Ease of use and comfort

USB socket

For more information about how to use this

In the event of a malfunction, the

equipment, refer to the sections describing

green indicator lamp flashes.

the audio and telematics systems.

Have it checked by a CITROËN dealer or a

qualified workshop.

220 V socket

Connect only one device to the socket at

a time (do not use an extension lead or

multi-socket) and only connect devices with

Class II insulation (indicated on the device).

Do not use devices with metallic cases.

Depending on version, a 220 V/50 Hz socket

The socket can be used to connect a portable

(maximum power: 120 W) is located underneath

If the power consumption becomes too

device or a USB memory stick.

the front right-hand seat and therefore

high and when required by the vehicle's

The socket reads audio files that are sent to your

accessible from row 2.

electrical system (particular weather

audio system to be played through the vehicle's

This socket works with the engine running, as

conditions, electrical overload, etc.), the

speakers.

well as in STOP mode of Stop & Start.

power supply to the socket will be cut off; the

These files can be managed using the steering-

green indicator lamp goes off

mounted controls or those on the audio system.

The USB socket also allows a

smartphone to be connected by

Load space cover

Android Auto^® or CarPlay^®, enabling certain

smartphone applications to be used on the touch

screen.

For best results, use a cable made or approved

by the device manufacturer.

These applications can be managed using the

steering-mounted controls or the audio system

controls.

► Lift the cover.

When the USB socket is used, the

► Check that the indicator lamp is on green.

portable device charges automatically.

► Connect your multimedia or other electrical

While charging, a message is displayed if the

device (telephone charger, laptop computer,

power drawn by the portable device exceeds

CD-DVD player, bottle warmer, etc.).

► To remove it, lift it up.

the current supplied by the vehicle.

CarManuals2.co

Ease of use and comfort

► To install it, insert the guides into their

Load retaining partition

housings.

In the event of sudden deceleration,

objects placed on the load space cover

can turn into projectiles.

Loading area fittings

Stowing rings

Use the stowing rings on the rear floor to secure

loads.

As a safety precaution in case of sharp braking,

we recommend placing heavy objects as far

forwards as possible (i.e. near the cab).

We recommend immobilising the load by firmly

On the floor, behind the front seats, a vertical

securing it using the stowing rings present on

partition protects the driver and front passengers

the floor.

against the risk of load movement.

Steel or glazed partitions separate the loading

area from the cab.

CarManuals2.co

Ease of use and comfort

Recommendations on

Firmly secure all parts of the load using

Seating area fittings

the stowing rings on the floor of the

loading area.

For more information on the Interior fittings

The weight of the load must comply with

and in particular on the stowing rings, refer to

the Gross Train Weight (GTW).

the corresponding section.

For more information on Engine technical

High load retaining net

data and towed loads, refer to the

corresponding section.

To avoid the risk of injury or accident, the

This allows the use of the entire loading capacity,

load must be made stable so that it

up to the roof:

cannot slide, tip over, fall or be projected. To

- behind the front seats in row 1, when the rear

If you are using a carrying system (roof

do this, use only retaining straps that conform

seats (and bench seats) in rows 2 and 3 are

bars/roof rack), comply with the

to current standards (DIN, for example).

folded or removed,

maximum loads associated with this system.

For more information on putting straps in

- behind the rear seats (and bench seats) in row

For more information on Roof bars/Roof

place, refer to the manufacturer’s user guide.

2, when the rear seats (and bench seats) in row

rack, refer to the corresponding section.

To prevent the load from sliding, there must

3 are folded or removed.

not be any empty spaces between the load

Make sure that the size, shape and

items and the vehicle wall panels.

Upper fixings

volume of the loads carried are

As well as the straps, optimise the stability

compatible with the highway code and safety

of the load with stable handling equipment

regulations and do not impair the driver’s field

(wedges, rigid blocks of wood or padding).

of vision.

When washing your vehicle, never clean

The load must be evenly distributed in

the inside directly using a water jet.

the loading area so as not to interfere

with driving the vehicle.

Place the load close to the side wall panels,

► Unclip the anchorage cover in the roof on

or push it against the side wall panels

each side.

between the wheel arches.

Lower fixings (behind row 1)

However, it is recommended that heavy

objects are placed as close to the cab as

If your vehicle has fixed one-piece bench seats

possible as a precaution in case of sharp

or seats and bench seats:

braking.

CarManuals2.co

Ease of use and comfort

Lower fixings (behind row 2)

Never use the ISOFIX ring provided for

fixing the strap of a child seat with Top

Tether.

Rear windows in row 2

If fitted to your vehicle, the side windows in row 2

can be opened.

► On each side in row 2, insert the fixings in the

floor anchorages (as shown above).

If your vehicle has seats and bench seats or

► Use the stowing rings.

individual seats on rails:

Fit the net

Unclip the upper fixing covers and secure the

lower fixings (as previously described).

► Fold (table position) the seats and bench

seats in rows 2 and 3 (according to equipment).

While driving, the windows must be closed or

► Close the rear heating and air conditioning

secured at one of the notches.

vents (depending on the equipment you have).

► Squeeze the two controls then move the

► Unroll the high load retaining net.

window sideways.

► Position the net upper fixings in the

corresponding anchorages in the roof (first one

For more information on the Child lock

side, then the other).

on rear windows, refer to the

► Fully extend the straps.

corresponding section.

► On each side in row 2, insert the fixings in the

► On each side, attach the bottom fixings of the

floor anchorages then turn them a quarter turn to

net to the lower anchorages (behind row 1) or in

lock them in place (as shown above).

Side blinds

the stowing rings (behind row 2).

Place them as close as possible to the end of

► Tension the straps to extend the net.

Fitted to the windows in row 2, these protect the

the rail.

► Check that the net is attached securely and

passenger compartment from the sun's rays.

properly extended.

CarManuals2.co

Ease of use and comfort

Blinds

Retractable sliding table

Opening/Closing

Shine, Business Lounge

► Pull the tab A and attach the blind to the hook

Always guide the blind slowly, using the

tab, when raising or lowering it.

► Take one of the blinds by its grip and push it

back or pull it forwards to the desired position.

The table has a central storage space covered

Panoramic sunroof

by a lid. When deployed, this device becomes

a table with two table tops on which you can

place objects. The central part has two cup/

can holders and can also be used to hold small

objects (e.g. credit card, pen).

This is fitted with two manual and independent

The assembly is mounted on a runner allowing it

blinds, which improve thermal and acoustic

to be positioned either in row 2 or row 3.

comfort.

CarManuals2.co

Ease of use and comfort

Storage

► Release the control when it is in the desired

Folding

position.

► Raise each table top, going beyond the point

► Check that the table is secured on the runner.

of resistance, to the vertical position.

If this is not the case, move the assembly slightly

► Push each table top down into its housing

to the next notch on the runner.

until it clicks into place.

You can move the table in both the open

and stowed position. However, to ensure

safety, it is advised that you handle the

assembly in the stowed position.

► Slide back the cover for access to 11 litres of

storage space.

For the table to run smoothly, ensure that

no objects are blocking the space used

The storage space can only support a

by the runner on the floor.

maximum weight of 3 kg; do not exceed

Before manoeuvring the table, check that

this maximum load in use.

there is nothing on the table.

Moving forward or backward

► Push the control then tip the table assembly

Unfolding

downward until it clicks into place.

Before stowing the table tops, check that

they are clear. Before tipping the

assembly down, check that the two table tops

have clicked home in the low position and that

there is nothing in the cup holder area (such

as a can or pen).

