SUBSTR

Example 2: Select all rows from the PROJECT table for which the project name

(PROJNAME) starts with the word ‘OPERATION ’.

SELECT * FROM PROJECT

WHERE SUBSTR(PROJNAME,1,10) = ’OPERATION ’

The space at the end of the constant is necessary to preclude initial words such as

‘OPERATIONS’.

Example 3: Assume there is a host variable VC300 (VARCHAR(300)), the host

variable START (int) has a value of 30, and the host variable LNGTH (int) has a

value of 250. Obtain a substring of VC300 starting at START with a length of

LNGTH.

Attempt 1:

SUBSTR(:VC300, :START, :LNGTH)

This is not allowed because LNGTH is a host variable and the resulting size is

assumed to be that of the source string (300). Thus the size of the host variable

exceeds the maximum allowed size of 254.

Attempt 2:

SUBSTR(SUBSTR(:VC300, :START, 254), 1, :LNGTH)

This attempt is successful.

1. The inner substring, that is:

SUBSTR(:VC300, :START, 254)

produces a CHAR(254) result whose value is taken from position 30 to position

273 of VC300 (and contains trailing blanks if VC300 is less than 273 bytes long).

2. The outer substring, that is:

SUBSTR(inner_result, 1, :LNGTH)

produces a VARCHAR(254) result whose value is taken from position one to

position 250 of the inner_result. The length of the result is 250.

Attempt 3:

SUBSTR(:VC300, 299)

This is not allowed because the result is a varying-length string with length

attribute 300 which is longer than 254.

TIME

►► TIME

(

time_expression

)

►◄

timestamp_expression

time_string_expression

The TIME function returns a time from a value.

The argument must be a timestamp, a time, or a valid string representation of a

time.

112

SQL Reference

TIME

The result of the function is a time. The data type is TIME. If the argument can be

null, the result can be null; if the argument is null, the result is the null value.

The other rules depend on the data type of the argument:

v If the argument is a timestamp:

The result is the time part of the timestamp.

v If the argument is a time:

The result is that time.

v If the argument is a character string:

The result is the time represented by the character string.

Notes:

1. When a string representation of a time is SBCS with a CCSID that is not the

same as the default CCSID for SBCS data, that value is converted to adhere

to the default CCSID for SBCS data before it is interpreted and converted to

a time value.

2. When a string representation of a time is mixed with a CCSID that is not the

same as the default CCSID for mixed data, that value is converted to adhere

to the default CCSID for mixed data before it is interpreted and converted to

a time value.

Example

Select all notes from the IN_TRAY sample table that were received at least one

hour later in the day (any day) than the current time.

SELECT * FROM IN_TRAY

WHERE TIME(RECEIVED) >= CURRENT TIME + 1 HOUR

TIMESTAMP

►► TIMESTAMP

(

timestamp_expression

)

►◄

timestamp_str_expression

yyyymmddhhmmss_character_expression

390_storeclock_character_expression

date_expression

,time_expression

date_str_expression

,time_str_expression

The TIMESTAMP function returns a timestamp from a value or a pair of values.

The rules for the arguments depend on whether the second argument is specified.

v If only one argument is specified:

It must be an expression that returns a timestamp, a valid string representation

of a timestamp, a character string of length 8, or a character string of length 14.

A character string of length 8 is assumed to be a System/390 Store Clock value.

A character string of length 14 must be a string of digits that represents a valid

date and time in the form yyyyxxddhhmmss, where yyyy is the year, xx is the

month, dd is the day, hh is the hour, mm is the minute, and ss is the seconds.

v If both arguments are specified:

The first argument must be an expression that returns either a date or a valid

string representation of a date. The second argument must be an expression that

returns either a time or a valid string representation of a time.

Chapter 4. Functions

113

TIMESTAMP

The result of the function is a timestamp. The data type is TIMESTAMP. If either

argument can be null, the result can be null; if either argument is null, the result is

the null value.

The other rules depend on whether the second argument is specified:

v If both arguments are specified:

The result is a timestamp with the date specified by the first argument and the

time specified by the second argument. The microsecond part of the timestamp

is zero.

v If only one argument is specified and it is a timestamp:

The result is that timestamp.

v If only one argument is specified and it is a character string:

The result is the timestamp represented by that character string. The

interpretation of a character string as a Store Clock value will yield a timestamp

with a year between 1900 to 2042 as described in the IBM System/370 Principles of

Operation manual.

Notes:

1. When a string representation of a timestamp or date and time is SBCS with a

CCSID that is not the same as the default CCSID for SBCS data, that value is

converted to adhere to the default CCSID for SBCS data before it is

interpreted and converted to a timestamp value.

2. When a string representation of a timestamp or date and time is mixed with

a CCSID that is not the same as the default CCSID for mixed data, that value

is converted to adhere to the default CCSID for mixed data before it is

interpreted and converted to a timestamp value.

Example

Assume the column START_DATE (date) has a value equivalent to 1988-12-25, and

the column START_TIME (time) has a value equivalent to 17.12.30.

TIMESTAMP(START_DATE, START_TIME)

Returns the value ’1988-12-25-17.12.30.000000’.

114

SQL Reference

TRANSLATE

►► TRANSLATE

(

char_string_exp

char_string_exp options

)

►◄

graphic_string_exp

char_string_exp options:

,’ABC...XYZ’,’abc...xyz’

,X’000102...FDFEFF’

,to_string_exp

,’ ’

,from_string_exp

,pad_char

graphic_string_exp:

,G’< >’

graphic_string_exp

,to_string_exp

,from_string_exp

,pad_char

The TRANSLATE function returns a value in which one or more characters in a

string expression may have been translated into other characters.

char_string_exp or graphic_string_exp

A short string expression that has either a character data type (CHAR,

VARCHAR, DATE, TIME, or TIMESTAMP) or a graphic data type (GRAPHIC

or VARGRAPHIC). This argument cannot be a long string.

when the first argument is char_string_exp:

to_string_exp

Is a short string expression that has a character data type.

If the length attribute of to_string_exp is less than the length attribute of

from_string_exp, then to_string-exp is padded to the longer length using

either the pad_char or a space.

If the length attribute of to_string_exp is more than the length attribute

of from_string_exp, the extra characters in to_string_exp are ignored,

without a warning.

from_string_exp

Is a short string expression that has a character data type.

If there are duplicate characters in from_string_exp, the first one

scanning from the left is used. No warning is issued.

The default value for from_string_exp is a string of 256 characters

starting with the character X'00' and ending with the character X'FF'

(decimal 255).

pad_char

Is a CHAR(1) constant used to pad to_string_exp if it is shorter than

from_string_exp. If the length is not equal to one, an error will occur.

The default pad_char is a space.

Note: None of the arguments can have a subtype of mixed.

Chapter 4. Functions

115

TRANSLATE

If to_string_exp is not supplied, then from_string_exp must not be supplied.

In this case, char_string_exp is simply translated to upper case. This is done

based on the folding rules specified in the SYSCHARSETS catalog table.

when the first argument is graphic_string_exp:

to_string_exp

Is a short string expression that also returns a graphic data type.

If the length attribute of to_string_exp is less than the length attribute of

from_string_exp, then to_string_exp is padded to the longer length using

either the pad_char or a graphic space.

If the length attribute of to_string_exp is more than the length attribute of

from_string_exp, the extra characters in to_string_exp are ignored, without a

warning.

from_string_exp

Is a short string expression that has a graphic data type.

If there are duplicate characters in from_string_exp, the first one scanning

from the left is used. No warning is issued.

pad_char

Is a GRAPHIC(1) constant that is used to pad to_string_exp if it is shorter

than from_string_exp. If the length is not equal to 1, an error will occur.

The default pad_char is a graphic space.

Translation Process

The result string is built character by character from char_string_exp, translating

characters in from_string_exp to the corresponding character in to_string_exp. For

each character in char_string_exp, the same character is searched for in

from_string_exp. If the character is found to be the nth character in from_string_exp,

the resulting string will contain the nth character from to_string_exp. If to_string_exp

is less than n characters long, the resulting string will contain the pad character. If

the character is not found in from_string_exp, it is moved to the result string

untranslated.

The data type and CCSID of the result depends on the data type of the string

argument. The possible data types and CCSIDs are shown in the following table:

Input Data Type

Output Data Type

Output CCSID

CHAR(n)

VARCHAR(n)

same as that of string

VARCHAR(n)

same as that of string

GRAPHIC(n)

VARGRAPHIC(n)

same as that of string

VARGRAPHIC(n)

same as that of string

DATE

VARCHAR(n)¹

CCSID default of the subtype

TIME

VARCHAR(n)¹

CCSID default of the subtype

TIMESTAMP

VARCHAR(26)

CCSID default of the subtype

For DATE and TIME data types, the value of n is determined by the

SYSTEM.SYSOPTIONS values for datetime formats. If a LOCAL format datetime

value is used, then n is the LOCAL length specified in SYSTEM.SYSOPTIONS,

otherwise 8, 10, and 26 will be used for TIME, DATE, and TIMESTAMP

respectively.

116

SQL Reference

TRANSLATE

The length of the result is identical to the length of the string argument. If any

argument can be null, the result can be null; if any argument is null, the result is

the null value.

