A few deﬁ nitions

Range: displays the distance which can be travelled with the remaining

fuel detected in the tank, based on the average consumption over the last

few miles (kilometres).

This diplayed value may vary signiﬁ cantly following a change in the vehicle
speed or the relief of the route.

When the range falls below 20 miles (30 km), dashes are displayed. After

ﬁ lling with at least 5 litres of fuel, the range is recalculated and is displayed

as soon as it exceeds 60 miles (100 km).

If, whilst driving, dashes are displayed continuously in place of digits, contact
a CITROËN dealer.

If, whilst driving, dashes are displayed continuously in place of digits, contact

Current fuel consumption: only calculated and displayed above 20 mph

(30 km/h).

Average fuel consumption: this is the average fuel consumption since the

last trip recorder zero reset.

Distance travelled: calculated since the last trip computer zero reset.

Distance remaining to the destination: calculated with reference to the

ﬁ nal destination entered by the user. If guidance is activated, the navigation
system calculates it as a current value.

Average speed: this is the average speed calculated since the last trip

computer zero reset (ignition on).

TRIP COMPUTER

With tab "1" (trip 1):

the average speed, the average consumption and the

distance travelled calculated over trip "1" .

Tab "2" (trip 2) with the same functions for a second trip.

On-board computer

Instantaneous info.

Range

km/h

l/100

740

6.5

238

STEERING WHEEL CONTROLS

    1.   Volume increase.
  2.   Volume decrease.
  3.   Mute.
4.   RADIO:

selection of the previous or next stored station.

MP3/JUKEBOX:

selection of the previous or next directory.

5. RADIO: automatic search for a higher frequency.

CD/MP3/JUKEBOX:

selection of the next track.

CD/MP3:

continuous press: fast forwards play.

1. Displays the main screen.
2. Selection of the mode displayed

(TRIP, TEL, NAV or AUDIO).

3. Abandon the operation in progress

and return to the previous display.

4. Navigation through the menus.
5. Conﬁ rmation of the function selected.

1. Short press:

Activation of voice recognition.

2. WHEN THE TELEPHONE IS NOT IN USE:

Long press: access to the telephone menu (phone book, call

list, ...).

INCOMING CALL:

Short press to accept.

Long press to reject the call.

CALL IN PROGRESS:

Short press to hang up.

Long press to access the telephone menu.

3. Personalisation:

Short press: conﬁ rmation of the selection made using the dial.

4. Rotation:

Move around the phone book, the call list.

Selection of personalisation.

239

Press the voice recognition control to

start the voice recognition.
Say the words one by one and wait

for the audible conﬁ rmation signal
between each word.
The list which follows is exhaustive.

To display the list of available
voice commands, press the voice

recognition control to start the voice

recognition, then say HELP or the

voice recognition command.

For the same operation, press and
hold the MENU button and select the
function VOICE COMMANDS LIST.

VOICE COMMANDS LIST

VOICE COMMANDS

DISPLAYING THE LIST AND USING THEM

LEVEL 1

LEVEL 2

LEVEL 3

radio

memory
autostore
previous/next
list

1 to 6/*

cd player

Jukebox (if activated)

USB

previous/next track
track number/track
scan
random play

directory (CD-MP3 inserted)

list

1 to 250/*

previous/next
repeat
help/what can I say/cancel

call/guide to

"Pre-recorded description"

telephone

last number
voice box
voice mail
directory

"Pre-recorded description"

message

display
read
directory

"Pre-recorded description"

navigation

stop/resume
zoom in/out
view

destination
vehicle

trafﬁ c info

display
read

display

audio
telephone
trip computer

Navigation

air conditioning

previous/next
stop
delete
yes/no

for all level 1 and 2

* help/what can I say/cancel

for all level 1, 2 or *

240

09 CONFIGURATION

ADJUSTING THE DATE AND TIME

Press the MENU button.

Turn the dial and select the
CONFIGURATION function.

Press the dial to conﬁ rm the selection.

Turn the dial and select the DISPLAY
CONFIGURATION function.

Adjust the settings one by one

conﬁ rming by pressing the dial.
Next select the OK tab on the screen

then conﬁ rm.

Press the dial to conﬁ rm the selection.

DISPLAY CONFIGURATION

ADJUST THE DATE AND TIME

Press the dial to conﬁ rm the selection.

Turn the dial and select the ADJUST
THE DATE AND TIME function.

