TRANSPORTING OBJECTS IN THE LUGGAGE COMPARTMENT (4/4)

Storage position

Maximum permissible load weight

on roof rack 7: 30 kg evenly distrib-

With the roof rack in the operating po-

uted.

sition, pull the handle 6 downwards to

unlock the roof rack, hold the roof rack

Maximum load length:

bar 5 and push it upwards until it locks

- standard chassis: 2 metres;

(movement D).

Always secure the transported

- long chassis: 2.5 metres.

loads using the rings 9.

The roof rack locks automatically.

Check that the bonnet is correctly

Make sure that you abide by the

locked.

maximum authorised length and

load weight.

Prepare any protections that may

be required and adapt your driving

to minimise the movement of the

When handling the roof rack, ensure

transported load and to avoid dam-

that nobody is near the moving

aging the vehicle or the load.

parts.

3.42

CarManuals2.co

TRANSPORTING OBJECTS towbar

Permissible nose weight, maxi- -

mum permissible towing weight

braked and unbraked: ➥ 6.10.

Choice and fitting of towing

equipment

Maximum weight of towing equip-

ment:

- 7.2 kg on a vehicle with towing

pre-equipment;

Dimension A (maximum)

- 28.5 kg on a vehicle without

Standard chassis

towing pre-equipment.

A = 935 mm.

It is not permitted to fit a mechanical

Long chassis

towing device (ball, hook, etc.) that

A = 975 mm.

is removable without tools or retract-

able if it cannot be easily removed

Any towing device must not ob-

or repositioned when not in use.

struct any lighting component or

the number plate when not in use.

For fitting and conditions of use,

Mechanical towing devices (ball,

refer to the equipment’s fitting in-

hook, etc.) which can be removed

structions.

without tools and retractable objects

Please keep these instructions with

must be removed or repositioned

the rest of the vehicle documenta-

when they are not in use.

tion.

In all cases, you must comply with

the regulations of the particular

country you are in.

3.43

CarManuals2.co

MODULAR ROOF BARS (1/2)

Before transporting a load on the mod-

ular roof bars, they must be set to their

operating position:

- Unclip the levers 1 (movement A);

When handling, ensure that the

bars do not touch the vehicle roof as

- Raise the bars sufficiently to allow

they may scratch the roof.

them to be pivoted (figure B);

- Lock the bars in the transverse

Make sure that the two roof

position by clipping the levers

bars are correctly posi-

(figure C);

tioned and locked.

- Check that they are correctly locked.

It is strictly forbidden to place the

modular roof bars in the transverse

position

(carrying position) when

Maximum weight on each roof bar:

entering a roller-type car wash.

40 kg evenly distributed (80 kg over

two roof bars).

3.44

CarManuals2.co

MODULAR ROOF BARS (2/2)

To slide the bar

Once you have chosen the position,

pivot the bar and lock it in the trans-

When not using the bars in trans-

Roof bar 2 can be slid to move it

verse position (figure E).

verse position, refit the bars in lon-

closer to or further from the other bar

gitudinal position in order to opti-

(figure D).

Check that both bars are correctly

mise fuel consumption and avoid air

locked in position.

There are two positions: centre or rear.

noise.

With the bar unlocked, pull it towards

the front or the rear of the vehicle to

slide it in rail 3.

Check that the objects and/

or accessories (bike rack,

roof box, etc.) fitted to the

roof bars are correctly po-

sitioned, evenly distributed and se-

cured.

3.45

CarManuals2.co

ROOF ANCHORAGE POINTS

User precautions

Handling the tailgate

Before operating the tailgate, check the

objects and/or accessories (bike rack,

roof box, etc.) fitted on the roof bars:

For information on the range of

these must be correctly positioned and

equipment adapted to your vehi-

secured, and must not prevent the tail-

cle, we advise you to consult an ap-

gate from operating correctly.

proved Dealer.

Refer to the fitting instructions for in-

formation on how to fit roof bars and

conditions of use.

Please keep these instructions with

the rest of the vehicle documenta-

tion.

Unscrew the blanking covers 1 in order

to access the mounting points.

Maximum permissible load on

roof: 100 kg (including carrying de-

vices).

If original roof bars, ap-

proved by our Technical

Department, are supplied

with screws, only use these

screws for attaching the roof bars to

the vehicle.

3.46

CarManuals2.co

BONNET (1/2)

To open the bonnet, open a door and

Opening the bonnet

pull the 1 handle, located on the left-

To unlock, gently lift the bonnet and

hand side of the dashboard.

push tab 2 in the direction of arrow A to

release the bonnet.

Lift the bonnet, guiding it up, and it

will rest in position with the help of two

Please note when work-

Before carrying out any

struts 3.

ing close to the engine that

action in the engine com-

it may be hot. The engine

partment, you must switch

cooling fan may also start

off the ignition.

➥ 2.4

➥ 2.5.

at any moment. The 

label

When working in the engine

in the engine compartment reminds

compartment, ensure that

you of this.

the windscreen wiper stalk

Risk of injury.

Do not press down on the

is in the park position.

bonnet: there is a risk that

Risk of injury.

the bonnet may accidentally

close.

4.2

CarManuals2.co

BONNET (2/2)

Closing the bonnet

Before closing the bonnet, make sure

that nothing has been left in the engine

compartment.

To close it again, hold the bonnet in the

middle and lower it to 25 cm above the

closed position, then release it. Ensure

that the bonnet is properly closed.

If it does not lock itself under its own

Ensure that the bonnet is

weight, gently push it until it fully locks.

properly locked.

Check that nothing is pre-

venting the catch from lock-

ing (gravel, cloth, etc.).

After any procedure in the

engine compartment, make

sure that you do not forget

anything (cloth, tools, etc.).

These may damage the engine or

cause a fire.

In the event of even a slight

impact involving the radi-

ator grille or bonnet, have

the bonnet lock checked by

an approved dealer as soon as pos-

sible.

4.3

CarManuals2.co

ENGINE OIL LEVEL: general information

It is normal for an engine to use oil for

Adding engine oil

lubrication and cooling of moving parts

and it is normal to top up the level be-

Use a funnel or protect the

tween oil changes.

filling neck area to avoid

However, contact your approved

engine oil escaping on to a

Dealer if more than 0.5 litres is being

hot part of the engine compartment

consumed every 600 miles (1,000 km)

or a sensitive part (e.g. electrical

after the running in period.

components).

