06

223

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Access to the "TELEPHONE" menu

"Telephone"

"Dial"
"Directory of contacts"
"Contacts management"
"Phone functions"
"Bluetooth functions"
"Hang up"

Go from the list to the menu (left/right).

or

List of recent calls sent and

received with the telephone

connected to the system.

Press this button.

To make a call, select a number in the list and confirm "OK"

to start the call.

Connecting a different telephone deletes the list of
recent calls.

No telephone connected.

Telephone connected.

Incoming call.

Outgoing call.

Synchronisation of
contacts in progress.

Telephone call in
progress.

In the top bar of the permanent
display

USING THE TELEPHONE

06

224

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

USING THE TELEPHONE

Pairing a Bluetooth

®

 telephone

First connection

For reasons of safety and because they require prolonged attention
on the part of the driver, the operations for pairing the Bluetooth
mobile telephone to the hands-free system of the audio unit must be

carried out with the vehicle stationary.

In the Bluetooth menu of your telephone, select the
name "CITROËN" from the list of devices detected.

Press this button.

Select "Bluetooth functions" and

confirm.

Select "Peripherals search" and

confirm.
The list of peripheral devices detected
is displayed. Wait until the "Connect"
button is available.

You can check the compatibility of your telephone at

www.citroen.co.uk (services).

Activate the telephone's Bluetooth function
and ensure that it is "visible to all" (telephone

configuration).

Quick procedure from the telephone

Enter a minimum 4 figure code in the telephone and

confirm.

Enter the same code in the system,
select "OK

" and confirm.

Procedure from the system

06

225

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

USING THE TELEPHONE

Select "Connect

" and confirm.

The system offers to connect the
telephone:
-

in "Hands-free mode" (telephone
only),

-

in "Audio" mode (streaming: playing

music files on the telephone),

-

or "All" (for selection of both
modes).

Select "OK

" and confirm.

Then accept automatic connection on the telephone to allow the

telephone to reconnect automatically every time the vehicle is
started.

The ability of the system to connect in only one mode depends on

the telephone. The two modes may both connect by default.

The "Hands-free mode" should be used in preference if
"Streaming" is not desired.

The services available depend on the network, the SIM card and the compatibility of the Bluetooth telephone used. Check the telephone

manual and with your network provider for details of the services available to you.

Depending on the type of telephone, the system will ask you to

accept or not the transfer of your contacts.

On return to the vehicle,the last telephone connected

automatically reconnects, within around 30 seconds after

switching on the ignition (Bluetooth activated and visible).
To modify the automatic connection mode, remove the pairing

and pair the telephone again with the desired mode.

Enter a minimum 4 figure code in the telephone

and confirm.

Enter the same code in the system,
select "OK

" and confirm.

Select the name of the desired
peripheral from the list of devices

detected then confirm.

06

226

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

USING THE TELEPHONE

Directory configuration / Synchronisation with the telephone

Press PHONE then select "Contacts
management

" and confirm.

Select "New contact

" to enter a new

contact.

Select "Sort by Name/First name" or
"Sort by First name/Name" to choose

the order in which they appear.

Select "Delete all contacts" to delete
the contacts saved in the system.

Select "Synchronization options":
-

No synchronization: only the
contacts saved in the system

(always present).

-

Display telephone contacts: only the
contacts saved in the telephone.

-

Display SIM card contacts: only the
contacts saved on the SIM card.

-

Display all phone contacts:
contacts on the SIM card and in the
telephone.

Select "Import all the entries" to import
all the contacts in the telephone and
save them in the system.
Once imported, a contact remains visible

whatever telephone is connected.

Select "Contact mem. status" to see the
number of contacts saved in the system
or imported, and the free memory.

06

227

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Editing, importing or deleting a contact

Press PHONE then select "Directory of
contacts

" and confirm.

Select "Search", then turn the knob to
choose in numerical or alphabetical order
a group of contacts from the entries made

previously, then confirm.
Go to the list of contacts, select the

desired contact then confirm.

Select "Open

" to view a contact on the

telephone or modify a contact saved in
the system.

Select "Import" to copy a contact from
the telephone to the system.

Select "Delete" to delete a contact
recorded in the system.