The CONFIGURATION function gives access to the colour, brightness and units settings and to voice
commands.

241

MAIN FUNCTION

NAVIGATION - GUIDANCE

previous destinations

SCREEN MENU MAP

set speech synthesis

activate/deactivate road names

delete last destinations

MAP

CHOICE A

choice A1

choice A2

CHOICE B...

SELECT DESTINATION

enter an address

country:

town:

road:

N°/_:

curr. loc

directory

previous destinations

order/delete journey legs

divert route

chosen destination

GUIDANCE OPTIONS

deﬁ ne calculation criteria

fastest

shortest

distance/time

with tolls

with ferry

trafﬁ c info

STOP/RESUME GUIDANCE

MAP ORIENTATION

vehicle direction

north direction

3D view

MAP DETAILS

administration and safety

town halls, town centre

universities, colleges

hospitals

hotels, restaurants and shops

hotels

restaurants

vineyards

business centres

242

supermarkets, shopping

culture, tourism and shows

culture and museums

casinos and nightlife

cinemas and theatres

tourism

shows and exhibitions

sports and open air centres

sports centres

golf courses

skating rinks, bowling alleys

winter sports resorts

parks, gardens

theme parks

transport and automobile

airports, ports

stations, bus stations

vehicle rental

lay-bys, car parks

service stations, garages

read messages

new message display

TRAFFIC INFORMATION

SELECT TMC STATION

automatic TMC

manual TMC

list of TMC stations

MOVE THE MAP/FOLLOW VEHICLE

DISPLAY MAP

full screen MAP

MAP

in window

MAP DATABASE DESCRIPTION

READ MESSAGES

FILTER TRAFFIC INFORMATION

geographic ﬁ lter

store all messages

store messages

around the vehicle

on the route

road information

trafﬁ c information

road closure

size limit

road condition

weather and visibility

urban/city information

parking

public transport

demonstrations

AUDIO FUNCTIONS

RADIO FAVOURITES

enter a frequency

activate/deactivate RDS mode

activate/deactivate regional mode

display/hide radio text

CD, USB, JUKEBOX FAVOURITES

activate/deactivate Introscan (SCN)

activate/deactivate Random mode (RDM)

activate/deactivate Repeat (RPT)

activate/deactivate display of CD info

copy CD to Jukebox

copy complete CD

multiple selection

CONFIGURE MESSAGE ANNOUNCEMENT

243

current track

eject CD

receive by infrared

exchange with SIM card

send all records to SIM

send one record to SIM

receive all SIM ﬁ les

receive a SIM ﬁ le

exchange with Bluetooth

TELEMATICS

call list

dial

directory

mailbox

services

customer contact centre

CITROËN assistance

CITROËN service

messages received

USB

copy USB to Jukebox

complete disc

multiple selection

current album

current track

eject USB

CALL

DIRECTORY

managing directory ﬁ les

consult or modify a ﬁ le

add a ﬁ le

delete a ﬁ le

delete all ﬁ les

conﬁ gure directory

select a directory

name directory

select starting directory

ﬁ le transfer

exchange by infrared

send all records

send one record

TEXT MESSAGES (SMS)

read received text messages

send a text message

write a text message

delete list of text messages

TELEPHONE FUNCTIONS

network

network search mode

automatic mode

manual mode

networks available

length of calls

reset

manage PIN code

activate/deactivate

save PIN code

JUKEBOX

jukebox management

jukebox conﬁ guration

hi-ﬁ (320 kbps)

high (192 kbps)

normal (128 kbps)

playlist management

delete jukebox data

Jukebox status

244

Display short cuts version 8.2

modify PIN code

call options

conﬁ gure calls

display my number

automatic reply after x ring(s)

ring options

for voice calls

for text messages (SMS)

text message ring

calls diversion to mailbox n°

delete calls log

CONFIGURATION

DISPLAY CONFIGURATION

choose colour

adjust luminosity

set date and time

select units

* The parameters vary according to vehicle.

