Lexus RX (2023 year). Manual in english

477

5-5. Using the other interior features

rior f
ea

ture
s

Accessories that use less than 150 W.
Open the lid.

■

The power outlet can be used when

The power switch is in ON.

To set the visor in the forward posi-
tion, flip it down.

To set the visor in the side position,
flip down, unhook, and swing it to
the side.

To use the side extender, place the
visor in the side position, then slide
it backward.

Slide the cover to open.

The light turns on when the cover is
opened.

Power outlets (220 VAC) (if
equipped)

NOTICE

■

To prevent the fuse from being blown

Do not use a 220 VAC appliance that

requires more than 150 W. If a 220 VAC

appliance that consumes more than 150

W is used, the protection circuit will cut

the power supply.

■

To avoid damaging the power outlet

Close the power outlet lid when the

power outlet is not in use.

Foreign objects or liquids that enter the

power outlet may cause a short circuit.

■

To prevent 12-volt battery discharge

Do not use the power outlet longer than

necessary when the hybrid system is not

running.

■

Appliances that may not operate

properly (220 VAC)

The following 220 VAC appliances may

not operate properly even if their power

consumption is under 150 W.

●

Appliances with high initial peak watt-

age

●

Measuring devices that process pre-

cise data

●

Other appliances that require an

extremely stable power supply

Sun visors

Vanity mirrors

478

5-5. Using the other interior features

■

To prevent 12-volt battery discharge

If the vanity lights remain on when the

power switch is turned off, the lights will go

off automatically after 20 minutes.

Pull the sunshade up using the tab and
hook the sunshade on to the anchors.

To lower the sunshade, pull it up slightly
using the tab, unhook it from the anchors,
and lower it slowly.

NOTICE

■

To prevent the 12-volt battery from

being discharged

Do not leave the vanity lights on for

extended periods while the hybrid sys-

tem is off.

Rear door sunshades (if
equipped)

WARNING

■

Closing the rear door sunshade

When a rear door sunshade is in use, do

not put fingers, etc. on the anchors or in

the groove of the rear door sunshade.

Otherwise, a finger, etc. may get caught,

possibly causing an injury.

NOTICE

■

To ensure normal operation of the

sunshade

●

Do not put anything in an area where it

may interfere with the operation of a

rear door sunshade.

●

To prevent damage to the rear door

sunshades, do not apply excessive

load or attach items to the rear door

sunshades.

479

Ma
inte
na

e and care

Maintenance and care

6-1. Maintenance and care

Cleaning and protecting the vehi-

cle exterior................................

480

Cleaning and protecting the vehi-

cle interior .................................

484

6-2. Maintenance

Maintenance requirements

(except for India)....................

487

Maintenance requirements (for

India)............................................

488

Scheduled maintenance ........

490

6-3. Do-it-yourself maintenance

Do-it-yourself service precautions

........................................................

496

Hood ..............................................

497

Positioning a floor jack............

498

Engine compartment...............

499

12-volt battery.............................

506

Tires ................................................

509

Tire inflation pressure...............

519

Wheels ..........................................

520

Air conditioning filter...............

522

Cleaning the hybrid battery (trac-

tion battery) air intake vents
........................................................

523

Electronic key battery.............

527

Checking and replacing fuses

........................................................

529

Light bulbs.....................................

531

480

6-1. Maintenance and care

6-1.Maintenance and care



Working from top to bottom, liber-
ally apply water to the vehicle body,
wheel wells and underside of the
vehicle to remove any dirt and dust.



Wash the vehicle body using a
sponge or soft cloth, such as a
chamois.



For hard-to-remove marks, use car
wash soap and rinse thoroughly with
water.



Wipe away any water.



Wax the vehicle when the water-
proof coating deteriorates.

If water does not bead on a clean surface,
apply wax when the vehicle body is cool.

■

Self-restoring coat

The vehicle body has a self-restoring coat-

ing that is resistant to small surface

scratches caused in a car wash etc.

●

The coating lasts for 5 to 8 years from

when the vehicle is delivered from the

plant.

●

The restoration time differs depending on

the depth of the scratch and outside tem-

perature.

The restoration time may become

shorter when the coating is warmed by

applying warm water.

●

Deep scratches caused by keys, coins,

etc. cannot be restored.

●

Do not use wax that contains abrasives.

■

Automatic car washes

●

Before washing the vehicle:

• Fold the mirrors

• Turn off the power back door
Start washing from the front of the vehicle.

Extend the mirrors before driving.

●

Brushes used in automatic car washes

may scratch the vehicle surface, parts

(wheel, etc.) and harm your vehicle’s

paint.

●

Rear spoiler may not be washable in

some automatic car washes. There may

also be an increased risk of damage to

vehicle.

●

When the shift position needs to be held

in N, refer to P.237, 244.

■

High pressure car washes

As water may enter the cabin, do not bring

the nozzle tip near the gaps around the

doors or perimeter of the windows, or spray

these areas continuously.

■

When using a car wash

If the door handle becomes wet while the

electronic key is within the effective range,

the door may lock and unlock repeatedly. In

that case, follow the following correction

procedures to wash the vehicle:

●

Place the key in a position 2 m (6 ft.) or

more separate from the vehicle while the

vehicle is being washed. (Take care to

ensure that the key is not stolen.)

●

Set the electronic key to battery-saving

mode to disable the smart entry & start

system. (



P.162)

■

Wheels and wheel ornaments (vehicles

without matte painted wheels)

●

Remove any dirt immediately by using a

neutral detergent.

●

Wash detergent off with water immedi-

ately after use.

●

To protect the paint from damage, make

sure to observe the following precau-

tions.

• Do not use acidic, alkaline or abrasive

detergent

Cleaning and protecting the
vehicle exterior

Perform cleaning in a manner
appropriate to each component
and its material.

Cleaning instructions

481

6-1. Maintenance and care

Ma
inte
na

e and care

• Do not use hard brushes

• Do not use detergent on the wheels when

they are hot, such as after driving or park-

ing in hot weather

■

Wheels and wheel ornaments (vehicles

with matte painted wheels)

A different set of care is necessary for matte

painted wheels and wheel ornaments. Con-

tact any authorized Lexus retailer or Lexus

authorized repairer, or any reliable repairer

for details.

