AIR VENTS, air outlets (2/2)

9

9

1

9

8

4

7

Central 4, side 1 and rear air

Rear seats

vents 8

(depending on vehicle)

Passenger footwell heater outlets 8.

Air flow

To close: move the cursor 9 towards the

outside of the vehicle beyond the resist-

ance point.

To open: move the cursor 9 towards the

inside of the vehicle.

Direction

Do not add anything to the

Move the cursor 9 to the desired posi-

vehicle’s ventilation circuit

tion.

(for example, to remove

bad odours).

Do not attach any objects to the air

vents (e.g. telephone mounting).

There is a risk of damage or of

fire.

Risk of damage.

3.4

CarManuals2.co

MANUAL AIR CONDITIONING, HEATING SYSTEM (1/6)

Distribution of air in the

A

2

3

4

5

passenger compartment

1

6

There are five air distribution options.

Turn control 1 to choose the distribution

option.

The air flow is directed to the

W

windscreen and the front side

window demisting vents.

The air flow is distributed be-



tween front side window de-

misting vents, the windscreen demist-

ing vents and the footwells.

The air flow is directed mainly



towards the footwells.

The A controls

The air flow is directed to-

(depending on vehicle)



wards the dashboard air vents,

1 Distribution of air in the passenger compartment.

the front footwells and, depending on

the vehicle, the second row footwells.

2 De-icing/demisting of the rear screen and, depending on the vehicle, the rear view

mirrors.

The air flow is mainly directed

J

to the dashboard air vents.

3 Adjusting the ventilation fan speed.

4 Air recirculation.

5 Adjusting the air temperature.

6 Air conditioning.

3.5

CarManuals2.co

MANUAL AIR CONDITIONING, HEATING SYSTEM (2/6)

Switching air conditioning on

B

7

6

3

1

or off

5

Activation is not possible if the 3 control

is set to “0" (control A) or "OFF" (con-

trol B).

Press the 6 button to deactivate the air

conditioning. The button’s warning light

will go out.

The air conditioning system is used

for:

- lowering the temperature inside the

passenger compartment;

2

4

- eliminating condensation more

Controls B

quickly.

(depending on the vehicle)

1 Distribution of air in the passenger compartment.

2 De-icing/demisting of the rear screen and, depending on the vehicle, the rear view

mirrors.

3 Adjusting the ventilation fan speed.

4 Air recirculation.

5 Adjusting the air temperature.

6 Air conditioning control.

7 “Clear View” function.

3.6

CarManuals2.co

MANUAL AIR CONDITIONING, HEATING SYSTEM (4/6)

1

3

5

Switching the air

recirculation on

Press button 4: the button’s warning

light comes on. Under these conditions,

air is taken from the passenger com-

partment and is recirculated, with no air

being taken from outside the vehicle.

If the air conditioning is not acti-

Air recirculation is for:

vated (“A/C" warning light on the 6

button goes off), prolonged use of

- isolating the vehicle from the exter-

recirculated air may cause mist to

nal atmosphere (driving in polluted

form on the side windows and wind-

areas, etc.);

screen as well as other problems

- to cool the passenger compartment

due to the presence of non-recircu-

temperature more quickly when air

lated air in the passenger compart-

conditioning is activated.

ment. To avoid this, air recirculation

is disabled automatically after a cer-

tain time.

3.8

CarManuals2.co

MANUAL AIR CONDITIONING, HEATING SYSTEM (5/6)

Adjusting the air temperature

2

3

4

5

Turn control 5 to obtain the desired

temperature. The further towards the

red the slide is, the higher the tempera-

ture will be.

1

When the air conditioning system is

used for long periods, it may begin to

feel cold. To increase the temperature,

turn control 5 to the right.

Adjusting the ventilation

speed

Move the 3 control to adjust the amount

of air blown. If you want to shut off the

flow of air, set the 3 control to “0" (con-

trol A) or "OFF" (controlB).

The system is deactivated: the ventila-

tion speed is zero (vehicle stationary).

You can, however, still feel a slight flow

of air when the vehicle is moving.

Using W

position on the 1 con-

trol will disable the air recirculation

function in order to prevent misting

of the windscreen.