Oil change frequency: check the oil

Fire hazard.

level from time to time and certainly

before any long journey to avoid the

risk of damaging your engine.

Reading the oil level

Exceeding the maximum

The oil level should be read with the ve-

– Remove the dipstick and wipe with a

engine oil level

hicle on level ground, after the engine

clean, lint-free cloth;

Under no circumstances

has been switched off for some time.

- push the dipstick in as far as it will

should maximum filling

The dipstick must be used to read

go (for vehicles equipped with a cap-

level B be exceeded: this could

the exact oil level and make sure that

type dipstick C, screw the cap in as

damage the engine and the anti-pol-

the maximum level has not been ex-

far as it will go);

lution system.

ceeded (risk of engine damage).

- take out the dipstick again;

If the oil level exceeds the maximum

Depending on the vehicle, the instru-

- read the level: it should never fall

level, do not start your vehicle and

ment panel display only alerts the driver

below the “mini” mark A and never

contact an approved Dealer.

when the oil level is at its minimum.

exceed the “maxi” B mark.

Once the operation has been com-

pleted, ensure that the dipstick is

pushed in as far as it will go or that

the “cap-type dipstick” is completely

Before carrying out any

screwed in.

action in the engine com-

partment, you must switch

off the ignition.

➥ 2.4 or

➥ 2.5.

4.4

CarManuals2.co

ENGINE OIL LEVEL: topping up, filling, oil change (1/2)

Do not exceed the “maxi” level and

Topping up/filling

- Unscrew cap 1;

do not forget to refit the cap 1 and

The vehicle must be parked on level

- top up the level (capacity between

the dipstick 2.

ground and the engine should be cold

“mini” and “maxi” of the gauge 2 and

(for instance, before the engine is

between 0.9 to 2 litres according to

started up for the first time in the day).

the engine);

- wait for approximately 20 minutes to

Adding engine oil

allow the oil to flow into the engine;

Use a funnel or protect the

- check the level using the dipstick 2

filling neck area to avoid

(as described above).

engine oil escaping on to a

Once the operation has been com-

hot part of the engine compartment

pleted, ensure that the dipstick is

or a sensitive part (e.g. electrical

pushed in as far as it will go or that the

components).

Before carrying out any

cap-type dipstick is completely screwed

Fire hazard.

action in the engine com-

in.

partment, you must switch

off the ignition.

➥ 2.4 or

➥ 2.5.

4.5

CarManuals2.co

ENGINE OIL LEVEL: topping up, filling, oil change (2/2)

Oil change

Service interval: refer to the

Maintenance Service Booklet for your

vehicle.

Exceeding the maximum

Oil change capacity

engine oil level

Please refer to the maintenance doc-

Consult your approved dealer at

Under no circumstances

ument for your vehicle, or contact an

once if you notice an abnormal or

should the maximum fill-

authorised dealer. Always check the

repeated drop in any of the fluid

ing level be exceeded: this could

engine oil level using the dipstick, as

levels.

damage the engine and the emis-

explained previously (it should never

sion control system.

fall below the minimum level, or be over

If the oil level exceeds the maximum

the maximum level on the dipstick).

level, do not start your vehicle and

When working in the engine

contact an approved Dealer.

Engine oil grade

compartment, ensure that

Refer to the Maintenance Service

the windscreen wiper stalk

Booklet for your vehicle.

is in the park position.

Risk of injury.

Never run the engine in an

enclosed space as exhaust

gases are poisonous.

Please note when work-

Filling: take care when

ing close to the engine that

topping up the oil that

it may be hot. The engine

no oil drips onto engine

cooling fan may also start

components - risk of fire.

Remember to refit the cap securely

at any moment. The 

label

as there is a risk of fire if oil splashes

in the engine compartment reminds

Engine oil change: if you

onto hot engine components.

you of this.

are changing the oil when

the engine is hot, be careful

Risk of injury.

not to scald yourself if the

oil overflows.

4.6

CarManuals2.co

LEVELS, FILTERS (1/3)

Frequency of checking coolant level

Replacement interval

Check the coolant level regularly

Refer to the Maintenance Document for

(very severe damage is likely to be

your vehicle.

caused to the engine if it runs out of

coolant).

If the level needs to be topped up, only

use products approved by our Technical

Department which ensure:

- protection against freezing;

When working in the engine

- an anti-corrosion protection for the

compartment, ensure that

cooling system.

the windscreen wiper stalk

is in the park position.

Risk of injury.



Coolant

With the engine switched off and on

level ground, the level when cold must

be between the “MINI” and “MAXI”

Consult your approved dealer at

marks on coolant reservoir 1.

once if you notice an abnormal or

Top this level up when cold before it

repeated drop in any of the fluid

reaches the MINI mark.

levels.

No operations should be

carried out on the cooling

Before carrying out any

circuit when the engine is

action in the engine com-

hot.

partment, you must switch

off the ignition.

➥ 2.4 or

Risk of burns.

➥ 2.5.

4.7

CarManuals2.co

LEVELS, FILTERS (2/3)

Level 2

It is normal for the level to drop as the

brake shoes become worn, but it must

never drop lower than the “MINI" warn-

ing line.

If you wish to check the disc and drum

wear yourself, you should obtain the

document explaining the checking pro-

cedure from the manufacturer’s net-

work or website.

Topping up

After any operation on the hydraulic cir-

cuit, a specialist must replace the brake

fluid.

Only use fluids approved by our



Brake fluid

Technical Department (and taken from

a sealed container).

This should be checked frequently,

and immediately if you notice even the

Replacement interval

slightest loss in braking efficiency.

Refer to the Maintenance Document for

The level should be read with the engine

your vehicle.

switched off and on level ground.

Please

note when work-

ing close to the engine that

it may be hot. The engine

cooling fan may also start

at any moment. The 

label

in the engine compartment reminds

you of this.

Consult your approved dealer at

Risk of injury.

once if you notice an abnormal or

repeated drop in any of the fluid

levels.

4.8

CarManuals2.co

LEVELS, FILTERS (3/3)

Liquid

Filters

Windscreen washer fluid. In winter, use

The replacement of filter components

anti-freeze product. Use products rec-

(air filter, cabin filter, diesel filter, etc.)

ommended by an authorised dealer.

is scheduled in the maintenance opera-

tions for your vehicle.

