REVERSING CAMERA (3/4)

Operating faults

When reverse gear is engaged, if the

system detects an operating fault, a

black screen is displayed temporarily

on the multimedia screen 2.

This may be caused by a fault affecting

the camera or screen (clearness, fixed

image, delayed communication etc.).

If the temporary display of the black

screen persists, please consult an ap-

proved dealer.

The screen shows a reverse mirror

image.

Settings

The frames are a representation

While the engine is on, from the multi-

projected on a flat surface. This in-

media screen 2 you can add or remove

formation is to not be taken into ac-

the guides and adjust the camera

count when superimposed on a

image settings (brightness, contrast,

vertical object or an object on the

etc.). Please refer to the multimedia in-

ground.

structions for further information.

Objects which appear on the edge

of the screen may be deformed.

In very bright light (snow, vehicle in

sunshine, etc.), the camera vision

may be adversely affected.

If the luggage compartment is open

or incorrectly closed, the message

“WARNING: Boot Open” appears

on the multimedia screen.

2.133

CarManuals2.co

REVERSING CAMERA (4/4)

H J K

D E

F G

Difference between the

Reversing towards a steep downhill

Reversing towards a protruding

slope

object

estimated distance and

actual distance

The fixed guidelines 5 show the dis-

Position H seems further than position J

tances as further than they actually are.

on the screen. However, position H is at

Reversing towards a steep uphill

the same distance as position K.

Therefore, the objects shown on the

slope

screen are actually closer on the slope.

The trajectory indicated by the fixed

The fixed guidelines 5 show the dis-

and mobile guidelines do not take into

For example, if the screen displays an

tances as closer than they actually are.

account the height of the object. So

object at G, the actual distance of the

there is a risk that the vehicle may col-

The objects shown on the screen are

object is at F.

lide with the object when reversing to-

actually further away on the slope.

wards position K.

For example, if the screen displays an

object at D, the actual distance of the

object is at E.

2.134

CarManuals2.co

ASSISTED PARKING (1/5)

Using ultrasonic detectors as indicated

Switching on

Special features

by the 3 arrows installed in the vehicle

With the engine on, the vehicle sta-

Ensure that the ultrasonic sensors indi-

bumpers, this function helps to find ac-

tionary or driving at less than approxi-

cated by arrows 3 are not obscured (by

cessible parking spaces and assists in

mately 19 mph (30 km/h):

dirt, mud, snow, etc.).

the parking manoeuvre.

- press switch 2. The indicator light in

Remove your hands from the steering

switch 2 lights up and display A ap-

wheel, you only control:

pears on the multimedia screen 1.

- the accelerator pedal;

- set the direction indicator to the side

- the brake pedal;

of the vehicle where you want to

park.

- the gear lever.

At any time, you can regain control by

using the steering wheel.

2.135

CarManuals2.co

ASSISTED PARKING (2/5)

Note: when starting the vehicle, or after

Operation

having successfully completed parallel

parking using the system, the default

Parking

manoeuvre proposed by the system is

As long as the vehicle speed is less

assistance in exiting a parallel parking

than 19 mph (30 km/h), the system

space. In other cases, the default ma-

searches for available parking spaces

noeuvre can be set from the multimedia

on the side of the vehicle chosen by the

screen 1. Please refer to the multime-

driver.

dia instructions for further information.

Note: if parking spaces are available

on the other side of the vehicle, set the

direction indicator to the other direc-

tion to enable the system to search for

spaces.

Once a space has been found, it is dis-

played on the multimedia screen, indi-

Choice of manoeuvre

cated by a small letter “P”. Drive slowly,

with the direction indicator activated on

The system can perform four types of

the side where the space is available,

manoeuvres:

until the “Stop” message is displayed

- parallel parking;

and a beep sounds.

- perpendicular parking;

- angle parking;

- moving out of a parallel parking

space.

From the 1 multimedia screen, select

the manoeuvre to carry out.

The system start up is accompa-

nied by activation of the parking dis-

tance control and, on those vehicles

equipped, the reversing camera to

help the driver visualise the ma-

noeuvre. ➥ 2.123 and ➥ 2.131.

2.136

CarManuals2.co

ASSISTED PARKING (3/5)

The space is then indicated on the mul-

- Release the steering wheel;

timedia screen by a capital letter “P”.

- carry out manoeuvres at the front

- Stop the vehicle;

and rear by following the instructions

shown on the multimedia screen 1

- select reverse gear.

and using the parking distance con-

trol system alerts.

The indicator light



lights up

on the instrument panel and a beep

Your speed should not exceed around 4

sounds.

mph (7 km/h).

- Release the steering wheel;

Once the vehicle is in a position to exit

- follow the instructions shown on the

the parking space, the 

warning

multifunction screen 1.

light disappears from the instrument

Your speed should not exceed around 4

panel and a sound signal and message

mph (7 km/h).

appear on the multimedia screen 1 to

confirm that the manoeuvre is com-

Exiting a parallel parking space

plete.

Once the warning light 

on the

instrument panel goes off and a beep

- Briefly press the 2 switch;

sounds, the manoeuvre has been com-

- Select the

“Exit parallel parking

pleted.

space” mode;

- activate the direction indicator on the

side you wish to go out of;

- press and hold switch 2 (approx. two

seconds).

This function is an addi-

The indicator light



lights up

tional driving aid.

on the instrument panel and a beep

Therefore, it can under no

sounds.

When manoeuvring, the

circumstances replace the

steering wheel may turn

driver’s vigilance and responsibility

quickly: do not put your

during manoeuvres (the driver must

hands inside, and make

always be ready to brake).

sure that nothing is caught inside.

