MOTORWAY AND TRAFFIC ASSISTANT (10/16)

If the vehicle crosses a line com-

pletely and moves out of lane, the

“Lane Centring” function is put on

15

standby. Standby of the function is

confirmed by the 15 

warning

light and the left-hand and right-hand

line indicators 17 appearing in grey on

the instrument panel.

17

17

In the case of a sharp bend

If the driver does not intervene, the

function triggers the vibration of the

In the case of a sharp band, and de-

steering wheel to signal that the vehi-

pending on the vehicle speed, the func-

cle is about to breach a line and that

tion’s side retaining capacities will be

the driver needs to carry out immediate

limited and require the driver to carry

action.

out immediate action on the steering

wheel so that the function can continue

The 15 

warning light and the

to maintain the vehicle in the centre of

left-hand or right-hand line indicator 17

the lane.

appear in red on the instrument panel.

2.126

CarManuals2.co

MOTORWAY AND TRAFFIC ASSISTANT (11/16)

- the Stop and Go adaptive cruise

control is deactivated ➥ 2.103;



button

Note: pressing the 10

once deactivates both the “Stop and

Go adaptive cruise control” function

and the “Lane Centring” function.

- the system will no longer detect the

driver’s hands on the steering wheel

for a period over 45 seconds approx-

imately.

10

The 15



warning light and the left-

11

hand and right-hand line indicators 17

disappear from the instrument panel.

Deactivating the “Lane

Centring” function

The “Lane Centring” function is deacti-

vated when:

- you press the 11 switch. The func-

tion’s deactivation is confirmed by

the appearance of the “Lane center-

ing deactivated” message on the in-

strument panel;

Note: pressing the 11 switch once

deactivates the

“Lane centring”

function but does not affect operation

of the Stop and Go adaptive cruise

control function.

2.127

CarManuals2.co

PARKING DISTANCE CONTROL (1/7)

Depending on the vehicle, the system

Location of the ultrasonic

detects obstacles to the front, the rear

sensors 1

and the sides of the vehicle.

Ensure that the ultrasonic sensors indi-

The parking distance control system

cated by the arrows 1 are not obscured

1

is only activated when the vehicle is

(by dirt, mud, snow, a badly fitted/at-

driven at a speed below approximately

tached number plate), impacted, mod-

6 mph (10 km/h).

ified (including paintwork) or obstructed

The function does not take into account

by any accessory fitted to the rear and/

towing or carrying systems that are not

or, depending on the vehicle, to the

recognised by the system.

front or sides of your vehicle.

This measurement is indicated by

beeps which become more frequent the

closer you come to the obstacle, until

they become a continuous beep when

the vehicle is approximately

20 to

Operating principle

30 centimetres from the obstacle.

Ultrasonic sensors, indicated

by

arrows 1, are fitted in the bumpers to

measure the distance between the ve-

hicle and an obstacle.

This function is an additional driving aid.

Under no circumstances should it replace the driver’s care or responsi-

bility whilst reversing.

The driver should always be ready for sudden incidents while driving: always

ensure that there are no small, narrow moving obstacles (such as a child, animal,

pushchair, bicycle, stone, post, etc.) in the blind spot when manoeuvring.

2.133

CarManuals2.co

PARKING DISTANCE CONTROL (2/7)

Note: for vehicles fitted with the “360°

2

camera” function ➥ 2.73, analysis of the

C

vehicle surroundings (areas A and B)

is not displayed in “Bird’s eye view” or

“Side view” mode.

Operation

Most objects located less near the

front, rear and sides of the vehicle are

detected.

Depending on the distance of the ob-

stacle, the frequency of the beep will

be higher while approaching it, and

A

B

will become a continuous beep around

20 cm away for obstacles to the sides,

Note: the display 2 shows the vehicle

and around 30 cm for obstacles to the

surroundings and emits beeps.

front or rear. The green, orange (or

It is necessary to travel a few metres

yellow depending on the vehicle) and

before the side detection is activated.

red zones will be shown on the C dis-

play.

