Lexus LS (2023 year). Manual in english

130

3-1. Key information

The electronic keys are equipped with
the following wireless remote control:

Locks the doors (



P.132)

Closes the windows and moon
roof

(



P.132)

Unlocks the doors (



P.132)

Opens the windows and moon
roof

(



P.132)

Opens the trunk (



P.140)

: These settings must be customized at

any authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

To take out the mechanical key, push
the release button and take the key out.

The mechanical key can only be inserted in
one direction, as the key only has grooves
on one side. If the key cannot be inserted in
a lock cylinder, turn it over and re-attempt
to insert it.
After using the mechanical key, store it in

NOTICE

■

When an electronic key is lost



P.511

■

Handling the card key (if equipped)

●

Do not apply excess force when insert-

ing the mechanical key into the card

key. Doing so may damage the card

key.

●

If the battery or card key terminals get

wet, the battery may corrode and the

card key may stop working.

If the key is dropped into water, or if

drinking water, etc. is spilled on the key,

immediately remove the battery cover

and wipe the battery and terminals. (To

remove the battery cover, lightly grasp

and pull it.) If the battery is corroded,

have any authorized Lexus retailer or

Lexus authorized repairer, or any relia-

ble repairer replace the battery.

●

Do not crush the battery cover or use

a screwdriver to remove the battery

cover.

Forcibly removing the battery cover

may bend or damage the key.

●

If the battery cover is frequently

removed, the battery cover may

become loose.

●

When installing the battery, make sure

to check the direction of the battery.

Installing the battery in the wrong

direction may cause the battery to

deplete rapidly.

●

The surface of the card key may be

damaged, or its coating may peel off in

the following situations:

• The card key is carried together with

hard objects, such as coins and keys.

• The card key is scraped with a sharp

object, such as the tip of a mechanical

pencil.

• The surface of the card key is wiped

with thinner or benzene.

Wireless remote control

Using the mechanical key

A
B

C
D

131

3-1. Key information

fore
driving

the electronic key. Carry the mechanical
key together with the electronic key. If the
electronic key battery is depleted or the
entry function does not operate properly,
you will need the mechanical key.
(



P.512)

■

When required to leave the vehicle’s

key with a parking attendant

Turn the trunk opener main switch off

(



P.143) and lock the glove box (



P.415)

as circumstances demand.

Remove the mechanical key for your own

use and provide the attendant with the elec-

tronic key only.

■

If you lose your mechanical keys



P.511

■

If a wrong key is used

The key cylinder rotates freely, isolated

from the internal mechanism.

132

3-2. Opening, closing and locking the doors and trunk

3-2.Opening, closing and locking the doors and trunk

■

Smart entry & start system

Carry the electronic key to enable this
function.

Grip the door handle to unlock the
doors.*

Make sure to touch the sensor on the back
of the handle.
The doors cannot be unlocked for 3 sec-
onds after the doors are locked.

: The door unlock settings can be

changed.

Touch the lock sensor (indentation
on the upper part of the door han-
dle) to lock all the doors.

Check that the door is securely locked.

■

Wireless remote control

Locks all the doors

Check that the door is securely locked.
Press and hold to close the windows and
moon roof.

Unlocks all the doors

Press and hold to open the windows and
moon roof.

: These settings must be customized at

any authorized Lexus retailer or Lexus
authorized repairer, or any reliable
repairer.

■

Switching the door unlock function

It is possible to set which doors the entry

function unlocks using the wireless remote

control.

Turn the power switch off.

Cancel the intrusion sensor and tilt sen-

sor of the alarm system to prevent unin-

tended triggering of the alarm while

changing the settings. (if equipped)

(



P.95)

When the indicator light on the key sur-
face is not on, press and hold

for approximately 5 seconds

while pressing and holding

The setting changes each time an operation

is performed, as shown below. (When

changing the setting continuously, release

the buttons, wait for at least 5 seconds, and

repeat step

Doors

Unlocking and locking the doors
from the outside

133

3-2. Opening, closing and locking the doors and trunk

fore
driving

For vehicles with an alarm: To prevent unin-

tended triggering of the alarm, unlock the

doors using the wireless remote control and

open and close a door once after the set-

tings have been changed. (If a door is not
opened within 30 seconds after

pressed, the doors will be locked again and

the alarm will automatically be set.)

In a case that the alarm is triggered, imme-

diately stop the alarm. (



P.94)

■

Impact detection door lock release sys-

tem

In the event that the vehicle is subject to a

strong impact, all the doors are unlocked.

Depending on the force of the impact or the

type of accident, however, the system may

not operate.

■

Operation signals

The emergency flashers flash to indicate

that the doors have been locked/unlocked.

(Locked: once; Unlocked: twice)

A buzzer sounds to indicate that the win-

dows and moon roof are operating.

■

Security feature

If a door is not opened within approximately

30 seconds after the vehicle is unlocked,

the security feature automatically locks the

vehicle again.

■

When the doors cannot be locked by the

lock sensor on the upper part of the

door handle

When the doors cannot be locked even if

the lock sensor on the upper part of the

door handle is touched by a finger, touch

the lock sensor with the palm.
If you are wearing gloves, remove them.

■

Open door warning buzzer

If an attempt to lock the doors is made when

a door is not fully closed, a buzzer sounds

continuously for 5 seconds. Fully close the

door to stop the buzzer, and lock the vehi-

cle once more.

■

Setting the alarm (if equipped)

Locking the doors will set the alarm system.

(



P.94)

■

Conditions affecting the operation of

the smart entry & start system or wire-

less remote control



P.146

■

If the smart entry & start system or the

wireless remote control does not oper-

ate properly

Use the mechanical key to lock and unlock

the doors. (



P.512)

Replace the key battery with a new one if it

is depleted. (



P.477)

■

If the 12-volt battery is discharged

The doors cannot be locked and unlocked

Multi-information

display/Beep

Unlocking function

(Left-hand drive vehi-

cles)

(Right-hand drive

vehicles)

Exterior: Beeps 3

times

Interior: Pings once

Holding the driver’s
door handle unlocks
only the driver’s
door.

Holding any of the
passenger door
handles unlocks all
the doors.

Exterior: Beeps

twice

Interior: Pings once

Holding a door han-
dle unlocks all the
doors.

134

3-2. Opening, closing and locking the doors and trunk

using the smart entry & start system or

wireless remote control. Lock or unlock the

doors using the mechanical key. (



P.512)

■

Rear seat reminder function

In order to remind you not to forget lug-

gage, etc. in the rear seat, when the power

switch is turned off after any of the following

conditions are met, a buzzer will sound and

a message will be displayed on the

multi-information display for approximately

6 seconds.

●

The hybrid system is started within

approximately 10 minutes after opening

and closing a rear door.

●

A rear door has been opened and closed

after the hybrid system was started.

However, if a rear door is opened and then

closed within approximately 2 seconds, the

rear seat reminder function may not oper-

ate.
The rear seat reminder function determines

that luggage, etc. has been placed in a rear

seat based on opening and closing of a rear

door. Therefore, depending on the situation,

the rear seat reminder function may not

operate and you may still forget luggage,

etc. in the rear seat, or it may operate

unnecessarily.

■

Customization

Some functions can be customized.

(



P.540)

WARNING

■

To prevent an accident

Observe the following precautions while

driving the vehicle.