●

Remove any dirt with water immediately.

If the wheels are excessively dirty, use

diluted neutral detergent.

●

When using detergent, make sure to

wash it off with water immediately. Then

use a soft cloth to wipe off the water.

●

Use a sponge or soft cloth to remove the

dirt by hand.

●

To prevent the matte paint from being

damaged or glossy, make sure to observe

the following precautions:

• Do not apply any coatings or wax.

• Do not use acidic, alkaline or abrasive

detergents.

• When using tire cleaners or tire wax, do

not allow them to be applied to the

wheels.

• Do not scrub or polish the wheels using a

brush or dry cloth, etc.

• When using an automatic car wash, do

not select the wheel brush function.

• Do not use a high pressure washer or

steam cleaner.

• Do not use detergent on the wheels when

they are hot, such as after driving or park-

ing in hot weather.

■

Brake pads and calipers

Rust may form if the vehicle is parked with

wet brake pads or disc rotors, causing them

to stick. Before parking the vehicle after it is

washed, drive slowly and apply the brakes

several times to dry the parts.

■

Brake caliper coating (F SPORT mod-

els)

●

When using detergent, use neutral deter-

gent. Do not use hard brushes or abra-

sive cleaners, as they will damage the

coating.

●

Do not use detergent on the brake cali-

pers when they are hot.

●

Wash detergent off immediately after

use.

■

Bumpers

Do not scrub with abrasive cleaners.

■

Front side windows water-repellent

coating

The following precautions can extend the

effectiveness of the water-repellent coating.

●

Remove any dirt, etc. from the front side

windows regularly.

●

Do not allow dirt and dust to accumulate

on the windows for a long period.

Clean the windows with a soft, damp

cloth as soon as possible.

●

Do not use wax or glass cleaners that

contain abrasives when cleaning the win-

dows.

●

Do not use any metallic objects to

remove condensation build up.

■

Plated portions

If dirt cannot be removed, clean the parts as

follows:

●

Use a soft cloth dampened with an

approximately 5% solution of neutral

detergent and water to clean the dirt off.

●

Wipe the surface with a dry, soft cloth to

remove any remaining moisture.

●

To remove oily deposits, use alcohol wet

wipes or a similar product.

WARNING

■

When washing the vehicle

Do not apply water to the inside of the

engine compartment. Doing so may

cause the electrical components, etc. to

catch fire.

482

6-1. Maintenance and care

WARNING

■

When cleaning the windshield

Set the wiper switch to off.

If the switch is in “AUTO”, the wipers may

operate unexpectedly in the following sit-

uations, and may result in hands being

caught or other serious injuries and

cause damage to the wiper blades.

Off
AUTO

●

When the upper part of the windshield

where the raindrop sensor is located is

touched by hand

●

When a wet rag or similar is held close

to the raindrop sensor

●

If something bumps against the wind-

shield

●

If you directly touch the raindrop sen-

sor body or if something bumps into

the raindrop sensor

■

Precautions regarding the exhaust

pipe

Exhaust gasses cause the exhaust pipe to

become quite hot.

When washing the vehicle, be careful not

to touch the pipe until it has cooled suffi-

ciently, as touching a hot exhaust pipe

can cause burns.

A
B

■

Precaution regarding the front and

rear bumpers

If the paint of the front or rear bumper is

chipped or scratched, the following sys-

tems may not function correctly. If this

occurs, consult any authorized Lexus

retailer or Lexus authorized repairer, or

any reliable repairer.

●

Lexus Safety System +

●

BSM (Blind Spot Monitor) (if

equipped)

●

Automatic Rear Flashing Hazard

Lights (if equipped)

●

Safe Exit Assist (if equipped)

●

Lexus parking assist-sensor

●

RCTA (Rear crossing traffic alert) (if

equipped)

●

PKSB (Parking Support Brake) (if

equipped)

●

Secondary Collision Brake (Rear

Impacts while Stopped) (if equipped)

NOTICE

■

To prevent paint deterioration and

corrosion on the body and compo-

nents (aluminum wheels, etc.)

●

Wash the vehicle immediately in the

following cases:

• After driving near the sea coast

• After driving on salted roads

• If coal tar or tree sap is present on the

paint surface

• If dead insects, insect droppings or

bird droppings are present on the

paint surface

• After driving in an area contaminated

with soot, oily smoke, mine dust, iron

powder or chemical substances

483

6-1. Maintenance and care

Ma
inte
na

e and care

NOTICE

• If the vehicle becomes heavily soiled

with dust or mud

• If liquids such as benzene and gasoline

are spilled on the paint surface

●

If the paint is chipped or scratched,

have it repaired immediately.

●

To prevent the wheels from corroding,

remove any dirt and store in a place

with low humidity when storing the

wheels.

■

Cleaning the exterior lights

●

Wash carefully. Do not use organic

substances or scrub with a hard brush.

This may damage the surfaces of the

lights.

●

Do not apply wax to the surfaces of the

lights.

Wax may cause damage to the lenses.

■

When using an automatic car wash

Set the wiper switch to the off position.

If the wiper switch is in “AUTO”, the wip-

ers may operate and the wiper blades

may be damaged.

■

When using a high pressure car wash

●

When washing the vehicle, do not

spray the camera or its surrounding

area directly with a high pressure

washer. Shock applied from high pres-

sure water may cause the device to not

operate normally.

●

Do not spray water directly on the

radar which is equipped behind the

emblem. Otherwise it may cause the

device to be damaged.

●

Do not bring the nozzle tip close to

boots (rubber or resin manufactured

cover), connectors or the following

parts. The parts may be damaged if

they come into contact with high-pres-

sure water.

• Traction related parts

• Steering parts

• Suspension parts

• Brake parts

●

Keep the cleaning nozzle at least 30

cm (11.9 in.) away from the vehicle

body. Otherwise resin section, such as

moldings and bumpers, may be

deformed and damaged.

Also, do not continuously hold the nozzle

in the same place.