3.9

CarManuals2.co

MANUAL AIR CONDITIONING, HEATING SYSTEM (6/6)

2

3

4

5

1

Rear screen de-icing/

Rapid demisting

demisting

Turn controls 1, 3 and 5 to:

With the engine running, press

- demisting W

;

button 2. The operating tell-tale comes

on.

- the fan speed in position 3 or 4;

This function permits rapid demisting/

- maximum temperature.

de-icing of the rear screen and de-icing

Press the 4 button to deactivate the air

of the door mirrors (on equipped vehi-

recirculation (warning light off).

cles).

To exit this function, press button 2

again. Warning light goes out.

Demisting automatically stops.

3.10

CarManuals2.co

AUTOMATIC CLIMATE CONTROL (1/4)

Adjusting the ventilation

1

2

3

4

5

6

speed.

In automatic mode, the system uses

the most suitable amount of air to reach

and maintain the desired comfort level.

You can still adjust the ventilation

speed by turning control 1 to increase

or reduce the ventilation speed.

Adjusting the air temperature

Turn control 3 to obtain the desired

temperature.

8

7

Turning the control to the

right

in-

creases the temperature.

The controls

Automatic mode

(depending on the vehicle)

The automatic climate control system

1

Adjusting the ventilation fan speed.

guarantees comfort in the passen-

ger compartment and good visibility

2

“Clear View” function.

(except in the event of extreme condi-

3

Adjusting the air temperature.

tions), while optimising consumption.

4

Automatic mode.

The system controls the ventilation

speed, air distribution, air recirculation,

5

Air conditioning control.

and starting and stopping the air condi-

6

Distribution of air in the passenger

tioning and air temperature.

compartment.

AUTO: allows the selected comfort

7

Air recirculation.

level to be best attained, depending on

the exterior conditions. Press button 4.

8

De-icing/demisting of the rear screen

and, depending on the vehicle, the

rear view mirrors.

Any action on a button other than

button AUTO triggers deactivation

of automatic mode.

3.11

CarManuals2.co

AUTOMATIC CLIMATE CONTROL (2/4)

Clear View function

2

4

6

Press the 2 button: the integrated indi-

cator light comes on.

This function quickly demists and de-

ices the windscreen, the rear screen,

the front side windows, and the door

mirrors (depending on the vehicle). It

automatically activates the air condi-

tioning and rear screen de-icing func-

tions.

Press button 8 to stop the heated rear

screen operating, and the integrated in-

dicator goes out.

8

To exit this function, press button 2

or 4.

Adjusting the distribution

The air flow is directed towards



the dashboard air vents, the

of air in the passenger

front footwells and, depending on the

compartment

vehicle, the second row footwells.

Turn control 6. The integrated warning

The air flow is mainly directed

light in the button comes on.



to the dashboard air vents.

All the air is then directed to

W

the windscreen and front side



owards the footwells.

window demisting vents.

The air flow is distributed be-



tween front side window de-

misting vents, the windscreen demist-

ing vents and the footwells.

3.12

CarManuals2.co

AUTOMATIC CLIMATE CONTROL (3/4)

5

8

Rear screen de-icing/

Switching air conditioning on

demisting

or off

Press the 8 button: the integrated in-

In automatic mode, the system switches

dicator light comes on. This function

the air conditioning system on or off,

enables rapid demisting or de-icing of

depending on the climate conditions.

the rear screen and de-icing of the rear

Press the 5 button to deactivate the air

view mirrors (on equipped vehicles).

conditioning. The integrated indicator

To exit this function, press button 8

light goes off.

again. Demisting automatically stops.

3.13

CarManuals2.co

AUTOMATIC CLIMATE CONTROL (4/4)

Stopping the system

1

4

Turn the control 1 to “OFF” to stop the

system. To start it, turn the control 1

again, then adjust the fan speed or

press the button 4.

7

Air recirculation (isolation of

Manual use

the passenger compartment)

Press the 7 button: the integrated indi-

cator light comes on.

This function is managed automatically

but you can also activate it manually. In

Prolonged use of this position may lead

this case, the operation is confirmed by

to odours, caused by non-renewal of

a warning light on the button 7.

air, and the formation of condensation

on the windows.

To avoid this, air recirculation is disa-

bled automatically after a certain time.

Fuel consumption increases when

Using the demisting/de-icing func-

the air conditioning is being used

tion will disable the air recirculation.

(switch it off when it is not required).