Cup holders

► Operate the control on the top and pull the

Two cups or cans and small objects (such as

table assembly up until it clicks into place.

a credit card, portable ashtray or pen) can be

► Lift the control (without going beyond the

► Pull each table top fully up then pivot them on

carried in the middle of the unfolded table.

point of resistance) and slide the assembly

each side into the horizontal position.

forwards or backwards.

CarManuals2.co

Ease of use and comfort

Liquids carried in an open vessel (a cup

Changing the direction

► Check that the control is in the upper position

or mug) could be spilt, presenting a risk.

(locking mechanism armed). If not, lift this control

Be careful.

fully to arm the mechanism.

Never use the table in this position while the

► Place the front of the table on the runner.

vehicle is being driven.

► Taking care not to interfere with the control,

tip the assembly towards the rear until you hear

it lock into place.

Removal

► Check that the assembly is fully locked into

the runner. If not, slide the assembly gently along

the runner until it meets the next notch.

Check that the table is fully locked into

the runner - risk of injury in the event of

With the table removed, you can turn it 180°.

an accident or sudden braking.

Remove a seat to make this easier.

► Release the control until the guide locks into

the runner.

Be careful of passengers' feet when

Refitting

manoeuvring the assembly.

► Raise the control fully to release the

► Check that there is no object obstructing the

anchorages and tip the table assembly forward.

runner and preventing proper locking.

Storage off the runner

► Remove the table assembly through the

sliding door in row 2.

If removing the table from the vehicle for

storage, ensure that it is placed in a

Check that there is nothing in the space

clean area, in order to avoid introducing any

around the runner on the floor, so that

foreign bodies into the mechanisms.

the table disengages cleanly.

The table must be placed outside the vehicle,

on a flat and level surface, resting on the

guide so as not to damage visible parts.

Caution, when out of the vehicle, the

table leans to the right or left when

placed on a surface.

CarManuals2.co

Ease of use and comfort

- risk of damaging the surface and starting a

fire!

When the table is deployed, each table

top can support a maximum of 10 kg. If

you exceed the maximum weight limit, you

When stowing the table tops, never place

risk damaging part or all of the table.

your hand inside the slide area - risk of

Never lift the table when it is between

trapping your fingers! Use the handle

individual seats; you risk damaging the table

provided.

tops.

Incorrect use of the table can cause

serious injury.

Never use the table in the open or deployed

Heating and Ventilation

position while the vehicle is in motion. In the

event of sudden braking, any object placed on

Advice

the table can become a projectile.

Ensure that the table is correctly stowed in

Using the ventilation and air

the low position before setting off.

conditioning system

Never use the table tops as seats or lean on

► To ensure that air is distributed evenly,

them.

keep the external air intake grilles at the base

A label attached to the side of the table

of the windscreen, the nozzles, the vents, the

serves as a reminder of this.

air outlets and the air extractor in the boot

free from obstructions.

► Do not cover the sunshine sensor located

on the dashboard; this sensor is used to

regulate the automatic air conditioning

system.

► Operate the air conditioning system for at

Before moving the table or an individual

least 5 to 10 minutes once or twice a month to

seat forwards or backwards, make sure

keep it in good working order.

Never place hot objects such as

that the seat's backrest is upright and the

► If the system does not produce cold air,

saucepans or frying pans on the table

table is stowed.

switch it off and contact a CITROËN dealer or

a qualified workshop.

CarManuals2.co

Ease of use and comfort

When towing a large load on a steep gradient

► To ensure correct operation of the

Heating

in high temperatures, switching off the air

air conditioning system, have it checked

conditioning increases the available engine

according to the recommendations in the

power, enhancing the towing capacity.

Manufacturer’s service schedule.

Avoid driving for too long with the

ventilation off or with prolonged operation

of interior air recirculation. Risk of misting and

Manual air conditioning

deterioration of the air quality!

Contains R134A fluorinated

The air conditioning system only operates with

greenhouse gases

the engine running.

If the interior temperature is very high

Depending on version and country of sale, the

after the vehicle has stood for a long

air conditioning system may contain R134A

time in the sunshine, air the passenger

fluorinated greenhouse gases. Gas capacity

compartment for a few moments.

0.5 kg (+/- 0.025 kg), GWP index 1430 (CO₂

Put the air flow control at a setting high

equivalent: 0.715 t).

enough to quickly change the air in the

1. Temperature.

passenger compartment.

Stop & Start

2. Air flow.

The heating and air conditioning systems

3. Air distribution.

Condensation created by the air

only work when the engine is running.

4. Interior air recirculation.

conditioning results in a discharge of

Temporarily deactivate the Stop & Start

5. Air conditioning on/off.

water underneath the vehicle. This is perfectly

system to maintain a comfortable temperature

normal.

in the passenger compartment.

Air flow

For more information on Stop & Start, refer

Servicing the ventilation and air

to the corresponding section.

► Turn the thumbwheel 2 to obtain a

conditioning system

comfortable air flow.

► Ensure that the passenger compartment

ECO driving mode

If you set the air flow control to the

filter is in good condition and have the filter

Selecting this mode reduces electrical

minimum position (off), the temperature

elements replaced regularly.

energy consumption, but restricts the

in the vehicle will no longer be controlled. A

We recommend using a composite passenger

performance of the heating and air

slight air flow can still be felt however,

compartment filter. Its specific active additive

conditioning systems, although it does not

resulting from the forward movement of the

helps protect against polluting gases and bad

deactivate them.

vehicle.

smells.

CarManuals2.co

Ease of use and comfort

Temperature

air recirculation for a few moments by pressing

The active mode appears in the display screen,

button 4. Then restore the intake of exterior air.

as described below:

► Turn the thumbwheel 1 from "LO" (cold)

Ensures soft, quiet operation by limiting

to "HI" (hot) to adjust the temperature to your

The air conditioning does not operate

air flow.

requirements.

when the air flow adjustment is set to off.

Offers the best compromise between a

comfortable temperature and quiet

Air distribution

Switching the system off could result in

operation.

► Pressing button 3 successively directs the air

discomfort (humidity, misting).

Provides dynamic, effective air flow.

flow towards:

- windscreen, side windows and footwells,

- footwells,

When the engine is cold, the air flow will

Dual-zone automatic air

- central vents, side vents and footwells,

only increase to its optimum level

- windscreen, side windows, central vents, side

conditioning

gradually, to avoid distributing too much cold

vents and footwells,

air.

- central and side vents,

In cold weather, it prioritises the distribution of

- windscreen and side windows (demisting or

warm air to the windscreen, the side windows

defrosting).

and the footwells only.

Air conditioning

Temperature.

Manual mode

With the engine running, the air conditioning is

Air flow.

It is possible to make a different choice from that

designed to operate effectively in all seasons,

Air distribution.

offered by the system by changing a setting.

with the windows closed.

Recirculation of interior air.

The other functions will still be automatically

It enables you to:

Air conditioning on/off.

managed.

- lower the temperature in summer,

Automatic comfort mode.

The "AUTO” symbol disappears if you change a

- enhance the effectiveness of the demisting

Visibility programme.

setting.

function in winter, above 3°C.

“Mono” function or Rear heating and air

conditioning on/off (depending on version).

Deactivating the system

On/Off

► Press button 2 "-" until the fan symbol

► Press button 5 to activate/deactivate the air

disappears.

conditioning system.

Automatic comfort mode

This action switches off all of the functions of the

When the air conditioning is in operation, to

► Press the "AUTO" button 6 to toggle the

system.

cool the air more quickly, you can use interior

mode.

CarManuals2.co

Ease of use and comfort

Temperature is no longer controlled. A slight air

exceed the minimum value 14 or the

Visibility programme

flow can still be felt, however, resulting from the

maximum value 28.

► Press the "visibility" button 7 to demist or

forward movement of the vehicle.