Note: do not use pure water (risk of

damage to the priming pump, limescale

Replacement intervals for filter el-

building up on the pump and the jets).

ements: refer to the Maintenance

Document for your vehicle.

Jets

To adjust the height of the windscreen

washer jets, please consult an author-

ised dealer.

When working in the engine

compartment, ensure that

the windscreen wiper stalk



Windscreen washer

is in the park position.

reservoir

Risk of injury.

Topping up

With the engine switched off, open the

cap 3. Fill until you can see the fluid,

then replace the cap.

Please note when work-

ing close to the engine that

Note: check the reservoir level regu-

it may be hot. The engine

larly and top up the liquid before taking

cooling fan may also start

a trip.

at any moment. The 

label

Before carrying out any

in the engine compartment reminds

action in the engine com-

you of this.

partment, you must switch

Risk of injury.

off the ignition.

➥ 2.4 or

➥ 2.5.

4.9

CarManuals2.co

TYRE PRESSURE (1/2)

Vehicle fitted with a tyre pressure

loss warning system

In the event of under-inflation (punc-

tures, under-inflation etc.), the 

warning light appears on the instrument

panel. ➥ 2.31 ➥ 2.37.

Label A

B: dimension of the tyres fitted to the

vehicle.

Open the driver’s door to read it.

C: intended driving speed.

Tyre pressures should be checked

when the tyres are cold.

D: front tyre pressure.

If the tyre pressures cannot be checked

E: rear tyre pressure.

when the tyres are cold, increase the

F: tyre pressure for the emergency

pressures from 0.2 to 0.3 bar (or 3 PSI).

spare wheel.

Never deflate a hot tyre.

G: emergency spare wheel dimensions.

4.10

CarManuals2.co

TYRE PRESSURE (2/2)

Tyre safety and chain fitting: for infor-

Vehicles used fully laden

mation on servicing conditions and, de-

(Maximum Permissible

pending on the vehicle version, the use

All-up Weight) and towing

of chains. ➥ 5.13.

a trailer

The maximum speed must be lim-

For your safety, please re-

ited to 62 mph (100 km/h) and the

spect the speed limit.

tyre pressure increased by 0.2 bar

When they need to be re-

(3 psi) ➥ 6.10.

placed, only tyres of the

Risk of tyre blowouts.

same make, size, type and profile

should be used on a single axle.

They must: either have a load ca-

pacity and speed rating at least

equal to those of the original

tyres, or conform to those recom-

mended by an authorised dealer.

Failure to heed these instructions

could endanger your safety and

affect your vehicle’s roadworthi-

ness.

Risk of loss of control of the ve-

hicle.

4.11

CarManuals2.co

BATTERY (1/2)

Depending on the vehicle, a system

continuously checks the battery charge

status. If this decreases, the “Battery

Now In Standby Mode” message ap-

pears on the instrument panel followed

by “Battery Low Start Engine”. In this

case, start the engine and the message

on the instrument panel will disappear.

Note: the message “Battery Now In

Standby Mode” may be displayed after

5 to 30 minutes of vehicle use with the

engine stopped to warn the user that

power consuming functions (interior

lighting, radio, navigation, ventilation,

accessories power supply, etc.) may be

automatically cut off.

Battery 1 does not require any mainte-

Before

carrying

out

any

nance. You should not open it or add

The charge status of your battery can

action in the engine com-

any fluid.

decrease especially if you use your ve-

partment, you must switch

hicle:

off the ignition.

➥ 2.4

- for short journeys;

➥ 2.5.

Handle the battery with care

- for driving in town;

as it contains sulphuric acid

- when the temperature drops;

which must not come into

- after extended use of energy-con-

contact with the eyes or

suming devices (radio, etc.) with the

Please note when work-

skin. If it does, wash the affected

engine switched off.

ing close to the engine that

area with plenty of cold water. If

it may be hot. In addition,

necessary, consult a doctor.

the engine cooling fan may

Ensure that naked flames, red hot

start at any moment. The 

objects and sparks do not come into

warning light in the engine compart-

contact with the battery as there is a

ment reminds you of this.

risk of explosion.

Risk of injury.

4.12

CarManuals2.co

BATTERY (2/2)

Replacing the battery

For your own safety and for

the proper operation of the

As this operation is complex, we advise

vehicle's electrical equip-

you to contact an approved Dealer.

ment

(lights, windscreen

wipers, ABS, etc.), any intervention

on the battery (removal, disconnec-

tion, etc.) must categorically be per-

formed by a specialist professional.

Risk of serious burns or electric

shocks.

You must respect the replacement

intervals (without exceeding them)

as stated in the maintenance doc-

ument.

Label A

The battery is a specific type.

Please ensure it is replaced with the

Observe the indications on the battery:

same type.

- 2 naked flames and smoking are for-

Call an approved Dealer.

bidden;

- 3 eye protection required;

- 4 keep away from children;

- 5 explosive materials;

- 6 refer to the handbook;

- 7 corrosive materials.

4.13

CarManuals2.co

BODYWORK MAINTENANCE (1/3)

A well-maintained vehicle will last

You should

Respect local regulations about wash-

longer. It is therefore recommended to

ing vehicles (e.g. do not wash your ve-

Wash your car frequently, with the

maintain the exterior of the vehicle reg-

hicle on a public highway).

engine off, with cleaning products rec-

ularly.

ommended by the manufacturer (never

Observe the vehicle stopping distances

Your vehicle has been treated with very

use abrasive products). Rinse thor-

when driving on gravelled surfaces to

effective anti-corrosion products. It is

oughly beforehand with a jet:

prevent paint damage.

nevertheless subject to various outside

spots of tree resin and industrial

Repair, or have repaired quickly, areas

influences.

grime;

where the paint has been damaged, to

mud in the wheel arches and under-

prevent corrosion spreading.

Corrosive agents in the atmosphere

neath the body which forms damp

– atmospheric pollution (built-up and

Remember to visit the body shop pe-

patches;

industrial areas);

riodically in order to maintain your an-

bird droppings, which cause a

– saline atmospheres (near the sea,

ti-corrosion warranty. Refer to the

chemical reaction with the paint that

particularly in hot weather);

Maintenance Document.

rapidly discolours paintwork and

– seasonal and damp weather condi-

may even cause the paint to peel

If it is necessary to clean mechani-

tions (e.g. road salt in winter, water

off;

cal components, hinges, etc., spray

from road cleaners, etc.).

wash the vehicle immediately to

them with products approved by our

remove these marks since it is im-

Technical Department to protect them

Minor impacts

possible to remove them by polish-

after they have been cleaned.

ing;

Abrasive action

salt, particularly in the wheel arches

Dust and sand in the air, mud, road grit

and underneath the body after driv-

thrown up by other vehicles, etc.

ing in areas where the roads have

You should take a number of minor pre-

been gritted.

cautions in order to safeguard your ve-

Remove any plant matter (resin, leaves,

hicle against such risks.

etc.) from the vehicle regularly.