2.137

CarManuals2.co

ASSISTED PARKING (4/5)

The switch warning light 2 goes out,

Cancelling the manoeuvre

The manoeuvre is cancelled in the fol-

the 

warning light disappears

lowing cases:

from the instrument panel and an au-

dible signal confirms that the manoeu-

- the vehicle is too far from the desired

vre has been suspended. The reason

parking space;

for suspending the manoeuvre will be

- the vehicle speed has exceeded 4

displayed on the multimedia screen 1.

mph (7 km/h);

- by pressing switch 2 or by deactivat-

Make sure:

ing from the multimedia screen;

- the vehicle is stationary;

- you have performed more than 14

and

forwards/backwards movements in

- you have released the steering

one manoeuvre;

wheel;

- the parking distance control sensors

and

are dirty or blocked;

- that all doors and the boot are closed;

- a fault in the Park Assist system;

and

- the vehicle wheels have skidded.

Suspending/Resuming the

– that no obstacles are in the way of

the direction of movement;

The 2 switch warning light and the

manoeuvre

and

The manoeuvre is suspended in the fol-



warning light disappear from the

- that the engine is started.

lowing circumstances:

instrument panel and a sound signal

If the warning light on the 2 switch

confirms that the manoeuvre has been

- you take control of the wheel;

flashes, this indicates that the system

cancelled. The reason for cancelling

- the vehicle is stationary for more

is once again available to resume the

the manoeuvre will be displayed on the

than one minute;

manoeuvre.

multimedia screen 1.

- an obstacle in the direction of move-

To resume the manoeuvre, press and

ment prevents the manoeuvre from

hold the 2 switch. The 2 switch warning

being completed;

light appears and 

is displayed

- the engine stops;

on the instrument panel.

- a door or the luggage compartment

Follow the instructions shown on the

is opened.

multimedia screen 1.

2.138

CarManuals2.co

ASSISTED PARKING (5/5)

This function is an additional driving aid. This function is not under any circumstances intended to replace the due care

and attention of the driver, who should at all times be in control of the vehicle. Make sure that the manoeuvre complies

with the applicable traffic regulations in your location.

The driver should always be ready for sudden incidents while driving: always ensure that there are no small, narrow

moving obstacles (such as a child, animal, pushchair, bicycle, stone, post, towing equipment, etc.) in the blind spot when

manoeuvring.

System servicing/repairs

- In the event of an impact, the alignment of the sensors may be changed and their operation may consequently be affected.

Deactivate the function and consult an authorised dealer.

- Any work in the area where the sensors are located (repairs, replacements, exterior trim modifications, etc.) must be carried

out by a qualified professional.

Only an authorised dealer is qualified to service the system.

In the event of system disturbance

Certain conditions may disrupt or impair operation of the system, such as poor weather conditions (snow, hail, ice, etc.).

In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.

Risk of erroneous false alarms.

Limitations of the system operation

- The system cannot detect objects located in the sensor blind spots.

- Always visually check that the parking space proposed by the system is still available and contains no obstacles.

- The system should not be used when towing a trailer or when there is a towing or load carrying system on the vehicle or on

surrounding vehicles.

2.139

CarManuals2.co

VEHICLE WITH OVERSPEED FUNCTION

Special case: if your vehicle is fitted

with the Cruise control/Speed limiter,

fully pressing the accelerator pedal

(beyond the kickdown point) will not

enable you to exceed the overspeed

function set speed. ➥ 2.84.

The vehicle speed may be permanently

set at a fixed value depending on the

vehicle or on local legislation.

To adjust the value or activate/deacti-

vate the function, consult an approved

dealer.

In the event of statutory limits, depend-

ing on the vehicle, this function cannot

be deactivated.

Label 1 attached to the dashboard

The function does not take

shows the speed limit.

the place of the driver.

Under no circumstances

should it replace observa-

In exceptional circumstances (e.g.

tion of speed limits nor vigilance

steep gradient), the overspeed func-

and responsibility on the part of the

tion speed may be exceeded slightly

driver.

as the function does not affect the

braking system.

2.140

CarManuals2.co

EMERGENCY CALL (1/3)

If the vehicle is equipped, the emer-

gency call function can be used to

call the emergency services (without

charge) automatically or manually in

the event of an accident or illness, re-

ducing the time it takes for the emer-

gency services to arrive.

Note: the emergency call operates:

- in countries covered by the associ-

ated telematics emergency services

and infrastructure compatible with

the system;

- depending on the coverage in the

geographical region where the vehi-

cle is being driven.

If you use the emergency call function

System operation warning light:

A call is always made as follows:

to report an accident which you have

- green: operational

witnessed, this implies stopping where

- the call is set up with the emergency

(network available);

traffic conditions allow in order for the

services;

- off: non-operational

emergency services to locate your ve-

(network unavailable);

- send data related to the incident (ve-

hicle and therefore the location of the

- red: operating

hicle identification plate, local time

reported accident.

fault;

of the call, last positions, direction of

In all cases, comply with local legisla-

- green flashing: call in progress.

the vehicle) ;

tion.

Automatic mode warning light;

- voice communication with the emer-

SOS button;

gency services;

Microphone;

In the event of an acci-

- if necessary, emergency assistance

Speaker.

dent, if the location and traf-

is called.

fic conditions permit, stay

Emergency call has two modes:

close to the vehicle in order

to be able answer the call centre

- automatic mode;

Use the emergency call only in the

quickly if necessary.

event of an emergency you are in-

– Manual mode.

volved in, if you witness an accident

or if you feel ill.

