DETECTION OF ROAD SIGNS (4/4)

Operating faults

The system cannot detect the speed

limit if:

- the windscreen is not clean;

- the camera is blinded by the sun;

- there is insufficient visibility (night,

fog etc.) ;

- the signs are not legible (snow, etc.)

or are hidden (by another vehicle or

by trees);

- the information taken from the navi-

gation system is not up to date.

This function is an additional driving aid. This function is not under any

circumstances intended to replace the due care and attention of the

driver, who should at all times be in control of the vehicle.

The driver should always adapt their speed to the traffic conditions, re-

gardless of the system indications.

The system detects speed limit signs and does not detect other signs (e.g. entry/

exit to/from urban areas, etc.).

The system may not detect all speed limit signs or may interpret them incorrectly.

The driver should not ignore signs that are not detected by the system and should,

as a priority, comply with the traffic signage and the highway code.

In the event of poor visibility (fog, snow, frost, etc.), it is possible that the system

may not indicate the correct speed to the driver.

The driver should always adapt their speed to the traffic conditions, regardless of

the system indications.

2.83

CarManuals2.co

SPEED LIMITER (1/4)

The speed limiter function controls the

engine and braking system to help

you not to exceed a driving speed that

you have chosen, known as the limit

speed.

Controls

1 Speed limiter On/Off switch.

2 Cruise control On/Off switch.

3 Switch to activate and decrease the

limit speed (SET/-).

4 Switch to activate and increase the

limit speed or to set the stored limit

speed (RES/+).

5 Speed limiter function standby (with

limited speed memory) (0).

You can link the speed limiter to

the “Road sign detection” function.

➥ 2.80.

2.84

CarManuals2.co

SPEED LIMITER (2/4)

Driving

Switching on

To store the current speed, press

the 4 switch (RES/+) or the 3 switch

When a limit speed has been set but

Press the switch 1. The 6 warning light

(SET/-): the limit speed replaces the

not yet reached, driving is similar to

appears in grey. The “Speed limiter ON”

dashes and, depending on the vehicle,

driving a vehicle without the speed lim-

message appears on the instrument

the 6 warning light appears in white.

iter function.

panel accompanied by dashes to indi-

The minimum stored speed is 19 mph

cate that the speed limiter function is in

Once you have reached the stored

(30 km/h).

operation, waiting to store a limit speed.

speed, no effort on the accelera-

tor pedal will allow you to exceed

the programmed speed except in an

emergency (refer to information on

“Exceeding the limit speed”).

Please note that you must

keep your feet close to the

pedals in order to react in

an emergency.

2.85

CarManuals2.co

SPEED LIMITER (3/4)

Exceeding the limit speed

It is possible to exceed the limit speed

at any time. To do this: press the accel-

erator pedal firmly and fully (beyond

the resistance point).

While the speed is being exceeded, the

speed limiter flashes red on the instru-

ment panel. Then, release the accelera-

Temporarily not available

tor pedal: the speed limiter function will

The system controls accelera-

return as soon as you reach a speed

tion and deceleration of your vehi-

lower than the memorised speed.

cle using the engine and braking

Limited speed cannot be maintained

system. The system activates the

brakes in order to maintain the set

If driving up or down a steep gradient,

speed, the system applies limited

the system is unable to maintain the

braking. In the event of a steep de-

limited speed: the stored speed flashes

Varying the limit speed

scent, for example in a mountainous

red on the instrument panel and a beep

area, you must select a lower gear

The limit speed may be changed by

sounds at regular intervals to inform

to benefit from engine braking.

pressing repeatedly or holding down:

you.

- switch 4 (RES/+) to increase speed;

To reduce the load imposed on the

– switch 3 (SET/-) to reduce speed.

braking system and to prevent the

brakes from overheating, the speed

limiter function may be temporar-

ily interrupted and the message

“Check Speed Limiter” may appear.

The message disappears when the

function becomes available again.

If the speed limiter is not

If the message remains, contact an

available (after several at-

approved dealer.

tempts to activate), contact

an approved dealer.

2.86

CarManuals2.co

SPEED LIMITER (4/4)

Putting the function on

Switching off the function

standby

The speed limiter function is inter-

The speed limiter function is suspended

rupted:

when you press switch 5 (0). The limit

- when you press the 1 switch. In this

speed is stored and displayed in grey

case, the speed is no longer stored;

on the instrument panel.

- when you press the 2 switch. In this

case the cruise control is selected

Recalling the limit speed

and there is no stored speed.

If a speed has been stored, it can be re-

The warning light 6 disappears from

called by pressing the 4 switch.

the instrument panel to confirm that the

When the speed limiter is set to

function is no longer active.

standby, pressing the

3 switch

re-activates the function without

taking into account the memorised

speed: the speed at which the vehi-

cle is moving is taken into account.

2.87

CarManuals2.co

CRUISE CONTROL (1/5)

The cruise control function controls the

engine and braking system to help you

to maintain a driving speed that you

have chosen, known as the cruising

speed.

This cruising speed may be set at any

speed above 19 mph (30 km/h).

This function is an addi-

tional driving aid.

It can under no circum-

stances replace the driver’s

Controls

responsibility to respect speed limits

1 Cruise control On/Off switch.

or to be vigilant.

2 Switch to activate and decrease

The driver must always be in control

cruising speed (SET/-).

of the vehicle.

3 Switch to activate and increase

Cruise control must not be used

cruising speed or to recall the mem-

in heavy traffic, on winding or slip-

orised cruising speed (RES/+).

pery roads (black ice, aquaplan-

ing, gravel) and during bad weather

4 Switch the function to standby (with

(fog, rain, side winds etc.).

cruising speed saved) (0).

There is a risk of accidents.

5 Speed limiter On/Off switch.

You can link the cruise control func-

tion to the “Road sign detection”

function ➥ 2.80.

2.88

CarManuals2.co

CRUISE CONTROL (2/5)

Switching on

Activating cruise control

Driving

Press switch 1.

While the vehicle is moving a steady

Once a cruising speed is registered

speed above approximately 19 mph

and the cruise control function is active,

The 6 warning light appears in grey.

(30 km/h), press the 2 (SET/-) switch

you may lift your foot off the accelera-

The “Cruise control ON” message ap-

or the 3 (RES/+) switch: the function

tor pedal.

pears on the instrument panel accom-

is activated and the current speed is

panied by dashes to indicate that the

taken into account.

cruise control function is in operation

The cruising speed replaces the

and waiting to memorise a cruising

dashes. Cruise control is confirmed

speed.

when the memorised speed and warn-

ing light appear in green 6.

If you try to activate the function below

19 mph (30 km/h), the message “Invalid

Please note that you must

Speed” will be displayed and the func-

keep your feet close to the

tion will remain inactive.

pedals in order to react in

an emergency.

2.89

CarManuals2.co

CRUISE CONTROL (3/5)

Exceeding the cruising speed

The cruising speed may be exceeded

at any time by depressing the accelera-

tor pedal.

