Harley Davidson HANDLEBAR INSTALLATION REQUIREMENTS (2019-02-13)

Table 427.

Diamond Black

Diamondback™

OEM Stock

Fitment

Handlebar ID will not fit with FLHTK stock heated grips or 56100034.

Requires separate purchase of accessory heated grips.

Heated Grips (stock FLHTK and 56100034)

57300063

Fairing Plugs (FLHX/S & models w/ fairing mounted mirrors)

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

2014-2016 FLHTCUTG

Table 428.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200045

37200039A

n/a

Hydraulic Clutch Line

41800260

41800246

n/a

Brake Lines, LINKED - UPPER

41600094

n/a

Brake Lines, LINKED - ADAPTER

41800558

41800292

Stock

OPTIONAL Brake Lines, LINKED - LOWER

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

2017-2018 FLHTCUTG

Table 429.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200291

37200248

n/a

Hydraulic Clutch Line

41800260

41800246

n/a

Brake Lines, LINKED - UPPER

41600094

n/a

Brake Lines, LINKED - ADAPTER

41800558

41800292

Stock

OPTIONAL Brake Lines, LINKED - LOWER

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

2019-later FLHTCUTG

Table 430.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200291

37200248

n/a

Hydraulic Clutch Line

41800738 & 41800260

41800738 & 41800246

n/a

Brake Lines, LINKED - UPPER

(1)

41800690 & 41800333

41800690 & 41800332

Stock

OPTIONAL Brake Lines, LINKED - LOWER

(1)

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

(1) Mid Brake lines 41800690 and 41800738 have OE black finish and are not cosmetically braided.

NOTE: Installation of handlebars and risers may require a change in clutch cables or lines, throttle cables, or brake lines for some models. All modular lower brake
lines listed are based on stock front suspension. Harley Davidson Motor Company cannot test and make specific fitment recommendations concerning every possible
mirror and handlebar combination. Therefore, after installing new mirrors, handlebars, or control cables/lines and before operating the motorcycle, check to ensure
that all controls are fully functional and that the mirrors provide the operator a clear view to the rear. Handlebar height is regulated in many areas. Check local laws
before installation.

114 / 165

BATWING

MINI-APE HANDLEBAR

57474-11 (CHROME), 57485-11 (SATIN BLACK)

Figure 37. BAT WING MINI-APE HANDLEBAR ('08-later models)

2009-2013 FLHT, FLHTC, FLHTCU & FLHX

Table 432.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200050A

38924-09A

n/a

Clutch Cables

41800440

41800424

n/a

Brake Lines, NON-ABS - UPPER

41800280

44905-08

n/a

Brake Lines, NON-ABS - LOWER

41800481

41800467

n/a

Brake Lines, ABS - UPPER

48946-10

41825-09

n/a

Brake Lines, ABS - LOWER

32310-08

Twist Grip Sensor Kit

732 (2x) & 755 (2x)

Fairing Plugs (FLHX & models w/ fairing mounted mirrors)

2014-2016 FLHTCU, FLHTK, FLHX & FLHXS

Table 433.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200046

37200040A

n/a

Hydraulic Clutch Line

41800260

41800246

n/a

Brake Lines, NON-ABS - UPPER

41800338

41800336

n/a

Brake Lines, NON-ABS - LOWER

41800321 & 41800441

41800321 & 41800425

n/a

Brake Lines, ABS - UPPER

(1)

41800323A &

41800333

41800323A &

41800332

Stock

OPTIONAL Brake Lines, ABS - LOWER

(1)

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

Handlebar ID will not fit with FLHTK stock heated grips or 56100034.

Requires separate purchase of accessory heated grips.

Heated Grips (stock FLHTK and 56100034)

57300063

Fairing Plugs (FLHX/S & models w/ fairing mounted mirrors)

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

2017-later FLHTCU, FLHTK, FLHX & FLHXS

Table 434.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200288

37200249

n/a

Hydraulic Clutch Line

41800260

41800246

n/a

Brake Lines, NON-ABS - UPPER

41800338

41800336

n/a

Brake Lines, NON-ABS - LOWER

41800321 & 41800441

41800321 & 41800425

n/a

Brake Lines, ABS - UPPER

(1)

41800323A &

41800333

41800323A &

41800332

Stock

OPTIONAL Brake Lines, ABS - LOWER

(1)

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

Handlebar ID will not fit with FLHTK stock heated grips or 56100034.

