRE INFLATION KIT (5/6)

With the engine running and the

If a minimum pressure of 1.8 bar is

parking brake applied,

not reached after 15 minutes, repair

is not possible; do not drive the ve-

Disconnect any accessories previ-

hicle but contact an approved dealer.

ously connected to the vehicle’s ac-

cessories sockets;

refer to the information on the in-

flation kit compressor that is lo-

cated under the driver’s seat and

follow the instructions;

inflate the tyre to the recommended

pressure ➥ 4.11;

Before using this kit, park

the vehicle at a sufficient

after a maximum of 15 minutes, stop

distance from traffic, switch

inflating and read the pressure (on

on the hazard warning

the pressure gauge 12);

lights, apply the handbrake, ask all

Inflation kit E

Note: while the bottle is empty-

passengers to leave the vehicle and

ing

(approximately

30 seconds),

Depending on the vehicle, in the event

keep them away from traffic.

the pressure gauge 12 will indicate

of a puncture, use the inflation kit lo-

briefly a pressure of 6 bar, then the

cated underneath the driver’s seat.

pressure drops.

Vehicle fitted with a tyre pressure

Adjust the pressure: to increase

loss warning system

it, continue inflation with the kit. To

In the event of under-inflation (punc-

reduce it, press the button 13.

If the vehicle is parked on

the hard shoulder, you must

tures, under-inflation etc.), the 

warn other road users of

warning light appears on the instrument

your vehicle’s presence

panel.➥ 2.36.

with a warning triangle or with other

devices as per the legislation apply-

ing to the country you are in.

5.9

CarManuals2.co

TYRE INFLATION KIT (6/6)

Affix the driving recommendation

label (located under the container) to

the dashboard where the driver can

see it.

Put the kit away.

–

At the end of this initial inflation op-

Please be aware that a

eration, air will still escape from the

poorly tightened or miss-

tyre. You must drive a short distance

ing valve cap can make the

in order to seal the hole.

tyres less airtight and may

Start immediately and drive at a

lead to pressure loss.

speed between 12 to 37 mph (20

Always use valve caps identical to

to 60 km/h) in order to distribute the

those fitted originally and tighten

product evenly in the tyre; after driv-

them fully.

ing a distance of 2 miles (3 km), stop

and check the pressure.

If the pressure is higher than 1.3 bar

Once

the

tyre is

correctly inflated,

but lower than the recommended

remove the kit: unscrew the inflation

pressure (refer to the label affixed to

adapter slowly from the container 14 to

the edge of the driver’s door), adjust

prevent any product spatter and store

it. Otherwise, contact an approved

Following repair with the kit,

the container in plastic packaging to

dealer: the tyre cannot be repaired.

do not travel further than

prevent product leaks.

120 miles (200 km). In addi-

Precautions when using the kit

tion, reduce your speed and

The kit should not be operated for more

under no circumstances exceed

than 15 consecutive minutes.

48 mph (80 km/h). The sticker,

The container must be replaced after

which you must affix in a prominent

the first use even if liquid remains

Nothing should be placed

position on the dashboard, reminds

inside.

around the driver’s feet

you of this.

as such objects may slide

Depending on the country or local

under the pedals during

legislation, a tyre repaired with the

sudden braking manoeuvres and

inflation kit may need to be replaced.

obstruct their use.

5.10

CarManuals2.co

WHEEL TRIMS (1/2)

Wheel trim 2

Central wheel trim 4

(concealed wheel bolts)

Remove it using hubcap tool 1 (found

Remove it using hubcap tool 1, insert-

in the tool kit), by pushing the hook into

ing the tool into the recesses 3 pro-

the opening located near the valve (to

vided.

reach the metal retaining wire located

To refit it, align it with the wheel bolts,

behind the wheel trim).

clip it in and check it is securely locked.

To refit it, align it with the valve. Push the

retaining hooks, starting with side A on

the valve side, then B and C and finish

with the side opposite the valve D.

5.11

CarManuals2.co

CHANGING A WHEEL: hydraulic jack (1/3)

Undo the wheel bolts by fitting the

wheel spanner 3 extended using the

hexagonal extension piece 2 (supplied

in the tool kit) and pressing down.