We have selected special products

to care for your vehicle and you can

obtain these from the manufactur-

er’s accessory outlets.

4.14

CarManuals2.co

BODYWORK MAINTENANCE (2/3)

What you should not do

Wash the vehicle in bright sunlight or

freezing temperatures.

Degrease or clean using

high-pressure cleaning

Do not scrape off mud or dirt without

equipment or by spray-

pre-wetting.

ing on products not ap-

Allow dirt to accumulate on the exterior.

proved by our Technical

Department:

Allow rust to form following minor im-

mechanical components

(e.g.:

pacts.

engine compartment);

Do not use solvents not approved by

the wheels

(e.g. braking system

our Technical Department to remove

components such as brake calli-

stains as this could damage the paint-

pers);

work.

underbody;

–

parts with hinges (e.g.: inside the

Do not drive in snow or muddy condi-

doors);

tions without washing the vehicle, par-

painted plastic external fittings (e.g.:

ticularly under the wheel arches and

bumpers).

body.

Doing this could give rise to corrosion

or operational faults.

4.15

CarManuals2.co

BODYWORK MAINTENANCE (3/3)

Vehicles with a matte paint

Using a roller type car wash

Cleaning stickers, decorative

finish

Return the wiper stalk to the park posi-

films, etc.

This type of paint requires certain pre-

tion. ➥ 1.141, ➥ 1.145. Check the mount-

You should do the following

cautions.

ing of external accessories, additional

lights and rear view mirrors, and ensure

Use a soft cloth or cotton wool.

You should do the following

that the wiper blades are secured with

Moisten it with soapy water, then

adhesive tape.

always wipe clean with a soft cloth or

Wash the vehicle by hand using plenty

cotton wool.

of water, using a soft cloth or a gentle

Remove the radio aerial mast if your

Finally, carefully dry off with a soft dry

sponge.

vehicle is fitted with this equipment.

cloth.

Check that the fuel filler flap is closed

Do not do the following

then lock the vehicle.

Do not do the following

Use wax-based products (polishing).

Remember to remove the tape and refit

Use alcohol-based cleaning products.

Rub too hard.

the antenna after washing.

Use utensils (e.g. scraper).

Wash the vehicle in a roller-type car

Rub too hard.

wash.

Cleaning the headlights,

Attach stickers to the paintwork (risk of

leaving marks).

sensors and cameras

Wash the area using a

Use a soft cloth or cotton wool. If this

high-pressure clean-

does not clean them properly, moisten

ing device.

Wash the vehicle

the cloth with soapy water, then wipe

using a high-pressure

clean with a soft damp cloth or cotton

cleaning device.

wool.

Finally, carefully dry off with a soft dry

cloth.

Do not use cleaning products con-

taining alcohol or utensils (e.g.: a

scraper).

4.16

CarManuals2.co

INTERIOR TRIM MAINTENANCE (1/2)

A well-maintained vehicle will last

Glass instrument panel

Textiles (seats, door trim, etc)

longer. It is therefore recommended to

(e.g. instrument panel, clock, exterior

Vacuum-clean the textiles regularly.

maintain the interior of the vehicle regu-

temperature display, radio display, etc.)

larly.

Use a soft cloth (or cotton wool).

Liquid stain

A stain should always be dealt with

If this does not clean them properly,

Use soapy water.

swiftly.

use a soft cloth (or cotton wool) slightly

Dab lightly (never rub) with a soft cloth,

moistened with soapy water and then

Whatever type of stain is on the trim,

rinse and remove the excess.

wipe clean with another soft damp cloth

use cold (or warm) soapy water with

or cotton wool.

natural soap.

Solid or pasty stain

Finally, carefully dry off with a soft dry

Detergents (washing-up liquid, pow-

cloth.

Carefully remove the excess solid or

dered products, alcohol-based prod-

pasty material immediately with a

ucts) should not be used.

Do not use products containing alco-

spatula (working from the edges to the

hol and/or spray fluids on the area.

Use a soft cloth.

centre to avoid spreading the stain).

Clean as for a liquid stain.

Rinse and soak up the excess.

Seat belts

Special instructions for sweets or

These must be kept clean.

chewing gum

Multimedia screen

Use products selected by our Technical

Maintenance of the screen may depend

Department

(approved outlets) or

Put an ice cube on the stain to solidify

on the type of multimedia equipment.

warm, soapy water and a sponge and

it, then proceed as for a solid stain.

Please refer to the multimedia instruc-

wipe with a dry cloth.

tions for further information.

Detergents or dyes must not be used

under any circumstances.

For further recommendations for

maintaining the interior, and/or for

any unsatisfactory results, please

see an authorised dealer.

4.17

CarManuals2.co

INTERIOR TRIM MAINTENANCE (2/2)

Removal/replacing removable

You should not:

equipment originally fitted in

Position objects such as deodorants,

the vehicle

scents etc. near air vents as this could

damage your dashboard trim.

If you need to remove equipment in

order to clean the passenger com-

partment (for example, mats), always

ensure that they are correctly refitted

and are the right way around (the driv-

Use high-pressure

er’s mat should be fitted on the driver’s

cleaning equipment or

side etc.) and fit them with the compo-

sprays inside the pas-

nents supplied with the equipment (for

senger compartment:

example, the driver mat should always

be fixed using the pre-fitted mounting

without careful use, this equipment

components).

could impair the correct functioning

With the vehicle stationary, always

of the electrical or electronic compo-

ensure that nothing will impede driving

nents in the vehicle, or have other

(anything obstructing the pedals, heel

detrimental effects.

wedged by the mat etc.).

