SEQUENTIAL GEARBOX (1/5)

Operation

Switch on the ignition.

The display on the instrument panel

switches on.

If neutral (N) is displayed and is ac-

companied (depending on the vehicle),

by the 4 warning light; press the brake

pedal and start the engine but do not

accelerate.

If a gear other than neutral is engaged,

N flashes on the display accompanied

by the 4 warning light; press the brake

pedal and place the lever in position N.

Start the engine.

Note: do not attempt to start the engine

Selector lever 1

Display

by pushing the vehicle if the battery is

- This allows you to shift directly from

2 Gear display

flat (the display remains off when the ig-

first gear to reverse gear, to select

The gear engaged in manual mode

nition is switched on).

reverse gear and neutral and to

(M1, M2, M6), neutral gear (N), or

change gear in manual mode.

the reverse gear (R) is shown on

the instrument panel display. In au-

- It also allows you to switch between

tomatic mode, (D) is displayed fol-

manual and automatic modes at

lowed by the gear selected (D1, D2,

any time, with the engine switched

D6).

on and reverse gear engaged, by

moving the lever to the left.

3 Load mode

Note: the selector lever automatically

4 Brake pedal depressed warning light

returns to the centre position after each

use.

2.69

CarManuals2.co

SEQUENTIAL GEARBOX (2/5)

Starting

Reverse gear (vehicle stationary)

Moving forwards (starting in neutral)

- Brake pedal depressed. Push the

selection lever towards the right

The display indicates gears N and D.

and to the rear as shown on the

Brake pedal depressed. Push the

base of the lever, and then release

selection lever forward and release

it. Reverse gear is engaged and the

it.

letter R appears on the display.

–

Release the brake pedal and accel-

- Release the brake pedal:

erate gently to move forwards.

- the engine’s idle speed is suffi-

cient for parking manoeuvres;

- accelerate gently to reverse.

You may shift from reverse gear to a

forwards gear by pushing the lever for-

wards once the vehicle is stationary.

Note: when the vehicle is stationary,

Gear shift pattern

you must depress the brake pedal to

engage or disengage a gear. Otherwise,

(see the marking on the lever base)

warning light 4 will come on.

: to move up through the gears

–

: to move down through the gears

: neutral

: Reverse

●

: only stable position of the lever

D/M : to switch from automatic mode

to manual mode and vice versa

Exactly like a vehicle equipped with a manual gearbox, a vehicle equipped

with a sequential gearbox is unable to prevent the vehicle from rolling on

a slope if the handbrake is not applied or the brake pedal constantly de-

pressed.

2.70

CarManuals2.co

SEQUENTIAL GEARBOX (3/5)

Operation in semiautomatic

The system will not tolerate a series

The vehicle will move off again:

of up or down changes that cause the

mode (manual)

- either slowly, if you release the brake

engine to underrev or overrev.

without accelerating (e.g. when in a

This mode can be activated at any time

By pushing the lever forwards twice

traffic jam);

when driving by pushing the lever to the

you can move up two gears at a time

left. The mode is switched without shift-

- or quickly, if you release the brake

(except if underrevving). By pushing

ing up a gear.

and accelerate.

the lever backwards twice you can

You can initiate gear changes using the

move down two gears at a time (unless

Note: neutral may only be selected

selector lever.

this causes overrevving).

when the vehicle is being driven or is

stationary when the brake pedal is

To shift up a gear, push the selector

When decelerating with the foot off

depressed (if you forget, warning

lever forwards; the accelerator pedal

the pedal, the gears will automatically

light 4 will come on).

does not have to be lifted.

drop to the low engine speed limit to

avoid stalling. First gear automatically

Push the gear selector lever to the right

To shift down a gear, push the selector

shifts below a certain speed limit. You

to engage neutral.

lever backwards; the accelerator pedal

does not have to be lifted.

can stop the vehicle at red lights or

If the engine speed is too high or too

junctions etc. by depressing the brake

low, the system will choose the opti-

pedal; there is no need to change to

mum gear.

neutral (N).

Semiautomatic mode can be deacti-

vated and reactivated at any time when

the engine is running by pushing the

lever to the left.

2.71

CarManuals2.co

SEQUENTIAL GEARBOX (4/5)

Operation in automatic mode

Note: automatic mode takes account

- to obtain maximum vehicle per-

of:

formance regardless of the mode

Automatic mode is selected by default

selected (automatic or manual),

every time the ignition is switched on.

- the position and speed of depression

quickly depress the accelerator

of the accelerator pedal to assess

The letter D appears on the display.

pedal beyond the kickdown point.

driving style and select the optimum

The vehicle is controlled using the ac-

gear;

The speed with which you depress the

celerator and the brake. Gears will

pedal will allow you to downshift ac-

change automatically at the correct

- action on the brake pedal, to com-

cording to the vehicle’s capabilities.

moment and at a suitable engine speed

mence engine braking in preparation

because the automatic mode takes the

for a downshift.

road surface and the chosen driving

You can stop the vehicle at red lights,

Parking the vehicle

style into consideration.

with the gear engaged, by depressing

It is possible to park in gear (for exam-

Gears may be shifted manually in this

the brake pedal; there is no need to

ple, on a slope):

mode. Pushing the lever forwards

change to neutral (N).

- with the ignition on, select a gear

or backwards shifts a gear upwards

The vehicle will move off again:

with your foot on the brake;

(except if there is a risk of underrev-

ving) or downwards (except if there is a

- either slowly, if you release the brake

- check that a gear other than N is dis-

risk of overrevving).

without accelerating (e.g. when in a

played on the instrument panel, then

traffic jam);

remove the ignition key;

- or quickly, if you release the brake

- apply the handbrake.

and accelerate.