●

Do not spray the lower part of the

windshield continuously.

If water enters the air conditioning sys-

tem intake located near the lower part of

the windshield, the air conditioning sys-

tem may not operate correctly.

●

Do not wash the underside of the vehi-

cle using a high pressure car washer.

484

6-1. Maintenance and care



Remove dirt and dust using a vac-
uum cleaner. Wipe dirty surfaces
with a cloth dampened with luke-
warm water.



If dirt cannot be removed, wipe it off
with a soft cloth dampened with
neutral detergent diluted to approx-
imately 1%.
Wring out any excess water from
the cloth and thoroughly wipe off
remaining traces of detergent and
water.

■

Shampooing the carpets

There are several commercial foaming-type

cleaners available. Use a sponge or brush

to apply the foam. Rub in overlapping cir-

cles. Do not use water. Wipe dirty surfaces

and let them dry. Excellent results are

obtained by keeping the carpet as dry as

possible.

■

Handling the seat belts

Clean with mild soap and lukewarm water

using a cloth or sponge. Also check the

belts periodically for excessive wear, fraying

or cuts.

Cleaning and protecting the
vehicle interior

Perform cleaning in a manner
appropriate to each component
and its material.

Protecting the vehicle interior

WARNING

■

Water in the vehicle

●

Do not splash or spill liquid in the vehi-

cle, such as on the floor, in the hybrid

battery (traction battery) air vents, and

in the luggage compartment. (



P.98)

Doing so may cause the hybrid battery,

electrical components, etc. to mal-

function or catch fire.

●

Do not get any of the SRS components

or wiring in the vehicle interior wet.

(



P.37)

An electrical malfunction may cause

the airbags to deploy or not function

properly, resulting in death or serious

injury.

●

Vehicles with wireless charger: Do not

let the wireless charger (



P.469) get

wet. Failure to do so may cause the

charger to become hot and cause

burns or could cause electric shock

resulting in death or serious injury.

■

Cleaning the interior (especially

instrument panel)

Do not use polish wax or polish cleaner.

The instrument panel may reflect off the

windshield, obstructing the driver’s view

and leading to an accident, resulting in

death or serious injury.

NOTICE

■

Cleaning detergents

●

Do not use the following liquids, as

they may discolor the vehicle interior

or cause streaks or damage to painted

surfaces:

• Areas other than the seats and steer-

ing wheel: Organic substances such as

benzene or gasoline, alkaline or acidic

solutions, dye, and bleach

• Seats: Alkaline or acidic solutions,

such as thinner, benzene, and alcohol

485

6-1. Maintenance and care

Ma
inte
na

e and care



Remove dirt and dust using a vac-
uum cleaner.



Wipe off any excess dirt and dust
with a soft cloth dampened with
diluted detergent.

Use a diluted water solution of approxi-
mately 5% neutral wool detergent.



Wring out any excess water from
the cloth and thoroughly wipe off all
remaining traces of detergent.



Wipe the surface with a dry, soft
cloth to remove any remaining
moisture. Allow the leather to dry in
a shaded and ventilated area.

■

Caring for leather areas

Lexus recommends cleaning the interior of

the vehicle at least twice a year to maintain

the quality of the vehicle’s interior.



Remove dirt and dust using a vac-
uum cleaner.

NOTICE

• Steering wheel: Organic substances,

such as thinner, and cleaner that con-

tains alcohol

●

Do not use polish wax or polish

cleaner. The instrument panel’s or

other interior part’s painted surface

may be damaged.

■

Preventing damage to leather sur-

faces

Observe the following precautions to

avoid damage to and deterioration of

leather surfaces:

●

Remove any dust or dirt from leather

surfaces immediately.

●

Do not expose the vehicle to direct

sunlight for extended periods of time.

Park the vehicle in the shade, espe-

cially during summer.

●

Do not place items made of vinyl, plas-

tic, or containing wax on the uphol-

stery, as they may stick to the leather

surface if the vehicle interior heats up

significantly.

■

Water on the floor

Do not wash the vehicle floor with water.

Vehicle systems such as the audio system

may be damaged if water comes into

contact with electrical components such

as the audio system above or under the

floor of the vehicle. Water may also

cause the body to rust.

■

When cleaning the inside of the wind-

shield

Do not allow glass cleaner to contact the

lens. Also, do not touch the lens.

(



P.271)

■

Cleaning the inside of the rear win-

dow

●

Do not use glass cleaner to clean the

rear window, as this may cause dam-

age to the rear window defogger

heater wires or antenna. Use a cloth

dampened with lukewarm water to

gently wipe the window clean. Wipe

the window in strokes running parallel

to the heater wires or antenna.

●

Be careful not to scratch or damage

the heater wires or antenna.

Cleaning the leather areas

Cleaning the synthetic leather
areas

487

6-2. Maintenance

Ma
inte
na

e and care

6-2.Maintenance

■

Where to go for maintenance service?

In order to maintain your vehicle in the best

possible condition, Lexus recommends that

maintenance service operations as well as

other inspections and repairs be carried out

by authorized Lexus retailers or Lexus

authorized repairers, or any reliable repair-

ers. For repairs and services covered by

your warranty, please visit an authorized

Lexus retailer or repairer, who will use gen-

uine Lexus parts in repairing any difficulties

you may encounter. There can also be

advantages in utilizing authorized Lexus

retailers or repairers for non-warranty

repairs and services, as members of the

Lexus network will be able to expertly assist

you with any difficulties you may encounter.
Your Lexus retailer or Lexus authorized

repairer, or any reliable repairer will per-

form all of the scheduled maintenance on

your vehicle reliably and economically due

to their experience with Lexus vehicles.

Scheduled maintenance should be
performed at specified intervals
according to the maintenance sched-
ule.

For full details of your maintenance sched-
ule, refer to the “Lexus Service Booklet” or
“Lexus Warranty Booklet”.

What about do-it-yourself mainte-
nance?