► Push button 1 down until "LO" is

de-ice the windscreen and side windows more

► Press button 2 "+" to switch the system on

displayed or up until "HI" is displayed.

quickly.

again.

The system automatically manages the air

"Mono" function

conditioning, air flow and air intake, and provides

Temperature

optimum distribution towards the windscreen and

The comfort setting for the passenger's side

The driver and front passenger can each set the

side windows.

can be indexed to the driver's comfort setting

temperature to suit their preferences.

► Press the "visibility" button 7 again to stop

(mono-zone).

The value shown on the display is a level

the programme.

of comfort, not a temperature in Celsius or

Fahrenheit.

► Press the "AUTO" button 6 to return to the

► Push button 1 down to decrease the value or

► Press the corresponding button 8 to activate/

automatic comfort programme.

up to increase it.

deactivate the function.

The indicator lamp in the button is on when the

Air conditioning

A setting of around 21 provides optimum

function is activated.

comfort. Depending on your

With the engine running, the air conditioning is

The function is deactivated automatically if a

requirements, a setting between 18 and 24 is

designed to operate effectively in all seasons,

passenger uses the temperature control.

normal.

with the windows closed.

In addition, we recommend avoiding left/right

It is used to:

Rear heating - air

setting differences of more than 3.

- lower the temperature in summer,

conditioning

- increase the effectiveness of the demisting in

winter, above 3°C.

On entering the vehicle, if the interior

temperature is significantly colder or

On/Off

warmer than the comfort value setting, there

► Press the corresponding button 8 to activate/

is no need to alter the value displayed in

deactivate the function.

► Press button 5 to activate/deactivate the air

conditioning system.

order to reach the required level of comfort.

For more information, refer to the Rear

When the air conditioning is in operation, to

The system compensates automatically and

heating - air conditioning section.

cool the air more quickly, you can use interior

corrects the temperature difference as quickly

air recirculation for a few moments by pressing

as possible.

button 4. Then restore the intake of exterior air.

For maximum cooling or heating of the

The air conditioning does not operate

passenger compartment, it is possible to

when the air flow adjustment is set to off.

CarManuals2.co

Ease of use and comfort

Switching the system off could result in

► Press this button to activate/deactivate

► For air conditioning, press this button;

discomfort (humidity, misting).

the function (confirmed by the

its indicator lamp comes on.

illumination/extinction of the indicator lamp).

Dual-zone automatic air

Air distribution

Front demisting

conditioning

► Pressing button 3 successively directs the air

flow towards:

- defrosting

- windscreen, side windows and footwells,

These markings on the control panel

- footwells,

indicate the positioning of the controls for

- central vents, side vents and footwells,

rapid demisting or defrosting of the windscreen

- windscreen, side windows, central vents, side

and side windows.

vents and footwells,

- central and side vents,

Heating or manual air

- windscreen and side windows (demisting or

► Press this button to demist or defrost

defrosting).

conditioning

the windscreen and side windows more

quickly.

Air flow

The system automatically manages the air

► Press the buttons 2 to increase/decrease the

conditioning, air flow and air intake, and provides

air flow.

optimum distribution towards the windscreen and

The air flow symbol (a fan) appears. It is filled in

side windows.

or emptied gradually, according to the value set.

► To turn it off, press this button

again or press "AUTO".

The system restarts with the values in use before

Interior air recirculation

it was deactivated.

The intake of exterior air prevents the formation

of mist on the windscreen and side windows.

Recirculating the interior air isolates the

passenger compartment from outside odours

and fumes and allows the desired passenger

compartment temperature to be achieved more

rapidly.

► Set the air flow, temperature and air

distribution controls to the appropriately marked

positions.

CarManuals2.co

Ease of use and comfort

Demisting/de-icing the

Rear heating - air

Air flow

► Turn the dial to increase or decrease

rear screen and/or the

conditioning

the air flow.

door mirrors

Comfort temperature

- Turn the thumbwheel from blue (cold)

to red (hot) to modulate the temperature

to your liking.

This control simultaneously adjusts the

temperature and the location of the air delivery:

- blue: the air is delivered mainly at roof level,

- red: the air is delivered mainly by the vent

located in row 3 on the right.

► Press one of these buttons to switch on/off

rear screen and door mirror demisting/de-icing

Activation/Deactivation

(depending on version).

The indicator lamp in the button comes on when

the function is activated.

Demisting/de-icing switches off automatically to

prevent excessive power consumption.

Switch off demisting/de-icing as soon

as you no longer consider it necessary,

as decreased power consumption in turn

reduces energy consumption.

Depending on version, this button is accessible

at the front, from the dual-zone automatic air

conditioning control panel.

Demisting/de-icing only operates with the

► Press this button to activate/deactivate

engine running.

the operation of the rear controls.

If your vehicle is fitted with a rear air conditioning

unit located in the roof, this system distributes

conditioned and heated air via a distribution rail

and individual outlets.

CarManuals2.co

Ease of use and comfort

Additional heating/

Programming

Using these two clocks and depending

on the season you can, for example,

With a MyCitroën Drive, use the remote control

ventilation system

select one or the other start time.

to start/stop the additional heating.

Only available for Diesel vehicles.

A message on the screen confirms your

With a Bluetooth^® audio system or a MyCitroën

choice.

Play, use the remote control to start/stop the

additional heating and/or adjust the pre-heating

times.

With MyCitroën Play

Press Connect-App to display the main

With Bluetooth^® audio system

page.

Then press "Programmable heating/

ventilation".

► Press the MENU button to access the

► Select the "Status" tab to activate/deactivate

main menu.

the system.

Heating

► Select "Pre-heat. / Pre-ventil.".

► Select the "Other settings" tab to choose

This is an additional and separate system which

► Select "Activation" and, if necessary, for

the "Heating" mode, to heat the engine and

heats the passenger compartment and improves

programming, “Parameters".

passenger compartment, or "Ventilation" to

defrosting performance.

► Select "Heating" to heat the engine and

ventilate the passenger compartment.

This indicator lamp is lit while the system

passenger compartment or "Ventilation" to

► Then set/save the time at which the

is programmed or set in operation

ventilate the passenger compartment.

preheating temperature will be reached for each

remotely via the remote control.

selection.

It flashes during the whole duration of the

Press this button to save.

heating and goes off at the end of the heating

cycle or when stopped using the remote control.

With MyCitroën Drive

► Select:

Ventilation

• the first clock to set/save the time at which

In the Applications > Car Apps menu:

This system allows ventilation of the passenger

the pre-heating temperature will be reached,

compartment with exterior air to improve the

• the second clock to set/save a second time

► Select Temperature conditioning.

temperature experienced on entering the vehicle

at which the pre-heating temperature will be

in summer.

reached,

► Press the Status tab to activate/deactivate

the system.

► Press the Settings tab to select Heating

mode to heat the engine and passenger

CarManuals2.co

Ease of use and comfort

compartment or Ventilation to ventilate the

► Use a coin to unscrew the cap and replace

passenger compartment.

► Pressing and holding this button starts

the battery.

► Then programme/save the activation time for

the heating immediately (confirmed by the

Do not throw remote control batteries

each selection.

green indicator lamp coming on briefly).

away, as they contain metals that are

► Press OK to confirm.

harmful to the environment. Take them to an

Switching off

You must allow at least 60 minutes

approved disposal point.

► Pressing and holding this button stops

between programming operations.

the heating immediately (confirmed by the

If the system is switched on using the

temporary illumination of the red indicator lamp).

Depending on the outside temperature, a

long-range remote control, the maximum

The indicator lamp in the remote control flashes

certain amount of pre-conditioning time is

heating duration is around 45 min.

for about 2 seconds if the vehicle has not

necessary in order to reach the programmed

received the signal.

temperature by the stored activation time.