3.14

CarManuals2.co

AIR CONDITIONING: information and operating instructions (1/2)

Advice on use

Fuel consumption

Operating faults

In some situations (air conditioning off,

You will normally notice an increase in

As a general rule, contact your ap-

air recirculation activated, ventilation

fuel consumption (especially in town)

proved dealer in the event of an oper-

speed at zero or low etc.), you may

when the air conditioning is operating.

ating fault.

notice that condensation starts to form

For vehicles fitted with air conditioning

- Reduction in de-icing, demisting

on the windows and windscreen.

with no automatic mode, switch off the

or air conditioning performance.

If there is condensation, use the “Clear

system when it is not required.

This may be caused by the passen-

View” function to remove it, then use

ger compartment filter cartridge be-

Advice for reducing consumption

the air conditioning in automatic mode

coming clogged.

and helping to preserve the environ-

to stop it forming again.

ment

- No cold air is being produced.

Check that the controls are set cor-

Drive with the air vents open and the

rectly and that the fuses are sound.

windows closed. If the vehicle has been

Otherwise, switch off the system.

parked in the sun, open the doors for a

few moments to let the hot air escape

before starting the engine.

Presence of water under the

vehicle

Maintenance

After prolonged use of the air condi-

Refer to the Maintenance Document

tioning system, it is normal for water

for your vehicle for the inspection fre-

to be present under the vehicle. This is

quency.

caused by condensation.

Do not add anything to the

vehicle’s ventilation circuit

Do not open the refriger-

(for example, to remove

Use the air conditioning system reg-

ant fluid circuit. The fluid

bad odours).

ularly, even in cold weather, running

may damage eyes or skin.

There is a risk of damage or of

it at least once a month for approxi-

fire.

mately 5 minutes.

3.15

CarManuals2.co

AIR CONDITIONING: information and operating instructions (2/2)

Type of refrigerant fluid

Ñ

A

A

A

Type of oil in the air condi-



tioning circuit

Inflammable product



Consult the driver’s hand-



book

Maintenance



Quantity of refrigerant

x.xxx kg

fluid present in the ve-

hicle.

The refrigerant fluid circuit (of which

some components are hermetically

Global

Warming

sealed) may contain fluorinated green-

GWP xxxxx

Potential (CO2 equiv-

house gases.

alent).

Depending on the vehicle, you will find

Do not open the refriger-

the following information on label A af-

ant circuit. The fluid may

CO2 eq

Quantity in weight and

fixed inside the engine compartment.

damage eyes or skin.

x.xx t

in CO2 equivalent.

The presence and location of the infor-

mation on label A depends on the ve-

hicle.

Before carrying out any

action in the engine com-

partment, you must switch

off the ignition.

➥ 2.4 or

➥ 2.6.

3.16

CarManuals2.co

MULTIMEDIA EQUIPMENT (1/3)

A

B

1

C

1

5

4

4

4

2

2

3

3

3

Multimedia system A, B or

Multimedia sockets 2

The sockets USB can also be used to

recharge accessories with a maximum

radio C

You can use the USB sockets to access

power rating of 12 Watts (5 Volts) per

The location and operation of equip-

the multimedia content of your acces-

socket, which have been approved by

ment may vary according to the vehicle.

sories and to update the system.

our Technical Department.

1 Multimedia screen;

The various sources can be selected

The JACK socket enables the radio to

2 Multimedia sockets;

using the multimedia screen or the

be used with an auxiliary cable.

3 Steering column controls;

radio and the steering column controls.

4 Steering wheel controls;

5 Radio.

Connect accessories with a

maximum power of 12 watts

only.

Please refer to the multimedia in-

Fire hazard.

structions for further information.

3.17

CarManuals2.co

MULTIMEDIA EQUIPMENT (2/3)

8

4

6

7

Steering column controls 4

Microphone 8

You can use the hands-free telephone 6

and voice recognition 7 controls on ve-

hicles fitted with these.

3.18

CarManuals2.co

MULTIMEDIA EQUIPMENT (3/3)

9

9

Wireless charger 9

(depending on the vehicle)

➥ 3.29

Using the telephone

We remind you of the need

to conform to the legislation

in force concerning the use

of such equipment.

3.19

CarManuals2.co

ELECTRIC WINDOWS (1/2)

These systems operate with the igni-

tion on or off, until one of the front doors

is opened (limited to about 3 minutes).