Requires separate purchase of accessory heated grips.

Heated Grips (stock FLHTK and 56100034)

57300063

Fairing Plugs (FLHX/S & models w/ fairing mounted mirrors)

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

115 / 165

2009-2013 FLHTCUTG & 2010-2011 FLHXXX

Table 435.

Diamond Black

Diamondback™

OEM Stock

Fitment

(1)

37200050A

38924-09A

n/a

Clutch Cables

n/a

41800246

n/a

Brake Lines, NON-ABS - UPPER

n/a

83666-10

n/a

Brake Lines, NON-ABS - LOWER

32310-08

Twist Grip Sensor Kit

732 (2x) & 755 (2x)

Fairing Plugs (FLHX & models w/ fairing mounted mirrors)

(1) Can NOT internally route 2013-earlier reverse wires of Trike models

2014-2016 FLHTCUTG

Table 436.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200046

37200040A

n/a

Hydraulic Clutch Line

41800260

41800246

n/a

Brake Lines, LINKED - UPPER

41600094

n/a

Brake Lines, LINKED - ADAPTER

41800558

41800292

Stock

OPTIONAL Brake Lines, LINKED - LOWER

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

2017-2018 FLHTCUTG

Table 437.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200288

37200249

n/a

Hydraulic Clutch Line

41800260

41800246

n/a

Brake Lines, LINKED - UPPER

41600094

n/a

Brake Lines, LINKED - ADAPTER

41800558

41800292

Stock

OPTIONAL Brake Lines, LINKED - LOWER

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

2019-later FLHTCUTG

Table 438.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200288

37200249

n/a

Hydraulic Clutch Line

41800738 & 41800260

41800738 & 41800246

n/a

Brake Lines, LINKED - UPPER

(1)

41800690 & 41800333

41800690 & 41800332

Stock

OPTIONAL Brake Lines, LINKED - LOWER

(1)

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

(1) Mid Brake lines 41800690 and 41800738 have OE black finish and are not cosmetically braided.

116 / 165

BATWING

REACH HANDLEBARS

55800589 (CHROME), 55800590 (GLOSS BLACK)

Figure 38. BATWING REACH HANDLEBARS

2008-2013 FLHT, FLHTC, FLHTCU & FLHX

Table 440.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200049A

38922-09A

n/a

Clutch Cables

41800254

41800240

n/a

Brake Lines, NON-ABS - UPPER

41800280

44905-08

n/a

Brake Lines, NON-ABS - LOWER

n/a

41800466

n/a

Brake Lines, ABS - UPPER ('09 - '13 models)

n/a

41825-09

n/a

Brake Lines, ABS - LOWER ('09 - '13 models)

Stock TGS if externally routing switch-wires

32310-08 req'd if internally routing switch-wires

Twist Grip Sensor Kit

732 (2x) & 755 (2x)

Fairing Plugs (FLHX & models w/ fairing mounted mirrors)

2014-2016 FLHTCU, FLHTK, FLHX & FLHXS

Table 441.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200044

37200038A

n/a

Hydraulic Clutch Line

41800440

41800424

n/a

Brake Lines, NON-ABS - UPPER

41800338

41800336

n/a

Brake Lines, NON-ABS - LOWER

41800321 & 41800258

41800321 & 41800244

n/a

Brake Lines, ABS - UPPER

(1)

41800323A &

41800333

41800323A &

41800332

Stock

OPTIONAL Brake Lines, ABS - LOWER

(1)

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

Handlebar ID will not fit with FLHTK stock heated grips or 56100034.

Requires separate purchase of accessory heated grips.

Heated Grips (stock FLHTK and 56100034)

57300063

Fairing Plugs (FLHX/S & models w/ fairing mounted mirrors)

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.
(2) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

2017-later FLHTCU, FLHTK, FLHX, FLHXS, FLHXSE & FLHTKSE

Table 442.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200290

37200247

n/a

Hydraulic Clutch Line

41800440

41800424

n/a

Brake Lines, NON-ABS - UPPER

41800338

41800336

n/a

Brake Lines, NON-ABS - LOWER

41800321 & 41800258

41800321 & 41800244

n/a

Brake Lines, ABS - UPPER

(1)

41800323A &

41800333

41800323A &

41800332

Stock

OPTIONAL Brake Lines, ABS - LOWER

(1)

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

Handlebar ID will not fit with FLHTK stock heated grips or 56100034.