Many maintenance items are easy to do
yourself if you have a little mechanical abil-
ity and a few basic automotive tools.
Note, however, that some maintenance
tasks require special tools and skills. These
are best performed by qualified techni-
cians. Even if you’re an experienced
do-it-yourself mechanic, we recommend
that repairs and maintenance be con-
ducted by any authorized Lexus retailer or
Lexus authorized repairer, or any reliable
repairer. Any authorized Lexus retailer or
repairer will keep a record of maintenance,
which could be useful should you ever
require Warranty Service. Should you
choose to select a qualified and equipped
professional other than an authorized
Lexus repairer to service or maintain your
vehicle, we recommend that you request
that a record of maintenance be kept.

■

Does your vehicle need repairs?

Be on the alert for changes in performance

and sounds, and visual tip-offs that indicate

service is needed. Some important clues

are:

●

Engine missing, stumbling or pinging

Maintenance requirements
(except for India)

To ensure safe and economical driv-
ing, day-to-day care and regular
maintenance are essential. Lexus
recommends the following mainte-
nance:

WARNING

■

If your vehicle is not properly main-

tained

Improper maintenance could result in

serious damage to the vehicle and possi-

ble death or serious injury.

■

Handling of the 12-volt battery

12-volt battery posts, terminals and

related accessories contain lead and

lead compounds which are known to

cause brain damage. Wash your hands

after handling. (



P.506)

Scheduled maintenance

Do-it-yourself maintenance

488

6-2. Maintenance

●

Appreciable loss of power

●

Strange engine noises

●

A fluid leak under the vehicle (However,

water dripping from the air conditioning

system after use is normal.)

●

Change in exhaust sound (This may indi-

cate a dangerous carbon monoxide leak.

Drive with the windows open and have

the exhaust system checked immedi-

ately.)

●

Flat-looking tires, excessive tire squeal

when cornering, uneven tire wear

●

Vehicle pulls to one side when driven

straight on a level road

●

Strange noises related to suspension

movement

●

Loss of brake effectiveness, spongy feel-

ing brake pedal, pedal almost touches the

floor, vehicle pulls to one side when brak-

ing

●

Engine coolant temperature continually

higher than normal (



P.112)

If you notice any of these clues, take your

vehicle to any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer as soon as possible. Your vehicle

may need adjustment or repair.



Scheduled maintenance should be
performed at specified intervals
according to the maintenance
schedule.

The interval for scheduled maintenance is
determined by the odometer reading or
the time interval, whichever comes first,
shown in the schedule.
Maintenance beyond the last period
should be performed at the same intervals.



Where to go for maintenance ser-
vice?

It makes good sense to take your vehicle to
your local Lexus dealer for maintenance
service as well as other inspections and

Maintenance requirements
(for India)

To ensure safe and economical driv-
ing, day-to-day care and regular
maintenance are essential. Lexus
recommends the following mainte-
nance:

WARNING

■

If your vehicle is not properly main-

tained

Improper maintenance could result in

serious damage to the vehicle and possi-

ble death or serious injury.

■

Handling of the 12-volt battery

12-volt battery posts, terminals and

related accessories contain lead and

lead compounds which are known to

cause brain damage. Wash your hands

after handling. (



P.506)

Scheduled maintenance

489

6-2. Maintenance

Ma
inte
na

e and care

repairs.
Lexus technicians are well-trained special-
ists receiving the latest service information
through technical bulletins, service tips and
in-dealership training programs. They
learn to work on Lexus before they work
on your vehicle, rather than while they are
working on it. Doesn’t that seem like the
best way?
Your Lexus dealer has invested a lot of
money in special Lexus tools and service
equipment. It helps them to do the job bet-
ter and at less cost.
Your Lexus dealer’s service department
will perform all of the scheduled mainte-
nance on your vehicle reliably and eco-
nomically.
Rubber hoses (for cooling and heater sys-
tem, brake system and fuel system) should
be inspected by a qualified technician
according to the Lexus maintenance
schedule.
Rubber hoses are particularly important
maintenance items. Have any deteriorated
or damaged hoses replaced immediately.
Note that rubber hoses will deteriorate
with age, resulting in swelling, chafing or
cracking.

What about do-it-yourself mainte-
nance?

Many of the maintenance items are easy to
do yourself if you have a little mechanical
ability and a few basic automotive tools.
Simple instructions for how to perform
them are presented in this section.
Note, however, that some maintenance
tasks require special tools and skills. These
are best performed by qualified techni-

cians. Even if you are an experienced
do-it-yourself mechanic, we recommend
that repairs and maintenance be con-
ducted by your Lexus dealer who will keep
a record of maintenance on your vehicle.
This record could be helpful should you
ever require Warranty Service.

■

Does your vehicle need repairs?

Be on the alert for changes in performance

and sounds, and visual tip-offs that indicate

service is needed. Some important clues

are:

●

Engine missing, stumbling or pinging

●

Appreciable loss of power

●

Strange engine noises

●

A fluid leak under the vehicle (However,

water dripping from the air conditioning

system after use is normal.)

●

Change in exhaust sound (This may indi-

cate a dangerous carbon monoxide leak.

Drive with the windows open and have

the exhaust system checked immedi-

ately.)

●

Flat-looking tires, excessive tire squeal

when cornering, uneven tire wear

●

Vehicle pulls to one side when driven

straight on a level road

●

Strange noises related to suspension

movement

●

Loss of brake effectiveness, spongy feel-

ing brake pedal, pedal almost touches the

floor, vehicle pulls to one side when brak-

ing

●

Engine coolant temperature continually

higher than normal (



P.112)

If you notice any of these clues, take your

vehicle to your Lexus dealer as soon as pos-

sible. Your vehicle may need adjustment or

repair.

Do-it-yourself maintenance

490

6-2. Maintenance

If you mainly operate your vehicle under one or more of the special operating con-
ditions below, some of the maintenance schedule items need to be serviced more
frequently in order to keep your vehicle in good condition. (See “Additional mainte-
nance schedule”.)

Maintenance operations:
I = Inspect, correct or replace as necessary
R = Replace, change or lubricate
C = Cleaning

Scheduled maintenance (for India)

Perform maintenance by the schedule as follows:

Maintenance schedule requirements

Your vehicle needs to be serviced according to the normal maintenance schedule. (See
“Maintenance schedule”.)

