207

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

List of recent destinations.

"Navigation - guidance"

To delete the list of recent destinations, select "Guidance
options" in the navigation menu then select "Delete last
destinations

" and confirm. Select "Yes" then confirm.

Deleting just one destination is not possible.

Go from the list to the menu (left/right).

"Select destination"
"Journey leg and route"
"Guidance options"
"Map management"
"Stop / Restore guidance"

Press NAV.

To make full use of all of the
functions of your navigation
system, update the mapping
regularly. Contact a
CITROËN dealer or order
your mapping update at
http://citroen.navigation.com

A short press on the end of the
lighting control stalk repeats
the last navigation message.

NAVIGATION - GUIDANCE

Access to the "NAVIGATION" menu

208

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Press NAV to display the
"Navigation - guidance" menu.

Towards a new destination

Selecting a destination

Select "Select destination" and

confirm, then select "Enter an address"

and confirm.

Select the "Country" function then

confirm.

Select the "Town" or "Post code"

function then confirm.

Select the letters in the name of the

town or the characters in a post code

one at a time, confirming each one with

the knob.

Selection the town from the list offered,

then confirm.

A pre-set list (by entering the first few

letters) of the towns in the country selected

can be accessed directly by selecting and

confirming "List" in the screen.

If possible, enter the "Road" and "N°/X"

information in the same way.

Select "Archive

" to save the address entered in a contact file.

After about 60 seconds with no address entered, the system returns

to the last home page; to return to the current input, start again with

steps 1 and 2 then press again.

Confirm "OK" to start guidance.

Select the guidance criteria: "Fastest
route", "Shortest route" or optimised
"Distance/Time", then select the
desired restriction criteria: "With tolls",
"With Ferry", or "

Traffic info" then

confirm "OK".

NAVIGATION - GUIDANCE

209

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Towards a recent destination

Press NAV to display the
"Navigation - guidance" menu.

Select the desired destination and

confirm to start navigation.

Towards a contact in the directory of contacts

Select "Select destination" and

confirm, then select "Directory" and

confirm.

Selection the desired destination from

your contacts and confirm "OK" to start

navigation.

Press NAV to display the
"Navigation - guidance" menu.

Navigation towards a contact is only possible if there is an address

entered in the audio navigation system.

Delete recent destinations

Press NAV to display the
"Navigation - guidance" menu.

Select "Options

" and confirm and then

"Delete recent destinations" and

confirm.

NAVIGATION - GUIDANCE

210

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Select "Select destination" and

confirm, then select "GPS coordinates"

and confirm.

Enter the GPS coordinates and confirm

"OK" to start navigation.

Press NAV to display the
"Navigation - guidance" menu.

Towards GPS coordinates

Towards a point on the map

With the map displayed, press OK to

display the contextual menu. Select

"Move the map

" and confirm.

Press OK

to display the contextual

menu for "Move the map" mode.

Select "Select as destination" or
"Select as stage

" and confirm.

Move the cursor using the control to
identify the desired destination.

NAVIGATION - GUIDANCE

211

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Towards points of interest (POI)

The points of interest (POI) indicate all of the service locations in the vicinity
(hotels, various businesses, airports...).

Select the "Enter an address" function

and confirm, then select Select

destination

and confirm.

To select a POI close to your current
location, select "POI

" and confirm, then

select "Around the current place" and

confirm.
To select a POI as a stage on the route,
select "POI

" and confirm, then select "On

the route

" and confirm.

To select a POI as a destination, first

enter the country and town (refer to the

"Towards a new destination" section),

select "POI

" and confirm, finally select

"Near

" and confirm.

Search for POIs in the categories

suggested in the following pages.

Select "Search by Name" to search for POIs by name and not by

proximity.

Select the POI and confirm "OK" to start

navigation.

Press NAV to display the
"Navigation - guidance" menu.

NAVIGATION - GUIDANCE

212

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

NAVIGATION - GUIDANCE

This icon appears when several POIs are grouped

together in the same area. Zooming in on this icon

shows details of the POIs.

Service station

Garage

CITROËN

Covered car park

Car park

Rest area

Hotel

Restaurant

Cafeteria

Bed and breakfast

Railway station

Bus station

Port

Industrial estate

Supermarket

Vending machine

Sports complex, sports centre,

sports ground

Swimming pool

Winter sports resort

Airport

Theme parks

Hospital, Chemist, Vet

Police station

Town hall

Post office

Museum, Culture, Theatre,
Historic monument

Tourist information, Tourist
attraction

Risk areas / Danger areas*

List of principal points of interest (POI)

* According to availability in the country.

School

An annual mapping update allows new points of interest to be presented to you.
You can also update the Risk areas / Danger areas every month.
The detailed procedure is available on:
http://citroen.navigation.com.

Cinema

213

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

NAVIGATION - GUIDANCE

Select:
-

"Visual alert"

"Audible alert"

"Alert only in guidance"

"Overspeed alarm only".

The choice of time of notification defines

how long in advance that Risk area

warnings are given.
Select "OK

" to confirm the screen.

Select "Guidance options

" and confirm,

then select "Set parameters for risk
areas

" and confirm.

These functions are only available if risk areas have been

downloaded and installed on the system.
The detailed procedure for updating risk area POIs can be found at
http://citroen.navigation.com.

Press NAV to display the "Navigation -
guidance" menu.