The ventilation is activated provided that

Then repeat the command after having changed

This pre-conditioning time lasts up to 45 min.

the battery is sufficiently charged.

location.

The heating is activated provided that:

Changing the battery

- the battery charge and the fuel level are

Long-range remote control

sufficient,

The indicator lamp in the remote control will

This enables you to switch the heating in

- the engine has been started since the

change to orange if the battery charge is low.

the passenger compartment on or off from a

previous heating cycle,

If the indicator lamp is not on, the battery is

distance.

- 60 minutes have elapsed between two

discharged.

The remote control has a range of about 0.6

heating requests.

miles (1 km) in open country.

Programmable heating is supplied by the

vehicle fuel tank. Before use, make sure

that you have sufficient fuel. If the fuel tank is

on reserve, you are strongly recommended

not to programme the heating.

CarManuals2.co

Ease of use and comfort

The additional heating must always be

high-pitched whistling and some emissions of

Temperature pre-

switched off while refuelling to avoid any risk

smoke or odour.

of fire or explosion.

The temperature near the heating system must

conditioning (Electric)

not exceed 120°C. A higher temperature (e.g. in

This function allows you to programme the

To avoid the risk of poisoning or

a paint oven) could damage the components of

temperature in the passenger compartment to

asphyxia, the programmable heating

electronic circuits.

reach a pre-defined, non-modifiable temperature

must not be used, even for short periods, in a

The additional heating is supplied by the

(approx. 21°C) before you enter the vehicle, on

closed environment such as a garage or

vehicle's fuel tank. Make sure that the low fuel

the days and at the times of your choice.

workshop which is not equipped with an

warning lamp is not on.

This function is available when the vehicle is

exhaust gas extraction system.

connected or not connected.

To avoid the risks of poisoning or

Do not park the vehicle on a flammable

suffocation, the additional heating must

surface (dry grass, dead leaves, paper, etc.)

Programming

not be used, even for short periods, in a

- Risk of fire!

closed environment such as a garage or

With Bluetooth^® audio system

workshop which is not equipped with an

Temperature pre-conditioning is not available

Glazed surfaces such as the rear screen

exhaust gas extraction system.

with the Bluetooth^® audio system.

or windscreen can become very hot in

With the MyCitroën Play or MyCitroën

places.

Do not park the vehicle on a flammable

Drive system

Never put objects on these surfaces; never

surface (for example: dry grass, fallen

touch these surfaces - Risk of burns!

Programming can be carried out from a

leaves, paper, etc.) - risk of fire!

smartphone using the MyCitroën App

application.

Have the additional heating checked at

Independent additional

For more information on Remote functions,

least once a year, at the beginning of

refer to the corresponding section.

heating

winter.

With MyCitroën Drive system

For maintenance and repairs, you must only

Depending on the country of sale, this is an

contact a CITROËN dealer or a qualified

In the Applications menu:

additional and independent system which heats

workshop.

the hot water circuit of the Diesel engine to

Press "Car Apps" to display the applications

improve comfort and to raise the temperature

home page.

of the cold engine. It improves demisting and

Select Temperature conditioning.

defrosting performance. With the engine idling

or the vehicle stationary, it is normal to notice a

► Press + to add a programme.

CarManuals2.co

Ease of use and comfort

► Select the time of entry into the vehicle and

Courtesy lamp(s)

the desired days. Press OK.

Front: comes on when one of the front or

► Press ON to activate this programme.

rear doors is opened (sliding side door

The temperature pre-conditioning sequence

and depending on equipment, left-hand

begins approximately 45 minutes before the

side-hinged door or tailgate).

programmed time when the vehicle is connected

Rear or row 2 and row 3: comes on when one of

(20 minutes when it is not connected) and is

the rear doors is opened (sliding side door and

maintained for 10 minutes after.

depending on equipment, left-hand side-hinged

You can set multiple programmes.

door or tailgate).

Each one is saved in the system.

Always lit, ignition on.

To optimise the driving range, we recommend

starting a programme while the vehicle is

Always off.

connected.

The fan noise that occurs during

Front

Rear

temperature pre-conditioning is perfectly

normal.

Operating conditions

- The function is only activated when the

ignition is switched off and the vehicle

locked.

- When the vehicle is not connected, the

function is only activated if the battery charge

level is greater than 30%.

- When the vehicle is not connected and a

recurring programme is active (e.g. from Monday

to Friday), if two temperature pre-conditioning

sequences are run without the vehicle being

used, the programme will be deactivated.

CarManuals2.co

Ease of use and comfort

Individual reading lamp

If fitted to the vehicle, these are switched

on and off by means of a manual switch.

Automatic switching on/off

With the ignition on, operate the corresponding

switch.

The front courtesy lamp comes on when the key

is removed from the ignition switch.

Take care not to put anything in contact

All courtesy lamps come on when the vehicle is

with the courtesy lamp.

unlocked, when one of the corresponding doors

is opened and when locating the vehicle using

the remote control.

They fade to off after the ignition is switched on

and when the vehicle is locked.

Take care not to allow objects to come

into contact with the courtesy lamp.

CarManuals2.co

Lighting and visibility

► Pull the lighting control stalk to switch

Lighting control stalk

between dipped and main beam headlamps.

In lamps off and sidelamps modes, pull the

Main lighting

lighting control stalk to switch the main beam

headlamps on directly ("headlamp flash").

► Rotate the ring forwards/backwards to turn

Operation of the selected lighting is

it on/off.

confirmed by the illumination of the

When the lighting is switched off automatically

corresponding indicator lamp.

(with AUTO model), the foglamp and the dipped

beam headlamps will remain on.

Without AUTO lighting

Front foglamps/Rear foglamps

They operate with the sidelamps, dipped

Lamps off (ignition off)/

or main beam headlamps on.

Daytime running lamps (engine running)

Automatic illumination of lamps/daytime

running lamps

Sidelamps only

With AUTO lighting

Dipped or main beam headlamps

► Rotate the ring forwards:

• once to switch on the front foglamps,

Headlamp dipping

• a second time to switch on the rear

foglamps.

► Turn in the opposite direction to switch off.

If the lighting is switched off automatically (with

AUTO model) or the dipped beam headlamps

Foglamps

are switched off manually, the foglamps and

sidelamps remain on.

Rear foglamp

► Rotate the ring backwards to switch the

It only works if the sidelamps are on.

foglamps off; the sidelamps will then switch off.

CarManuals2.co

Lighting and visibility

Switching on the foglamps is prohibited

after the lamps have been on for a few

Three flashes

in clear weather or in rain, both day and

minutes.

► Press briefly upwards or downwards, without

night. In these situations, the power of their

going beyond the point of resistance; the

beams may dazzle other drivers. They must

Travelling abroad

direction indicators will flash 3 times.

only be used in fog or falling snow (rules may

If planning to use your vehicle in a

vary depending on country).

country that drives on the other side of the

Daytime running lamps/

Do not forget to switch off the foglamps when

road, the dipped beam headlamps must be

Sidelamps

they are no longer necessary.

adjusted to avoid dazzling oncoming drivers.

Contact a CITROËN dealer or a qualified

Switching on the lamps after

workshop.

switching off the ignition

To reactivate the lighting control, rotate the

Direction indicators

ring to the "0" position - lamps off, then to the

desired position.

If the driver's door is opened, a temporary

audible signal warns the driver that the lamps

are on.

They will go off automatically after a period

of time that depends on the level of charge in

the battery (entering energy economy mode).

If the vehicle is so equipped, they come on

automatically when the engine is started, when

Switching off of the lighting when the

the lighting control stalk is in position "0" or

ignition is switched off

► Left or right: lower or raise the lighting control

"AUTO".