A. Road Conditions
1. Operating on rough or muddy roads, or
roads with melted snow or waterlogged
roads.
2. Operating on dusty roads. (Roads in areas
where their pavement rate is low, or a cloud
of dust often arises and the air is dry.)

B. Driving Conditions
1. Heavily loaded vehicle. (For example,
using a car top carrier and so forth.)
2. Extensive idling and/or low speed driving
for a long distance such as police, profes-
sional/private use like taxi or door-to-door
delivery use.
3. Continuous high speed driving (80% or
more of maximum vehicle speed) for over 2
hours.

Maintenance schedule

SERVICE INTERVAL: ODOMETER READING

MONTHS

(Odometer reading or
months, whichever
comes first.)

x1000 km

10 20 30 40 50 60 70 80

x1000 miles

6 12 18 24 30 36 42 48

BASIC ENGINE COMPONENTS

1 Drive belts (RX500h)

491

6-2. Maintenance

Ma
inte
na

e and care

2 Engine oil

Replace when the maintenance reminder
appears. <<See note 1.>>

3 Engine oil filter

Replace when the maintenance reminder
appears. <<See note 1.>>

Cooling and heater system <<See
note 2.>>

Engine coolant (Including inter-
cooler coolant) (RX350h) <<See
note 3.>>

Power control unit coolant
(Including intercooler coolant)
(RX500h) <<See note 4.>>

7 Exhaust pipes and mountings

IGNITION SYSTEM

Spark
plugs

RX350h

Replace every 100000 km (60000 miles).

RX500h

9 12-volt battery

10 Fuel filter <<See note 5.>>

FUEL AND EMISSION CONTROL SYSTEMS

11 Air cleaner filter

I: 24

R:48

Fuel tank cap, fuel lines, connec-
tions and fuel vapor control valve
<<See note 2.>>

13 Charcoal canister

Hybrid battery (traction battery)
cooling intake filter <<See note
6.>>

SERVICE INTERVAL: ODOMETER READING

MONTHS

(Odometer reading or
months, whichever
comes first.)

x1000 km

10 20 30 40 50 60 70 80

x1000 miles

6 12 18 24 30 36 42 48

492

6-2. Maintenance

NOTE:

1. Replace both the engine oil and oil filter, even when the maintenance reminder

does not appear, after 12 months have passed, or when driven over 10000 km

(6000 miles) since the last oil change. This may cause the maintenance reminder

appear even when driven less than 10000 km (6000 miles). Replace both engine

oil and oil filter every 5000 km (3000 miles) or 6 months, in which the vehicle is

mainly driven in dirt or dusty roads, when the maintenance reminder does not

appear.

CHASSIS AND BODY

15 Brake pedal and parking brake

<<See note 7.>>

16 Brake pads and discs

17 Brake fluid

I: 6

R:24

18 Brake pipes and hoses

19 Vacuum pump (RX500h) <<See

note 8.>>

Inspect every 200000 km (120000 miles).

20 Steering wheel, linkage and steer-

ing gear box

21 Drive shaft boots

22 Suspension ball joints and dust

covers

23 Transmission fluid (including front

differential)

24 Rear differential oil <<See note 9.>>

25 Front and rear suspension

26 Tires and inflation pressure

27 Lights, horns, wipers and washers

28 Air conditioning filter

29 Air conditioner condenser dryer Replace every 80000 km (48000 miles) or 48

months.

SERVICE INTERVAL: ODOMETER READING

MONTHS

(Odometer reading or
months, whichever
comes first.)

x1000 km

10 20 30 40 50 60 70 80

x1000 miles

6 12 18 24 30 36 42 48

493

6-2. Maintenance

Ma
inte
na

e and care

2. After 80000 km (48000 miles) or 48 months inspection, inspect every
20000 km (12000 miles) or 12 months.
3. First replace at 160000 km (100000 miles), then replace every 80000 km
(50000 miles).
4. First replace at 240000 km (150000 miles), then replace every 80000 km
(50000 miles).
5. Including the filter in fuel tank.
6. Visually check the hybrid battery (traction battery) cooling intake filter for dirt or
dust every 10000 km (6000 miles) and clean if necessary. Clean every 30000
km (18000 miles).
7. Parking brake inspection is not necessary.
8. Replace the vacuum pump vane and the vacuum pump vane caps with new ones
and never reuse the vacuum pump vane and the vacuum pump vane caps.
9. Integrated in rear transaxle.

Refer to the following table for normal maintenance schedule items requiring more
frequent service specific to the type of severe conditions. (For outline, see “Mainte-
nance schedule requirements”.)

Additional maintenance schedule

A-1: Operating on rough or muddy roads, or roads with melted snow or waterlogged
roads.



Inspection

of brake pads and discs

Every 5000 km (3000 miles) or 3 months



Inspection

of brake pipes and hoses

Every 10000 km (6000 miles) or 6 months



Inspection

of steering wheel, linkage and

steering gear box

Every 5000 km (3000 miles) or 3 months



Inspection

of drive shaft boots

Every 10000 km (6000 miles) or 12
months



Inspection

of suspension ball joints and

dust covers

Every 10000 km (6000 miles) or 6 months



Inspection

of front and rear suspension

Every 10000 km (6000 miles) or 6 months



Tightening of bolts and nuts on chassis and
body <<See note 1.>>

Every 10000 km (6000 miles) or 6 months

494

6-2. Maintenance

A-2: Operating on dusty roads. (Roads in areas where their pavement rate is low, or a
cloud of dust often arises and the air is dry.)



Inspection

or replacement of air cleaner

filter

I: Every 2500 km (1500 miles) or 3 months
R: Every 40000 km (24000 miles) or 48
months



Inspection

of brake pads and discs

Every 5000 km (3000 miles) or 3 months

B-1: Heavily loaded vehicle. (For example, using a car top carrier and so forth.)



