DB2 Server for VSE & VM SQL Reference (Version 7 Release 5)

Expressions

An expression specifies a value.

| operator |

(1)

►►

▼

function

►◄

(expression)

−

constant

column_name

host_variable

special_register

labeled_duration

operator:

(2)

CONCAT

−

labeled_duration:

function

YEAR

(expression)

YEARS

constant

MONTH

column_name

MONTHS

host_variable

DAY

DAYS

HOUR

HOURS

MINUTE

MINUTES

SECOND

SECONDS

MICROSECOND

MICROSECONDS

Notes:

Not all combinations of operands and operations are supported.

Either || or !! can be used as an alternative to CONCAT in all DB2

Server for VSE &

VM-supported code pages. However, !! is not supported in IBM-SQL.

Without Operators

If no operators are used, the result of the expression is the specified value.

Examples:

SALARY

:SALARY

’SALARY’

MAX(SALARY)

Chapter 3. Language Elements

Expressions

With the Concatenation Operator

The concatenation operator (CONCAT) links two string operands to form a string

expression.

The operands of concatenation must be compatible strings. Note that datetime data

types (including the CURRENT DATE, CURRENT TIME, and CURRENT

TIMESTAMP special registers) can be used as operands in a character string

expression because the datetime data types are compatible with the character data

type. If both operands are character strings, the sum of their length attributes must

not exceed 254; if both are graphic strings, the sum of their length attributes must

not exceed 127.

If either operand can be null, the result can be null, and if either is null, the result

is the null value. Otherwise, the result consists of the first operand string followed

by the second.

With mixed data this result will not have redundant shift codes “at the seam”.

Thus, if the first operand is a string ending with a “shift-in” character, while the

second operand is a character string beginning with a “shift-out” character, these

two bytes are eliminated from the result. Note that no check is made for

improperly formed mixed data when doing concatenation.

The length of the result is the sum of the lengths of the operands, unless

redundant shift codes are eliminated, in which case the length is two less than the

lengths of the operands.

If both operands are fixed-length character strings (neither of which is mixed data)

the result is a fixed-length character string whose length attribute is the sum of the

length of the operands. Otherwise, the result is a varying-length character string

whose length attribute is the sum of the length attributes of the operands.

If both operands are fixed-length graphic strings, the result is a fixed-length

graphic string whose length attribute is the sum of the length of the operands.

Otherwise, the result is a varying-length graphic string whose length attribute is

the sum of the length attributes of the operands.

The CCSID of the result is determined by the CCSID of the operands as explained

under “Conversion Rules for Operations that Combine Strings” on page 130.

If an operand is a string from a column with a field procedure, the operation

applies to the decoded form of the value; the result does not inherit the field

procedure.

Example 1: FIRSTNME CONCAT ’ ’ CONCAT LASTNAME

Example 2: Given:

COLA defined as VARCHAR(5) with value ’AA’

COLB defined as VARCHAR(5) with value ’BB

’

COLC defined as CHAR(5) with value ’CC

’

COLD defined as CHAR(5) with value ’DDDDD’

The value of COLA CONCAT COLB CONCAT COLC CONCAT COLD is:

’AABB CC DDDDD’

SQL Reference

Expressions

With Arithmetic Operators

Arithmetic operators (+, -, *, /) link two numeric or datetime operands to form a

numeric expression.

If arithmetic operators are used, the result of the expression is a number derived

from the application of the operators to the values of the operands. If any operand

can be null, or the expression is used in an outer SELECT list, the result can be

null. If any operand has the null value, the result of the expression is the null

value. Arithmetic operators must not be applied to character strings. For example,

USER+2 is incorrect.

The prefix operator + (unary plus) does not change its operand. The prefix operator

- (unary minus) reverses the sign of a nonzero operand. If the data type of A is

small integer, the data type of -A is large integer. If the data type of A is small float,

then the data type of -A is large float. The first character of the token following a

prefix operator must not be a plus or minus sign.

The infix operators +, -, *, and / specify addition, subtraction, multiplication, and

division, respectively. Either an error or a warning results if the second operand of

division has a value of zero.

Two-Integer Operands

If both operands of an arithmetic operator are integers, the operation is performed

in binary and the result is a large integer. Any remainder of division is lost. The

result of an integer arithmetic operation (including unary minus) must be within

the range of large integers.

Integer and Decimal Operands

If one operand is an integer and the other is decimal, the operation is performed in

decimal using a temporary copy of the integer that has been converted to a

decimal number with zero scale and precision as defined in the following table:

Operand

Precision of Decimal Copy

Column or variable:large integer

Column or variable:small integer

Constant

Same as the number of digits (including

leading zeros) in the constant

Two-Decimal Operands

If both operands are decimal, the operation is performed in decimal. The result of

any decimal arithmetic operation is a decimal number with a precision and scale

that are dependent on the operation and the precision and scale of the operands. If

the operation is addition or subtraction and the operands do not have the same

scale, the operation is performed with a temporary copy of one of the operands

that has been extended with trailing zeros so that its fractional part has the same

number of digits as the other operand.

Unless specified otherwise, all functions and operations that accept decimal

numbers allow a precision of up to 31 digits. The result of a decimal operation

cannot have a precision greater than 31.

Chapter 3. Language Elements

Expressions

Decimal Arithmetic in SQL

The following formulas define the precision and scale of the result of decimal

operations in SQL. The symbols p and s denote the precision and scale of the first

operand and the symbols p' and s' denote the precision and scale of the second

operand.

The precision of the result of addition and subtraction is min(31, max(p-s,

p'-s')+max(s, s')+1) and the scale is max(s, s').

The precision of the result of multiplication is min(31, p+p') and the scale is min(31,

s+s').

The precision of the result of division is 31 and the scale is 31-p+s-s'. If the scale is

negative, a negative value is returned in the SQLCODE field of the SQLCA.

Precision and scale can be influenced by decimal constants with leading or trailing

zeros.

Floating-Point Operands

If either operand of an arithmetic operator is floating-point, the operation is

performed in floating-point. If necessary, the operands are first converted to double

precision floating-point numbers. Thus, if any element of an expression is a

floating-point number, the result of the expression is a double precision

floating-point number.

An operation involving a floating-point number and an integer is performed with

a temporary copy of the integer that has been converted to double precision

floating-point. An operation involving a floating-point number and a decimal

number is performed with a temporary copy of the decimal number that has been

converted to double precision floating-point. The result of a floating-point

operation must be within the range of floating-point numbers.

Datetime Operands

Datetime values can be incremented, decremented, and subtracted. These

operations may involve decimal numbers called durations. Following is a definition

of durations and a specification of the rules for datetime arithmetic.

Durations

A duration is a number representing an interval of time. There are four types of

durations:

Labeled Durations (see diagram on page 71)

A labeled duration represents a specific unit of time as expressed by a

number (which can be the result of an expression) followed by one of the

seven duration keywords: YEARS, MONTHS, DAYS, HOURS, MINUTES,

SECONDS, or MICROSECONDS (the singular form of these keywords is

also acceptable: YEAR, MONTH, DAY, HOUR, MINUTE, SECOND, and

MICROSECOND.). The number specified is converted as if it were

assigned to a DECIMAL(15,0) number. A labeled duration can only be used

as an operand of an arithmetic operator in which the other operand is a

value of data type DATE, TIME, or TIMESTAMP. Thus, the expression

START_DATE + 2 MONTHS + 14 DAYS is valid, while the expression

START_DATE + (2 MONTHS + 14 DAYS) is not. In both of these

expressions, the labeled durations are 2 MONTHS and 14 DAYS.

Date Duration

A date duration represents a number of years, months, and days, expressed

SQL Reference

Expressions

as a DECIMAL(8,0) number. To be properly interpreted, the number must

have the format yyyyxxdd, where yyyy represents the number of years, xx

the number of months, and dd the number of days. The result of

subtracting one DATE value from another, as in the expression END_DATE

- START_DATE, is a date duration.

Time Duration

A time duration represents a number of hours, minutes, and seconds,

expressed as a DECIMAL(6,0) number. To be properly interpreted, the

number must have the format hhmmss where hh represents the number of

hours, mm the number of minutes, and ss the number of seconds. The

result of subtracting one TIME value from another is a time duration.

Timestamp Duration

A timestamp duration represents a number of years, months, days, hours,

minutes, seconds, and microseconds, expressed as a DECIMAL (20,6)

number. To be properly interpreted, the number must have the format

yyyyxxddhhmmsszzzzzz, where yyyy, xx, dd, hh, mm, and ss represent,

respectively, the number of years, months, days, hours, minutes, and

seconds, and zzzzzz represents the number of microseconds. The result of

subtracting one timestamp value from another is a timestamp duration.

Datetime Arithmetic in SQL

The only arithmetic operations that can be performed on datetime values are

addition and subtraction. If a datetime value is the operand of addition, the other

operand must be a duration. The specific rules governing the use of the addition

operator with datetime values follow.

v If one operand is a date, the other operand must be a date duration or labeled

duration of years, months, or days.

v If one operand is a time, the other operand must be a time duration or a labeled

duration of hours, minutes, or seconds.

v If one operand is a timestamp, the other operand must be a duration. Any type

of duration is valid.

v Neither operand of the addition operator can be a parameter marker.