Failure to do so may result in a door

opening and an occupant throwing out of

the vehicle, resulting in death or serious

injury.

●

Ensure that all doors are properly

closed.

●

Do not pull the inside handle of the

doors while driving.

For India: Be especially careful for the
driver’s door, as the door may be opened
even if the inside lock button is in locked
position.
Except for India: Be especially careful for
the front doors, as the doors may be
opened even if the inside lock buttons
are in locked position.

●

Set the rear door child-protector locks

when children are seated in the rear

seats.

■

When opening or closing a door

Check the surroundings of the vehicle

such as whether the vehicle is on an

incline, whether there is enough space

for a door to open and whether a strong

wind is blowing. When opening or clos-

ing the door, hold the door handle tightly

to prepare for any unpredictable move-

ment.

■

When using the wireless remote con-

trol and operating the power windows

or moon roof

Operate the power windows or the

moon roof after checking to make sure

that there is no possibility of any passen-

ger having any of their body parts caught

in the windows or the moon roof. Also, do

not allow children to operate the wireless

remote control. It is possible for children

and other passengers to get caught in

the power windows or the moon roof.

■

Vehicle height control precautions

In the following situations, make sure to

check the safety of the area around the

vehicle, as the vehicle height may change

and part of someone’s body may be

caught in the vehicle, possibly causing

injury or the vehicle may be damaged.

●

When opening or closing a door

135

3-2. Opening, closing and locking the doors and trunk

fore
driving

■

Door lock switches (to
lock/unlock)

Locks all the doors

Unlocks all the doors

■

Inside lock buttons (to lock)

Push down the inside lock button to
lock the door.

■

Inside door handles (to unlock)



For India

For the driver's door: Pull the handle to
unlock and open the door.

When the door is unlocked, the inside lock
button will pop up.

For the passenger doors: Pull the han-
dle to unlock the door. Pull the handle a
second time to open the door.

When the door is unlocked, the inside lock
button will pop up.



Except for India

For the front doors: Pull the handle to
unlock and open the door.

When the door is unlocked, the inside lock
button will pop up.

For the rear doors: Pull the handle to
unlock the door. Pull the handle a sec-
ond time to open the door.

When the door is unlocked, the inside lock
button will pop up.

■

Locking the front doors from the outside

without a key

Push down the inside lock button.

Close the door while pulling the door

handle.

The door cannot be locked if the power

switch is in ACCESSORY or ON mode, or

the electronic key is left inside the vehicle.

However, the key may not be detected cor-

rectly and the door may be locked.

■

Door closer

In the event that a door is left slightly open,

the door closer will automatically close it to

the fully closed position.

●

The door closer will operate regardless

of the power switch mode.

WARNING

●

When locking the doors

Unlocking and locking the doors
from the inside

136

3-2. Opening, closing and locking the doors and trunk

●

The door closer will not function if the

door has been closed while pulling the

inside or outside door handle.

●

The door can be opened by pulling the

inside or outside door handle, even when

the door closer is operating (except

when the lock button is in the lock posi-

tion or the child-protector lock is set).

●

A motor sound may be heard for several

seconds after the door closer closes the

door. This does not indicate a malfunc-

tion.

■

Open door warning buzzer

If a door or the trunk is not fully closed, a

buzzer will sound when the vehicle speed

reaches 5 km/h (3 mph).

The open door(s) or trunk is indicated on

the multi-information display.

The door cannot be opened from
inside the vehicle when the lock is set.

Unlock

Lock

These locks can be set to prevent children
from opening the rear doors. Push down
on each rear door switch to lock both rear
doors.

The following functions can be set or
canceled:

For instructions on customizing, refer to
P.540.

WARNING

■

Door closer

In the event that a door is left slightly

open, the door closer will automatically

close it to the fully closed position. It

takes several seconds before the door

easy closer begins to operate.

If the child-protector lock is set, the door

closer will not stop during operation even

if an attempt is made to open the door

from inside the vehicle. Be careful not to

catch fingers or anything else in the door.

Failure to do so may result in serious

injury.

NOTICE

■

To prevent door closer malfunction

Do not frequently repeat opening and

closing of doors, or apply excessive force

to a door while the door closer is operat-

ing.

Rear door child-protector lock

Automatic door locking and
unlocking systems

137

3-2. Opening, closing and locking the doors and trunk

fore
driving

Function

Operation

Speed linked
door locking
function

All doors are automati-
cally locked when vehi-
cle speed is
approximately 20
km/h (12 mph) or
higher.

Shift position
linked door lock-
ing function

All doors are automati-
cally locked when the
shift position is shifted
to a position other than
P.

Shift position
linked door
unlocking func-
tion

All doors are automati-
cally unlocked when
the shift position is
shifted to P.

Driver’s door
linked door
unlocking func-
tion

All doors are automati-
cally unlocked when
driver’s door is opened
within approximately
45 seconds after turn-
ing the power switch
off.

Trunk

The trunk can be opened using the
trunk opener switch, entry function
or wireless remote control.

The trunk can be closed using the
trunk closer.

WARNING

Observe the following precautions.

Failure to do so may result in death or

serious injury.

■

Before driving

●

Make sure that the trunk lid is fully

closed. If the trunk lid is not fully

closed, it may open unexpectedly

while driving and hit near-by objects or

luggage in the trunk may be thrown

out, causing an accident.

●

Do not allow children to play in the

trunk.

If a child is accidentally locked in the

trunk, they could suffer from heat

exhaustion, suffocation or other inju-

ries.

●

Do not allow a child to open or close

the trunk lid.

Doing so may cause the trunk lid to

open unexpectedly, or cause the

child’s hands, head, or neck to be

caught by the closing trunk lid.

■

Important points while driving

Never let anyone sit in the trunk. In the

event of sudden braking or a collision,

they are susceptible to death or serious

injury.

■

Using the trunk

Observe the following precautions.

Failure to do so may cause parts of the

body to be caught, resulting in serious

injury.

138

3-2. Opening, closing and locking the doors and trunk

WARNING

●

Remove any heavy loads, such as snow

and ice, from the trunk lid before

opening it. Failure to do so may cause

the trunk lid to suddenly shut again

after it is opened.

●

When opening or closing the trunk lid,

thoroughly check to make sure the

surrounding area is safe.

●

If anyone is in the vicinity, make sure

they are safe and let them know that

the trunk is about to open or close.

●

Use caution when opening or closing

the trunk lid in windy weather as it may

move abruptly in strong wind.

●

The trunk lid may suddenly shut if it is

not opened fully. It is more difficult to

open or close the trunk lid on an

incline than on a level surface, so

beware of the trunk lid unexpectedly

opening or closing by itself. Make sure

that the trunk lid is fully open and

secure before using the trunk.

●

When closing the trunk lid, take extra

care to prevent your fingers etc. from

being caught.

●

When closing the trunk lid, make sure

to press it lightly on its outer surface. If

the trunk handle is used to fully close

the trunk lid, it may result in hands or

arms being caught.

●

Do not attach any accessories other

than genuine Lexus parts to the trunk

lid. Such additional weight on the trunk

lid may cause the lid to suddenly shut

again after it is opened.

■

Trunk easy closer

In the event that the trunk lid is left slightly

open, the trunk easy closer will automati-

cally close it to the fully closed position. It

takes several seconds before the trunk

easy closer begins to operate. Be careful

not to catch fingers or anything else in

the trunk lid, as this may cause bone frac-

tures or other serious injuries.