When removing dual wheels, unscrew

Anti-theft bolt

inflating extension piece 1.

If you use anti-theft bolts, fit these

Switch on the hazard warn-

Do not forget to reattach it when re-

nearest the valve (otherwise it may

ing lights.

fitting.

not be possible to fit the wheel trim).

Keep the vehicle away from

traffic and on a level surface

where it will not slip.

If the vehicle is parked on

Apply the parking brake and engage

the hard shoulder, you must

a gear (first or reverse, or D, M or

warn other road users of

R position on a sequential gearbox).

your vehicle’s presence

Ask all the passengers to leave the

with a warning triangle or with other

vehicle and keep them away from

devices as per the legislation apply-

traffic.

ing to the country you are in.

5.13

CarManuals2.co

CHANGING A WHEEL: hydraulic jack (2/3)

Fit the emergency spare wheel on the

central hub and, depending on the ve-

hicle, turn it to align the mounting holes

in the wheel and the hub.

If bolts are supplied with the emergency

spare wheel, only use these bolts for

the emergency spare wheel.

Take the jack 3 out of the tool kit.

Start pumping using the three exten-

Familiarise yourself with the jack ar-

sion pieces 4 placed end to end, avail-

rangement prior to using it.

able in the tool kit ➥ 5.4.

Free the wheel from the ground.

Using the jack

Note: the use of the three extension

Position the head of the jack against

pieces 4 prevents you having to go

the contact point 2 close to the wheel

under the vehicle to operate the jack 3

concerned.

when raising the vehicle.

Place the jack 3 horizontally. The jack

Remove the screws, then remove the

head must line up with the point 2 pro-

wheel (take off the central wheel trim if

vided.

necessary).

To prevent any risk of injury

or damage to the vehi-

cle, raise the jack until the

wheel you are replacing is

a maximum of 3 centimetres off the

ground.

5.14

CarManuals2.co

CHANGING A WHEEL: hydraulic jack (3/3)

Have the tightening and the pressure

of the spare wheel checked as soon as

possible.

Tighten the nuts and lower the jack.

Wheel with 5 holes: start with screw G,

then J, H, K and finish with I.

With the wheel on the ground, tighten

the bolts completely, following the order

of tightening below:

Wheel with 6 holes: start with screw A,

then D, B, E, C and finish with F.

5.15

CarManuals2.co

CHANGING A WHEEL: jack (1/2)

If the vehicle is parked on

the hard shoulder, you must

warn other road users of

your vehicle’s presence

with a warning triangle or with other

devices as per the legislation apply-

ing to the country you are in.

Vehicle equipped with a jack with a

If necessary, remove the wheel trim.

heightener

Use the wheelbrace 2 to slacken off the

Switch on the hazard warn-

When changing a front wheel, use the

wheel bolts. Position it so as to be able

ing lights.

heightener 1 (figure A).

to push from above.

Keep the vehicle away from

When changing a rear wheel, remove

traffic and on a level surface

the heightener 1 (figure B).

where it will not slip.

Apply the parking brake and engage

a gear (first or reverse, or D, M or R

position in the case of a sequential

gearbox).

Ask all the passengers to leave the

To prevent any risk of injury

vehicle and keep them away from

or damage to the vehi-

traffic.

cle, raise the jack until the

wheel you are replacing is

a maximum of 3 centimetres off the

ground.

5.16

CarManuals2.co

CHANGING A WHEEL: jack (2/2)

Position jack 4 horizontally. Jack head 3

If bolts are supplied with the emergency

With the wheel on the ground, tigh-

must be positioned level with the rein-

spare wheel, only use these bolts for

ten the bolts firmly, starting on side C,

forcement panel closest to the wheel in

the emergency spare wheel. Tighten

then E, G, D and ending with F. Check

question or the contact points 5;

the bolts, checking that the wheel is

the tightness and the tyre pressure on

start cranking the jack up by hand to

correctly positioned on its hub and un-

the emergency spare wheel as soon as

align the base plate (which should be

screw the jack.

possible.

pushed slightly under the vehicle).

Note: do not lubricate the wheel bolts.