4.18

CarManuals2.co

Section 5: Practical advice

Puncture, emergency spare wheel

5.2

Tyre inflation kit

5.4

Tools

5.8

Wheel trims - wheel

5.10

Changing a wheel

5.11

Tyres (tyre and wheel safety, use in winter)

5.13

Headlights (changing bulbs)

5.16

Rear lights and side lights (replacing bulbs)

5.18

Interior lighting: changing bulbs

5.22

Remote control key: battery

5.27

“Hands-free” card: battery

5.29

Battery: troubleshooting

5.31

Fitting a radio

5.33

Accessories

5.34

Fuses

5.35

Wiper blades: replacement

5.38

Towing

5.40

Operating faults

5.42

5.1

CarManuals2.co

PUNCTURE, EMERGENCY SPARE WHEEL (1/2)

In case of puncture

If the vehicle is parked on

Depending on the vehicle, either an

the hard shoulder, you must

emergency spare wheel or a tyre infla-

warn other road users of

tion kit is provided ➥ 5.4.

your vehicle’s presence

with a warning triangle or with other

Vehicle fitted with a tyre pressure

devices as per the legislation apply-

loss warning system

ing to the country you are in.

In the event of under-inflation (punc-

tures, under-inflation etc.), the 

warning light appears on the instrument

panel. ➥ 2.31, ➥ 2.37.

Do not leave the tools unse-

Emergency spare wheel 2

cured inside the vehicle as

they may come loose under

This is stored in cage 4 under the floor

braking. After use, make

at the rear of the vehicle.

sure the tools are correctly posi-

tioned in their mountings: not doing

To access the emergency spare

so presents a risk of injury.

wheel

- Open the boot lid;

If bolts are supplied with the emer-

- loosen the nut using the wheel-

gency spare wheel, you must use

brace 1 ➥ 5.8;

these bolts only for the emergency

- unhook the cradle, taking it by the

spare wheel.

handle 3;

The jack is designed for wheel

In some cases (rear puncture, vehi-

- release the emergency spare wheel.

changing purposes only. Under no

cle loaded with towing equipment),

circumstances should it be used for

it is necessary to raise the vehicle

carrying out repairs underneath the

(using the lifting point nearest the

vehicle or to gain access to the un-

wheel concerned) to access to the

derside of the vehicle.

emergency spare wheel ➥ 5.11.

5.2

CarManuals2.co

PUNCTURE, EMERGENCY SPARE WHEEL (2/2)

- attach the handle 3 by moving it

slightly to the left, if necessary, to

find the hook 5;

- tighten the nut using the 1 key to refit

and lock the assembly;

- check that it is correctly locked in

place.

If the emergency spare wheel has been stored for several years, have it

To store the wheel in the cage

checked by your Dealer to ensure that it is safe to use.

– Make sure that you reposition the

Vehicle fitted with an emergency spare wheel that differs from the

wheel 2 correctly in the cage, with

other wheels:

the valve facing downwards;

Never fit more than one emergency spare wheel to the same vehicle.

–

The punctured wheel is wider than the emergency spare wheel, so the height

– position the wheel as far to the right

of the vehicle ground clearance is reduced.

as possible and at the bottom of the

Replace the emergency spare wheel as soon as possible with a wheel identi-

cage 4 (movement A);

cal to the original one.

- ensure that the handle 3 located

When this is fitted to the vehicle, which must only be a temporary measure, the

on the left-hand side is raised and

driving speed must not exceed the speed indicated on the label on the wheel.

mobile;

Fitting an emergency spare wheel may alter the way the vehicle usually runs.

- lift the cage 4 by the handle 3 using

Avoid sudden acceleration or deceleration and reduce your speed when cor-

your left hand, while holding down

nering.

the wheel 2 at the bottom of the cage

If you need to use snow chains, fit the emergency spare wheel to the rear axle

using your right hand;

and check the tyre pressure.

5.3

CarManuals2.co

TYRE INFLATION KIT (1/4)

Do not attempt to use the

The kit is only approved for

inflation kit if the tyre has

inflating the tyres of the ve-

been damaged as a result

hicle originally equipped

of driving with a puncture.

with the kit.

You should therefore carefully check

It must never be used to inflate

the condition of the tyre sidewalls

the tyres of another vehicle, or any

before any operation.

other inflatable object (rubber ring,

rubber boat, etc.).

Driving with underinflated, flat or

punctured tyres can be dangerous

Avoid spillage on skin when han-

and may make the tyre impossible

dling the repair product bottle. If

to repair.

droplets do leak out, rinse them off

with plenty of water.

This repair is temporary.

Keep the repair kit away from chil-

A tyre which has been punctured

dren.

should always be inspected (and re-

paired, where possible) as soon as

Do not dispose of the empty bottle

The kit repairs tyres when

possible by a specialist.

in the countryside. Return it to your

tread A has been dam-

approved dealer or to a recycling or-

aged by objects smaller

When taking a tyre which has been

ganisation.

than 4 mm. It cannot repair

repaired using this kit to be replaced,

all types of puncture, such as cuts

you must inform the specialist.

The bottle has a limited service

larger than 4 mm, or cuts in tyre

life which is indicated on its label.

When driving, vibration may be felt

sidewall B.

Check the expiry date.

due to the presence of the repair

Ensure also that the wheel rim is in

product injected into the tyre.

Contact an approved dealer to re-

good condition.

place the inflation tube and repair

product bottle.

Do not pull out the foreign body

causing the puncture if it is still in

the tyre.

5.4

CarManuals2.co

TYRE INFLATION KIT (2/4)

Note: while the bottle is emptying

(approximately

30 seconds), the

pressure gauge 2 will briefly indicate

a pressure of 6 bar, then the pres-

sure drops;

- Adjust the pressure: to increase it,

continue inflation with the kit. To

reduce it, press the button 1.

Depending on the vehicle, in the event

Engine running, handbrake applied:

of a puncture use the kit located in the

- Disconnect any accessories previ-

storage compartment under the flap C

ously connected to the vehicle’s ac-

at the footwell of the front right-hand

cessories sockets;

seat.

- refer to the information on the in-

flation kit compressor located in

Vehicle fitted with a tyre pressure

the luggage compartment of the ve-

loss warning system

hicle and follow the instructions;

In the event of under-inflation (punc-

- inflate the tyre to the recommended

pressure ➥ 4.10 ;

Before using this kit, park

tures, under-inflation etc.), the 

- after a maximum of 15 minutes, stop

the vehicle at a sufficient

warning light appears on the instrument

inflating and read the pressure (on

distance from traffic, switch

panel. ➥ 2.31, ➥ 2.37.

pressure gauge 2).

on the hazard warning

lights, apply the handbrake, ask all

passengers to leave the vehicle and

keep them away from traffic.