2.141

CarManuals2.co

EMERGENCY CALL (2/3)

Automatic mode

In the event of unintended operation, it

is possible to cancel the call by press-

If the automatic mode 2 warning light

ing the 3 button for around two sec-

appears in green this confirms that the

onds, before the call is connected to

automatic system is activated.

the call centre.

The emergency call starts automati-

Once a call is established, only the call

cally in the event of an accident that

centre can end the call.

has required the activation of the pro-

tective equipment (seat belt pretension-

Test mode

ers, airbag etc.).

(depending on local laws)

Test mode is reserved exclusively for

Approved Dealers to check that the

emergency call feature is working prop-

erly.

To activate test mode:

Manual mode

- briefly press the 3 button three times;

The emergency call is carried out by:

- wait approximately 15 seconds;

- pressing and holding the 3 button for

- briefly press the 3 button three times.

at least three seconds;

Exit from test mode is automatic.

- pressing the

3 button five times

within ten seconds.

2.142

CarManuals2.co

EMERGENCY CALL (3/3)

The system operates with a dedi-

cated battery. The battery serv-

ice life is approximately four years

(the 1 warning light lights up in red

Without the emergency call feature,

to warn you when approaching

the system is not trackable and will

expiry).

not be under constant surveillance.

Consult an approved dealer

Data is automatically and constantly

erased, and the system stores only

the last three positions of the vehi-

cle.

To guarantee your safety

and the proper operation of

According to local legislation, data

the system, any operation

is only sent in the event of an emer-

carried out on the battery

gency call. Data sent to the call

Operating faults

(removal, disconnection, etc.) must

centre is treated according to the

In some cases, the emergency call may

be carried out by a qualified special-

personal data protection laws appli-

not work (e.g. low battery).

ist.

cable in the country where you are

located. The system stores activity

When the system detects an operating

Risk of serious burns or electric

history data for 13 hours only.

fault, the 1 warning light turns red for

shocks.

over 30 minutes; consult an Approved

The vehicle owner has the right of

You must respect the replacement

Dealer as soon as possible.

access to their data. They can re-

intervals (without exceeding them)

quest that the data be corrected,

as stated in the maintenance docu-

deleted or locked.

ment.

The battery is a specific type.

Please ensure it is replaced with the

same type.

Call an approved Dealer.

2.143

CarManuals2.co

“VEHICLE DATE CONFIDENTIALITY” MODE (1/2)

Vehicle not fitted with a

Operating faults

multimedia screen

When the system detects an operating

fault, data sharing is deactivated and

The collection of vehicle data may be

the 1 switch warning light is switched

temporarily suspended.

off.

To enable privacy mode:

Please consult an authorised dealer.

- press 1 to enable the privacy mode;

- the 1 switch warning light goes out.

The system does not allow the collec-

tion and downloading of the vehicle

data.

The services will be disabled, except

for the compulsory safety functions re-

lating to the automatic emergency call

Data collection

in the event of an accident ➥ 2.141.

To ensure the operation of connected

To disable privacy mode:

services, your vehicle (during charging

or use, once the driver’s door is opened)

- press 1 again to deactivate the confi-

collects data concerning mainly the ve-

dentiality mode;

Each time the driver’s door is

hicle position and its operation status.

opened, the privacy mode returns to

- the 1 switch warning light comes on.

the last configuration status saved

These data are of a personal nature. In

The system authorises the collection

before the vehicle was locked.

accordance with the regulations in force

and downloading of the vehicle data.

on data protection, they are treated in a

confidential manner with the consent of

the vehicle user.

The manufacturer takes all the nec-

essary precautions to ensure that

your personal data is processed in

total security.

2.144

CarManuals2.co

“VEHICLE DATE CONFIDENTIALITY” MODE (2/2)

Protection of your personal data

Your personal data is collected via your

vehicle and processed by the manu-

facturer, members of its network and

the other entities in the manufacturer’s

group.

For further information on data pro-

cessing conditions and exercising your

rights, please consult the manufactur-

er’s personal data protection policy on

the manufacturer’s website.

Vehicle fitted with a

multimedia screen 2

Please refer to the multimedia instruc-

tions for further information.

2.145

CarManuals2.co

Section 3: Your comfort

Air Vents

3.2

Manual air conditioning, heating system

3.5

Automatic climate control

3.9

Air conditioning: programming

3.13

Air conditioning: information and advice on use

3.15

Multimedia equipment

3.17

Electric windows

3.20

Interior lighting

3.23

Sun visor, mirrors, grab handle

3.25

Passenger compartment storage, fittings

3.26

Accessories socket

3.33

Rear headrests

3.34

Rear seats: functions

3.35

Rear parcel shelf

3.38

Luggage net

3.39

Luggage compartment storage space and fittings

3.41

Transporting objects in the luggage compartment

3.42

Transporting objects: towbar

3.46

Roof bars

3.47

Roof anchorage points

3.49

3.1

CarManuals2.co

AIR VENTS: air outlets (2/3)

Centre air vents 4

Side air vents 2

Air flow

To close: move the cursor 9 towards the

To close: move the cursor 10 towards

outside of the vehicle up to the point of

the inside of the vehicle.

Do not attach any objects to the air

resistance.

To open: move the cursor 10 towards

vents (e.g. telephone mounting).

To open: move the cursor 9 towards the

the outside of the vehicle up to the point

Risk of damage.

inside of the vehicle.

of resistance.

Direction

Move the cursor 9 to the desired posi-

Move the cursor 10 to the desired po-

tion.

sition.