Inspection

of brake pads and discs

Every 5000 km (3000 miles) or 3 months



Inspection

or replacement of transmis-

sion fluid (including front differential)

I: Every 40000 km (24000 miles) or 24
months
R: Every 80000 km (48000 miles) or 48
months



Inspection

or replacement of rear differ-

ential oil <<See note 2.>>

I: Every 40000 km (24000 miles) or 24
months
R: Every 80000 km (48000 miles) or 48
months



Inspection

of front and rear suspension

Every 10000 km (6000 miles) or 6 months



Tightening of bolts and nuts on chassis and
body <<See note 1.>>

Every 10000 km (6000 miles) or 6 months

B-2: Extensive idling and/or low speed driving for a long distance such as police, profes-
sional/private use like taxi or door-to-door delivery use.



Inspection

of brake pads and discs

Every 5000 km (3000 miles) or 3 months



Inspection

or replacement of transmis-

sion fluid (including front differential)
(RX500h)

I: Every 40000 km (24000 miles) or 24
months
R: Every 80000 km (48000 miles) or 48
months

495

6-2. Maintenance

Ma
inte
na

e and care

NOTE:
1. For seat mounting bolts, front and rear suspension member retaining bolts.
2. Integrated in rear transaxle.

: Perform correction or replacement as necessary.

B-3: Continuous high speed driving (80% or more of maximum vehicle speed) for over 2
hours.



Inspection

or replacement of transmis-

sion fluid (including front differential)

I: Every 40000 km (24000 miles) or 24
months
R: Every 80000 km (48000 miles) or 48
months



Inspection

or replacement of rear differ-

ential oil <<See note 2.>>

I: Every 40000 km (24000 miles) or 24
months
R: Every 80000 km (48000 miles) or 48
months

496

6-3. Do-it-yourself maintenance

6-3.Do-it-yourself maintenance

Do-it-yourself service pre-
cautions

If you perform maintenance by
yourself, be sure to follow the cor-
rect procedure as given in these
sections.

Maintenance

Items

Parts and tools

12-volt battery
condition
(



P.506)

• Grease
• Conventional

wrench (for terminal
clamp bolts)

Engine/inter-
cooler/power
control coolant
level (



P.503)

• “Toyota Super Long

Life Coolant” or a
similar high quality
ethylene gly-
col-based non-sili-
cate, non-amine,
non-nitrite and
non-borate coolant
with long-life hybrid
organic acid tech-
nology
“Toyota Super Long
Life Coolant” is
pre-mixed with 50%
coolant and 50%
deionized water.

• Funnel (used only for

adding coolant)

Engine oil level
(



P.500)

• “Toyota Genuine

Motor Oil” or equiv-
alent

• Rag or paper towel
• Funnel (used only for

adding engine oil)

Fuses (



P.529)

• Fuse with same

amperage rating as
original

Light bulbs
(



P.531)

• Bulb with same num-

ber and wattage rat-
ing as original

Radiator, con-
denser and inter-
cooler radiator
(



P.505)



Tire inflation pres-
sure (



P.519)

• Tire pressure gauge
• Compressed air

source

Washer fluid
(



P.505)

• Water or washer

fluid containing anti-
freeze (for winter
use)

• Funnel (used only for

adding water or
washer fluid)

WARNING

The engine compartment contains many

mechanisms and fluids that may move

suddenly, become hot, or become elec-

trically energized. To avoid death or seri-

ous injury, observe the following

precautions.

■

When working on the engine com-

partment

●

Make sure that the “ACCESSORY” or

“IGNITION ON” on the multi-infor-

mation display and the “READY” indi-

cator are both off.

●

Keep hands, clothing and tools away

from the moving fan.

Items

Parts and tools

497

6-3. Do-it-yourself maintenance

Ma
inte
na

e and care

Pull the hood lock release lever.

The hood will pop up slightly.

Pull up the auxiliary catch lever and
lift the hood.

WARNING

●

Be careful not to touch the engine,

power control unit, radiator, exhaust

manifold, etc. right after driving as they

may be hot. Oil and other fluids may

also be hot.

●

Do not leave anything that may burn

easily, such as paper and rags, in the

engine compartment.

●

Take care because brake fluid can

harm your hands or eyes and damage

painted surfaces. If fluid gets on your

hands or in your eyes, flush the

affected area with clean water imme-

diately.

If you still experience discomfort, con-

sult a doctor.

■

When working near the electric cool-

ing fan or radiator grille

Be sure the power switch is off.

With the power switch in ON, the elec-

tric cooling fan may automatically start to

run if the air conditioning is on and/or the

coolant temperature is high. (



P.505)

■

Safety glasses

Wear safety glasses to prevent flying or

falling material, fluid spray, etc. from get-

ting in your eyes.

NOTICE

■

If you remove the air cleaner filter

Driving with the air cleaner filter

removed may cause excessive engine

wear due to dirt in the air.

■

If the fluid level is low or high

It is normal for the brake fluid level to go

down slightly as the brake pads wear or

when the fluid level in the accumulator is

high.

If the reservoir needs frequent refilling, it

may indicate a serious problem.

Hood

Opening the hood

WARNING

■

When the hood is open (RX500h)

Even if the power switch is turned off, the

cooling fan may continue to operate for a

short time. When the cooling fan is rotat-

ing, do not touch or approach the inside

of the engine compartment.

■

Pre-driving check

Check that the hood is fully closed and

locked.

If the hood is not locked properly, it may

open while the vehicle is in motion and

cause an accident, which may result in

death or serious injury.

499

6-3. Do-it-yourself maintenance

Ma
inte
na

e and care



RX500h

Fuse boxes (



P.529)

Engine oil filler cap (



P.502)

Washer fluid tank (



P.505)

Radiator (



P.505)

Electric cooling fan
Condenser (



P.505)

Engine oil level dipstick (



P.500)

Intercooler radiator (



P.505)

Intercooler/Power control unit coolant reservoir (



P.503)

Engine coolant reservoir (



P.503)

Engine compartment

Components

A
B
C
D

E
F

500

6-3. Do-it-yourself maintenance



RX350h

Fuse boxes (



P.529)

Engine oil filler cap (



P.502)

Engine oil level dipstick (



P.500)

Washer fluid tank (



P.505)

Radiator (



P.505)

Electric cooling fan
Condenser (



P.505)

Power control unit coolant reservoir (



P.503)

Engine coolant reservoir (



P.503)

■

12-volt battery



P.506

With the engine at operating tempera-
ture and turned off, check the oil level
on the dipstick.