While it is being exceeded, the cruising

speed flashes in red on the instrument

panel. Then, release the accelerator

pedal: after a few seconds, the vehicle

Temporarily not available

will automatically return to its set cruis-

The system controls accelera-

ing speed.

tion and deceleration of your vehi-

Cruising speed cannot be

cle using the engine and braking

maintained

system. The system activates the

brakes in order to maintain the set

If driving up or down a steep gradi-

speed, the system applies limited

ent, the system is unable to maintain

braking. In the event of a steep de-

Adjusting the cruising speed

the cruising speed: the stored speed is

scent, for example in a mountainous

flashes red on the instrument panel to

The cruising speed may be changed by

area, you must select a lower gear

inform you of this situation.

pressing the following repeatedly:

to benefit from engine braking.

- the 2 switch (SET/-) to reduce the

To reduce the load imposed on the

speed;

braking system and to prevent the

- the 3 switch (RES/+) to increase the

brakes from overheating, the cruise

speed.

control function may be temporar-

Note: press and hold one of the

ily interrupted and the message

switches to modify speed by succes-

“Check Cruise Control” may appear.

sive increments.

The message disappears when the

function becomes available again.

If the message remains, contact an

If the cruise control is no

approved dealer.

longer available (after sev-

eral attempts to activate

it), contact an Approved

Dealer.

2.90

CarManuals2.co

CRUISE CONTROL (4/5)

Putting the function on

Returning to the cruising speed

NB: if the speed previously stored is

much higher than the current speed,

standby

If a speed is stored, it can be recalled,

the vehicle will accelerate more rapidly

once you are sure that the road condi-

The function is set to standby if you:

to reach this threshold.

tions are suitable (traffic, road surface,

- 4 switch (0);

weather conditions, etc.). Press the

When the cruise control is set to

- the brake pedal;

switch 3 (RES/+) if the vehicle speed is

standby, pressing switch 2 (SET/-) re-

above 19 mph (30 km/h).

activates the cruise control function

- move to the neutral position.

without taking into account the stored

When the speed is stored, cruise con-

The cruising speed is stored and dis-

speed: it is the speed at which the vehi-

trol activation is confirmed by the dis-

played in grey on the instrument panel.

cle is moving that is taken into account.

play in green of the cruising speed and,

depending on the vehicle, the 6 warn-

ing light is displayed.

2.91

CarManuals2.co

CRUISE CONTROL (5/5)

Switching off the function

The warning light 6 disappears from

the instrument panel to confirm that the

The cruise control function is inter-

function is no longer active.

rupted:

- when you press the 1 switch. In this

case, the speed is no longer stored;

- when you press the 5 switch. In this

case the speed limiter is selected

and there is no stored speed.

Putting the cruise control

on standby or switching it

off does not cause a rapid

reduction in speed: you

must brake by depressing the brake

pedal.

2.92

CarManuals2.co

STOP AND GO ADAPTIVE CRUISE CONTROL (1/14)

Based on information from a radar or

According to conditions on the road

This function is an addi-

camera, the Stop and Go adaptive

(traffic, weather, etc.), the Stop and Go

tional driving aid.

cruise control function gives you the

adaptive cruise control function can be

option of maintaining a selected speed,

activated:

It can under no circum-

known as the cruising speed, while

stances replace the driver’s

- from 0 mph (0 km/h) to 84 mph

keeping a safe distance from the vehi-

responsibility to respect speed limits

(135 km/h).

cle in front in the same lane.

or to be vigilant.

The function is indicated by the



Depending on the vehicle, when the

The driver must always be in control

symbol.

“Road sign detection” function is ac-

of the vehicle.

tivated ➥ 2.80, the system can adjust

Note:

The driver must always adapt their

your vehicle’s speed according to the

- the driver must observe the maxi-

speed according to the surround-

speed limit signs recognised by the

mum speed limit and safe distances

ings and traffic conditions.

camera.

in the country where they are driving;

The Stop and Go adaptive cruise

If the vehicle in front stops, the Stop

- the Stop and Go adaptive cruise con-

control must only be used on a mo-

and Go adaptive cruise control may

trol can brake the vehicle up to a third

torway (or multi-lane road separated

brake your vehicle to a complete stop

of the braking capacity. Depending

by a barrier). The cruise control

before setting off again.

on the situation, the driver may need

must not be used in heavy traffic, on

The system controls acceleration and

to brake harder.

winding or slippery roads (black ice,

deceleration of your vehicle using the

aquaplaning, gravel) or during bad

engine and braking system.

weather (fog, rain, side winds etc.).

There is a risk of accidents.

The system’s maximum range is ap-

proximately 150 m. This may vary ac-

cording to the road conditions (ground

relief, weather conditions, etc.).

The Stop and Go adaptive cruise

control does not trigger an emer-

gency stop and its braking capabil-

ity is limited.

2.93

CarManuals2.co

STOP AND GO ADAPTIVE CRUISE CONTROL (2/14)

Location of the camera 1

Controls

6 Cruising speed activation, storage

and decrease switch (SET/-).

Make sure the windscreen is not ob-

3 Safe distance settings

scured (by dirt, mud, snow, condensa-

7 Switch to activate and increase cruis-

4 Switch the function to standby (with

tion etc.).

ing speed or to recall the memorised

cruising speed saved) (0).

cruising speed (RES/+).

5 Stop and Go Adaptive cruise control

Location of the radar 2

main on/off switch



Ensure that the radar area is not ob-

structed

(dirt, mud, snow, a badly

fitted/attached front number plate), im-

pacted, modified (including paintwork)

or hidden by any accessory fitted on the

The radar and camera

front of the vehicle (on the grille or logo

zones must be kept clean

etc.).

and free of any tampering in

You can link the cruise control func-

order to ensure the proper

tion to the “Road sign detection”

operation of the system.

function ➥ 2.80.

2.94

CarManuals2.co

STOP AND GO ADAPTIVE CRUISE CONTROL (3/14)

Switching on

The cruising speed 11 replaces the

dashes and the cruise control function

Press switch 5.

is confirmed by the display of the cruis-

Warning light



appears in grey, and

ing speed in green along with the



the message “Adaptive Cruise Ctl ON”

warning light. If you try to activate the

appears on the instrument panel, ac-

function while the vehicle is moving at

companied by dashes to indicate that

a speed over 84 mph (135 km/h), the

the cruise control function is activated

message “Invalid Speed” is displayed

and waiting to store a cruising speed.

and the function remains deactivated.

Once a cruising speed is memorised

This function cannot be activated when:

and the cruise control function is active,

- the parking brake is applied;

you may lift your foot off the accelera-

- the Park Assist function is already

tor pedal.

activated ➥ 2.135.

If your vehicle speed is lower than

The message “Adaptive Cruise Ctl una-

about 19 mph (30 km/h), the func-

vailable” is displayed on the instrument

tion uses a default cruising speed of

Displays

panel.

19 mph (30 km/h). The vehicle will

Stop and Go adaptive cruise con-

accelerate until it reaches the stored

trol warning light.

cruising speed.

Activating cruise control

Vehicle in front.

