Honda Civic Hybrid (2015 year). Manual - part 8





uu

Locking and Unlocking the Doors

u

Childproof Door Locks

112

Co
ntrols

Press the master door lock switch in as shown
to lock or unlock all doors.

Childproof Door Locks

The childproof door locks prevent the rear doors from being opened from the inside
regardless of the position of the lock tab.

Slide the lever in the rear door to the lock
position, and close the door.

When opening the door

Open the door using the outside door handle.

Using the Master Door Lock Switch

1

Using the Master Door Lock Switch

When you lock/unlock each front door using the
master lock switch, all the other doors lock/unlock at
the same time.

To Unlock

Master Door
Lock Switch

To Lock

Setting the Childproof Door Locks

1

Childproof Door Locks

To open the door from the inside when the
childproof door lock is on, put the lock tab in the
unlock position, lower the rear window, put your
hand out of the window, and pull the outside door
handle.

Lock

Unlock

113

uu

Locking and Unlocking the Doors

u

Auto Door Locking/Unlocking

Co
ntrols

Auto Door Locking/Unlocking

Your vehicle locks and unlocks all doors automatically when a certain condition is
met.

Drive lock mode

All doors lock when the vehicle’s speed reaches about 10 mph (15 km/h).

Driver’s door open mode

All doors unlock when the driver’s door is opened.

Auto Door Locking

Auto Door Unlocking

1

Auto Door Locking/Unlocking

You can turn off or change to another auto door
locking/unlocking setting using the i-MID.

Customized Features P. 93

114

Co
ntrols

Opening and Closing the Trunk

Precautions for Opening/Closing the Trunk

Opening the trunk

Open the trunk all the way.

u

If it is not fully opened, the trunk lid may begin to close under its own weight.

Closing the trunk

Keep the trunk lid closed while driving to:

u

Avoid possible damage.

u

Prevent exhaust gas from leaking into the vehicle.

Carbon Monoxide Gas P. 64

Using the Trunk Opener

Pulling the trunk release on the outside of the
driver’s seat unlocks and opens the trunk.

Trunk
Release

115

uu

Opening and Closing the Trunk

u

Using the Trunk Release Button

Co
ntrols

Locking the trunk opener

You can lock the trunk release with the built-
in key.

Locking the trunk release disables the trunk
release button on the smart entry remote and
trunk lid to protect luggage in the trunk.

Using the Trunk Release Button

Push up the release button on the trunk lid
after the doors are unlocked.

Even if the trunk is locked, you can open the
trunk if you carry the smart entry remote.

u

The beeper will sound.

1

Locking the trunk opener

If you need to give the key to someone else, give
them the remote from which you have removed the
built-in key.

1

Using the Trunk Release Button

Do not leave the smart entry remote in the vehicle
when you get out. Carry it with you.

Even if you are not carrying the smart entry remote,
you can unlock the trunk while someone else with
the remote is within range.

Do not leave the smart entry remote inside the
trunk and close the lid. The beeper sounds and the
trunk cannot be closed.

Do not carry the smart entry remote near the trunk
lid when closing it.

Do not place the smart entry remote around the
rear seat when closing the trunk.

Trunk Release Button

116

uu

Opening and Closing the Trunk

u

Using the Remote Transmitter

Co
ntrols

Using the Remote Transmitter

Press the trunk release button for
approximately one second to unlock and open
the trunk.

Emergency Trunk Opener

The trunk release lever allows you to open the
trunk from inside for your safety.

Slide the release lever in the direction of the
arrow.

Trunk
Release
Button

1

Emergency Trunk Opener

Parents should decide if their children should be
shown how to use this feature.

Lever

117

Continued

Co
ntrols

Security System

Immobilizer System

The immobilizer system prevents a key that has not been pre-registered from
starting the engine. Each key contains electronic transmitters that use electronic
signals to verify the key.