Requires separate purchase of accessory heated grips.

Heated Grips (stock FLHTK and 56100034)

57300063

Fairing Plugs (FLHX/S & models w/ fairing mounted mirrors)

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

117 / 165

2009-2013 FLHTCUTG & 2010-2011 FLHXXX

Table 443.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200049A

38922-09A

n/a

Clutch Cables

n/a

41800244

n/a

Brake Lines, NON-ABS - UPPER

n/a

83666-10

n/a

Brake Lines, NON-ABS - LOWER

Stock TGS externally routing switch-wires Can

NOT internally route switch- or reverse-wires

Twist Grip Sensor Kit

732 (2x) & 755 (2x)

Fairing Plugs (FLHX & models w/ fairing mounted mirrors)

2014-2016 FLHTCUTG

Table 444.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200044

37200038A

n/a

Hydraulic Clutch Line

41800258

41800244

n/a

Brake Lines, LINKED - UPPER

41600094

n/a

Brake Lines, LINKED - ADAPTER

41800558

41800292

Stock

OPTIONAL Brake Lines, LINKED - LOWER

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

2017-2018 FLHTCUTG

Table 445.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200290

37200247

n/a

Hydraulic Clutch Line

41800258

41800244

n/a

Brake Lines, LINKED - UPPER

41600094

n/a

Brake Lines, LINKED - ADAPTER

41800558

41800292

Stock

OPTIONAL Brake Lines, LINKED - LOWER

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

2019-later FLHTCUTG

Table 446.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200290

37200247

n/a

Hydraulic Clutch Line

41800738 & 41800258

41800738 & 41800244

n/a

Brake Lines, LINKED - UPPER

(1)

41800690 & 41800333

41800690 & 41800332

Stock

OPTIONAL Brake Lines, LINKED - LOWER

(1)

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

(1) Mid Brake lines 41800690 and 41800738 have OE black finish and are not cosmetically braided.

118 / 165

BATWING

TALLBOY HANDLEBARS

55800591 (CHROME), 55800592 (GLOSS BLACK)

Figure 39. BATWING TALLBOY HANDLEBARS

2009-2013 FLHT, FLHTC, FLHTCU & FLHX

Table 448.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200049A

38922-09A

n/a

Clutch Cables

41800254

41800240

n/a

Brake Lines, NON-ABS - UPPER

41800280

44905-08

n/a

Brake Lines, NON-ABS - LOWER

n/a

41800466

n/a

Brake Lines, ABS - UPPER ('09 - '13 models)

n/a

41825-09

n/a

Brake Lines, ABS - LOWER ('09 - '13 models)

Stock TGS if externally routing switch-wires

32310-08 req'd if internally routing switch-wires

Twist Grip Sensor Kit

732 (2x) & 755 (2x)

Fairing Plugs (FLHX & models w/ fairing mounted mirrors)

2014-2016 FLHTCU, FLHTK, FLHX & FLHXS

Table 449.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200044

37200038A

n/a

Hydraulic Clutch Line

41800440

41800424

n/a

Brake Lines, NON-ABS - UPPER

41800338

41800336

n/a

Brake Lines, NON-ABS - LOWER

41800321 & 41800258

41800321 & 41800244

n/a

Brake Lines, ABS - UPPER

(1)

41800323A &

41800333

41800323A &

41800332

Stock

OPTIONAL Brake Lines, ABS - LOWER

(1)

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

Handlebar ID will not fit with FLHTK stock heated grips or 56100034.

Requires separate purchase of accessory heated grips.

Heated Grips (stock FLHTK and 56100034)

57300063

Fairing Plugs (FLHX/S & models w/ fairing mounted mirrors)

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

119 / 165

2017-later FLHTCU, FLHTK, FLHX & FLHXS

Table 450.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200290

37200247

n/a

Hydraulic Clutch Line

41800440

41800424

n/a

Brake Lines, NON-ABS - UPPER

41800338

41800336

n/a

Brake Lines, NON-ABS - LOWER

41800321 & 41800258

41800321 & 41800244

n/a

Brake Lines, ABS - UPPER

(1)

41800323A &

41800333

41800323A &

41800332

Stock

OPTIONAL Brake Lines, ABS - LOWER

(1)

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

Handlebar ID will not fit with FLHTK stock heated grips or 56100034.