5.5

CarManuals2.co

TYRE PRESSURE KIT (3/4)

Once the tyre is correctly inflated,

remove the kit: unclip the inflation

adapter slowly from the container 3 to

prevent any product spatter and store

the container in plastic packaging to

prevent product leaks.

- Affix the driving recommendation

label (located under the container) to

the dashboard where the driver can

see it.

- Put the kit away.

- At the end of this initial inflation op-

eration, air will still escape from the

Nothing should be placed

tyre. You must drive a short distance

around the driver’s feet

in order to seal the hole.

as such objects may slide

- Start immediately and drive at a

under the pedals during

If a minimum pressure of 1.8 bar is

speed between 12 to 37 mph (20 to

sudden braking manoeuvres and

not reached after 15 minutes, repair

60 km/h) in order to distribute the

obstruct their use.

is not possible; do not drive the ve-

product evenly in the tyre; after driv-

hicle but contact an approved dealer.

ing a distance of 2 miles (3 km), stop

and check the pressure.

- If the pressure is higher than 1.3 bar

but lower than the recommended

pressure (refer to the label affixed to

If the vehicle is parked on

the edge of the driver’s door), adjust

the hard shoulder, you must

it. Otherwise, contact an approved

warn other road users of

dealer: the tyre cannot be repaired.

your vehicle’s presence

with a warning triangle or with other

devices as per the legislation apply-

ing to the country you are in.

5.6

CarManuals2.co

TYRE INFLATION KIT (4/4)

Precautions when using the

kit

The kit should not be operated for more

than 15 consecutive minutes.

The container must be replaced after

the first use even if liquid remains

inside.

Following repair with the kit,

do not travel further than

120 miles (200 km). In addi-

tion, reduce your speed and

under no circumstances exceed

48 mph (80 km/h). The sticker,

which you must affix in a prominent

Please be aware that a

position on the dashboard, reminds

poorly tightened or miss-

you of this.

ing valve cap can make the

Depending on the country or local

tyres less airtight and may

legislation, a tyre repaired with the

lead to pressure loss.

inflation kit may need to be replaced.

Always use valve caps identical to

those fitted originally and tighten

them fully.

5.7

CarManuals2.co

TOOLS (1/2)

Hubcap tool 3

This tool is used to remove the wheel

trims.

Wheel bolt guide 4

To finish loosening or starting to tighten

the wheel bolts.

Tow eye 5

➥ 5.40

Wheelbrace 6

Locks or unlocks the wheel bolts and

Tool kit storage

Jack 2

tow eye 5.

The tool kit 1 is located under the flap at

Fold it correctly before refitting it in its

the footwell of the front right-hand seat.

housing (ensure that the wheelbrace is

correctly positioned).

5.8

CarManuals2.co

TOOLS (2/2)

Do not leave the tools un-

secured inside the vehicle

as they may come loose

under braking. After use,

Jack storage position A

Storage position B in the tool

check that all the tools are correctly

Fold the jack away correctly before

kit 1

clipped into the tool kit, then posi-

storing it in its housing. Make sure that

tion it correctly in its housing: risk of

Reposition the tools in the casing and

the handle is placed correctly in its stor-

injury.

check that the assembly is correctly

age position.

positioned (not doing so may result in

If bolts are supplied with the emer-

noise).

gency spare wheel, you must use

these bolts only for the emergency

spare wheel.

The jack is designed for wheel

changing purposes only. Under no

circumstances should it be used for

carrying out repairs underneath the

vehicle or to gain access to the un-

derside of the vehicle.

5.9

CarManuals2.co

WHEEL TRIMS - WHEEL

Wheel trim with concealed

Wheel trim 3

Central wheel trim with

wheel bolts

visible wheel bolts

Remove using hubcap tool 1 (located in

(Wheel trim 4)

Remove the wheel trim using hubcap

the tool kit) by engaging the hook in the

tool 1 (located in the tool kit) by en-

opening near the edge of the trim.

The bolts are directly accessible.

gaging the hook in the opening near

To refit, position the trim attachments

valve 2.

facing the wheel attachments and

To refit it, align it with valve 2. Push the

press hard in the middle of the trim to

Do not leave the tools un-

retaining hooks in fully, starting with

clip it to the wheel.

secured inside the vehicle

side A near the valve, followed by B

as they may come loose

and C, finishing at D opposite the valve.

under braking. After use,

check that all the tools are correctly

clipped into the tool kit, then position

it correctly in its housing.

Risk of injury.

5.10

CarManuals2.co

CHANGING A WHEEL (1/2)

Vehicles equipped with a jack

Start cranking the jack by hand, posi-

tioning the jack support plate 1 in the

and wheelbrace

slightly indented groove underneath

If necessary, remove the wheel trim.

the vehicle, located between the two

Use the wheelbrace 3 to slacken off the

notches 2.

wheel bolts. Position it so as to be able

Continue to crank the jack so that the

to push from above.

baseplate is correctly positioned

(it

Position the jack 4 horizontally. The jack

should be underneath the vehicle and

head must be positioned at the same

aligned with the jack head).

level as the reinforced panel nearest to

Turn it a few times to lift the wheel off

the wheel concerned.

the ground.

Switch on the hazard warn-

ing lights.

Keep the vehicle away from

traffic and on a level surface

where it will not slip.

Apply the parking brake and engage

a gear (first or reverse gear, or posi-

If the vehicle is parked on

tion P on automatic gearboxes).

the hard shoulder, you must

Ask all the passengers to leave the

warn other road users of

vehicle and keep them away from

your vehicle’s presence

traffic.

with a warning triangle or with other

devices as per the legislation apply-

ing to the country you are in.

5.11

CarManuals2.co

CHANGING A WHEEL (2/2)

Undo the bolts and take off the wheel.

Vehicle fitted with a tyre pressure

loss warning system

Fit the emergency spare wheel on the

central hub and turn it to locate the

In the event of under-inflation (punc-

mounting holes in the wheel and the

tures, under-inflation etc.), the 

hub.

warning light appears on the instrument

Tighten the bolts, checking that the

panel. ➥ 2.31 ➥ 2.37.

wheel is correctly positioned on its hub.

Lower the jack.