The use of an argument expression (for example, column or host variable) defined

as mixed character is not allowed.

Examples

Example 1: Assume the host variable SITE (varchar(30)) has a value of ’Pivabiska

Lake Place’.

TRANSLATE(:SITE)

Returns the value ’PIVABISKA LAKE PLACE’.

TRANSLATE(:SITE,’$’,’L’)

Returns the value ’Pivabiska $ake Place’.

TRANSLATE(:SITE,’$$’,’Ll’)

Returns the value ’Pivabiska $ake P$ace’.

TRANSLATE(:SITE,’pLA’,’Place’,’.’)

Returns the value ’pivAbiskA LAk. pLA..’.

Example 2: Produce a list that includes the first three columns from all rows in

the IN_TRAY sample table and order the list on SUBJECT in a case insensitive

manner.

SELECT SUBJECT, RECEIVED, SOURCE, TRANSLATE(SUBJECT)

FROM IN_TRAY

ORDER BY 4

Example 3: This shows the treatment of a graphic string.

TRANSLATE(G’

<▌JJOOHHNN▐>’,G’

<▌AACCKK▐>’,G’

<▌OOHHNN▐>’)

Returns the value G’<▌JJAACCKK▐>’.

VALUE

▼

►► VALUE

( expression

,expression

)

►◄

The VALUE function returns the first non-null result in a series of expressions.

v None of the expressions can be long strings.

v The data types of the arguments must be compatible.

If any argument is numeric, all arguments must be numeric (SMALLINT,

INTEGER, DECIMAL, and FLOAT). If any argument is a character string, all

arguments must be character-compatible strings (CHAR, VARCHAR, DATE, TIME,

TIMESTAMP). If any argument is a graphic string, all arguments must be graphic

strings (GRAPHIC and VARGRAPHIC).

Chapter 4. Functions

117

VALUE

The arguments are evaluated in the order in which they are specified, and the

result value of the function is equal to the first argument that is not NULL. If the

arguments can be null, the result can be null; if all the arguments are null, the

result is the null value.

If all arguments are dates, the result data type is a date; if all arguments are

times, the result data type is a time; and if all arguments are timestamps, the

result data type is a timestamp.

If the arguments are strings, the CCSID of the result is calculated using the rules

given in “Conversion Rules for Operations that Combine Strings” on page 130.

If all arguments are fixed-length strings, the result is a fixed-length string of

length n, where n is the length of the longest argument.

If any argument is a varying-length string, the result is a varying-length string

with length attribute n, where n is the length attribute of the argument with the

greatest length attribute. The actual length of the result is the actual length of

the selected argument.

If the arguments are numeric, the result data type is the strongest of the

argument data types (FLOAT > DECIMAL > INTEGER > SMALLINT).

If the resultant data type is DECIMAL, precision and scale values are

determined as follows: scale is the largest result scale of any data type, and

precision is 'MIN(31,SCALE+n)' where 'n' is the largest integral part (precision

minus scale) result of any argument. For example, in VALUE(A, B, C), where A

is DECIMAL(10, 4), B is DECIMAL(8, 5), C is DECIMAL(5, 2), the resulting scale

is MAX(4, 5, 2) = 5 and the resulting precision is

MIN(31, 5 + MAX(10-4, 8-5, 5-2)) = 11

If scale + 'n' is greater than 31, then there is a potential for a conversion error

because there may be a value whose integer part will not fit and an error occurs.

For example, in VALUE(X, Y) where X is DECIMAL(27, 2) and Y is

DECIMAL(14, 9) the resultant data type is DECIMAL(31,9). If the value of 'X' is

1000000000000000000000000.02 and the value of 'Y' is 30000.000000004, then a

decimal overflow occurs because 'X' will not fit in DECIMAL(31,9).

Examples

Example 1: Select all the values from all the rows in the DEPARTMENT table. If

the value for department manager (MGRNO) is missing (that is, null) then return a

value of ‘ABSENT’.

SELECT DEPTNO, DEPTNAME, VALUE(MGRNO, ’ABSENT’), ADMRDEPT

FROM DEPARTMENT

Example 2: Select the employee number (EMPNO) and salary (SALARY) from all

the rows in the EMPLOYEE table. If the salary is missing (that is, null) then return

a value of zero.

SELECT EMPNO, VALUE(SALARY,0)

FROM EMPLOYEE

VARGRAPHIC

►► VARGRAPHIC

( expression

)

►◄

The VARGRAPHIC function returns a graphic string representation of a character

string.

118

SQL Reference

VARGRAPHIC

The argument must be a character string (CHAR, VARCHAR) or a character

compatible string (DATE, TIME, TIMESTAMP). If varying-length, the maximum

length must not be greater than 127. If the argument is a character string constant

that is to be interpreted as mixed data, it must contain properly paired shift control

characters.

The result of the function is a varying-length graphic string. If the subtype of the

argument is SBCS then the CCSID of the result is the system default CCSID for

graphic data. If the subtype of the argument is mixed, then the CCSID of the result

is the graphic CCSID which makes up the DBCS portion of the mixed argument

CCSID. For details, see the DB2 Server for VM System Administration or DB2 Server

for VSE System Administration manual for the table showing mixed CCSIDs and

their corresponding DBCS (and SBCS) component CCSIDs.

If the argument can be null, the result can be null; if the argument is null, the

result is the null value. The result includes all DBCS characters of the argument

and the DBCS equivalent of all single-byte characters of the argument. The first

character of the result is the first logical character of the argument, the second

character of the result is the second logical character of the argument, and so on.

The result does not include X'0E' or X'0F'.

The DBCS equivalent of X'40' is X'4040'. The DBCS equivalent of every single-byte

character (nn) other than X'40' is X'42nn'.

The length of the result depends on the number of logical characters in the

argument. If the length or maximum length of the argument is n bytes, the

maximum length of the result is n (DBCS characters).

VARGRAPHIC will convert a mixed data value to GRAPHIC in the following

manner:

v DBCS characters from the source will be placed into the target unchanged

v SBCS characters from the source will have their DBCS equivalent placed into the

target

v No shift-in or shift-out characters will be transferred to the target.

Example

Using the EMPLOYEE table, set the host variable VAR_DESC (vargraphic(24)) to

the VARGRAPHIC equivalent of the first name (FIRSTNME) for employee number

(EMPNO) ‘000050’.

SELECT VARGRAPHIC(FIRSTNME)

INTO :VAR_DESC

FROM EMPLOYEE

WHERE EMPNO = ’000050’

VAR_DESC will be set to the GRAPHIC form of ’JOHN’ when using the sample

table. The hex representation of this is: X'42D142D642C842D5'.

Chapter 4. Functions

119

YEAR

►► YEAR

(

date_expression

)

►◄

timestamp_expression

date_duration_expression

timestamp_duration_expression

The YEAR function returns the year part of a value.

The argument must be a date, timestamp, date duration, or timestamp duration. If

a decimal number, the argument must be:

v DECIMAL(8,0) for date duration

v DECIMAL(20,6) for timestamp duration

to be properly interpreted.

The result of the function is a large integer. If the argument can be null, the result

can be null; if the argument is null, the result is the null value.

The other rules depend on the data type of the argument specified:

v If the argument is a date or a timestamp:

The result is the year part of the value, which is an integer between 1 and 9 999.

v If the argument is a date duration or timestamp duration:

The result is the year part of the value, which is an integer between -9 999 and

9 999. A nonzero result has the same sign as the argument.

Examples

Example 1: Select all the projects in the PROJECT table that are scheduled to start

(PRSTDATE) and end (PRENDATE) in the same calendar year.

SELECT * FROM PROJECT

WHERE YEAR(PRSTDATE) = YEAR(PRENDATE)

Example 2: Select all the projects in the PROJECT table that are scheduled to take

less than one year to complete.

SELECT * FROM PROJECT

WHERE YEAR(PRENDATE - PRSTDATE) < 1

120

SQL Reference

Chapter 5. Queries

A query specifies a result table.

In a program, a query is a component of certain SQL statements. There are three

forms of a query:

v The subselect

v The fullselect

v The select-statement.

There is another form of select, described under “SELECT INTO” on page 336.

Authorization

For any form of a query, the privileges held by the authorization ID of the

statement must include at least one of the following for each of the tables or views

identified in the statement:

v Ownership of the table or view

v The SELECT privilege on the table or view

v DBA authority.

subselect

►► select_clause

from_clause

►◄

where_clause

group_by_clause

having_clause

The subselect is a component of the fullselect, the CREATE VIEW statement, and

the INSERT statement. It is also a component of certain predicates which, in turn,

are components of a subselect. A subselect that is a component of a predicate is

called a subquery. If more than one table or view is identified in the FROM clause,

the subselect is called a join. (See the DB2 Server for VSE & VM Application

Programming manual for information on joining tables.)

A subselect specifies a result table derived from the tables or views identified in

the FROM clause. The derivation can be described as a sequence of operations in

which the result of each operation is input for the next. (This is only a way of

describing the subselect. The method used to perform the derivation may be quite

different from this description.)