If all areas have a grey background, the

An impact to the under-

whole area around the vehicle is being

Note: in the event of a change in tra-

side of the vehicle while

monitored:

jectory during a manoeuvre, the risk of

manoeuvring

(e.g. strik-

collision with an obstacle may be sig-

ing a post, raised kerb or

- A: analysis of the vehicle surround-

nalled late.

other street furniture) may result in

ings in progress;

damage to the vehicle (e.g. defor-

- B: analysis of the vehicle surround-

mation of an axle).

ings carried out.

To avoid any risk of accident, have

your vehicle checked by an ap-

proved dealer.

2.134

CarManuals2.co

PARKING DISTANCE CONTROL (3/7)

If a side obstacle is detected:

4

D

- the beeps become faster and then

sound continuously as the obstacle

gets nearer. Green, orange and red

zones will be displayed on the dis-

play D;

- if there is no risk of collision, no beep

will sound when approaching the ob-

stacle. Green, orange and red zones

will be displayed interspersed on the

display D.

3

Note: in the event of a change in tra-

jectory during a manoeuvre, the risk of

collision with an obstacle may be sig-

nalled late.

Detection of obstacles to the side

Activation/deactivation

Depending on the direction of the

Vehicles fitted with a multimedia

wheels, the system determines the tra-

screen.

jectory of the vehicle and notifies the

driver of any risk or otherwise of a col-

To activate or deactivate the various

lision with an obstacle 3 to the side of

zones covered by the ultrasonic detec-

the vehicle.

tors, please refer to the multimedia in-

structions.

Select “ON” or “OFF”.

An impact to the underside of the vehicle while manoeuvring (e.g. striking a post, raised kerb or other street furniture)

may result in damage to the vehicle (e.g. deformation of an axle).

To avoid any risk of accident, have your vehicle checked by an approved Dealer.

2.135

CarManuals2.co

PARKING DISTANCE CONTROL (4/7)

Vehicles not fitted with a multimedia

screen

With the vehicle stopped, press the 6

switch to deactivate parking distance

control. Warning light 5 in the switch

lights up. Press again on the 6 switch to

activate the function. The indicator light

built into the 5 switch goes out.

5

Adjustment

6

Vehicles fitted with a multimedia

screen 4

Depending on the vehicle, with the

engine running, some settings can be

System sound

adjusted from the multimedia screen 4.

Enables the system sound

to

be

Please refer to the multimedia instruc-

chosen.

tions for further information.

Deactivating the system sound

Parking distance control audio

Activate or deactivate the parking dis-

volume

tance control sound.

Adjust the volume of the parking dis-

Note: if you deactivate the sound, you

tance control by pressing + or -.

will no longer be notified with beeps

when approaching an obstacle.

When the vehicle is travelling at a

speed below approximately 6 mph

(10 km/h), some noises (motorcy-

cle, lorry, pneumatic drill etc.) may

trigger the beeping sound of the

parking distance control.

2.136

CarManuals2.co

PARKING DISTANCE CONTROL (5/7)

- select “Beep volume” to adjust the

- when an operating fault is detected.

volume of Park Assist using control 8

Note: if the vehicle is fitted with a

or 9.

towbar recognised by the system, only

the rear Park Assist function is deacti-

vated.

Deactivating the parking

distance control manually

You must disable the function if:

Operating faults

- if towing, carrying or trailer equip-

When the system detects an operating

ment that is unrecognised by the

fault, a beep sounds for approximately

7

8

system is present in front of the ul-

three seconds each time reverse gear

trasonic sensors;

is selected and the message “Check

- in the event of damage to the ultra-

parking distance control” appears on

sonic sensors.

the instrument panel. Consult an ap-

proved dealer.

