289

Drivin

WARNING

■

Driving with snow tires
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in a loss of vehicle control and cause death or
serious injury.

●

Use tires of the size specified.

●

Maintain the recommended level of air pressure.

●

Do not drive in excess of 75 mph (120 km/h), regardless of the type of
snow tires being used.

●

Use snow tires on all, not just some wheels.

■

Driving with tire chains
Observe the following precautions to reduce the risk of accidents.
Failure to do so may result in the vehicle being unable to be driven safely,
and may cause death or serious injury.

●

Do not drive in excess of the speed limit specified for the tire chains being
used, or 30 mph (50 km/h), whichever is lower.

●

Avoid driving on bumpy road surfaces or over potholes.

●

Avoid sudden acceleration, abrupt steering, sudden braking and shifting
operations that cause sudden engine braking.

●

Slow down sufficiently before entering a curve to ensure that vehicle con-
trol is maintained.

NOTICE

■

Repairing or replacing snow tires
Request repairs or replacement of snow tires from Toyota dealers or legiti-
mate tire retailers.
This is because the removal and attachment of snow tires affects the opera-
tion of the tire pressure warning valves and transmitters.

■

Fitting tire chains
The tire pressure warning valves and transmitters may not function correctly
when tire chains are fitted

290

4-6. Driving tips

291

Interior features

5-1. Using the air conditioning

system and defogger

Air conditioning system ..... 292
Seat heaters...................... 300

5-2. Using the interior lights

Interior lights list ................ 302

• Interior lights ................. 303
• Personal lights .............. 304

5-3. Using the storage

features

List of storage features ..... 305

• Glove box...................... 306
• Console box.................. 306
• Bottle holders................ 307
• Cup holders .................. 308

Luggage compartment

features........................... 309

5-4. Using the other interior

features

Other interior features ....... 315

• Sun visors ..................... 315
• Vanity mirrors................ 315
• Clock............................. 316
• Power outlet.................. 317
• Assist grips ................... 318

Safety Connect ................. 319

292

5-1. Using the air conditioning system and defogger

Air conditioning system

■

Adjusting the temperature setting

Increases the temperature
Decreases the temperature

If the

indicator is turned

off, the system will blow ambient
temperature air or heated air.

Air outlets are automatically selected and fan speed is automati-
cally adjusted according to the set temperature setting.

Air conditioning controls

293

5-1. Using the air conditioning system and defogger

rior

ures

■

Fan speed setting

Increases the fan speed
Decreases the fan speed

Press

to turn the fan off.

■

Change the airflow mode
To change the airflow mode,
move the airflow change knob
upward or downward.

The air outlets used are
changed each time the knob is
operated.

Air flows to the upper body.
Air  flows  to  the  upper  body
and feet.
Air flows to the feet.
Air  flows  to  the  feet  and  the
windshield  defogger  oper-
ates.

294

5-1. Using the air conditioning system and defogger

Press

The dehumidification function begins to operate. Air outlets and fan
speed are automatically adjusted according to the temperature set-
ting.
Adjust the temperature setting.

To stop the operation, press

■

Automatic mode indicator
If the fan speed setting or air flow modes are operated, the auto-
matic mode indicator goes off. However, automatic mode for func-
tions other than that operated is maintained.

■

Adjusting the temperature for driver and passenger seats sep-
arately
To turn on the dual control mode, perform any of the following pro-
cedures:

● Press

● Adjust the passenger’s side temperature setting.

The indicator comes on when the dual control mode is on.

Using automatic mode

295

5-1. Using the air conditioning system and defogger

rior

ures

■

Switching between outside air and recirculated air modes

Press

The mode switches between outside air mode (indicator off) and recir-

culated air mode (indicator on) each time

is pressed.

■

Defogging the windshield
Defoggers are used to defog the windshield and front side win-
dows.