The rules for the use of the subtraction operator on datetime values are not the

same as those for addition because a datetime value cannot be subtracted from a

duration, and because the operation of subtracting two datetime values is not the

same as the operation of subtracting a duration from a datetime value. The specific

rules governing the use of the subtraction operator with datetime values follow.

v If the first operand is a date, the second operand must be a date, a date

duration, a string representation of a date, or a labeled duration of years,

months, or days.

v If the second operand is a date, the first operand must be a date, or a string

representation of a date.

v If the first operand is a time, the second operand must be a time, a time

duration, a string representation of a time, or a labeled duration of hours,

minutes, or seconds.

v If the second operand is a time, the first operand must be a time, or string

representation of a time.

v If the first operand is a timestamp, the second operand must be a timestamp, a

string representation of a timestamp, or a duration.

v If the second operand is a timestamp, the first operand must be a timestamp or

a string representation of a timestamp.

Chapter 3. Language Elements

Expressions

v Neither operand of the subtraction operator can be a parameter marker.

Date Arithmetic

Dates can be subtracted, incremented, or decremented.

Subtracting Dates: The result of subtracting one date (DATE2) from another

(DATE1) is a date duration that specifies the number of years, months, and days

between the two dates. The data type of the result is DECIMAL(8,0). If DATE1 is

greater than or equal to DATE2, DATE2 is subtracted from DATE1. If DATE1 is

less than DATE2, however, DATE1 is subtracted from DATE2, and the sign of the

result is made negative. The following procedural description clarifies the steps

involved in the operation RESULT = DATE1 - DATE2.

If DAY(DATE2) <= DAY(DATE1)

then DAY(RESULT) = DAY(DATE1) - DAY(DATE2).

If DAY(DATE2) > DAY(DATE1)

then DAY(RESULT) = N + DAY(DATE1) - DAY(DATE2)

where N = the last day of MONTH(DATE2).

MONTH(DATE2) is then incremented by 1.

If MONTH(DATE2) <= MONTH(DATE1)

then MONTH(RESULT) = MONTH(DATE1) - MONTH(DATE2).

If MONTH(DATE2) > MONTH(DATE1)

then MONTH(RESULT) = 12 + MONTH(DATE1) - MONTH(DATE2).

YEAR(DATE2) is then incremented by 1.

YEAR(RESULT) = YEAR(DATE1) - YEAR(DATE2).

For example, the result of DATE('3/15/2000') - '12/31/1999' is 215 (or, a duration

of 0 years, 2 months, and 15 days).

Incrementing and Decrementing Dates: The result of adding a duration to a

date, or of subtracting a duration from a date, is itself a date. The result must fall

between the dates January 1, 0001 and December 31, 9999 inclusive. If a duration

of years is added or subtracted, only the year portion of the date is affected. The

month is unchanged, as is the day unless the result would be February 29 of a

non-leap-year. Here the day portion of the result is set to 28, and the SQLWARN7

condition is set, indicating that an end-of-month adjustment was made to correct

an incorrect date.

Similarly, if a duration of months is added or subtracted, only months and, if

necessary, years are affected. (For the purposes of the operation, a month is a

calendar page. Adding n months to a date, for example, is like turning n pages of

a calendar starting with the page on which the date appears.) The day portion of

the date is unchanged unless the result would be incorrect (September 31, for

example). Here, the day is set to the last day of the month, and the SQLWARN7

field in SQLCA is set indicating the adjustment.

Adding or subtracting a duration of days will, of course, affect the day portion of

the date, and potentially the month and year.

Date durations, whether positive or negative, may also be added to and subtracted

from dates. As with labeled durations, the result is a valid date and SQLWARN7 is

set whenever an end-of-month adjustment is necessary.

When a positive date duration is added to a date, or a negative date duration is

subtracted from a date, the date is incremented by the specified number of years,

months, and days, in that order. Thus, DATE1 + X, where X is a positive

SQL Reference

Expressions

DECIMAL(8,0) number, is equivalent to the expression DATE1 + YEAR(X) YEARS

+ MONTH(X) MONTHS + DAY(X) DAYS.

When a positive date duration is subtracted from a date, or a negative date

duration is added to a date, the date is decremented by the specified number of

days, months, and years in that order. Thus, DATE1 − X, where X is a positive

DECIMAL(8,0) number, is equivalent to the expression DATE1 − DAY(X) DAYS −

MONTH(X) MONTHS − YEAR(X) YEARS.

When adding durations to dates, adding one month to a given date gives the same

date one month later unless that date does not exist in the later month. In that case,

the date is set to that of the last day of the later month. For example, January 28

plus one month gives February 28; and one month added to January 29, 30, or 31

results in either February 28 or, for a leap year, February 29.

Note: If one or more months is added to a given date and then the same number

of months is subtracted from the result, the final date is not necessarily the

same as the original date.

Time Arithmetic

Times can be subtracted, incremented, or decremented.

Subtracting Times: The result of subtracting one time (TIME2) from another

(TIME1) is a time duration that specifies the number of hours, minutes, and

seconds between the two times. The data type of the result is DECIMAL(6,0). If

TIME1 is greater than or equal to TIME2, TIME2 is subtracted from TIME1. If

TIME1 is less than TIME2, however, TIME1 is subtracted from TIME2, and the sign

of the result is made negative. The following procedural description clarifies the

steps involved in the operation RESULT = TIME1 - TIME2.

If SECOND(TIME2) <= SECOND(TIME1)

then SECOND(RESULT) = SECOND(TIME1) - SECOND(TIME2).

If SECOND(TIME2) > SECOND(TIME1)

then SECOND(RESULT) = 60 + SECOND(TIME1) - SECOND(TIME2).

MINUTE(TIME2) is then incremented by 1.

If MINUTE(TIME2) <= MINUTE(TIME1)

then MINUTE(RESULT) = MINUTE(TIME1) - MINUTE(TIME2).

If MINUTE(TIME2) > MINUTE(TIME1)

then MINUTE(RESULT) = 60 + MINUTE(TIME1) - MINUTE(TIME2).

HOUR(TIME2) is then incremented by 1.

HOUR(RESULT) = HOUR(TIME1) - HOUR(TIME2).

For example, the result of TIME('11:02:26') - '00:32:56' is 102930 (a duration of 10

hours, 29 minutes, and 30 seconds).

Incrementing and Decrementing Times: The result of adding a duration to a

time, or of subtracting a duration from a time, is itself a time. Any overflow or

underflow of hours is discarded, thereby ensuring that the result is always a time.

If a duration of hours is added or subtracted, only the hours portion of the time is

affected. The minutes and seconds are unchanged.

Similarly, if a duration of minutes is added or subtracted, only minutes and, if

necessary, hours are affected. The seconds portion of the time is unchanged.

Chapter 3. Language Elements

Expressions

Adding or subtracting a duration of seconds will, of course, affect the seconds

portion of the time, and potentially the minutes and hours.

Time durations, whether positive or negative, also can be added to and subtracted

from times. The result is a time that has been incremented or decremented by the

specified number of hours, minutes, and seconds, in that order.

For example, TIME1 + X, where X is a DECIMAL(6,0) number, is equivalent to the

expression

TIME1 + HOUR(X) HOURS + MINUTE(X) MINUTES + SECONDS(X) SECONDS

Timestamp Arithmetic

Timestamps can be subtracted, incremented, or decremented.

Subtracting Timestamps: The result of subtracting one timestamp (TS2) from

another (TS1) is a timestamp duration that specifies the number of years, months,

days, hours, minutes, seconds, and microseconds between the two timestamps. The

data type of the result is DECIMAL(20,6). If TS1 is greater than or equal to TS2,

TS2 is subtracted from TS1. If TS1 is less than TS2, however, TS1 is subtracted from

TS2 and the sign of the result is made negative. The following procedural

description clarifies the steps involved in the operation RESULT = TS1 - TS2.

If MICROSECOND(TS2) <= MICROSECOND(TS1) then

MICROSECOND(RESULT) = MICROSECOND(TS1) -

MICROSECOND(TS2).

If MICROSECOND(TS2) > MICROSECOND(TS1)

then MICROSECOND(RESULT) = 1000000 +

MICROSECOND(TS1) - MICROSECOND(TS2),

and SECOND(TS2) is incremented by 1.

The seconds and minutes part of the timestamps are subtracted as specified in the

rules for subtracting times.

If HOUR(TS2) <= HOUR(TS1)

then HOUR(RESULT) = HOUR(TS1) - HOUR(TS2).

If HOUR(TS2) > HOUR(TS1)

then HOUR(RESULT) = 24 + HOUR(TS1) - HOUR(TS2)

and DAY(TS2) is incremented by 1.

The date part of the timestamps is subtracted as specified in the rules for

subtracting dates.

Incrementing and Decrementing Timestamps: The result of adding a duration to

a timestamp, or of subtracting a duration from a timestamp, is itself a timestamp.

Date and time arithmetic is performed as previously defined, except that an

overflow or underflow of hours is carried into the date part of the result, which

must be within the range of valid dates. Microseconds overflow into seconds.

Precedence of Operations

Expressions within parentheses are evaluated first. When the order of evaluation is

not specified by parentheses, prefix operators are applied before multiplication and

division, and multiplication and division are applied before addition and

subtraction. Operators at the same precedence level are applied from left to right.

Example:

SQL Reference

Expressions

1.10

(SALARY + BONUS) + SALARY / :VAR3

Concatenation is performed before datetime arithmetic.

Predicates

A predicate specifies a condition that is true, false, or unknown about a given row

or group.

The following rules apply to all types of predicates:

v All values specified in the same predicate must be compatible.

v The length attribute of a host variable referenced in a predicate must not be

greater than 254 bytes.

v With the exception of the LIKE predicate, a long string column must not be

referenced.

v A view column referenced in a predicate must not be derived from a column

function.

v If a basic predicate or a LIKE predicate contains an operand with a null value,

then it is evaluated as unknown. Other predicates containing negative indicator

values are evaluated according to:

- The rules for defining the predicate in terms of the basic predicates

- The rules for nulls in basic predicates

- The truth tables for logic with three values.

v The value of an indicator variable provided at runtime for a parameter marker

in a predicate must not be negative.