The sequence of the (hypothetical) operations is:

1. FROM clause

2. WHERE clause

3. GROUP BY clause

4. HAVING clause

5. SELECT clause.

121

select-clause

ALL

►► SELECT

►◄

DISTINCT

▼

expression

table_name.*

view_name.*

correlation_name.*

The SELECT clause specifies the columns of the final result table. The column

values are produced by the application of the select list to R. The select list is the

names or expressions specified in the SELECT clause. R is the result of the

previous operation of the subselect. For example, if the only clauses specified are

SELECT, FROM, and WHERE, R is the result of that WHERE clause.

ALL

Retains all rows of the final result table and does not eliminate redundant

duplicates. This is the default.

DISTINCT

Eliminates all but one of each set of duplicate rows of the final result table.

DISTINCT must not be used more than once in a subselect. This restriction

includes SELECT DISTINCT and the use of DISTINCT in a column function of

the select list or HAVING clause, but does not include subqueries of the

subselect.

Two rows are duplicates of one another only if each value in the first row is

equal to the corresponding value in the second row. (For determining duplicate

rows, two null values are considered equal.)

Select List Notation

Represents a list of names that identify the columns of table R. The first name

in the list identifies the first column of R, the second name identifies the

second column of R, and so on.

The list of names is established when the statement containing the SELECT

clause is prepared. Hence, * does not identify any columns that have been

added to a table after the statement has been prepared.

expression

Can be any expression of the type described in Chapter 3. Each column name

used in the select list must unambiguously identify a column of R. The

operand of an operator must not be a column function that includes the

keyword DISTINCT.

name.*

Represents a list of names that identify the columns of name. The name can be a

table name, view name, or correlation name, and must designate a table or

view named in the FROM clause. The first name in the list identifies the first

column of the table or view, the second name in the list identifies the second

column of the table or view, and so on.

The list of names is established when the statement containing the SELECT

clause is prepared. Hence, * does not identify any columns that have been

added to a table after the statement has been prepared.

122

SQL Reference

select-clause

The number of columns in the result of SELECT is the same as the number of

expressions in the operational form of the select list (that is, the list established

during program preparation) and must not exceed 255. The result table of a

subquery must be a single column, unless the subquery is used in the EXISTS

predicate.

Limitation on Long String Columns

No column in the list may be a long string column if:

v SELECT DISTINCT is used

v The subselect is a subquery

v The subselect is an operand of UNION or UNION ALL.

Note:

The restriction does not apply to a subquery of an EXISTS predicate because an

EXISTS subquery does not return values.

Applying the Select List

Some of the results of applying the select list to R depend on whether GROUP BY

or HAVING is used. Those results are described separately.

If GROUP BY or HAVING is used::

v Each column-name in the select list must either identify a grouping column or be

specified within a column function.

v The select list is applied to each group of R, and the result contains as many

rows as there are groups in R. When the select list is applied to a group of R,

that group is the source of the arguments of the column functions in the select

list.

If neither GROUP BY nor HAVING is used:

v The select list must not include any column functions, or it must be entirely a

list of column functions.

v If the select list does not include column functions, it is applied to each row of R

and the result contains as many rows as there are rows in R.

v If the select list is a list of column functions, R is the source of the arguments of

the functions and the result of applying the select list is one row.

In either case the nth column of the result contains the values specified by

applying the nth expression in the operational form of the select list.

Null attribute of result columns

Result columns allow null values if they are derived from:

v Any column function but COUNT

v A column that allows null values

v An arithmetic expression in an outer select list

v An arithmetic expression that allows nulls

v A scalar function or string expression that allows null values

v A host variable that has an indicator variable

v A result of a UNION if at least one of the corresponding items in the select list

is nullable.

Names of result columns

A result column derived from a column name acquires the unqualified name of

that column. All other result columns have no names.

Chapter 5. Queries

123

select-clause

Data type of result columns

Each column of the result of SELECT acquires a data type from the expression

from which it is derived.

When the expression is ...

The data type of the result column is ...

the name of any numeric column

the same as the data type of the column,

with the same precision and scale for

decimal columns.

an integer constant

INTEGER.

a decimal or floating-point constant

the same as the data type of the constant,

with the same precision and scale for

decimal constants. For floating-point

constants, the data type is DOUBLE

PRECISION.

the name of any numeric host variable

the same as the data type of the variable,

with the same precision and scale for

decimal variables. If the data type of the

variable is not identical to an SQL data type

(for example, DISPLAY SIGN LEADING

SEPARATE in COBOL), the result column is

decimal.

an arithmetic or string expression

the same as the data type of the result.

Decimal results have the same precision and

scale as described under “Expressions” on

page 71.

any function

(see Chapter 4 to determine the data type of

the result.)

the name of any string column

the same as the data type of the column,

with the same length attribute.

the name of any string host variable

the same as the data type of the variable,

with a length attribute equal to the length of

the variable. If the data type of the variable

is not identical to an SQL data type (for

example, a NUL-terminated string in C), the

result column is a varying-length string.

a character string constant of length n

VARCHAR(n)

a graphic string constant of length n

VARGRAPHIC(n)

the name of a datetime column

the same as the data type of the column.

from-clause

►► FROM

▼

table_name

►◄

view_name

correlation_name

The FROM clause specifies an intermediate result table. If a single table or view is

identified, the intermediate result table is simply that table or view. If more than

one table or view is identified, the intermediate result table consists of all possible

combinations of the rows of the identified tables or views. Each row of the result is

a row from the first table or view concatenated with a row from the second table

124

SQL Reference

from-clause

or view, concatenated in turn with a row from the third, and so on. The number of

rows in the result is the product of the number of rows in all the named tables or

views.

The following rules apply to the names specified in a FROM clause:

v Each table_name or view_name must identify an existing table or view at the

application server.

v Each correlation_name is defined as a designator of the table or view identified

by the immediately preceding table_name or view_name.

v The exposed names must be unique. An exposed name is a correlation_name, a

table_name that is not followed by a correlation_name, or a view_name that is

not followed by a correlation_name.

If a correlation_name is specified for a table or view, any qualified reference to a

column of that table or view in the subselect must use that correlation_name. For

more information about the FROM clause, see “Correlation Names” on page 64.

where-clause

►► WHERE search_condition

►◄

The WHERE clause specifies an intermediate result table that consists of those

rows of R for which the search_condition is true. R is the result of the FROM

clause of the subselect.

The search_condition must conform to the following rules:

v Each column name must unambiguously identify a column of R or be a

correlated reference. A column name is a correlated reference if it identifies a

column of a table or view identified in an outer subselect.

v A column function must not be specified unless the WHERE clause is specified

in a subquery of a HAVING clause and the argument of the function is a

correlated reference to a group.

Any subquery in the search_condition is effectively processed for each row of R and

the results are used in the application of the search_condition to the given row of R.

A subquery is actually processed for each row of R only if it includes a correlated

reference. In fact, a subquery with no correlated references is processed just once,

whereas a subquery with a correlated reference may have to be processed once for

each row.

group-by-clause

▼

►► GROUP BY

column_name

►◄

The GROUP BY clause specifies an intermediate result table that consists of a

grouping of the rows of R. R is the result of the previous clause of the subselect.

Each column_name must unambiguously identify a column of R other than a long

string column. Each identified column is called a grouping column.

Chapter 5. Queries

125

group-by-clause

The result of GROUP BY is a set of groups of rows. The rows within each group

are in an arbitrary order. In each group of more than one row, all values of each

grouping column are equal; and all rows with the same set of values of the

grouping columns are in the same group. For grouping, all null values within a

grouping column are considered equal.

Because every row of a group contains the same value of any grouping column,

the name of a grouping column can be used in a search condition in a HAVING

clause or an expression in a SELECT clause; in each case, the reference specifies

only one value for each group.

If the grouping column contains varying-length strings with trailing blanks, the

values in the group can differ in the number of trailing blanks and may not all

have the same length. In that case, a reference to the grouping column still

specifies only one value for each group, but the value for a group is chosen

arbitrarily from the available set of values. Thus, the actual length of the result

value is unpredictable.

If a field procedure is not involved, the collating sequence depends on the CCSID

of the application server. With the DRDA protocol, the application server could be

using an ASCII CCSID, producing an unexpected result to an application program

assuming an EBCDIC CCSID and code page (see the IBM SQL Reference manual for

details).

GROUP BY is ignored if used in a subquery of a basic predicate.

having-clause

►► HAVING search_condition

►◄

The HAVING clause specifies an intermediate result table that consists of those

groups of R for which the search_condition is true. R is the result of the previous

clause of the subselect. If this clause is not GROUP BY, R is considered a single

group with no grouping columns.

Each column name in the search_condition must:

v unambiguously identify a grouping column of R, or

v be specified within a column function, or

v be a correlated reference. A column name is a correlated reference if it identifies

a column of a table or view identified in an outer subselect.

A group of R to which the search condition is applied supplies the argument for

each column function in the search condition, except for any function whose

argument is a correlated reference.

If the search condition contains a subquery, the subquery can be thought of as

being processed each time the search condition is applied to a group of R, and the

results used in applying the search condition. In actuality, the subquery is

processed for each group only if it contains a correlated reference. For an

illustration of the difference, see examples 6 and 7 under “Examples of a subselect”

on page 127.

126

SQL Reference

having-clause

A correlated reference to a group of R must either identify a grouping column or

be contained within a column function.

The HAVING clause must not be used in a subquery of a basic predicate.