SOUND

voice commands setting

speech synthesis setting

guidance instructions volume

other message volume

select female/male voice

activate/deactivate auxiliary source

VIDEO

VEHICLE DIAGNOSTICS

SELECT LANGUAGE

ACTIVATE VIDEO MODE

VIDEO PARAMETERS

display formats

adjust luminosity

set colours

set contrasts

ALERT LOG

STATUS OF FUNCTIONS *

RESET TYRE PRESS. DETEC. SYS. *

phone book synchronisation mode

no synchronisation

view telephone phone book

view SIM card phone book

view all phone books

BLUETOOTH FUNCTIONS

activation mode

deactivated

activated and visible

activated and not visible

list of matched peripheral equipment

change the name of the audio/telephone

authentication code

DEFINE VEHICLE PARAMETERS *

245

Press the MENU button for more
than 2 seconds to access the

following ﬂ ow chart.

VOICE COMMANDS LIST

Press the Music button several
times in succession to access the

following settings.

AUTO VOLUME CORRECTION

Each audio source (Radio, CD, MP3,

Jukebox, CD changer) has its own

separate settings.

AUDIO/TELEPHONE DIAGNOSTICS

GPS COVERAGE

UNIT BACKUP POWER

UNIT DESCRIPTION

NAVIGATION DEMONSTRATION

SERVICES CONFIGURATION

LOUDNESS CORRECTION

TREBLE

BASS

MUSICAL AMBIENCE

FR - RR BALANCE

LH - RH BALANCE

246

sound quality between
the different audio

sources (radio, CD...).

Check that the audio settings (Volume, Bass,

Treble, Ambience, Loudness) are adapted to
the sources listened to. It is advisable to set
the AUDIO functions (Bass, Treble, Front-Rear

Balance, Left-Right Balance) to the middle
position, select the musical ambience "None"
and set the loudness correction to the "Active"
position in CD mode or to the "Inactive" position
in radio mode.

For optimum sound quality, the audio settings (Volume, Bass, Treble,

Ambience, Loudness) can be adapted to the different sound sources,

which may result in audible differences when changing source

(radio, CD...).

The CD is ejected
automatically or is not
played by the player.

The CD is protected by an anti-pirating protection

system which is not recognised by the audio equipment.

The CD is inserted upside down, is unplayable, does not contain any audio
data or contains an audio format which the player cannot play.

The CD player sound
is poor.

Insert good quality CDs and store them in
suitable conditions.

The CD used is scratched or of poor quality.

The audio equipment settings (bass, treble, ambiences) are unsuitable.

Set the treble or bass level to 0, without selecting
an ambience.

The table below groups together the answers to the most frequently asked questions.

QUESTION

SOLUTION

ANSWER

FREQUENTLY ASKED QUESTIONS

- Check that the CD is inserted in the player the

right way up.

- Check the condition of the CD: the CD cannot

be played if it is too damaged.

- Check the content in the case of a recorded

CD: consult the advice in the Audio section.

- The audio equipment's CD player does not

play DVDs.

- Due to inadequate quality, certain recorded

CDs will not be played by the audio system.

247

SOLUTION

ANSWER

The environment (hills, buildings, tunnels, basement car parks...) block

reception, including in RDS mode.

The aerial is absent or has been damaged (for example when going

through a car wash or into an underground car park).

This phenomenon is normal and does not
indicate a failure of the audio equipment.

Have the aerial checked by a CITROËN dealer.

Sound cut-outs of 1
to 2 seconds in radio
mode.

During this brief sound cut-out, the RDS searches for any frequency

permitting better reception of the station.

Deactivate the RDS function if the phenomenon
is too frequent and always on the same route.

With the engine off,
the audio equipment
switches off after a
few minutes of use.

When the engine is switched off, the audio equipment operating time

depends on the battery charge.

The switch-off is normal: the audio equipment switches to economy mode

and switches off to prevent discharging of the vehicle's battery.

The stored stations do
not function (no sound,

87.5 Mhz is displayed...)

An incorrect waveband is selected.

Press the BAND AST button to return to the

waveband (AM, FM1, FM2, FMAST) on which the
stations are stored.

Start the vehicle's engine to increase the battery

charge.

The quality of reception
of the radio station

listened to gradually
deteriorates or the
stored stations do
not function (no
sound, 87.5 Mhz is

displayed...).

The vehicle is too far from the transmitter used by the station listened to or

there is no transmitter in the geographical area through which the vehicle

is travelling.

Activate the RDS function to enable the system
to check whether there is a more powerful

transmitter in the geographical area.

248

QUESTION

SOLUTION

ANSWER

The TRAFFIC INFO
box is ticked. However,

certain trafﬁ c jams

along the route are not
indicated in real time.

