TROUBLESHOOTING

LV Operation Manual

87

TROUBLESHOOTING
INFORMATION

If your engine does not operate properly, refer to
the troubleshooting chart or consult your
authorized Yanmar industrial engine dealer or
distributor.

Supply the authorized Yanmar industrial engine
dealer or distributor with the following information:

• Model name and serial number of your

engine

• The driven machine type (tractor, generator,

skid steer loader), manufacturers name,
model and serial number

• How long the engine has been in service (the

number of engine hours or the number of
calendar months)

• Operating conditions when problem occurs:

‹

Engine rpm

‹

Color of exhaust smoke

‹

Type of diesel fuel

‹

Type of engine oil

‹

Any abnormal noises or vibration

‹

Operating environment such as high
altitude or extreme ambient temperatures,
etc.

• Engine maintenance history and previous

problems

• Other factors that contribute to the problem

• White exhaust smoke

• Improper diesel fuel

• Replace with recommended

diesel fuel

Diesel Fuel

Specifications on

page 29

• Faulty spray pattern of fuel

injection

• See authorized Yanmar

industrial engine dealer or
distributor

—

• Fuel injection timing delay

—

• Engine burning oil

—

SYMPTOM

PROBABLE CAUSE

ACTION

REFER TO

TROUBLESHOOTING

88

LV Operation Manual

This Page Intentionally Left Blank

LV Operation Manual

89

LONG TERM

STORAGE

LV Operation Manual

This section of the Operation Manual describes
the procedures necessary to place the engine
into long term storage (six months or longer) and
how to place it back into operation.

BEFORE YOU PLACE THE
ENGINE IN LONG TERM
STORAGE

A

 DANGER

EXPLOSION HAZARD!

• NEVER check the remaining battery

charge by shorting out the terminals.
This will result in a spark and may
cause an explosion or fire. Use a
hydrometer to check the remaining
battery charge.

• If the electrolyte is frozen, slowly warm

the battery before you recharge it.

• Failure to comply will result in death or

serious injury.

0000007en

A

 WARNING

BURN HAZARD!

• Batteries contain sulfuric acid. NEVER

allow battery fluid to come in contact
with clothing, skin or eyes. Severe
burns could result. ALWAYS wear
safety goggles and protective clothing
when servicing the battery. If contact
with the skin and / or eyes should
occur, flush with a large amount of
water and obtain prompt medical
treatment.

• Failure to comply could result in death

or serious injury.

0000007en

LONG TERM STORAGE

90

LV Operation Manual

1. Perform the next Periodic Maintenance

procedure. For example, if there are 10 hours
before the 200 hour maintenance, you should
do the maintenance before you place the
engine in storage. See the Periodic
Maintenance Schedule on page 65.

2. Start the engine. Allow the engine to idle, or

run without load if there is no idle position in
your application, for approximately 3 minutes
and then stop the engine.

3. L48V Engines Only -

(a) Remove the oil plug (Figure 1, (1)).

Figure 1

(b) Add 2 cc of engine oil to the oil port

(Figure 2, (1)).

Figure 2

(c) Reinstall the oil plug (Figure 1, (1)).

4. Drain the engine oil while the engine is still

warm and fill with new oil. See Replace
Engine Oil on page 74.

A

 CAUTION

FLYING OBJECT HAZARD!

• ALWAYS wear eye protection when

servicing the engine and when using
compressed air or high-pressure
water. Dust, flying debris, compressed
air, pressurized water or steam may
injure your eyes.

• Failure to comply may result in minor

or moderate injury.

0000003en

CAUTION

Protect the air cleaner, turbocharger (if
equipped) and electric components
from damage when you use steam or
use high-pressure water to clean the
engine.

0000014en

(1)

0001581

(1)

0001580