Requires separate purchase of accessory heated grips.

Heated Grips (stock FLHTK and 56100034)

57300063

Fairing Plugs (FLHX/S & models w/ fairing mounted mirrors)

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

2009-2013 FLHTCUTG & 2010-2011 FLHXXX

Table 451.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200049A

38922-09A

n/a

Clutch Cables

n/a

41800244

n/a

Brake Lines, NON-ABS - UPPER

n/a

83666-10

n/a

Brake Lines, NON-ABS - LOWER

Stock TGS externally routing switch-wires Can

NOT internally route switch- or reverse-wires

Twist Grip Sensor Kit

732 (2x) & 755 (2x)

Fairing Plugs (FLHX & models w/ fairing mounted mirrors)

2014-2016 FLHTCUTG

Table 452.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200044

37200038A

n/a

Hydraulic Clutch Line

41800258

41800244

n/a

Brake Lines, LINKED - UPPER

41600094

n/a

Brake Lines, LINKED - ADAPTER

41800558

41800292

Stock

OPTIONAL Brake Lines, LINKED - LOWER

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

2017-2018 FLHTCUTG

Table 453.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200290

37200247

n/a

Hydraulic Clutch Line

41800258

41800244

n/a

Brake Lines, LINKED - UPPER

41600094

n/a

Brake Lines, LINKED - ADAPTER

41800558

41800292

Stock

OPTIONAL Brake Lines, LINKED - LOWER

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

2019-later FLHTCUTG

Table 454.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200290

37200247

n/a

Hydraulic Clutch Line

41800738 & 41800258

41800738 & 41800244

n/a

Brake Lines, LINKED - UPPER

(1)

41800690 & 41800333

41800690 & 41800332

Stock

OPTIONAL Brake Lines, LINKED - LOWER

(1)

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

(1) Mid Brake lines 41800690 and 41800738 have OE black finish and are not cosmetically braided.

120 / 165

ELECTRA-GLIDE

HANDLEBAR

56036-08 (CHROME)

Figure 40. ELECTRA-GLIDE

HANDLEBAR (stock on '08 CVO Electra Glide)

2009-2013 FLHT, FLHTC, FLHTCU & FLHX

Table 456.

Diamond Black

Diamondback™

OEM Stock

Fitment

38967-10A

38921-09A

Stock 38667-08A

Clutch Cables

41800252

41800238

Stock 43350-08

Brake Lines, NON-ABS - UPPER

41800280

44905-08

n/a

Brake Lines, NON-ABS - LOWER

41800551

41800468

Stock 41679-09

Brake Lines, ABS - UPPER ('09 - '13 models)

48946-10

41825-09

Stock 40612-09

Brake Lines, ABS - LOWER ('09 - '13 models)

32310-08

Twist Grip Sensor Kit

732 (2x) & 755 (2x)

Fairing Plugs (FLHX & models w/ fairing mounted mirrors)

2014-2016 FLHTCU, FLHTK, FLHX & FLHXS

Table 457.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200043

37200037A

Stock 37200024

Hydraulic Clutch Lines

41800254

41800240

Stock 41800174

Brake Lines, NON-ABS - UPPER

41800338

41800336

n/a

Brake Lines, NON-ABS - LOWER

41800321 & 41800440

41800321 & 41800424

Stock

Brake Lines, ABS - UPPER

(1)

41800323A &

41800333

41800323A &

41800332

Stock

OPTIONAL Brake Lines, ABS - LOWER

(1)

Stock

Twist Grip Sensor Kit

Handlebar ID will not fit with FLHTK stock heated grips or 56100034.

Requires separate purchase of accessory heated grips.