Basic Predicate

►► expression

expression

►◄

(1)

(subselect)

Notes:

Either ¬= or ^= may be used as an alternative to the <> operand in all code pages

supported by the DB2 Server for VSE & VM database manager. However, these

alternatives are not supported in IBM-SQL. Portable applications should use <>.

A basic predicate compares two values.

A subselect in a basic predicate must specify a single result column and must not

return more than one value.

Chapter 3. Language Elements

Basic

If the value of either operand is null or the subselect returns no value, the result of

the predicate is unknown. Otherwise the result is either true or false.

For values x and y:

Predicate

Is True If and Only If...

x = y

x is equal to y

x<> y

x is not equal to y

x < y

x is less than y

x > y

x is greater than y

x>= y

x is greater than or equal to y

x<= y

x is less than or equal to y

Examples:

EMPNO = ’528671’

PRTSTAFF <> :VAR1

SALARY + BONUS + COMM < 20000

SALARY > (SELECT AVG(SALARY) FROM EMPLOYEE)

Quantified Predicate

►► expression

SOME

(subselect)

►◄

(1)

ANY

ALL

Notes:

Either ¬= or ^= may be used as an alternative to the <> operand in all code pages

supported by the DB2 Server for VSE & VM database manager. However, these

alternatives are not supported in IBM-SQL. Portable applications should use <>.

A quantified predicate compares a value with a set of values.

The subselect must specify a single result column and can return any number of

values, including null values.

A quantified predicate has the same form as a basic predicate except that the

second operand is a subselect preceded by SOME, ANY, or ALL.

When ALL is specified, the result of the predicate is:

v true if any of the following are true:

- the subselect returns no values

- the specified relationship is true for every value returned by the subselect

- the subselect returns no value and the first operand is null.

v false if the specified relationship is false for at least one value returned by the

subselect.

v unknown if the specified relationship is not false for any of the values returned

by the subselect and at least one comparison is unknown because of a null

value.

SQL Reference

Quantified

When SOME or ANY is specified, the result of the predicate is:

v true if the specified relationship is true for at least one value returned by the

subselect.

v false if any of the following are true:

- the subselect returns no values

- the specified relationship is false for every value returned by the subselect.

v unknown if the specified relationship is not true for any of the values returned

by the subselect and at least one comparison is unknown because of a null

value.

Use the information below when referring to the following examples.

TBLA: COLA

TBLB: COLB

Example 1

SELECT * FROM TBLA WHERE COLA = ANY(SELECT COLB FROM TBLB)

Results in 2,3. The subselect returns (2,3). COLA in rows 2 and 3 equals at least

one of these values.

Example 2

SELECT * FROM TBLA WHERE

COLA > ANY(SELECT COLB FROM TBLB)

Results in 3,4. The subselect returns (2,3). COLA in rows 3 and 4 is greater than at

least one of these values.

Example 3

SELECT * FROM TBLA WHERE COLA> ALL(SELECT COLB FROM TBLB)

Results in 4. The subselect returns (2,3). COLA in row 4 is the only one that is

greater than both these values.

Example 4

SELECT * FROM TBLA WHERE COLA> ALL(SELECT COLB FROM TBLB WHERE COLB<0)

Results in 1,2,3,4. The subselect returns no values. Thus, the predicate is true for all

rows in TBLA.

BETWEEN Predicate

►► expression

BETWEEN expression AND expression

►◄

NOT

The BETWEEN predicate compares a value with a range of values. The BETWEEN

predicate:

value1 BETWEEN value2 AND value3

is logically equivalent to the search condition:

value1 >= value2 AND value1 <= value3

Chapter 3. Language Elements

BETWEEN

The BETWEEN predicate:

value1 NOT BETWEEN value2 AND value3

is logically equivalent to the search condition:

NOT(value1 BETWEEN value2 AND value3)

that is:

value1 < value2 OR value1 > value3

If any expression evaluates to a datetime data type, then comparisons will be done

with all expressions converted to the appropriate datetime data type.

The values for the expressions in the BETWEEN predicate can have different

CCSID values. If a conversion is necessary then it will be based on the above

logical equivalence. Conversion is based on the rules for comparisons (see

“Conversion Rules for String Comparison” on page 58). If a column’s CCSID is

chosen as the final CCSID value then both the other values are converted, if

necessary, to that CCSID; this need not be true if the value is not a column’s

CCSID.

Example 1

EMPLOYEE.SALARY BETWEEN 20000 AND 40000

Example 2

SALARY NOT BETWEEN 20000 + :HV1 AND 40000

Example 3

Given the following:

┌────────────┬───────────────┬───────┐

│ Expression │ Type

│ CCSID │

├────────────┼───────────────┼───────┤

│ CON_1

│ constant

│ 00001 │

│ HV_2

│ host variable │ 00002 │

│ HV_3

│ host variable │ 00003 │

└────────────┴───────────────┴───────┘

When evaluating the predicate:

CON_1 BETWEEN :HV_2 AND :HV_3

conversion will be based on considering this to be the same as:

CON_1 >= :HV_2 AND CON_1 <= :HV_3

The values in both HV_2 and HV_3 will be converted to CCSID

00001.

Example 4

Given the following:

┌────────────┬───────────────┬───────┐

│ Expression │ Type

│ CCSID │

├────────────┼───────────────┼───────┤

│ CON_1

│ constant

│ 00001 │

│ HV_2

│ host variable │ 00002 │

│ COL_3

│ column

│ 00003 │

└────────────┴───────────────┴───────┘

When evaluating the predicate:

CON_1 BETWEEN :HV_2 AND COL_3

SQL Reference

BETWEEN

conversion will be based on considering this to be the same as:

CON_1 >= :HV_2 AND CON_1 <= COL_3

Because the CCSID of the column (that is, 00003) is used as the final CCSID value,

the values of CON_1 and HV_2 both will be converted to 00003 before any

comparisons are done.

Example 5

Given the following:

┌────────────┬───────────────┬───────┐

│ Expression │ Type

│ CCSID │

├────────────┼───────────────┼───────┤

│ COL_1

│ column

│ 00001 │

│ HV_2

│ host variable │ 00002 │

│ CON_3

│ constant

│ 00003 │

└────────────┴───────────────┴───────┘

When evaluating the predicate:

COL_1 BETWEEN :HV_2 AND CON_3

conversion will be based on considering this to be the same as:

COL_1 >= :HV_2 AND COL_1 <= CON_3

The values in both HV_2 and CON_3 will be converted to CCSID 00001. (Note the

difference in this example’s conversion when using a column and example 4.)

Example 6

Given the following:

┌────────────┬─────────────────┬──────────────┐

│ Expression │ Type

│ Value

│

├────────────┼─────────────────┼──────────────┤

│ COL_1

│ column CHAR(10) │ '01/01/1992' |

└────────────┴─────────────────┴──────────────┘

When evaluating the predicate:

COL_1 BETWEEN '07/20/1991' AND '10/22/1992'

the comparison will be done as character strings and the predicate will evaluate to

false.

When evaluating the predicate:

COL_1 BETWEEN DATE('7/20/1991') AND '10/22/1992'

the comparison will be done as date types and the predicate will evaluate to true.

EXISTS Predicate

►►

EXISTS

(subselect)

►◄

NOT

The EXISTS predicate tests for the existence of certain rows. The subselect may

specify any number of columns, and

v The result is true only if the number of rows specified by the subselect is not

zero

v The result is false only if the number of rows specified by the subselect is zero

Chapter 3. Language Elements

EXISTS

v The result cannot be unknown.

The values returned by the subselect are ignored.

Example: EXISTS (SELECT * FROM EMPLOYEE WHERE SALARY > 60000)

IN Predicate

►► expression

(subselect)

►◄

NOT

(

▼

constant

)

host_variable_list

special_register

The IN predicate compares a value with a set of values.

In the subselect form, the subselect must identify a single result column and may

return any number of values, including null values.

An IN predicate of the form:

expression IN (subselect)

is equivalent to a quantified predicate of the form:

expression = ANY (subselect)

An IN predicate of the form:

expression NOT IN (subselect)

is equivalent to a quantified predicate of the form:

expression <> ALL (subselect)

If any value evaluates to a datetime data type, then comparisons will be done with

all values converted to the appropriate datetime data type.

In the non-subselect form of the IN predicate, the second operand is a set of one or

more values specified by any combination of constants, host variables, host

structures, or special registers. This form of the IN predicate is equivalent to the

subselect form except that the second operand consists of the specified values

rather than the values returned by a subselect.

The values for the expressions in the IN predicate can have different CCSIDs.

Conversion occurs where required based on the assumption that:

value1 IN (value2, value3, ...)

is logically equivalent to the clause:

value1 = value2

OR value1 = value3

OR ...

Conversion is based on the rules for comparisons (see “Conversion Rules for String

Comparison” on page 58).

