Westfalia. Testing repair electrical manual - part 27
AR83.65-D-2070B
Remove/install refrigerant compressor motor
7.6.04
MODEL 903.662
with CODE (ZU8) National version for USA
with CODE (Z29) "James Cook" touring camper, NAFTA
Roof air conditioning refrigerant compressor motor
D83.65-0050-08
1 Motor
2 Nut
3 Load relay
4 Electrical line
5 Nut
6 Electrical line
7 Electrical line
8 Screw
9 Nuts
Remove/Install
Danger!
Risk of death caused by falling
down from the roof of the
vehicle. Risk of injury to other
persons caused by falling objects
during work in the area of the
roof.
Work on or in the area of the
vehicle's roof may only be
performed on suitable equipment
(ladders, scaffolds, lifting
platforms). Sufficiently secure
the area to be worked in.
Danger!
Risk of injury caused by exiting
refrigerant and by contact with
the components of the refrigerant
system
Wear protective clothing, safety
gloves and safety glasses
Danger!
Risk of death from coming into
contact with electrical parts of
the 110 V system. Risk of injury
caused by burns, which can be
produced by electrical shocks or
by body parts coming in direct
contact with electrical currents.
Do not touch any conductive
parts of the 110 V system.