Heated Grips (stock FLHTK and 56100034)

57300063

Fairing Plugs (FLHX/S & models w/ fairing mounted mirrors)

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

2017-later FLHTCU, FLHTK, FLHX & FLHXS

Table 458.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200289

37200246

Stock 37200129

Hydraulic Clutch Lines

41800254

41800240

Stock 41800174

Brake Lines, NON-ABS - UPPER

41800338

41800336

n/a

Brake Lines, NON-ABS - LOWER

41800321 & 41800440

41800321 & 41800424

Stock

Brake Lines, ABS - UPPER

(1)

41800323A &

41800333

41800323A &

41800332

Stock

OPTIONAL Brake Lines, ABS - LOWER

(1)

Stock

Twist Grip Sensor Kit

Handlebar ID will not fit with FLHTK stock heated grips or 56100034.

Requires separate purchase of accessory heated grips.

Heated Grips (stock FLHTK and 56100034)

57300063

Fairing Plugs (FLHX/S & models w/ fairing mounted mirrors)

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

121 / 165

ROAD KING

FAT HANDLEBAR

55800386 (CHROME), 55800388 (BLACK)

Figure 41. ROAD KING

FAT HANDLEBAR (stock on '14 CVO Road King)

2014-2016 FLHR & FLHRC

Table 460.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200049A

38922-09A

n/a

Clutch Cables

41800442 & 41800321

41800426 & 41800321

n/a

Brake Lines, ABS - UPPER

(1)

41800333 &

41800323A

41800332 &

41800323A

Stock 41800194 & 41800195

OPTIONAL Brake Lines, ABS - LOWER

(1)

55900067

Riser Kit

Stock

Handlebar Cover Kit

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

2017-Later FLHR & FLHRC

Table 461.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200280

37200255

n/a

Hydraulic Clutch Line

41800442 & 41800321

41800426 & 41800321

n/a

Brake Lines, ABS - UPPER

(1)

41800333 &

41800323A

41800332 &

41800323A

Stock 41800194 & 41800195

OPTIONAL Brake Lines, ABS - LOWER

(1)

55900067

Riser Kit

Stock

Handlebar Cover Kit

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

2017-Later FLHRXS

Table 462.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200280

37200255

n/a

Hydraulic Clutch Line

41800442 & 41800321

41800426 & 41800321

n/a

Brake Lines, ABS - UPPER

(1)

41800333 &

41800323A

41800332 &

41800323A

Stock 41800194 & 41800195

OPTIONAL Brake Lines, ABS - LOWER

Stock

Handlebar Cover Kit

Stock

Twist Grip Sensor Kit

69200034

Switch Wire Extensions, 10"

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

122 / 165

ROAD KING

/ ROAD GLIDE

REACH HANDLEBAR

56166-08 (CHROME)

Figure 42. ROAD KING

/ ROAD GLIDE

REACH

HANDLEBAR

2008-2013 FLHR & FLHRC

Table 464.

Diamond Black

Diamondback™

OEM Stock

Fitment

38967-10A

38921-09A

Stock 38667-08A

Clutch Cables

n/a

41800452

n/a

Brake Lines, NON-ABS - UPPER

n/a

44907-08

n/a

Brake Lines, NON-ABS - LOWER

41800482

41800469

n/a

Brake Lines, ABS - UPPER ('09 - '13 models)

48946-10

41825-09

n/a

Brake Lines, ABS - LOWER ('09 - '13 models)

Stock length adequate if externally routing

switch-wires 70198-07 req'd if internally routing

switch-wires

Switch Wire Extensions, 5"

32310-08

Twist Grip Sensor Kit

2935A (2x)

Tamper-proof Screws (HDI, Australia, England, Japan only)

2014-2016 FLHR & FLHRC

Table 465.

Diamond Black

Diamondback™

OEM Stock

Fitment

38967-10A

38921-09A

Stock 37200005

Clutch Cables

41800254

41800240

Stock 41800174

Brake Lines, NON-ABS - UPPER

41800338

41800336

n/a

Brake Lines, NON-ABS - LOWER

41800321 & 41800440

41800321 & 41800424

Stock

Brake Lines, ABS - UPPER

(1)

41800323A &

41800333

41800323A &

41800332

Stock

OPTIONAL Brake Lines, ABS - LOWER

(1)

Stock

Twist Grip Sensor Kit

(1) Mid Brakelines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

2017-later FLHR & FLHRC

Table 466.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200280

37200255

Stock 37200005

Clutch Cables

41800254

41800240

Stock 41800174

Brake Lines, NON-ABS - UPPER

41800338

41800336

n/a

Brake Lines, NON-ABS - LOWER

41800321 & 41800440

41800321 & 41800424

Stock

Brake Lines, ABS - UPPER

(1)

41800323A &

41800333

41800323A &

41800332

Stock

OPTIONAL Brake Lines, ABS - LOWER

(1)

Stock

Twist Grip Sensor Kit

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

124 / 165

2008-2013 FLTR, FLTRX & FLTRU

Table 467.