When the ignition is switched off, all of the

stalk, beyond the point of resistance.

lamps turn off immediately, except for the

Automatic headlamp

If you keep the direction indicators on for

dipped beam headlamps if automatic guide-

more than 20 seconds, the volume of the

illumination

me-home lighting is activated.

audible signal will increase if the speed is

When a low level of ambient light is detected

above 50 mph (80 km/h).

by a sunshine sensor, the number plate

In some weather conditions (e.g. low

lamps, sidelamps and dipped beam headlamps

temperature or humidity), misting on the

are switched on automatically, without any action

internal surface of the glass of the headlamps

on the part of the driver. They can also come

and rear lamps is normal, and will disappear

CarManuals2.co

Lighting and visibility

on if rain is detected, at the same time as the

Guide-me-home and

With audio system or touch screen

automatic rain sensitive wipers.

The activation, deactivation and

welcome lighting

As soon as the brightness returns to a sufficient

duration of guide-me-home lighting

level or after the windscreen wipers are switched

are set in the vehicle configuration menu.

Guide-me-home lighting

off, the lamps are switched off automatically.

Manual

Exterior welcome lighting

Malfunction

The remote operation of the lighting makes your

In the event of a malfunction of the rain/sunshine

approach to the vehicle easier in poor light. It

sensor, the vehicle’s lamps come on and this

is activated when the lighting control is in the

warning lamp is displayed on the instrument

"AUTO" position and the level of light detected

panel, accompanied by an audible signal and/or

by the sunshine sensor is low.

the display of a message.

Have it checked by a CITROËN dealer or a

Switching on

qualified workshop.

Press this button on the remote control or

► With the ignition off, pull the lighting control

Do not cover the rain/sunshine sensor

on one of the front door handles with the

stalk toward you ("headlamp flash") to activate/

located at the top centre of the

"Keyless Entry and Start" system.

deactivate the function.

windscreen behind the interior rear view

The dipped beam headlamps and sidelamps

Manual guide-me-home lighting goes off

mirror; the associated functions would no

come on; your vehicle is also unlocked.

automatically after a period of time.

longer be controlled.

Switching off

Automatic

The exterior welcome lighting switches off

In fog or snow, the rain/sunshine sensor

With the "Automatic illumination of lamps"

automatically after a set time, when the ignition

may detect sufficient light. For this

function activated (lighting control stalk in the

is switched on or on locking the vehicle.

reason, the lighting will not come on

"AUTO" position) and when the light is poor, the

automatically.

dipped beam headlamps come on automatically

Programming

when the ignition is switched off.

With audio system or touch screen

The inner surface of the windscreen may

With the ring in the "AUTO" position and when

become misted up and affect the proper

the light is poor, the dipped beam headlamps

The activation, deactivation and

operation of the rain/sunshine sensor.

come on automatically when the ignition is

duration of the welcome lighting

In humid and cold weather, demist the

switched off.

can be set via the vehicle configuration menu.

windscreen regularly.

CarManuals2.co

Lighting and visibility

Do not allow snow to accumulate on the

This system is a driving aid.

Automatic lighting

bonnet or roof of the vehicle as this could

The driver remains responsible for

systems - General

obstruct the camera.

the vehicle's lighting, its correct use in the

prevailing light, visibility and traffic conditions,

recommendations

and for compliance with driving and vehicle

The automatic lighting systems use a detection

Automatic headlamp

regulations.

camera, located at the top of the windscreen.

dipping

Operating limits

The system becomes operational when

The system may be disrupted or not work

the vehicle exceeds 16 mph (25 km/h).

For more information, refer to the

correctly:

When the speed falls below 9 mph (15 km/h),

General recommendations for

- When visibility conditions are poor

the function is no longer operational.

automatic lighting systems.

(e.g. snowfall, heavy rain).

- If the windscreen is dirty, misted-up or

With the ring of the lighting control stalk in the

Activation/Deactivation

masked (e.g. sticker) in front of the camera.

"AUTO" position and the function activated on

- If the vehicle is facing highly reflective signs

the touch screen, this system automatically

With audio system

or safety barrier reflectors.

switches between dipped and main beam

The system is not able to detect:

headlamps, according to lighting and traffic

- Road users that do not have their own

conditions, using a camera located at the top of

lighting, such as pedestrians.

the windscreen.

- Vehicles with hidden lighting (e.g. travelling

behind a safety barrier on the motorway).

- Vehicles at the top or bottom of a steep

slope, on winding roads, on crossroads.

► To activate or deactivate the system, press

Maintenance

this button.

Clean the windscreen regularly,

The indicator lamp in the button is on when the

particularly the area in front of the camera.

function is activated.

The internal surface of the windscreen can

also become misted around the camera.

With touch screen

In humid and cold weather, demist the

The settings are adjusted via the vehicle

windscreen regularly.

configuration menu.

CarManuals2.co

Lighting and visibility

► Then put the lighting control stalk ring in the

When the system detects thick fog, it

Headlamp beam height

"AUTO" or "Dipped/main beam position".

temporarily deactivates the function.

The system is not able to detect:

adjustment

Pause

- Road users that do not have their own

If the situation requires a change of headlamp

lighting, such as pedestrians.

beam, the driver can take over at any time.

- Vehicles whose lighting is obscured (for

► A "headlamp flash" pauses the

example, vehicles driving behind a safety

function and the lighting system switches

barrier on a motorway).

to "automatic illumination of lamps" mode:

- Vehicles at the top or bottom of a steep

- If the "AUTO" and "Dipped beam" indicator

slope, on winding roads, on crossroads.

lamps were on, the system changes to main

beam.

Clean the windscreen regularly,

To avoid inconvenience to other road users,

- If the "AUTO" and "Main beam"

particularly the area in front of the

the height of the halogen headlamps must be

indicator lamps were on, the system changes to

camera.

adjusted according to the load in the vehicle.

dipped beam.

The internal surface of the windscreen can

► To reactivate the function, once again switch

also become misted around the camera.

the headlamps manually between dipped and

In humid and cold weather, demist the

main beam.

windscreen regularly.

Empty (initial setting)

Do not allow snow to accumulate on the

Flashing the headlamps does not

Partial load

bonnet or roof of the vehicle as this could

deactivate the system.

Medium load

obstruct the detection camera.

The state of the system is stored when the

Maximum authorised load

ignition is switched off.

4 5 6

Not used

The system may be disrupted or not work

correctly:

- When visibility conditions are poor

1 or 2 people in the front seats (initial

(snowfall, heavy rain, etc.).

setting)

- If the windscreen in front of the camera is

5 people

dirty, misted or obscured (for example, by a

6 to 9 people

sticker).

Driver + maximum authorised load

- If the vehicle is facing highly reflective

4 5 6

Not used

signs.

CarManuals2.co

Lighting and visibility

Interior ambient lighting

Do not operate the wipers on a dry

Windscreen wipers

windscreen. In extremely hot or cold

► To select the wiping speed: raise or lower the

weather, check that the wiper blades are not

stalk to the desired position.

stuck to the windscreen before operating the

Fast wiping (heavy rain)

wipers.

The dimmed passenger compartment lighting

Normal wiping (moderate rain)

improves visibility inside the vehicle when the

After using an automatic car wash, you

light is poor.

may temporarily notice abnormal noises

Intermittent wiping (proportional to the

and poorer wiping performance. You do not

vehicle’s speed)

Switching on

need to replace the wiper blades.

Switching off

At night, the front roof lighting and panoramic

roof lighting (if fitted to your vehicle) comes on

Single wipe (press down and release).

Without AUTO wiping

automatically when the sidelamps are switched

on.