Pay attention to the following when pressing the ENGINE START/STOP button:
• Do not allow objects that emit strong radio waves near the ENGINE START/

STOP button.

• Make sure the key is not covered by or touching a metal object.
• Do not bring a key from another vehicle’s immobilizer system near the smart entry

remote.

Security System Alarm

The security system alarm activates when the trunk, hood or doors are forcibly
opened. The alarm does not go off if the trunk or doors are opened with the key,
remote transmitter or smart entry system.

However, the alarm goes off when a door is opened with the key, then the shift
lever is moved out of

(

P or the hood is opened before the power mode is set to ON.

When the security system alarm activates

The horn sounds intermittently and all the exterior lights flash.

To deactivate the security system alarm

Unlock the vehicle using the remote transmitter or smart entry system. The system,
along with the horn and flashing lights, is deactivated.

1

Immobilizer System

NOTICE

Leaving the smart entry remote in the vehicle can
result in theft or accidental movement of the vehicle.
Always take the key with you whenever you leave the
vehicle unattended.

Do not alter the system or add other devices to it.
Doing so may damage the system and make your
vehicle inoperable.

1

Security System Alarm

The security alarm continues for a maximum of two
minutes until the security system deactivates.

uu

Security System

u

Security System Alarm

118

Co
ntrols

Setting the security system alarm

The security system alarm automatically sets when the following conditions have
been met:
• The power mode is set to VEHICLE OFF (LOCK).
• The hood and trunk are closed.
• All doors are locked from outside with the key, remote transmitter or smart entry

system.

When the security system alarm sets

The security system indicator in the instrument panel blinks. When the blinking
interval changes after about 15 seconds, the security system is set.

To cancel the security system alarm

The security system is canceled when the vehicle is unlocked using the remote
transmitter, or smart entry system, or the power mode is set to ON. The security
system indicator goes off at the same time.

The panic button on the remote
transmitter

If you press the panic button for
approximately one second, the following will
occur for about 30 seconds:
• The horn sounds.
• Some exterior lights flash.

Canceling panic mode

Press any button on the remote transmitter, or set the power mode to ON.

Panic Mode

1

Security System Alarm

Do not set the security system alarm when someone
is in the vehicle or a window is open. The system can
accidentally activate when:

Unlocking the door with the lock tab.

Opening the trunk with the trunk release or the
emergency trunk opener.

Moving the shift lever out of

(

P.

Opening the hood with the hood release.

If the battery goes dead after you have set the
security system alarm, the security alarm may go off
once the battery is recharged or replaced.
If this occurs, deactivate the security system alarm by
unlocking a door using the remote transmitter.

Do not attempt to alter this system or add another
device to it.

Panic
Button

119

Continued

Co
ntrols

Opening and Closing the Windows

Opening/Closing the Power Windows

The power windows can be opened and closed when the power mode is in ON,
using the switches on the doors. The driver’s side switches can be used to open and
close all the windows.

The power window lock button on the driver’s side must be switched off (not
pushed in, indicator off) to open and close the windows from anywhere other than
the driver’s seat.

When the power window lock button is pushed in, the indicator comes on and you
can only operate the driver’s window. Turn the power window lock button on when
children are in the vehicle.

Automatic operation

To open: Push the switch down firmly.
To close: Pull the switch up firmly.

The window opens or closes completely. To
stop the window at any time, push or pull the
switch briefly.

Manual operation

To open: Push the switch down lightly, and
hold it until the desired position is reached.
To close: Pull the switch up lightly, and hold it
until the desired position is reached.

Opening/Closing Windows with Auto-Open/Close Function

1

Opening/Closing the Power Windows

The power windows can be operated for up to 10
minutes after you set the power mode to VEHICLE
OFF (LOCK).
Opening either front door cancels this function.

Auto Reverse
If a power window senses resistance when closing
automatically, it will stop closing and reverse
direction.