When the vehicle is stationary or

Stored safe distance

moving at a steady speed (for all ve-

Stored cruising speed.

hicles), press switch 6 (SET/-) or 7

(RES/+) to activate the function and

store the current speed. The minimum

cruising speed is 19 mph (30 km/h).

Important: you should keep

your feet near the pedals at

all times to prepare for any

event.

2.95

CarManuals2.co

STOP AND GO ADAPTIVE CRUISE CONTROL (4/14)

Safe distance control

activation

As soon as cruise control is activated,

the default safe distance 10 is displayed

in green on the instrument panel. The

default safe distance corresponds to

approximately two seconds (see follow-

ing pages).

If the system detects a vehicle in your

lane, an outline of a vehicle 9 appears

above the distance gauge 10 on the in-

strument panel.

Your vehicle adapts its speed to that

of the vehicle in front and applies the

brakes if necessary (the brake lights

Setting the cruising speed

Adjusting the following

come on) in order to maintain the dis-

tance displayed on the instrument

You can vary the speed by repeatedly

distance

panel.

pressing (for a small variation) or press-

You can vary the safe distance from the

ing and holding (for a larger variation)

vehicle in front at any time by pressing

Note: the size of the 9 outline varies ac-

switch 6 or 7:

switch 3 repeatedly.

cording to the distance separating you

from the vehicle in front. The larger the

- use the “SET/-” switch 6 to reduce

The horizontal distance gauge on the

outline, the closer the vehicle in front.

the speed;

instrument panel indicates the various

- use the “RES/+” switch 7 to increase

available safe distances:

the speed.

- distance gauge A: long distance

(corresponding to approximately

2.4 seconds);

2.96

CarManuals2.co

STOP AND GO ADAPTIVE CRUISE CONTROL (5/14)

Adjusting the following

distance

(continued)

- distance gauge B: intermediate dis-

tance 2 (corresponding to approxi-

mately 2 seconds);

- distance gauge C: intermediate dis-

tance 1 (corresponding to approxi-

mately 1.6 seconds);

- distance gauge D: short distance

(corresponding to approximately

1.2 seconds).

The selected distance gauge appears

in green on the instrument panel. The

other gauges remain in grey.

Exceeding the cruising speed

Then, release the accelerator pedal:

the cruise control and safe distance

Note: the distance must be set accord-

The cruising speed may be exceeded

control will automatically resume the

ing to the traffic level, local regulation

at any time by applying the accelerator

speed and distance instructions that

and weather conditions.

pedal.

you had previously selected.

If it is exceeded, the cruising speed 11

appears in red.

Overtaking manoeuvre

The distance gauge flashes if the dis-

If you wish to overtake the vehicle in

tance between your vehicle and the

front, activating the indicator will tem-

vehicle in front is less than the safe

porarily cancel the safe distance con-

distance selected: the Safe Distance

trol and enable an acceleration speed

Control function is no longer active.

sufficient to complete overtaking.

The safe distance is adjusted by de-

fault on the distance gauge B.

2.97

CarManuals2.co

STOP AND GO ADAPTIVE CRUISE CONTROL (6/14)

Stop and start

Putting the function on

If the vehicle in front slows down, the

standby

system adapts its speed, if necessary

You can set the function to standby

to a complete stop (e.g. in heavy traf-

when:

fic). The vehicle stops a few metres

- you press switch 4 (0);

from the vehicle in front.

- you apply the brake pedal while the

When the vehicle in front sets off again:

vehicle is moving.

- if the stop does not exceed about

The function is deactivated by the

three seconds, the vehicle sets off

system if:

automatically without any action by

the driver;

- you put the gear control in P or N po-

sition;

- if the stop exceeds about three sec-

onds, you must apply the accelera-

- you engage the reverse gear;

tor pedal or press button 7 (RES/+) in

- you unbuckle the driver’s seatbelt;

order for the vehicle to set off again.

In all circumstances, the standby is con-

The message “Press RES/+ or ac-

- you open one of the opening ele-

firmed when the warning lights appear

celerate” appears on the instrument

ments;

in grey and the message “Adaptive

panel to confirm.

- you press the engine start/stop

Cruise Ctl Disconnected” appears on

If the stop exceeds about three min-

button;

the instrument panel.

utes, the electronic parking brake is

- the slope is too steep;

automatically applied and the Stop

- the vehicle speed is above 84 mph

and Go adaptive cruise control is de-

(135 km/h);

activated. The



warning light disap-

pears to confirm that the function is de-

- certain driving aids and correction

Putting the Stop and Go

activated.

devices are triggered (active emer-

adaptive cruise control in

gency braking, ABS, ESC.).

standby or switching it off

does not cause a rapid re-

duction in speed: you must brake

by applying the brake pedal if nec-

essary.

2.98

CarManuals2.co

STOP AND GO ADAPTIVE CRUISE CONTROL (7/14)

Exit from standby

Depending on the situation, the system

sounds a beep associated with:

Based on the stored cruising speed

- the orange alert E if the situation re-

If a speed is stored, it can be recalled,

quires the driver’s attention;

once you are sure that the road con-

ditions are suitable (traffic, road sur-

face, weather conditions, etc.). Press

- the red alert F accompanied by the

switch 7 (RES/+) in the range of con-

message “Brake”, if the situation re-

firmed speeds.

quires the driver’s immediate atten-

When the stored speed is recalled, acti-

tion.

vation of the cruise control is confirmed

In all situations, react accordingly

by the illumination of the cruising speed

and perform the appropriate ma-

in green.

noeuvres.

Note: if the stored speed is higher than

the current speed, the vehicle will ac-

celerate to reach that speed.

“Take control of the vehicle”

Based on the current speed

warnings

When the cruise control is set to

In some situations (e.g. coming upon

standby, pressing switch 6 (SET/-) re-

a much slower vehicle, vehicle in

activates the cruise control function

front changing lanes quickly etc.), the

without taking into account the stored

system may not have time to react.

speed: it is the speed at which the vehi-

cle is moving that is taken into account.

2.99

CarManuals2.co

STOP AND GO ADAPTIVE CRUISE CONTROL (8/14)

If the radar detection area is obstructed

Operating faults

or the radar signal is disrupted, the

If a Stop and Go adaptive cruise control

message “Front radar no visibility” is

function operating fault is detected, the

displayed on the instrument panel and

message “Check Adaptive Cruise con-

the Stop and Go adaptive cruise con-

trol” appears on the instrument panel

trol is interrupted. The green warning

and the Stop and Go adaptive cruise

light



disappears to confirm that the

control function is deactivated.

function has been automatically deac-

tivated.

If an operating fault is detected on one

Ensure that the radar area is not ob-

or more components of the system, the

structed

(dirt, mud, snow, a badly

Stop and Go adaptive cruise control

fitted/attached front number plate), im-

function is deactivated.

pacted, modified (including paintwork)

The

warning light appears on

or hidden by any accessory fitted on the

the instrument panel along with, de-

front of the vehicle (on the grille or logo

pending on the malfunction, one of the

etc.).

following messages:

Switching off the function

Conditions in certain geographical

- “Front camera to check”;

The Stop and Go adaptive cruise con-

areas may hinder the function, for ex-

trol function is deactivated when you

ample:

- “Front radar to check”;

press the 5 switch.