1

5

6

Driver’s responsibility

2

Never leave your vehicle

with the card or key inside,

4

3

with a child, adult who is not

self-sufficient or a pet in the vehicle,

even for a short while.

They may pose a risk to themselves

One-touch electric windows

or to others by starting the engine

Avoid resting any objects against

Briefly press or pull a window switch

or activating equipment (such as the

a half-open window: there is a risk

as far as it will go: the window will be

gear lever or electric windows).

that the electric window could be

raised or lowered fully. Pressing the

If any part of the body becomes

switch again stops the window moving.

damaged.

trapped, reverse the direction of the

Note: the rear windows do not open

window immediately by pressing the

fully

relevant switch.

From the driver’s seat, use switch:

Passenger safety

1

for the driver’s side;

Risk of serious injury.

The driver can prevent the

2

for the front passenger side;

front and rear passenger

3

and 5 for the rear passengers.

electric windows from op-

From the passenger seats, use

erating (and the driver’s window)

switch 6.

by pressing switch 4. A confirmation

message is displayed on the instru-

ment panel.

3.20

CarManuals2.co

ELECTRIC SUNROOF (1/3)

1

Driver’s responsibility

Never leave an animal,

child or non-autonomous

adult alone in your vehicle,

even for a short time.

B

A

C

2

The reason for this is that the child

D

may endanger himself or others by

0

starting the engine, activating equip-

ment such as the window winders

4

for example, or locking the doors.

3

If something gets trapped, reverse

the direction of travel as soon as

possible by turning button 4 fully to

the right (position D).

To slide the curtain 1

To slide the sunroof

Risk of serious injury.

- To open: push the handle 2 rear-

- To tilt: move the marked position 3

wards to move the blind to the de-

to position A;

sired position;

- to open: move the marked posi-

- to close: pull the handle 2 forwards

tion 3 to position B, C or Ddepending

to move the blind to the desired posi-

on the type of opening required;

tion.

- to close: move the marked posi-

tion 3 to position 0.

If the vehicle is equipped

with this function, this action

will activate deadlocking.

➥ 1.5 or ➥ 1.9.

Check that there is no-one still

inside the vehicle

3.22

CarManuals2.co

ELECTRIC SUNROOF (2/3)

Closing the sunroof by

remote control

If you press the locking button on the

card twice in quick succession, the

windows and sunroof will close auto-

matically.

It is recommended that the user only

A B C

operates the system when the vehi-

0

D

cle can be seen clearly and no one is

inside.

4

3

Special features

Your vehicle is fitted with an anti-pinch

facility: when the sunroof encounters

resistance whilst closing

(branch of

a tree, etc.), it stops and then moves

back a few centimetres.

After closing the sunroof by remote

control, pressing button 4 allows the

sunroof to return to its previous posi-

tion.

If the vehicle is equipped

When closing the sunroof,

with this function, this action

The sunroof will not open when the

ensure that no part of the

will activate deadlocking.

temperature is below -20°C. However,

body (arm, hand, etc.) is

➥ 1.5 or ➥ 1.9.

it will still close.

protruding from the vehicle.

Check that there is no-one still

Risk of serious injury.

inside the vehicle

3.23

CarManuals2.co

ELECTRIC SUNROOF (3/3)

Precautions during use

-

Vehicle with loaded roof bars.

As a general rule, if there is a load

on the roof, use of the sunroof is not

recommended.

B

Before using the sunroof, check the

A

C

objects and/or accessories

(bike

0

D

racks, roof boxes, etc.) attached to

the roof bars: they should be prop-

Driver’s responsibility

erly arranged and secured and

Never leave an animal,

4

should not interfere with the opera-

3

child or non-autonomous

tion of the sunroof.

adult alone in your vehicle,

Contact an approved dealer for de-

even for a short time.

tails of possible conversions;

The reason for this is that the child

Operating faults

-

check that the sunroof is properly

may endanger himself or others by

closed before leaving your vehicle;

starting the engine, activating equip-

If the sunroof will not close, move the

ment such as the window winders

marked position 3 to position 0 then

-

clean the seal every three months

for example, or locking the doors.

press button 4 until the sunroof is com-

using products recommended by our

pletely closed: consult an approved

Technical Department;

If something gets trapped, reverse

dealer.

the direction of travel as soon as

-

do not open the sunroof immedi-

possible by turning button 4 fully to

ately after it has rained or immedi-

the right (position D).

ately after washing the vehicle.