■

Power trunk lid

Observe the following precautions when

operating the power trunk lid.

Failure to do so may cause serious injury.

●

Check the safety of the surrounding

area to make sure there are no obsta-

cles or anything that could cause any

of your belongings to get caught.

●

If anyone is in the vicinity, make sure

they are safe and let them know that

the trunk is about to open or close.

●

If the trunk closer switch is pressed

while the trunk lid is opening during

automatic operation, the trunk lid

stops opening. Take extra care when

on an incline, as the trunk lid may open

or close suddenly.

139

3-2. Opening, closing and locking the doors and trunk

fore
driving

■

Trunk opener switch

Press the trunk opener switch.

The trunk lid will fully open.

WARNING

●

On an incline, the trunk lid may sud-

denly shut after it opens automatically.

Make sure the trunk lid is fully open

and secure before using the trunk.

●

In the following situations, the power

trunk lid may detect an abnormality

and automatic operation may be

stopped. In this case, the trunk lid has

to be operated manually. Take extra

care in this situation, as the stopped

trunk lid may suddenly shut, causing an

accident.

• When the trunk lid contacts an obsta-

cle

• When the 12-volt battery voltage sud-

denly drops, such as when the power

switch is turned to ON mode or the

hybrid system is started during auto-

matic operation

●

Do not attach any accessories other

than genuine Lexus parts to the trunk

lid. The power trunk lid may not oper-

ate, causing itself to malfunction, or the

trunk lid may suddenly shut again after

it is opened.

■

Hands Free Power Trunk Lid (if

equipped)

Observe the following precautions.

Failure to do so may cause serious injury.

●

Exhaust gasses cause the exhaust

pipes to become quite hot. When

operating the Hands Free Power Trunk

Lid, be careful not to touch the exhaust

pipe.

●

Do not operate the Hands Free Power

Trunk Lid if there is little space under

the rear bumper.

■

Jam protection function

Observe the following precautions.

Failure to do so may cause serious injury.

●

Never use any part of your body to

intentionally activate the jam protec-

tion function.

●

The jam protection function may not

work if something gets caught just

before the trunk lid fully closes. Be

careful not to catch fingers or anything

else in the trunk lid.

●

The jam protection function may not

work depending on the shape of the

object that is caught. Be careful not to

catch fingers or anything else.

NOTICE

■

To prevent trunk easy closer malfunc-

tions

Do not apply force to the trunk lid while

the trunk easy closer is operating.

■

To prevent damage to the power

trunk lid

●

Make sure that there is no luggage or

snow on the trunk lid before operating

the power trunk lid. In addition, make

sure that there is no ice between the

trunk lid and frame that prevents

movement of the trunk lid. Operating

the power trunk lid when excessive

load is present on the trunk lid may

cause a malfunction.

●

Do not apply excessive force to the

trunk lid while the power trunk lid is

operating.

Opening/closing the trunk

140

3-2. Opening, closing and locking the doors and trunk

■

Smart entry & start system

While carrying the electronic key,
press the button.

The trunk lid will fully open.
If the button is pressed while the trunk lid is
opening, the trunk lid will stop moving.

When all the doors are unlocked using
one of the following methods, the trunk
can be opened without the electronic
key:



Entry function



Wireless remote control



Door lock switches



Automatic door unlocking system



Mechanical key

■

Wireless remote control

Press and hold the switch.

The trunk lid will fully open.
If the button is pressed while the trunk lid is

opening, the trunk lid will stop moving.

■

Hands Free Power Trunk Lid (if
equipped)

While carrying an electronic key,
stand within the smart entry & start
system operation area, approxi-
mately 30 to 50 cm (11.8 to 19.7
in.) from the rear bumper.

Kick sensor
Hands Free Power Trunk Lid opera-
tion detection area
Smart entry & start system opera-
tion detection area (



P.145)

A
B

141

3-2. Opening, closing and locking the doors and trunk

fore
driving

Perform a kick operation by mov-
ing your foot to within approxi-
mately 10 cm (3.9 in.) of the rear
bumper and then pulling it back.

• Perform the entire kick operation

within 1 second.

• The trunk lid will not start operating

while a foot is detected under the
rear bumper.

• Operate the Hands Free Power

Trunk Lid without contacting the
rear bumper with your foot.

• If another electronic key is in the

cabin or trunk, it may take slightly
longer than normal for the opera-
tion to begin.

Kick sensor
Hands Free Power Trunk Lid opera-
tion detection area

When the kick sensor detects that
your foot is pulled back, a buzzer
will sound and the trunk will auto-
matically fully open/close.

If a foot is moved under the rear bumper

while the trunk lid is opening, the trunk lid

will stop moving.

If a foot is moved under the rear bumper

while the trunk lid is closing, the trunk lid

will open.

■

Trunk closer switch

Press the trunk closer switch.

A buzzer will sound and the trunk lid will
fully close.
Pressing the switch while the trunk lid is
closing opens the trunk lid again.

■

Trunk grip

Using the trunk grip, pull down the
trunk lid without applying sideways
force and push the trunk lid down from
the outside to close it.

■

Trunk lid light/trunk light

●

The trunk lid light/trunk light turns on

when the trunk is opened.

●

If the trunk lid light/trunk light is left on

when the power switch is turned off, the

light will go off automatically after 20

minutes.

■

Trunk easy closer

In the event that the trunk lid is left slightly

open, the trunk easy closer will automati-

A
B

142

3-2. Opening, closing and locking the doors and trunk

cally close it to the fully closed position.

●

The trunk easy closer will operate

regardless of the power switch mode.

●

If the trunk easy closer does not operate,

open the trunk to the half open position

or more and then close it.

■

Function to prevent the trunk being

locked with the electronic key inside

●

When all doors are locked, closing the

trunk lid with the electronic key left inside

the trunk will sound an alarm.

In this case, the trunk lid can be opened

pressing the trunk release button on the

trunk lid.

●

If the spare electronic key is put in the

trunk with all the doors locked, the key

confinement prevention function is acti-

vated so the trunk can be opened. In

order to prevent theft, take all electronic

keys with you when leaving the vehicle.

●

If the electronic key is put in the trunk with

all the doors locked, the key may not be

detected depending on the location of

the key and the surrounding radio wave

conditions. In this case, the key confine-

ment prevention function cannot be acti-

vated, causing the doors to lock when the

trunk is closed. Make sure to check

where the key is before closing the trunk.

●

The key confinement prevention function

cannot be activated if any one of the

doors is unlocked. In this case, open the

trunk using the trunk opener.

■

Overload protection function

The trunk lid will not operate when exces-

sive load is present on the top of the trunk

lid.

■

Fall-down protection function

While the trunk lid is opening automatically,

applying excessive force to it will stop the

opening operation to prevent the trunk lid

from rapidly falling down.

■

Jam protection function

While the trunk lid is closing automatically,

the trunk lid will stop closing and open if

something gets caught.

■

Using the mechanical key

The trunk can be also opened using the

mechanical key. (



P.513)

If the trunk is unlocked using the mechani-

cal key, the power trunk lid and trunk easy

closer will not be operational. To return

them to an operational state, fully close the

trunk lid by hand.

■

If the smart entry & start system or the

wireless remote control does not oper-

ate properly

Use the mechanical key to unlock the trunk.