Press

The dehumidification function operates and fan speed increases.
Set the outside/recirculated air mode button to the outside air mode if
the recirculated air mode is used. (It may switch automatically.)
To defog the windshield and the front side windows early, turn the air
flow and temperature up.

To return to the previous mode, press

again when the windshield

is defogged.

■

Defogging the rear window and outside rear view mirrors
Defoggers are used to defog the rear window, and to remove rain-
drops, dew and frost from the outside rear view mirrors.

Press

The defoggers will automatically turn off after a period of time.

■

Windshield wiper de-icer (if equipped)
This feature is used to prevent ice from building up on the wind-
shield and wiper blades.
Press

The windshield wiper de-icer will automatically turn off after a period of
time.

Other functions

296

5-1. Using the air conditioning system and defogger

■

Climate control customization
Climate control setting can be changed.

Press

The air conditioning is controlled with low fuel consumption prioritized
such as reducing fan speed, etc.

■

Location of air outlets
The air outlets and air volume
change

according

the

selected airflow mode.
(

P. 293)

■

Adjusting the position of and opening and closing the air out-
lets

Direct air flow to the left or
right, up or down.
Turn the knob to open or
close the vent.

Air outlets

297

5-1. Using the air conditioning system and defogger

rior

ures

■

Using automatic mode
Fan speed is adjusted automatically according to the temperature setting and
the ambient conditions.
Therefore, the fan may stop for a while until warm or cool air is ready to flow

immediately after

is pressed.

■

Fogging up of the windows

●

The windows will easily fog up when the humidity in the vehicle is high.

Turning

on will dehumidify the air from the outlets and defog the

windshield effectively.

●

If you turn

off, the windows may fog up more easily.

●

The windows may fog up if the recirculated air mode is used.

■

Outside/recirculated air mode

●

When driving on dusty roads, in tunnels, or in heavy traffic set the outside/
recirculated air mode button to the recirculated air mode. This is effective in
preventing outside air from entering the vehicle interior. During cooling oper-
ation, setting the recirculated air mode will also cool the vehicle interior
effectively.

●

Outside/recirculated air mode may automatically switch depending on the
temperature setting or the inside temperature.

■

Operation of the air conditioning system in Eco drive mode

●

In Eco drive mode, the air conditioning system is controlled as follows to pri-
oritize fuel efficiency:
• Engine speed and compressor operation controlled to restrict heating/

cooling capacity

• Fan speed restricted when automatic mode is selected

●

To improve air conditioning performance, perform the following operations:
• Adjust the fan speed
• Adjust the temperature setting
• Turn off Eco drive mode

●

Even when the drive mode is set to Eco drive mode, the air conditioning eco

mode can be turned off by pressing

298

5-1. Using the air conditioning system and defogger

■

When the outside temperature exceeds 75°F (24°C) and the air condition-
ing system is on

●

In order to reduce the air conditioning power consumption, the air condition-
ing system may switch to recirculated air mode automatically. This may also
reduce fuel consumption.

●

Recirculated air mode is selected as a default mode when the engine switch
is turned to the “ON” position (vehicles without a smart key system) or
IGNITION ON mode (vehicles with a smart key system).

●

It is possible to switch to outside air mode at any time by pressing

■

When the outside temperature falls to nearly 32

F (0C)

The dehumidification function may not operate even when

is pressed.

■

Ventilation and air conditioning odors

●

To let fresh air in, set the air conditioning system to the outside air mode.

●

During use, various odors from inside and outside the vehicle may enter into
and accumulate in the air conditioning system. This may then cause odor to
be emitted from the vents.

●

To reduce potential odors from occurring:
• It is recommended that the air conditioning system be set to outside air

mode prior to turning the vehicle off.

• The start timing of the blower may be delayed for a short period of time

immediately after the air conditioning system is started in automatic
mode.

■

Air conditioning filter
P. 382

■

Customization
Settings (e.g. air conditioning setting) can be changed.
(Customizable features

P. 486)

299

5-1. Using the air conditioning system and defogger

rior

ures

WARNING

■

To prevent the windshield from fogging up

●

Do not use

during cool air operation in extremely humid weather.

