To prevent sensor error
To ensure that the sensors operate prop-
erly, do not touch or cover them.

WARNING

Do not adjust the position of the mirror while driving.
Doing so may lead to mishandling of the vehicle and cause an accident,
resulting in death or serious injury.

146

Outside rear view mirrors

To select a mirror to adjust, turn
the switch.

Left
Right

To adjust the mirror, operate the
switch.

Up
Right
Down
Left

Adjustment procedure

147



Manual type

Push the mirror back in the direc-
tion of the rear of the vehicle.



Power type

Folds the mirrors
Extends the mirrors

Putting the outside rear view mirror
folding  switch  in  the  neutral  posi-
tion  sets  the  mirrors  to  automatic
mode.
Automatic mode allows the folding
or  extending  of  the  mirrors  to  be
linked  to  locking/unlocking  of  the
doors.

Folding and extending the mirrors

148

■

Mirror angle can be adjusted when
Vehicles without a smart key system:
The engine switch is in the “ACC” or “ON” position.
Vehicles with a smart key system:
The engine switch is in ACCESSORY or IGNITION ON mode.

■

When the mirrors are fogged up
The outside rear view mirrors can be cleared using the mirror defoggers. Turn
on the rear window defogger to turn on the outside rear view mirror defog-
gers. (

P. 295)

■

Using the automatic folding/extending mirror function in cold weather (if
equipped)
When the automatic folding/extending mirror function is used in cold weather,
the outside rear view mirrors could freeze up and automatic folding and
extension may not be possible. In this event, remove any ice and snow from
the outside rear view mirror, then operate the mirror manually by using the
mirror fold switch or moving the mirror by hand.

■

Customization
The automatic mirror folding and extending operation can be changed.
(Customizable features:

P. 486)

WARNING

■

Important points while driving
Observe the following precautions while driving.
Failure to do so may result in loss of control of the vehicle and cause an
accident, resulting in death or serious injury.

●

Do not adjust the mirrors while driving.

●

Do not drive with the mirrors folded.

●

Both the driver and passenger side mirrors must be extended and properly
adjusted before driving.

■

When a mirror is moving
To avoid personal injury and mirror malfunction, be careful not to get your
hand caught by the moving mirror.

■

When the mirror defoggers are operating
Do not touch the rear view mirror surfaces, as they can become very hot
and burn you.

149

Power windows

The power windows can be opened and closed using the switches.
Operating the switch moves the windows as follows:

Closing
One-touch closing

Opening
One-touch opening

: To stop the window partway, oper-

ate the switch in the opposite direc-
tion.

Press the switch down to lock the
passenger windows.

Use this switch to prevent children
from accidentally opening or clos-
ing a passenger window.
Press the switch again to unlock
the passenger windows.

Opening and closing procedures

Window lock switch

150

■

The power windows can be operated when
Vehicles without a smart key system:
The engine switch is in the “ON” position.
Vehicles with a smart key system:
The engine switch is in IGNITION ON mode.

■

Operating the power windows after turning the engine off
Vehicles without a smart key system:
The power windows can be operated for approximately 45 seconds after the
engine switch is turned to the “ACC” or “LOCK” position. They cannot, how-
ever, be operated once either front door is opened.
Vehicles with a smart key system:
The power windows can be operated for approximately 45 seconds after the
engine switch is turned to ACCESSORY mode or turned off. They cannot,
however, be operated once either front door is opened.

■

Jam protection function
If an object becomes jammed between the side window and the window
frame while the side window is closing, side window movement is stopped
and the side window is opened slightly.

■

Catch protection function
If an object becomes caught between the door and side window while the
side window is opening, side window movement is stopped.

151

■

When the side window cannot be opened or closed
When the jam protection function or catch protection function operates
unusually and the side window cannot be opened or closed, perform the fol-
lowing operations with the power window switch of that door.

●

Stop  the  vehicle.  With  the  engine  switch  is  in  the  “ON”  position  (vehicles
without a smart key system) or IGNITION ON mode (vehicles with a smart
key system), within 4 seconds of the jam protection function or catch protec-
tion  function  activating,  continuously  operate  the  power  window  switch  in
the  one-touch  closing  direction  or  one-touch  opening  direction  so  that  the
side window can be opened and closed.

●

If the side window cannot be opened and closed even when performing the
above operations, perform the following procedure for function initialization.