On starting, it is several minutes before the system begins to receive the

trafﬁ c information.

Wait until the trafﬁ c information is being received

correctly (displaying of the trafﬁ c information

symbols on the map).

In certain countries, only major routes (motorways, ...) are listed for the

trafﬁ c information.

The time taken to
calculate a route
sometimes seems

longer than usual.

This phenomenon is normal. The system is

dependent on the trafﬁ c information available.

The performance of the system may slow down temporarily if a CD is

being copied onto the Jukebox at the same time as a route is being
calculated.

Wait until the CD has been copied or stop the

copying before starting the guidance function.

Does the emergency call
function work without a

SIM card?

Certain national regulations impose the presence of a SIM card in order to

make an emergency call.

Insert a valid SIM card in the slot on the system.

My SIM card is not

recognised.

The system accepts 3.3 V SIM cards, the old 5 V and 1.8 V SIM cards are

not recognised.

Contact your telephone operator.

The altitude is not
displayed.

On starting, the initialisation of the GPS may take up to 3 minutes to
receive more than 4 satellites correctly.

Wait until the system has started up completely.

Check that there is a GPS coverage of at least

4 satellites (long press on the MENU button, then
select AUDIO/TELEPHONE DIAGNOSTICS,

then GPS COVERAGE).

Depending on the geographical environment (tunnel, ...) or the weather,

the conditions of reception of the GPS signal may vary.

This phenomenon is normal. The system is
dependent on the conditions of reception of the

GPS signal.

251

The MyWay is protected in such a way that it will only
operate in your vehicle. If it is to be installed in another

vehicle, contact a CITROËN dealer for conﬁ guration of

operate in your vehicle. If it is to be installed in another

le. If it i

the system.

Certain functions described in this handbook will become

available during the course of the year.

MyWay

CONTENTS

01 First steps

p . 252

02 General operation

p . 253

03 Navigation - Guidance

p . 255

04 Trafﬁ c information

p . 262

05 Radio

p . 263

06 Music media players

p . 264

07 Bluetooth telephone

p . 267

08 Conﬁ guration

p . 269

09 Steering wheel controls

p . 271

10 Screen menu map

p . 272

Frequently asked questions p . 275

For safety reasons, the driver should only carry out

operations which require prolonged attention while the
vehicle is stationary.

When the engine is switched off and to prevent

discharging of the battery, the MyWay switches off

following the activation of the Energy Economy mode.

MULTIMEDIA AUDIO EQUIPMENT/BLUETOOTH TELEPHONE

GPS EUROPE BY SD CARD

252

01 FIRST STEPS

1. Engine not running

- Short press: on/off.

- Long press: CD pause, mute for the radio.

Engine running

- Short press: CD pause, mute for the radio.

- Long press: reinitialisation of the system.

   2.    Volume adjustment.
   3.    Access to the "Radio" Menu. Display the list of stations.
  4.   Access to the "Music" Menu. Display the tracks.

6. Access to the "Phone" Menu. Display the call list.
7. Access to the "MODE" Menu.

Selection of the successive display of:

Radio, Map, NAV (if navigation is in progress), Telephone

(if a conversation is in progress), Trip Computer.

Long press: display of a black screen (DARK).

   8.    Access to the "Navigation" Menu. Display the last destinations.
   9.    Access to the "Trafﬁ c" Menu. Display the current trafﬁ c alerts.
   10.    ESC: abandon the operation in progress.
   11.    CD eject.
   12.    Selection of the previous/next radio station from the list.

Selection of the previous/next CD.

Selection of the previous/next MP3 directory.

Selection of the previous/next page of a list.

13. Selection of the previous/next radio station.

Selection of the previous/next CD or MP3 track.

Selection of the previous/next line of a list.

14. Buttons 1 to 6:

Selection of the stored radio station.

Selection of the CD in the CD changer.

Long press: store the current radio station.

15. SD card reader.
16. Dial for selection of the screen display and according to

the context of the menu.

Short press: conﬁ rmation.

MyWay CONTROL PANEL

3 - 4. Long press: access to the audio settings: front/rear and left/

right balance, bass/treble, equalizer, loudness, automatic

volume adjustment, initialise the settings.

5. Access to the "SETUP" Menu.

Long press: access to the GPS coverage and the

demonstration mode.

Citroen C4 Picasso Dag (2009 year). Manual - part 18