Examples

SQL Reference

Example 1

DEPTNO IN (’D01’, ’B01’, ’C01’)

Example 2

EMPNO IN (SELECT EMPNO FROM EMPLOYEE WHERE WORKDEPT = ’E11’)

Example 3

Given the following:

┌────────────┬───────────────┬───────┐

│ Expression │ Type

│ CCSID │

├────────────┼───────────────┼───────┤

│ COL_1

│ column

│ 00001 │

│ HV_2

│ host variable │ 00002 │

│ HV_3

│ host variable │ 00003 │

│ CON_4

│ constant

│ 00004 │

└────────────┴───────────────┴───────┘

When evaluating the predicate:

COL_1 IN (:HV_2, :HV_3, CON_4)

conversion will be based on considering this to be the same as:

COL_1 = :HV_2 OR COL_1 = :HV_3 OR COL_1 = CON_4

The values in HV_2, HV_3, and CON_4 will be converted to CCSID

00001.

Example 4

Given the following:

┌────────────┬───────────────┬───────┐

│ Expression │ Type

│ CCSID │

├────────────┼───────────────┼───────┤

│ HV_1

│ host variable │ 00001 │

│ CON_2

│ constant

│ 00002 │

│ CON_3

│ constant

│ 00002 │

│ HS_4

│ host structure│

│

HV_41

│ host variable │ 00003 │

│

HV_42

│ host variable │ 00004 │

└────────────┴───────────────┴───────┘

When evaluating the predicate:

:HV_1 IN ( CON_2, CON_3, :HS_4)

conversion will be based on considering this to be the same as:

:HV_1 = CON_2 OR :HV_1 = CON_3 OR :HV_1 = :HV_41 OR :HV_1 = :HV_42

Thus, the value in HV_1 will be converted to CCSID 00002 before it is compared to

CON_2 and CON_3, and the values in HV_41 and HV_42 will be converted to

CCSID 00001 before they are compared to HV_1.

Chapter 3. Language Elements

LIKE Predicate

►► column_name

USER

►

NOT

host_variable

string_constant

►

►◄

ESCAPE

host_variable

string_constant

The LIKE predicate searches for strings that have a certain pattern. The pattern is

specified by a string in which the underscore and percent sign have special

meanings.

The column_name must identify a string column. If a character string column is

identified, the other operands must be character strings. If a graphic string column

is identified, the other operands must be graphic strings. With character strings,

the terms character, percent sign, and underscore in the following description refer to

single-byte characters. With graphic strings, the terms refer to double-byte

characters.

Note that trailing blanks in a pattern are usually part of the pattern. The exception

to this is that trailing blanks in a pattern that is specified within a fixed-length host

variable are ignored when that pattern is compared against a varying-length

column.

Simple Description

For character columns, a simple description of the LIKE pattern is as follows:

v The underscore sign (_) represents any single character.

v The percent sign (%) represents a string of zero or more characters.

v Any other character represents itself.

Rigorous Description

Let x denote a value of a column and y denote the string specified by the second

operand.

The string y is interpreted as a sequence of the minimum number of substring

specifiers so each character of y is part of exactly one substring specifier. A

substring specifier is an underscore, a percent sign, or any non-empty sequence of

characters other than an underscore or a percent sign.

The result of the predicate is unknown if x or y is the null value. Otherwise, the

result is either true or false. The result is true if x and y are both empty strings or

if there exists a partitioning of x into substrings such that:

v A substring of x is a sequence of zero or more contiguous characters and each

character of x is part of exactly one substring.

v If the nth substring specifier is an underscore, the nth substring of x is any

single character.

v If the nth substring specifier is a percent sign, the nth substring of x is any

sequence of zero or more characters.

v If the nth substring specifier is neither an underscore nor a percent sign, the nth

substring of x is equal to that substring specifier and has the same length as that

substring specifier.

SQL Reference

v The number of substrings of x is the same as the number of substring specifiers.

It follows that if y is an empty string and x is not an empty string, the result is

false.

The predicate x NOT LIKE y is equivalent to the search condition NOT(x LIKE y).

If the CCSID of either the pattern value or the escape value is different than the

CCSID of the column, that value is converted to adhere to the CCSID of the

column before the predicate is applied.

With Mixed Data

If the column has a mixed subtype, the pattern can include both SBCS and DBCS

characters. The special characters in the pattern are interpreted as follows:

v An SBCS underscore refers to one SBCS character.

v A DBCS underscore refers to one DBCS character.

v A percent (either SBCS or DBCS) refers to any number of characters of any type,

either SBCS or DBCS.

v Any redundant shifts in either column values or the pattern value are ignored.

With a Field Procedure

If the column has a field procedure, the procedure is invoked to decode the values

of the column, and the comparisons are made with the decoded values.

The ESCAPE Clause

This clause allows the definition of patterns intended to match values that contain

the actual percent and underscore characters. The following rules govern the use of

the ESCAPE clause:

v If a character string column is identified, the escape character must be a

character string constant or variable of length 1.

v If a graphic string column is identified, the escape character must be a graphic

string constant or variable of length 1.

v If the ESCAPE host_variable has a negative indicator variable, the result of the

predicate is unknown.

v The host_variable or string_constant forming the pattern must not contain the

escape character except when followed by the escape character, '%' or '_'.

For example, if '+' is the escape character, any occurrences of '+' other than '++',

'+_', or '+%' in the pattern is an error.

v An escape clause cannot be used with a pattern having a mixed subtype.

If both the pattern and the escape character are constants, the entire pattern will

always be checked for incorrect occurrences of the escape character.

If either the pattern or the escape character is a host_variable, occurrences of the

escape character in the pattern will not be validated unless the portion of the

pattern proceeding the escape character matches at least one row.

USER as a Pattern

The rules for the LIKE predicate are unchanged with the special register USER.

This means that the value of the special register USER is treated as a pattern.

USER evaluates to a CHAR(8) string whose value is the user ID of the currently

connected user. If the value of USER contains a '_' it will match any character and

the result of:

WHERE C1 LIKE USER

Chapter 3. Language Elements

would not be the same as the result of:

WHERE C1 = USER

It is recommended that the 'equals' predicate be used where user IDs may contain

special characters, and the value of USER is not to be treated as a pattern.

Examples:

Example 1: Search for the string ‘SYSTEMS’ appearing anywhere within the

PROJNAME column in the PROJECT table.

PROJECT.PROJNAME LIKE '%SYSTEMS%'

Example 2: Search for a string with a first character of ‘J’ that is exactly two

characters long in the FIRSTNME column of the EMPLOYEE table.

EMPLOYEE.FIRSTNME LIKE 'J_'

Example 3: In:

C1 LIKE ’AAAA+%BBB%’ ESCAPE ’+’

'+' is the escape character and indicates that the search is for a string that starts

with 'AAAA%BBB'. The '+%' is interpreted as a single occurrence of '%' in the

pattern.

Example 4::

both: WHERE COL1 LIKE ’aaa<▌AABB▐%%▌CC▐>’

and : WHERE COL1 LIKE ’aaa<▌AABB▐>%<▌CC▐>’

would match the value

-->’aaa<▌AABBDDZZCC▐>’

as well as the value

-->’aaa<▌AABB▐>dzx<▌CC▐>’

Example 5::

WHERE COL1 LIKE ’a%<▌CC▐>’

would match the values -->

’a<▌CC▐>’

and

’ax<▌CC▐>’ and

’ab<▌DDEE▐>fg<▌CC▐>’

Example 6::

WHERE COL1 LIKE ’a_<▌CC▐>’

would match the value

-->

’ax<▌CC▐>’

but not the value

-->

’a<▌XXCC▐>’

Example 7::

WHERE COL1 LIKE ’a<__▌CC▐>’

would match the value

-->

’a<▌XXCC▐>’

but not the value

-->

’ax<▌CC▐>’

Example 8::

WHERE COL1 LIKE ’<>’

would match the "empty string" value.

Example 9::

WHERE COL1 LIKE ’ab<▌CC▐>_’

would match the values -->

’ab<▌CC▐>d and

’ab<><▌CC▐>d

SQL Reference

NULL

NULL Predicate

►► column_name IS

NULL

►◄

NOT

The NULL predicate tests for null values.

The result of a NULL predicate cannot be unknown. If the value of the column is

null, the result is true. If the value is not null, the result is false. If NOT is

specified, the result is reversed.

To search for fields that contain null values, the words IS NULL must be used.

'WHERE PAY IS NULL' is correct, but 'WHERE PAY = NULL' is incorrect.

Examples:

EMPLOYEE.PHONE IS NULL

SALARY IS NOT NULL

Search Conditions

►►

predicate

►

NOT

(search_condition)

► ▼

►◄

AND

predicate

NOT

(search_condition)

A search condition specifies a condition that is true, false, or unknown about a given

row or group. When the condition is “true,” the row or group qualifies for the

results. When the condition is “false” or “unknown,” the row or group does not

qualify.

The result of a search condition is derived by application of the specified logical

operators (AND, OR, NOT) to the result of each specified predicate. If logical

operators are not specified, the result of the search condition is the result of the

specified predicate.

AND and OR are defined in the following table in which P and Q are any

predicates:

Table 5. Truth Tables for AND and OR

P AND Q

P OR Q

True

False

True

Unknown

True

False

True

False

True

Chapter 3. Language Elements

NULL

Table 5. Truth Tables for AND and OR (continued)

P AND Q

P OR Q

False

Unknown

False

Unknown

True

Unknown

True

Unknown

False

Unknown

NOT(true) is false, NOT(false) is true, and NOT(unknown) is unknown.

Search conditions within parentheses are evaluated first. If the order of evaluation

is not specified by parentheses, NOT is applied before AND, and AND is applied

before OR. The order in which operators at the same precedence level are

evaluated is undefined to allow for optimization of search conditions.