The driver’s window auto reverse function is disabled
when you continuously pull up the switch.

The auto reverse function stops sensing when the
window is almost closed to ensure that it fully closes.

3

WARNING

Closing a power window on someone’s
hands or fingers can cause serious injury.

Make sure your passengers are away from
the windows before closing them.

On

Off

Power Window
Lock Button

Indicator

Driver’s
Window
Switch

120

uu

Opening and Closing the Windows

u

Opening/Closing the Power Windows

Co
ntrols

To open: Push the switch down.
To close: Pull the switch up.

Release the switch when the window reaches
the desired position.

Opening/Closing Windows without Auto-Open/Close Function

Close

Open

121

Continued

Co
ntrols

Operating the Switches Around the Steering Wheel

ENGINE START/STOP Button

*1:Canadian models

Changing the Power Mode

1

ENGINE START/STOP Button

ENGINE START/STOP Button Operating Range

You can start the engine when the smart entry
remote is inside the vehicle.
The engine may also run if the smart entry remote is
close to the door or window, even if it is outside the
vehicle.

ON mode:
Indicator in the button is off, if the engine is running.

If the smart entry remote battery is weak, beeper
sounds and the TO START, HOLD REMOTE NEAR
START BUTTON
 message appears on the i-MID.

If the Smart Entry Remote Battery is Weak

P. 342

Do not leave the power mode in ACCESSORY or ON
when you get out.

Operating Range

VEHICLE OFF (LOCK)
Indicator in the button is off.
The steering wheel is locked

*1

.

The power to all electrical
components is turned off.

Press the button without the
shift lever in

(

P.

Shift to

(

P then press the button.

Press the button.

Without pressing
the brake pedal

ACCESSORY
Indicator in the button is on.
Indicator in the button blinks
(from ON to ACCESSORY).
Operate the audio system and
other accessories in this position.

ON
Indicator in the button is on.
All electrical components can be
used.

Indicator

U.S. models

Shift to

(

P.

122

uu

Operating the Switches Around the Steering Wheel

u

ENGINE START/STOP Button

Co
ntrols

If you leave the vehicle for 30 to 60 minutes with the shift lever in

(

P and the power

mode in ACCESSORY, the vehicle automatically goes into the mode similar to
VEHICLE OFF (LOCK) to avoid the battery drain.

When in this mode:
The steering wheel does not lock.
You cannot lock or unlock doors with the remote transmitter or the smart entry
system.
Press the ENGINE START/STOP button three times to switch the mode to VEHICLE
OFF (LOCK).

Automatic Power Off

Canadian models

123

uu

Operating the Switches Around the Steering Wheel

u

ENGINE START/STOP Button

Co
ntrols

If you open the driver’s door when the power mode is set to ACCESSORY, a warning
buzzer sounds.

Warning buzzers may sound from inside or/
and outside the vehicle to remind you that the
smart entry remote is out of the vehicle. If the
buzzer continues even after the remote is put
back inside, place it to be within its
operational range.

When the power mode is in ON

If the smart entry remote is taken out of the
vehicle, and the driver’s door is closed,
warning buzzers sound from both inside and
outside the vehicle. A warning message on
the i-MID notifies the driver inside that the
remote is out.

When the power mode is in
ACCESSORY

If the smart entry remote is taken out of the
vehicle, and all the doors are closed, a
warning buzzer sounds from outside the
vehicle.

Power Mode Reminder

Smart Entry Remote Reminder

1

Smart Entry Remote Reminder

When the smart entry remote is within the system’s
operational range, and the driver’s door is closed, the
warning function cancels.

If the smart entry remote is taken out of the vehicle
after the engine has been started, you can no longer
change the ENGINE START/STOP button mode or
restart the engine. Always make sure if the remote is
in your vehicle when you operate the ENGINE
START/STOP
 button.

Removing the smart entry remote from the vehicle
through a window does not activate the warning
buzzer.