- arid zones, tunnels, long bridges or

- “Camera/Radar to check”;

lightly used roads without road lines,

The warning light



disappears from

- “Check vehicle”.

without signs or trees nearby;

the instrument panel to confirm that the

- a military or airport zone.

Consult an approved dealer.

function is no longer active.

You must leave such areas in order for

the function to work.

Temporary unavailability

In all cases, if the message is not

The radar is able to detect vehicles

erased after the engine is restarted,

in front of your vehicle. The system

please contact an authorised dealer.

cannot operate correctly if the radar de-

tection area is obscured or if its signal

is disrupted.

2.100

CarManuals2.co

STOP AND GO ADAPTIVE CRUISE CONTROL (9/14)

Limitations of system

The system cannot detect:

Detection during cornering

operation

- vehicles arriving at intersections: slip

When entering a corner or bend, the

road (e.g. H) etc;

radar and/or camera may temporarily

Vehicle detection

not be able to detect the vehicle in front

- vehicles driving on the wrong side of

The system detects only vehicles (cars,

(e.g. J).

the road or reversing towards you.

trucks, motorbikes) that are moving in

The system may trigger an accelera-

the same direction as your vehicle.

tion.

A vehicle turning into the same lane

When exiting a bend, the system’s de-

(e.g. G) will be taken into account by

tection of the vehicle in front may be

the system only once it enters the

disrupted or delayed.

camera and radar detection areas.

The system may trigger abrupt or

delayed braking.

The Stop and Go adaptive cruise

control must only be used on a mo-

torway (or multi-lane road with a

central barrier).

2.101

CarManuals2.co

STOP AND GO ADAPTIVE CRUISE CONTROL (10/14)

Detection of vehicles in adjacent

Vehicles hidden due to variations in

- vehicles transporting long objects

lanes

ground relief

which exceed the line;

The system may detect vehicles driving

The system will not detect vehicles

- the actual length of tall vehicles

on an adjacent lane when:

hidden due to variations in ground relief

(e.g. L) outside the radar detection

or those located outside of the camera

area (construction machine, agricul-

- you drive into a bend (e.g. K);

and radar detection areas when driving

tural equipment towing vehicle, etc.)

- you are driving on a road with narrow

uphill or downhill.

;

lanes;

- vehicles insufficiently centred in the

Vehicles outside the camera and

- the speed of the vehicle on the ad-

lane;

radar detection areas.

jacent lane is slower and if one of

- narrow vehicles which are very close

these vehicles is located too close to

The system will react late or not at all

(e.g. M).

the lane of the other.

if the detected vehicles are outside the

camera and radar detection areas, par-

The system may incorrectly trigger

ticularly in the following cases:

vehicle slowing or braking.

2.102

CarManuals2.co

STOP AND GO ADAPTIVE CRUISE CONTROL (11/14)

Stationary and slow moving

- vehicles in front12 which change

vehicles

lane, revealing a stationary vehi-

cle 13 (e.g. P).

When your speed is over approximately

31 mph (50 km/h), the system does

not detect:

- stationary vehicles (e.g N);

- very slow moving vehicles.

When your speed is less than approxi-

Always be ready to take control

mately 31 mph (50 km/h), the system

of your vehicle when you come

may not react or may react very late

upon stationary or very slow

to:

moving vehicles (e.g. N).

- stationary vehicles (e.g N);

The Stop and Go adaptive cruise

- very slow moving vehicles;

control does not trigger an emer-

gency stop and its braking capabil-

ity is limited.

2.103

CarManuals2.co

STOP AND GO ADAPTIVE CRUISE CONTROL (12/14)

Non-detection of fixed obstacles

Detection of vehicles moving into

and objects of a small size

lane at high speed

The system cannot detect:

When your vehicle is overtaken by an-

other vehicle driving at high speed 14

- pedestrians, bikes, scooters, etc. ;

(motorcycle, car, etc.) (e.g. R) and that

- animals;

vehicle temporarily moves in between

- fixed obstacles (toll barriers, walls,

you and the vehicle in front 15, the

etc.) (e.g. Q).

system may trigger undue accelera-

tion, slow down or braking.

These are not taken into account by the

system. They do not trigger any alert or

reaction by the system.

2.104

CarManuals2.co

STOP AND GO ADAPTIVE CRUISE CONTROL (13/14)

This function is an additional driving aid. It can under no circumstances replace the driver’s responsibility to respect

speed limits and safe distances and to be vigilant.

The driver must always be in control of the vehicle.

The driver must always adapt their speed to the surroundings and driving conditions, regardless of system indications.

Except for lines delimiting lanes, traffic indicators (traffic lights, signs, pedestrian crossings etc.) are not recognised by the

system. These do not trigger any alert or reaction by the system.

The system should under no circumstances be taken to be an obstacle detector or an anti-collision system.

Use the adaptive cruise control function Stop and Go only on a motorway (or a dual carriageway divided by a safety

barrier).

System servicing/repairs

- In the event of an impact, the radar and/or camera alignment may be changed and its operation may consequently be af-

fected. Deactivate the system and consult an authorised dealer.

- Any work in the proximity of the radar and/or camera (replacements, repairs, windscreen modifications, paintwork etc.) must

be carried out by a qualified professional.

Only an authorised dealer is qualified to service the system.

Deactivating the function

You must disable the function if:

- the vehicle is travelling on a windy road;

- the vehicle is being towed (breakdowns);

- the vehicle is towing a trailer or a caravan;

- the vehicle is being driven in a tunnel or close to a metallic structure;

- the vehicle arrives at a toll point, a roadwork area or on a narrow lane;

- the vehicle is being driven up or down a very steep slope;

- the visibility is poor (glaring sun, fog etc.);

- the vehicle is being driven on a slippery road surface (rain, snow, gravel, etc.);

- the weather conditions are poor (rain, snow, side winds, etc.);

- the radar area has been damaged (impacts etc.) ;

- the camera area has been damaged (e.g. on the inside or outside of the windscreen);

- the windscreen is cracked or distorted.

In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.

2.105

CarManuals2.co

STOP AND GO ADAPTIVE CRUISE CONTROL (14/14)

In the event of system disturbance

Some conditions can disturb or damage the operation of the system, such as:

- the windscreen or radar area is obscured (by dirt, ice, snow, condensation, number plate etc.);

- a complex environment (tunnel etc.);

- poor weather conditions (snow, heavy rain, hail, black ice, etc.);

- poor visibility (night, fog etc.);

- poor contrast between the vehicle preceding it and the surrounding area (e.g. white vehicle in a snowy area etc.) ;

- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);

- narrow, winding or undulating road (tight bends etc.) ;

- a slower vehicle with a significant difference in speed;

- use of mats not adapted to the vehicle. On the driver’s side, only use mats suitable for the vehicle, attached with the pre-

fitted components, and check the fitting regularly. Do not lay one mat on top of another. There is a risk of wedging the

pedals.

In these cases, the system may wrongly intervene.

Risk of unwanted braking or acceleration.