Do not add anything to the

vehicle’s ventilation circuit

(for example, to remove

bad odours).

There is a risk of damage or of

fire.

3.3

CarManuals2.co

MANUAL AIR CONDITIONING, HEATING (1/4)

Adjusting the ventilation

speed

Turn control 3 to one of the eight posi-

tions to adjust the power.

Position OFF

In this position:

- the manual heating and/or air condi-

tioning stops automatically;

- the ventilation speed of air in the

passenger compartment is zero;

- there is, however, a slight flow of air

when the vehicle is moving.

This position should not normally be

The controls

Switching on

used.

1 Adjusting the air temperature.

The heating can be switched on (indi-

cator light off) or off (indicator light on)

2 “Clear View” function.

using button 4.

3 Adjusting the ventilation fan speed.

4 Manual heating and/or air condition-

ing activation control.

5 Passenger compartment air distribu-

tion adjustment.

6 Air recirculation.

7 De-icing/demisting of the rear screen

and, depending on the vehicle, the

door mirrors.

Heating can only be used when the

engine is running.

3.5

CarManuals2.co

MANUAL AIR CONDITIONING, HEATING (2/4)

The air flow is directed towards

the dashboard vents and to-

wards the footwells.

The air flow is mainly directed

to the dashboard air vents.

owards the footwells.

Rear screen de-icing/

demisting

Press the 7 button: the integrated indi-

cator light comes on. This function ena-

bles rapid demisting/de-icing of the rear

screen and the rear view mirrors (on

Adjusting the air temperature

Adjusting the distribution

equipped vehicles).

Turn the control 1 to one of the eight

of air in the passenger

To exit this function, press button 7

positions to set the temperature. The

compartment

again. Demisting automatically stops.

further towards the red the slide is, the

Turn control 5 to choose the distribution

higher the temperature will be. The fur-

option.

ther towards the blue the slide is, the

lower the temperature will be.

All the air is then directed to

the windscreen and front side

window demisting vents.

The air flow is distributed be-



tween front side window de-

misting vents, the windscreen demist-

Recommendations

ing vents and the footwells.

In the event of freezing, manu-

ally de-ice the windscreen using a

Use of the W

position on the 5

scraper rather than the de-icing/de-

control leads automatically to the air

misting function in order to reduce

flowing out in order to prevent the

your energy consumption.

risk of misting on the windscreen.

3.6

CarManuals2.co

MANUAL AIR CONDITIONING, HEATING (3/4)

Prolonged use of air recirculation

can lead to condensation form-

ing on the side windows and wind-

screen, and discomfort due to the

use of non-renewed air in the pas-

senger compartment. We therefore

advise you to return to normal mode

(external air) as soon as the air re-

circulation function is no longer re-

quired, by pressing button 6 again.

Clear View function

Switching the air

Immediate activation of the

recirculation on

heating

Press the 2 button: the integrated indi-

cator light comes on.

Press button 6: the integrated indicator

It is possible to carry out immediate

This system quickly demists and de-

light comes on. In these conditions, air

starting of the air conditioning using a

ices the windscreen and the front side

is taken from the passenger compart-

smartphone application, as long as:

windows. It requires automatic activa-

ment and is recycled, with no air being

- the bonnet is closed;

tion of the heating.

taken from outside the vehicle.

- the traction battery charge level is

To exit this function, select the adjust-

Air recirculation is for:

over 20%;

ment required (distribution, ventilation

- the doors are closed and locked;

- isolating the vehicle from the exter-

speed, temperature, air recirculation).

- the engine is stopped.

nal atmosphere (driving in polluted

areas, etc.).

For further information, please contact

an approved dealer.

Stopping the system

Turn the control 3 to “OFF” to stop the

system.

3.7

CarManuals2.co

MANUAL AIR CONDITIONING, HEATING (4/4)

Electric windscreen



de-icer

(depending on vehicle)

With the engine on, press switch 8

(the built-in warning light comes on).

This function de-ices/demists the wind-

screen (on equipped vehicles).

To exit the function, press the switch 8

again.

Some buttons have an operating

tell-tale which indicates the operat-

ing status.

3.8

CarManuals2.co

AUTOMATIC CLIMATE CONTROL (1/4)

Adjusting the ventilation

speed.

In automatic mode, the system uses

the most suitable amount of air to reach

and maintain the desired comfort level.

You can still adjust the ventilation

speed by turning control 1 to increase

or reduce the ventilation speed.

Adjusting the air temperature

Turn control 3 to obtain the desired

temperature.

Turning the control to the right in-

creases the temperature.

The controls

Automatic mode

(depending on the vehicle)

Special note: the highest and lowest

The automatic climate control system

settings enable the system to produce

Adjusting the ventilation fan speed.

guarantees comfort in the passen-

maximum hot or cold temperature

ger compartment and good visibility

“Clear View” function.

levels (“16.5°C” and “25.5°C”).

(except in the event of extreme condi-

Adjusting the air temperature.

tions), whilst optimising consumption.

Automatic mode.

The system controls the ventilation

speed, air distribution, air recirculation,

Air conditioning control.

and starting and stopping the air condi-

Distribution of air in the passenger

tioning and air temperature.

compartment.

AUTO: allows the selected comfort

Air recirculation.

level to be best attained, depending on

the exterior conditions. Press button 4.

De-icing/demisting of the rear screen

and, depending on the vehicle, the

rear view mirrors.

Any action on a button other than

the AUTO button triggers deactiva-

tion of automatic mode.