Diamond Black

Diamondback™

OEM Stock

Fitment

38967-10A

38921-09A

n/a

Clutch Cables

n/a

41800452

n/a

Brake Lines, NON-ABS - UPPER

n/a

44907-08

n/a

Brake Lines, NON-ABS - LOWER

41800482

41800469

n/a

Brake Lines, ABS - UPPER ('09 - '13 models)

48946-10

41825-09

n/a

Brake Lines, ABS - LOWER ('09 - '13 models)

32310-08

Twist Grip Sensor Kit

125 / 165

ROAD KING

/ ROAD GLIDE

TALLBOY HANDLEBAR

56180-08 (CHROME)

Figure 43. ROAD KING

/ ROAD GLIDE

TALLBOY HANDLEBAR

2008-2013 FLHR & FLHRC

Table 469.

Diamond Black

Diamondback™

OEM Stock

Fitment

38967-10A

38921-09A

n/a

Clutch Cables

n/a

41800242

n/a

Brake Lines, NON-ABS - UPPER

n/a

44907-08

n/a

Brake Lines, NON-ABS - LOWER

n/a

41800470

n/a

Brake Lines, ABS - UPPER ('09 - '13 models)

n/a

41825-09

n/a

Brake Lines, ABS - LOWER ('09 - '13 models)

Stock length adequate if externally routing

switch-wires 70198-07 req'd if internally routing

switch-wires

Switch Wire Extensions, 5"

32310-08

Twist Grip Sensor Kit

2935A (2x)

Tamper-proof Screws (HDI, Australia, England, Japan only)

2014-2016 FLHR & FLHRC

Table 470.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200049A

38922-09A

n/a

Clutch Cables

41800440

41800424

n/a

Brake Lines, NON-ABS - UPPER

41800338

41800336

n/a

Brake Lines, NON-ABS - LOWER

41800321 & 41800258

41800321 & 41800244

n/a

Brake Lines, ABS - UPPER

(1)

41800323A &

41800333

41800323A &

41800332

Stock

OPTIONAL Brake Lines, ABS - LOWER

(1)

Stock

Twist Grip Sensor Kit

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

2017-later FLHR & FLHRC

Table 471.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200280

37200255

n/a

Hydraulic Clutch Line

41800440

41800424

n/a

Brake Lines, NON-ABS - UPPER

41800338

41800336

n/a

Brake Lines, NON-ABS - LOWER

41800321 & 41800258

41800321 & 41800244

n/a

Brake Lines, ABS - UPPER

(1)

41800323A &

41800333

41800323A &

41800332

Stock

OPTIONAL Brake Lines, ABS - LOWER

(1)

Stock

Twist Grip Sensor Kit

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

126 / 165

2008-2013 FLTR, FLTRX & FLTRU

Table 472.

Diamond Black

Diamondback™

OEM Stock

Fitment

38967-10A

38921-09A

n/a

Clutch Cables

n/a

41800242

n/a

Brake Lines, NON-ABS - UPPER

n/a

44907-08

n/a

Brake Lines, NON-ABS - LOWER

n/a

41800470

n/a

Brake Lines, ABS - UPPER ('09 - '13 models)

n/a

46049-09

n/a

Brake Lines, ABS - LOWER ('09 - '13 models)

32310-08

Twist Grip Sensor Kit

2015-2016 FLRT

Table 473.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200109

37200107

Stock 37200084

Hydraulic Clutch Line

41800455

41800452

Stock 41800343

Brake Lines, LINKED - UPPER

41600094

n/a

Brake Lines, LINKED - ADAPTER

41800558

41800292

Stock 41800184 & 41800187

OPTIONAL Brake Lines, LINKED - LOWER

Stock

Twist Grip Sensor Kit

2017-2018 FLRT

Table 474.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200281

37200253

Stock 37200084

Hydraulic Clutch Line

41800455

41800452

Stock 41800343

Brake Lines, LINKED - UPPER

41600094

n/a

Brake Lines, LINKED - ADAPTER

41800558

41800292

Stock 41800184 & 41800187

OPTIONAL Brake Lines, LINKED - LOWER

Stock

Twist Grip Sensor Kit

2019-later FLRT

Table 475.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200281

37200253

Stock 37200084

Hydraulic Clutch Line

41800738 & 41800455

41800738 & 41800452

Stock 41800343

Brake Lines, LINKED - UPPER

(1)