Turn the wheelbrace a few times using

the wheel spanner 2 until the wheel is

lifted off the ground. Remove the bolts

and take off the wheel;

If you have a puncture, re-

fit the emergency spare wheel on the

place the wheel as soon as

central hub and turn it to locate the

possible.

mounting holes in the wheel and the

Anti-theft bolt

A tyre which has been punc-

hub.

tured should always be inspected

If you use anti-theft bolts, fit these

(and repaired, where possible) by a

nearest the valve (otherwise it may

specialist.

not be possible to fit the wheel trim).

5.17

CarManuals2.co

TYRES (1/3)

The tyres are the only contact between

When the tyre tread has been worn to

the vehicle and the road, so it is essen-

the level of the wear indicators, they

tial to keep them in good condition.

become visible 2: it is then necessary

to replace your tyres because the tread

You must make sure that your tyres

rubber is no more than 1.6 mm deep,

conform to local road traffic regulations.

resulting in poor roadholding on wet

roads.

An overloaded vehicle, long journeys

by motorway, particularly in very hot

weather, or continual driving on poorly

surfaced minor roads will lead to more

rapid tyre wear and affect safety.

Maintaining the tyres

The tyres must be in good condition

and the tread form must have sufficient

depth; tyres approved by our Technical

Department have tread wear indica-

tors 1 which are indicators moulded

into the tread at several points.

Incidents which occur when

driving, such as striking the

kerb, may damage the tyres

and wheel rims, and could

also lead to misalignment of the

front or rear axle geometry. In this

case, have the condition of these

checked by an approved dealer.

5.18

CarManuals2.co

TYRES (2/3)

Tyre pressures

Pressures should be checked when the

Vehicle fitted with a tyre pressure

tyres are cold; ignore higher pressures

loss warning system

Adhere to the tyre pressures (including

which may be reached in hot weather

the emergency spare wheel). The tyre

In the event of under-inflation (punc-

or following a fast journey.

pressures should be checked at least

tures, under-inflation, etc.), the 

once a month and additionally before

If tyre pressures cannot be checked

warning light appears on the instrument

any long journey (refer to the label af-

when the tyres are cold, the normal

panel ➥ 2.36

fixed to the edge of the driver’s door).

pressures must be increased by 0.2 to

0.3 bar (or 3 PSI).

Never deflate a hot tyre.

Changing wheels around

This practice is not recommended.

Dual wheel versions

To inflate the outer wheel, it is recom-

Emergency spare wheel

mended that the inflation tube is passed

Incorrect tyre pressures

between the two wheels.

➥ 5.2 ➥ 5.16

lead to abnormal tyre wear

and unusually hot running.

These are factors which

may seriously affect safety and lead

to:

- poor road holding;

- risk of bursting or tread separa-

tion.

Please be aware that a

The pressure depends on the load

poorly tightened or miss-

and the speed of use. Adjust the

ing valve cap can make the

pressure according to the condi-

tyres less airtight and lead

tions of use (refer to the label affixed

to pressure loss.

to the edge of the driver’s door).

Always use valve caps identical to

those fitted originally and tighten

them fully.

5.19

CarManuals2.co

TYRES (3/3)

Fitting new tyres

Use in winter

Note: be aware that these tyres may

sometimes have:

Chains

- a direction of travel ;

Chains must not be fitted to tyres

- a maximum speed index which may

For your safety, please re-

which are larger than those originally

be lower than the maximum speed of

spect the speed limit.

fitted to the vehicle.

your vehicle.

When they need to be re-

placed, only tyres of the

Front wheel drive versions

Studded tyres

same make, size, type and profile

For safety reasons, fitting snow

This type of equipment may only be

should be used on a single axle.

chains to the rear axle is strictly for-

used for a limited period and as laid

bidden.

They must either have a load ca-

down by local legislation.

pacity and speed rating at least

Rear wheel drive versions

It is necessary to observe the speed

equal to those of the original

For safety reasons, only fit chains

specified by current legislation.

tyres, or be recommended by an

on the rear axle.

These tyres must, as a minimum, be

authorised dealer.