Many unforeseen situations may affect the system operation. Certain objects or vehicles that can appear in the camera or

radar detection zone may be interpreted by the system incorrectly, possibly leading to inappropriate acceleration or braking.

You should always be attentive to sudden events that might occur while you are driving. Always keep your vehicle

under control by keeping your feet near the pedals, so that you are ready to act in any event.

2.106

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (1/16)

The Motorway and Traffic Assistant is a

The Stop and Go adaptive

The system controls acceleration and

driving aid system designed for use on

deceleration of your vehicle using the

cruise control function

long motorway journeys, where traffic is

engine and braking system.

Based on information from a radar or

flowing or in jams.

The Stop and Go adaptive cruise con-

camera, the Stop and Go adaptive

trol function can be activated from 0 to

Depending on the vehicle, this system

cruise control function gives you the

84 mph (0 to 135 km/h) according to

comprises the adaptive cruise control

option of maintaining a selected speed,

conditions on the road (traffic, weather,

function Stop and Go ➥ 2.93 and the

known as the cruising speed, while

etc.).

“Lane Centring” function.

keeping a safe distance from the vehi-

It is represented by the following symbol

When these two functions are activated

cle in front in the same lane.



➥ 000.

simultaneously, the system allows the

If the vehicle in front stops, the Stop

Note:

driver to:

and Go adaptive cruise control may

- the driver must observe the maxi-

- maintain vehicle speed based on a

brake your vehicle to a complete stop

mum speed limit and safe distances

previously saved speed;

before setting off again.

in the country where they are driving;

- adjust the distance between this ve-

- the Stop and Go adaptive cruise con-

hicle and the vehicle in front;

trol can brake the vehicle up to a third

- direct the vehicle to the centre of the

of the braking capacity. Depending

lane.

on the situation, the driver may need

to brake harder.

Important: you should keep

your feet near the pedals

and your hands on the

The Stop and Go adaptive cruise

steering wheel at all times

control does not trigger an emer-

to prepare for any event.

gency stop and its braking capabil-

ity is limited.

2.107

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (2/16)

The “Lane centring” function

Additional information

Using information from a camera, the

Depending on the vehicle, the

“Lane Centring” function manipulates

“Motorway and Traffic Assistant” func-

the steering system to direct the vehi-

tion may be used with other driving aid

cle to the middle of the lane. This func-

functions.

tion is only available while the Stop and

Please note that:

Go adaptive cruise control is activated

➥ 2.93.

- activating the speed limiter causes

deactivation of the system;

If the conditions allow it, the function is

available between:

- the system cannot be activated when

the “Park Assist” function is active;

- approximately 0 mph (0 km/h) and

84 mph (135 km/h) with a vehicle in

- activation of the

“Lane Centring”

front;

function leads to suspension of the

“Lane Departure Warning” or “Lane

Keep Assist” functions if these have

- 37 mph

(60 km/h) et

84 mph

been activated. They will be reac-

(135 km/h) approximately without a

tivated when the driver decides to

vehicle in front.

stop the “Lane Centring” function.

The “Lane Centring” function is a com-

fort feature. It is represented by the

symbol



Note: in the event of a sharp bend,

the function’s lateral retention capaci-

ties are limited and require the driver to

take immediate action on the steering

wheel.

2.108

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (4/16)

Computer 1

Power-assisted steering 4

Active vehicle control 7

Receives information from the radar

Operates the front wheels to assist the

This system provides information on

and camera to determine the vehicle

trajectory of your vehicle according to

vehicle dynamics to the computer 1

trajectory and speed (acceleration or

details transmitted by the 1 computer.

(speed, lateral acceleration, etc.) and

braking). Amongst other things, it con-

It also enables detection of the driver's

acts on the braking system to control

trols the system activation/deactivation

hands on the steering wheel.

deceleration and to keep the vehicle

parameters (door opening, etc.).

stationary.

Engine computer 5

Camera 2

It controls and directs the engine to

Detects markings on the ground and

carry out the required acceleration.

the position of vehicles on the various

traffic lanes. It complements the infor-

Radar 6

mation transmitted by the 6 radar.

Calculates the distance between your

Make sure the windscreen is not ob-

vehicle and the vehicle in front.

scured (by dirt, mud, snow, etc.).

The system's maximum range is ap-

proximately 150 m. This may vary ac-

Electronic parking brake 3

cording to the road conditions (ground

It the vehicle stationary under certain

relief, weather conditions, etc.)

conditions.

Ensure that the radar area is not ob-

structed (dirt, mud, snow, a badly fitted

front number plate), impacted, modified

(including painting) or hidden by any

accessory fitted on the front of the vehi-

cle (on the grille or logo etc.).

The

radar

and

camera

zones must be kept clean

and free of any tampering in

order to ensure the proper

operation of the system.

2.110

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (6/16)

Controls

Displays on the instrument

Steering wheel 21

Safe distance settings

panel

The driver must always keep their

14 Stop and Go adaptive cruise con-

hands on the steering wheel. If too

Set active functions to standby

trol function warning light

much force is applied when turning the

(with cruising speed saved) (0).



steering wheel, the “Lane Centring”

10 Stop and Go Adaptive cruise con-

15 “Lane Centring” function warning

function is put on standby so the driver

light



trol main stop/start switch



can regain control of the vehicle.

11 “Lane Centring” function activa-

16 Vehicle in front.

Under certain conditions (sharp bends,

tion/deactivation switch



17 Left-hand and right-hand line indi-

etc.) a vibration may be triggered on the

12 Cruising speed activation, stor-

cators.

steering wheel to warn the driver that

age and decrease switch (SET/-).

they must regain control of the vehicle.

Stored safe distance.

13 Switch to activate and increase

If the driver does not handle the steer-

Stored cruising speed.

cruising speed or to recall the

ing wheel (no hands are detected) the

20 “Hands off steering wheel” detec-

“Lane Centring” function is deactivated

memorised cruising speed

tion warning light



after several alerts.

(RES/+).

2.112

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (7/16)

Activating the “Lane

The warning light 15



is displayed

in green and the left-hand and right-

Centring” function

hand line indicators 17 are displayed on

Once the Stop and Go adaptive cruise

the instrument panel to confirm that the

control is activated

➥ 2.93, press

function is activated and directing your

button 11 to activate the “Lane Centring”

vehicle to the centre of the lane.

function. The message “Lane centering

activated” appears on the instrument

Note: if you press button 11 when the

panel accompanied by the 15



Stop and Go adaptive cruise control is

warning light and the



symbol to

not activated, the message: “First acti-

confirm that the function is activated.

vate Adapt. cruise ct” appears on the

instrument panel.

Note: you must keep your hands on

the driving wheel when using the “Lane

Centring” function. The



symbol is

displayed to confirm that the function is

activated.

2.113

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (8/16)

“Lane Centring” function on

- the vehicle speed is over approxi-

mately 84 mph (135 km/h);

standby

- the vehicle speed is below approx-

The “Lane Centring” function is put on

imately 37 mph (60 km/h), without

standby automatically when:

any vehicle in front;

- the Stop and Go adaptive cruise con-

- the vehicle touches or breaches a

trol is put on standby ➥ 2.93;

line;

- the system no longer detects the

- the system is temporarily disrupted

lines or only one line is detected in

(for example: camera obscured by

your lane;

dirt, mud, snow,condensation, etc.).