3.9

CarManuals2.co

AUTOMATIC CLIMATE CONTROL (2/4)

Clear View function

Press the 2 button: the integrated indi-

cator light comes on.

This function quickly demists and de-

ices the windscreen, the rear screen,

the front side windows, and the exterior

rear view mirrors (depending on the ve-

hicle).

Press button 8 to stop the heated rear

screen operating, and the integrated in-

dicator goes out.

To exit this function, press button 2

or 4.

Adjusting the distribution

The air flow is directed towards



the dashboard air vents, the

of air in the passenger

front footwells and, depending on the

compartment

vehicle, the second row footwells.

Turn control 6. The integrated warning

The air flow is mainly directed

light in the button comes on.



to the dashboard air vents.

All the air is then directed to

the windscreen and front side



owards the footwells.

window demisting vents.

The air flow is distributed be-



tween front side window de-

misting vents, the windscreen demist-

ing vents and the footwells.

Some buttons have an operating

tell-tale which indicates the operat-

ing status.

3.10

CarManuals2.co

AUTOMATIC CLIMATE CONTROL (3/4)

Rear screen de-icing/

Switching air conditioning on

Electric windscreen

demisting

or off



de-icer

(depending on vehicle)

Press button 8 - the integrated indica-

In automatic mode, the system switches

tor light comes on. This function ena-

the air conditioning system on or off,

With the engine on, press switch 9

bles rapid demisting or de-icing of the

depending on the climate conditions.

(the built-in warning light comes on).

rear screen and de-icing of the door

Press the button 5 to force the air con-

This function de-ices/demists the wind-

mirrors (on equipped vehicles).

ditioning to stop. The integrated warn-

screen (on equipped vehicles).

To exit this function, press button 8

ing light will go out.

To exit the function, press switch 9

again. Demisting automatically stops.

again.

Do not open the refriger-

ant fluid circuit. The fluid

may damage eyes or skin.

3.11

CarManuals2.co

AUTOMATIC CLIMATE CONTROL (4/4)

Stopping the system

Turn the control 1 to “OFF” to stop the

system. To start it, turn the control 1

again, then adjust the fan speed or

press the button 4.

Air recirculation (isolation of

Manual use

the passenger compartment)

Press the 7 button: the integrated indi-

cator light comes on.

This function is managed automatically

but you can also activate it manually. In

Prolonged use of this position may lead

this case, the operation is confirmed by

to odours, caused by non-renewal of

a warning light on the button 7.

air, and the formation of condensation

on the windows.

To avoid this, air recirculation is disa-

bled automatically after a certain time.

Electric energy consumption in-

creases when the air conditioning is

being used (switch it off when it is

Using the demisting/de-icing func-

not required).

tion will disable the air recirculation.

3.12

CarManuals2.co

AIR CONDITIONING: programming (1/2)

EV programming

Comfort programme 1

OFF

Ready to 06:00 AM

L M M J V S D

Program

Comfort programme 2

Edit

Ready to 06:00 AM

L M M J V S D

Comfort programme 3

L M M J V S D

Ready to

09:00 AM

L M M J V S D

Charge

Climate

Calendar

With the engine on and the vehi-

On vehicles without automatic air con-

cle stationary, from the multimedia

ditioning, you can activate/deactivate

screen 1 select the “Settings” menu,

the saved programmes.

Driver’s responsibility

the “Vehicle” tab, the “EV program-

Select the time and date 5 for the

when parking or stopping

ming” menu 2 then the “Climate” tab 4.

schedule that you wish to change to

the vehicle

access the settings.

Never leave an animal,

Programming the departure

Programmed times are displayed in

child or adult who is not self-suffi-

area A.

cient alone on your vehicle, even for

time

a short time.

Note: you can program the air condi-

Press “Edit” 3 to access the comfort

tioning using a smartphone application.

In hot and/or sunny weather, please

settings.

Please refer to the multimedia instruc-

remember that the temperature

You may store multiple comfort pro-

tions for further information.

inside the passenger compartment

grams.

increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

3.13

CarManuals2.co

AIR CONDITIONING: programming (2/2)

Note:

Immediate activation of the

- You can deactivate the comfort pro-

air-conditioning

grams by pressing “OFF”;

It is possible to carry out immediate

- the minimum time period between

starting of the air conditioning using a

each programme is two hours;

smartphone application, as long as:

- depending on the vehicle, the se-

- the bonnet is closed;

lected temperature is displayed on

- the traction battery charge level is

the 2 menu.

over 20%;

- the doors are closed and locked;

“Programme” activation

- the engine is stopped.

The function launches before the time

Please refer to the multimedia instruc-

scheduled by the customer, so that the

tions for further information.

vehicle reaches a comfortable temper-

ature by the time they arrive, if:

- the vehicle is connected to the elec-

Stopping the programmed air

trical supply;

conditioning

- the bonnet is closed;

- the traction battery charge level is

The air conditioning stops automati-

Driver’s responsibility

over 20%;

cally around ten minutes after the set

when parking or stopping

- the doors are closed and locked;

end time.

the vehicle

- the engine is stopped.

However, the function can be deacti-

Never leave an animal,

vated if:

Warning light 

comes on the in-

child or adult who is not self-suffi-

- the engine is running;

strument panel.

cient alone on your vehicle, even for

- the charging socket is disconnected;

a short time.

Note: if your vehicle is not connected,

- the traction battery charging level is

your programme is reduced to 10 min-

lower than 20%;

In hot and/or sunny weather, please

utes in order to maintain vehicle range.

- the bonnet is open.

remember that the temperature

inside the passenger compartment

increases very quickly.

RISK OF DEATH OR SERIOUS

INJURY.