Turn the engine switch to the “ON” position (vehicles without a smart key
system) or IGNITION ON mode (vehicles with a smart key system).
Pull and hold the power window switch in the one-touch closing direction
and completely close the side window.
Release  the  power  window  switch  for  a  moment,  resume  pulling  the
switch  in  the  one-touch  closing  direction,  and  hold  it  there  for  approxi-
mately 6 seconds or more.
Press and hold the power window switch in the one-touch opening direc-
tion. After  the  side  window  is  completely  opened,  continue  holding  the
switch for an additional 1 second or more.
Release  the  power  window  switch  for  a  moment,  resume  pushing  the
switch in the one-touch opening direction, and hold it there for approxi-
mately 4 seconds or more.
Pull and hold the power window switch in the one-touch closing direction
again. After the side  window is completely closed,  continue holding the
switch for a further 1 second or more.

If you release the switch while the window is moving, start again from the
beginning. If the window reverses and cannot be fully closed or opened, have
the vehicle inspected by your Toyota dealer.

152

■

Door lock linked window operation

●

The power windows can be opened and closed using the key or mechanical
key.

(

P. 113, 448)

●

The power windows can be opened using the wireless remote control.

(

P. 112)

: These settings must be customized at your Toyota dealer.

■

Power window open reminder function
The buzzer sounds and a message is shown on the multi-information display
in the instrument cluster when the engine switch is turned off and the driver’s
door is opened with the power windows open.

■

Customization
Some functions can be changed. (

P. 486)

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

Closing the windows

●

The driver is responsible for all the power window operations, including the
operation for the passengers. In order to prevent accidental operation,
especially by a child, do not let a child operate the power windows. It is
possible for children and other passengers to have body parts caught in
the power window. Also, when riding with a child, it is recommended to use
the window lock switch. (

P. 149)

●

Check to make sure that all passengers
do not have any part of their body in a
position where it could be caught when
a window is being operated.

153

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

Closing the windows

●

When using the wireless remote control, key or mechanical key (

P. 104)

and operating the power windows, operate the power window after check-
ing to make sure that there is no possibility of any passenger having any of
their body parts caught in the side window. Also do not let a child operate
side window by the wireless remote control, key or mechanical key. It is
possible for children and other passengers to get caught in the power win-
dow.

●

When exiting the vehicle, turn the engine switch off, carry the key and exit
the vehicle along with the child. There may be accidental operation, due to
mischief, etc., that may possibly lead to an accident.

■

Jam protection function

●

Never use any part of your body to intentionally activate the jam protection
function.

●

The jam protection function may not work if something gets jammed just
before the side window is fully closed. Be careful not to get any part of
your body jammed in the side window.

■

Catch protection function

●

Never use any part of your body or clothing to intentionally activate the
catch protection function.

●

The catch protection function may not work if something gets caught just
before the side window is fully opened. Be careful not to get any part of
your body or clothing caught in the side window.

154

155

Driving

4-1. Before driving

Driving the vehicle............. 156
Cargo and luggage ........... 166
Vehicle load limits ............. 169
Trailer towing..................... 170
Dinghy towing ................... 171

4-2. Driving procedures

Engine (ignition) switch

(vehicles without
a smart key system)........ 172

Engine (ignition) switch

(vehicles with
a smart key system)........ 175

Continuously variable

transmission.................... 181

Turn signal lever................ 186
Parking brake .................... 187
Brake Hold ........................ 192

4-3. Operating the lights

and wipers

Headlight switch ................ 195
Automatic High Beam ....... 200
Windshield wipers and

washer ............................ 205

Rear window wiper and

washer ............................ 211

4-4. Refueling

Opening the fuel tank

cap .................................. 213

4-5. Using the driving

support systems

Toyota Safety Sense P ..... 217
PCS (Pre-Collision

System)........................... 224

LDA (Lane Departure

Alert with steering
control)............................ 238

Dynamic radar cruise

control with full-speed
range............................... 248

Driving mode select .......... 263
BSM

(Blind Spot Monitor) ........ 265
• BSM function ................ 270
• RCTA function .............. 275

Driving assist systems ...... 280

4-6. Driving tips

Winter driving tips ............. 286

156

Driving the vehicle

P. 172, 1 75

With the brake pedal depressed, shift the shift lever to D. (

Release the parking brake. (

P. 188)

If the parking brake is in automatic mode, the parking brake is released
automatically when shifting the shift lever to any position other than P.
(

P. 187)

Gradually release the brake pedal and gently depress the accelera-
tor pedal to accelerate the vehicle.

With the shift lever in D, depress the brake pedal.
If necessary, set the parking brake.

If the vehicle is to be stopped for an extended period of time, shift the shift
lever to P or N. (

The following procedures should be observed to ensure safe
driving:

Starting the engine

Driving

Stopping

1
2

157

Drivin

With the shift lever in D, depress the brake pedal.
Set the parking brake (

P. 188), and shift the shift lever to P.

(

If parking on a hill, block the wheels as needed.