The ambient lighting switches off automatically

Automatic wiping

when the sidelamps are switched off.

Refer to the corresponding section.

Programming

After the ignition has been switched off,

With audio system or touch screen

the wipers may move slightly at the foot

The activation, deactivation and

of the windscreen.

the choice of brightness of the

ambience lighting can be set via the vehicle

If the ignition has been switched off with

configuration menu.

With AUTO wiping

the windscreen wipers active, you must

operate the control stalk again to reactivate

Wiper control stalk

wiping when the ignition is switched on again

(unless the ignition was off for less than

Before operating the wipers in wintry

a minute).

conditions, clear any snow, ice or frost

from the windscreen and around the wiper

Windscreen wash

arms and blades.

► Pull the wiper control stalk towards you and

hold.

CarManuals2.co

Lighting and visibility

The screenwash then the windscreen wipers

Automatic windscreen

Switching off

operate for a pre-determined time.

► Give the control stalk another brief push

wipers

downwards or set the control stalk to another

With automatic air conditioning, any

In AUTO mode, the windscreen wipers operate

position (Int, 1 or 2).

action on the screenwash control results

automatically and adapt to the intensity of the

This indicator lamp goes off on the

in temporary closure of the air intake to

rainfall.

instrument panel, accompanied by a

protect the passenger compartment from any

Detection is via a rain/brightness sensor, located

message.

odour.

at the top centre of the windscreen behind the

rear view mirror.

If the ignition has been off for more than

To avoid damaging the wiper blades, do

one minute, the automatic wipers must

Do not cover the rain/sunshine sensor.

not operate the screenwash if the

be reactivated by pushing the control stalk

When using an automatic car wash,

screenwash reservoir is empty.

downwards.

switch off the automatic wipers and the

Only operate the screenwash if there is no

ignition.

risk of the fluid freezing on the windscreen

In winter, wait until the windscreen is

Malfunction

and hindering visibility. During the winter

completely clear of ice before activating the

If a fault occurs with the automatic wipers, the

period, use "very cold climate" rated products.

automatic wipers.

wipers operate in intermittent mode.

Never top up with water.

Have it checked by a CITROËN dealer or a

qualified workshop.

Switching on

Low screenwash fluid level

When the low level of the reservoir is

Rear wiper

reached, this warning lamp lights up on

the instrument panel, accompanied by an

audible signal and a message.

It comes on when the ignition is switched on,

or every time the stalk is operated, until the

► Give a short downwards push to the control

reservoir is refilled.

stalk.

Off.

Refill the screenwash reservoir (or have it

A wiping cycle confirms that the instruction has

refilled) the next time you stop.

been accepted.

Intermittent wipe.

This indicator lamp lights up on the

instrument panel, accompanied by a

Wash-wipe (set duration).

message.

CarManuals2.co

Lighting and visibility

Reverse gear

useful, in wintry weather (ice, snow), to release

Changing a wiper blade

When reverse gear is engaged, if the windscreen

the wiper blades from the windscreen.

wipers are operating, the rear wiper will come

Removing/Refitting at the front

To maintain the effectiveness of the flat

into operation automatically (activated by

wiper blades, it is advisable to:

default).

- handle them with care.

- clean them regularly using soapy water.

Activation/Deactivation

- avoid using them to hold cardboard on the

With audio system or touch screen

windscreen.

The system's settings are adjusted

- replace them at the first signs of wear.

via the vehicle configuration menu.

Before removing a windscreen wiper blade

This function is activated by default.

In the event of accumulation of snow or

► Carry out these wiper blade replacement

hard frost or if a bicycle carrier is fitted to

operations from the driver's side.

the tailgate, deactivate the automatic rear

► Starting with the wiper blade farthest from

wiper via the vehicle configuration menu.

you, hold each arm by the rigid section and raise

it as far as possible.

Rear screenwash

Do not touch the wiper blades - risk of

► Turn the ring as far as it will go and hold it in

irreparable deformation.

position.

Do not release them while moving them. Risk

The screenwash and the wiper operate for as

Operating the wiper control stalk immediately

of damaging the windscreen!

long as the ring remains turned.

after switching off the ignition will place the wiper

blades in a vertical position.

► Clean the windscreen using screenwash

A final wiping cycle is performed when screen

► Proceed with the desired operation or the

fluid.

washing ends.

replacement of the wiper blades.

Do not apply "Rain X" type water-

Special position of the

After refitting a windscreen wiper blade

repellent products.

windscreen wipers

► To return the wiper blades to their initial

► Unclip the worn wiper blade closest to you

This maintenance position is used while cleaning

position after the operation, switch on the ignition

and remove it.

or replacing the wiper blades. It can also be

and operate the wiper control stalk.

CarManuals2.co

Safety

CITROËN dealers or qualified workshops,

General safety

Hazard warning lamps

equipped with the special tools required (risk

recommendations

of malfunctions of the vehicle's electronic

systems that could cause breakdowns or

Do not remove the labels attached in

serious accidents). The Manufacturer cannot

different places on your vehicle. They

be held responsible if this advice is not

include safety warnings as well as

followed.

identification information for the vehicle.

- Any modification or adaptation not intended

or authorised by CITROËN or carried out

For all work on your vehicle, use a

without meeting the technical requirements

► Pressing this red button causes all the

qualified workshop that has the technical

defined by the Manufacturer will result in the

direction indicators to flash.

information, skills and equipment required, all

suspension of the commercial warranty.

They can work with the ignition switched off.

of which a CITROËN dealer is able to

provide.

Automatic operation of

Installation of accessory radio

communication transmitters

hazard warning lamps

Depending on country regulations,

Before installing a radio communication

When braking in an emergency, depending on

certain safety equipment may be

transmitter with an external aerial, you must

the rate of deceleration, the hazard warning

mandatory: high visibility safety vests,

without fail contact a CITROËN dealer for

lamps come on automatically. They switch off

warning triangles, breathalysers, spare bulbs,

the specification of transmitters which can

automatically when you next accelerate.

spare fuses, fire extinguisher, first aid kit, mud

be fitted (frequency, maximum power, aerial

They can be switched off by pressing the button.

flaps at the rear of the vehicle, etc.

position, specific installation requirements),

in line with the Vehicle Electromagnetic

Installing electrical accessories:

Compatibility Directive (2004/104/EC).

- The fitting of electrical equipment or

accessories not approved by CITROËN may

Declarations of conformity for radio

cause excessive current consumption and

equipment

faults and failures with the electrical system

The relevant certificates are available on the

of your vehicle. Contact a CITROËN dealer

brand website:

for information on the range of approved

http://service.citroen.com/ACddb/

accessories.

- As a safety measure, access to the

diagnostic socket, used for the vehicle's

electronic systems, is reserved strictly for

CarManuals2.co

Safety

The lit indicator lamp and a voice message

- The indicator lamp is fixed red: system

Emergency or assistance

confirm that the call has been made to the

malfunction. The emergency and assistance call

call

emergency services*.

services may not work.

The eCall (SOS) system immediately locates

- If the indicator lamp does not come on when

your vehicle and puts you in contact with the

the ignition is switched on, this also means that

appropriate emergency services**.

there is a system malfunction.

► Pressing again immediately cancels the

If the problem persists, contact a qualified

request.

workshop as soon as possible.

The indicator lamp flashes while the vehicle

A system fault does not prevent the

data is being sent, and then remains lit when

vehicle from being driven.

communication is established.

If an impact is detected by the airbag

Data processing

1. Localised Emergency Call

control unit, an emergency call is made

All processing of personal information

2. Localised Assistance Call

automatically, irrespective of the deployment

by the "Localised Emergency Call" system

of any airbags.