3.14

CarManuals2.co

AIR CONDITIONING: information and operating instructions (1/2)

Advice on use

Recommendations to limit energy

Operating faults

consumption and maintain the

In some situations, (air conditioning

As a general rule, contact your ap-

vehicle range

off, air recirculation activated, ventila-

proved dealer in the event of an oper-

tion speed at zero or low, etc.) you may

Drive with the air vents open and the

ating fault.

notice that condensation starts to form

windows closed. If the vehicle has been

- Reduction in de-icing, demisting

on the windows and windscreen.

parked in the sun, open the doors for a

or air conditioning performance.

few moments to let the hot air escape

If there is condensation, use the “Clear

This may be caused by the passen-

before starting the engine.

View” function to remove it, then use

ger compartment filter cartridge be-

the air conditioning in automatic mode

It is preferable, before setting off, to

coming clogged.

to stop it forming again.

use of the programmed air conditioning

- No hot or cold air is being pro-

➥ 3.13.

duced. Check that the controls are

Maintenance

set correctly and that the fuses are

sound. Otherwise, switch off the

Refer to the Maintenance Document

system.

for your vehicle for the inspection fre-

quency.

Presence of water under the

vehicle

Range

After prolonged use of the air condi-

It is normal to notice an increase in

tioning system, it is normal for water

energy usage when the air conditioning

to be present under the vehicle. This is

is operating.

caused by condensation.

Do not open the refriger-

Use the air conditioning system reg-

ant fluid circuit. The fluid

ularly, even in cold weather, running

may damage eyes or skin.

it at least once a month for approxi-

mately 5 minutes.

3.15

CarManuals2.co

AIR CONDITIONING: information and operating instructions (2/2)

Type of refrigerant fluid

Type of oil in the air condi-



tioning circuit

Inflammable product



Consult the driver’s hand-



book

Maintenance



Quantity of refrigerant

x.xxx kg

fluid present in the ve-

The refrigerant fluid circuit (of which

hicle.

some components are hermetically

sealed) may contain fluorinated green-

Global

Warming

house gases.

GWP xxxxx

Potential

(CO2 equi-

Depending on the vehicle, you will find

valent).

Do not open the refriger-

the following information on label A af-

ant circuit. The fluid may

fixed inside the engine compartment.

damage eyes or skin.

CO2 eq

Quantity in weight and

The presence and location of the infor-

x,xxt

in CO2 equivalent.

mation on label A depends on the ve-

hicle.

Before carrying out any

action in the engine com-

partment, you must switch

off the ignition.

➥ 2.2 or

➥ 2.3.

3.16

CarManuals2.co

MULTIMEDIA EQUIPMENT (1/3)

The location and operation of equip-

Multimedia socket 3

Sockets USB 1

ment may vary according to the vehicle.

You can use USB socket to access the

The sockets USB can only allow re-

1 USB sockets;

multimedia content of your accessories.

charge accessories approved by the

2 Multimedia screen;

The various sources can be selected

brand's Technical Services of power

3 Multimedia socket;

from the multimedia screen and from

not exceeding 12 watts (voltage 5 V)

4 Steering column controls;

the steering column controls.

per outlet.

5 Radio.

The USB ports can also be used to re-

charge accessories which have been

approved by our Technical Department

and have a maximum power rating of

12 Watts (5 V) per port.

Connect accessories with a

maximum power of 12 watts

only.

Please refer to the multimedia in-

Fire hazard.

structions for further information.

3.17

CarManuals2.co

MULTIMEDIA EQUIPMENT (2/3)

Steering wheel controls 6

Microphone 9

(depending on the vehicle)

On those vehicles equipped, you can

use the “hands-free” telephone 7 and

voice recognition 8 controls.

Wireless charger - Induction

charging 10

(depending on the vehicle)

➥ 3.26

Using the telephone

We remind you of the need

to conform to the legislation

in force concerning the use

of such equipment.

3.18

CarManuals2.co

MULTIMEDIA EQUIPMENT (3/3)

Telephone holder 11

To place your smartphone in the 12

Note: the holder 12 can be repositioned.

holder:

Use the tightening nut 13 to attach the

On equipped vehicles, open the storage

holder in the desired position.

compartment A and insert the phone

- move the clips 15;

holder into one of the locations 16 while

To remove the telephone holder 11,

- place your smartphone in the phone

pressing the button 14.

open the storage compartment A and

holder 12 while pressing the clips 15;

remove the holder while pressing the

- release the clips so that the smart-

button 14.

phone is held firmly in place.

Make sure that the base of the telephone holder is correctly fitted and that

the telephone is securely held in place in the telephone holder, so that it is

For safety reasons, carry

not thrown onto the occupants during sudden turning or braking.

out any adjustments when

the vehicle is not being

driven.

3.19

CarManuals2.co

ELECTRIC WINDOWS (1/3)

Electric windows

These systems operate with the igni-

tion on or off, until one of the front doors

is opened (limited to about 3 minutes).

Press the switch for the window con-

cerned to lower it to the desired height.

Lift the switch to raise the window to the

desired height.

Driver’s responsibility

From the driver’s seat

Never leave your vehicle

Operate the switches as follows:

with the card or key inside,

with a child, adult who is not

- 1 for the driver’s side;

self-sufficient or a pet in the vehicle,

- 2 for the front passenger side;

even for a short while.

- depending on the vehicle, 3 and 5 for

They may pose a risk to themselves

the rear passengers;

or to others by starting the engine

– 4 to lock the rear windows.

or activating equipment (such as the

gear lever or electric windows).