To disengage the gear, switch on the

ignition without starting the engine and

Accelerating and overtaking

shift the selector lever to neutral with

the brake pedal depressed. Check

- Slowly depress the accelerator pedal

that N is displayed on the instrument

to accelerate gradually;

panel.

The oil level in the automatic gear-

box system reservoir varies depend-

ing on use. Adding oil is strictly

forbidden (except by qualified ap-

proved network personnel).

2.72

CarManuals2.co

SEQUENTIAL GEARBOX (5/5)

Bleep

In very cold weather, to ensure opti-

mal passage through the gears, wait a

- If you hold the vehicle on a slope

few seconds before moving the selec-

for too long without applying the

tor lever out of position N and into posi-

brakes or handbrake, you will strain

tion Dor R.

the system (risk of overheating the

clutch).

Operating faults

In this case, an intermittent beep-

ing sound will remind you that you

iIf this warning light comes on

should put your foot on the brake

when the vehicle is being driven,

pedal or apply the handbrake.

it indicates a fault in the system. In most

cases, you may still drive the vehicle,

- Never leave the vehicle with the

although it will not function perfectly.

engine running when in gear. For

Contact an approved dealer as soon as

safety reasons you will hear an in-

possible.

termittent beeping sound when you

open the door if you have not shifted

The vehicle should always be towed

Towing a vehicle with a sequential

into neutral or you have not switched

gearbox

with the ignition switched off.

off the ignition or depressed the

brake pedal.

If the gearbox is stuck in a gear:

- switch on the ignition;

Load position

- Select neutral with the brake pedal

Special circumstances

When the vehicle is driven loaded,

depressed;

press the 5 switch on the dashboard.

On a slippery surface or surface with

- check that the gearbox is in neutral

little grip, change to manual mode

(by pushing the vehicle for example).

The indicator light § on the instru-

(D/M) and select second gear before

If you cannot find neutral you must tow

ment panel will light up.

accelerating to avoid wheelspin.

the vehicle with the front wheels raised.

Load mode is deselected every time

the engine is switched off. It will be nec-

essary to select it again.

Load mode may be used to equal effect

in both automatic and manual modes.

2.73

CarManuals2.co

EMERGENCY CALL (1/3)

If the vehicle is equipped, the emer-

gency call system enables the emer-

gency services to be called (without

charge) automatically or manually in

the event of an accident or illness, in

order to reduce the time they take to

arrive on the scene.

If you use the emergency call function

to report an accident which you have

witnessed, this implies stopping where

traffic conditions allow in order for the

emergency services to locate your ve-

hicle and therefore the location of the

reported accident.

In all cases, comply with local legisla-

tion.

System operation warning light:

A call is always made as follows:

– green: operational

- the call is set up with the emergency

(network available);

services;

- off: non-operational

(network unavailable);

- send data related to the incident (ve-

Use the emergency call only in the

- red: operating

hicle identification plate, local time

event of an emergency you are in-

fault;

of the call, last positions, direction of

volved in, if you witness an accident

- green flashing: call in progress.

the vehicle);

or if you feel ill.

Automatic mode warning light;

- voice communication with the emer-

SOS button;

gency services;

Microphone;

In the event of an acci-

- if necessary, emergency assistance

Speaker.

dent, if the location and traf-

is called.

fic conditions permit, stay

Emergency call has two modes:

close to the vehicle in order

to be able answer the call centre

- automatic mode;

quickly if necessary.

– Manual mode.

2.74

CarManuals2.co

EMERGENCY CALL (2/3)

Automatic mode

In the event of unintended operation, it

is possible to cancel the call by press-

If the automatic mode 2 warning light

ing the 3 button for around two sec-

appears in green this confirms that the

onds, before the call is connected to

automatic system is activated.

the call centre.

The emergency call starts automati-

Once a call is established, only the call

cally in the event of an accident having

centre can end the call.

required the activation of the protective

equipment (seat belt pretensioners,

Test mode

airbag, etc.).

(depending on local laws)

Test mode is reserved for Approved

Dealers to check that the emergency

call feature is working properly.

To activate test mode:

- briefly press the 3 button three times;

Manual mode

- wait approximately 15 seconds;

The emergency call is carried out by:

- briefly press the 3 button three times.

- pressing and holding the 3 button for

at least three seconds;

Exit from test mode is automatic.

- pressing the

3 button five times

within less than approximately ten

seconds.

2.75

CarManuals2.co

EMERGENCY CALL (3/3)

The system operates with a dedi-

cated battery. The battery service

life is approximately four years

(the

1 warning light lights up in

red to warn you when approaching

expiry).

Consult an approved dealer

Without the emergency call feature,

the system is not trackable and will

not be under constant surveillance.

Data is automatically and constantly

To guarantee your safety

erased, and the system stores only

and the proper operation of

the last three positions of the vehi-

the system, any operation

Operating faults

cle.

carried out on the battery

In some cases, the emergency call may

(removal, disconnection, etc.) must

According to local legislation, data

not work (e.g. low battery).

be carried out by a qualified special-

is only sent in the event of an emer-

When the system detects an operating

ist.

gency call. Data sent to the call

fault, the 1 warning light turns red for

centre is treated according to the

Risk of serious burns or electric

over 30 minutes; consult an Approved

personal data protection laws appli-

shocks.