Risk of serious injury.

Important: during this operation, the

sunroof anti-pinch function is de-

activated. Contact your approved

Dealer as soon as possible;

3.24

CarManuals2.co

SUN VISOR

2

1

3

Front sun visor

Lower sun visor 1.

Courtesy mirrors

(depending on the vehicle)

Lift the cover 2. The light 3 switches on

automatically.

When driving, ensure the

courtesy mirror cover is

closed.

Risk of injury.

3.25

CarManuals2.co

INTERIOR LIGHTING (1/3)

1

2

2

3

3

A

B

C

Courtesy light A

Reading lights B or C

Press switch 1 for:

Press the 2 switch for the driver, 3

switch for the front passenger, for per-

- permanent lighting;

manent lighting.

- lighting controlled by the unlocking of

Note: on vehicles fitted with a multime-

the vehicle or by opening one of the

dia screen, you can use the multime-

doors. This switches off after a time

dia screen to deactivate/activate the

delay, once the doors concerned

reading lights which switch on when

have been closed correctly;

the doors or luggage compartment are

– lighting switches off immediately.

opened. ➥ 1.83.

3.26

CarManuals2.co

INTERIOR LIGHTING (2/3)

D

E

4

5

6

7

Courtesy light D

Map reading lights E

Press switch 4 for:

Press switch 5 6 or 7 for constant light-

ing

- permanent lighting;

Note: on vehicles fitted with a multime-

- lighting controlled by the unlocking of

dia screen, you can use the multime-

the vehicle or by opening one of the

dia screen to deactivate/activate the

doors. This switches off after a time

reading lights which switch on when

delay, once the doors concerned

the doors or luggage compartment are

have been closed correctly;

opened. ➥ 1.83.

- lighting switches off immediately.

3.27

CarManuals2.co

INTERIOR LIGHTING (3/3)

9

8

8

Glove box light

Luggage compartment light

Depending on the vehicle, the 8 light

Light 9 comes on when the luggage

switches on when the cover is opened.

compartment is opened.

Unlocking and opening the doors or

tailgate switches on the timed cour-

tesy lights and lights.

3.28

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (1/4)

2

3

1

Front door storage pockets 1

Sun blind storage

Centre console storage

compartment 2

compartment/induction

They can hold a 1.5-litre bottle.

charging zone 3

This can be used for storing motorway

tickets, cards, etc.

For more information on the induction

charging zone, please refer to the mul-

timedia instructions.

Nothing should be placed

Ensure that no hard, heavy

on the floor area in front of

or pointed objects are

the driver as such objects

placed in the “open” storage

may slide under the pedal

compartments in such a

during braking manoeuvres, thus

way that they may fall onto passen-

obstructing its use.

gers during sudden turning, braking

or in the event of an accident.

3.29

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (2/4)

4

7

8

6

5

Centre console storage

Passenger storage

Passenger storage drawer

compartment 4/ induction

compartment

To open, press the button 7 to unlock

charging zone 5

the drawer and pull the handle 8.

Pull handle 6 to open it.

For more information on the induction

The glove box can hold A4-sized docu-

charging zone, please refer to the mul-

ments, a bottle etc.

timedia instructions.

Ensure that no hard, heavy

or pointed objects are

placed in the “open” storage

compartments in such a

way that they may fall onto passen-

gers during sudden turning, braking

or in the event of an accident.

3.30

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (3/4)

10

11

9

12

Centre armrest storage

Cup holders 12

compartment 11

Depending on the vehicle, the cup

Lift the cover 9 of the sliding armrest by

holder may be equipped with retaining

pressing the 10 button.

hooks to keep the cup in place.

This can be used to store a mobile ash-

tray, drink cans, etc.

When turning corners,

accelerating or braking,

ensure that the recepta-

cle being held by the cup

holder is not dislodged.

There is a risk of injury if hot

liquid escapes.

3.31

CarManuals2.co

PASSENGER COMPARTMENT STORAGE, FITTINGS (4/4)

15

14

13

Rear door storage

Rear seat storage pockets 14

Grab handle 15

compartment 13

This offers support and can be held

They can hold a 0.5-litre bottle.

when the vehicle is moving.

Do not use it for getting into or out of

the vehicle.