(



P.513)

Replace the key battery with a new one if it

is depleted.

■

Hands Free Power Trunk Lid operating

conditions (if equipped)

●

When the Hands Free Power Trunk Lid

(kick sensor) operation setting is turned

on and the power switch is turned off

●

When an electronic key is carried within

the operation range

■

Situations in which the Hands Free

Power Trunk Lid may not operate prop-

erly (if equipped)

In the following situations, the Hands Free

Power Trunk Lid may not operate properly:

●

When a foot remains under the rear

bumper

●

If the rear bumper is strongly hit with a

foot or is touched for a while

If the rear bumper has been touched for a

while, wait for a short time before

attempting to operate the Hands Free

Power Trunk Lid again.

●

When standing excessively close to the

rear bumper

●

When an external radio wave source

interferes with the communication

between the electronic key and the vehi-

cle (



P.146)

●

When the vehicle is parked near an elec-

trical noise source which affects the sen-

sitivity of the Hands Free Power Trunk Lid,

such as a pay parking spot, gas station,

electrically heated road, or fluorescent

light

143

3-2. Opening, closing and locking the doors and trunk

fore
driving

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When mud, snow, ice, etc. is attached to

the rear bumper

●

When the vehicle has been parked for a

while near objects that may move and

contact the rear bumper, such as plants

●

When an accessory is installed to the rear

bumper

If an accessory has been installed, turn the
Hands Free Power Trunk Lid (kick sensor)
operation setting off.

■

Preventing unintentional operation of

the Hands Free Power Trunk Lid (if

equipped)

When an electronic key is in the operation

detection area, the Hands Free Power Trunk

Lid may operate unintentionally, so be care-

ful in the following situations:

●

When a large amount of water is applied

to the rear bumper, such as when the

vehicle is being washed or in heavy rain

●

When dirt is wiped off the rear bumper

●

When a small animal or small object, such

as a ball, moves under the rear bumper

●

When an object is moved from under the

rear bumper

●

If someone is swinging their legs while sit-

ting on the rear bumper

●

If the legs or another part of someone’s

body contacts the rear bumper while

passing by the vehicle

●

When the vehicle is parked near an elec-

trical noise source which affects the sen-

sitivity of the Hands Free Power Trunk Lid,

such as a pay parking spot, gas station,

electrically heated road, or fluorescent

light

●

When the vehicle is near a TV tower,

electric power plant, radio station, large

display, airport or other facility that gen-

erates strong radio waves or electrical

noise

●

When the vehicle is parked in a place

where objects such as plants are near the

rear bumper

●

If luggage, etc. is set near the rear

bumper

●

If accessories or a vehicle cover is

installed/removed near the rear bumper

●

When the vehicle is being towed

To prevent unintentional operation, turn the

Hands Free Power Trunk Lid (kick sensor)

operation setting off.

■

Open door warning buzzer



P.136

■

Customization

Some functions can be customized.

(



P.540)

The trunk opener switch can be tem-
porarily disabled to protect luggage
stored in the trunk against theft.
Turn the main switch in the glove box
off to disable the trunk opener.

On
Off

The trunk lid cannot be opened even with
the wireless remote control, entry function
or Hands Free Power Trunk Lid.

Luggage security system

A
B

145

3-2. Opening, closing and locking the doors and trunk

fore
driving

■

Effective range (areas within which the

electronic key is detected)

When locking or unlocking the doors

The system can be operated when the
electronic key is within about 0.7 m (2.3 ft.)
of an outside door handle. (Only the doors
detecting the key can be operated.)

When opening the trunk

The system can be operated when the
electronic key is within about 0.7 m (2.3 ft.)
of the trunk release button.

When starting the hybrid system or
changing power switch modes

The system can be operated when the
electronic key is inside the vehicle.

■

Alarms and warning messages

An alarm sounds and warning messages

are displayed on the multi-information dis-

play to protect against unexpected acci-

dents or theft of the vehicle resulting from

erroneous operation. When a warning mes-

sage is displayed, take appropriate meas-

ures based on the displayed message.

(



P.505)

When only an alarm sounds, circumstances

and correction procedures are as follows.

●

When an exterior alarm sounds once for

5 seconds

●

When an interior alarm sounds continu-

ously

■

If “Key Detected in Vehicle” is shown on

the multi-information display

An attempt was made to lock the doors

using the smart entry & start system while

the electronic key was still inside the vehi-

cle. Retrieve the electronic key from the

vehicle and lock the doors again.

■

Battery-saving function

The battery-saving function will be acti-

vated in order to prevent the electronic key

battery and the 12-volt battery from being

discharged while the vehicle is not in opera-

tion for a long time.

●

In the following situations, the smart entry

& start system may take some time to

Situation

Correction

procedure

An attempt was made to

lock the vehicle while a

door was open.

Close all of the
doors and lock

the doors

again.

The trunk was closed

while the electronic key

was still inside the trunk

and all the doors were

locked.

Retrieve the

electronic key
from the trunk

and close the

trunk lid.

Situation

Correction

procedure

The power switch was

turned to ACCESSORY

mode while the driver’s

door was open (The

driver’s door was opened

when the power switch

was in ACCESSORY

mode).

Turn the power

switch off and

close the

driver’s door.

The power switch was

turned off while the

driver’s door was open.

Close the

driver’s door.

146

3-2. Opening, closing and locking the doors and trunk

unlock the doors.

• The electronic key has been left in an

area of approximately 2 m (6 ft.) of the

outside of the vehicle for 10 minutes or

longer.

• The smart entry & start system has not

been used for 5 days or longer.

●

If the smart entry & start system has not

been used for 14 days or longer, the

doors cannot be unlocked at any doors

except the driver’s door. In this case, take

hold of the driver’s door handle, or use

the wireless remote control or the

mechanical key, to unlock the doors.

■

Turning an electronic key to bat-

tery-saving mode

When battery-saving mode is set, battery

depletion is minimized by stopping the elec-

tronic key from receiving radio waves.

Press

twice while pressing and holding

. Confirm that the electronic key indica-

tor flashes 4 times.
While the battery-saving mode is set, the

smart entry & start system cannot be used.

To cancel the function, press any of the elec-

tronic key buttons.

■

Conditions affecting operation

The smart entry & start system uses weak

radio waves. In the following situations, the

communication between the electronic key

and the vehicle may be affected, preventing

the smart entry & start system, wireless

remote control and immobilizer system

from operating properly. (Ways of coping:



P.512)

●

When the electronic key battery is

depleted

●

Near a TV tower, electric power plant,

gas station, radio station, large display,

airport or other facility that generates

strong radio waves or electrical noise

●

When carrying a portable radio, cellular

phone, cordless phone or other wireless

communication device

●

When the electronic key is in contact

with, or is covered by the following metal-

lic objects

• Cards to which aluminum foil is attached

• Cigarette boxes that have aluminum foil

inside

• Metallic wallets or bags

• Coins

• Hand warmers made of metal

• Media such as CDs and DVDs

●

When other wireless keys (that emit radio

waves) are being used nearby

●

When carrying the electronic key

together with the following devices that

emit radio waves

• Another vehicle’s electronic key or a

wireless key that emits radio waves

• Personal computers or personal digital

assistants (PDAs)

• Digital audio players

• Portable game systems

●

If window tint with a metallic content or

metallic objects are attached to the rear

window

●

When the electronic key is placed near a

battery charger or electronic devices

●

When the vehicle is parked in a pay park-

ing spot where radio waves are emitted.