Dealer as soon as possible.

cable in the country where you are

You must respect the replacement

located. The system stores activity

intervals (without exceeding them)

history data for 13 hours only.

as stated in the maintenance docu-

The vehicle owner has the right of

ment.

access to their data. They can re-

The battery is a specific type.

quest that the data be corrected,

Please ensure it is replaced with the

deleted or locked.

same type.

Call an approved Dealer.

2.76

CarManuals2.co

Section 3: Your comfort

Air Vents

3.2

Manual air conditioning, heating system

3.4

Automatic climate control

3.7

Air conditioning: information and advice on use

3.13

Multimedia equipment

3.15

Windows

3.17

Interior lighting

3.19

Sun visor, grab handle

3.20

Ashtrays, cigarette lighter, accessories socket

3.22

Passenger compartment storage, fittings

3.23

Rear bench seats

3.29

Transporting objects

3.32

Roof bars

3.35

3.1

CarManuals2.co

AIR VENTS, air outlets (2/2)

To remove bad odours from your ve-

hicles, only use the systems designed

for this purpose. Consult an approved

Dealer.

Centre air vents 4

Side air vents 2

Air flow

To close: move the cursor 7 towards the

outside of the vehicle beyond the resist-

inside of the vehicle beyond the resist-

ance point.

To open: move the cursor 7 towards the

inside of the vehicle.

outside of the vehicle.

Direction

Move the cursor 7 to the desired posi-

tion.

Do not add anything to the

vehicle’s ventilation circuit

(for example, to remove

bad odours).

Do not attach any objects to the air

vents (e.g. telephone mounting).

There is a risk of damage or of

fire.

Risk of damage.

3.3

CarManuals2.co

MANUAL AIR CONDITIONING, HEATING SYSTEM (1/3)

The air flow is directed mainly

A B

C D

E F

towards the footwells.

The air flow is distributed be-

tween all the air vents, the

front side window demisting vents, the

windscreen demisting vents and the

footwells.

The air flow is directed to the

windscreen demisting/de-icing

outlets and the side windows. This po-

sition prevents the formation of conden-

sation. Use at the highest temperature.

Rear screen and/

or door mirror de-icing/

Controls

Distribution of air in the

demisting.

passenger compartment

A Adjusting the amount of air blown

Press button E: the integrated indicator

into the passenger compartment.

Turn control F.

light comes on. This function demists

B Air recirculation operation (isolation

All the air flow is directed to the

the rear screen and/or the heated door

of the passenger compartment)

dashboard vents.

mirrors quickly.

C Adjusting the air temperature.

D Activating air conditioning (depend-

This selection is not appropriate if all

To exit this function, press the button

ing on the vehicle).

the air vents are closed.

again; the integrated indicator goes

E Rear screen and/or door mirror de-

out. Demisting automatically stops by

The air flow is directed to the

icing/demisting.

default.

dashboard vents and the foot-

F Air distribution.

wells.

Information and advice on use

➥ 3.13

3.4

CarManuals2.co

MANUAL AIR CONDITIONING, HEATING SYSTEM (2/3)

This function also allows the de-

sired comfort level to be achieved as

quickly as possible.

This starts or stops air recirculation.

Operating tell-tale lights up when the

function is operational. In this position

the air is taken from inside the passen-

ger compartment and is recycled with-

out letting air in from outside.

Adjusting the air temperature

Air recirculation operation

(isolation of the passenger

Turn control C.

compartment)

Turning the control to

the right in-

creases the temperature.

Normal operation of the heating and

ventilation system is obtained using air

from outside.

Prolonged use of this position can

Recirculation of air allows the external

lead to condensation forming on the

atmosphere to be isolated (driving in

side windows and windscreen and

polluted areas, etc.).

problems due to the use of nonre-

newed air in the passenger com-

Press button B to switch to isolation

partment.

mode.

We therefore advise you to return

to normal mode (external air) as

soon as the air recirculation function

is no longer required, by pressing

button B again.

3.5

CarManuals2.co

MANUAL AIR CONDITIONING, HEATING SYSTEM (3/3)

The air conditioning system is used

for:

- lowering the temperature inside the

passenger compartment;

- eliminating condensation more

quickly.

Note: the air conditioning does not op-

erate if the exterior temperature is low

or the ventilation speed is less than 1.

Adjusting the amount of air

Switching air conditioning on

blown into the passenger

or off

compartment

(depending on the vehicle)

Turn control A from 0 to 4.

The air conditioning is switched on (in-

The passenger compartment is venti-

dicator light lit) or off (indicator light off)

lated by blown air.

using button D.

The ventilation fan determines how

much air flows in. Vehicle speed has a

slight effect.

The further the control is positioned to

the right, the greater the amount of air

blown into the passenger compartment.

Note: to promote demisting, turn con-

trol A into position 4.

3.6

CarManuals2.co

AUTOMATIC CLIMATE CONTROL (1/6)

Controls

9 and 10 - Adjusting the air tempera-

(depending on vehicle)

ture.

1 - “Clear View” button to demist and

11 - Heated rear screen and/or heated

de-ice the windows.

door mirror de-icing.

2 - Air conditioning off button.

12 - Air recirculation control.

3 - Automatic mode.

Information and advice on use

➥ 3.13

4 - Display.

5 and 7 - Adjusting the ventilation

speed.

6 and 8 - Passenger compartment air

distribution adjustment.

3.7

CarManuals2.co

AUTOMATIC CLIMATE CONTROL (2/6)

Only the temperature and the AUTO

symbol are displayed.

Functions managed in automatic mode

are not displayed.

- press button 9 to increase the tem-

perature;

- press button 10 to decrease the tem-

perature.