Ensure that no hard, heavy

or pointed objects are

placed in the “open” storage

compartments in such a

way that they may fall onto passen-

gers during sudden turning, braking

or in the event of an accident.

3.32

CarManuals2.co

ACCESSORIES SOCKET

1

1

Accessories socket 1

You can use the 1 socket. It is provided

for connecting accessories approved

by our Technical Department.

Connect accessories with

a maximum power of

120 watts (12 V) only.

When several accessory

sockets are used at the same time,

the total power of the connected

accessories must not exceed

180 watts.

Fire hazard.

3.33

CarManuals2.co

REAR HEAD RESTS

2

1

Position for use

To refit the headrest

When the headrest is set at the

lowest position, this is for storage

Raise the headrest as far as possible to

Fit the rods into their housing and push

only. It should not be in this position

use it in the high position. Check that it

down the headrest until it locks to set

when a seat is occupied.

is correctly locked.

it to raised position. Check that the

bonnet is correctly locked.

To remove the headrest

Folding positions 2 for the

Raise the headrest as far as it will go,

then press button 1 and remove the

headrest

headrest.

Press the button 1 and lower the head-

The headrest is a safety

rest completely.

component; check that it is

fitted and in the correct po-

sition. The top of the head-

rest should be as close as possible

to the top of the head.

3.34

CarManuals2.co

REAR BENCH SEAT: functions (1/2)

Pull the vane 1 and lower the seat-

1

A

back B.

Note: for safety reasons, the seat-

back B is equipped with a retaining

system. You may experience resist-

B

ance when handling.

To replace the seatback, proceed in

the reverse order to removal.

Raise the seatback again until it

reaches the locking joint of the seat-

back. Be careful not to jam the safety

strap between the backrest and the

parcel shelf.

Check the operation of the seat belt.

To fold down the seatback

Ensure that the front seats are far

enough forward.

Before folding down a seatback:

- lower the headrest fully;

When refitting the seat-

- place the seat belt in the belt guide A

back, make sure it is cor-

and buckle the seat belt. This pre-

rectly locked in place.

vents the seat belt from locking when

If seat covers are fitted,

the seatback is lifted up again.

make sure these do not prevent the

seatback latch from locking in.

Make sure that the seat belts are

positioned correctly.

Reposition the headrests.

Before moving the seatback, put

the seat belt in belt guide A to avoid

damaging it.

3.35

CarManuals2.co

REAR BENCH SEAT: functions (2/2)

3

2

To move forwards or

backwards

To unlock the seat:

- from the rear seats, lift the lever 2 ;

- from the luggage compartment, op-

For safety reasons, carry

erate the handle 3.

out any adjustments when

the vehicle is not being

Move the seat forwards or back to the

driven.

required position.

Release lever 2 or handle 3 and make

sure that the seat is locked correctly in

When moving the rear

position.

seats, ensure that nothing

obstructs the anchorage

points (passenger’s arm or

leg, a pet, gravel, cloth, toys, etc.).

3.36

CarManuals2.co

BOOT

2

3

1

To open

Opening the doors manually

from the inside

Press the 1 button to open the luggage

compartment lid a few centimetres.

If it is impossible to unlock the tailgate,

Lift the luggage compartment lid.

it can be done manually from inside:

- access the luggage compartment by

tilting the rear bench seatback(s),

To close

- insert a pencil or similar object in

Lower the tailgate using the handles 2

recess 3 and slide the unit as shown

inside the tailgate to help you.

The attaching of any carry-

in the illustration;

ing device (bike rack, lug-

- push the tailgate to open it.

gage box etc.) resting on

the luggage compartment

lid is prohibited. To install a carrying

device on your vehicle, contact an

Approved Dealer.

3.37

CarManuals2.co

REAR PARCEL SHELF

1

A

2

2

Removal

- Unhook the two straps 1 of the door

of the boot;

- lift the shelf

2 to unclip it (move-

ment A);

- pull the shelf towards you.

To refit, proceed in the reverse order to

removal.

Do not place any heavy or

hard object on the parcel

shelf. These may pose a

risk to the vehicle occu-

pants if the driver has to brake sud-

denly or if the vehicle is involved in

an accident.

