CG935G Wheel Loader. Manual - part 3





16

15．Instruction on safety stand for oil cylinder    16. Symbol of crane hook

  (on the machine body)                                                (on the machine body)





















17．  Symbol of lock rod (on the machine body)

The safety stand for oil cylinder is a
safety device and is hanged at the rear
frame. Before servicing, take it off and
lock it in piston of oil cylinder.
Notice: when installing and using the
device, please keep the bucket empty
and the loader at non-operating state.

When the machine needs to be
hoisted, please hang the hook or
rope at the location where the hook
symbol is affixed.







17

Safety rules

Ⅱ



2.1  EU Safety Requirements

1． Noise limit requirement

Complying with the 2000/14/EC directive, this machine meets the following requirements:

L

B

PA

B

：

≤85dB(A)

L

B

WA

B

：

≤106 dB(A)

2． The vibration value of the seat of operator’s cabin of this machine meets the

requirements of ISO 7096-2000.

3． Electromagnetic compatibility

The electromagnetic compatibility of this machine complies with the relevant requirements

of ISO13766 Standard. The machines can maintain its normal functions in centain

electromagnetic environments and the electromagnetism generated during the operation

does not cause damages to surrounding environment.

4．  The operator’s cabin of this machine has ROPS – rollover protective structure and

FOPS – falling object protective structure.

2.2  Safety of Operator

Pay attention to location of all safety and warning symbols on the machine and comprehend

their meanings. The symbols and warnings that are obscure or damaged during use shall be

replaced by new ones.

When the operator is in one of the following status, he shall not operate the machine:

 When the operator is exhausted, he shall not operate

the machine.

 When the operator has taken medicines that may cause

sleepiness, he shall not operate the machine.

 The operator shall not operate the machine after

drinking alcohol.

 The operator shall wear work clothes, work cap and work gloves for the servicing of the

machine. The operator shall not wear clothes or ornamental articles that may either hook or

entangle the machine, or cause combustion or sparkles in contact with electrical devices.





18

 Personnel who is not approved or certificated (operation qualification certificate) is not

allowed to conduct operation, repair, or maintenance of the machine.

 Be familiar with the command signs and only follow the command signs of one person.

 Before starting the machine, be clear of:

Location of fire extinguisher

Location of toolkit

Fire alarm telephone number

Emergency telephone number

 Walk around the machine to ensure nobody is working around the machine and nobody is

working lying underneath the machine.

2.3 Safety Protective Appliances

 When servicing the machine, determine the needed

individual pretective appliances according to the

specific work environment.

 Do not wear clothes or ornamental articles that may

either hook or entangle the machine.

 Do not wear clothes or ornamental articles that may

cause combustion or sparkles in contact with electrical devices.

 All pretective appliances shall be checked prior to use for their usability.



























19

 Operation of the

Ⅲ

Machine

3.1 Get Familiar with the Machine

 Only those personnel who have received training and

obtained qualification are allowed operate and

maintain the machine.

 Read and comprehend operation and maintenance

instructions and safety issues, otherwise do not work

on the machine.

 Failure to follow the instructions or ignorance of warnings may cause injuries.

 When there is oil or grease at or near the operation position, please remove it. Otherwise

there will be peril of slip.

 During the operation, repair, lubrication, maintenance and operation of this machine, only

one person with operation certificate is allowed to operate machine or conduct servicing of

repair, lubrication, maintenance, etc. Other people shall stay away from the machine. When

operating the machine, it is prohibited to have more than one person in the operator’s cabin.

 Various checks on the machine shall be conducted prior to operation. Check whether all the

safety protective devices are in a safe status; whether the tires are worn and whether the tire

pressure is proper. Check whether there is abnormal phenomenon of oil leakage, water

leakage, gas leakage, deformation, looseness, abnormal sound, etc., which may cause

malfunction or severe accident.

3.2 Get in and off the Machine

●

When getting in or off the machine, do not wear loose clothes such as headscarf or jewels,

otherwise they may be clamped and injuries may be caused.

●

Check the handrails and steps before getting in and off the machine; remove oil stains,

lubricants or mud if there is any. Besides, damages of parts shall be repaired and loose bolts

shall be fastened.

●

It is prohibited to jump onto or off the machine.

●

It is prohibited to get in or off the machine when the machine is moving.

● When getting in or off the machine, face the machine, hold the handrail and step on the steps;