Note: The maximum and minimum

settings of 15°C and 27°C allow the

system to produce a minimum or maxi-

mum temperature, whatever the ambi-

ent conditions.

Automatic mode

To reach and keep the chosen comfort

level and to maintain good visibility, the

Press button 3. AUTO lights up on dis-

system controls:

play 4.

- ventilation speed;

In most cases, the automatic climate

- air distribution;

control system ensures a comfortable

temperature in the passenger compart-

- air recirculation management;

ment, while maintaining good visibility

- air conditioning start/stop;

and optimising fuel consumption.

This is the recommended mode of

– the air temperature.

In automatic mode (AUTO lit on the

use.

display), all heating and air condi-

tioning functions are controlled by

the system.

When you modify certain functions,

AUTO goes out. Only the modified

function stops being controlled by

the system.

3.8

CarManuals2.co

AUTOMATIC CLIMATE CONTROL (3/6)

Adjusting automatic mode

The system normally operates in auto-

matic mode but you can alter the stand-

ard settings used by the system (air

distribution, etc.). These options are

explained on the following pages.

The displayed temperature values

show a comfort level.

When starting the engine, increas-

Automatic mode is the recom-

ing or decreasing the value dis-

mended mode of use

played will not allow the com-

fort level to be reached any more

In most cases, the automatic cli-

quickly. The system will always op-

mate control system ensures a com-

timise the temperature increase or

fortable temperature in the passen-

decrease (the ventilation system

ger compartment, while maintaining

does not start instantly at maximum

good visibility and optimising fuel

speed: it gradually increases). This

consumption.

may take several minutes.

The types of adjustments that can

Generally speaking, unless there is

be made are described in the follow-

a particular reason not to, the dash-

ing pages.

board air vents should remain open.

Return to automatic mode as soon

as possible.

3.9

CarManuals2.co

AUTOMATIC CLIMATE CONTROL (4/6)

The air flow is directed mainly

to the dashboard air vents.

The air flow is directed towards

all the air vents and the pas-

senger footwells.

The air flow is directed mainly

towards the footwells.

Distribution of air in the

The air flow is directed to the

windscreen demisting vents

passenger compartment

and the side windows.

There are five possible combinations

The air flow is directed to the

for air distribution, which may be se-

windscreen and side window

lected by pressing buttons 6 and 8 re-

demisting vents, and the passenger

peatedly. The arrows on display 4 indi-

footwells.

cate the setting selected:

The manual air distribution option

causes the operating tell-tale light

on display 4 to go out (automatic

mode), but only air distribution is no

longer controlled automatically by

the system.

Press button 3 to return to auto-

matic mode.

3.10

CarManuals2.co

AUTOMATIC CLIMATE CONTROL (5/6)

Rear screen and/or door

mirror de-icing/demisting.

Press button 11: the integrated indica-

tor light comes on.

This function allows electric demisting

of the rear screen and/or the electric

heated door mirrors, depending on the

vehicle.

To exit this function, press button 11

again. Demisting automatically stops

by default.

Switching air conditioning on

Varying the ventilation speed

or off

In automatic mode, the system uses

In automatic mode, the system switches

the most suitable amount of air to reach

the air conditioning system on or off,

and maintain the desired comfort level.

depending on the climate conditions.

Exit automatic mode by pressing but-

Exit automatic mode by pressing

tons 5 and 7.

button 2: AUTO goes out on display 4

These buttons allow you to increase or

and AC OFF lights up.

decrease ventilation speed.

In automatic mode, depending on

Note: the “Clear View” function auto-

the outside air conditions, the ven-

matically activates the air conditioning.

tilation may not start immediately at

Press button 3 to return to automatic

maximum power but will increase

mode.

progressively until the engine tem-

perature is warm enough to heat the

passenger compartment air. This

may take from a few seconds to

several minutes.

3.11

CarManuals2.co

AUTOMATIC CLIMATE CONTROL (6/6)

Air recirculation

Pressing button 12 activates air recir-

culation (the symbol lights up on the

display).

During recirculation, air is taken from

the passenger compartment and is re-

cycled, with no air being taken from out-

side the vehicle.

Air recirculation allows the external at-

mosphere to be cut off (when driving in

polluted areas, etc.).

Prolonged use of the air recirculation

mode may cause the windows to mist

up or lead to odours, as the air is not

Clear View function

Press button 11 if you do not wish to

renewed.

switch on the heated rear screen and/

We therefore advise you to return to

Press button 1; the indicator lights in

or heated door mirrors.

normal mode (external air) as soon as

buttons 1 and 11 come on.

Note: if you wish to reduce the air flow

the air recirculation function is no longer

AUTO goes out on display 4.

required, by pressing button 12 again.

(which may produce a certain amount

This function rapidly demists/de-ices

of noise in the passenger compart-

the windscreen, the front side windows

ment), press button 5.

and the door mirrors.

To exit this function, press:

It imposes automatic operation of the

- button 1 again;

air conditioning and heating of the rear

screen and/or heated door mirrors, and

- button 3 (AUTO lights up on the dis-

inhibits air recirculation.

play).

3.12

CarManuals2.co

AIR CONDITIONING: information and operating instructions (1/2)

Advice on use

Fuel consumption

Operating faults

In some situations (air conditioning off,

You will normally notice an increase in

As a general rule, contact your ap-

air recirculation activated, ventilation

fuel consumption (especially in town)

proved dealer in the event of an oper-

speed at zero or low etc.), you may

when the air conditioning is operating.

ating fault.

notice that condensation starts to form

For vehicles fitted with air conditioning

- Reduction in de-icing, demisting

on the windows and windscreen.

with no automatic mode, switch off the

or air conditioning performance.

system when it is not required.