With the wheel on the ground, tighten

the bolts fully and have the tightness of

the bolts checked and the emergency

Do not leave the tools un-

spare wheel pressure checked as soon

secured inside the vehicle

as possible.

as they may come loose

under braking. After use,

check that all the tools are correctly

clipped into the tool kit, then posi-

tion it correctly in its housing: risk of

injury.

If bolts are supplied with the emer-

gency spare wheel, you must use

these bolts only for the emergency

spare wheel.

The jack is designed for wheel

changing purposes only. Under no

If you have a puncture, re-

circumstances should it be used for

place the wheel as soon as

carrying out repairs underneath the

possible.

vehicle or to gain access to the un-

A tyre which has been punc-

derside of the vehicle.

tured should always be inspected

(and repaired, where possible) by a

specialist.

5.12

CarManuals2.co

TYRES (1/3)

Tyre and wheel safety

Tyre pressures

The tyres are the only contact between

Adhere to the tyre pressures (including

the vehicle and the road, so it is essen-

the emergency spare wheel). The tyre

tial to keep them in good condition.

pressures should be checked at least

once a month and additionally before

You must make sure that your tyres

any long journey (refer to the label af-

con- form to local road traffic regula-

fixed to the edge of the driver’s door).

tions.

Maintaining the tyres

The tyres must be in good condition

and the tread form must have sufficient

depth; tyres approved by our Technical

Department have wear warning strips 1

Incorrect tyre pressures

which are indicators moulded into

lead to abnormal tyre wear

the tread at several points.

and unusually hot running.

When the tyre tread has been worn

These are factors which

to the level of the warning strips, they

may seriously affect safety and lead

become visible 2: it is then necessary

to:

to replace your tyres because the tread

rubber is now only 1.6 mm deep at

- poor road holding;

most, resulting in poor road holding

- risk of bursting or tread separa-

on wet roads.

tion.

An overloaded vehicle, long journeys

The pressure depends on the load

by motorway, particularly in very hot

Incidents which occur when

and the speed of use. Adjust the

weather, or continual driving on poorly

driving, such as striking the

pressure according to the condi-

surfaced minor roads will lead to more

kerb, may damage the tyres

tions of use (refer to the label affixed

rapid tyre wear and affect safety.

and wheel rims, and could

to the edge of the driver’s door).

also lead to misalignment of the

front or rear axle geometry. In this

case, have the condition of these

checked by an approved dealer.

5.13

CarManuals2.co

TYRES (2/3)

Pressures should be checked when the

Vehicle fitted with a tyre pressure

Fitting new tyres

tyres are cold; ignore higher pressures

loss warning system

which may be reached in hot weather

In the event of under-inflation (punc-

or following a fast journey.

tures, under-inflation etc.), the 

If tyre pressures cannot be checked

warning light appears on the instrument

when the tyres are cold, assume an in-

panel. ➥ 2.31, ➥ 2.37.

crease of 0.2 to 0.3 bar (or 3 PSI).

Never deflate a hot tyre.

Emergency spare wheel

For your safety, please re-

➥ 5.2, ➥ 5.11.

spect the speed limit.

When they need to be re-

Changing wheels around

placed, only tyres of the

same make, size, type and profile

This practice is not recommended.

should be used on a single axle.

They must either have a load ca-

pacity and speed rating at least

equal to those of the original

tyres, or be recommended by an

authorised dealer.

Failure to heed these instructions

could endanger your safety and

Please be aware

that

affect your vehicle’s roadworthi-

poorly tightened or miss-

ness.

ing valve cap can make the

Risk of loss of control of the ve-

tyres less airtight and lead

hicle.

to pressure loss.

Always use valve caps identical to

those fitted originally and tighten

them fully.

5.14

CarManuals2.co

TYRES (3/3)

Use in winter

Snow or Winter tyres

We would recommend that these be

Chains

fitted to all four wheels to ensure that

For safety reasons, fitting snow

your vehicle retains maximum adhe-

chains to the rear axle is strictly for-

sion.

bidden.

Warning: These tyres sometimes have

Chains cannot be fitted to tyres which

a specific direction of rotation and a

are larger than those originally fitted to

maximum speed index which may be

the vehicle.

lower than the maximum speed of your

vehicle.

One-way tyres

Studded tyres

An one-way tyre must only be fitted in

This type of equipment may only be

one direction. You must observe this di-

used for a limited period and as laid

rection.

down by local legislation. It is neces-

If an one-way tyre must be fitted in the

sary to observe the speed specified by

opposite to its direction of rotation fol-

17”

wheels

cannot

current legislation.

lowing a puncture, drive with caution,

fitted with chains.

These tyres must, at a minimum, be

particularly on a wet road, because the

If you wish to fit snow

fitted to the two front wheels.

tyre specifications will not be adapted.

chains, you must use spe-

cial equipment.

Consult an approved dealer

Chains may only be fitted

In all cases, we would recommend

to tyres of the same size

that you contact an approved Dealer

as those originally fitted to

who will be able to advise you on

your vehicle.

the choice of equipment which is

most suitable for your vehicle.

5.15

CarManuals2.co

HEADLIGHTS: changing bulbs (1/2)

To comply with current legislation, or

as a precaution, you can obtain an

emergency kit from your approved

dealer containing a set of spare

bulbs and fuses.

Vehicles with halogen

Main beam headlights

The bulbs are under pres-

sure and can break when

headlights

Remove cover B.

replaced.

Tilt bulb holder 2 to release it and then

Dipped beam headlights

Risk of injury.

replace the bulb.

Remove cover A.

Type of bulb: H7.

Tilt bulb holder 1 to release it and then

Do not touch the bulb glass. Hold it

replace the bulb.

by its base.

Type of bulb: H7.

Please note when work-

It is essential to use anti-U.V. 55W

ing close to the engine that

After replacing the bulb, please ensure

bulbs so as not to damage the plastic

it may be hot. The engine

that the lights are adjusted by a profes-

on the headlights. Mark the bulb’s po-

cooling fan may also start

sional.

sition before removal to ensure correct

positioning when replacing.

at any moment. The 

label

When the bulb has been changed,

in the engine compartment reminds

make sure you refit the cover correctly.

you of this.

Risk of injury.

5.16

CarManuals2.co

HEADLIGHTS: changing bulbs (2/2)

LED front fog lights 8

Please see an authorised dealer.

