PERIODIC MAINTENANCE

82

LV Operation Manual

Perform the following maintenance every 1000
hours of operation.

• Check Compression

Check Compression

Checking the engine compression is required
every 1000 hours to obtain optimum engine
performance. See your authorized Yanmar
industrial engine dealer or distributor for this
service.

Perform the following maintenance every 1500
hours of operation.

• Inspect, Clean and Test Fuel Injection

Nozzle

Inspect, Clean and Test Fuel
Injection Nozzle

Proper operation of the fuel injectors is required
to obtain the optimum injection pattern for full
engine performance. The EPA / ARB requires that
you have the injectors inspected, cleaned and
tested every 1500 hours. See your authorized
Yanmar industrial engine dealer or distributor for
this service.

Every 1000 Hours of Operation

Every 1500 Hours of Operation

A

 WARNING

HIGH PRESSURE HAZARD!

• Avoid skin contact with the high

pressure diesel fuel spray caused by a
fuel system leak such as a broken fuel
injection line. High pressure fuel can
penetrate your skin and result in
serious injury. If you are exposed to
high pressure fuel spray, obtain
prompt medical treatment.

• NEVER check for a fuel leak with your

hands. ALWAYS use a piece of wood
or cardboard. Have your authorized
Yanmar industrial engine dealer or
distributor repair the damage.

• Failure to comply could result in death

or serious injury.

0000008en

PERIODIC MAINTENANCE

LV Operation Manual

83

Perform the following maintenance every 2000
hours of operation.

• Check and Replace Fuel Hoses

Check and Replace Fuel Hoses

Regularly check the fuel system hoses. If they are
cracked or degraded, replace them. Replace the
hoses at least every two years, or 2000 hours,
whichever occurs first. Consult your authorized
Yanmar industrial engine dealer or distributor to
replace fuel system hoses.

Every 2000 Hours of Operation

CAUTION

Be environmentally responsible. Follow
these procedures for hazardous waste
disposal. Failure to follow these
procedures may seriously harm the
environment.

• Follow the guidelines of the EPA or

other governmental agency for the
proper disposal of hazardous
materials such as engine oil, diesel
fuel and engine coolant. Consult the
local authorities or reclamation facility.

• NEVER dispose of hazardous

materials irresponsibly by dumping
them into a sewer, on the ground or
into ground water or waterways.

0000013en

LV Operation Manual

85

TROUBLESHOOTING

LV Operation Manual

If a problem occurs, stop the engine immediately.
Refer to the SYMPTOM column in the
Troubleshooting Chart to identify the problem.

TROUBLESHOOTING CHART

CAUTION

If any indicator fails to illuminate when
the key switch is in the ON position, see
your authorized Yanmar industrial
engine dealer or distributor for service
before operating the engine.

0000028en

CAUTION

If any indicator illuminates during
engine operation stop the engine
immediately. Determine the cause and
repair the problem before you continue
to operate the engine.

0000029en

SYMPTOM

PROBABLE CAUSE

ACTION

REFER TO

Indicator Turns On - Engine Running

Engine oil pressure indicator (If
equipped)

• Low level of engine oil
• Too high an oil level

• Check and adjust oil level as

necessary

Checking Engine

Oil on page 33

• Clogged engine oil filter

• Replace engine oil filter

element

Replace Engine Oil on

page 74

Battery Indicator

• Battery failure

• Check battery condition

Check Indicators on

page 35

• Faulty dynamo

• See authorized Yanmar

industrial engine dealer or
distributor

—

Indicator Does Not Turn On - Key Switch is Turned to ON (OFF

→ ON)

• Faulty electrical wiring or

faulty indicator

• See authorized Yanmar

industrial engine dealer or
distributor

—

TROUBLESHOOTING

86

LV Operation Manual

Indicator Stays On - Key Switch is Turned from Start to ON (START

→ ON)

• Battery indicator stays On

• Faulty alternator

• See authorized Yanmar

industrial engine dealer or
distributor

—

• Engine oil pressure indicator

stays On

• Faulty engine oil pressure

switch

—

Engine Does Not Start

• Starter motor operates but

engine does not start

• No diesel fuel

• Refuel fuel system

Filling the Fuel

Tank on page 30

• Improper diesel fuel

• Replace with recommended

diesel fuel

Diesel Fuel

Specifications on

page 29

• Clogged fuel filter

• Replace fuel filter

Drain the Fuel Tank

and Replace Outlet

Fuel Filter on page 79

• Poor fuel injection

• See authorized Yanmar

industrial engine dealer or
distributor

—

• Compressed air leakage from

intake / exhaust valves

—

• Faulty engine stop solenoid (if

equipped)

—

• Starter motor does not

operate or rotates too slowly
(engine can be turned
manually)

• Battery needs charging

• Check electrolyte, recharge

Check Battery (If

Equipped) on page 67

• Faulty cable connection at
• battery terminals

• Clean terminals, retighten

—

• Faulty starter switch

• See authorized Yanmar

industrial engine dealer or
distributor

—

• Faulty starter motor

—

• Engine cannot be manually

turned

• Inner parts seized or damaged

—

White or Black Exhaust Smoke

• Black exhaust smoke

• Engine overloaded

• Reduce load

—

• Clogged air cleaner element

• Clean element or replace

Clean Air Cleaner

Element on page 77

• Improper diesel fuel

• Replace with recommended

diesel fuel

Diesel Fuel

Specifications on

page 29

• Faulty spraying of fuel

injection

• See authorized Yanmar

industrial engine dealer or
distributor

—

• Excessive intake / exhaust

valve clearance

—

SYMPTOM

PROBABLE CAUSE

ACTION

REFER TO