Vehicles without a smart key system: Turn the engine switch to the
“LOCK” position to stop the engine.
Vehicles with a smart key system: Press the engine switch to stop
the engine.
Lock the door, making sure that you have the key on your person.

With the brake pedal depressed, shift the shift lever to D.
Pull the parking brake switch and parking brake is set manually.
(

P. 188)

Release the brake pedal and gently depress the accelerator pedal
to accelerate the vehicle.
Press the parking brake switch and parking brake is released man-
ually. (

P. 188)

Parking the vehicle

Starting off on a steep uphill

1
2

158

■

When starting off on an uphill
The hill-start assist control will activate. (

P. 281)

■

Driving in the rain

●

Drive carefully when it is raining, because visibility will be reduced, the win-
dows may become fogged-up, and the road will be slippery.

●

Drive carefully when it starts to rain, because the road surface will be espe-
cially slippery.

●

Refrain from high speeds when driving on an expressway in the rain,
because there may be a layer of water between the tires and the road sur-
face, preventing the steering and brakes from operating properly.

■

Engine speed while driving
In the following conditions, the engine speed may become high while driving.
This is due to automatic up-shifting control or down-shifting implementation to
meet driving conditions. It does not indicate sudden acceleration.

●

The vehicle is judged to be driving uphill or downhill

●

When the accelerator pedal is released

●

When the brake pedal is depressed while sport mode is selected

●

When the brake pedal is depressed suddenly and vehicle speed is reduced
sharply

■

Restraining the engine output (Brake Override System)

●

When the accelerator and brake pedals are depressed at the same time, the
engine output may be restrained.

●

A warning message is displayed on the multi-information display while the
system is operating.

■

Restraining sudden start (Drive-Start Control)

●

When the following unusual operation is performed, the engine output may
be restrained.
• When the shift lever is shifted from R to D, D to R, N to R, P to D, or P to

R (D includes M) with the accelerator pedal depressed, a warning mes-
sage appears on the multi-information display.

• When the accelerator pedal is depressed too much while the vehicle is in

reverse.

●

While Drive-Start Control is being activated, your vehicle may have trouble
escaping from the mud or fresh snow. In such case, deactivate TRAC (

P. 281)

to cancel Drive-Start Control so that the vehicle may become able to escape
from the mud or fresh snow.

159

Drivin

■

Breaking in your new Toyota
To extend the life of the vehicle, observing the following precautions is recom-
mended:

●

For the first 186 miles (300 km):
Avoid sudden stops.

●

For the first 621 miles (1000 km):
• Do not drive at extremely high speeds.
• Avoid sudden acceleration.
• Do not drive continuously in low gears.
• Do not drive at a constant speed for extended periods.

■

Operating your vehicle in a foreign country
Comply with the relevant vehicle registration laws and confirm the availability
of the correct fuel. (

P. 464)

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

When starting the vehicle
Always keep your foot on the brake pedal while stopped with the engine
running. This prevents the vehicle from creeping.

160

WARNING

Observe the following precautions.
Failure to do so may result in death or serious injury.

■

When driving the vehicle

●

Do not drive if you are unfamiliar with the location of the brake and accel-
erator pedals to avoid depressing the wrong pedal.
• Accidentally depressing the accelerator pedal instead of the brake

pedal will result in sudden acceleration that may lead to an accident.

• When backing up, you may twist your body around, leading to a diffi-

culty in operating the pedals. Make sure to operate the pedals properly.

• Make sure to keep a correct driving posture even when moving the

vehicle only slightly. This allows you to depress the brake and accelera-
tor pedals properly.

• Depress the brake pedal using your right foot. Depressing the brake

pedal using your left foot may delay response in an emergency, result-
ing in an accident.

●

Do not drive the vehicle over or stop the vehicle near flammable materials.
The exhaust system and exhaust gases can be extremely hot. These hot
parts may cause a fire if there is any flammable material nearby.

●

During normal driving, do not turn off the engine. Turning the engine off
while driving will not cause loss of steering or braking control, but the
power assist to these systems will be lost. This will make it more difficult to
steer and brake, so you should pull over and stop the vehicle as soon as it
is safe to do so.
However, in the event of an emergency, such as if it becomes impossible
to stop the vehicle in the normal way:

P. 409

●

Use engine braking (downshift) to maintain a safe speed when driving
down a steep hill.
Using the brakes continuously may cause the brakes to overheat and lose
effectiveness. (
