SIDE WINDOW GLASS

GW-15

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

SIDE WINDOW GLASS

Exploded View

INFOID:0000000001094008

Removal and Installation

INFOID:0000000001096058

REMOVAL

1.

Remove the rear pillar finisher. Refer to

INT-14, "Removal and Installation"

.

2.

Remove the headlining. Refer to

INT-21, "Removal and Installation"

.

3.

Apply protective tape around the side window to protect the painted surface from damage.

4.

Remove the side window glass using piano wire or power cutting tool and an inflatable pump bag.

1.

Side window glass

2.

Spacer

3.

Adhesive

4.

Primer

5.

Body side outer panel

6.

Rear door weather strip

7.

Rear door outer panel

Refer to

GI-4, "Components"

 for symbols in the figure.

JMKIA0467GB

GW-16

< ON-VEHICLE REPAIR >

SIDE WINDOW GLASS

WARNING:

When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help pre-
vent glass splinters from entering your eyes or cutting your hands.

CAUTION:

• Be careful not to scratch the glass when removing.
• Do not set or stand the glass on its edge. Small chips may develop into cracks.

INSTALLATION

• Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the manuals furnished

with it.

• While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out

by passenger room air pressure when a door is closed.

• The molding must be installed securely so that it is in position and leaves no gap.
• Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely

cured (preferably 24 hours). Curing time varies with temperature and humidity.

WARNING:

• Keep heat and open flames away as primers and adhesive are flammable.
• The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid

contact with the skin and eyes.

• Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if inhaled.

If affected by vapor inhalation, immediately move to an area with fresh air.

• Driving the vehicle before the urethane adhesive has completely cured may affect the performance

of the side window in case of an accident.

CAUTION:

• Do not use an adhesive which is past its usable term. Shelf life of this product is limited to six

months after the date of manufacture. Carefully adhere to the expiration or manufacture date printed
on the box.

• Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
• Do not leave primers or adhesive cartridge unattended with their caps open or off.
• The vehicle should not be driven for at least 24 hours or until the urethane adhesive has completely

cured. Curing time varies depending on temperature and humidity. The curing time will increase
under lower temperature and lower humidity.

Repairing Water Leaks

Leaks can be repaired without removing and reinstalling glass.
If water is leaking between the urethane adhesive material and body or glass, determine the extent of leakage.
This can be done by applying water to the side window area while pushing glass outward.
To stop the leak, apply primer (if necessary) and then urethane adhesive to the leak point.

BACK DOOR WINDOW GLASS

GW-17

< ON-VEHICLE REPAIR >

C

D

E

F

G

H

I

J

L

M

A

B

GW

N

O

P

BACK DOOR WINDOW GLASS

Exploded View

INFOID:0000000001093977

Removal and Installation

INFOID:0000000001093978

REMOVAL

1.

Remove the back door trim finisher upper and lower. Refer to

INT-26, "Removal and Installation"

2.

Remove the connectors and grounds for the back door window defogger and printed antenna.

3.

Remove the rear wiper arm and moter.Refer to

WW-112, "Removal and Installation"

.

1.

Back door window glass

2.

Terminal

3.

Back door glass holder

4.

Back door molding

5.

Adhesive

6.

Primer

7.

Back door outer panel

Refer to

GI-4, "Components"

 for symbols in the figure.

JMKIA0468GB

GW-18

< ON-VEHICLE REPAIR >

BACK DOOR WINDOW GLASS

4.

After removing molding using pliers, remove glass using piano wire or power cutting tool (A) and an inflat-
able pump bag (B).

5.

If a rear window glass is reused, mark the body and the glass with matching marks.

WARNING:

When cutting the glass from the vehicle, always wear safety glasses and heavy gloves to help pre-
vent glass splinters from entering your eyes or cutting your hands.

CAUTION:

• When a window glass is reused, do not use a cutting knife or power cutting tool.
• Do not scratch the glass when removing.
• Do not set or stand the glass on its edge. Small chips may develop into cracks.

INSTALLATION

• The dam rubber should be installed in position.
• Use a genuine Nissan Urethane Adhesive Kit (if available) or equivalent and follow the manuals furnished

with it.

• While the urethane adhesive is curing, open a door window. This will prevent the glass from being forced out

by passenger compartment air pressure when a door is closed.

• The molding must be installed securely so that it is in position and leaves no gap.
• Inform the customer that the vehicle should remain stationary until the urethane adhesive has completely

cured (preferably 24 hours). Curing time varies with temperature and humidity.

WARNING:

• Keep heat and open flames away as primers and adhesive are flammable.
• The materials contained in the kit are harmful if swallowed, and may irritate skin and eyes. Avoid

contact with the skin and eyes.

• Use in an open, well ventilated location. Avoid breathing the vapors. They can be harmful if

inhaled. If affected by vapor inhalation, immediately move to an area with fresh air.

• Driving the vehicle before the urethane adhesive has completely cured may affect the performance

of the rear window in case of an accident.

CAUTION:

• Perform adjustment of front wiper stop location. Refer to

WW-113, "Adjustment"

.

• Do not use an adhesive which is past its usable term. Shelf life of this product is limited to six

months after the date of manufacture. Carefully adhere to the expiration or manufacture date
printed on the box.

• Keep primers and adhesive in a cool, dry place. Ideally, they should be stored in a refrigerator.
• Do not leave primers or adhesive cartridge unattended with their caps open or off.
• The vehicle should not be driven for at least 24 hours or until the urethane adhesive has com-

pletely cured. Curing time varies depending on temperature and humidity. The curing time will
increase under lower temperature and lower humidity.

Inspection

INFOID:0000000001093979

REPAIRING WATER LEAKAGE

Leakage can be repaired without removing and reinstalling glass.
If water is leaking between the urethane adhesive material and body or glass, determine the extent of leakage.
This can be done by applying water to the side window area while pushing glass outward.
To stop the leakage, apply primer (if necessary) and then urethane adhesive to the leakage point.