USING THE TELEPHONE

Select OK

 or press the back button to exit

this menu.

Once the contact has been imported, the Bluetooth symbol

disappears, replaced by the telephone symbol which shows that the

contact has been saved in the system.

It is not possible to modify or delete contacts in the telephone or the
SIM card via the Bluetooth connection.

In the "Directory of contacts" menu, the import and deletion of
contacts is done one by one.

06

228

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

USING THE TELEPHONE

Press PHONE

 twice.

Select "Dial

" then confirm.

Select "Directory of contacts" then

confirm.

Dial the telephone number using the
virtual keypad selecting each number
in turn.
Confirm "OK" to make the call.

Press TEL

 or twice on PHONE.

Calling a new number

Calling a contact

Select the desired contact and confirm.

If access was via the PHONE button,

select "Call

" and confirm.

Select the number and confirm to start

the call.

Making a call

Using the telephone is not recommended while driving. We

recommended that you park safely or make use of the steering
mounted controls.

06

229

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

USING THE TELEPHONE

Calling a recently entered number

Press TEL, select "Call list" and

confirm,

Select the desired number and confirm.

To erase the calls log, press PHONE

 twice, select "Phone

functions

" and confirm then select "Delete calls log" and confirm.

Ending a call

Press PHONE then select "OK" to end
the call.

Or make a long press on TEL at the
steering mounted controls.

Or make two short presses on TEL at

the steering mounted controls.

Or press the MODE button, as many
times as necessary, until the telephone
screen is displayed.

Press PHONE to display the calls log.

or

Press "OK

" to display the contextual

menu then select "Hang up" and

confirm.

It is always possible to start a call directly from the telephone; park

the vehicle as a safety measure.

06

230

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

USING THE TELEPHONE

Receiving a call

An incoming call is announced by a ring and a superimposed display
on the screen.

"Yes" to accept the call is selected by
default.
Press "OK" to accept the call.
Select "No

" and confirm to reject the

call.

A short press on TEL accepts an
incoming call.
A long press on TEL rejects an incoming
call.

06

231

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Options during a call*

During a call, press the MODE button
several times to select display of the
telephone screen, then press "OK" to

open the contextual menu.

Select "Private mode

" and confirm to

take the call on the handset.
Or select "Hands-free mode" and

confirm to take the call via the vehicle's

speakers.

Select "Put call on hold

" and confirm to

put the current call on hold.
Or select "Resume the call" and

confirm to resume the call on hold.

Select "DTMF ring tones" to use the
numerical keypad, so as to navigate
through the menu of an interactive vocal
server.

Select "Hang up" to end the call.

* Depending on the compatibility of the phone and your service plan.

it is possible to hold a 3-way conference

call by making 2 calls in succession*.
Select "Conference mode call" in the

contextual menu accessible using this

button.

Or make a short press on this button.

USING THE TELEPHONE

06

232

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Press PHONE

 twice.

Select "List of the paired peripherals"

and confirm.

It is possible to:
- "Connect" or "Disconnect" the

selected telephone,

-

delete the pairing of the selected
telephone.

It is also possible to select all pairings.

Managing paired telephones

Changing the ringtone

Press PHONE

 twice.

Select "Phone functions

" and confirm.

Select "Ring options

" and confirm.

You can adjust the volume and the type
of ringtone.

Select "Bluetooth functions".

Select "OK

" and confirm to save the

changes.

USING THE TELEPHONE

07

233

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

"FM / AM band"

"Change Waveband" ("AM / FM")
"Guidance options" ("TA, RDS")
"Audio settings"
"Update radio list"

Alphabetical list of stations
received.

Press 5 or 6 or use the rotary control to select the

previous or next station in the list.

Go from the list to the menu (left/right).

or

Press RADIO.

RADIO

Access to the "RADIO" menu

07

234

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

By alphabetical list
Press RADIO, select the station of your

choice and confirm.

By automatic frequency search
Press 7 or 8 for the automatic search

for a lower or higher radio frequency.

Or turn the thumb wheel at the steering

mounted controls.

By manual frequency search
Press 5 or 6 to adjust the radio
frequency step by step.

Selecting a station

The external environment (hill, building, tunnel, underground car park...) may interfere with the reception, including in RDS station tracking mode.