Note: for rear wheel drive, dual wheel

fitted to the two wheels on the front

Failure to heed these instructions

versions, fit chains on the outer rear

axle for front wheel drive versions and

could endanger your safety and

wheels.

all the rear wheels for rear wheel drive

affect your vehicle’s roadworthi-

versions.

ness.

Snow or winter tyres

We would recommend that these be

Risk of loss of control of the ve-

fitted to all four wheels to ensure that

hicle.

your vehicle retains maximum grip.

In all cases, we would recommend

that you contact an approved Dealer

Chains may only be fitted to tyres of the same size as those originally

who will be able to advise you on

fitted to your vehicle.

the choice of equipment which is

Only certain chains can be fitted to tyres. Consult an approved Dealer.

most suitable for your vehicle.

5.20

CarManuals2.co

HEADLIGHTS: changing bulbs (1/2)

Direction indicators

Turn the bulb holder 3 a quarter turn to

the left.

To refit, turn the bulb holder a quarter

turn to the right.

Bulb type: PY21W.

Dipped beam headlights

Main beam headlights

To comply with current legislation,

Remove the cover B and unclip the

Remove the cover A and unclip the

or as a precaution, you can obtain

bulb holder 2.

bulb holder 1.

an emergency kit from an approved

Bulb type: H7LL.

dealer containing a set of spare

Bulb type: H1.

Do not touch the bulb glass. Hold it

bulbs and fuses.

by its base.

Note: once the bulb has been replaced,

ensure the cover is refitted correctly.

Note: once the bulb has been replaced,

Please note when work-

ensure the cover is refitted correctly.

ing close to the engine that

it may be hot. In addition,

the engine cooling fan may

Before carrying out any

start at any moment. The 

action in the engine com-

warning light in the engine compart-

partment, you must switch

ment reminds you of this.

off the ignition. ➥ 2.3.

The bulbs are under pres-

sure and can break when

Risk of injury.

replaced.

Risk of injury.

5.21

CarManuals2.co

HEADLIGHTS: changing bulbs (2/2)

Front fog lights5

- Unscrew the wheel arch liner 6 using

a screwdriver type tool;

- access the bulb holder located

behind the bumper, via the wheel

arch liner;

- unscrew the bulb holder.

Type of bulb: H16LL

LED side lights/daytime

running lights 4

Consult an approved dealer.

Any operation on (or modi-

fication to) the electrical

system must be performed

by an approved dealer

since an incorrect connection might

damage the electrical equipment

(harness, components and in par-

ticular the alternator). In addition,

To comply with current legislation,

your Dealer has all the parts re-

The bulbs are under pres-

or as a precaution, you can obtain

quired for fitting these units.

sure and can break when

an emergency kit from an approved

replaced.

dealer containing a set of spare

bulbs and fuses.

Risk of injury.

5.22

CarManuals2.co

REAR LIGHTS AND SIDE LIGHTS: changing bulbs (1/3)

Rear lights

Unscrew the bolt 2 using a flat-blade

4 Side lights and brake lights

screwdriver or similar to remove the

Depending on the vehicle, remove

Pear-shaped, bayonet type P21/5W

bulb holder 3.

the protective grilles. Unscrew the two

bulb with two filaments.

nuts 1 and pull rear light unit A.

5 Indicator

Orange pear-shaped, bayonet type

PY21W bulb.

6 Reversing light

Pear-shaped, bayonet type bulb

P21W.

7 Fog light

Pear-shaped, bayonet type bulb

P21W.

The bulbs are under pres-

sure and can break when

replaced.

Risk of injury.

5.23

CarManuals2.co

REAR LIGHTS AND SIDE LIGHTS: changing bulbs (3/3)

Side indicator lights

Clearance lights

Move mirror 11 to access the bolt.

Push light 13 (movement B) and press

at C to release the light.

Undo the bolt using a Torx screwdriver.

Turn the bulb holder a quarter of a turn

Take out the indicator light and replace

and replace the bulb.

bulb 12.

Bulb type: W5W.

Bulb type, depending on vehicle:

WY5W or W16W.

To comply with current legislation,

or as a precaution, you can obtain

an emergency kit from an approved

dealer containing a set of spare

bulbs and fuses.

The bulbs are under pres-

sure and can break when

replaced.