■

Note for the entry function

●

Even when the electronic key is within the

effective range (detection areas), the sys-

tem may not operate properly in the fol-

lowing cases:

• The electronic key is too close to the win-

dow or outside door handle, near the

ground, or in a high place when the doors

are locked or unlocked.

• The electronic key is near the ground or

in a high place, or too close to the center

of the rear bumper when the trunk is

opened.

• The electronic key is on the instrument

panel, rear package tray or floor, or in the

door pockets or glove box when the

147

3-2. Opening, closing and locking the doors and trunk

fore
driving

hybrid system is started or power switch

modes are changed.

●

Do not leave the electronic key on top of

the instrument panel or near the door

pockets when exiting the vehicle.

Depending on the radio wave reception

conditions, it may be detected by the

antenna outside the cabin and the doors

will become lockable from the outside,

possibly trapping the electronic key

inside the vehicle.

●

As long as the electronic key is within the

effective range, the doors may be locked

or unlocked by anyone. However, only

the doors detecting the electronic key

can be used to unlock the vehicle.

●

Even if the electronic key is not inside the

vehicle, it may be possible to start the

hybrid system if the electronic key is near

the window.

●

The doors may unlock or lock if a large

amount of water splashes on the door

handle, such as in the rain or in a car

wash, when the electronic key is within

the effective range. (The doors will auto-

matically be locked after approximately

30 seconds if the doors are not opened

and closed.)

●

If the wireless remote control is used to

lock the doors when the electronic key is

near the vehicle, there is a possibility that

the door may not be unlocked by the

entry function. (Use the wireless remote

control to unlock the doors.)

●

Touching the door lock sensor while

wearing gloves may delay or prevent lock

operation.

●

If the door handle becomes wet while the

electronic key is within the effective

range, the door may lock and unlock

repeatedly. In this case, follow the follow-

ing correction procedures to wash the

vehicle:

• Place the electronic key in a location 2 m

(6 ft.) or more away from the vehicle.

(Take care to ensure that the key is not

stolen.)

• Set the electronic key to battery-saving

mode to disable the smart entry & start

system. (



P.146)

●

If the electronic key is inside the vehicle

and a door handle becomes wet during a

car wash, a message may be shown on

the multi-information display and a

buzzer will sound outside the vehicle. To

turn off the alarm, lock all the doors.

●

The lock sensor may not work properly if

it comes into contact with ice, snow, mud,

etc. Clean the lock sensor and attempt to

operate it again.

●

A sudden approach to the effective

range or door handle may prevent the

doors from being unlocked. In this case,

return the door handle to the original

position and check that the doors unlock

before pulling the door handle again.

●

If there is another electronic key in the

detection area, it may take slightly longer

to unlock the doors after the door handle

is gripped.

■

When the vehicle is not driven for

extended periods

●

To prevent theft of the vehicle, do not

leave the electronic key within 2 m (6 ft.)

of the vehicle.

●

The smart entry & start system can be

deactivated in advance.

●

Setting the electronic key to battery-sav-

ing mode helps to reduce key battery

depletion. (



P.146)

■

To operate the system properly

●

Make sure to carry the electronic key

when operating the system. Do not get

the electronic key too close to the vehicle

when operating the system from the out-

side of the vehicle.

Depending on the position and holding
condition of the electronic key, the key may
not be detected correctly and the system
may not operate properly. (The alarm may
go off accidentally, or the door lock pre-
vention function may not operate.)

●

Do not leave the electronic key inside the

trunk.

The key confinement prevention function

may not operate, depending on the loca-

tion of the key (the inside edge of the

148

3-2. Opening, closing and locking the doors and trunk

trunk), conditions (inside a metal bag,

close to metallic objects) and the radio

waves in the surrounding area. (



P.142)

■

If the smart entry & start system does

not operate properly

●

Locking and unlocking the doors and

trunk:



P.512

●

Starting the hybrid system:



P.513

■

Customization

Some functions can be customized.

(



P.540)

■

If the smart entry & start system has

been deactivated in a customized set-

ting

●

Locking and unlocking the doors and

opening the trunk:

Use the wireless remote control or

mechanical key. (



P.132, 140, 512)

●

Starting the hybrid system and changing

power switch modes:



P.513

●

Stopping the hybrid system:



P.201

WARNING

■

Caution regarding interference with

electronic devices

●

People with implantable cardiac pace-

makers, cardiac resynchronization

therapy-pacemakers or implantable

cardioverter defibrillators should

maintain a reasonable distance

between themselves and the smart

entry & start system antennas.

(



P.144)

The radio waves may affect the opera-

tion of such devices. If necessary, the

entry function can be disabled. Ask

any authorized Lexus retailer or Lexus

authorized repairer, or any reliable

repairer for details, such as the fre-

quency of radio waves and timing of

the emitted radio waves. Then, consult

your doctor to see if you should disa-

ble the entry function.

●

Users of any electrical medical device

other than implantable cardiac pace-

makers, cardiac resynchronization

therapy-pacemakers or implantable

cardioverter defibrillators should con-

sult the manufacturer of the device for

information about its operation under

the influence of radio waves.

Radio waves could have unexpected

effects on the operation of such medi-

cal devices.

Ask any authorized Lexus retailer or

Lexus authorized repairer, or any reliable

repairer for details on disabling the entry

function.

149

3-3. Adjusting the seats

fore
driving

3-3.Adjusting the seats

■

Seat adjustment switches

Seat position adjustment
Seatback angle adjustment
Head restraint height adjustment (if
equipped) (



P.167)

Front seats

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat

position to ensure that other passen-

gers are not injured by the moving

seat.

●

Do not put your hands under the seat

or near the moving parts to avoid

injury.

Fingers or hands may become

jammed in the seat mechanism.

●

Make sure to leave enough space

around the feet so they do not get

stuck.

■

Seat adjustment

To reduce the risk of sliding under the lap

belt during a collision, do not recline the

seat more than necessary.

If the seat is too reclined, the lap belt may

slide past the hips and apply restraint

forces directly to the abdomen, or your

neck may contact the shoulder belt,

increasing the risk of death or serious

injury in the event of an accident.

Adjustments should not be made while

driving as the seat may unexpectedly

move and cause the driver to lose control

of the vehicle.

■

Operating the front passenger’s seat

from the driver’s seat or rear seat

Do not operate the front passenger’s seat

when a passenger is seated in it. In addi-

tion, do not let anyone sit down in the

front passenger’s seat while the seat is

being operated or when the head

restraint is being folded. The front pas-

senger may catch their legs between the

instrument panel and seat, or the head

restraint may interfere with their head,

resulting in injury.

■

When the front passenger’s seat is

folded forward

If the outside rear view mirror is difficult

to see, due to the position of the front

passenger’s seat, move the front passen-

ger’s seat to an appropriate position.

Doing so may lead to mishandling of the

vehicle and cause an accident, resulting

in death or serious injury.

NOTICE

■

Operating the front passenger’s seat

from the driver’s seat or rear seat

Before operating the front passenger’s

seat, make sure that there is no luggage

or any other objects on the seat or in the

footwell that could prevent its operation.

Such items may result in excess force

being applied, causing damage to the

seat and/or the luggage.