(PE112) complies with the framework for

eCall (SOS)

protection of personal information established

Your vehicle may be fitted with the eCall (SOS)

This system is a public service and is

by Regulation 2016/679 (GDPR) and

system either as standard or as an option.

free of charge.

Directive 2002/58/EC of the European

The eCall (SOS) system provides direct access

Parliament and the Council, and in particular,

to the emergency services and is built directly

seeks to protect the vital interests of the

Operation of the system

into the vehicle.

data subject, in accordance with Article 6.1,

According to the country of sale, the eCall (SOS)

- Upon switching on the ignition, the indicator

paragraph d) of Regulation 2016/679.

system corresponds to the systems PE112,

lamp lights up red, then green, and then goes

Personal information processing is strictly

ERAGLONASS, 999, etc.

out: the system is operating correctly.

limited to the management of the "Localised

The eCall (SOS) system is activated by default.

- The indicator lamp flashes red: replace the

Emergency Call" system used with the “112”

► In an emergency, press button 1 for more

back-up battery.

European single emergency call number.

than 2 seconds.

The "Localised Emergency Call" system is

able to collect and process only the following

* In accordance with the general conditions of use of the service, available from dealers and subject to technological and technical limitations.

** Depending on the geographic coverage of the "eCall (SOS)" and "ASSISTANCE" systems.

The list of countries covered and the telematic services provided is available from dealers or on the website for your country.

CarManuals2.co

Safety

data relating to the vehicle: chassis number,

Access to data

By default, depending on equipment,

type (passenger vehicle or light commercial

You have the right to access the data

deactivate/reactivate geolocation by

vehicle), fuel type or power source, most

and, if necessary, submit a request to

simultaneously pressing the 2 buttons, then

recent three locations and direction of travel,

rectify, erase or restrict the processing of

press the "ASSISTANCE" button to confirm.

and a timestamped log file recording the

any personal information not processed in

automatic activation of the system.

accordance with the provisions of Regulation

If you purchased your vehicle outside the

The recipients of the processed data are the

2016/679 (GDPR). Third parties to which data

CITROËN dealer network, we invite you

emergency call handling centres designated

has been communicated shall be notified of

to have a dealer check the configuration of

by the relevant national authorities in the

any rectification, erasure or restriction carried

these services and, if desired, modify them to

territory in which they are located, enabling

out in accordance with the aforementioned

suit your wishes. In a multilingual country,

priority reception and handling of calls to the

Directive, unless doing so would be

configuration is possible in the official national

“112” emergency number.

impossible or require a disproportionate effort.

language of your choice.

You also have the right to lodge a complaint

Data storage

with the relevant data protection authority.

For technical reasons, in particular to

Data contained in the system’s memory

improve the quality of telematic services

is not accessible from outside the system until

for customers, the Manufacturer reserves the

Localised Assistance Call

a call is made. The system is not traceable

right to carry out updates to the vehicle's

► If the vehicle breaks down, press button 2

and is not continuously monitored in its

on-board telematic system at any time.

for more than 2 seconds to request assistance

normal operating mode.

(confirmed by a voice message*).

The data in the system's internal memory is

► Pressing again immediately cancels the

If you benefit from the Citroën Connect

automatically and continuously erased. Only

request.

Box offer with the SOS and Assistance

the vehicle’s three most recent locations are

Pack included, there are additional services

stored.

Privacy mode allows you to manage the

available to you in your personal space, via

When an emergency call is triggered, the data

level of sharing (data and/or location)

the website for your country.

log is stored for no more than 13 hours.

between your vehicle and CITROËN.

For information about the SOS and

It can be configured in the Settings touch

Assistance Pack, please refer to the general

screen menu.

conditions for these services.

* Depending on the geographic coverage of "Localised Emergency Call", "Localised Assistance Call" and the official national language chosen by the

owner of the vehicle.

The list of countries covered and the telematic services provided is available from dealers or on the website for your country.

CarManuals2.co

Safety

- Anti-slip regulation (ASR).

accompanied by a message and an audible

Horn

- Dynamic stability control (DSC).

signal, indicates an EBFD malfunction.

- Intelligent traction control.

You must stop the vehicle.

- Trailer stability assist (TSA).

Stop as soon as it is safe to do so and switch off

the ignition.

Anti-lock braking system

Contact a CITROËN dealer or a qualified

workshop.

(ABS)/Electronic brake force

distribution (EBFD)

When changing wheels (tyres and rims),

ensure that these are approved for your

These systems enhance the vehicle’s stability

vehicle.

and handling during braking, and enable greater

control while cornering, particularly on poor or

slippery road surfaces.

After an impact

► Press the central part of the steering wheel.

ABS prevents wheel locking in the event of

Have it checked by a CITROËN dealer or

emergency braking.

a qualified workshop.

Electronic brake force distribution (EBFD)

Pedestrian horn (Electric)

manages overall braking pressure on each

Emergency braking

This system alerts pedestrians that the vehicle is

individual wheel.

approaching.

► When braking in an emergency, depress

assistance (EBA)

The pedestrian horn operates once the vehicle

the pedal very firmly and maintain this

In an emergency, this system enables you

is moving and at speeds of up to 19 mph

pressure.

to reach the optimum braking pressure more

(30 km/h), in forward or reverse gear.

quickly and therefore reduce the stopping

Normal operation of the ABS may make

This function cannot be deactivated.

distance.

itself felt by slight vibrations of the brake

It is triggered in relation to the speed at which

pedal.

the brake pedal is pressed. This is felt by a

Electronic stability control

The fixed illumination of this warning lamp

reduction in the resistance of the pedal and an

(ESC)

signals that there is a fault with the ABS.

increase in braking efficiency.

The electronic stability control programme

The vehicle retains conventional braking. Drive

includes the following systems:

carefully at a moderate speed.

- Anti-lock braking system (ABS) and Electronic

Have it checked by a CITROËN dealer or a

brake force distribution (EBFD).

qualified workshop.

– Emergency braking assistance (EBA).

This warning lamp, when lit together with

the STOP and ABS warning lamps,

100

CarManuals2.co

Safety

Anti-slip regulation (ASR)/

Deactivating using the button or Advanced

Below 31 mph (50 km/h), these systems must be

Grip Control

reactivated manually.

Dynamic stability control

Press this button or turn the thumbwheel

(DSC)

to this position.

Malfunction

Anti-slip regulation (or traction control) optimises

The indicator lamp in the button or thumbwheel

In the event of a malfunction, this warning

traction by using engine braking and by applying

comes on: the DSC/ASR systems no longer

lamp lights up on the instrument panel,

the brakes on the driving wheels to avoid one

have an effect on engine operation.

accompanied by the display of a message and

or more wheels spinning. It also enhances the

Deactivating using the touch screen

an audible signal.

vehicle's directional stability.

In the "Driving/Vehicle" menu, deactivate

Have it checked by a CITROËN dealer or a

If there is a difference between the vehicle’s

the ASR system.

qualified workshop.

trajectory and the path desired by the driver, the

A confirmation message is displayed and

ASR/DSC

dynamic stability control system automatically

this warning lamp on the instrument panel

These systems enhance safety during

uses engine braking and the brakes on one or

comes on.

normal driving, but should not encourage

more wheels to return the vehicle to the desired

The ASR system no longer acts on the operation

the driver to take extra risks or drive at high

path, within the limits of the laws of physics.

of the engine.

speed.

These systems are activated automatically every

Reactivating using the button or Advanced

It is in conditions of reduced grip (rain, snow,

time the vehicle is started.

Grip Control

ice) that the risk of loss of grip increases. It

These systems are activated in the event

Press this button.

is therefore important for your safety to keep

of a problem with grip or trajectory

these systems activated in all conditions, and

(confirmed by this warning lamp flashing on the

particularly in difficult conditions.

instrument panel).