Park the vehicle on level ground.
After warming up the engine and
turning off the hybrid system, wait
about 5 minutes for the oil to drain
back into the bottom of the engine.

Holding a rag under the end, pull
the dipstick out.

A
B
C
D

E
F

Checking the engine oil

501

6-3. Do-it-yourself maintenance

Ma
inte
na

e and care



RX500h



RX350h

Wipe the dipstick clean.

Reinsert the dipstick fully.

Holding a rag under the end, pull
the dipstick out and check whether
the oil level is above low level mark.

Low level mark

The shape of the dipstick may differ

depending on the type of vehicle or

engine.

Wipe the dipstick and reinsert it
fully.

■

Engine oil consumption

A certain amount of engine oil will be con-

sumed while driving. In the following situa-

tions, oil consumption may increase, and

engine oil may need to be refilled in

between oil maintenance intervals.

●

When the engine is new, for example

directly after purchasing the vehicle or

after replacing the engine

●

If low quality oil or oil of an inappropriate

viscosity is used

●

When driving at high engine speeds or
with a heavy load, when towing

, or when

driving while accelerating or decelerat-

ing frequently

●

When leaving the engine idling for a long

time, or when driving frequently through

heavy traffic

: Vehicles with towing package

■

Engine oil level rise

If the vehicle is repeatedly driven without

the engine warmed up, moisture caused by

dew condensation inside the engine or fuel

which did not burn mixes into the engine oil,

resulting in a rise in engine oil level. How-

ever, this is not a malfunction.
For example, the engine become difficult to

be warmed up in the following situations.

●

When driving a short distance

●

When driving at a low speed

●

When the outside temperature is low

When checking the engine oil, make sure

that the engine is warmed up. If the engine

oil level exceeds the refill upper limit mark,

contact any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer.

502

6-3. Do-it-yourself maintenance

■

Checking the oil type and prepar-
ing the item needed

Make sure to check the oil type and
prepare the items needed before add-
ing oil.



Engine oil selection



P.614



Oil quantity (Low level mark



Refill upper limit mark)
1.5 L (1.6 qt., 1.3 Imp. qt.)



Item
Clean funnel

■

Adding engine oil

If the oil level is below or near the low
level mark, add engine oil of the same
type as that already in the engine.



RX500h



RX350h

Remove the oil filler cap by turning
it counterclockwise.

Add engine oil slowly, checking the
dipstick.

Make sure that the oil level does not

exceed the refill upper limit mark and is

between the low level mark and refill upper

limit mark.

Low level mark
Refill upper limit mark

The shape of the dipstick may differ
depending on the type of vehicle or
engine.

Install the oil filler cap by turning it
clockwise.

■

After changing the engine oil

After the engine oil has been replaced, the

engine oil maintenance data should be

reset. Perform the following procedures:

NOTICE

■

To prevent serious engine damage

Check the oil level on a regular basis.

Adding engine oil

A
B

503

6-3. Do-it-yourself maintenance

Ma
inte
na

e and care

Select

on the center display.

Select “Vehicle customise”.

Select “Utility”.

Select “Oil maintenance”.

Select “Reset”.

“The data has been reset.” will be displayed

on the center display when the resetproce-

dure has been completed.

■

Engine coolant reservoir

The coolant level is satisfactory if it is
between the “MAX” and “MIN” lines
on the reservoir when the hybrid sys-
tem is cold.



RX500h

Reservoir cap
“MAX” line
“MIN” line

If the level is on or below the “MIN” line,
add coolant up to the “MAX” line.
(



P.602)

WARNING

■

Used engine oil

●

Used engine oil contains potentially

harmful contaminants which may

cause skin disorders such as inflamma-

tion and skin cancer, so care should be

taken to avoid prolonged and

repeated contact. To remove used

engine oil from your skin, wash thor-

oughly with soap and water.

●

Dispose of used oil and filters only in a

safe and acceptable manner. Do not

dispose of used oil and filters in house-

hold trash, in sewers or onto the

ground.

Call any authorized Lexus retailer or

Lexus authorized repairer, or any relia-

ble repairer, service station or auto

parts store for information concerning

recycling or disposal.

●

Do not leave used engine oil within the

reach of children.

NOTICE

■

When replacing the engine oil

●

Be careful not to spill engine oil on the

vehicle components.

●

Avoid overfilling, or the engine could

be damaged.

●

Check the oil level on the dipstick

every time you refill the vehicle.

●

Be sure the engine oil filler cap is prop-

erly tightened.

■

If oil is spilled on the engine cover

To prevent the engine cover from being

damaged, remove any engine oil from

the engine cover as soon as possible

using a neutral detergent. Do not use an

organic solvent such as brake cleaner.

Checking the coolant

A
B
C

504

6-3. Do-it-yourself maintenance



RX350h

Reservoir cap
“MAX” line
“MIN” line

If the level is on or below the “MIN” line,
add coolant up to the “MAX” line.
(



P.602)

■

Intercooler/Power control unit
coolant reservoir (RX500h)

The coolant level is satisfactory if it is
between the “MAX” and “MIN” lines
on the reservoir when the engine is
cold.

Reservoir cap
“MAX” line
“MIN” line

If the level is on or below the “MIN” line,
add coolant up to the “MAX” line.
(



P.602)

■

Power control unit coolant reser-
voir (RX350h)

The coolant level is satisfactory if it is
between the “FULL” and “LOW” lines
on the reservoir when the hybrid sys-
tem is cold.

Reservoir cap
“FULL” line
“LOW” line

If the level is on or below the “LOW” line,
add coolant up to the “FULL” line.
(



P.602)

■

Coolant selection

Only use “Toyota Super Long Life Coolant”

or a similar high quality ethylene glycol

based non-silicate, non-amine, non-nitrite,

and non-borate coolant with long-life

hybrid organic acid technology.
“Toyota Super Long Life Coolant” is a mix-

ture of 50% coolant and 50% deionized

water. (Minimum temperature: -35°C

[-31°F])
For more details about coolant, contact any

authorized Lexus retailer or Lexus author-

ized repairer, or any reliable repairer.