Adjustment procedure

A
B
C

150

3-3. Adjusting the seats

Seat cushion (front) angle adjust-
ment
Vertical height adjustment
Lumbar support adjustment
Seat cushion length adjustment (if
equipped)

■

Center Display

Press the seat switch.

Select “Adjustments”.

Select “Driver seat” or “Passenger
seat”.

Select the button for the desired
adjustment.



Head restraint (if equipped)
(



P.167)



Shoulder bolster (if equipped)



Lumbar support



Pelvic support



Hip support (if equipped)



Seatback side bolster and seat
cushion side bolster (if equipped)

Perform adjustment using the dis-
played buttons.

The seat will move while a button is

selected.

■

When adjusting the front seats

While adjusting a front seat, to avoid con-

tact with the ceiling, instrument panel or

rear seats, the operation of the seat may be

restricted or parts of the seat other than that

being adjusted may move.

■

Operation after the power switch is

turned off

After a certain time elapses after the power

switch is turned off, the following parts of

the front seats will move to their neutral

positions.

●

Shoulder bolster (if equipped)

●

Lumbar support

●

Pelvic support

●

Hip support (if equipped)

●

Seatback side and seat cushion side bol-

ster (if equipped)

■

Automatic angle adjustment of the rear

displays (if equipped)

When a seat is adjusted, the angle of the

rear display will be adjusted automatically

to maintain an optimal viewing angle for the

rear display from the rear seat.

■

Pre-collision seatbacks for the passen-

ger seats (vehicles with Lexus Safety

System + A or Lexus Safety System +)



P.248, 262

■

Customization

Some functions can be customized.

(



P.540)

■

Using the driver’s seat adjustment
switches to adjust the front passen-
ger’s seat (front passenger mode)

The mode of the driver’s seat adjust-
ment switches can be changed to
adjust the front passenger’s seat.

E
F

Operating the front passenger’s
seat from the driver’s seat

151

3-3. Adjusting the seats

fore
driving

Press the mode change button on
the driver’s side door.

The indicator

will illuminate when front

passenger mode is selected.

Using the seat adjustment switches
on the driver’s seat, adjust the front
passenger’s seat.

To cancel front passenger mode, press the

mode change button again.
Front passenger mode will be canceled

automatically if the driver’s seat adjustment

switches are not operated for approxi-

mately 30 seconds.

■

Using the Center Display (vehicles
with a foldable head restraint)

Press the seat switch.

Select “Arrangement”.

Select “Passenger seat”.

Select the button for the desired
operation.

“Seat fold”: Move the front passenger’s

seat forward and folds the seatback and

head restraint.
“Seat return”: Move the front passenger’s

seat rearward and the seatback and head

restraint to the upright position.
If the rear seat behind the front passenger’s

seat is not in the upright position, it will

move to the upright position before the

front passenger’s seat moves to its upright

position.
Vehicles with a rear seat entertainment

system: If the front passenger’s seat is

moved to the upright position and then

“Seat return” is selected again, the front

passenger’s seat will move rearward.

To stop the front passenger's seat while
it is moving, select the “Seat fold” or
“Seat return” or press the seat switch.

■

Operating the foldable head restraint

using the driver’s seat adjustment

switches in front passenger mode (if

equipped)

●

When the front passenger’s seatback

angle is adjusted using the driver’s seat

adjustment switches in front passenger

mode, the front passenger’s head

restraint will operate automatically as fol-

lows:

• When the front passenger’s seatback is

moved forward to the upright position,

the head restraint will lower and fold for-

ward when the seatback angle adjust-

ment switch is released.

• When the front passenger’s seatback is

moved backward to the upright position,

the head restraint will move to the upright

position when the seatback angle adjust-

ment switch is released.

●

If any of the following conditions are met,

the front passenger’s head restraint will

not fold forward even though the front

passenger’s seatback angle is being

adjusted using the driver’s seat adjust-

ment switches in front passenger mode:

• The power switch is in ACCESSORY

mode or off.

• The weight of an occupant or heavy

object, etc. is detected on the front pas-

152

3-3. Adjusting the seats

senger’s seat.

Once weight is detected on the seat, the
seat will be judged as occupied until the
front passenger’s door is opened then
closed or the power switch is turned off.
• Vehicles without a rear seat entertain-

ment system:The front passenger’s seat is

in the rear most position.

• The front passenger’s seat belt is fas-

tened.

• The front passenger’s door is open. (The

front seat will not move forward.)

• The front passenger’s seat is not in the

lowest position.

• The front passenger’s seat seat cushion

(front) is not in the lowest position.

• The front passenger’s seat seat cushion is

extended (if equipped).

●

If either of the following conditions is met,

the front passenger’s head restraint will

not return to the upright position even

though the front passenger’s seatback

angle is being adjusted using the driver’s

seat adjustment switches in front passen-

ger mode:

• The power switch is in ACCESSORY

mode or off.

• The front passenger’s seat position is

moved to a position forward of the neu-

tral position.

■

Operating the foldable head restraint

using the front passenger’s seat adjust-

ment switches (if equipped)

When the front passenger’s head restraint is

folded forward and the front passenger’s

door is open, if the front passenger’s seat

adjustment switches are used to move the

seat backward or recline the seatback, the

head restraint will move to the upright posi-

tion automatically when the switch is

released.
To stop the operation of the front passen-

ger’s head restraint part-way, perform any

of the following operations:

●

Operate any front passenger’s seat

adjustment switch.

The head restraint will stop when the seat
position adjustment switch or seatback

angle adjustment switch is operated to
move the seat backward or recline the
seatback, and will resume operating when
the switch is released.

●

Press the “SET” button.

●

Press the “1”, “2” or “3” button.

●

Press the seat switch.

■

Operation of the front passenger’s seat

using the Center Display will be

canceled when (vehicles with a foldable

head restraint)

In the following situations, the front passen-

ger’s seat cannot be operated using the

Center Display:

●

The power switch is in ACCESSORY

mode or off.

●

The weight of an occupant or heavy

object, etc. is detected on the front pas-

senger’s seat.

Once weight is detected on the seat, the
seat will be judged as occupied until the
front passenger’s door is opened then
closed or the power switch is turned off.

●

The front passenger’s seat belt is fas-

tened.

●

The front passenger’s door is open. (The

front seat will not move forward.)

■

When the front passenger’s seat is

folded forward

By reclining the front passenger’s seat

seatback, the forward view of the rear pas-

senger can be improved.

153

3-3. Adjusting the seats

fore
driving

Press and hold to move the front
passenger’s seat forward and fold
the seatback forward.

Press and hold to move the front
passenger’s seat backward and
move the seatback to the upright
position.

Display the home screen on the
Rear Multi Operation Panel
(



P.390) and then touch “Seat”.

Touch “Passenger”.

Touch the button for the desired
operation.

When the operating conditions are not

met, the buttons will be grayed out.

Move the front passenger’s seat
forward and fold the seatback for-
ward.

On vehicles with a foldable head restraint,
the head restraint will also fold forward.
To stop the front passenger seat while it is
moving, touch “STOP”.

Move the front passenger’s seat
backward and the seatback to the
upright position.