3.38

CarManuals2.co

BOOT ARRANGEMENTS

1

1

1

2

3

4

Mobile floor 1

Intermediate position

Storage position

(depending on the vehicle)

In the blocked position, it allows you to

Flat position

access the tools stored under the boot

This allows for more space to store

Enables you to flatten the floor by fold-

carpet.

things in the boot.

ing down the back of the rear bench

- Remove the mobile floor 1;

- Remove the mobile floor 1;

seat and to compartmentalise the boot

into two distinct spaces.

- position it in the luggage compart-

- from the luggage compartment, pull

ment, using the 2 runners provided.

the handle 3 to move the rear bench

The mobile floor is positioned on the

seat forwards;

runner 2.

- place the mobile floor 1 in the luggage

compartment, under the runner 2.

If necessary, remove the inflation kit 4

before placing the false floor in the

In the storage position, moving the

lower position.

sliding rear bench seat is only pos-

sible from the rear seats. For more

Maximum weight for the mobile

information ➥ 3.35.

floor: 100 kg evenly distributed.

3.39

CarManuals2.co

TRANSPORTING OBJECTS IN THE LUGGAGE COMPARTMENT

Always position the objects transported

so that the largest surface is against:

- the rear bench seatback, for normal

loading (example A);

A

1

1

– the front seatbacks with the rear seat-

backs folded down, as is the case for

B

maximum loads (example B).

Always position the heavi-

If you have to place objects on the folded

est items directly on the

seatback, it is necessary that you lower

floor. Use the lashing

the headrests before folding the seat-

points 1 on the boot floor, if

back so that it can be folded as flat as

these are fitted to the vehicle. The

possible against the seat.

luggage should be loaded in such a

Note: in the absence of an emergency

way that no items will be thrown for-

spare wheel or tyre inflation kit, do not

ward and strike the occupants if the

load the bottom of the luggage compart-

driver has to brake suddenly. Fasten

ment.

the rear seat belts, even if the seats

are not occupied.

3.40

CarManuals2.co

TRANSPORTING OBJECTS towbar

A

Permissible nose weight, maxi- -

mum permissible towing weight

braked and unbraked: ➥ 6.9.

Choice and fitting of towing

equipment

Maximum weight of towing equip-

ment:

- 10 kg on a vehicle with towing

pre-equipment;

Maximum dimension A: 837 mm.

- 28 kg on a vehicle without towing

pre-equipment.

It is not permitted to fit a mechanical

towing device (ball, hook, etc.) that

is removable without tools or retract-

able if it cannot be easily removed

Any towing device must not ob-

or repositioned when not in use.

struct any lighting component or

the number plate when not in use.

For fitting and conditions of use,

Mechanical towing devices (ball,

refer to the equipment’s fitting in-

hook, etc.) which can be removed

structions.

without tools or which are retract-

Please keep these instructions with

able must be removed or reposi-

the rest of the vehicle documenta-

tioned when they are not in use.

tion.

In all cases, you must comply with

the regulations of the particular

country you are in.

3.41

CarManuals2.co

ROOF BARS, SPOILER (1/2)

1

3

2

For information on the range of

equipment adapted to your vehi-

cle, we advise you to consult an ap-

proved Dealer.

Refer to the fitting instructions for in-

formation on how to fit roof bars and

Accessing the mounting

Vehicles not fitted with longitudinal

conditions of use.

roof bars

points

Please keep these instructions with

Open the doors to access the fixing

the rest of the vehicle documenta-

Vehicles fitted with longitudinal roof

points 3.

tion.

bars

Maximum permissible load on

The attachment inserts 2 are located on

roof rack ➥ 6.9.

the longitudinal roof bars 1.

If original roof bars, ap-

proved by our Technical

Department, are supplied

with screws, only use these

screws for attaching the roof bars to

the vehicle.

3.42

CarManuals2.co

ROOF BARS, SPOILER (2/2)

Precautions during use

Handling the tailgate

A

Before handling the tailgate, check the

objects and/or accessories (bike rack,

roof box, etc.) fitted to the roof bars:

these must be correctly positioned and

secured, so as not to hinder the opera-

tion of the tailgate.

Spoiler A

It is prohibited to attach any

carrying equipment

(bike

rack, luggage box etc.)

resting against the spoiler

or tailgate. To install a carrying

device on your vehicle, contact an

Approved Dealer.

3.43

CarManuals2.co

Content      ..     6      7      8      9     ..