Before carrying out any op-

eration in the engine com-

partment, you must switch

Daytime running lights, LED front

LED headlights

off the ignition.

side lights 3

Daytime running lights, LED front

Please see an authorised dealer.

side lights 5

LED direction indicator lights 4

Please see an authorised dealer.

LED main beam headlights, dipped

Any operation on (or modi-

beam headlights 6

fication to) the electrical

system must be performed

Please see an authorised dealer.

by an approved dealer

since an incorrect connection might

LED direction indicator lights 7

damage the electrical equipment

Please see an authorised dealer.

(harness, components and in partic-

ular the alternator). In addition, your

Dealer has all the parts required for

fitting these units.

5.17

CarManuals2.co

REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (1/4)

Direction indicator lights,

Release the light assembly from out-

4 Brake light

side the vehicle by pulling towards the

Bulb type 4: P21W or, depending on

reversing lights, fog lights

rear.

the vehicle, PR21W.

and brake lights

Remove the bulb holder 3 by releasing

5 Reversing light

Undo bolt 1 to remove the light.

clips 2.

Bulb type 5: W16W.

6 Indicator light

Refitting

Bulb type 6: PY21W.

To refit, proceed in the reverse order,

7 Fog light

taking care not to damage the wiring,

Bulb type 7: P21W.

and fasten clips 2 on the bulb holder 3.

The bulbs are under pres-

To comply with current legislation, or

sure and can break when

as a precaution, you can obtain an

replaced.

emergency kit from your approved

Risk of injury.

dealer containing a set of spare

bulbs and fuses.

5.18

CarManuals2.co

REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (4/4)

Indicator lights 14

Bulb type: WY5W.

As the door mirror shell needs to be

To refit it, carry out the above opera-

removed, we advise you to have the

tions in reverse order.

bulb replaced by an approved dealer.

Make sure:

To access the bulb:

- that the bulb holder 17 is aligned cor-

- carefully unclip the door mirror

rectly before inserting it into its housing;

shell 15 from its base 16 (movement A);

- that the door mirror shell 15 clips

- disengage the bulb holder 17 using a

properly onto its base 16.

flat-blade screwdriver or similar, lever-

When disassembling and refitting,

ing at C (movement B);

ensure that the wiring and the surround-

- disengage and remove the bulb

ing components are not damaged.

holder 17 then replace the bulb 18.

5.21

CarManuals2.co

INTERIOR LIGHTING: changing bulbs (1/5)

Front ceiling light 1

Refitting

- Unclip the lens 2 (using a tool such

- Clip the lens 2 on to the bulb holder 3;

as a flat screwdriver), positioned

- clip in the interior lights 1 until the unit

at A;

clicks;

- unclip and release the bulb

- ensure that the interior lights are

holder 3 using the tabs 4;

properly positioned and locked into

- remove the bulb concerned.

place.

Type of bulb 5: W5W.

The bulbs are under pres-

sure and can break when

replaced.

Risk of injury.

5.22

CarManuals2.co

INTERIOR LIGHTING: changing bulbs (2/5)

Front map reading lights 6

Refitting

(depending on the vehicle)

- Clip the lens 7 on to the bulb holder 8;

- Unclip the lens 7 (using a tool such

- clip in the reading spots block 6 until

as a flat screwdriver), positioned

the unit clicks;

at B;

- make sure that the reading spots

- unclip and release the bulb

block is correctly positioned and

holder 8 using the tabs 9;

locked into place.

- remove the bulb concerned.

Type of bulb 10: W5W.

5.23

CarManuals2.co

INTERIOR LIGHTING: changing bulbs (3/5)

Rear reading spot 11

Refitting

(depending on the vehicle)

- Clip the lens

12 on to the bulb

- Unclip the lens 12 (using a tool such

holder 13;

as a flat screwdriver), positioned

- clip in the reading spots block 11 until

at C;

the unit clicks;

- unclip and release the bulb

- make sure that the reading spots

holder 13 using the tabs 14;

block is correctly positioned and

- remove the bulb concerned.

locked into place.

Type of bulb 15: W5W.

The bulbs are under pres-

sure and can break when

replaced.

Risk of injury.

5.24

CarManuals2.co

INTERIOR LIGHTING: changing bulbs (5/5)

Luggage compartment

Release the lens 20 and access the

Halogen rear light 22

bulb 21.

light 18

Unclip the ceiling light diffuser using a

Type of bulb 21: W5W.

flat blade screwdriver or similar.

Unclip light 18 (using a flat-blade screw-

driver or similar), by pressing on tab 19

Pull the bulb to remove it from its hous-

to move the light towards the inside of

ing.

the luggage compartment.

Bulb type: W6W

Remove the bulb concerned.

Replace the bulb and refit the lens.

Type of bulb: W5W.

LED rear light 22

Consult an approved dealer.

The bulbs are under pres-

sure and can break when

replaced.

Risk of injury.

5.26

CarManuals2.co

REMOTE CONTROL KEY: BATTERY: battery (1/2)

Replacing the battery

Note: It is not advisable to touch the

electronic circuit in the key cover when

Open the case at slot 1 using a flat-

replacing the battery.

blade screwdriver or similar, and re-

place the battery 2, observing the type

When refitting, ensure that the cover is

and polarity shown on the back of the

correctly clipped on and the screw tight-

cover.

ened.

If they need to be replaced,

be sure to use the same

The batteries are available from ap-

or equivalent type of bat-

proved Dealers, and their service

tery (consult an Approved

life approximately two years.

Dealer).

Check that there is no dye on the

battery: risk of an incorrect electri-

cal contact.

5.27

CarManuals2.co

REMOTE CONTROL KEY: BATTERY: battery (2/2)

Operating faults

If the battery is too weak to ensure cor-

rect operation, you will still be able to

start and lock/unlock the vehicle

➥ 1.29.

Do not throw away your used bat-

Precautions relating to

teries; give them to an organisation

batteries:

responsible for collecting and recy-

- keep (new or used) bat-

cling batteries.

teries out of reach of chil-

dren;

- do not swallow batteries;

When replacing:

Risk of chemical burns which

- make sure that the batter-

may lead to death.

ies are correctly inserted.

- if ingested or inserted into any

part of the body, consult a doctor

Risk of explosion.

as soon as possible.

- if the flap does not close cor-

rectly, do not use and keep out of

reach of children.

5.28

CarManuals2.co

Renault Kangoo (2023 year). Manual in english - page 8