41800690 & 41800333

41800690 & 41800332

Stock 41800184 & 41800187

OPTIONAL Brake Lines, LINKED - LOWER

(1)

Stock

Twist Grip Sensor Kit

(1) Mid Brake lines 41800690 and 41800738 have OE black finish and are not cosmetically braided.

127 / 165

ROAD KING

/ ROAD GLIDE

HERITAGE STYLE HANDLEBAR

56902-08 (POLISHED), 55864-09 (SATIN BLACK)

Figure 44. ROAD KING

/ ROAD GLIDE

HERITAGE STYLE HANDLEBAR

2008-2013 FLHR & FLHRC

Table 477.

Diamond Black

Diamondback™

OEM Stock

Fitment

38967-10A

38921-09A

Stock 38667-08A

Clutch Cables

n/a

41800424

Stock 43350-08

Brake Lines, NON-ABS - UPPER

n/a

44907-08

n/a

Brake Lines, NON-ABS - LOWER

n/a

Stock

Brake Lines, ABS ('08 models)

41800551

41800468

Stock 41679-09

Brake Lines, ABS - UPPER ('09 - '13 models)

48946-10

41825-09

Stock 40612-09

Brake Lines, ABS - LOWER ('09 - '13 models)

Stock length adequate if externally routing

switch-wires 70198-07 req'd if internally routing

switch-wires

Switch Wire Extensions, 5"

32310-08

Twist Grip Sensor Kit

2935A (2x)

Tamper-proof Screws (HDI, Australia, England, Japan only)

2014-2016 FLHR & FLHRC

Table 478.

Diamond Black

Diamondback™

OEM Stock

Fitment

38967-10A

38921-09A

Stock 37200005

Clutch Cables

41800254

41800240

Stock 41800174

Brake Lines, NON-ABS - UPPER

41800338

41800336

n/a

Brake Lines, NON-ABS - LOWER

41800321 & 41800440

41800321 & 41800424

Stock

Brake Lines, ABS - UPPER

(1)

41800323A &

41800333

41800323A &

41800332

Stock

OPTIONAL Brake Lines, ABS - LOWER

(1)

Stock

Twist Grip Sensor Kit

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

128 / 165

2017-later FLHR & FLHRC

Table 479.

Diamond Black

Diamondback™

OEM Stock

Fitment

37200280

37200255

Stock 37200129

Clutch Cables

41800254

41800240

Stock 41800174

Brake Lines, NON-ABS - UPPER

41800338

41800336

n/a

Brake Lines, NON-ABS - LOWER

41800321 & 41800440

41800321 & 41800424

Stock

Brake Lines, ABS - UPPER

(1)

41800323A &

41800333

41800323A &

41800332

Stock

OPTIONAL Brake Lines, ABS - LOWER

(1)

Stock

Twist Grip Sensor Kit

(1) Mid Brake lines 41800321 and 41800323A have OE black finish and are not cosmetically braided.

2008-2013 FLTR, FLTRX & FLTRU

Table 480.

Diamond Black

Diamondback™

OEM Stock

Fitment

38967-10A

38921-09A

Stock 38667-08A

Clutch Cables

n/a

41800452

Stock 43350-08

Brake Lines, NON-ABS - UPPER

n/a

44907-08

n/a

Brake Lines, NON-ABS - LOWER

n/a

Stock

Brake Lines, ABS ('08 models)

n/a

41800469

Stock 41679-09

Brake Lines, ABS - UPPER ('09 - '13 models)

n/a

46049-09

Stock 42161-09

Brake Lines, ABS - LOWER ('09 - '13 models)

32310-08

Twist Grip Sensor Kit

129 / 165

Harley Davidson HANDLEBAR INSTALLATION REQUIREMENTS (2019-02-13) - page 8