If there is condensation, use the “Clear

This may be caused by the passen-

View” function to remove it, then use

Advice for reducing consumption

ger compartment filter cartridge be-

the air conditioning in automatic mode

and helping to preserve the environ-

coming clogged.

to stop it forming again.

ment

- No cold air is being produced.

Drive with the air vents open and the

Check that the controls are set cor-

windows closed.

rectly and that the fuses are sound.

If the vehicle has been parked in the

Otherwise, switch off the system.

sun, open the doors for a few moments

to let the hot air escape before starting

Presence of water under the

the engine.

vehicle

After prolonged use of the air condi-

Maintenance

tioning system, it is normal for water

Vehicles equipped with

Refer to the Maintenance Document

to be present under the vehicle. This is

modeECO

for your vehicle for the inspection fre-

caused by condensation.

Once activated, ECO mode may

quency.

reduce air conditioning perfor-

mance. ➥ 2.12.

Do not add anything to the

vehicle’s ventilation circuit

Do not open the refriger-

(for example, to remove

Use the air conditioning system reg-

ant fluid circuit. The fluid

bad odours).

ularly, even in cold weather, running

may damage eyes or skin.

There is a risk of damage or of

it at least once a month for approxi-

fire.

mately 5 minutes.

3.13

CarManuals2.co

AIR CONDITIONING: information and operating instructions (2/2)

Type of refrigerant fluid

Type of oil in the air condi-



tioning circuit

Inflammable product



Consult the driver’s hand-



book

Maintenance



Quantity of refrigerant

x.xxx kg

fluid present in the ve-

hicle.

The refrigerant fluid circuit (of which

some components are hermetically

Global

Warming

sealed) contains fluorinated green-

GWP xxxxx

Potential (CO2 equiv-

house gases.

alent).

Depending on the vehicle, you will find

the following information on label A af-

CO2 eq

Quantity in weight and

Do not open the refriger-

fixed inside the engine compartment.

x.xx t

in CO2 equivalent.

ant circuit. The fluid may

The presence and location of the infor-

damage eyes or skin.

mation on label A depends on the ve-

hicle.

Before carrying out any

action in the engine com-

partment, you must switch

off the ignition. ➥ 2.3.

3.14

CarManuals2.co

MULTIMEDIA EQUIPMENT (1/2)

The presence and location of this

Multimedia sockets 1

equipment depends on the vehicle’s

You can use the USB sockets to access

multimedia equipment.

the multimedia content of your acces-

1 Multimedia sockets;

sories and to update the system.

2 Radio;

The USB sockets can also be used to

recharge accessories with a maximum

3 steering column control;

power rating of 12 Watts (5 Volts) per

4 multimedia screen.

socket, which have been approved by

our Technical Department.

The JACK socket enables the radio to

be used with an auxiliary cable.

Connect accessories with a

maximum power of 12 watts

only.

Please refer to the multimedia in-

Fire hazard.

structions for further information.

3.15

CarManuals2.co

WINDOWS (1/2)

Driver’s responsibility

Never leave your vehi-

cle with the key, remote

control or transmitter-recei-

ver inside, and never leave a child,

Electric windows

From the front passenger seat

adult who is not self-sufficient or a

pet, even for a short while. They

Press switch 3.

With the ignition on:

may pose a risk to themselves or to

others by starting the engine or acti-

- press the switch for the window

vating equipment (such as the gear

concerned to lower it to the desired

lever or electric windows). If any

height;

part of the body becomes trapped,

- pull the switch of the window con-

reverse the direction of the window

cerned to raise it to the desired

immediately by pressing the rele-

height.

vant switch.

Risk of serious injury.

From the driver’s seat

Operate the switches as follows:

- 1 for the driver’s side;

- 2 for the front passenger side.

Avoid resting any objects against

a half-open window: there is a risk

that the electric window could be

damaged.

3.17

CarManuals2.co

WINDOWS (2/2)

Impossible to operate the one-touch

electric window

The one-touch electric window is

equipped with heat protection: if you

press the switch for the window more

than sixteen consecutive times it goes

into protection mode

(locking the

window).

You can:

- use the electric window switch briefly

and with intervals of approximately

30 seconds;

- with the engine running, the window

will be unlocked after approximately

20 minutes of inaction on the electric

One-touch electric window

Sliding rear windows

window switch.

The one-touch mode works in addition

Press the tab 4 and slide the window.

to the operation of the electric windows

Note: if the window detects resistance

described previously.

when closing (e.g.: branch of a tree,

It is fitted to the driver’s window and

etc.) it stops and then lowers again by a

is used for lowering only.

few centimetres.

Briefly press switch 1: the window

lowers completely.

Pressing the switch again while the

window is moving will stop its move-

ment.

When closing the windows,

ensure that no part of the

body (arm, hand, etc.) is

protruding from the vehicle.

Risk of serious injury.

3.18

CarManuals2.co

INTERIOR LIGHTING

Note

Remote unlocking of the doors triggers

timed lighting of the passenger com-

partment.

If one of the front or rear doors is

opened, the timed lighting will start

again.

Then the courtesy light and the luggage

compartment light dim and go out. The

lighting timer will cut out for various rea-

sons:

after approximately 15 minutes when

a door has been left open;

after approximately

15 seconds

Courtesy light

Rear light 3

when all of the doors are closed,

Use switch 1 to:

Turn switch 4 to:

when the ignition is switched on.