10

9

Automatic deactivation of the

Vehicles not fitted with a multimedia

parking distance control

screen

The system deactivates:

- With the vehicle stopped, press the 7

- when the vehicle speed is above ap-

switch as many times as required to

proximately 6 mph (10 km/h);

reach the “Vehicle” tab;

- depending on the model, when the

An impact to the under-

- press the 8 or 9 control repeatedly to

vehicle is stationary for more than

side of the vehicle while

reach the “Settings” menu. Press the

approximately 5 seconds and an ob-

manoeuvring

(e.g. strik-

switch 10 OK ;

stacle is detected (such as when in a

ing a post, raised kerb or

traffic jam, etc.);

other street furniture) may result in

- press the 8 or 9 control repeatedly

- when the vehicle is in neutral on

damage to the vehicle (e.g. defor-

to reach the “PARKING ASSIST”

manual gearboxes, or in position N

mation of an axle).

menu. Press the switch 10 OK;

or P on automatic gearboxes;

To avoid any risk of accident, have

your vehicle checked by an ap-

proved dealer.

2.137

CarManuals2.co

REVERSING CAMERA (1/2)

2

1

3

4

C

B

A

Operation

Fixed clearance gauge 3

4 moving guide line:

When the vehicle is reversing, the

The fixed clearance gauge comprises

This is shown in blue on the multime-

camera 1 on the luggage compart-

coloured markers A, B and C indicating

dia screen 2. It indicates the vehicle tra-

ment lid transmits a view of the area

the distance behind the vehicle:

jectory according to the position of the

surrounding the rear of the vehicle to

steering wheel.

- A(red) approximately 30 centimetres

the multimedia display 2 accompanied

from the vehicle;

by two guiding lines 3 and 4 (fixed and

- B(yellow) approximately 70 centime-

Special feature

mobile).

tres from the vehicle;

Make sure that the camera is not ob-

This system uses several guidelines for

- C(green) approximately 150 centi-

scured (by dirt, mud, snow, condensa-

its operation (mobile for trajectory and

metres from the vehicle.

tion etc.).

fixed for distance). When the red zone

This gauge remains fixed and indicates

is reached, use the bumper image to

the vehicle trajectory if the wheels are

stop accurately.

in line with the vehicle.

2.140

CarManuals2.co

REVERSING CAMERA (2/2)

2

The screen shows a reverse mirror

image.

The frames are a representation

projected on a flat surface. This in-

formation is to not be taken into ac-

count when superimposed on a

vertical object or an object on the

ground.

Objects which appear on the edge

of the screen may be deformed.

Settings

This function is an additional

In very bright light (snow, vehicle in

While the engine is running, from the

aid. It cannot, therefore,

sunshine, etc.), the camera vision

multimedia screen 2 you can add or

under any circumstances

may be adversely affected.

remove the guides and adjust the

replace the vigilance or the

camera image settings (brightness,

If the boot is open or poorly closed,

responsibility of the driver.

contrast etc.). Please refer to the mul-

the message

“WARNING: Boot

The driver should always be ready

timedia instructions for further informa-

Open” appears and the camera dis-

for sudden incidents while driv-

tion.

play disappears.

ing: always ensure that there are

no small, narrow moving obstacles

(such as a child, animal, pushchair,

bicycle, stone, post, etc.) in the blind

spot when manoeuvring.

2.141

CarManuals2.co

PARKING EXIT WARNING (1/4)

A

B

B

B

B

Using information from the radars in-

Special feature

stalled on each side of the rear bumper

Make sure that the radar area A is not

(area A), the system notifies the driver

obscured (by stickers, mud, snow etc.).

The system’s detection capability

when another vehicle appears in the

depends on the vehicle’s surround-

If a radar is obscured, the message

detection zone B.

ings (static objects etc.) and the

“Side radars no visibility” will appear on

The function is activated if:

condition of the bumper etc.

the instrument panel. Clean the area

where the sensors are located.

- reverse gear is engaged;

and

This function is an addi-

- the vehicle is stationary or driving at

tional driving aid. This func-

a low speed.

tion is not under any cir-

cumstances intended to

replace the due care and attention

of the driver, who should at all times

be in control of the vehicle.