Examples:

Example 1

MAJPROJ = ' MA2100 '

AND

DEPTNO = ' D11 '

DEPTNO = ' B03 '

DEPTNO = ' E11 '

2 or 3

Example 2

MAJPROJ = ' MA2100 ' AND DEPTNO = ' D11 ' OR DEPTNO = ' B03 ' OR DEPTNO = ' E11 '

SQL Reference

Chapter 4. Functions

A function is an operation denoted by a function name followed by one or more

operands which are enclosed in parentheses. The operands of functions are called

arguments. Most functions have a single argument that is specified by an expression.

The result of a function is a single value derived by applying the function to the

result of the expression.

Functions are classified as column functions or scalar functions. The argument of a

column function is a set of values. An argument of a scalar function is a single

value. If multiple arguments are allowed, each argument is a single value.

In the syntax of SQL, the term function is used only in the definition of an

expression. Thus a function can be used only where an expression can be used.

Additional restrictions apply to the use of column functions as specified in the

following section and in Chapter 5, “Queries,” on page 121.

Column Functions

The following information applies to all column functions, except for the

COUNT(*) variation of the COUNT function.

The argument of a column function is a set of values derived from one or more

columns. The scope of the set is a group or an intermediate result table as

explained in Chapter 5, “Queries,” on page 121. For example, the result of the

following SELECT statement is the number of distinct values of JOB for employees

in department D01:

SELECT COUNT(DISTINCT JOB)

FROM EMPLOYEE

WHERE WORKDEPT = ’D01’

The keyword DISTINCT is not considered an argument of the function but rather a

specification of an operation that is performed before the function is applied. If

DISTINCT is specified, duplicate values are eliminated. If ALL is implicitly or

explicitly specified, duplicate values are not eliminated.

The DISTINCT operation can only be applied to values of a column. If DISTINCT

is omitted, the values of the arguments are specified by an expression. That

expression must not include a column function and must include at least one

column-name, a requirement that is not satisfied by a reference to a view column

derived from a constant or expression without a column-name. If a column_name is

a correlated reference (which is allowed in a subquery of a HAVING clause) the

expression must not include operators.

AVG

ALL

►► AVG

(

numeric_expression

)

►◄

DISTINCT column_name

The AVG function returns the average of a set of numbers.

AVG

The argument values must be numbers and their sum must be within the range of

the data type of the result. The result can be null.

The data type of the result is the same as the data type of the argument values,

except that:

v The result is a double-precision floating-point if the argument values are

single-precision floating-point.

v The result is a large integer if the argument values are small integers.

If the data type of the argument values is decimal with precision p and scale s, the

precision of the result is 31 and the scale is 31-p+s. Negative scale is not allowed.

The function is applied to the set of values derived from the argument values by

the elimination of null values. If DISTINCT is specified, duplicate values are

eliminated.

If the function is applied to an empty set, the result is a null value. Otherwise, the

result is the average value of the set.

The order in which the summation part of the operation is performed is undefined,

but every intermediate result must be within the range of the result data type.

If the type of the result is integer, the fractional part of the average is lost.

Examples

Example 1: Using the PROJECT table, set the host variable AVERAGE

(decimal(5,2)) to the average staffing level (PRSTAFF) of projects in department

(DEPTNO) ‘D11’.

SELECT AVG(PRSTAFF)

INTO :AVERAGE

FROM PROJECT

WHERE DEPTNO = ’D11’

Results in AVERAGE being set to 4.25 (that is, 17 / 4) when using the sample

table.

Example 2: Using the PROJECT table, set the host variable ANY_CALC to the

average of each unique staffing level value (PRSTAFF) of projects in department

(DEPTNO) ‘D11’.

SELECT AVG(DISTINCT PRSTAFF)

INTO :ANY_CALC

FROM PROJECT

WHERE DEPTNO = ’D11’

Results in ANY_CALC being set to 4.66 (that is, 14 / 3) when using the sample

table.

COUNT

►► COUNT

( DISTINCT column_name

)

►◄

(*)

The COUNT function returns the number of rows or values in a set of rows or

values.

SQL Reference

COUNT

The column_name must not identify a long string column. The result of the function

is a large integer and must be within the range of large integers. The result cannot

be null.

The argument of COUNT(*) is a set of rows. The result is the number of rows in

the set.

The argument of COUNT(DISTINCT column_name) is a set of values. The function

is applied to the set of values derived from the argument values by the elimination

of null values and duplicate values. The result is the number of values in the set.

Examples

Example 1: Using the EMPLOYEE TABLE, set the host variable FEMALE (int) to

the number of rows where the value of the SEX column is ‘F’.

SELECT COUNT(*)

INTO :FEMALE

FROM EMPLOYEE

WHERE SEX = ’F’

Results in FEMALE being set to 13 when using the sample table.

Example 2: Using the EMPLOYEE table, set the host variable FEMALE_IN_DEPT

(int) to the number of departments (WORKDEPT) that have at least one female as

a member.

SELECT COUNT(DISTINCT WORKDEPT)

INTO :FEMALE_IN_DEPT

FROM EMPLOYEE

WHERE SEX = ’F’

Results in FEMALE_IN_DEPT being set to 5 when using the sample table. (There

is at least one female in departments A00, C01, D11, D21, and E11.)

MAX

ALL

►► MAX

(

expression

)

►◄

(1)

DISTINCT

column_name

Notes:

Although it is allowed, the keyword DISTINCT does not affect the result of the

function.

The MAX function returns the maximum value in a set of values.

The argument values can be any values other than long strings.

The data type and length attribute of the result are the same as the data type and

length attribute of the argument values. When the argument is a string, the result

has the same CCSID as the argument. The result can be null.

The function is applied to the set of values derived from the argument values by

the elimination of null values.

Chapter 4. Functions

MAX

If the function is applied to an empty set, the result is a null value. Otherwise, the

result is the maximum value in the set.

Examples

Example 1: Using the EMPLOYEE table, set the host variable MAX_SALARY

(decimal(7,2)) to the maximum monthly salary (SALARY / 12) value.

SELECT MAX(SALARY) /12

INTO :MAX_SALARY

FROM EMPLOYEE

Results in MAX_SALARY being set to 4395.83 when using the sample table.

Example 2: Using the PROJECT table, set the host variable LAST_PROJ (char(24))

to the project name (PROJNAME) that comes last in the collating sequence.

SELECT MAX(PROJNAME)

INTO :LAST_PROJ

FROM PROJECT

Results in LAST_PROJ being set to ‘WELD LINE PLANNING’ when using the

sample table.

MIN

ALL

►► MIN

(

expression

)

►◄

(1)

DISTINCT

column_name

Notes:

Although it is allowed, the keyword DISTINCT does not affect the result of the

function.

The MIN function returns the minimum value in a set of values.

The argument values can be any values other than long strings.

The data type and length attribute of the result are the same as the data type and

length attribute of the argument values. When the argument is a string, the result

has the same CCSID as the argument. The result can be null.

The function is applied to the set of values derived from the argument values by

the elimination of null values.

If the function is applied to an empty set, the result is a null value. Otherwise, the

result is the minimum value in the set.

Examples

Example 1: Using the EMPLOYEE table, set the host variable COMM_SPREAD

(decimal(7,2)) to the difference between the maximum and minimum commission

(COMM) for the members of department (WORKDEPT) ‘D11’.

SELECT MAX(COMM) - MIN(COMM)

INTO :COMM_SPREAD

FROM EMPLOYEE

WHERE WORKDEPT

= ’D11’

SQL Reference

MIN

Results in COMM_SPREAD being set to 1118 (that is, 2580 - 1462) when using the

sample table.

Example 2: Using the PROJECT table, set the host variable FIRST_FINISHED

(char(10)) to the estimated ending date (PRENDATE) of the first project scheduled

to be completed.

SELECT MIN(PRENDATE)

INTO :FIRST_FINISHED

FROM PROJECT

Results in FIRST_FINISHED being set to ‘1982-09-15’ when using the sample table.

SUM

ALL

►► SUM

(

numeric_expression

)

►◄

DISTINCT column_name

The SUM function returns the sum of a set of numbers.

The argument values must be numbers and their sum must be within the range of

the data type of the result.

The data type of the result is the same as the data type of the argument values

except that the result is a large integer if the argument values are small integers

and double precision floating-point if the argument values are single precision

floating-point. If the data type of the argument values is decimal, the precision of

the result is 31 and the scale is the same as the scale of the argument values. The

result can be null.

The function is applied to the set of values derived from the argument values by

the elimination of null values. If DISTINCT is specified, duplicate values are

eliminated.

If the function is applied to an empty set, the result is a null value. Otherwise, the

result is the sum of the values in the set.

Examples

Example 1: Using the EMPLOYEE table, set the host variable JOB_BONUS

(decimal(9,2)) to the total bonus (BONUS) paid to clerks (JOB=‘CLERK’).

SELECT SUM(BONUS)

INTO :JOB_BONUS

FROM EMPLOYEE

WHERE JOB = ’CLERK’

Results in JOB_BONUS being set to 2800 when using the sample table.

Example 2: Assume that a table SALES has the following columns and values:

Name:

CUSTOMER

SALES

MONTHS

Type:

smallint

int

Desc:

Customer number

Total value of

Number of months

purchases by this

that customer has

customer

bought something

Chapter 4. Functions

SUM

Name:

CUSTOMER

SALES

MONTHS

Values:

101

1000

102

500

103

300

Set the host variable TOT_AVG_SALE (integer) to the sum of the average monthly

sales per customer.

SELECT SUM(SALES / MONTHS)

INTO :TOT_AVG_SALE

FROM SALES

Results in TOT_AVG_SALE being set to 800. Note that the expression for each row

is calculated before it is added to the sum.