Examples of a subselect

Example 1

Select all columns and rows from the EMPLOYEE table.

SELECT * FROM EMPLOYEE

Example 2

Join the EMP_ACT and EMPLOYEE tables, select all the columns from the

EMP_ACT table and add the employee’s surname (LASTNAME) from the

EMPLOYEE table to each row of the result.

SELECT EMP_ACT.*, LASTNAME

FROM EMP_ACT, EMPLOYEE

WHERE EMP_ACT.EMPNO = EMPLOYEE.EMPNO

Example 3

Using a join-condition on the EMPLOYEE and DEPARTMENT tables, select the

employee number (EMPNO), employee name (FIRSTNME concatenated with

MIDINIT concatenated with LASTNAME), department number (WORKDEPT in

the EMPLOYEE table and DEPTNO in the DEPARTMENT table) and department

name (DEPTNAME) of all employees who were born (BIRTHDATE) earlier than

1930.

SELECT EMPNO, FIRSTNME CONCAT ’ ’ CONCAT MIDINIT CONCAT ’ ’ CONCAT LASTNAME,

WORKDEPT, DEPTNAME

FROM EMPLOYEE, DEPARTMENT

WHERE WORKDEPT = DEPTNO

AND YEAR(BIRTHDATE) < 1930

Example 4

Select the job (JOB) and the minimum and maximum salaries (SALARY) for each

group of rows with the same job code in the EMPLOYEE table, but only for groups

with more than one row and with a maximum salary greater than or equal to 27

000.

SELECT JOB, MIN(SALARY), MAX(SALARY)

FROM EMPLOYEE

GROUP BY JOB

HAVING COUNT(*) > 1 AND MAX(SALARY) >= 27000

Example 5

Select all the rows of EMP_ACT table for employees (EMPNO) in department

(WORKDEPT) ‘E11’. (Employee department numbers are shown in the EMPLOYEE

table.)

SELECT * FROM EMP_ACT

WHERE EMPNO IN (SELECT EMPNO FROM EMPLOYEE

WHERE WORKDEPT = ’E11’)

Chapter 5. Queries

127

subselect

Example 6

From the EMPLOYEE table, select the department number (WORKDEPT) and

maximum departmental salary (SALARY) for all departments whose maximum

salary is less than the average salary for all employees.

SELECT WORKDEPT, MAX(SALARY)

FROM EMPLOYEE

GROUP BY WORKDEPT

HAVING MAX(SALARY) < (SELECT AVG(SALARY)

FROM EMPLOYEE)

The subquery in the HAVING clause would only be processed once in this

example.

Example 7

Using the EMPLOYEE table, select the department number (WORKDEPT) and

maximum departmental salary (SALARY) for all departments whose maximum

salary is less than the average salary in all other departments.

SELECT WORKDEPT, MAX(SALARY)

FROM EMPLOYEE EMP_COR

GROUP BY WORKDEPT

HAVING MAX(SALARY) < (SELECT AVG(SALARY)

FROM EMPLOYEE

WHERE NOT WORKDEPT = EMP_COR.WORKDEPT)

Note: In contrast to example 6, the subquery in the HAVING clause would need to

be executed for each group.

fullselect

▼

►►

subselect

►◄

(fullselect)

UNION

subselect

UNION ALL

(fullselect)

A fullselect specifies a result table. If UNION is not used, the result of the fullselect

is the result of the specified subselect.

UNION or UNION ALL

Derives a result table by combining two other result tables (R1 and R2). If

UNION ALL is specified, the result consists of all rows in R1 and R2. If

UNION is specified without the ALL option, the result is the set of all rows in

either R1 or R2, with duplicate rows eliminated. In either case, each row of the

UNION table is either a row from R1 or a row from R2. The columns of the

result are not named in the SQLDA.

Two rows are duplicates if each value in the first is equal to the corresponding

value of the second. (For determining duplicates, two null values are considered

equal.)

UNION and UNION ALL are associative operations. However, when UNION and

UNION ALL are used in the same statement, the result depends on the order in

which the operations are performed. Operations within parentheses are performed

first. When the order is not specified by parentheses, operations are performed in

left-to-right order.

128

SQL Reference

fullselect

Rules for columns

R1 and R2 must have the same number of columns, and the data type of the

nth column of R1 must be compatible with the data type of the nth column of

R2.

R1 and R2 must not include long string columns.

The nth column of the result of UNION and UNION ALL is derived from the

nth columns of R1 and R2. The following table shows all valid combinations of

operand columns and, for each combination, the data type of the result column.

The data type of the result

If one operand column is...

And the other operand is...

column is...

CHAR(x)

CHAR(y)

CHAR(z) where z = max(x,y)

VARCHAR(x)

CHAR(y) or VARCHAR(y)

VARCHAR(z) where z =

max(x,y)

bit data

mixed, SBCS, or bit data

bit data

mixed data

mixed or SBCS data

mixed data

SBCS data

GRAPHIC(x)

GRAPHIC(y)

GRAPHIC(z) where z =

max(x,y)

VARGRAPHIC(x)

GRAPHIC(y) or

VARGRAPHIC(z) where z =

VARGRAPHIC(y)

max(x,y)

DATE

TIME

TIMESTAMP

FLOAT (double)

any numeric type

FLOAT (double)

FLOAT (single)

DECIMAL, NUMERIC,

FLOAT (double)

INTEGER, or SMALLINT

DECIMAL(w,x)

DECIMAL(y,z) or

DECIMAL(p,s) where p =

NUMERIC(y,z,)

max(x,z)+max(w-x,y-z) s =

max(x,z) (see note below)

DECIMAL(w,x)

INTEGER

DECIMAL(p,x) where p =

x+max(w-x,11) (see note

below)

DECIMAL(w,x)

SMALLINT

DECIMAL(p,x) where p =

x+max(w-x,5) (see note

below)

INTEGER

SMALLINT

INTEGER

SMALLINT

Note: A decimal result column must not have a precision greater than 31.

If neither operand column allows nulls, the result column does not allow nulls.

Otherwise, the result column allows nulls. If the description of any operand

column is not the same as the description of the result column, its values are

converted to conform to the description of the result column.

The conversion operation is exactly the same as if the values were assigned to

the result column. For example, if one operand column is CHAR(10), and the

Chapter 5. Queries

129

fullselect

other operand column is CHAR(5), the result column is CHAR(10), and the

values derived from the CHAR(5) column are padded on the right with five

blanks.

Examples of a fullselect

Example 1

Select all columns and rows from the EMPLOYEE table.

SELECT * FROM EMPLOYEE

Example 2

List the employee numbers (EMPNO) of all employees in the EMPLOYEE table

whose department number (WORKDEPT) either begins with ‘E’ or who are

assigned to projects in the EMP_ACT table whose project number (PROJNO)

begins with either ‘MA2100’, ‘MA2110’, or ‘MA2112’.

SELECT EMPNO FROM EMPLOYEE

WHERE WORKDEPT LIKE ’E%’

UNION

SELECT EMPNO FROM EMP_ACT

WHERE PROJNO IN(’MA2100’, ’MA2110’, ’MA2112’)

Example 3

Make the same query as in example 2, and, in addition, “tag” the rows from the

EMPLOYEE table with ‘emp’ and the rows from the EMP_ACT table with

‘emp_act’.

SELECT EMPNO, ’emp’ FROM EMPLOYEE

WHERE WORKDEPT LIKE ’E%’

UNION

SELECT EMPNO, ’emp_act’ FROM EMP_ACT

WHERE PROJNO IN(’MA2100’, ’MA2110’, ’MA2112’)

Example 4

Make the same query as in example 2, only use UNION ALL so that no duplicate

rows are eliminated.

SELECT EMPNO FROM EMPLOYEE

WHERE WORKDEPT LIKE ’E%’

UNION ALL

SELECT EMPNO FROM EMP_ACT

WHERE PROJNO IN(’MA2100’, ’MA2110’, ’MA2112’)

Conversion Rules for Operations that Combine Strings

The operations that combine strings are concatenation, UNION, and UNION ALL.

These rules also apply to the VALUE scalar function. In each case, the CCSID of

the result is determined at bind time, and the execution of the operation may

involve conversion of strings to the coded character set identified by that CCSID.

The CCSID of the result is determined by the CCSIDs of the operands. The CCSIDs

of the first two operands determine an intermediate result CCSID, this CCSID and

the CCSID of the next operand determine a new intermediate result CCSID, and so

on. The last intermediate result CCSID and the CCSID of the last operand

determine the CCSID of the result string or column. For each pair of CCSIDs, the

result CCSID is determined by the sequential application of the following rules:

v If the CCSIDs are equal, the result is that CCSID.

v If either CCSID is 65535 (X'FFFF'), the result is 65535.

v If one CCSID denotes SBCS data and the other denotes mixed data, the result is

the CCSID for mixed data.

130

SQL Reference

fullselect

Table 6. Selecting the CCSID of the Intermediate Result

Second Operand

First

Column

Derived

Special

Operand

Value

Constant

Host Variable

Column

Value

first

Derived

Value

second

first

Constant

second

first

Special

second

first

Host Variable

second

first

However, a host variable containing data in a foreign encoding scheme is always

converted to the native form of data before it is used in any operation. The

above rules are based on the assumption that this conversion has already

occurred.