2.142

CarManuals2.co

PARKING EXIT WARNING (2/4)

1

2

4

3

Activation/deactivation from

Operation

The indicators 4 on the multimedia

screen show you on which side the ap-

the multimedia screen 1

The function warns you if a vehicle is in

proaching vehicle has been detected.

To activate or deactivate the function,

area B and is approaching your vehicle.

Note: clean the camera regularly so

refer to the multimedia instructions.

When a vehicle is detected, the indica-

that it is not obscured.

Select “ON” or “OFF”.

tors 2 illuminate on both door mirrors 3.

Indicators 2 and 4 are accompanied by

Note: clean the rear view mirrors 3 reg-

an audible signal when your vehicle is

ularly so that the indicators 2 can be

reversing.

seen.

2.143

CarManuals2.co

ASSISTED PARKING (1/5)

1

3

A

2

Using ultrasonic detectors as indicated

Switching on

Special features

by the 3 arrows installed in the vehicle

While the engine is running, vehicle

Ensure that the ultrasonic detectors

bumpers, this function helps to find ac-

stationary or driving at less than ap-

indicated by the arrows 3 are not ob-

cessible parking spaces and assists in

proximately 19 mph (30 km/h):

scured (by dirt, mud, snow, a badly

the parking manoeuvre.

fitted number plate, etc.).

- press switch 2. The indicator light in

Remove your hands from the steering

switch 2 lights up and display A ap-

wheel, you only control:

pears on the multimedia screen 1.

- the accelerator pedal;

- set the direction indicators to the

- the brake pedal;

side of the vehicle where you want to

park.

- the gear lever.

At any time, you can regain control by

using the steering wheel.

2.146

CarManuals2.co

ASSISTED PARKING (2/5)

Note: when starting the vehicle, or after

Operation

1

having successfully completed parallel

parking using the system, the default

Parking

manoeuvre proposed by the system is

As long as the vehicle speed is less

assistance in exiting a parallel parking

than 19 mph (30 km/h), the system

space. In other cases, the default ma-

searches for available parking spaces

noeuvre can be set from the multimedia

on the side of the vehicle chosen by the

screen 1. Please refer to the multime-

driver.

dia instructions for further information.

Note: if parking spaces are available

on the other side of the vehicle, set the

direction indicators to the other direc-

tion to enable the system to search for

spaces.

Once a space has been found, it is dis-

played on the multimedia screen, indi-

Choice of manoeuvre

cated by a small letter “P”. Drive slowly,

with the direction indicators activated

The system can perform four types of

on the side where the space is avail-

manoeuvres:

able, until the “Stop” message is dis-

- parallel parking;

played and a beep sounds.

- perpendicular parking;

- angle parking;

- moving out of a parallel parking

space.

From the 1 multimedia screen, select

the manoeuvre to carry out.

The system start up is accompa-

nied by activation of the parking dis-

tance control and, on those vehicles

equipped, the reversing camera

or 360° camera to help the driver

visualise the manoeuvre. ➥ 2.133,

➥ 2.140 and ➥ 2.73.

2.147

CarManuals2.co

ASSISTED PARKING (3/5)

The space is then indicated on the mul-

- Release the steering wheel;

timedia screen by a capital letter “P”.

1

- carry out manoeuvres at the front

- Stop the vehicle;

and rear by following the instructions

shown on the multimedia screen 1

- select reverse gear.

and using the parking distance con-

trol system alerts.

The indicator light



lights up

on the instrument panel and a beep

Your speed should not exceed around 4

sounds.

mph (7 km/h).

- Release the steering wheel;

Once the vehicle is in a position to exit

- follow the instructions shown on the

2

the parking space, the 

warning

multifunction screen 1.

light disappears from the instrument

Your speed should not exceed around 4

panel and a sound signal and message

mph (7 km/h).

appear on the multimedia screen 1 to

confirm that the manoeuvre is com-

Exiting a parallel parking space

plete.

Once the warning light 

on the

instrument panel goes off and a beep

- Briefly press the 2 switch;

sounds, the manoeuvre has been com-

- Select the

“Exit parallel parking

pleted.

space” mode;

- activate the direction indicators on the

side on which you wish to pull out;

- press and hold switch 2 (approx. two

seconds).