Safety of rear occupants

If any part of the body becomes

The driver can prevent op-

trapped, reverse the direction of the

eration of the rear elec-

window immediately by pressing the

tric windows by pressing

relevant switch.

switch 4. A confirmation message is

Risk of serious injury.

displayed on the instrument panel.

3.20

CarManuals2.co

ELECTRIC WINDOWS (2/3)

From the front passenger seat

From the rear seats

Half-opening window

Press switch 6.

With the doors closed, press switch 7.

To half-open the window, turn handle 8

in the direction of the arrow, then lock it

by pushing the handle. When closing it,

check that it is properly locked.

Avoid resting any objects against a

half-open window: there is a risk that

the electric window winder could be

damaged.

3.21

CarManuals2.co

ELECTRIC WINDOWS (3/3)

Operating faults

Pressing the switch again while the

window is moving will stop its move-

In case of a fault when closing a

ment.

window, the system reverts to normal

Note: if the window detects resistance

mode: pull the switch concerned up as

when closing (e.g. tree branch etc.), it

often as necessary to fully close the

stops and then lowers again by a few

window (the window will close gradu-

centimetres.

ally), hold the switch (still on the clos-

ing side) for one second then lower and

raise the window fully to reinitialise the

system.

If necessary, contact an approved

Dealer.

One-touch electric window

The one-touch mode works in addition

to the operation of the electric windows

described previously.

It is fitted to the driver’s window.

Briefly press or pull the switch 1 as far

as it will go: the window will be fully

raised or lowered.

When closing the windows,

ensure that no part of the

body (arm, hand, etc.) is

protruding from the vehicle.

Risk of serious injury.

3.22

CarManuals2.co

INTERIOR LIGHTING (1/2)

Courtesy light

Map reading lights

(depending on vehicle)

Pressing switch 1 provides:

Pressing switch 2 provides:

- continuous lighting;

- or temporary lighting by opening one

of the front doors, or by opening one

of the four doors, depending on the

vehicle. The light only goes out when

the doors are correctly closed;

– no lighting.

- no lighting.

Glovebox light 3

Light 3 comes on when the cover is

opened.

3.23

CarManuals2.co

INTERIOR LIGHTING (2/2)

Special features

Depending on the vehicle, remote un-

locking of the doors triggers timed light-

ing of the passenger compartment. If

one of the front or rear doors is opened,

the period for which the light is switched

on will start again.

Then the courtesy light and the luggage

compartment light dim and go out.

The lighting timer will cut out for vari-

ous reasons:

- if a door has been open for 15 min-

utes;

- if all the doors have been closed for

Boot light 4

Rear light

15 seconds or 5 minutes, depending

on the vehicle;

Light 4 comes on when the luggage

Turning the switch 5 gives you:

compartment is opened.

- when the ignition is switched on.

- continuous lighting;

- or temporary lighting, controlled by

opening one of the front doors, or

by opening one of the four doors,

depending on the vehicle. The light

only goes out when the doors are

correctly closed;

– or else the light definitively turned off.

When the doors or luggage com-

partment are unlocked and opened

the courtesy and footwell lights

come on temporarily.

3.24

CarManuals2.co

SUN VISOR, MIRRORS, GRAB HANDLE

Front sun visor

Child minder mirror 4

(depending on the vehicle)

Lower sun visor 2.

The child minder mirror allows you to

keep an eye on your child in the back

Courtesy mirrors

seat. Pull downwards (movement A) to

(depending on the vehicle)

set it to its operating position.

Lift the cover 1.

Front 5 and rear 6 grab

Sun visor storage 3

handles

This can be used for storing motorway

These can be used for support by pas-

tickets, cards, etc.

sengers while the vehicle is moving. Do

not use them for getting into or out of

the vehicle.

When driving, ensure the

courtesy mirror cover is

closed.

Risk of injury.

3.25

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (1/7)

Front door storage pockets 1

Open storage compartment 2

Driver’s dashboard upper

storage compartment A

Press the button 3, place your hand

in areas 4 and lift to open the storage

compartment A.

It is recommended that you open the

storage compartment only when the ve-

hicle is stationary.

Nothing should be placed

on the floor area in front of

Check that the dashboard

the driver as such objects

storage compartment A is

may slide under the pedal

correctly closed before driv-

during braking manoeuvres, thus

ing the vehicle.

obstructing its use.

Risk of the driver’s field of vision

being obstructed if it inadvert-

ently opens.

3.26

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (2/7)

Storage compartment 5

Dashboard storage 7

Storage compartment 8

Centre console storage

compartment/Wireless

charger - Induction

charging 6

For more information on the induction

charging zone, please refer to the mul-

timedia instructions.

Ensure that no hard, heavy

or pointed objects are

placed in the “open” storage

compartments in such a

way that they may fall onto passen-

gers during sudden turning, braking

or in the event of an accident.

3.27

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (3/7)

Cup holders 9

Centre armrest storage

compartment 11

Depending on the vehicle, the cup

holder may be equipped with retaining

Lift the armrest cover 10.

hooks to keep the cup in place.

This can be used to store a mobile ash-

Centre console storage

tray, drink cans, etc.

compartment 12

When turning corners,

accelerating or braking,

ensure that the recepta-

cle being held by the cup

holder is not dislodged.

There is a risk of injury if hot

liquid escapes.

3.28

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (4/7)

Front upper cab storage

Passenger storage drawer 14

compartment 13

If fitted on the vehicle, pull paddle 15 to

Do not use it for getting into or out of the

open.

vehicle and do not hang from it.