- the lane is too narrow or too wide;

Certain actions carried out by the driver

- the system does not detect any

also suspend the “Lane Centring” func-

hands on the steering wheel;

tion:

– the bend is too sharp.

- activating the indicators;

Once the conditions are met, the func-

- too much force is used when han-

tion again directs the vehicle to the

dling the steering wheel.

centre of the lane. The 15



warn-

Standby of the function is confirmed by

ing light and left-hand and right-hand

the 15



warning light and the left-

line indicators 17 are displayed in green

hand and right-hand line indicators 17

on the instrument panel.

appearing in grey on the instrument

panel.

Important: you should keep

your feet near the pedals

and your hands on the

steering wheel at all times

You can affect the vehicle trajec-

to prepare for any event.

tory at any point by turning the

steering wheel.

2.114

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (9/16)

Note: in some situations, the Lane

Centring function may no longer detect

your hands on the steering wheel and

may sound a signal:

- the vehicle is moving along a long

straight lane and the driver’s hands

are immobile on the steering wheel;

- the driver is holding the steering

wheel very lightly;

- ...

If the “Lane Centring” function is de-

activated due to the driver’s hands not

being detected on the steering wheel,

the Stop and Go adaptive cruise control

function continues to function.

“Hands off steering wheel”

- after approximately 30 seconds,

the message: “Keep hands on steer-

detection warning

ing wheel” appears on the instrument

When the “Lane Centring” function no

panel 22 and the warning light 20

longer detects your hands on the steer-



appears in red, accompanied

ing wheel, several warning levels will

by an audible signal of gradually in-

be triggered:

creasing volume;

- after

15 seconds, the message:

- after approximately 45 seconds,

Keep hands on steering wheel is

the audio sources go on standby, the

shown in yellow on the instrument

audible signal sounds continually,

panel 22;

the warning light 20



is switched

off and the message “Lane center-

In the first two alert levels, when the

ing deactivated” appears in red on

system again detects the presence

the instrument panel 22: the “Lane

of the driver’s hands on the steering

Centring” function is deactivated.

wheel, the system stops the alerts.

The function continues to direct the

vehicle to the centre of the lane.

2.115

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (10/16)

If the vehicle crosses a line com-

pletely and moves out of lane, the

“Lane Centring” function is put on

standby. Standby of the function is

confirmed by the 15



warning light

and the left-hand and right-hand line in-

dicators 17 appearing in grey on the in-

strument panel.

In the case of a sharp bend

If the driver does not intervene, the

function triggers the vibration of the

In the case of a sharp band, and de-

steering wheel to signal that the vehi-

pending on the vehicle speed, the func-

cle is about to breach a line and that

tion’s side retaining capacities will be

the driver needs to carry out immediate

limited and require the driver to carry

action.

out immediate action on the steering

wheel so that the function can continue

The 15



warning light and the left-

to maintain the vehicle in the centre of

hand or right-hand line indicator 17

the lane.

appear in red on the instrument panel.

2.116

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (11/16)

- the Stop and Go adaptive cruise

control is deactivated ➥ 2.93.

Note: pressing the 10



button

once deactivates both the Stop and

Go adaptive cruise control function

and the “Lane Centring” function;

- the system will no longer detect the

driver’s hands on the steering wheel

for a period over 45 seconds approx-

imately.

The 15



warning light and the left-

hand and right-hand line indicators 17

disappear from the instrument panel.

Deactivating the “Lane

Centring” function

The “Lane Centring” function is deacti-

vated when:

- you press switch 11. The function’s

deactivation is confirmed by the ap-

pearance of the message: “Lane cen-

tering deactivated” on the instrument

panel.

Note: pressing the 11 switch once

deactivates the

“Lane Centring”

function but does not affect operation

of the Stop and Go adaptive cruise

control function;

2.117

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (12/16)

Temporary unavailability

- a military or airport zone.

If a Stop and Go adaptive cruise control

function operating fault is detected, the

The radar is able to detect vehicles

You must leave such areas in order for

message “Check Adaptive Cruise con-

in front of your vehicle. The system

the function to work.

trol” appears on the instrument panel

cannot operate correctly if the radar de-

In all cases, if the message is not

and both the Stop and Go adaptive

tection area is obscured or if its signal

erased after the engine is restarted,

cruise control and Lane Centring func-

is disrupted.

please contact an authorised dealer.

tions are suspended.

If the radar detection area is obstructed

or the radar signal is disrupted, the

Consult an approved dealer.

message “Front radar no visibility” is

Operating faults

If an operating fault is detected on one

displayed on the instrument panel and

If a Lane Centring function operating

or more components of the “Motorway

the Stop and Go adaptive cruise con-

fault is detected, the message “Lane

and Traffic Assistant” system, the

trol is interrupted. The green warning

centering to check” is displayed on the

warning light appears on the in-

light



disappears to confirm that

instrument panel and the function is

strument panel, alongside, depending

the function has been automatically de-

disabled.

on the nature of the fault, the message:

activated.

The Stop and Go adaptive cruise con-

- “Front camera to check”;

Ensure that the radar area is not ob-

trol function remains in operation.

structed (dirt, mud, snow, a badly fitted

- “Front radar to check”;

front number plate), impacted, modified

Consult an approved dealer.

- “Camera/Radar to check”;

(including painting) or hidden by any

accessory fitted on the front of the vehi-

- “Check vehicle”.

cle (on the grille or logo etc.).

The Stop and Go adaptive cruise con-

Conditions in certain geographical

trol function and Lane Centring function

areas may hinder the function, for ex-

are both suspended.

ample:

- arid zones, tunnels, long bridges or

Consult an approved dealer.

lightly used roads without road lines,

without signs or trees nearby;

2.118

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (13/16)

The “Motorway and Traffic Assistant” function is an additional driving aid. This system does not take the place of the

driver.

Therefore, it can under no circumstances replace the driver’s responsibility to respect speed limits and safe distances

and to be vigilant (the driver must always be ready to brake).

The driver must always be in control of the vehicle. The driver must always adapt their trajectory and speed according to the

surroundings and traffic conditions.

The “Motorway and Traffic Assistant” uses the Stop and Go adaptive cruise control function and the Lane Centring function. It

must only be used on a motorway or multi-lane road (separated by a barrier).

It must not be used in heavy traffic, on winding or slippery roads (black ice, aquaplaning, gravel) or during bad weather (fog,

rain, side winds etc.).

There is a risk of accidents.

2.119

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (14/16)

The “Motorway and Traffic Assistant” function is an additional driving aid. it can under no circumstances replace the

driver's responsibility to respect speed limits and safe distances and to be vigilant.

The driver must always be in control of the vehicle.

The driver must always adapt their trajectory and speed according to the surroundings and driving conditions, regard-

less of system indications.