This function is an addi-

The indicator light



lights up

tional driving aid.

on the instrument panel and a beep

Therefore, it can under no

sounds.

When manoeuvring, the

circumstances replace the

steering wheel may turn

driver’s vigilance and responsibility

quickly: do not put your

during manoeuvres (the driver must

hands inside, and make

always be ready to brake).

sure that nothing is caught inside.

2.148

CarManuals2.co

ASSISTED PARKING (4/5)

The switch warning light 2 goes out,

Cancelling the manoeuvre

1

the 

warning light disappears

The manoeuvre is cancelled in the fol-

from the instrument panel and an au-

lowing cases:

dible signal confirms that the manoeu-

- the vehicle speed has exceeded

vre has been suspended. The reason

4 mph (7 km/h);

for suspending the manoeuvre will be

- by pressing switch 2;

displayed on the multimedia screen 1.

- you have performed more than ten

Make sure:

forwards/backwards movements in

- you have released the steering

one manoeuvre;

2

wheel;

- the parking distance control sensors

and

are dirty or blocked;

- that all doors and the boot are closed;

- the vehicle wheels have skidded;

and

- the manoeuvre has been suspended

- that no obstacles are in the way of

Suspending/Resuming the

for too long.

the direction of movement;

manoeuvre

The 2 switch warning light and the

and

The manoeuvre is suspended in the fol-

- that the engine is started.



warning light disappear from the

lowing circumstances:

If the warning light on the 2 switch

instrument panel and a sound signal

- you take control of the wheel;

flashes, this indicates that the system

confirms that the manoeuvre has been

is once again available to resume the

cancelled. The reason for cancelling

- the vehicle is stationary for too long;

manoeuvre.

the manoeuvre will be displayed on the

- an obstacle in the direction of move-

multimedia screen 1.

To resume the manoeuvre, press and

ment prevents the manoeuvre from

hold the 2 switch. The 2 switch warning

being completed;

- the engine stops;

light appears and 

is displayed

on the instrument panel.

- a door or the luggage compartment

is opened.

Follow the instructions shown on the

multimedia screen 1.

2.149

CarManuals2.co

AUTOMATIC GEARBOX, ELECTRONIC LEVER (1/6)

6

5

1

4

5

7

2

3

6

Electronic selector lever 1

4: position of the gear engaged;

The 7 triangle comes on when manual

mode is activated.

R: reverse

5 : position accessible from the cur-

rent position by moving the selector

N: Neutral

lever 1 one notch forwards or back-

D: automatic mode

wards;

P : park, button 2

6 : position accessible from the cur-

rent position by moving the selec-

The 3 indicator light displays the gear

tor lever 1 two notches forwards or

engaged.

backwards.

On the instrument panel, the following

symbols inform you:

The 5 or 6 symbols are displayed to in-

Check that warning light P

dicate the gears that can be selected. If

on the instrument panel and

these symbols are absent this indicates

the warning light integrated

that the gears cannot be selected from

on the button 2 are acti-

the current position.

vated before leaving the vehicle.

Risk of loss of immobilisation of

the vehicle.

2.151

CarManuals2.co

AUTOMATIC GEARBOX, ELECTRONIC LEVER (2/6)

If the brake pedal is not fully depressed,

the message “Press Brake Pedal” and

the warning light



are displayed on

the instrument panel.

1

1

Note:

- if the driver opens their door to leave

the vehicle and position P has not

2

been engaged, a beep sounds and

the message “P not engaged” is dis-

played on the instrument panel;

- the warning light



appears

each time the brake pedal must be

pressed to change the automatic

gearbox lever position.

One-touch selector

To engage P position

To engage neutral

Move the selector lever 1 one or two

With the vehicle at a standstill, engine

With the vehicle stopped and the

notches forwards or backwards to

running or ignition on, press button 2 to

engine running, to select N position,

engage the desired position (R, N or D)

engage position P. The warning light on

move the 1 selector lever one notch

then release the lever and it will return

the 2 button lights up in orange once

forwards or backwards according to the

to the stable position.

the Park position P on the gearbox is

gear engaged.

engaged.