Scalar Functions

A scalar function can be used wherever an expression can be used. The restrictions

on the use of column functions do not apply to scalar functions. For example, the

argument of a scalar function can be a function; that is, scalar functions can be

nested. However, the restrictions that apply to the use of expressions and column

functions also apply when an expression or column function is used within a

scalar function. For example, the argument of a scalar function can be a column

function only if a column function is allowed in the context in which the scalar

function is used.

The restrictions on the use of column functions do not apply to scalar functions

because a scalar function is applied to a single value rather than a set of values.

For example, the result of the following SELECT statement has as many rows as

there are employees in department D11:

SELECT EMPNO, LASTNAME, YEAR(CURRENT DATE - BIRTHDATE)

FROM EMPLOYEE

WHERE WORKDEPT = ’D11’

CHAR

►► CHAR

(

date_expression

)

►◄

time_expression

,ISO

,USA

,EUR

,JIS

,LOCAL

timestamp_expression

decimal_expression

The CHAR function returns a string representation of a datetime value or decimal

value.

The first argument must be a decimal number, timestamp, date, or time. The

second argument, if applicable, is the name of a string format.

The result of the function is a fixed-length character string. The CCSID of the

string is the default CCSID (based on the default subtype value, CHARSUB) of the

SQL Reference

CHAR

application server. If the first argument can be null, the result can be null; if the

first argument is null, the result is the null value.

The other rules depend on the data type of the first argument:

If the first argument is a decimal number:

The second argument must not be specified. The result is the fixed length

character string representation of the argument. The first character of the result

is a minus sign if the argument is negative; otherwise, the first character is

blank.

The result includes a decimal point, sign, and p digits, where p is the precision

of the argument. The length of the result is 2+p.

If the first argument is a timestamp:

The second argument is not applicable and must not be specified.

The result is the character string representation of the timestamp. The length of

the result is 26.

If the first argument is a date:

Omission of the second argument is an implicit specification of the string format

specified at installation time. The installation default for the string format can be

overridden by preprocessor options. If LOCAL is implicitly or explicitly

specified, a date installation exit must be installed.

The result is the character string representation of the date in the format

specified by the second argument. If LOCAL is specified, the length of the result

is the length specified in the SYSOPTIONS catalog during start-up. Otherwise,

the length of the result is 10.

If the first argument is a time:

Omission of the second argument is an implicit specification of the string format

specified at installation time. The installation default can be overridden by

preprocessor options. If LOCAL is implicitly or explicitly specified, a time exit

must be installed.

The result is the character string representation of the time in the format

specified by the second argument. If LOCAL is specified, the length of the result

is the length specified in the SYSOPTIONS catalog during start-up. Otherwise,

the length of the result is 8.

Examples

Example 1: Assume the column PRSTDATE has an internal value equivalent to

1988-12-25.

CHAR(PRSTDATE, USA)

Results in the value ‘12/25/1988’.

Example 2: Assume the column STARTING has an internal value equivalent to

17.12.30, and the host variable HOUR_DUR (decimal(6,0)) is a time duration with a

value of 050000 (that is, 5 hours).

CHAR(STARTING, USA)

Results in the value ‘5:12 PM’.

CHAR(STARTING + :HOUR_DUR, USA)

Results in the value ‘10:12 PM’.

Chapter 4. Functions

CHAR

Example 3: Assume the column RECEIVED (timestamp) has an internal value

equivalent to the combination of the PRSTDATE and STARTING columns.

CHAR(RECEIVED)

Results in the value ‘1988-12-25-17.12.30.000000’.

DATE

►► DATE

( expression

)

►◄

The DATE function returns a date from a value.

The argument must be a timestamp, a date, a positive number less than or equal to

3652059, a valid string representation of a date, or a character string of length 7.

If the argument is a character string of length 7, it must represent a valid date in

the form yyyynnn, where yyyy are digits denoting a year, and nnn are digits

between 001 and 366 denoting a day of that year.

The result of the function is a date. The data type is DATE. If the argument can be

null, the result can be null; if the argument is null, the result is the null value.

The other rules depend on the data type of the argument:

v If the argument is a timestamp:

The result is the date part of the timestamp.

v If the argument is a date:

The result is that date.

v If the argument is a number:

The result is the date that is n-1 days after January 1, 0001, where n is the

number that would occur if the INTEGER function were applied to the

argument.

v If the argument is a character string:

The result is the date represented by the character string.

Notes:

1. When a string representation of a date is SBCS with a CCSID that is not the

same as the default CCSID for SBCS data, that value is converted to adhere

to the default CCSID for SBCS data before it is interpreted and converted to

a date value.

2. When a string representation of a date is mixed with a CCSID that is not the

same as the default CCSID for mixed data, that value is converted to adhere

to the default CCSID for mixed data before it is interpreted and converted to

a date value.

Examples

Example 1: Assume that the column RECEIVED (timestamp) has an internal

value equivalent to ‘1988-12-25-17.12.30.000000’.

DATE(RECEIVED)

Results in an internal representation of ‘1988-12-25’.

Example 2:

SQL Reference

DATE

DATE(’1988-12-25’)

Results in an internal representation of ‘1988-12-25’.

DATE(’25.12.1988’)

Results in an internal representation of ‘1988-12-25’.

DATE(35)

Results in an internal representation of ‘0001-02-04’.

DAY

►► DAY

(

date_expression

)

►◄

timestamp_expression

date_duration_expression

timestamp_duration_expression

The DAY function returns the day part of a value.

The argument must be a date, timestamp, date duration, or timestamp duration. If

a decimal number, the argument must be:

v DECIMAL(8,0) for date duration

v DECIMAL(20,6) for timestamp duration

to be properly interpreted.

The result of the function is a large integer. If the argument can be null, the result

can be null; if the argument is null, the result is the null value.

The other rules depend on the data type of the argument:

v If the argument is a date or a timestamp:

The result is the day part of the value, which is an integer between 1 and 31.

v If the argument is a date duration or timestamp duration:

The result is the day part of the value, which is an integer between -99 and 99.

A nonzero result has the same sign as the argument.

Examples

Example 1: Using the PROJECT table, set the host variable END_DAY (smallint)

to the day that the WELD LINE PLANNING project (PROJNAME) is scheduled to

stop (PRENDATE).

SELECT DAY(PRENDATE)

INTO :END_DAY

FROM PROJECT

WHERE (PROJNAME) = ’WELD LINE PLANNING’

Results in END_DAY being set to 15 when using the sample table.

Example 2: Assume that the column DATE1 (date) has an internal value

equivalent to 2000-03-15 and the column DATE2 (date) has an internal value

equivalent to 1999-12-31.

DAY(DATE1 - DATE2)

Results in the value 15.

Chapter 4. Functions

DAYS

►► DAYS

(

date_expression

)

►◄

timestamp_expression

date_string_expression

The DAYS function returns an integer representation of a date.

The argument must be a date, a timestamp, or a valid string representation of a

date.

Notes:

1. When a string representation of a date is SBCS with a CCSID that is not the

same as the default CCSID for SBCS data, that value is converted to adhere to

the default CCSID for SBCS data before it is interpreted and converted to a

date value.

2. When a string representation of a date is mixed with a CCSID that is not the

same as the default CCSID for mixed data, that value is converted to adhere to

the default CCSID for mixed data before it is interpreted and converted to a

date value.

The result of the function is a large integer. If the argument can be null, the result

can be null; if the argument is null, the result is the null value.

The result is 1 more than the number of days from January 1, 0001 to D, where D

is the date that would occur if the DATE function were applied to the argument.

Examples

Example 1: Using the PROJECT table, set the host variable EDUCATION_DAYS

(int) to the number of elapsed days (PRENDATE - PRSTDATE) estimated for the

project (PROJNO) ‘IF2000’.

SELECT DAYS(PRENDATE) - DAYS(PRSTDATE)

INTO :EDUCATION_DAYS

FROM PROJECT

WHERE (PROJNO) = ’IF2000’

Results in EDUCATION_DAYS being set to 396 when using the sample table.

Example 2: Using the PROJECT table, set the host variable TOTAL_DAYS (int) to

the sum of elapsed days (PRENDATE - PRSTDATE) estimated for all projects in

department (DEPTNO) ‘E21’.

SELECT SUM(DAYS(PRENDATE) - DAYS(PRSTDATE))

INTO :TOTAL_DAYS

FROM PROJECT

WHERE (DEPTNO) = ’E21’

Results in TOTAL_DAYS being set to 1584 when using the sample table.

100

SQL Reference

DECIMAL

►► DECIMAL

( numeric_expression

►

,precision_integer

,scale_integer

► )

►◄

The DECIMAL function returns a decimal representation of a number.

numeric_expression

An expression that returns a value of any numeric data type.

precision_integer

An integer constant with a value in the range of 1 to 31.

The default for the precision_integer depends on the data type of the

numeric_expression:

15 for floating-point and decimal

11 for large integer

5 for small integer.

scale_integer

An integer constant in the range of 0 to the precision_integer value.

The result of the function is a decimal number with precision of p and scale of s,

where p and s are the second and third arguments. If the first argument can be

null, the result can be null; if the first argument is null, the result is the null value.

The result is the same number that would occur if the first argument were

assigned to a decimal column or variable with a precision of p and a scale of s. An

error occurs if the number of significant decimal digits required to represent the

whole part of the number is greater than p-s.

Examples

Example 1: Use the DECIMAL function in order to force a DECIMAL data type

(with a precision of 5 and a scale of 2) to be returned in a select-list for the

EDLEVEL column (data type = SMALLINT) in the EMPLOYEE table. The EMPNO

column should also appear in the select list.