If the rear seat behind the front passenger’s
seat is not in the upright position, it will
move to the upright position before the
front passenger’s seat moves to its previous
position.
On vehicles with a foldable head restraint,
the head restraint will also move to the
upright position.
Vehicles with a rear seat entertainment
system: If the front passenger’s seat is
moved to the upright position and then

is selected again, the front passenger’s seat
will move rearward.
To stop the front passenger seat while it is
moving, touch “STOP”.

Move the front passenger’s seat
forward or backward

The seat will move while a button is
touched and held.

Operating the front passenger’s
seat from the rear seat (vehicles
without power rear seat)

Operating the front passenger’s
seat from the rear seat (vehicles
with power rear seat)

154

3-3. Adjusting the seats

Adjust the angle of the front pas-
senger’s seat seatback

The seatback will move while a button is
touched and held.

: Vehicles with a foldable head restraint

■

Operating the front passenger’s seat

from the rear seat

●

In the following situations, the front pas-

senger’s seat cannot be operated using

the Rear Multi Operation Panel:

• The power switch is in ACCESSORY

mode or off.

• The rear seat belt is not fastened and

weight is not detected on the rear seat.

Once weight is detected on the seat, the
seat will be judged as occupied until a rear
door is opened then closed or the power
switch is turned off and the doors are
locked.
• The weight of an occupant or heavy

object, etc. is detected on the front pas-

senger’s seat.

Once weight is detected on the seat, the
seat will be judged as occupied until the
front passenger’s door is opened then
closed or the power switch is turned off.
• The front passenger’s seat belt is fas-

tened.

• The front passenger’s door is open. (The

front seat will not move forward.)

: Vehicles with foldable head restraint:

Even when the power switch is in
ACCESSORY mode or off, the front
passenger seat position and seatback
angle can be adjusted.

●

If the rear armrest is stowed while the

seat position is being adjusted, the opera-

tion will stop.

■

Canceling an operation

To cancel an operation, press and hold the

button of the Rear Multi Opera-

tion Panel or press it 3 times in quick suc-

cession.

■

When the front passenger’s seat is

folded forward



P.152

Pneumatic chambers built into the
front seat apply pressure to the occu-
pant’s body at different modes and
intensities.

Press the seat switch.

Select “Massage”.

Select “Driver seat” or “Passenger
seat”.

Select the desired mode.



“Centripetal”

Applies pressure sequentially from the
front of the seat cushion to top of the
seatback



“Centrifugal”

Applies pressure sequentially from the top
of the seatback to the front of the seat
cushion



“Upper body”

Applies pressure sequentially from the bot-
tom to the top of the seatback

Front seat refresh system (if
equipped)

155

3-3. Adjusting the seats

fore
driving



“Lower body”

Applies pressure sequentially from the
front to the back of the seat cushion



“Lumbar”

Applies pressure sequentially from the bot-
tom to the top of the lumbar area of the
seatback

Select the desired intensity and
then select

(on).

The intensity can be adjusted in 5 steps.

To stop the operation, select

(off).
If a seat is not occupied, do not operate the

front seat refresh system for that seat.

■

Refresh system

●

Operating conditions

• The power switch is in ON mode.

• The temperature in the cabin is not

extremely high.

• For the front passenger’s seat: The weight

of an occupant is detected on the front

passenger’s seat or the front passenger’s

seat belt is fastened.

Once weight is detected on the seat, the
seat will be judged as occupied until the
front passenger’s door is opened then
closed or the power switch is turned off.

●

Automatic stop function

• The operation will be canceled automati-

cally after approximately 15 minutes.

• If the power easy access system begins

operating, the front seat refresh system

will stop.

WARNING

■

Important points while driving

Do not adjust the driver’s seat refresh

system while driving.

Using it may affect your ability to control

the vehicle, possibly leading to an acci-

dent resulting in death or serious injury.

■

Using the refresh system

●

Those who are pregnant, have recently

given birth, or suffer from ailments

requiring rest (heart disease etc.)

should consult a doctor before use.

●

Do not allow children to use the

refresh function.

●

Do not use immediately after consum-

ing a meal or alcohol, or for an

extended period of time.

●

If you feel sick while using the refresh

function, immediately discontinue use.

156

3-3. Adjusting the seats

: If equipped

■

Automatic operation

The seat can be moved to preset posi-
tions.

Display the home screen on the
Rear Multi Operation Panel
(



P.390) and then touch “Seat”.

Touch “Left” or “Right”.

Touch the desired preset button.

Power rear seat

WARNING

■

When adjusting the seat position

●

Take care when adjusting the seat

position to ensure that other passen-

gers are not injured by the moving

seat.

●

When adjusting the rear seat with an

ottoman, make sure there is sufficient

space so that a foot does not get

caught between the ottoman and front

passenger seat. (if equipped)

●

Vehicles with a rear seat entertainment

system: When the rear seat is moving

to the Entertainment Mode position,

do not allow hands near the rear dis-

play. Otherwise, a hand or finger may

be caught, possibly causing injury.

■

Seat adjustment

To reduce the risk of sliding under the lap

belt during a collision, do not recline the

seat more than necessary.

If the seat is too reclined, the lap belt may

slide past the hips and apply restraint

forces directly to the abdomen, or your

neck may contact the shoulder belt,

increasing the risk of death or serious

injury in the event of an accident.

Adjustments should not be made while

driving as the seat may unexpectedly

move and cause the driver to lose control

of the vehicle.

■

Using the ottoman (if equipped)

●

Do not sit on the ottoman.

If someone sits on the ottoman, the seat
belt cannot be fitted properly, and they
may be thrown from the seat, resulting in
death or serious injury in the event of an
accident or sudden braking.

●

When getting in or out of the vehicle,

retract the ottoman. If the ottoman is

not retracted, it may cause a fall, result-

ing in injury.

●

Do not operate the ottoman when the

vehicle is moving.

●

Do not allow anyone to put their hands

or feet under the rear seat when stow-

ing the ottoman.

NOTICE

■

To prevent an ottoman malfunction (if

equipped)

●

Do not place any objects in the rear

seat footwell that could prevent the

operation of the ottoman.

●

Do not place heavy luggage on the

ottoman.

●

Do not place any objects under the

ottoman while it is raised for use. These

objects may interfere with the ottoman

being folded, causing damage to the

ottoman or the objects themselves.

■

To prevent a rear display malfunction

(if equipped)

Do not attempt to move the rear display

by hand, as doing so may damage the

rear display.

Adjustment procedure

157

3-3. Adjusting the seats

fore
driving

When the operating conditions are not

met, the preset buttons will be grayed out.

: Moves the rear seat

to the upright position (Business
Mode)

: Moves the rear seat

with an ottoman to a slightly reclined
position (Entertainment Mode) (if
equipped)

Vehicles without a rear seat entertainment
system: Moves the front passenger’s seat
forward.
Vehicles with a rear seat entertainment
system: Moves the front passenger’s seat
and rear display to allow the rear display to
be comfortably viewed.

: Moves the rear seat with an

ottoman to a deeply reclined position
(Relaxation Mode) (if equipped)

Moves the front passenger’s seat forward
and folds the seatback and head restraint
forward.
To stop the front passenger seat while it is
moving, touch “STOP”.

■

Manual operation

Display the home screen on the
Rear Multi Operation Panel
(



P.390) and then touch “Seat”.

Touch “Left” or “Right”.

Touch the button for the desired
adjustment.

Select the part you wish to adjust.
Adjust the position of the selected
part.