- permanent lighting;

- continuous lighting;

- intermittent lighting, which comes on

- intermittent lighting, which comes

when a door is opened. It goes out

on when a rear door is opened. The

when the doors concerned are prop-

lights only go out when the doors are

erly closed;

correctly closed;

- immediate switching off.

- or else the light definitively turned

off.

Map reading lights

(depending on the vehicle)

Move switch 2.

3.19

CarManuals2.co

SUN VISOR, GRAB HANDLE (1/2)

Sun visor

Courtesy mirror or additional

Grab handle 3

rear-view mirror 2

Lower sun visor 1.

This offers support and can be held

(depending on the vehicle)

when the vehicle is being driven.

The sun visor can be swung round

against the door window.

Lower the sun visor to access the

mirror.

Special feature of the additional rear

view mirror ➥ 1.84

Do not use it for getting into or out of

the vehicle.

3.20

CarManuals2.co

ASHTRAY, CIGAR LIGHTER, ACCESSORIES SOCKET

Accessories sockets 1

(depending on vehicle)

They are designed for connecting ac-

cessories with a maximum power rating

120 Watts (voltage:

12V) which

have been approved by our Technical

Department.

Ashtray 2

Accessories socket 3 (in the

(depending on vehicle)

luggage compartment)

This is a removable ashtray which can

be placed in the cup holders.

Lift the cover to open.

To empty it, pull the assembly. The ash-

tray will come out of its housing.

Connect accessories with

Cigar lighter 1

a maximum power of

(depending on vehicle)

120 watts (12 V) only.

With the ignition on, push in cigar

When several accessory

lighter 1, it will spring back with a click

sockets are used at the same time,

when it is ready. Pull it out to use. After

the total power of the connected

use, replace it without pushing it all the

accessories must not exceed

If your vehicle is not fitted with a

way in.

180 watts.

cigar lighter and an ashtray, these

Fire hazard.

can be obtained from an approved

Dealer.

3.22

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (1/6)

Front door storage

Sun blind storage

Centre console storage

compartments

compartment 4

compartment/induction

charging area 5

This can be used for storing motorway

Storage compartment 1

tickets, cards, etc.

For more information on the induction

Do not use it as a handle to close the

door.

charging zone, please refer to the mul-

timedia instructions.

Storage compartment 2

Storage compartment 3

Ensure that no hard, heavy

It can hold a 1.5 litre bottle.

or pointed objects are

Nothing should be placed

placed in the “open” storage

on the floor area in front of

compartments in such a

the driver as such objects

way that they may fall onto passen-

may slide under the pedal

gers during sudden turning, braking

during braking manoeuvres, thus

or in the event of an accident.

obstructing its use.

3.23

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (2/6)

Dashboard storage

compartments 7, 8, 10 and 12

Closed storage compartments 10

and 12

To open, press the 9 or 11 control.

Glove compartment 14

To open, press the 15 control or, de-

pending on the vehicle, raise the

handle.

It can hold A4 size documents, a 2 litre

bottle of water etc.

Depending on the vehicle, it may be

Cup holder 6, 13 and 16

Location for storage

ventilated and refrigerated.

These can be used to hold cups or the

compartment or radio 17

ashtray.

Maximum weight allowed in the

glove box 14: 4 kg evenly distrib-

uted.

Always leave the storage

compartment cover closed

When turning corners,

Ensure that no hard, heavy

when you are driving:

accelerating or braking,

or pointed objects are

ensure that the recepta-

placed in the “open” storage

- there is a risk of injury

cle being held by the cup

compartments in such a

when braking suddenly or in

holder is not dislodged.

way that they may fall onto passen-

the event of an accident;

gers during sudden turning, braking

There is a risk of burning if hot

- there is a risk of objects being

or in the event of an accident.

liquid escapes.

hurled through the passenger

compartment.

3.24

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (3/6)

Tray 18

Upper cab storage

compartment 20 and 21

Pull tray 18 fully towards you.

Turn it and push it fully.

Reserved for the transport of objects

only.

You can use clip 19 to attach A5 format

documents.

To refit it, pull the table tray fully to-

wards you, lift it up until it is horizontal

and push it in fully.

Maximum weight allowed in the

upper cabin storage unit 20: 5 kg

Nothing should be placed

uniformly distributed.

on the floor area in front of

the driver as such objects

may slide under the pedal

Do not hang any heavy and/

during braking manoeuvres, thus

or sharp objects which may

obstructing its use.

fall whilst driving.

Risk of injury.

3.25

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (4/6)

Cup holder 24

Tray 25

To open, press the 22 control.

To open, press the 23 control.

When turning corners,

accelerating or braking,

Maximum weight allowed on the

Nothing should be placed

ensure that the recepta-

parcel shelf 25: 25 kg evenly distrib-

on the floor area in front of

cle being held by the cup

uted.

the driver as such objects

holder is not dislodged.

may slide under the pedal

There is a risk of burning if hot

during braking manoeuvres, thus

Before driving, make sure

liquid escapes.

obstructing its use.

the tray is stored.

Risk of injury.

3.26

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (5/6)

Note: make sure the tray is put back in

place correctly before lifting the back of

the centre seat. Check that the back of

the centre seat is properly locked.

Ensure that nothing is obstructing

the operation of the folding tray.

When turning corners,

accelerating or braking,

ensure that the recepta-

Tray 26

cle being held by the cup

Clothes hooks 30

holder is not dislodged.

On equipped vehicles, lower the back

of the centre seat by lifting control 29.

There is a risk of burning if hot

liquid escapes.