Note that an intermediate result is considered to be a derived value operand.

For example, assume COLA, COLB, and COLC are columns with CCSIDs 37,

278, and 500, respectively. The result CCSID of COLA CONCAT COLB CONCAT

COLC would be determined as follows:

- The result of the CCSID of COLA CONCAT COLB is first determined to be

37, because both operands are columns, so the CCSID of the first operand is

chosen.

- The result CCSID of “intermediate result” CONCAT COLC is determined to

be 500, because the first operand is a derived value and the second operand

is a column, so the CCSID of the second operand is chosen.

An operand of concatenation or the selected argument of the VALUE scalar

function is converted, if necessary, to the coded character set of the result string.

Each string of an operand of UNION or UNION ALL is converted, if necessary, to

the coded character set of the result column. Character conversion is necessary

only if all of the following are true:

v The CCSIDs are different.

v Neither CCSID is 65535 (X'FFFF').

v The string is neither null nor empty.

v The CCSID Conversion Selection Table indicates that conversion is necessary.

An error occurs if a character of a string cannot be converted or if the CCSID

Conversion Selection Table is used but does not contain any information about the

CCSID pair. A warning occurs if a character of a string is converted to the

substitution character.

Examples

Example 1

Given the following:

Expression

Type

CCSID

COL_1

column

00001

HV_2

host variable

00002

COL_3

column

00003

132

SQL Reference

fullselect

When evaluating the predicate:

COL_1 CONCAT :HV_2 CONCAT COL_3

The resulting CCSID of the first two operands is 00001. Because the result of the

first concatenation is a derived string, the second concatenation will have a result

CCSID of 00003 (the column CCSID is chosen over the CCSID of the derived

string). The final CCSID is 00003.

Example 2

Using the information from the previous example, when evaluating the predicate:

VALUE(COL_1, :HV_2, COL_3)

The resulting CCSID of the first two operands is 00001. However, the expression

type is column, not derived string, since the two operands are not combined as in

the concatenation example. Using the rules for the intermediate CCSID and the

third operand’s CCSID, 00001 (the intermediate CCSID) is chosen as the final

CCSID. This is because the CCSID of the first column is chosen over the CCSID of

the second column.

select-statement

►► fullselect

►◄

order_by_clause

with_clause

for_fetch_only_clause

for_read_only_clause

(1)

update_clause

Notes:

The update-clause cannot be specified if the fullselect contains an order-by-clause.

The select-statement is the form of a query that can be directly specified in a

DECLARE CURSOR statement, or prepared and then referenced in a DECLARE

CURSOR statement. It can also be issued interactively, causing a result table to be

displayed at your terminal. In either case, the table specified by a select-statement is

the result of the fullselect.

order-by-clause

ASC

▼

►► ORDER BY

column_name

►◄

integer

DESC

The ORDER BY clause specifies an ordering of the rows of the result table. If a

single column is identified, the rows are ordered by the values of that column. If

more than one column is identified, the rows are ordered by the values of the first

identified column, then by the values of the second identified column, and so on.

A long string column must not be identified.

Chapter 5. Queries

133

order-by-clause

A named column may be identified by an integer or a column_name. An unnamed

column must be identified by an integer. A column is unnamed if it is derived

from a constant, an arithmetic expression, or a function. If the fullselect includes a

UNION operator, every column of the result table is unnamed.

column_name

Must unambiguously identify a column of the result table. Although columns

not included in the result table cannot be referenced in the ORDER BY clause,

the rules for unambiguous column references are the same as in the other

clauses of the fullselect. See “Column Name Qualifiers to Avoid Ambiguity” on

page 66 for more information

integer

Must be greater than 0 and not greater than the number of columns in the

result table. The integer n identifies the nth column of the result table.

ASC

Uses the values of the column in ascending order. This is the default.

DESC

Uses the values of the column in descending order.

Ordering is performed in accordance with the comparison rules described in

Chapter 3. The null value is higher than all other values. If your ordering

specification does not determine a complete ordering, rows with duplicate values

of the last identified column have an arbitrary order. If the ORDER BY clause is

not specified, the rows of the result table have an arbitrary order.

If a field procedure is not involved, the collating sequence depends on the CCSID

of the application server. With the DRDA protocol, the application server could be

using an ASCII CCSID, producing an unexpected result to an application program

assuming an EBCDIC CCSID and code page (see the IBM SQL Reference for

details).

for_fetch_only/for_read_only clause

The FOR FETCH/READ ONLY clause forces blocking on read only cursors

without the use of BLOCK as a preprocessing option.

If the application has been preprocessed with the NOBLOCK option (no

blocking) then the FOR FETCH ONLY will be ignored.

FOR READ ONLY is a synonym of the FOR FETCH ONLY.

update-clause

►►

FOR UPDATE OF

▼

column_name

►◄

The UPDATE clause identifies the columns that can be updated in a subsequent

Positioned UPDATE statement. Each column_name must be unqualified and must

identify a column of the table or view identified in the first FROM clause of the

fullselect. The clause must not be specified if the result table of the fullselect is

read-only.

If an UPDATE clause is specified, only the columns identified in that clause can be

updated in subsequent Positioned UPDATE statements.

134

SQL Reference

update-clause

If a dynamically prepared select-statement does not include an UPDATE clause, its

associated cursor is not updateable.

The use of this clause for statically prepared select-statements and statically

prepared Positioned UPDATE statements depends on whether the NOFOR

preprocessor option is in effect. If the UPDATE clause is not specified:

v If NOFOR is in effect, all updateable columns can be updated in subsequent

Positioned UPDATE statements.

v If NOFOR is not in effect, the cursor associated with the select-statement is not

updateable.

See the DB2 Server for VSE & VM Application Programming manual for information

on preprocessing and running programs.

If blocking is not in effect, a row may be deleted from a non-read-only table if the

FOR UPDATE OF clause is specified.

If blocking is in effect and you intend to perform a positioned delete operation,

blocking must be explicitly turned off by specifying the FOR UPDATE OF clause in

the DECLARE statement.

Notes:

1. There is no corresponding FOR DELETE OF clause.

2. The order-by clause is not allowed with the update-clause.

with-clause

►► WITH

►◄

The WITH clause specifies the isolation level at which the statement is executed.

Repeatable read

Cursor stability

Uncommitted read

WITH UR can be specified only if the result table is read-only.

The isolation level specified on the SELECT statement will override any other

isolation level specification; for example, in ISQL, if SET ISOLATION CS has been

specified, and a SELECT statement WITH UR is executed, that statement will use

an isolation level of uncommitted read. A SELECT statement without the WITH

clause will use an isolation level of CS, as defined by the SET ISOLATION

statement. As another example, a statement specifying WITH UR in a package

prepped with ISOL(CS) will use an isolation level of uncommitted read.

If a SELECT statement specifying WITH UR is used with a cursor that is not

read-only, SQLCODE -173 will be returned indicating that WITH UR cannot be

specified on a select statement used in a non-read-only cursor.

Chapter 5. Queries

135

select-statement

Examples of a select-statement

Example 1

Select all columns and rows from the EMPLOYEE table.

SELECT * FROM EMPLOYEE

Example 2

Select the project name (PROJNAME), start date (PRSTDATE), and end date

(PRENDATE) from the PROJECT table. Order the result table by the end date with

the most recent dates appearing first.

SELECT PROJNAME, PRSTDATE, PRENDATE

FROM PROJECT

ORDER BY PRENDATE DESC

Example 3

Select the department number (WORKDEPT) and average departmental salary

(SALARY) for all departments in the EMPLOYEE table. Arrange the result table in

ascending order by average departmental salary.

SELECT WORKDEPT, AVG(SALARY)

FROM EMPLOYEE

GROUP BY WORKDEPT

ORDER BY 2

Example 4

Declare a cursor named UP_CUR to be used in a PL/I program to update the start

date (PRSTDATE) and the end date (PRENDATE) columns in the PROJECT table.

The program must receive both of these values together with the project number

(PROJNO) value for each row.

EXEC SQL DECLARE UP_CUR CURSOR FOR

SELECT PROJNO, PRSTDATE, PRENDATE

FROM PROJECT

FOR UPDATE OF PRSTDATE, PRENDATE;

136

SQL Reference

Chapter 6. Statements

This chapter contains syntax diagrams, semantic descriptions, rules, and examples

of the use of the SQL statements listed in the following table.

Table 7. SQL Statements

SQL Statement

Function

Refer to Page

ACQUIRE DBSPACE

Obtains and names a dbspace.

“ACQUIRE DBSPACE” on

page 144

ALLOCATE CURSOR

Defines a cursor and associates it with a result set

“ALLOCATE CURSOR” on

locator variable.

page 146

ALTER DBSPACE

Alters the percentage of free space. Also alters the lock

“ALTER DBSPACE” on

size of a PUBLIC dbspace.

page 148

ALTER PROCEDURE

Alters the definition of an existing stored procedure.

“ALTER PROCEDURE” on

page 150

ALTER PSERVER

Alters the definition of an existing stored procedure

“ALTER PSERVER” on page

server.

155

ALTER TABLE

Adds a column to a table or manages referential

“ALTER TABLE” on page

constraints.