Risk of injury.

5.25

CarManuals2.co

INTERIOR LIGHTING: changing bulbs

Halogen bulb courtesy light

Special features for vehicles fitted

Halogen rear light

with a reading lamp

Unclip the ceiling light diffuser 1 using a

Unclip the ceiling light diffuser using a

flat blade screwdriver or similar.

Bulb type 2: W6W or W5W

flat blade screwdriver or similar.

Pull the bulb to remove it from its hous-

Type of reading lamp 3: W5W

ing.

Bulb type: W6W or W5W

Type of bulb 4: W6W

Replace the bulb and refit the lens.

LED courtesy light

LED rear light

Consult an approved dealer.

The bulbs are under pres-

sure and may break when

replaced. Risk of injury.

5.26

CarManuals2.co

FUSES (1/5)

Your vehicle is equipped with two fuse

boxes: in the passenger compartment

and in the engine compartment.

If any electrical component does not

Fuses in the passenger

work, check the condition of the fuses.

compartment

Remove the fuse using tweezers 1, lo-

cated at the back of flap A.

Unclip flap A using notch B to help you.

To remove the fuse from the tweezers,

To identify the fuses, refer to the fuse

slide the fuse to the side.

allocation label (see the next page for

It is not advisable to use the free fuse

Check the fuse in question

details), located on the rear of flap A.

locations.

and replace it, if neces-

sary, by a fuse of the same

rating.

If a fuse is fitted where the rating is

too high, it may cause the electrical

circuit to overheat (risk of fire) in the

To comply with legislation, or as a

event of an item of equipment using

precaution, you can obtain an emer-

an excessive amount of current.

gency kit containing a set of spare

bulbs and fuses from an approved

dealer.

5.27

CarManuals2.co

FUSES (2/5)

Allocation of fuses (DEPENDING ON THE EQUIPMENT LEVEL)

Numbers

Allocation

Numbers

Allocation

Numbers

Allocation

Radio, heated seats, multi-

Brake lights, interior lighting

ABS/ESC

function display, sockets for

audio and alarm connec-

Lighting dimmer, interior

tions



Hands-free access

lighting

Accessories sockets

Brake lights

Tachograph

Electric windows, heating

and air conditioning system

Heating and air conditioning

Cigarette lighter

‚

and passenger compart-

system fan

ment computer

Instrument panel, diagnos-

Left-hand heated rear



Additional adaptations

tic socket

screen

Electric windows and pas-

Right-hand heated rear

Central door control

senger compartment com-

screen

puter

Windscreen washer

Heated door mirror

Passenger compartment

computer, direction indica-

tor lights and rear fog lights

Engine immobiliser

Diesel fuel heater

Right-hand side light

Heated seats

PTO

Engine power take-off

Passenger compartment

Left-hand side light

Horn

ECU

5.28

CarManuals2.co

FUSES (3/5)

Fuses in the engine

Unscrew the four screws 4.

Turn unit 5 over to access the fuses in

the engine compartment.

compartment

To identify the fuses, refer to the fuse

Removing fuse box C

allocation label (see the next page for

Remove screw 2 and remove coolant

details), located on unit 5.

reservoir 3.

Please note when work-

ing close to the engine that

Check that no water or dust enters

it may be hot. The engine

unit 5 when it is being removed/re-

cooling fan may also start

fitted.

No operations should be

at any moment. The 

warning

carried out on the cooling

light in the engine compartment re-

circuit when the engine is

minds you of this.

hot.

Deactivate the Stop and

Risk of injury.

Start function for any opera-

Risk of burns.

tion performed in the engine

compartment.

5.29

CarManuals2.co

BATTERY: troubleshooting (1/3)

To avoid all risk of sparks:

Connecting a battery charger

Before carrying out any

Ensure that any power consumers

The battery charger must be com-

action in the engine com-

(courtesy lights, etc.) are switched

patible with a battery with nominal

partment, you must switch

off before disconnecting or recon-

voltage of 12 volts.

off the ignition. ➥ 2.3.

necting a battery;

Do not disconnect the battery when the

Risk of injury.

when charging, stop the charger

engine is running. Follow the instruc-

before connecting or disconnecting

tions given by the manufacturer of

the battery;

the battery charger you are using.