SELECT EMPNO, DECIMAL(EDLEVEL,5,2)

FROM EMPLOYEE

Example 2: Assume the host variable PERIOD is of type INTEGER. Then, in order

to use its value as a date duration it must be ″cast″ as decimal(8,0).

SELECT PRSTDATE + DECIMAL(:PERIOD,8)

FROM PROJECT

DIGITS

►► DIGITS

(

integer_expression

)

►◄

decimal_expression

The DIGITS function returns a character string representation of a number.

Chapter 4. Functions

101

DIGITS

The argument is an expression that returns a value of an integer, small integer, or

decimal data type.

The result of the function is a fixed-length character string. The CCSID of the

string is the default CCSID (based on the default subtype value, CHARSUB) of the

application server. If the argument can be null, the result can be null; if the

argument is null, the result is the null value.

The result is a string of digits that represents the absolute value of the argument

without regard to its scale. Thus, the result does not include a sign or a decimal

point. The result includes any necessary leading zeros so that the length of the

string is:

5 if the argument is a small integer

10 if the argument is a large integer

v p if the argument is a decimal number with a precision of p.

Examples

Example 1: Using the EMP_ACT table, set the host variable TIME_DISPLAY

(char(5)) to the time (EMPTIME) that employee number (EMPNO) ‘000130’ is to

spend on an activity (ACTNO) 90.

SELECT DIGITS(EMPTIME)

INTO :TIME_DISPLAY

FROM EMP_ACT

WHERE EMPNO = ’000130’ AND ACTNO = 90

TIME_DISPLAY will be set to ’00100’ when using the sample table.

Example 2: Return activity number (ACTNO) from the EMP_ACT table as a

character string in a select list. The EMPNO and PROJNO columns should also

appear in the select list.

SELECT EMPNO, PROJNO, DIGITS(ACTNO)

FROM EMP_ACT

FLOAT

►► FLOAT

( numeric_expression

)

►◄

The FLOAT function returns a floating-point representation of a number.

The argument is an expression that returns a value of any numeric data type.

The result of the function is a double precision floating-point number. If the

argument can be null, the result can be null; if the argument is null, the result is

the null value.

The result is the same number that would occur if the argument were assigned to

a double precision floating-point column or variable.

Example

Using the EMPLOYEE table, find the ratio of salary to commission for employees

whose commission is not zero. The columns involved (SALARY and COMM) have

DECIMAL data types. To eliminate the possibility of out-of-range results, FLOAT is

applied to SALARY so that the division is carried out in floating point:

102

SQL Reference

FLOAT

SELECT EMPNO, FLOAT(SALARY)/COMM

FROM EMPLOYEE

WHERE COMM > 0

HEX

►► HEX

(expression)

►◄

The HEX function returns a hexadecimal representation of a value.

The argument is an expression that returns a value of any data type other than a

long string.

The result of the function is a character string. The CCSID of the string is the

default CCSID (based on the default subtype value, CHARSUB) of the application

server. If the argument can be null, the result can be null; if the argument is null,

the result is the null value.

The result is a string of hexadecimal digits. The first two represent the first byte of

the argument, the next two represent the second byte of the argument, and so

forth. If the argument is a datetime value, the result is the hexadecimal

representation of the internal form of the argument.

If the argument is a single-byte character string (SBCS), the length of the argument

must be 127 or less, and the length of the result is twice the defined (maximum)

length of the argument. If the argument is a double-byte character string (DBCS),

the length of the argument must be 63 or less, and the length of the result is four

times the defined (maximum) length of the argument.

The result is fixed-length if the argument is fixed length. If the argument is

varying-length, the result is also varying-length.

Examples

Example 1: Using the DEPARTMENT table set the host variable HEX_MGRNO

(char(12)) to the hexadecimal representation of the manager number (MGRNO) for

the ‘PLANNING’ department (DEPTNAME).

SELECT HEX(MGRNO)

INTO :HEX_MGRNO

FROM DEPARTMENT

WHERE DEPTNAME = ’PLANNING’

HEX_MGRNO will be set to ’F0F0F0F0F2F0’ when using the sample table.

Example 2: Suppose COL_1 is a column with a data type of char(1) and a value

of 'B'. The hexadecimal representation of the letter 'B' is X'C2'. HEX(COL_1) returns

a two-character string 'C2'.

Example 3: Suppose COL_3 is a column with a data type of decimal(6,2) and a

value of 40.1. HEX(COL_3) returns the internal representation, an eight-character

string '0004010C'.

Chapter 4. Functions

103

HOUR

►► HOUR

(

time_expression

)

►◄

timestamp_expression

time_duration_expression

timestamp_duration_expression

The HOUR function returns the hour part of a value.

The argument must be a time, timestamp, time duration, or timestamp duration. If

a decimal number, the argument must be:

v DECIMAL(6,0) for time duration

v DECIMAL(20,6) for timestamp duration

to be properly interpreted.

The result of the function is a large integer. If the argument can be null, the result

can be null; if the argument is null, the result is the null value.

The other rules depend on the data type of the argument:

v If the argument is a time or timestamp:

The result is the hour part of the value, which is an integer between 0 and 24.

v If the argument is a time duration or timestamp duration:

The result is the hour part of the value, which is an integer between -99 and 99.

A nonzero result has the same sign as the argument.

Example

Using the CL_SCHED sample table, select all the classes that start in the afternoon.

SELECT * FROM CL_SCHED

WHERE HOUR(STARTING) BETWEEN 12 AND 17

INTEGER

►► INTEGER

( numeric_expression

)

►◄

The INTEGER function returns an integer representation of a number.

The argument is an expression that returns a value of any numeric data type.

The result of the function is a large integer. If the argument can be null, the result

can be null; if the argument is null, the result is the null value.

The result is the same number that would occur if the argument were assigned to

a large integer column or variable. If the whole part of the argument is not within

the range of integers, an error occurs. The decimal part of the argument is

truncated if present.

Example

Using the EMPLOYEE table, select a list containing salary (SALARY) divided by

education level (EDLEVEL). Truncate any decimal in the calculation. The list

should also contain the values used in the calculation and employee number

(EMPNO). The list should be in descending order of the calculated value.

104

SQL Reference

INTEGER

SELECT INTEGER(SALARY / EDLEVEL), SALARY, EDLEVEL, EMPNO

FROM EMPLOYEE

ORDER BY 1 DESC

LENGTH

►► LENGTH

( expression

)

►◄

The LENGTH function returns the length of a value.

The argument is an expression that returns a value of any data type. The

expression cannot be a long string host variable.

The result of the function is a large integer. If the argument can be null, the result

can be null; if the argument is null, the result is the null value.

The result is the length of the argument. The length of strings includes blanks. The

length of a varying-length string is the actual length, not the maximum length.

The length of a graphic string is the number of DBCS characters. The length of all

other values is the number of bytes used to represent the value:

2 for small integer

4 for large integer

v The integer part of (p/2)+1 for packed decimal numbers with precision p

4 for single-precision float

8 for double-precision float

v The length of the string for character strings

4 for date

3 for time

10 for timestamp

Note that no special consideration is given for mixed character strings. Shift-in,

shift-out, and each byte of a DBCS character within a mixed string are all

considered to be single bytes.

Examples

Example 1: Assume the host variable ADDRESS is a varying-length character

string with a value of ‘895 Don Mills Road’.

LENGTH(:ADDRESS)

Returns the value 18.

Example 2: Assume that START_DATE is a column of type DATE.

LENGTH(START_DATE)

Returns the value 4.

Example 3: Assume that START_DATE is a column of type DATE.

LENGTH(CHAR(START_DATE, EUR))

Returns the value 10.

Chapter 4. Functions

105

MICROSECOND

►► MICROSECOND

(

timestamp_expression

)

►◄

timestamp_duration_expression

The MICROSECOND function returns the microsecond part of a value.

The argument must be a timestamp or timestamp duration. If a decimal number,

the argument must be DECIMAL(20,6) for timestamp duration to be properly

interpreted.

The result of the function is a large integer. If the argument can be null, the result

can be null; if the argument is null, the result is the null value.

The other rules depend on the data type of the argument:

v If the argument is a timestamp:

The result is the microsecond part of the value, which is an integer between 0

and 999 999.

v If the argument is a duration:

The result is the microsecond part of the value, which is an integer between

−999 999 and 999 999. A nonzero result has the same sign as the argument.

Example

Assume a table TABLEA contains two columns, TS1 and TS2, of type TIMESTAMP.

Select all rows in which the microseconds portion of TS1 is not zero and the

seconds portion of TS1 and TS2 are identical.

SELECT * FROM TABLEA

WHERE MICROSECOND(TS1) <> 0 AND SECOND(TS1) = SECOND(TS2)

MINUTE

►► MINUTE

(

time_expression

)

►◄

timestamp_expression

time_duration_expression

timestamp_duration_expression

The MINUTE function returns the minute part of a value.

The argument must be a time, timestamp, time duration, or timestamp duration. If

a decimal number, the argument must be:

v DECIMAL(6,0) for time duration

v DECIMAL(20,6) for timestamp duration

to be properly interpreted.

The result of the function is a large integer. If the argument can be null, the result

can be null; if the argument is null, the result is the null value.

The other rules depend on the data type of the argument:

v If the argument is a time or a timestamp:

The result is the minute part of the value, which is an integer between 0 and 59.

v If the argument is a time duration or timestamp duration.