The back of the centre seat has the fol-

lowing features:

- a tray 26 which can be turned only to

the driver’s side (depending on the

vehicle);

Ensure that no hard, heavy

- a cup holder 28;

or pointed objects are

– storage compartment 27.

placed in the “open” storage

compartments in such a

way that they may fall onto passen-

gers during sudden turning, braking

It is forbidden to sit in the

or in the event of an accident.

centre seat if its seatback is

folded down.

3.27

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (6/6)

Storage compartment 33

Storage compartment

Rear load area storage

underneath front bench seat

underneath rear bench seat

compartment 35

To access, pull tabs 31 or 32.

Seat base 34 lifts up to give access to

Reserved for the transport of objects

a storage compartment underneath the

only.

bench seat.

Maximum weight allowed in the

Always close the seat base

upper rear storage cell 35: 35 kg

when driving:

evenly distributed.

- there is a risk of injury

Check that the rear seat

when braking suddenly or

belts are positioned and op-

in the event of an accident;

Do not hang any heavy and/

erating correctly each time

or sharp objects which may

- there is a risk of objects being

the rear seats are moved.

fall while you are driving.

hurled through the passenger

compartment.

Risk of injury.

3.28

CarManuals2.co

REAR BENCH SEATS (1/3)

Access to the rear seats

Removing the bench seat

Move the handle 1 backwards to lower

Lift levers 2 situated behind each bench

the seat back.

seat. The spigots 3 protrude to indicate

that the bench seat is unlocked.

To return the seat to its original position,

bring the seatback back into position.

Pull the bench seat backwards to re-

lease the anchoring points, then lift it to

remove it.

The bench seat is rather

heavy

(approximately

kg). For your own safety,

For safety reasons, carry

please handle it carefully.

out any adjustments when

Removing the anchoring

Risk of injury.

the vehicle is not being

points is prohibited.

driven.

3.29

CarManuals2.co

REAR BENCH SEATS (2/3)

Refitting the rear bench seat

- Position the guides 4 on the rails set

The bench seats in rows 2 and 3 are

back in relation to the anchorage

not interchangeable: do not force

points;

them into position.

- slide the bench seat forwards.

Risk of damage.

The bench seat will lock automatically.

Check that the red spigots 3 can no

longer be seen.

When moving the rear

bench seat, check that

The rear bench seats must

the bench seat anchor-

be placed on their original

age points are clean (they

anchorage points.

should be free from grit, cloths or

Driving with the bench seat

any other item which may prevent

in a rear-facing position is prohib-

the bench seat from locking se-

ited.

curely).

3.30

CarManuals2.co

REAR BENCH SEATS (3/3)

Use restriction

Special note for three-seater

versions

It is forbidden to drive with a seatback

or a front seat folded down when there

This version differs in that it has rear

is a passenger occupying a rear seat.

seatbelts and headrests on the rear

side seats only. Never seat a passen-

ger in the centre seat area.

A labels inform you that it is prohibited

to seat passengers in areas other than

the seats provided.

Check that the rear seat

belts are positioned and

For safety reasons, carry

operating correctly each

out any adjustments when

time the rear bench seat is

the vehicle is not being

moved.

driven.

3.31

CarManuals2.co

TRANSPORTING OBJECTS (1/3)

Transporting objects in the

F max: 400 daN or 500 daN (depending

on the vehicle).

rear load area

Depending on the vehicle, secur-

Always position the heavi-

ing rings 1 and 2 can be used to stop

est items directly on the

transported objects from moving. The

floor. Use the lashing points

number of rings and their position may

on the floor of the luggage

vary depending on the vehicle.

compartment, if these are fitted to

the vehicle. The luggage should be

loaded in such a way that no items

will be thrown forward and strike the

occupants if the driver has to brake

suddenly. Fasten the rear seat belts,

The sole purpose of rings 2 is to

even if the seats are not occupied.

prevent transported objects from

moving. The objects must be se-

cured to mounting rings 1 on the ve-

hicle floor beforehand.

3.32

CarManuals2.co

TRANSPORTING OBJECTS (3/3)

Permissible nose weight, maxi-

mum permissible towing weight

braked and unbraked ➥ 6.9.

Choice and fitting of towing

equipment

Maximum weight of towing equip-

ment: 25 kg.

It is not permitted to fit a mechanical

towing device (ball, hook, etc.) that

Any towing device must not ob-

is removable without tools or retract-

struct any lighting component or

able if it cannot be easily removed

the number plate when not in use.

or repositioned when not in use.

Mechanical towing devices (ball,

hook, etc.) which can be removed

For fitting and conditions of use,

without tools or which are retract-

refer to the equipment’s fitting in-

able must be removed or reposi-

structions.

tioned when they are not in use.

Please keep these instructions with

In all cases, you must comply with

the rest of the vehicle documenta-

the regulations of the particular

tion.

country you are in.

3.34

CarManuals2.co

ROOF BARS

Precautions during use

Handling the tailgate

Before handling the tailgate, check the

objects and/or accessories (bike rack,

roof box, etc.) fitted to the roof bars:

these must be correctly positioned and

secured, so as not to hinder the opera-

tion of the tailgate.

Accessing the mounting

points 1

For information on the range of

equipment adapted to your vehi-

cle, we advise you to consult an ap-

proved Dealer.

Refer to the manufacturer’s instruc-

tions for information on how to fit

If original roof bars, ap-

and use the roof rack bar.

proved by our Technical

Department, are supplied

Please keep these instructions with

with screws, only use these

the rest of the vehicle documenta-

screws for attaching the roof bars to

tion.

the vehicle.

Maximum permissible load on

roof rack ➥ 6.9.