Do not place wet items or containers

Glovebox

with liquid in them in the upper cab stor-

If fitted on the vehicle, pull paddle 16 to

age compartment.

open.

Passenger storage

compartment 17

Do not hang any heavy and/

or sharp objects which may

fall whilst driving.

Risk of injury.

3.29

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (5/7)

Sliding side door storage

Storage compartment 19

compartment 18

Pass a hand in location 20 and pull to

Items stored in the sliding side door

open the storage compartment 19.

storage compartments should not stick

out from the storage compartment, so

Rear seat storage pockets 21

as not to hamper the sliding of the door.

Rear parcel shelves 22

Raise them to their horizontal position.

Note: the maximum permissible load

on the parcel shelf is 5 kg, evenly dis-

tributed.

3.30

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (6/7)

Storage compartment 23

To replace the seat, proceed in reverse:

Parcel shelf 24, storage area 25, pen

- lift the bench seat cushion so as to

holder 26 and cup holder 27

under front passenger seat

position the rear section B of the

(depending on the vehicle)

(for vehicles fitted with front bench seat

cushion under the seatback;

for two)

Lower the seatback D ➥ 1.55.

- push down on the front of the cush-

Depending on the vehicle, the cup

To get to it:

ion C so as to lock the seat base.

holder may be equipped with retaining

- pull the front of the bench seat cush-

Check that the bonnet is correctly

hooks to keep the cup in place. This

ion C as far as the stop;

locked.

can be used for storing a mobile ash-

- then, lift the rear section B of the

tray, cup holder, etc.

cushion and pivot the seat base.

When turning corners, accelerating or braking, ensure that the receptacle

being held by the cup holder is not dislodged.

There is a risk of injury if hot liquid escapes.

Maximum load weight allowed in the

storage area 23: 10 kg.

3.31

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (7/7)

Tray 24

To refit the parcel shelf:

Clothes hooks 32

To remove the parcel shelf, press con-

- insert the end 31 of the parcel shelf

Depending on the vehicle, the hooks

trol

28 (movement E) and raise the

into the slot 30;

may be located on the ceiling behind

parcel shelf (movement F).

- press the 28 control (movement E)

the seats.

You can attach documents using the

and place the parcel shelf in the stor-

For safety reasons, these hooks may

clamp 29.

age position;

only be used to hang clothes.

You can attach sticky notes to the dedi-

- release the 28 control.

Note: the maximum permitted load is

cated area on the clamp 29.

4 kg.

Note: make sure that you refit the

parcel shelf properly and remove any

items from the cup holder before rais-

ing the centre seatback. Check that

the back of the centre seat is properly

locked.

3.32

CarManuals2.co

ACCESSORIES SOCKET

Accessories sockets 1, 2, 3, 4

and 5

Depending on the vehicle, they are pro-

vided to connect accessories approved

by our Technical Department.

Connect accessories with

a maximum power of

120 watts (12 V) only.

When several accessory

sockets are used at the same time,

the total power of the connected

accessories must not exceed

180 watts.

Fire hazard.

3.33

CarManuals2.co

REAR HEAD RESTS

To raise it

Storage position 2

When the headrest is set at the

lowest position, this is for storage

Slide it to the required height.

Pull it towards you and lower it com-

only. It should not be in this position

pletely.

when a seat is occupied.

To lower it

Pull it towards you and slide it to the re-

quired height.

To remove it

Raise the headrest then press tabs 1 to

release it.

To refit it

Press tab 1 and insert the rods into the

The headrest is a safety

holes, with the notches facing forwards.

component; check that it is

fitted and in the correct po-

sition.

3.34

CarManuals2.co

REAR SEATS: functions (1/3)

To move the seats forwards

To fold down the seatback

- pull the lever 2 of the seatback that

(flat-floor position)

you wish to fold down and lower it as

or backwards

far as possible.

Lift lever 1 to unlock the seat. Once in

Seatback A or B may be folded down

onto the seat base to create a flat-floor

Make sure the seat is correctly locked

the desired position, release the lever

position:

in position.

and check that the seat is correctly

locked.

- before handling, make sure that the

front seats are far enough forward;

To raise the seatback

- make sure that no devices are con-

Make sure that the seat belt is correctly

nected to the accessories socket 5;

positioned. You must pull the handle 2,

- attach the seat belt to the hook 3 to

then grab the seatback and raise it.

avoid damaging it;

Check that the bonnet is correctly

When moving the rear

- remove the rear headrests 4;

locked.

seats, ensure that nothing

- move the seat backwards to lock it;

obstructs the anchorage

points (passenger’s arm or

For safety reasons, carry

leg, a pet, gravel, cloth, toys, etc.).

out any adjustments when

the vehicle is not being

driven.

3.35

CarManuals2.co

REAR SEATS: functions (2/3)

To access the luggage

Restriction of use

Check that the rear seat

compartment

belts are positioned and op-

It is strictly forbidden to

In some situations (for example, to

erating correctly after each

drive with a rear seat in the

allow access to the luggage compart-

time the rear seats are han-

“tilted” position.

ment), you can tilt the seat A or B:

dled.

- move the seat forwards if necessary;

- lift the handle 6 and guide the seat

forwards until it locks in place.

After use, the seat must be returned to

For safety reasons, carry

its original position. Grab the seatback

out any adjustments when

and fold it down.

the vehicle is not being

driven.

Check that the bonnet is correctly

locked.

Before moving a rear seat forwards, ensure that the seat is not in the flat-floor

position.

3.36

CarManuals2.co

Renault Kangoo E-Tech (2023 year). Manual in english - page 7