The difference between the temperature of the outside air and that of the
windshield can cause the outer surface of the windshield to fog up, block-
ing your vision.

■

To prevent burns

●

Do not touch the rear view mirror surfaces when the outside rear view mir-
ror defoggers are on.

●

Do not touch the glass at the lower part of the windshield or to the side of
the front pillars when the windshield wiper de-icer is on.

NOTICE

■

To prevent battery discharge
Do not leave the air conditioning system on longer than necessary when the
engine is stopped.

●

Do not place anything on the instrument
panel  which  may  cover  the  air  outlets.
Otherwise,  air  flow  may  be  obstructed,
preventing  the  windshield  defoggers
from defogging.

300

5-1. Using the air conditioning system and defogger

Seat heaters



: If equipped

Seat heaters heat the front seats.

WARNING

●

Care should be taken to prevent injury if anyone in the following categories
comes in contact with the seats when the heater is on:
• Babies, small children, the elderly, the sick and the physically chal-

lenged

• Persons with sensitive skin
• Persons who are fatigued
• Persons who have taken alcohol or drugs that induce sleep (sleeping

drugs, cold remedies, etc.)

●

Observe the following precautions to prevent minor burns or overheating:
• Do not cover the seat with a blanket or cushion when using the seat

heater.

• Do not use seat heater more than necessary.

NOTICE

●

Do not put heavy objects that have an uneven surface on the seat and do
not stick sharp objects (needles, nails, etc.) into the seat.

●

To prevent battery discharge, do not use the functions when the engine is
not running.

301

5-1. Using the air conditioning system and defogger

rior

ures

Each time the switch is pressed,
the operation condition changes
as follows.
Hi (3 segments lit)

 Mid (2 seg-

ments lit)

 Lo (1 segment lit) 

Off

The level indicator (amber) light up
during operation.

■

Operation condition



Vehicles without a smart key system

The seat heaters can be used when the engine switch is in the “ON” position.



Vehicles with a smart key system

The seat heaters can be used when the engine switch is in IGNITION ON
mode.

Operating instructions

302

5-2. Using the interior lights

Interior lights list

Vanity lights (if equipped) (

P. 315)

Front interior light/front personal lights (

P. 303 , 304)

Rear interior light (

P. 303)

Engine switch light (vehicles with a smart key system)
Glove box light (

P. 306)

Cup holder illumination (if equipped)
Door trim lights (if equipped)

303

5-2. Using the interior lights

rior

ures

■

Front
Turns the door position on/off

■

Rear

On
Door position

Operation is linked with the front
interior light main switch. When
the switch is off, the light does
not illuminate.

Off

Interior lights

304

5-2. Using the interior lights

Turns the lights on/off

When the lights are on due to the
door link switch, a light will not turn
off even if its switch is pressed.

■

Illuminated entry system



Vehicles without a smart key system

When the interior light switch is in the door position, the interior lights auto-
matically turn on/off according to the engine switch position, whether the
doors are locked/unlocked and whether the doors are open/closed.



Vehicles with a smart key system

When the interior light switch is in the door position, the interior lights and
engine switch light automatically turn on/off according to engine switch mode,
the presence of the electronic key, whether the doors are locked/unlocked
and whether the doors are open/closed.

■

Outer mirror illumination (if equipped)
The illumination automatically turns on according to the presence of the elec-
tronic key (vehicles with a smart key system), or the doors are unlocked.

■

To prevent battery discharge
The following lights will turn off automatically after 20 minutes:

●

Front interior light/front personal lights

●

Rear interior light

●

Luggage compartment light

●

Vanity lights (if equipped)

■

Customization
Settings (e.g. the time elapsed before lights turn off) can be changed.
(Customizable features:

P. 486)

Personal lights

Content .. 17 18 19 20 ..