The part will move while a button is
touched.

■

Adjustment of the rear seat

●

When a rear seat is close to a front seat,

the operation of the rear seat may be

restricted.

●

If the rear armrest is stowed while the

seat position is being adjusted, the opera-

tion will stop.

■

Operating conditions of Business Mode

When the rear seat belt is not fastened and

weight is not detected on the rear seat,

Business Mode cannot be selected.
Once weight is detected on the seat, the
seat will be judged as occupied until a rear
door is opened then closed or the power
switch is turned off and the doors are
locked.

A
B

158

3-3. Adjusting the seats

■

The rear seat with an ottoman cannot be

moved to Entertainment Mode/Relaxa-

tion Mode when (if equipped)

In the following situations, Entertainment

Mode or Relaxation Mode cannot be

selected:

●

The power switch is in ACCESSORY

mode or off.

●

The rear seat belt is not fastened and

weight is not detected on the rear seat.

Once weight is detected on the seat, the
seat will be judged as occupied until a rear
door is opened then closed or the power
switch is turned off and the doors are
locked.

●

The weight of an occupant or heavy

object, etc. is detected on the front pas-

senger’s seat.

Once weight is detected on the seat, the
seat will be judged as occupied until the
front passenger’s door is opened then
closed or the power switch is turned off.

●

The front passenger’s seat belt is fas-

tened.

●

The front passenger’s door is open.

■

When the front passenger’s seat is

folded forward



P.152

■

Automatic angle adjustment of the rear

displays (if equipped)

When a seat is adjusted, the angle of the

rear display will be adjusted automatically

to maintain an optimal viewing angle for the

rear display from the rear seat.

■

Operation after the power switch is

turned off

After a certain time elapses after the power

switch is turned off, the following parts of

the rear seats will move to their neutral

positions.

●

Shoulder bolster

●

Lumbar/pelvic support

■

Canceling an operation

To cancel an operation, press and hold the

button of the Rear Multi Opera-

tion Panel or press it 3 times in quick suc-

cession.

■

Pre-collision seatbacks for the passen-

ger seats (vehicles with Lexus Safety

System + A or Lexus Safety System +)



P.248, 262

■

Customization

Some functions can be customized.

(



P.540)

Press the seat switch.

Select “Arrangement”.

Select “Rear seat”.

Select “Return”.

The rear seat will move to the upright posi-

tion.
If the “Cancel” is selected while the seat

position is being adjusted, the operation

will stop.

■

Operation of the rear seats from the

front seats

In the following situations, the rear seats

cannot be operated from the front seats.

●

When the armrest is stowed and weight

Returning the rear seat from the
front seats

159

3-3. Adjusting the seats

fore
driving

of an occupant, heavy object, etc. is

detected on a rear seat

Once weight is detected on the seat, the
seat will be judged as occupied until a rear
door is opened then closed or the power
switch is turned off and the doors are
locked.

●

When the armrest is stowed and a rear

seat belt is fastened.

The rear seat relaxation system utilizes
pneumatic chambers and dedicated
heaters, and applies pressure to the
occupant’s body at different modes
and intensities.
To display the rear seat relaxation sys-
tem screen, display the home screen
on the Rear Multi Operation Panel
(



P.390) and then touch “Relaxa-

tion”.

Touch to select the desired rear

seat.
Touch to select the desired mode.

When a button is touched, operation will
begin.

Touch to adjust the intensity.

The intensity can be adjusted in 5 steps.

Touch to turn the spot heaters
on/off.
Touch to stop the operation.

If a seat is not occupied, do not operate the
rear seat relaxation system for that seat.

■

Relaxation system

●

Operating conditions

• The power switch is in ON mode.

• The temperature in the cabin is not

extremely high.

• The weight of an occupant is detected on

the rear seat or the rear seat belt is fas-

tened.

Once weight is detected on the seat, the
seat will be judged as occupied until a rear
door is opened then closed or the power
switch is turned off and the doors are
locked.

●

Automatic stop function

• The operation will be canceled automati-

cally after approximately 15 minutes.

• If the door for a seat that the relaxation

system is currently being used is opened,

the relaxation system will stop operating.

WARNING

■

When returning the rear seats to the

neutral position

To avoid injuring the rear passengers,

wait until they have gotten out of the

vehicle before operating the switch.

Rear seat relaxation system (if
equipped)

WARNING

■

Using the relaxation system

●

Those who are pregnant, have recently

given birth, or suffer from ailments

requiring rest (heart disease etc.)

should consult a doctor before use.

●

Do not allow children to use the relax-

ation function.

160

3-3. Adjusting the seats

The following functions will cause the
rear seats to move automatically.

■

Seat return function linked to the
door opening operation

The rear seat will return to the upright
position automatically when the rear
door is opened for easier entry and exit
of the vehicle.
For the rear seat with an ottoman (if
equipped): When the rear door on the
side with the rear seat with an ottoman
is opened, the seatback of the rear seat
with an ottoman will move to a more
upright position. The seatback will
move to the upright position after the
door is closed and the system deter-
mines that the rear passenger has
exited.
However, if the armrest is stowed, the
rear seat will not move.

■

Shift-linked rear seat reclining
function

When the shift position is shifted from
P, to enhance rear visibility for the
driver, the rear seats will recline slightly.
However, the shift-linked rear seat
reclining function will not operate in

the following situations:



The weight of an occupant or heavy
object, etc. is detected on a rear
seat.

Once weight is detected on the seat, the
seat will be judged as occupied until a rear
door is opened then closed or the power
switch is turned off and the doors are
locked.



A rear seat belt is fastened.



A rear door is open.



The armrest is stowed.

When a front seat is close to a rear
seat, the rear seats may not operate or
the range of movement may be
restricted.

■

Changing automatic seat opera-
tion settings

The settings can be changed on the
Rear Multi Operation Panel.
(



P.390)

Display the home screen on the
Rear Multi Operation Panel
(



P.390) and then touch “Seat”.

Touch “Left” or “Right”.

Touch .

WARNING

●

Do not use immediately after consum-

ing a meal or alcohol, or for an

extended period of time.

●

If you feel sick while using the relaxa-

tion function, immediately discontinue

use.

Automatic Seat Operation

161

3-3. Adjusting the seats

fore
driving

Touch a button to change the set-
ting.

Rear right seat automatic operation
Rear right seatback movement
amount when door-linked rear seat
return function operates

Rear left seat automatic operation

: Vehicles with a rear seat with an ottoman

The seat and steering wheel are auto-
matically adjusted to allow the driver to
enter and exit the vehicle easily.



Driver’s seat

When all of the following have been
performed, the seat and steering
wheel are automatically adjusted to a
position that allows driver to enter and
exit the vehicle easily.
• The shift position has been shifted to

• The power switch has been turned

off.

• The driver’s seat belt has been

unfastened.

When the driver’s seat adjustment
switches are in front passenger mode
(



P.150), the seat and steering wheel will

not move.

A
B

Driving position memory

This feature automatically adjusts
the positions of the front seats,
steering wheel, outside rear view
mirrors and head-up display (if
equipped) to make entering and
exiting the vehicle easier or to suit
your preferences.

Up to 3 different driving positions
can be recorded.

Each electronic key (including a
card key) can be registered to
recall your preferred driving posi-
tion.

Power easy access system

Lexus LS (2023 year). Manual in english - page 4