106

SQL Reference

MINUTE

The result is the minute part of the value, which is an integer between -99 and

99. A nonzero result has the same sign as the argument.

Example

Using the CL_SCHED sample table, select all classes with a duration less than 50

minutes.

SELECT * FROM CL_SCHED

WHERE HOUR(ENDING - STARTING) = 0 AND

MINUTE(ENDING - STARTING) < 50

MONTH

►► MONTH

(

date_expression

)

►◄

timestamp_expression

date_duration_expression

timestamp_duration_expression

The MONTH function returns the month part of a value.

The argument must be a date, timestamp, date duration, or timestamp duration. If

a decimal number, the argument must be:

v DECIMAL(8,0) for date duration

v DECIMAL(20,6) for timestamp duration

to be properly interpreted.

The result of the function is a large integer. If the argument can be null, the result

can be null; if the argument is null, the result is the null value.

The other rules depend on the data type of the argument:

v If the argument is a date or a timestamp:

The result is the month part of the value, which is an integer between 1 and 12.

v If the argument is a date duration or timestamp duration:

The result is the month part of the value, which is an integer between -99 and

99. A nonzero result has the same sign as the argument.

Example

Select all rows from the EMPLOYEE table for people who were born (BIRTHDATE)

in DECEMBER.

SELECT * FROM EMPLOYEE

WHERE MONTH(BIRTHDATE) = 12

SECOND

►► SECOND

(

time_expression

)

►◄

timestamp_expression

time_duration_expression

timestamp_duration_expression

The SECOND function returns the seconds part of a value.

The argument must be a time, timestamp, time duration, or timestamp duration. If

decimal number, the argument must be:

Chapter 4. Functions

107

SECOND

v DECIMAL(6,0) for time duration

v DECIMAL(20,6) for timestamp duration

to be properly interpreted.

The result of the function is a large integer. If the argument can be null, the result

can be null; if the argument is null, the result is the null value.

The other rules depend on the data type of the argument:

v If the argument is a time or timestamp:

The result is the seconds part of the value, which is an integer between 0 and 59.

v If the argument is a time duration or timestamp duration:

The result is the seconds part of the value, which is an integer between -99 and

99. A nonzero result has the same sign as the argument.

Examples

Example 1: Assume that the host variable TIME_DUR (decimal(6,0)) has the value

153045.

SECOND(:TIME_DUR)

Returns the value 45.

Example 2: Assume that the column RECEIVED (timestamp) has an internal

value equivalent to 1988-12-25-17.12.30.000000.

SECOND(RECEIVED)

Returns the value 30.

STRIP

,’ ’

►► STRIP

(

character_string

)

►◄

,’ ’

,strip_character

,’G< >’

graphic_string

,’G< >’

,strip_character

The STRIP function returns a value in which blanks, or another specified character,

have been removed from the end or the beginning of a string.

character_string or graphic_string

Either a character-compatible expression (CHAR, VARCHAR, TIME, DATE,

TIMESTAMP) or a graphic expression (GRAPHIC, VARGRAPHIC). The

argument cannot be a long string.

Note that the argument cannot have a subtype of mixed.

108

SQL Reference

STRIP

B One of L, T, or B (not in quotation marks) to remove leading, trailing, or both

leading and trailing characters from a string. If a value other than L, T, or B is

specified, an error will occur.

The default value is B.

strip_character

A character constant indicating the character to be stripped from string.

The default is either a single character space or a graphic double character

space (X'4040') depending on the data type of string.

The data type and CCSID of the result depends on the data type of the string

argument. The possible data types and CCSIDs are shown in the following table:

Input Data Type

Output Data Type

Output CCSID

CHAR(n)

VARCHAR(n)

same as that of string

VARCHAR(n)

same as that of string

GRAPHIC(n)

VARGRAPHIC(n)

same as that of string

VARGRAPHIC(n)

same as that of string

DATE

VARCHAR(n)¹

CCSID of the default subtype

TIME

VARCHAR(n)¹

CCSID of the default subtype

TIMESTAMP

VARCHAR(26)

CCSID of the default subtype

For DATE and TIME data types, the value of n is determined by the

SYSTEM.SYSOPTIONS values for datetime formats. If a LOCAL format datetime

value is used, then n is the LOCAL length specified in SYSTEM.SYSOPTIONS,

otherwise 8, 10, and 26 will be used for TIME, DATE, and TIMESTAMP

respectively.

The defined length of the result is identical to the defined length of the string

argument.

If the first argument can be null, then the result can be null. If the first argument is

null, the result is the null value.

Examples

Example 1: Assume the host variable HELLO (char(9)) has a value of ‘ Hello ’.

STRIP(:HELLO)

Returns the value ‘Hello’.

STRIP(:HELLO, T)

Returns the value ‘ Hello’.

Example 2: Assume the host variable BALANCE (char(9)) has a value of

‘000345.50’.

STRIP(:BALANCE,L,’0’, )

Returns the value ‘345.50’.

Example 3: This example shows the treatment of a graphic string.

STRIP(G’<▌XXLLMMNNXXXX▐>’, T,G’<▌XX▐>’)

Chapter 4. Functions

109

STRIP

Returns the value G’<▌XXLLMMNN▐>’

Example 4: This example shows that spaces are treated like any other character.

Therefore, if spaces precede the character that is to be stripped from the start of the

string, then nothing is stripped.

STRIP(’

00123.400’,B,’0’)

Returns the value ‘ 00123.4’.

SUBSTR

►► SUBSTR

( string_expression, start_integer_expression

►

)

►◄

,length_integer_expression

The SUBSTR function returns a substring of a string. If any argument of the

SUBSTR function can be null, the result can be null; if any argument is null, the

result is the null value. The CCSID of the result is the same as that of string.

string

Denotes an expression that specifies the string from which the result is

derived. string must be a character string or a graphic string. If a long string is

specified, it must be a column, not a host variable, and the resulting string

must have a length attribute of not more than 254 bytes (127 characters for

graphic data).

A substring of string is zero or more contiguous characters of string. If string is

a graphic string, a character is a DBCS character. If string is a character string,

a character is a byte.

The SUBSTR function accepts mixed data strings. However, because SUBSTR

operates on a strict byte-count basis, the result will not necessarily be a

properly formed mixed data string.

The SUBSTR function also accepts a datetime argument type for extended

flexibility in extracting datetime substring values.

Note: TIMESTAMP expressions always have an implicit length of 26 and

datatype of CHAR. If the statement is a dynamically prepared one,

DATE and TIME expressions each have an implicit length of 254 and a

data type of VARCHAR. If the statement is not a dynamically prepared

one, DATE and TIME expressions each have an implicit data type of

CHAR and a length which is determined by the value for datetime

formats in the SYSTEM.SYSOPTIONS catalog table. If the datetime

format is LOCAL, the length is the LOCAL length in the

SYSTEM.SYSOPTIONS catalog table; otherwise, it is 8 for TIME and 10

for DATE.

start

Denotes an expression that specifies the position of the first character of the

result. It must be a positive binary integer that is not greater than the length

attribute of string. (The length attribute of a varying-length string is its

maximum length.)

length

Denotes an expression that specifies the length of the result. If specified,

length-expression must evaluate to a binary integer in the range 0 to n, where n

110

SQL Reference

SUBSTR

is the length attribute of string - start + 1. It must not, however, be the integer

constant 0. (SUBSTR(col,1,1-1) is valid; SUBSTR(col,1,0) is not).

If length is explicitly specified, string is effectively padded on the right with the

necessary number of blank characters so that the specified substring of string

always exists.

The default for length is the number of characters from the character specified

by the start to the last character of string. However, if string is a varying-length

string with an actual length less than start (for example, SUBSTR('abcde', 7),

the default is zero and the result is the empty string.

If string is a character string:

If length is explicitly specified by an integer constant less than or equal to 254,

the result is a fixed-length character string with a length attribute of length.

If length is not explicitly specified, but string is a fixed-length character string

and start is an integer constant, the result is a fixed-length character string with

a length attribute of:

LENGTH(string) - start + 1

If length is not explicitly specified, but string is a varying-length character string

or start is not an integer constant, the result is a varying-length character string

with a length attribute that is the same as the length attribute of string.

(Remember, that if the actual length of the string is less than the start position,

the actual length of the substring is zero.)

The maximum length attribute of the result is 254.

If string is a graphic string:

If length is explicitly specified by an integer constant less than or equal to 127,

the result is a fixed-length graphic string with a length attribute of length.

If length is not explicitly specified, but string is a fixed-length graphic string and

start is an integer constant, the result is a fixed-length graphic string with a

length attribute of:

LENGTH(string) - start + 1

If length is not explicitly specified, but string is a varying-length graphic string or

start is not an integer constant, the result is a varying-length graphic string with

a length attribute that is the same as the length attribute of string. (Remember,

that if the actual length of the string is less than the start position, the actual

length of the substring is zero.)

The maximum length attribute of the result is 127.

If string is a fixed-length string, omission of length is an implicit specification of

LENGTH(string) - start + 1. If string is a varying-length string, omission of length is

an implicit specification of zero or LENGTH(string) - start + 1, whichever is greater.

Examples

Example 1: Assume the host variable NAME (varchar(50)) has a value of ‘KATIE

AUSTIN’ and the host variable SURNAME_POS (int) has a value of 7.

SUBSTR(:NAME, :SURNAME_POS)

Returns the value ‘AUSTIN’

SUBSTR(:NAME, :SURNAME_POS, 1)

Returns the value ‘A’.

Chapter 4. Functions

111

DB2 Server for VSE & VM SQL Reference (Version 7 Release 5) - page 3