The selected position is displayed on

the instrument panel along with the 4

warning light in front of the position.

To disengage position P

If certain conditions prevent shifting

With the vehicle stationary and the

from one position to another, the re-

engine running, press the brake pedal

quested position flashes on the instru-

and, move the 1 selector lever forwards

ment panel.

or backwards according to the posi-

tion desired. The 2 button warning light

switches off.

2.152

CarManuals2.co

AUTOMATIC GEARBOX, ELECTRONIC LEVER (4/6)

Driving in manual mode

When driving in position D you can

switch to manual driving mode using

paddles 8 and 9 on the steering wheel.

8

9

Depending on the vehicle, two manual

driving modes are available:

- the

“temporary” manual mode

can be used to force gear shifting

10

by briefly pressing one of the two

paddles. the driving mode D and

the gear engaged appear on the in-

strument panel. the letter D and the

lower arrow appear brighter on the

indicator light 3.

Note: the gearbox adjusts itself to

automatic mode D if the gear en-

Gear shifting paddles 8 and 9

Note: depending on the vehicle, you

gaged is no longer optimal to vehi-

can return to automatic mode by

Depending on the vehicle, you can use

cle performance or if no action has

pressing and holding the right-hand

paddles 8 and 9 to change gear when

been taken on a paddle for a certain

paddle or by moving the one-touch

the lever is in position D.

amount of time.

lever 1 one or two notches back-

- permanent manual mode is ac-

8: Change to a lower gear.

wards.

tivated by pressing and holding

9: Change to a higher gear.

either of the paddles. Driving mode

In all situations:

P, N and R are not accessible using the

M and the gear engaged will appear

- to move down through the gears,

paddles.

on the 10 display on the instrument

press the left-hand paddle;

panel. All of the letters and the lower

- to move up through the gears, press

arrow appear as backlighting on the

the right-hand paddle.

indicator light 3.

Note: depending on the display, the +

and - or 

and 

indicators

will suggest moving up or down a gear.

2.154

CarManuals2.co

AUTOMATIC GEARBOX, MANUAL LEVER (1/4)

Driving in automatic mode

Put lever 1 into position D.

1

In most road conditions you will en-

counter, you will not need to touch your

lever again: the gears will change au-

tomatically at the right time and at the

3

most suitable engine speed because

the automatic system takes into ac-

2

count the vehicle load and road contour

and adjusts itself to the particular driv-

4

ing style you have chosen.

Economical driving

When driving, always leave the lever

in position D, keeping the accelerator

Selector lever 1

Operation

pedal lightly depressed to ensure auto-

matic gear changes at a lower engine

P: park

With gear lever 1 in position P, start the

speed.

engine.

R: reverse

To move out of position P, you must de-

Accelerating and overtaking

N: Neutral

press the brake pedal before pressing

Depress the accelerator pedal firmly

D: automatic mode

the unlocking button 2.

and fully.

The 4 display on the instrument panel

With your foot on the brake pedal

This will enable you to change down

shows the position engaged by the se-

(warning light 3 on the display goes

to the optimum gear within the

lector lever 1 or displays the gear en-

out), move the lever out of position P.

engine range.

gaged in manual mode.

Only engage D or R when the vehi-

Note: press the 2 button to exit position

cle is stopped, with your foot on the

P or to shift from position D or N to po-

brake and the accelerator pedal re-

sition R or P.

leased.

2.157

CarManuals2.co

AUTOMATIC GEARBOX, MANUAL LEVER (2/4)

Driving in manual mode

When driving in position D you can

switch to manual driving mode using

paddles 5 and 6 on the steering wheel.

5

6

Depending on the vehicle, two manual

driving modes are available:

- the

“temporary” manual mode

can be used to force gear shifting by

7

briefly pressing one of the two pad-

dles. the driving mode D and the

gear engaged appear on the instru-

ment panel.