157

ASSOCIATE LOCATORS

Obtains the RESULT SET LOCATOR value for each

“ASSOCIATE LOCATORS”

result set returned by a stored procedure.

on page 166

BEGIN DECLARE

Marks the beginning of a host variable declaration

“BEGIN DECLARE

SECTION

section.

SECTION” on page 169

CALL

Invokes a stored procedure.

“CALL” on page 171

Closes a cursor.

“CLOSE” on page 175

Extended CLOSE

Closes a cursor defined by an Extended DECLARE

“Extended CLOSE” on page

CURSOR statement.

177

COMMENT ON

Replaces or adds a comment to the description of a

“COMMENT ON” on page

table, view, or column.

178

COMMENT ON

Replaces or adds a comment to the description of a

“COMMENT ON

PROCEDURE

stored procedure identified.

PROCEDURE” on page 180

COMMIT

Terminates a logical unit of work and commits the

“COMMIT” on page 182

database changes made by that logical unit of work.

CONNECT

Connects to an application server.

“CONNECT (for VM)” on

page 185

CREATE INDEX

Defines an index on a table.

“CREATE INDEX” on page

198

CREATE PACKAGE

Creates a package.

“CREATE PACKAGE” on

page 201

CREATE PROCEDURE

Defines a stored procedure.

“CREATE PROCEDURE”

on page 208

CREATE PSERVER

Defines a stored procedure server.

“CREATE PSERVER” on

page 216

CREATE SYNONYM

Defines an alternate name for a table or view.

“CREATE SYNONYM” on

page 218

CREATE TABLE

Defines a table.

“CREATE TABLE” on page

219

2007

137

Table 7. SQL Statements

(continued)

SQL Statement

Function

Refer to Page

CREATE VIEW

Defines a view of one or more tables or views.

“CREATE VIEW” on page

231

DECLARE CURSOR

Defines an SQL cursor.

“DECLARE CURSOR” on

page 235

Extended DECLARE

Defines a cursor that is to be associated with a

“Extended DECLARE

CURSOR

statement that was prepared using an Extended

CURSOR” on page 240

PREPARE statement.

DELETE

Deletes zero or more rows from a table.

“DELETE” on page 242

DESCRIBE

Describes the result columns of a prepared statement.

“DESCRIBE” on page 247

Extended DESCRIBE

Describes the result columns of a SELECT statement that

“Extended DESCRIBE” on

was prepared using an Extended PREPARE statement.

page 251

DESCRIBE CURSOR

Obtains information about the result set that is

“DESCRIBE CURSOR” on

associated with the cursor and puts that information

page 252

into a descriptor.

DESCRIBE PROCEDURE

Obtains information about the result sets returned by a

“DESCRIBE PROCEDURE”

stored procedure and puts that information into a

on page 254

descriptor.

DROP

Deletes a dbspace, index, package. synonym, table, or

“DROP” on page 257

view

DROP PROCEDURE

Deletes the definition of a stored procedure.

“DROP PROCEDURE” on

page 260

DROP PSERVER

Deletes the definition of a stored procedure server.

“DROP PSERVER” on page

261

DROP STATEMENT

Deletes a statement from a package created with

“DROP STATEMENT” on

CREATE PACKAGE.

page 262

END DECLARE SECTION

Marks the end of a host variable declaration section.

“END DECLARE

SECTION” on page 263

EXECUTE

Executes a prepared SQL statement.

“EXECUTE” on page 264

Extended EXECUTE

Executes an SQL statement prepared using an Extended

“Extended EXECUTE” on

PREPARE statement.

page 268

EXECUTE IMMEDIATE

Prepares and executes an SQL statement.

“EXECUTE IMMEDIATE”

on page 270

EXPLAIN

Obtains information about the structure and execution

“EXPLAIN” on page 273

performance of a DELETE, INSERT, UPDATE, or

SELECT statement.

FETCH

Assigns values of a row of a result table to host

“FETCH” on page 283

variables.

Extended FETCH

Assigns values of a row in a result table to host

“Extended FETCH” on page

variables using a cursor defined by an Extended

287

DECLARE CURSOR statement.

GRANT (Package

Grants privilege to execute statements in a package

“GRANT (Package

Privileges)

Privileges)” on page 288

GRANT (System

Grants system authorities.

“GRANT (System

Authorities)

Authorities)” on page 290

GRANT (Table Privileges)

Grants privileges on a table or view.

“GRANT (Table Privileges)”

on page 293

INCLUDE

Inserts declarations into a source program.

“INCLUDE” on page 296

138

SQL Reference

Table 7. SQL Statements

(continued)

SQL Statement

Function

Refer to Page

INSERT

Inserts zero or more rows into a table.

“INSERT” on page 298

LABEL ON

Replaces or adds a label on the description of a table,

“LABEL ON” on page 303

view, or column.

LOCK DBSPACE

Either prevents concurrent processes from changing a

“LOCK DBSPACE” on page

dbspace or prevents concurrent processes from using a

305

dbspace.

LOCK TABLE

Either prevents concurrent processes from changing a

“LOCK TABLE” on page

table or prevents concurrent processes from using a

306

table.

OPEN

Opens a cursor.

“OPEN” on page 307

Extended OPEN

Opens a cursor defined by an Extended DECLARE

“Extended OPEN” on page

CURSOR statement.

312

PREPARE

Prepares an SQL statement (with optional parameters)

“PREPARE” on page 313

for execution within the same logical unit of work.

Extended PREPARE

Prepares an SQL statement into a package created with

“Extended PREPARE” on

CREATE PACKAGE.

page 317

PUT

Inserts (a row of) data into a table.

“PUT” on page 322

Extended PUT

Inserts (a row of) data into a table using a cursor

“Extended PUT” on page

defined by an Extended DECLARE CURSOR statement.

325

REVOKE (Package

Revokes the privilege to execute statements in a

“REVOKE (Package

Privileges)

package.

Privileges)” on page 327

REVOKE (System

Revokes system authorities.

“REVOKE (System

Authorities)

Authorities)” on page 328

REVOKE (Table Privileges)

Revokes privileges on a table or view.

“REVOKE (Table

Privileges)” on page 330

ROLLBACK

Terminates a logical unit of work and backs out the

“ROLLBACK” on page 334

database changes made by that unit of work.

SELECT INTO

Specifies a result table of no more than one row and

“SELECT INTO” on page

assigns the values to host variables.

336

UPDATE

Updates the values of one or more columns in zero or

“UPDATE” on page 338

more rows of a table.

UPDATE STATISTICS

Update statistics on tables and indexes in system

“UPDATE STATISTICS” on

catalogs.

page 344

WHENEVER

Defines actions to be taken on the basis of SQL return

“WHENEVER” on page 346

codes.

How SQL Statements Are Invoked

The SQL statements described in this chapter are classified as executable or

nonexecutable. The Invocation section in the description of each statement indicates

whether the statement is executable.

An executable statement can be invoked in three ways:

v Embedded in an application program

v Dynamically prepared and processed

v Issued interactively.

Chapter 6. Statements

139

Depending on the statement, you can use some or all of these methods. The

Invocation section in the description of each statement tells you which methods can

be used.

A nonexecutable statement can only be embedded in an application program.

In addition to the statements described in this chapter, there is one more SQL

statement construct: the select-statement. (See “select-statement” on page 133.) It is

not included in this chapter because it is used differently from other statements.

A select-statement can be invoked in three ways:

v Included in DECLARE CURSOR and implicitly processed by OPEN

v Dynamically prepared, referenced in DECLARE CURSOR, and implicitly

processed by OPEN

v Entered interactively.

The first two methods are called, respectively, the static and the dynamic invocation

of select-statement.

The different methods of invoking an SQL statement are discussed below in more

detail. For each method, the discussion includes the mechanism of execution,

interaction with host variables, and testing if the execution was successful.

Embedding a Statement in an Application Program

You can include SQL statements in a source program that will be submitted to the

preprocessor. Such statements are said to be embedded in the program. An

embedded statement can be placed where a similar host language statement is

allowed in the program. You must precede each embedded statement with EXEC

SQL.

Executable statements

An executable statement embedded in an application program is run every time a

statement of the host language would be processed if specified in the same place.

(Thus, for example, a statement within a loop is run every time the loop is

processed, and a statement within a conditional construct is run only when the

condition is satisfied.)

An embedded statement can contain references to host variables. A host variable

referenced in this way can be used in two ways:

v As input (the current value of the host variable is used in the execution of the

statement)

v As output (the variable is assigned a new value as a result of executing the

statement).

In particular, all references to host variables in expressions and predicates are

effectively replaced by current values of the variables, that is, the variables are

used as input. The treatment of other references is described individually for each

statement.

All executable statements should be followed by a test of an SQL return code (see

“SQL Return Codes” on page 142). Alternatively, you can use the WHENEVER

statement (which is itself nonexecutable) to change the flow of control immediately

after the execution of an embedded statement.

140

SQL Reference

If the program is prepared with the NOEXIST option (see the DB2 Server for VSE &

VM Application Programming manual), then objects referenced in SQL statements

need not exist when the statements are prepared.

Nonexecutable statements

An embedded nonexecutable statement is processed only by the preprocessor. The

preprocessor reports any errors encountered in the statement. The statement is

never processed, and acts as a no-operation if placed among executable statements

of the application program. Therefore, you should not follow such statements by a

test of an SQL return code.