Settings for risk area / danger area alerts

214

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Adding a stage

Press NAV to display the
"Navigation - guidance" menu.

Select "Journey leg and route" then

confirm.

Select "Close to" a route passing
close to the stage or "Strict" for a route
passing through the stage.
Confirm "OK" to start the guidance, and

give a general indication of the guidance
route.

Select "Add a stage

" then confirm.

The address of the stage is entered as
a destination, by "Enter an address",
a contact in "Directory", or "Previous
destinations".

Organising stages

To organise stages, carry out
operations 1 to 2 again, then select
"Order/delete journey legs" and

confirm.

Select and confirm to save the

modifications.

Select the stage that you want to move

in the order.

Select "Delete" to delete the stage.

NAVIGATION - GUIDANCE

215

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Route options

Calculation criteria

Select "Guidance options

" and confirm.

Select "OK

" and confirm to save the

modifications.

Select "

Define calculation criteria" and

confirm.

This function allows modification of:
-

the guidance criteria: ("Fastest
route", "Shortest route",
"Distance/Time"),

- the exclusion criteria: ("With tolls"

or "With Ferry"),

- traffic avoidance: ("

Traffic info").

Press NAV to display the
"Navigation - guidance" menu.

If traffic avoidance (Traffic info) is selected, the system suggests

an alternative route if there is a delay on the guidance route.

NAVIGATION - GUIDANCE

216

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Press NAV to display the
"Navigation - guidance" menu.

Map management

Selecting the points of interest displayed on the map

Select "Map management

" and confirm.

Select from the various categories

the ones that you want to display on

the screen.

Select "Map details

" and confirm.

Select "Default" to have only "Filling stations, garages" and
"Risk areas" appear on the map (if installed in the system).

Select "OK

" then confirm and select

"OK

" again then confirm to save the

modifications.

NAVIGATION - GUIDANCE

217

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Select "Map management

" and confirm.

Select:
- "Vehicle direction" to have the map

follow the direction of travel,

- "North direction" to keep the map

always North up,

- "Perspective view" to display a

perspective view.

Select "Map orientation

" and confirm.

The colour of the map, different from the day and night mode, is

configured in the "SETUP" menu.

Map orientation

Press NAV to display the
"Navigation - guidance" menu.

Street names are visible on the map from the 100 m scale.

NAVIGATION - GUIDANCE

218

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Press NAV to display the
"Navigation - guidance" menu.

Navigation voice synthesis

Select "Guidance options

" and confirm.

Adjusting the volume / Deactivation

Select "Set speech synthesis" and

confirm.

Select the volume graph and confirm.

Select "Deactivate" to deactivate voice messages.

Select "OK" and press the dial to

confirm.

Adjust the volume to the desired level

and confirm.

The volume of messages can be adjusted during the transmission
of the message using the volume adjustment control.

The volume setting of guidance messages is also accessible via
the "SETUP" / "Voice synthesis" menu.

NAVIGATION - GUIDANCE

219

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Male voice / Female voice

Press SETUP to display the

configuration menu.

Select "Select male voice" or "Select
female voice

" then confirm "Yes" to

activate a male or female voice. The
system restarts.

Select "Voice synthesis

" and confirm.

NAVIGATION - GUIDANCE

220

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Access to the "TRAFFIC INFORMATION" menu

List of TMC messages in order
of distance from the vehicle.

Go from the list to the menu (left/right).

Traffic information"

Geographic filter"

"Select TMC station"
(automatic, manual)
"Display/Do not display
messages"

Press "TRAFFIC".

TRAFFIC INFORMATION

221

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Configure the filtering and display of TMC messages

TMC (Traffic Message Channel) messages with GPS Navigation provide traffic information in real time.

Press the TRAFFIC button to display
the "

Traffic information" menu.

Select the "

Geographic filter" function

and confirm.

The system offers a choice of:
- "Retain all the messages",
or
- "Retain the messages"

● "Around the vehicle", (confirm

the mileage to modify and select
the distance),

● "On the route".

Confirm "OK" to save the modifications.

We recommend:
- a filter on the route and

- a filter around the vehicle of:

- 12 miles (20 km) in urban areas,
- 30 miles (50 km) on motorways.

TRAFFIC INFORMATION

222

C3Picasso_en_Chap13a_RT6-2-8_ed01-2015

Principal TMC symbols

Red and yellow triangle: traffic information, for example:

Black and blue triangle: general information, for example:

Weather reports

Modified signage

Risk of explosion

Traffic reports

Narrow carriageway

Road closed

Wind

Slippery surface

Demonstration

Fog

Accident

Danger

Parking

Delay

No entry

Snow / ice

Roadworks

Traffic jam

Receiving TA messages

The TA (Traffic Announcement) function gives priority to TA alert

messages. To operate, this function needs good reception of a

radio station transmitting this type of message. When a traffic report

is transmitted, the current audio source (Radio, CD, USB, ...) is
interrupted automatically to play the TA message. Normal playback
of the audio source resumes at the end of the transmission of
the message.

Press RADIO to display the menu.

Select "Service announcements" then

confirm.

Activate or deactivate "TA

" then confirm.

The volume setting for TA messages can be adjusted only during the
transmission of this type of alert.

Activate or deactivate the function at any time by pressing
the button.
During a message, press the button to interrupt it.

TRAFFIC INFORMATION

Content .. 12 13 14 15 ..