Note: the gearbox returns to auto-

matic mode D automatically if the

gear engaged is not optimal or if the

Gear changing paddles 5

Note: return to automatic mode by

paddles have not been used for a

pressing and holding the right-hand

and 6

certain length of time.

paddle. Automatic mode D is dis-

Depending on the vehicle, you can use

- permanent manual mode is ac-

played on the instrument panel.

paddles 5 and 6 to change gear when

tivated by pressing and holding

In all situations:

the lever is in position D.

either of the paddles. Driving mode

- to move down through the gears,

M and the gear engaged will appear

5: change to a lower gear.

press the left-hand paddle;

on the 7 display on the instrument

6: change to a higher gear.

- to move up through the gears, press

panel.

P, N and R are not accessible using the

the right-hand paddle.

paddles.

Note: depending on the display, the +

and - or 

and 

indicators

will suggest moving up or down a gear.

2.158

CarManuals2.co

AUTOMATIC GEARBOX, MANUAL LEVER (4/4)

Maintenance period

Refer to the maintenance document

for your vehicle or consult an Approved

Dealer to check whether the automatic

gearbox requires scheduled mainte-

8

nance.

If it does not need to be serviced, there

is no need to top up the oil.

9

Operating faults

- when driving, if the message

“WARNING: Check Gearbox” ap-

pears on the instrument panel, it indi-

cates a failure.

Contact your approved Dealer as

When setting off, if the lever is stuck in

soon as possible;

P when you press the brake pedal (e.g.

- when driving, if the message

battery fault), it is possible to manually

“WARNING: Gearbox Overheating”

release the lever to unblock the drive

appears on the instrument panel,

wheels. To do this, unclip the base of

stop as soon as possible to let the

the gaiter and press the 9 button while

gearbox cool down and wait for the

simultaneously pressing the 8 button

message to disappear;

on the lever to unlock the lever and shift

to position N.

- Troubleshooting on a vehicle with

an automatic gearbox ➥ 5.36.

Contact an authorised dealer as soon

as possible.

2.160

CarManuals2.co

EMERGENCY CALL (1/3)

If the vehicle is equipped, the emer-

gency call function can be used to

call the emergency services (without

charge) automatically or manually in

the event of an accident or illness, re-

ducing the time it takes for the emer-

3

gency services to arrive.

2

Note: the emergency call operates:

- in countries covered by the associ-

ated telephone emergency services

and infrastructure compatible with

1

the system;

4

- depending on the network coverage

in the geographical region where the

5

vehicle is being driven.

1

System operation warning light:

A call is always made as follows:

If you use the emergency call function

– green: operational

to report an accident which you have

- the call is set up with the emergency

(network available);

witnessed, this implies stopping where

services;

- off: non-operational

traffic conditions allow in order for the

- send data related to the incident (ve-

(network unavailable);

emergency services to locate your ve-

hicle identification plate, local time

- red: operating

hicle and therefore the location of the

of the call, last positions, direction of

fault;

reported accident.

the vehicle) ;

- green flashing: call in progress.

In all cases, comply with local legisla-

- voice communication with the emer-

2

Automatic mode warning light.

tion.

gency services;

3

SOS button.

- if necessary, emergency assistance

4

Microphone.

is called.

5

Speaker.

Emergency call has two modes:

- automatic mode;

Use the emergency call only in the

event of an emergency you are in-

- Manual mode.

volved in, if you witness an accident

or if you feel ill.

2.161

CarManuals2.co

EMERGENCY CALL (2/3)

Automatic mode

In the event of unintended operation, it

is possible to cancel the call by press-

If the automatic mode 2 warning light

ing the 3 button for around two sec-

appears in green this confirms that the

onds, before the call is connected to

automatic system is activated.

the call centre.

The emergency call starts automati-

3

Once a call is established, only the call

cally in the event of an accident that

centre can end the call.

has required the activation of the pro-

2

tective equipment (seat belt pretension-

Test mode

ers, airbag etc.).