Dynamic Preparation and Execution

Your application program can dynamically build an SQL statement in the form of a

character string placed in a host variable. In general, the statement is built from

some data available to the program (for example, input from a terminal). The

statement so constructed can be prepared for execution by means of the

(embedded) statement PREPARE and processed by means of the (embedded)

statement EXECUTE. Alternatively, you can use the (embedded) statement

EXECUTE IMMEDIATE to prepare and process a statement in one step.

A statement that is going to be dynamically prepared must not contain references

to host variables. It can instead contain parameter markers. (See “PREPARE” on

page 313 for rules concerning the parameter markers.) When the prepared

statement is processed, the parameter markers are effectively replaced by current

values of the host variables specified in the EXECUTE statement. (See “EXECUTE”

on page 264 for rules concerning this replacement.) After prepared, a statement can

be processed several times with different values of host variables. Note that

parameter markers are not allowed in EXECUTE IMMEDIATE.

The successful or unsuccessful execution of the statement is indicated by the

setting of an SQL return code in the SQLCA after the EXECUTE (or EXECUTE

IMMEDIATE) statement. You should check the SQL return code as described above

for embedded statements. See “SQL Return Codes” on page 142 for more

information.

Static Invocation of a select-statement

You can include a select-statement as a part of the (nonexecutable) statement

DECLARE CURSOR. Such a statement is processed every time you open the cursor

by means of the (embedded) statement OPEN. After the cursor is open, you can

retrieve the result table a row at a time by successive executions of the FETCH

statement.

The select-statement used in this way may contain references to host variables.

These references are effectively replaced by the values that the variables have at

the moment of executing OPEN.

Dynamic Invocation of a select-statement

Your application program can dynamically build a select-statement in the form of a

character string placed in a host variable. In general, the statement is built from

some data available to the program (for example, a query obtained from a

terminal). The statement so constructed can be prepared for execution by means of

the (embedded) statement PREPARE, and referenced by a (nonexecutable)

statement DECLARE CURSOR. The statement is then processed every time you

Chapter 6. Statements

141

open the cursor by means of the (embedded) statement OPEN. After the cursor is

open, you can retrieve the result table one row at a time by successive executions

of the FETCH statement.

The select-statement used in that way must not contain references to host variables.

It can instead contain parameter markers. (See “PREPARE” on page 313 for rules

concerning the parameter markers.) The parameter markers are effectively replaced

by the values of the host variables specified in the OPEN statement. (See “OPEN”

on page 307 for rules concerning this replacement.)

Interactive Invocation

A capability for entering SQL statements from a terminal is part of the architecture

of the database manager. This product provides ISQL and the Database Services

utility for this facility. An associated product, Query Management Facility (QMF),

also provides interactive access to DB2 Server for VSE & VM databases. A

statement entered in this way is said to be issued interactively. See the DB2 Server

for VSE & VM Interactive SQL Guide and Reference manual and the DB2 Server for

VSE & VM Database Services Utility manual for more information and examples.

A statement issued interactively must be an executable statement that does not

contain parameter markers or references to host variables. These make sense only

in the context of an application program.

SQL Return Codes

An application program containing executable SQL statements must either provide

a structure named SQLCA or a stand-alone integer variable named SQLCODE

(SQLCOD in Fortran and RPG). An SQLCA is provided automatically in REXX and

RPG. In other languages, an SQLCA can be obtained by using the INCLUDE

SQLCA statement. INCLUDE SQLCA must not be used if a stand-alone SQLCODE

is provided.

The SQLCA includes an integer variable named SQLCODE (SQLCOD in Fortran

and RPG). The option of providing a stand-alone SQLCODE instead of an SQLCA

allows for conformance with the ISO/ANSI SQL standard. This option can be

requested with either the STDSQL(89) or NOSQLCA preprocessor option as

described in the DB2 Server for VSE & VM Application Programming manual.

SQLCODE

Regardless of whether the application program provides an SQLCA or a

stand-alone variable, SQLCODE is set by the database manager after each SQL

statement is processed. All IBM database managers conform to the ISO/ANSI SQL

standard, as follows:

v If SQLCODE = 0 and SQLWARN0 is blank, execution was successful.

v If SQLCODE = 100, “no data” was found. For example, a FETCH statement

returned no data, because the cursor was positioned after the last row of the

result table.

v If SQLCODE > 0 and not = 100, execution was successful with a warning.

v If SQLCODE = 0 and SQLWARN0 = 'W', execution was successful with a

warning.

v If SQLCODE < 0, execution was not successful.

The meaning of SQLCODE values other than 0 and 100 is usually product-specific.

142

SQL Reference

SQLSTATE

SQLSTATE is also set by the database manager after execution of each SQL

statement. Thus, application programs can check the execution of SQL statements

by testing SQLSTATE instead of SQLCODE. SQLSTATE (SQLSTT in Fortran and

RPG) is a character string variable in the SQLCA.

SQLSTATE provides application programs with common codes for common error

conditions. Furthermore, SQLSTATE is designed so that application programs can

test for specific errors or classes of errors. The coding scheme is the same for all

database managers and is based on the proposed ISO/ANSI SQL2 standard. See

“SQLSTATEs” in the DB2 Server for VM Messages and Codes or the DB2 Server for

VSE Messages and Codes manual for more information and a complete list of the

possible values of SQLSTATE.

SQL Comments

Static SQL statements can include host language or SQL comments. SQL comments

are introduced by two hyphens.

These rules apply to the use of SQL comments:

v The two hyphens must be on the same line, not separated by a space.

v Comments can be started wherever a space is valid (except within a delimiter

token or before or between 'EXEC' and 'SQL').

v Comments are terminated by the end of line.

v Comments are not allowed within statements that are dynamically prepared

(using PREPARE or EXECUTE IMMEDIATE) or prepared using any of the

extended dynamic PREPARE statements.

v In COBOL, the hyphens must be preceded by a space.

For host language rules regarding the use of SQL comments, see the DB2 Server for

VSE & VM Application Programming manual.

Example

This example shows how to include comments in a statement:

CREATE VIEW PRJ_MAXPER -- projects with most support personnel

AS SELECT PROJNO, PROJNAME -- number and name of project

FROM PROJECT

WHERE DEPTNO = ’E21’ -- systems support dept code

AND PRSTAFF > 1

Chapter 6. Statements

143

ACQUIRE DBSPACE

The ACQUIRE DBSPACE statement causes the database manager to find and name

an available dbspace.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

The privileges held by the authorization ID of the statement must include at least

one of the following:

v DBA authority to acquire either a public dbspace or a dbspace for another user

v RESOURCE authority to acquire a private dbspace.

Syntax

►► ACQUIRE

PUBLIC

DBSPACE NAMED dbspace_name

►

PRIVATE

►

►◄

(1)

▼

(

NHEADER =

integer

)

128

PAGES =

integer

PCTINDEX =

integer

PCTFREE =

integer

PAGE

LOCK =

DBSPACE

ROW

STORPOOL = integer

Notes:

If any of these clauses is specified more than once, the value with the first

specification is used.

Description

PUBLIC/PRIVATE

Is the type of dbspace requested. If the dbspace is PUBLIC, its owner becomes

PUBLIC; if the type is PRIVATE, its owner becomes the authorization ID of the

statement.

NAMED dbspace-name

Provides a name for the dbspace. The name must be a valid SQL identifier. It

must be unique within all the dbspaces owned by the same user, but may

duplicate the name of a dbspace owned by another user.

If the dbspace name of a private dbspace is qualified, the qualifier is the owner

of the dbspace. Otherwise, the authorization ID of the statement is the owner

of the dbspace. The owner has all privileges on the dbspace. The privileges can

be granted by the owner and cannot be revoked from the owner.

144

SQL Reference

ACQUIRE DBSPACE

If the dbspace name of a public dbspace is qualified, the qualifier must be

"PUBLIC".

NHEADER

Is the number of 4096-byte logical pages in the dbspace that the database

manager reserves for header pages. Header pages record information about the

contents of the dbspace. NHEADER cannot be larger than eight pages.

PAGES

Is the minimum number of 4096-byte logical pages required for this dbspace.

The database manager determines the page number by rounding the number

you specify to the next higher multiple of 128.

PCTINDEX

Is the percentage of all pages in the dbspace that the database manager is to

reserve for the construction of indexes.

PCTFREE

Is the percentage of space on each page that the database manager is to keep

free when data is inserted into the dbspace.

LOCK

Is the lock size, applicable to public dbspaces only. The lock size determines

the extent of locking that the database manager acquires when a user reads or

updates data. If ROW is specified, only a row in the table is locked; PAGE or

DBSPACE cause the smallest lockable unit to be a page (4096 bytes) or the

dbspace, respectively.

STORPOOL

Is the storage pool number. This parameter tells the database manager to

acquire the dbspace from a specified storage pool. If a dbspace of the specified

type and size is not available in the storage pool, the ACQUIRE DBSPACE is

not successful and the database manager returns an error. If STORPOOL is not

specified, the database manager acquires a dbspace of the correct size and type

from any recoverable storage pool. For more information, see the DB2 Server

for VM System Administration or DB2 Server for VSE System Administration

manual.