–

do not place metal objects on the

If many accessories are fitted to the

Handle the battery with care

battery as this could create a short

vehicle, have them connected to the +

as it contains sulphuric acid,

circuit between the terminals;

After ignition feed.

which must not come into

contact with eyes or skin. If

always wait at least one minute after

it does, wash the affected area with

the engine has been switched off

plenty of cold water. If necessary,

before disconnecting a battery;

consult a doctor.

make sure that you reconnect the

Ensure that naked flames, red hot

battery terminals after refitting.

objects and sparks do not come into

contact with the battery as there is a

risk of explosion.

Special procedures may be

Please note when working close to

required to charge some

the engine that it may be hot. In ad-

batteries. Contact your ap-

dition, the engine cooling fan may

proved dealer.

Avoid all risk of sparks which may

start at any moment. The 

cause an immediate explosion, and

warning light in the engine compart-

charge the battery in a well venti-

ment reminds you of this.

lated area.

Risk of injury.

Risk of serious injury.

5.32

CarManuals2.co

BATTERY: troubleshooting (2/3)

Starting the vehicle using the

battery from another vehicle

If you have to use the battery from an-

other vehicle to start, obtain suitable

jump leads (with a large cross section)

from an approved dealer or, if you al-

ready have jump leads, ensure that

they are in perfect condition.

The two batteries must have an iden-

tical nominal voltage: 12 volts. The

battery supplying the current should

have a capacity (amp-hours, Ah) which

is at least the same as that of the dis-

charged battery.

Ensure that there is no risk of contact

Attach the positive cable (+) A to termi-

between the two vehicles (risk of short

nal 3, then to terminal (+) 2 of the bat-

circuiting when the positive terminals

tery supplying the current.

are connected). Switch off your vehicle

ignition.

Attach the negative cable (-) B to ter-

minal (-) 1 of the battery supplying the

current, then to earth (-) 4.

5.33

CarManuals2.co

BATTERY: troubleshooting (3/3)

Start the engine of the vehicle supply-

ing the current and run it at an interme-

diate engine speed.

If your vehicle’s engine does not start

immediately, switch off the ignition and

wait a few seconds before repeating

the operation.

With the engine running, disconnect

Check that there is no con-

the A and B cables in reverse order

tact between leads A and B

(4 - 1 - 2 - 3).

and that the positive lead A

is not touching any metal

parts on the vehicle supplying the

current.

Risk of injury and/or damage to

the vehicle.

5.34

CarManuals2.co

RADIO FREQUENCY REMOTE CONTROL: battery (1/2)

Replacing the battery

Special feature of key A

Open the case at slot 1 using a flat-

Undo screw 3 to remove the remote

blade screwdriver or similar and re-

control cover.

place the battery 2, observing the type

and polarity shown on the back of the

cover.

Note: It is not advisable to touch the

electrical circuit in the key cover when

replacing the battery.

When they need to be re-

placed, be sure to use

the same or equivalent

The batteries are available from ap-

type of battery (consult an

proved Dealers, and their service

Approved Dealer).

life approximately two years. Check

When refitting, ensure that the cover

that there is no dye on the battery:

is correctly clipped on and the screw

risk of an incorrect electrical con-

tightened.

tact.

5.35

CarManuals2.co

RADIO FREQUENCY REMOTE CONTROL: battery (2/2)

Operating faults

If the battery is too weak to ensure cor-

rect operation, you will still be able to

start and lock/unlock the vehicle

➥ 1.10.

Do not throw away your used bat-

Precautions relating to

teries; give them to an organisation

batteries:

responsible for collecting and recy-

- keep (new or used) bat-

cling batteries.

teries out of reach of chil-

dren;

- do not swallow batteries;

When replacing:

Risk of chemical burns which

- make sure that the batter-

may lead to death.

ies are correctly inserted.

- if ingested or inserted into any

part of the body, consult a doctor

Risk of explosion.

as soon as possible.

- if the flap does not close cor-

rectly, do not use and keep out of

reach of children.

5.36

CarManuals2.co

Renault Master (2023 year). Manual in english - page 6