Do not put the smart entry remote on the dashboard
or in the glove box. It may cause the warning buzzer
to go off. Under some other conditions that can
prevent the vehicle from locating the remote, the
warning buzzer may also go off even if the remote is
within the system’s operational range.

124

uu

Operating the Switches Around the Steering Wheel

u

Turn Signals

Co
ntrols

Turn Signals

The turn signals can be used when the power
mode is in ON.

One-touch turn signal

When you lightly push up or down and release
the turn signal lever, the exterior turn signals
and turn signal indicator blink three times.

This feature can be used when signaling for a
lane change.

Light Switches

Rotating the light switch turns the lights on
and off, regardless of the power mode
setting.

High beams

Push the lever forward until you hear a click.

Low beams

When in high beams, pull the lever back to
return to low beams.

Flashing the high beams

Pull the lever back, and release it.

Right Turn

Left Turn

Manual Operation

1

Light Switches

If you leave the power mode in VEHICLE OFF (LOCK)
with the lights on, a light on reminder chime will
sound when you open the driver’s door.

Do not leave the lights on when the engine is off
because it will cause the battery to discharge.

If you sense that the level of the headlights is
abnormal, have the vehicle inspected by a dealer.

High Beams

Flashing the high beams

Low Beams

Turns on parking, side marker,
tail, and rear license plate lights

Turns on headlights, parking,
side marker, tail, and rear
license plate lights

Continued

125

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

Co
ntrols

Automatic lighting control can be used when
the power mode is in ON.

When you turn the light switch to AUTO, the
headlights and other exterior lights will switch
on and off automatically depending on the
ambient brightness.

u

You can change the auto light sensitivity
setting.

Customized Features P. 93

Automatic Lighting Control

1

Automatic Lighting Control

We recommend that you turn on the lights manually
when driving at night, in a dense fog, or in dark areas
such as long tunnels or parking facilities.

The light sensor is in the location shown below.
Do not cover this light sensor with anything;
otherwise, the automatic lighting system may not
work properly.

Adjust the auto light sensitivity as follows:

Setting

The exterior lights come on

when the ambient light is at

Max

High

Mid

Low

Min

Light Sensor

Bright

Dark

uu

Operating the Switches Around the Steering Wheel

u

Light Switches

126

Co
ntrols

The headlights automatically come on when the wipers are used several times within
a certain number of intervals with the headlight switch in AUTO.
The headlights automatically go off a few minutes later if the wipers are stopped.

The headlights, all other exterior lights, and the instrument panel lights turn off 15
seconds after you set the power mode to VEHICLE OFF (LOCK), take the remote with
you, and close the driver’s door.

u

You can change the headlight auto off timer setting.

Customized Features P. 93

If you set the power mode to VEHICLE OFF (LOCK) with the headlight switch on, but
do not open the door, the lights turn off after 10 minutes (three minutes, if the
switch is in the AUTO position).

The lights turn on again when you unlock or open the driver’s door. If you unlock
the door, but do not open it within 15 seconds, the lights go off. If you open the
driver’s door, you will hear a lights on reminder chime.

Headlight Integration with Wipers

*

Automatic Lighting Off Feature

1

Headlight Integration with Wipers

*

This feature activates during the headlights are off in
AUTO.
The instrument panel brightness does not change
when the headlights come on.

At dark ambient light levels, the automatic lighting
control feature turns on the headlights, regardless of
the number of wiper sweeps.

* Not available on all models

127

uu

Operating the Switches Around the Steering Wheel

u

Daytime Running Lights

Co
ntrols

Daytime Running Lights

The daytime running lights come on when the following conditions have been met:
• The power mode is in ON.
• The headlight switch is off, or in

.

• The parking brake is released.

The lights remain on even if you set the parking brake. Setting the power mode to
VEHICLE OFF turns off the daytime running lights.















Content   ..  6  7  8  9   ..