This phenomenon is a normal result of the way in which radio waves are transmitted and does not in any way indicate a fault with the audio system.

The quality of reception is represented by the number of

active waves in this symbol.

Press RADIO or OK to display the

contextual menu.

Changing waveband

Select "Change waveband".

Select "AM / FM

" and confirm.

RADIO

07

235

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Press the button on the numerical keypad to recall a
preset station.
Or press then turn the thumb wheel at the steering

mounted controls.

Presetting a station

After selecting a station, press one of the buttons
on the numerical keypad for 2 seconds to preset the
current station.
An audible signal confirms that the station has been

preset.

Press RADIO.

Activate / Deactivate RDS

RDS, if activated, allows you to continue listening to the same station

by automatic retuning to alternative frequencies. However, in certain

conditions, coverage of an RDS station may not be assured throughout
the entire country as radio stations do not cover 100 % of the territory.

This explains the loss of reception of the station during a journey.

Select "Guidance options" then

confirm.

Activate or deactivate "RDS" then

confirm.

RADIO

08

236

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

"MEDIA"

"Change media"
"Eject USB device" (if USB
connected)
"Play mode" ("Normal",
"Random", "Random on all
media", "Repetition")
"Audio settings"
"Activate / Deactivate AUX input"

List of the current media
tracks.

Go from the list to the menu (left/right).

or

Press MUSIC.

MUSIC MEDIA PLAYERS

Access to the "MUSIC MEDIA PLAYER" menu

08

237

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

CD, MP3 CD / USB player

The audio equipment will only play audio files with ".wma, .aac, .flac,

.ogg and .mp3" file extensions and with a bit rate of between 32 Kbps

and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other type of file (.mp4, .m3u...) can be played.

WMA files must be of the standard wma 9 type.
The sampling rates supported are greater than 32 KHz.

It is advisable to restrict file names to 20 characters, without using of

special characters (e.g.: " " ? ; ù) to avoid any playing and displaying

problems.

In order to be able to play a recorded CDR or CDRW, when recording

it is preferable to select the ISO 9660 level 1, 2 or Joliet standard.
If the disc is recorded in another format (udf, ...), it may not be played
correctly.
It is recommended that the same recording standard is always used

for an individual disc, with as low a speed as possible (4x maximum)

for optimum sound quality.
In the particular case of a multi-session CD, the Joliet standard is

recommended.

Information and advice

The system supports USB mass storage or iPod
devices via the USB port (suitable cable not supplied).
If a partitioned USB memory key is connected to the

system, only the first partition is recognised.

Control of the peripheral device is with the audio

system controls.
The number of tracks is limited to 2000 maximum,

999 tracks per folder.
If the current consumption at the USB port exceeds

500 mA, the system goes into protection mode and
deactivates the port.
Other peripherals, not recognised on connection, must

be connected to the auxiliary socket using a Jack cable

(not supplied).

Use only USB memory sticks formatted FAT32 (File Allocation Table).

The system does not support the operation of an Apple

®

 player and a

USB memory stick connected at the same time.

It is recommended that official Apple

®

 USB cables are used to ensure

correct operation.

MUSIC MEDIA PLAYERS

08

238

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Insert the CD in the player, insert the USB
memory stick in the USB player or connect the
USB peripheral to the USB port using a suitable
cable (not supplied).
The system builds playlists (in temporary

memory), an operation which can take from

a few seconds to several minutes at the first

connection.
Reduce the number of non-music files and the

number of folders to reduce the waiting time.
The playlists are updated every time the ignition

is switched off or connection of a USB memory

stick. However, the system memorises these

lists and if they are not modified, the loading

time will be shorter.

Play starts automatically after a period which

depends on the capacity of the USB memory
stick.

Selection of source

The SOURCE

 button on the steering mounted controls allows a

direct change to the next media source.

"CD / CD MP3"

"USB, iPod"

"AUX"

"STREAMING"

"RADIO"

Press MUSIC to display the "MEDIA"
menu.

Select "Following media source" and

confirm.

Repeat the operation as many times as necessary to obtain the

desired media source (except for radio which is accessible either

with SOURCE or RADIO).

Sources

MUSIC MEDIA PLAYERS