Turn the thumbwheel to this position.

Correct operation of these systems depends

on compliance with the manufacturer's

Deactivation/Reactivation

The indicator lamp in the button or thumbwheel

recommendations relating to the wheels

In exceptional conditions (moving a vehicle that

goes off.

(tyres and rims), braking and electronic

is bogged down in mud, stuck in snow, on loose

Reactivating using the touch screen

components, as well as the assembly and

soil, etc.), it may prove useful to deactivate the

In the "Driving/Vehicle" menu, activate

repair procedures provided by CITROËN

DSC/ASR systems, so that the wheels can move

the ASR system.

dealers.

freely and regain grip.

A confirmation message is displayed and

In order to ensure that these systems remain

However, it is recommended that the systems be

this warning lamp on the instrument panel

effective in wintry conditions, the use of snow

reactivated as soon as possible.

goes off.

or all-season tyres is recommended. All four

These systems are reactivated automatically

Only the ASR system can be deactivated

wheels must be fitted with tyres approved for

every time the ignition is switched off, or at

from the touch screen.

your vehicle.

speeds over 31 mph (50 km/h).

101

CarManuals2.co

Safety

All tyre specifications are listed on the

The vehicle speed must be between 37 and 99

tyres, faulty braking system) or driving at

tyre/paint label. For more information

mph (60 and 160 km/h).

excessive speed.

on Identification markings, refer to the

If the system detects that the trailer is

In certain cases, the system may not detect

corresponding section.

snaking, it applies the brakes to stabilise

trailer snaking, particularly with a light trailer.

the trailer and reduces engine power, if

When driving on slippery or poor surfaces, the

necessary, to slow the vehicle (indicated by the

system may not be able to prevent sudden

Intelligent traction control

flashing of this warning lamp on the instrument

trailer snaking.

(Snow motion)

panel and the brake lamps coming on).

(Depending on version)

For more information on weights and towed

The intelligent traction control system helps

loads, refer to the Engine technical data

Advanced Grip Control

improve grip when driving on snow.

and towed loads section or your vehicle’s

This system detects situations of poor surface

registration certificate.

grip that could make it difficult to move off

To ensure safe driving with a Towing device,

refer to the corresponding section.

(Depending on version)

or make progress on deep fresh snow or

A special, patented traction control system,

compacted snow.

Malfunction

which improves driveability on snow, mud and

In these situations, the system limits the amount

If a fault occurs, this warning lamp lights

sand.

of wheel spin to provide the best traction and

up on the instrument panel, accompanied

This system, optimised for operation in a range

trajectory control for the vehicle.

by a message and an audible signal.

of conditions, enables you to manoeuvre in most

The use of winter tyres is strongly

slippery conditions (encountered during normal

To continue towing a trailer, reduce speed and

recommended on slippery surfaces.

passenger car use).

drive carefully!

Have it checked by a CITROËN dealer or a

When combined with all-season Peak Mountain

qualified workshop.

Snow Flake tyres, this system offers a

Trailer stability assist (TSA)

compromise between safety, grip and driveability.

When towing, this system reduces the risk of the

The trailer stability control system

The accelerator pedal should be pressed

vehicle or trailer snaking.

provides an extra safety feature under

sufficiently to allow the system to harness the

normal driving conditions, when following the

power of the engine. Operation at high engine

Operation

recommendations for use of trailers and

speeds is completely normal.

The system is activated automatically when the

current legislation in force in your country. It

A five-position selector knob allows you to

ignition is switched on.

must not encourage the driver to take extra

choose the setting best suited to the driving

The electronic stability control system (ESC)

risks, such as using a trailer in unsuitable

conditions encountered.

must not have any faults.

conditions of operation (e.g. excessive load,

exceeded nose weight, worn or under-inflated

102

CarManuals2.co

Safety

An indicator lamp associated with each mode

All terrain (mud, damp grass, etc.)

or of the brakes in the event of a change of

comes on, accompanied by the display of a

This mode, when moving off, allows

trajectory.

message to confirm your choice.

considerable spin on the wheel with the

These systems are reactivated automatically

least grip to optimise clearing of the mud and to

from 31 mph (50 km/h) and whenever the

Operating modes

ignition is switched on.

regain grip. At the same time, the wheel with the

most grip is controlled in such a way as to

transmit as much torque as possible.

Recommendations

When moving, the system optimises wheel spin

The vehicle is designed principally

to respond to the driver's requirements as fully

to drive on tarmac roads, but it may

as possible.

occassionally drive on other less passable

(mode active up to 31 mph (50 km/h))

terrain.

However, it does not permit off-road driving:

Sand

- Driving on terrain that can damage the

This mode allows little spin on the two

underbody or tear off elements (e.g. fuel

driving wheels at the same time to allow

pipe, fuel cooler) by obstacles or stones in

the vehicle to move forward and limit the risks of

particular.

getting stuck in the sand.

- Driving on terrain with steep gradients and

(mode active up to 75 mph (120 km/h))

poor grip.

Standard (ESC)

- Crossing a waterway.

Do not use the other modes on sand as

This mode is calibrated for a low level of

the vehicle may become stuck.

wheel spin, based on the different levels

of grip normally encountered on the road.

Seat belts

Deactivation

Whenever the ignition is switched off, the

Inertia reel

You can deactivate the ASR and DSC

system automatically resets to this mode.

The seat belts are equipped with an inertia

systems by turning the knob to the "OFF"

reel which allows the strap length to adjust

position.

automatically to the shape of the user. The seat

Snow

The ASR and DSC systems will no

belt returns to its storage automatically when it

This mode adapts its strategy to the

longer act on the operation of the engine

is not used.

conditions of grip encountered for each of

The inertia reels are fitted with a device which

the two front wheels on moving off.

automatically locks the strap in the event of a

(mode active up to 50 mph (80 km/h))

collision, emergency braking or if the vehicle rolls

103

CarManuals2.co

Safety

over. It can be released by pulling the strap firmly

Front seat belts

The force limiter reduces the pressure of the

and then releasing it so that it reels in slightly.

seat belt on the chest of the occupant, thus

Pyrotechnic pretensioning

improving their protection.

This system improves safety in the event of a

frontal or side impact.

Fastening

Depending on the severity of the impact, the

pyrotechnic pretensioning system instantly

tightens the seat belts against the body of the

occupants.

The pyrotechnic pretensioning seat belts are

enabled when the ignition is on.

Force limiting system

This system reduces the pressure of the seat

belt on the chest of the occupant, thus improving

their protection.

In the event of an impact

Depending on the nature and

► Pull the strap, then insert the tongue into the

seriousness of the impacts, the pyrotechnic

buckle.

device may trigger before and independently

► Check that the seat belt is fastened correctly

of airbag deployment. Deployment of the

by pulling on the strap.

pretensioners is accompanied by a slight

The front seat belts are fitted with a pyrotechnic

pretensioning system and a force limiting

Unfastening

discharge of harmless smoke and a noise,

due to the activation of the pyrotechnic

system.

► Press the red button on the buckle.

cartridge incorporated in the system.

This system improves safety in the front seats in

In all cases, the airbag warning lamp comes

the event of a front or side impact.

on.

Depending on the severity of the impact, the

Following an impact, have the seat belt

pyrotechnic pretensioning system instantly

system checked, and if necessary replaced,

tightens the seat belts against the body of the

by a CITROËN dealer or a qualified

occupants.

workshop.

The pyrotechnic pretensioning seat belts are

enabled when the ignition is on.

104

CarManuals2.co

Citroen Jumpy Dispatch (2023 year). Manual in english - page 3