Except for lines delimiting lanes, traffic indicators (traffic lights, traffic signs except for speed limit signs within the limits of the

system’s detection capacity, pedestrian crossings, etc.) are not recognised by the system. These do not trigger any alert or

reaction by the system.

The “Motorway and Traffic Assistant” uses the Stop and Go adaptive cruise control function and the Lane Centring function.

The system should under no circumstances be taken to be an obstacle detector or an anti-collision system.

The Motorway and Traffic Assistant function must only be used on a motorway or multi-lane road separated by a barrier.

System servicing/repairs

- In the event of an impact, the radar and/or camera alignment may be changed and its operation may consequently be af-

fected. Deactivate the system and consult an authorised dealer.

- Any work in the proximity of the radar and/or camera (replacements, repairs, windscreen modifications, paintwork etc.) must

be carried out by a qualified professional.

Only an authorised dealer is qualified to service the system.

2.120

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (15/16)

Deactivating the system

You must deactivate the system if:

- the vehicle is travelling on a windy road;

- the vehicle is being towed (breakdowns);

- the vehicle is towing a trailer or a caravan;

- the vehicle is being driven in a tunnel or close to a metallic structure;

- the vehicle arrives at a toll point, a roadwork area or on a narrow lane;

- the vehicle is being driven up or down a very steep slope;

- the visibility is poor (glaring sun, fog etc.);

- the weather conditions are poor (rain, snow, side winds, etc.);

- the vehicle is being driven on a slippery road surface (rain, snow, gravel, etc.);

- the camera area has been damaged (e.g. interior or exterior windscreen area); the windscreen is cracked or distorted;

- the radar area has been damaged (impacts, etc.) ;

- the surface of the steering wheel is damaged or damp.

In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.

2.121

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (16/16)

Some conditions can disrupt or damage the operation of the system, for example:

- obstruction of the windscreen or the radar area (by dirt, ice, snow, condensation etc.) Frequently check the cleanli-

ness and condition of the windscreen, front wiper blades and front bumper;

- a complex environment (tunnel etc.);

- poor weather conditions (snow, heavy rain, hail, black ice, etc.);

- poor visibility (night, fog etc.);

- poor contrast between the vehicle preceding it and the surrounding area (e.g. white vehicle in a snowy area etc.) ;

- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);

- narrow, winding or undulating road (tight bends etc.);

- the tar lines detected as a line by the system;

- narrowing/widening lanes;

- road markings which are worn, lacking in contrast or very widely spaced from one another (lines partially erased etc);

- multiple markings on the road (roadworks area, slip roads connecting to adjacent motorways, hard shoulder etc.);

- road signs that do not include an arrow, located in a motorway exit;

- an area with low connectivity that makes it impossible to geolocate the vehicle or maps that are not up-to-date;

- a slower vehicle with a significant difference in speed;

- use of mats not adapted to the vehicle. On the driver’s side, only use mats suitable for the vehicle, attached with the pre-

fitted components, and check the fitting regularly. Do not lay one mat on top of another. There is a risk of wedging the

pedals.

In these cases, the system may wrongly intervene.

- Risk of unwanted braking or acceleration.

- Risk of unwanted, incorrect correction or no correction of trajectory.

Many unforeseen situations may affect the system operation. Certain objects or vehicles that can appear in the camera or

radar detection zone may be interpreted by the system incorrectly, possibly leading to inappropriate acceleration or braking.

You should always be attentive to sudden events that might occur while you are driving. Always maintain your vehi-

cle under control by keeping your feet near the pedals and your hands on the steering wheel, so that you are ready

to act in any event.

2.122

CarManuals2.co

PARKING DISTANCE CONTROL (1/8)

Operating principle

This function is an addi-

Ultrasonic sensors fitted in the bumpers

tional aid that uses sound

measure the distance between the ve-

signals to indicate the dis-

hicle and an obstacle.

tance between the vehicle

and an obstacle during reversing.

This measurement is indicated by

beeps which become more frequent the

Under no circumstances should it

closer you come to the obstacle, until

replace the driver’s care or respon-

they become a continuous beep when

sibility whilst reversing.

the vehicle is approximately 30 centi-

The driver should always be ready

metres from the obstacle.

for sudden incidents while driv-

Depending on the vehicle, the system

ing: always ensure that there are

detects obstacles to the front, the rear

no small, narrow moving obstacles

and the sides of the vehicle.

(such as a child, animal, pushchair,

bicycle, stone, post, etc.) in the blind

The parking distance control system

spot when manoeuvring.

is only activated when the vehicle is

Location of the ultrasonic

driven at a speed below approximately

sensors 1

6 mph (10 km/h).

Ensure that the ultrasonic sensors indi-

The function does not take into account

cated by the arrows 1 are not obscured

towing or carrying systems that are not

(by dirt, mud, snow, a badly fitted/at-

recognised by the system.

tached number plate), impacted, mod-

ified (including paintwork) or obstructed

by any accessory fitted to the rear and/

or, depending on the vehicle, to the

front or sides of your vehicle.

2.123

CarManuals2.co

PARKING DISTANCE CONTROL (2/8)

Note: in the event of a change in tra-

jectory during a manoeuvre, the risk of

collision with an obstacle may be sig-

nalled late.

Note: the display 2 shows the vehicle

Operation

surroundings and emits beeps.

Most objects located less near the

It is necessary to travel a few metres

front, rear and sides of the vehicle are

before the side detection is activated.

detected.

If all areas have a grey background, the

Depending on the distance of the ob-

An impact to the under-

whole area around the vehicle is being

stacle, the frequency of the beep will

side of the vehicle while

monitored:

be higher while approaching it, and

manoeuvring

(e.g. strik-

will become a continuous beep around

ing a post, raised kerb or

- A: analysis of the vehicle surround-

20 cm away for obstacles to the sides,

other street furniture) may result in

ings in progress;

and around 30 cm for obstacles to the

damage to the vehicle (e.g. defor-

- B: analysis of the vehicle surround-

mation of an axle).

front or rear. The green, orange (or

ings carried out.

yellow depending on the vehicle) and

To avoid any risk of accident, have

red zones will be shown on the dis-

your vehicle checked by an ap-

play C.

proved dealer.

2.124

CarManuals2.co

PARKING DISTANCE CONTROL (3/8)

If a side obstacle is detected:

- the beeps become faster and then

sound continuously as the obstacle

gets nearer. Green, orange and red

zones will be displayed on the dis-

play D;

- if there is no risk of collision, no beep

will sound when approaching the ob-

stacle. Green, orange and red zones

will be displayed interspersed on the

display D.

Note: in the event of a change in tra-

jectory during a manoeuvre, the risk of

collision with an obstacle may be sig-

nalled late.

Detection of obstacles to the side

Depending on the direction of the

wheels, the system determines the tra-

jectory of the vehicle and notifies the

driver of any risk or otherwise of a col-

lision with an obstacle 3 to the side of

the vehicle.

2.125

CarManuals2.co

PARKING DISTANCE CONTROL (4/8)

Adjustment

Depending on the vehicle, while the

engine is on some settings can be ad-

justed from the multimedia screen 4.

Please refer to the multimedia instruc-

tions for further information.