(depending on local laws)

Test mode is reserved exclusively for

1

Approved Dealers to check that the

emergency call feature is working prop-

erly.

To activate test mode:

Manual mode

- briefly press the 3 button three times;

The emergency call is carried out by:

- wait approximately 15 seconds;

- pressing and holding the 3 button for

- briefly press the 3 button three times.

at least three seconds;

Exit from test mode is automatic.

or

- pressing the

3 button five times

within ten seconds.

In the event of an acci-

dent, if the location and traf-

fic conditions permit, stay

close to the vehicle in order

to be able answer the call centre

quickly if necessary.

2.162

CarManuals2.co

EMERGENCY CALL (3/3)

The system operates with a dedi-

cated battery. The battery serv-

ice life is approximately four years

(the 1 warning light lights up in red

to warn you when approaching

expiry).

Consult an approved dealer.

Without the emergency call feature,

1

the system is not trackable and will

not be under constant surveillance.

Data is automatically and constantly

To guarantee your safety

erased, and the system stores only

and the proper operation of

the last three positions of the vehi-

the system, any operation

Operating faults

cle.

carried out on the battery

In some cases, the emergency call may

(removal, disconnection, etc.) must

According to local legislation, data

not work (e.g. low battery).

be carried out by a qualified special-

is only sent in the event of an emer-

When the system detects an operating

ist.

gency call. Data sent to the call

fault, the 1 warning light turns red for

centre is treated according to the

Risk of serious burns or electric

over 30 minutes; consult an Approved

personal data protection laws appli-

shocks.

Dealer as soon as possible.

cable in the country where you are

You must respect the replacement

located. The system stores activity

intervals (without exceeding them)

history data for 13 hours only.

as stated in the maintenance docu-

The vehicle owner has the right of

ment.

access to their data. They can re-

The battery is a specific type.

quest that the data be corrected,

Please ensure it is replaced with the

deleted or locked.

same type.

Call an approved Dealer.

2.163

CarManuals2.co

MULTI-SENSE

The MULTI-SENSE system enables a

Mode Eco

1

choice between three driving modes

Eco mode focuses on energy saving.

that can be used to control, depending

The steering is smooth, engine and

on the vehicle: driving, ambient lighting,

gearbox management enable fuel con-

comfort and engine sound:

sumption to be reduced ➥ 2.30.

- the Eco and Sport modes are pre-

configured and can be partially cus-

Sport mode

tomised (ambient lighting, etc.);

This mode enables an increased re-

- the My Sense mode is customisable.

sponsiveness from the engine and the

The drive modes affect the:

2

gearbox. The steering is firmer.

- power-assisted steering;

- Electronic Stability Program;

- the response of the engine and gear-

My Sense mode

box.

Using standard default vehicle settings,

this mode can be used to manually con-

They also affect the:

figure driving, ambient lighting, comfort

- the lighting in the passenger com-

and engine sound (depending on the

Accessing the menu

partment and of the instrument

vehicle).

You can access MULTI-SENSE, de-

panel;

pending on the vehicle:

- the information on the instrument

- from the multimedia screen 1;

panel and multimedia screen;

- using the 2 switch.

- depending on the vehicle, the engine

sound.

Please refer to the multimedia instruc-

tions for further information.

After the engine is switched off, the

vehicle will always restart in My

Sense mode.

In any mode, you can change the colour of the ambient lighting as well as the

Engine settings are specific to each

format of the information displayed on the instrument panel and multimedia

of the driving modes and cannot be

screen.

customised.

You can also reset to the default settings.

3.2

CarManuals2.co

AIR VENTS, air outlets (1/2)

3

2

1

2

3

4

1

3

5

6

7

5

8

1

Side air vents

5 Footwell heater outlets for front

2 Demister outlets for side windows

passengers

3 Windscreen demisting vents

6

Control panel

4

Centre air vents

7 Footwell heater outlets for rear

passengers (depending on the

vehicle)

8

Rear console air vents

3.3

CarManuals2.co

Content      ..     5      6      7      8     ..