3.35

CarManuals2.co

BONNET (1/2)

To open the bonnet, pull handle 1.

Unlocking the bonnet catch

To unlock, push the tab 2 to the left as

you open the bonnet.

Please note when work-

ing close to the engine that

it may be hot. In addition,

the engine cooling fan may

Before carrying out any

In the event of even a slight

start at any moment. The 

action in the engine com-

impact involving the radia-

warning light in the engine compart-

partment, you must switch

tor grille or bonnet, have the

ment reminds you of this.

off the ignition. ➥ 2.3.

bonnet lock checked by an

authorised dealer as soon as pos-

Risk of injury.

sible.

4.2

CarManuals2.co

BONNET (2/2)

Closing the bonnet

Ensure that the windscreen wiper

blades are correctly positioned.

Place the stay 4 into its holder 5, hold

the bonnet in the middle and lower it to

about 20 cm above the closed position,

then release it. It will latch automatically

under its own weight.

Opening the bonnet

Lift the bonnet and release the stay 4

from its holder 5. For your own safety, it

is very important to fix the stay into the

retainer 3 in the bonnet.

After any procedure in the

engine compartment, make

Ensure that the bonnet is

sure that you do not forget

properly locked.

anything (cloth, tools, etc.).

Check that nothing is pre-

Otherwise, this may lead to engine

venting the catch from lock-

damage or cause a fire.

ing (gravel, cloth, etc.).

4.3

CarManuals2.co

ENGINE OIL LEVEL: general information (1/2)

It is normal for an engine to use oil for

Reading the oil level

Minimum oil level warning

lubrication and cooling of moving parts

The oil level should be read with the ve-

The “WARNING: Top Up Engine Oil”

and it is normal to top up the level be-

hicle on level ground, after the engine

message and warning light

are

tween oil changes.

has been switched off for some time.

displayed on the instrument panel.

However, contact your approved Dealer

The dipstick must be used to read

It is vital to top up the oil as soon as

if more than 0.11 gal (0.5 litre) is being

the exact oil level and make sure

possible.

consumed every 620 miles (1,000 km)

that the maximum level has not been

after the running in period.

exceeded (risk of engine damage).

Oil change frequency: check the oil

Refer to the following pages.

level from time to time and certainly

Depending on the vehicle, the instru-

before any long journey to avoid the

ment panel display only alerts the driver

risk of damaging your engine.

when the oil level is at its minimum.

Exceeding the maximum

engine oil level

Under no circumstances

should the maximum fill-

ing level be exceeded: this could

damage the engine and the emis-

sion control system.

The display only warns the

If the level exceeds the

“MAXI”

driver if the oil level is at the

Before carrying out any

level, do not start your vehicle,

minimum level. It does not

action in the engine com-

contact an authorised dealer.

inform the driver that the oil

partment, you must switch

level has exceeded the maximum

off the ignition. ➥ 2.3.

level as this can only be measured

using a dipstick.

4.4

CarManuals2.co

ENGINE OIL LEVEL: general information (2/2)

Consult your approved Dealer at

once if you notice an abnormal or

repeated drop in any of the fluid

levels.

Adding engine oil

Use a funnel or protect the

filling neck area to avoid

engine oil escaping onto a

hot part of the engine compartment

or a sensitive part (e.g. electrical

components).

Reading the level using the

Depending on the vehicle, the oil dip-

stick must be locked:

Fire hazard.

dipstick

- push the dipstick as far as it will go

Engine switched off:

(movement C);

- remove the dipstick and wipe with a

- rotate to lock (movement D).

clean, lint-free cloth;

- push the dipstick in as far as it will

go;

Please note when work-

ing close to the engine that

- take out the dipstick again;

it may be hot. In addition,

- read the level: it should never fall

the engine cooling fan may

below the “MINI” mark B and never

exceed the “MAXI” A mark.

start at any moment. The 

warning light in the engine compart-

Once the level has been read, push the

ment reminds you of this.

dipstick in as far as it will go.

Risk of injury.

4.5

CarManuals2.co

ENGINE OIL LEVEL : topping up, filling (1/2)

Oil change

Service interval: refer to the mainte-

nance document for your vehicle.

Oil change capacity

Please refer to the maintenance docu-

ment for your vehicle, or contact an au-

thorised dealer.

Always check the engine oil level using

the dipstick, as explained previously (it

should never fall below the “MINI”, or be

over the “MAXI” level on the dipstick).

Engine oil grade

Refer to the maintenance document for

Topping up/filling

- Unscrew cap 1;

your vehicle.

The vehicle must be parked on level

- top up the level (as a guide, the ca-

ground and the engine should be cold

pacity between the “MINI” and the

(for instance, before the engine is

“MAXI” reading on the dipstick 2

started up for the first time in the day).

is between 0.33 and 0.44 gallons

(1.5 and 2 litres) depending on the

engine);

Adding engine oil

Engine oil grade

Refer to the Maintenance Document for

- wait for approximately 10 minutes to

Use a funnel or protect the

your vehicle.

allow the oil to drain;

filling neck area to avoid

engine oil escaping onto a

- check the level using the dipstick 2

hot part of the engine compartment

(as described above).

or a sensitive part (e.g. electrical

Once the level has been read, insert

components).

the dipstick 2 as far as it will go and,

Fire hazard.

depending on the vehicle, turn it a quar-

Do not exceed the “MAXI” level and

ter of a turn to lock it. Fully tighten the

do not forget to refit cap 1 and dip-

cap 1.

stick 2.

4.6

CarManuals2.co

Renault Master (2023 year). Manual in english - page 5