Parking distance control audio

volume

Adjust the volume of the parking dis-

tance control by pressing + or -.

System sound

Enables the system sound to be

chosen.

Vehicles fitted with a

Deactivating the system sound

multimedia screen

Activate or deactivate the parking dis-

Activation/deactivation

tance control sound.

To activate or deactivate the various

Note: if you deactivate the sound, you

zones covered by the ultrasonic detec-

will no longer be notified with beeps

tors from the multimedia screen 4, refer

when approaching an obstacle.

to the multimedia instructions.

Select “ON” or “OFF”.

When the vehicle is travelling at a

speed below approximately 6 mph

(10 km/h), some noises (motorcy-

When the engine is started, the

cle, lorry, pneumatic drill etc.) may

system recalls the last position

trigger the beeping sound of the

stored before the ignition was

parking distance control.

switched off.

2.126

CarManuals2.co

PARKING DISTANCE CONTROL (5/8)

- press the 8 or 9 control repeatedly

to reach the “PARKING ASSIST”

menu. Press the switch 10 OK;

- select “ON” or “OFF” to activate or

deactivate the function.

If the 6 button cannot be used to re-

activate Park Assist, check that the

function has not been deactivated

on the instrument panel. To reacti-

vate it, please refer to the paragraph

entitled “Special feature on vehicles

Vehicles not fitted with a

Special feature on vehicles fitted

fitted with front, rear and side Park

with front, rear and side Park Assist

multimedia screen

Assist”.

You can also activate/deactivate the

Activation/deactivation

function from the instrument panel:

With the vehicle stopped, press the 6

- with the vehicle stationary, press

An impact to the under-

switch to deactivate parking distance

the 7 switch as many times as re-

side of the vehicle while

control. Warning light 5 in the switch

quired to reach the “Vehicle” tab;

manoeuvring

(e.g. strik-

lights up. Press again on the 6 switch to

ing a post, raised kerb or

- press the 8 or 9 control repeatedly to

activate the function. The indicator light

other street furniture) may result in

reach the “Settings” menu. Press the

built into the 5 switch goes out.

damage to the vehicle (e.g. defor-

switch 10 OK;

mation of an axle).

To avoid any risk of accident, have

your vehicle checked by an ap-

proved dealer.

When the engine is started, the

system recalls the last position

stored before the ignition was

switched off.

2.127

CarManuals2.co

PARKING DISTANCE CONTROL (6/8)

- select “Beep volume” to adjust the

Deactivating the parking

volume of Park Assist using control 8

distance control manually

or 9.

You must disable the function if:

- if towing, carrying or trailer equip-

Automatic deactivation of the

ment that is unrecognised by the

parking distance control

system is present in front of the ul-

The system deactivates:

trasonic sensors;

- when the vehicle speed is above ap-

- in the event of damage to the ultra-

proximately 6 mph (10 km/h);

sonic sensors.

- depending on the vehicle, when the

vehicle is stationary for more than

Operating faults

approximately three seconds and an

When the system detects an operating

obstacle is detected (such as when

fault, a beep sounds for approximately

in a traffic jam etc.);

three seconds each time reverse gear

Adjustment

- when you are in N or P position;

is selected and is accompanied by

- With the vehicle stopped, press the 7

the message “Check parking sensor”

- when an operating fault is detected.

switch as many times as required to

shown on the instrument panel. Consult

reach the “Vehicle” tab;

Note: if the vehicle is fitted with a

an approved dealer.

towbar recognised by the system, only

- press the 8 or 9 control repeatedly to

the rear Park Assist is deactivated.

reach the “Settings” menu. Press the

switch 10 OK;

- press the 8 or 9 control repeatedly

to reach the “PARKING ASSIST”

menu. Press the switch 10 OK;

2.128

CarManuals2.co

PARKING DISTANCE CONTROL (7/8)

System servicing/repairs

- In the event of an impact, the alignment of the sensors may be altered and their operation may consequently be affected.

Deactivate the function and consult an authorised dealer.

- Any work in the area where the sensors are located (repairs, replacements, etc.) must be carried out by a qualified profes-

sional.

Only an authorised dealer is qualified to service the system.

System disturbance

Some conditions can disrupt or damage the operation of the system, for example:

- poor weather conditions (rain, snow, hail, black ice, etc.);

- in the event of exposure to strong electromagnetic waves (under high-voltage lines, etc.);

- some types of noise (motorcycle, lorry, pneumatic drill etc.);

- fitting an unsuitable towing ball or hook.

Risk of false alarms or absence of warnings

In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.

2.129

CarManuals2.co

PARKING DISTANCE CONTROL (8/8)

Limitation of the system operation

- The area around the sensors must be kept clean and free of any modifications in order to ensure the proper operation of the

system.

- Small objects moving close to the vehicle (motorcycles, bicycles, pedestrians, etc.) may not be recognised by the system.

- The system may not detect objects that are too close to the vehicle.

- The system may not provide a warning when the other vehicles or objects are travelling at a significantly different speed.

- During a change in trajectory during a manoeuvre, the system may report obstacles with a delay.

- When the vehicle is towing a trailer, the rear Park Assist system must be deactivated.

Deactivating the function

You must disable the function if:

- the area around the sensors has been damaged;

- the vehicle is equipped with a towing device that is not recognised by the system (ball, hook, adapter, etc.).

2.130

CarManuals2.co

REVERSING CAMERA (1/4)

Operation

Depending on the vehicle, when the re-

verse gear is engaged, the camera 1

located on the tailgate or on the rear

hinged door transmits a view of the sur-

roundings behind the vehicle to:

- the multimedia screen 2, accom-

panied by one or two guidelines 5

and 6 (fixed and moving);

- the rear view mirror 3, accompanied

by a fixed guideline 5;

- the camera rear view system

screen 4, accompanied by a fixed

guideline 5.

2.131

CarManuals2.co

REVERSING CAMERA (2/4)

Fixed clearance gauge 5

6 moving guide line:

The fixed clearance gauge comprises

This is shown in blue and indicates

coloured markers A, B and C indicating

the vehicle trajectory in relation to the

the distance behind the vehicle:

steering wheel position.

- A(red) approximately 30 centimetres

from the vehicle;

Special feature

- B(yellow) approximately 70 centime-

Make sure that the camera is not ob-

tres from the vehicle;

scured (by dirt, mud, snow, condensa-

- C(green) approximately 150 centi-

tion etc.).

metres from the vehicle.

This gauge remains fixed and indicates

the vehicle trajectory if the wheels are

in line with the vehicle.

This system uses several guidelines for

This function is an additional

its operation (mobile for trajectory and

aid. It cannot, therefore,

fixed for distance). When the red zone

under any circumstances

is reached, use the bumper image to

replace the vigilance or the

stop accurately.

responsibility of the driver.

The driver should always be ready

for sudden incidents while driv-

ing: always ensure that there are

no small, narrow moving obstacles

(such as a child, animal, pushchair,

bicycle, stone, post, etc.) in the blind

spot when manoeuvring.

2.132

CarManuals2.co

Renault Kangoo E-Tech (2023 year). Manual in english - page 6