Examples

Acquire a private dbspace in storage pool number 3 and call it FCPSPACE. Leave

25% of the space free on each page.

ACQUIRE PRIVATE DBSPACE NAMED FCPSPACE

(STORPOOL=3, PCTFREE=25)

Chapter 6. Statements

145

ALLOCATE CURSOR

The ALLOCATE CURSOR statement defines a cursor and associates it with a result

set locator variable.

Invocation

This statement can be embedded in an application program. It is an executable

statement that can be dynamically prepared. It cannot by issued interactively.

Authorization

None required.

Syntax

►► ALLOCATE cursor-name CURSOR FOR RESULT SET rs-locator-variable

►◄

Description

cursor-name

Identifies a cursor name, which must be unique within the logical unit of work

in which it is used. It is an ordinary identifier.

CURSOR FOR RESULT SET rs-locator-variable

Identifies a result set locator variable that has been declared in the application

program according to the rules for declaring result set locator variables. The

result set locator variable must contain a valid result set locator value, as is

returned by the ASSOCIATE LOCATORS or DESCRIBE PROCEDURE SQL

statement.

Notes

Dynamically prepared ALLOCATE CURSOR statements:

One restriction is that a statement identifier cannot be used for an ALLOCATE

CURSOR statement if the same statement identifier has been used for a

DECLARE CURSOR statement. For example, the following SQL statements are

not valid because the PREPARE statement uses STMT1 as an identifier for the

ALLOCATE CURSOR statement when it has already been used for a DECLARE

CURSOR statement:

DECLARE C1 CURSOR FOR STMT1;

PREPARE STMT1 FROM

’ALLOCATE C2 CURSOR FOR RESULT SET ?’; INVALID

If an ALLOCATE CURSOR statement is dynamically prepared, the DYNALC

prep option must be used for the preprocessor to successfully process any

FETCH statements issued against the allocated cursor. If the prep option is not

used, the preprocessor returns SQLCODE -504 for these FETCH statements

because the cursor was not identified by the prep.

Rules for using an allocated cursor:

The following rules apply when you use an allocated cursor:

v You cannot open an allocated cursor by using the SQL OPEN cursor

statement.

v You can close an allocated cursor by using the SQL CLOSE cursor statement.

This closes the cursor in the stored procedure as well.

146

SQL Reference

ALLOCATE CURSOR

v You can allocate only one cursor to each result set.

3. Mortality of an allocated cursor:

A rollback and an implicit and explicit close will destroy allocated cursors. A

commit destroys allocated cursors that are not defined WITH HOLD by the

stored procedure. However, note that DB2 Server for VSE & VM does not

support CURSOR WITH HOLD. Destroying an allocated cursor closes the

associated cursor in the stored procedure.

4. For the ALLOCATE CURSOR statement to be successful, the application must

be connected to the site at which the stored procedure was executed.

Examples

The statement in the following example is assumed to be in a PL/I program.

Define and associate cursor C1 with the result set locator variable :loc1 and the

related result set returned by the stored procedure:

EXEC SQL ALLOCATE C1 CURSOR FOR RESULT SET :loc1

Chapter 6. Statements

147

ALTER DBSPACE

The ALTER DBSPACE statement lets you change the amount of free space that the

database manager reserves on each data page, and lets you change the type of a

lock on a public dbspace.

Invocation

This statement can be embedded in an application program or issued interactively.

It is an executable statement that can be dynamically prepared.

Authorization

The privileges held by the authorization ID of the statement must include at least

one of the following:

v For a private dbspace:

Ownership of the dbspace or

DBA authority.

v For a public dbspace:

DBA authority.

Syntax

(1)

▼

►► ALTER DBSPACE dbspace_name

(

PCTFREE = integer

)

►◄

LOCK =

PAGE

DBSPACE

ROW

Notes:

If either of these clauses is specified more than once, the value with the first

specification is used.

Description

dbspace_name

Identifies the dbspace to be changed. It must be a dbspace that exists at the

application server.

PCTFREE

Is the percentage of space on each page that the database manager is to keep

empty when inserting data into the dbspace’s tables. A common practice is to

set PCTFREE to a higher value when a dbspace is acquired, load the data, and

create an index defined in the same order as the data was loaded. After this

process is complete, the PCTFREE is lowered. Some or all of the free space is

now available for inserts. The judicious use of reserved free space may result

in a more favorable placement of data on pages and, therefore, improve access

time.

LOCK

Alters the lock size of a public dbspace. The valid lock sizes are DBSPACE,

PAGE, and ROW. If DBSPACE is specified, the system locks the whole

dbspace. Page causes the smallest lockable unit to be a page (4096 bytes); ROW

causes this unit to be a row.

148

SQL Reference

ALTER PROCEDURE

The ALTER PROCEDURE statement is used to alter the definition of an existing

stored procedure. It updates the catalog and the corresponding cached information.

The STOP PROC command must be issued with the REJECT option before the

ALTER PROCEDURE statement will be accepted.

Invocation

This statement can be issued from an application program or interactively. It is an

executable statement that can be dynamically prepared.

Authorization

The issuer of the ALTER PROCEDURE must have DBA authority.

Syntax

ALTER PROCEDURE

►► ALTER PROCEDURE procedure-name

►

AUTHID authid

(1)

► ▼

►◄

options

Notes:

One or more clauses may be specified, however each clause may be specified

at most once.

150

SQL Reference

ALTER PROCEDURE

options:

LANGUAGE ASSEMBLE

COBOL

PLI

EXTERNAL NAME external-program-name

SERVER GROUP

server-group-name

DEFAULT SERVER GROUP YES

DEFAULT SERVER GROUP NO

(1)

GENERAL

PARAMETER STYLE

(2)

GENERAL WITH

NULLS

STAY RESIDENT NO

YES

PROGRAM TYPE MAIN

(3)

PROGRAM TYPE SUB

RUN OPTIONS run-time-options

RESULT

SET

integer

SETS

COMMIT ON RETURN NO

YES

(4)

(5)

NOT DETERMINISTIC

(4)

(6)

DETERMINISTIC

(4)

CONTAINS SQL

(4)

NO SQL

(4)

READS SQL DATA

(4)

MODIFIES SQL DATA

(4)

NO COLLID

(4)

COLLID collection-id

(4)

WLM ENVIRONMENT

name

(name,*)

(4)

NO WLM ENVIRONMENT

(4)

ASUTIME

NO LIMIT

LIMIT integer

(4)

EXTERNAL SECURITY DB2

USER

DEFINER

(4)

NO DBINFO

(4)

DBINFO

Notes:

SIMPLE CALL may be used as an alternative to GENERAL. This is for

compatibility within the DB2 family.

SIMPLE CALL WITH NULLS may be used as an alternative to GENERAL

WITH NULLS. This is for compatibility within the DB2 family.

Currently, DB2 Server for VSE & VM supports stored procedures written as

main programs only.

This parameter is included for compatibility with the DB2 family. If specified,

it is ignored.

Chapter 6. Statements

151

ALTER PROCEDURE

VARIANT may be specified as an alternative to NOT DETERMINISTIC. This

is for compatibility within the DB2 family.

NOT VARIANT may be specified as an alternative to DETERMINISTIC. This

is for compatibility within the DB2 family.

Only the parameters that are meaningful to DB2 Server for VSE & VM are

described here. If a parameter is not specified on the ALTER PROCEDURE

statement, its value is unchanged.

Description

procedure-name

Names the stored procedure. For DB2 Server for VSE & VM, the name must be

an ordinary identifier of 18 characters or less.

authid

The authorization ID for the stored procedure. The authid must be an ordinary

identifier of 8 characters or less. If specified, then only the version of

procedure-name that is accessible only by authid will be altered.

LANGUAGE

Specifies the programming language used to create the stored procedure. All

stored procedure programs must be designed to run in the IBM Language

Environment.

ASSEMBLE

Specifies that the stored procedure is written in Assembler.

Specifies that the stored procedure is written in C.

COBOL

Specifies that the stored procedure is written in COBOL.

PLI

Specifies that the stored procedure is written in PLI.

EXTERNAL NAME external-program-name

Identifies the load module or phase associated with the stored procedure. The

external-program-name must be an ordinary identifier of 8 characters or less. The

load module or phase does not need to exist when the ALTER PROCEDURE

statement is issued. However, when a CALL for the stored procedure is issued,

the load module must exist and be accessible to the stored procedure server.

SERVER GROUP server-group-name

Identifies the group of stored procedure servers in which this stored procedure

will run. If specified, server-group-name must be an ordinary identifier of 18

characters or less. server-group-name must be defined in

SYSTEM.SYSPSERVERS.

The SERVER GROUP clause can be specified without a server group name.

This provides the ability to take a stored procedure out of a named group and

move it to the default group. If server-group-name is not specified, the stored

procedure must be able to run in the default group. The DEFAULT SERVER

GROUP clause determines whether the stored procedure can run in the default

stored procedure server group.

DEFAULT SERVER GROUP

Specifies whether the stored procedure can run in the default server group.

YES The stored procedure can run in the default server group.

NO The stored procedure cannot run in the default server group. If NO is

152

SQL Reference

DB2 Server for VSE & VM SQL Reference (Version 7 Release 5) - page 4