■

If the coolant level drops within a short

time of replenishing

Visually check the radiator, hoses,

engine/power control unit coolant reservoir

caps, drain cock and water pump.

If you cannot find a leak, have any author-

ized Lexus retailer or Lexus authorized

A
B
C

505

6-3. Do-it-yourself maintenance

Ma
inte
na

e and care

repairer, or any reliable repairer, test the

cap and check for leaks in the cooling sys-

tem.

: RX500h only

Check the radiator, condenser and
intercooler radiator (RX500h only)
and clear away any foreign objects.
If either of the above parts is extremely
dirty or you are not sure of their condi-
tion, have your vehicle inspected by
any authorized Lexus retailer or Lexus
authorized repairer, or any reliable

repairer.

If any washer does not work or the
warning message appears on the
multi-information display, the washer
tank may be empty. Add washer fluid.



RX500h



RX350h

WARNING

■

When the hybrid system is hot

Do not remove the engine/inter-
cooler

/power control unit coolant res-

ervoir caps and radiator cap.

The cooling system may be under pres-

sure and may spray hot coolant if the cap

is removed, causing serious injuries, such

as burns.

: RX500h only

NOTICE

■

When adding coolant

Coolant is neither plain water nor

straight antifreeze. The correct mixture

of water and antifreeze must be used to

provide proper lubrication, corrosion

protection and cooling. Be sure to read

the antifreeze or coolant label.

■

If you spill coolant

Be sure to wash it off with water to pre-

vent it from damaging parts or paint.

Checking the radiator, con-
denser and intercooler radiator

WARNING

■

When the hybrid system is hot

Do not touch the radiator, condenser or
intercooler radiator

as they may be hot

and cause serious injuries, such as burns.

: RX500h only

Washer fluid

506

6-3. Do-it-yourself maintenance

The 12-volt battery is located in the
right-hand side of luggage compart-
ment.

■

Before recharging

When recharging, the 12-volt battery pro-

duces hydrogen gas which is flammable

and explosive. Therefore, observe the fol-

lowing precautions before recharging:

●

If recharging with the 12-volt battery

installed on the vehicle, be sure to discon-

nect the ground cable.

●

Make sure the power switch on the

charger is off when connecting and dis-

connecting the charger cables to the

12-volt battery.

■

After recharging/reconnecting the

12-volt battery

●

Unlocking the doors using the smart

entry & start system may not be possible

immediately after reconnecting the

12-volt battery. If this happens, use the

wireless remote control or the mechani-

cal key to lock/unlock the doors.

●

Start the hybrid system with the power

switch in ACC. The hybrid system may

not start with the power switch turned off.

However, the hybrid system will operate

normally from the second attempt.

●

The power switch mode is recorded by

the vehicle. If the 12-volt battery is dis-

WARNING

■

When adding washer fluid

Do not add washer fluid when the hybrid

system is hot or operating as washer fluid

contains alcohol and may catch fire if

spilled on the engine, etc.

NOTICE

■

Do not use any fluid other than

washer fluid

Do not use soapy water or engine anti-

freeze instead of washer fluid.

Doing so may cause streaking on the

vehicle’s painted surfaces, as well as

damaging the pump leading to problems

of the washer fluid not spraying.

■

Diluting washer fluid

Dilute washer fluid with water as neces-

sary.

Refer to the freezing temperatures listed

on the label of the washer fluid bottle.

12-volt battery

Location

507

6-3. Do-it-yourself maintenance

Ma
inte
na

e and care

connected and reconnected, the vehicle

will return the power switch mode to the

status it was in before the 12-volt battery

was disconnected. Make sure to turn off

the power switch before disconnecting

the 12-volt battery. Take extra care when

connecting the 12-volt battery if the

power switch mode prior to the 12-volt

battery being disconnected is unknown.

If the system will not start even after multiple

attempts at all the methods above, contact

any authorized Lexus retailer or Lexus

authorized repairer, or any reliable repairer.

WARNING

■

Chemicals in the 12-volt battery

The 12-volt battery contains poisonous

and corrosive sulfuric acid and may pro-

duce hydrogen gas which is flammable

and explosive. To reduce the risk of death

or serious injury, take the following pre-

cautions while working on or near the

12-volt battery:

●

Do not cause sparks by touching the

12-volt battery terminals with tools.

●

Do not smoke or light a match near the

12-volt battery.

●

Avoid contact with eyes, skin and

clothes.

●

Never inhale or swallow electrolyte.

●

Wear protective safety glasses when

working near the 12-volt battery.

●

Keep children away from the 12-volt

battery.

■

Where to safely charge the 12-volt

battery

Always charge the 12-volt battery in an

open area. Do not charge the 12-volt bat-

tery in a garage or closed room where

there is insufficient ventilation.

■

Emergency measures regarding

electrolyte

●

If electrolyte gets in your eyes

Flush your eyes with clean water for at

least 15 minutes and get immediate

medical attention. If possible, continue

to apply water with a sponge or cloth

while traveling to the nearest medical

facility.

●

If electrolyte gets on your skin

Wash the affected area thoroughly. If

you feel pain or burning, get medical

attention immediately.

●

If electrolyte gets on your clothes

It can soak through clothing on to your

skin. Immediately take off the clothing

and follow the procedure above if nec-

essary.

●

If you accidentally swallow electrolyte

Drink a large quantity of water or milk.

Get emergency medical attention

immediately.

■

When replacing the 12-volt battery

Use a 12-volt battery designed for this

vehicle. Failure to do so may cause gas

(hydrogen) to enter the passenger com-

partment, causing a fire or explosion.

For replacement of the 12-volt battery,

contact any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer.

■

When handling the 12-volt battery



P.601

NOTICE

■

When recharging the 12-volt battery

Never recharge the 12-volt battery while

the hybrid system is operating. Also, be

sure all accessories are turned off.

Lexus RX (2023 year). Manual in english - page 15
