Suzuki Grand Vitara JB416 / JB420 / JB419. Service manual - part 151

1D-130 Engine Mechanical: For J20 Engine

Special Tools and Equipment

Recommended Service Material

S6JB0A1428001

NOTE
Required service material is also described in the following.
“Timing Chain Cover Components: For J20 Engine”
“2nd Timing Chain and Chain Tensioner Components: For J20 Engine”
“1st Timing Chain and Chain Tensioner Components: For J20 Engine”
“Camshafts, Tappet and Shim Components: For J20 Engine”
“Valves and Cylinder Head Components: For J20 Engine”
“Pistons, Piston Rings, Connecting Rods and Cylinders Components: For J20 Engine”
“Main Bearings, Crankshaft and Cylinder Block Components: For J20 Engine”



Special Tool

S6JB0A1428002

Material

SUZUKI recommended product or Specification

Note

Water tight sealant

SUZUKI Bond No.1207B

P/No.: 99000–31140

)

SUZUKI Bond No.1207F

P/No.: 99000–31250

)

 / ) / )

09355–35754–600

09367–04002

Hose

3-way joint

)

)

09911–97710

09911–97811

Oil seal guide

Oil seal installer

)

)

09913–75510

09915–64512

Bearing installer

Compression gauge

)

)

09915–64530

09915–67010

Compression gauge hose

Compression gauge
attachment (C)

)

)

09915–67311

09916–14510

Vacuum gauge

Valve lifter

)

)

 / )

Engine Mechanical: For J20 Engine 1D-131

09916–16510

09916–34542

Valve lifter attachment

Reamer handle

)

 / )

)

 / )

09916–37810

09916–38210

Valve guide reamer (6 mm)

Valve guide reamer (11 mm)

)

)

09916–46020

09916–57340

Valve guide remover

Valve guide installer
attachment

)

)

09916–57350

09916–66510

Valve guide installer handle
(6 mm)

Tappet holder

)

 / )

)

 / )

09916–77310

09916–84511

Piston ring compressor (50-
125 mm)

Forceps

)

)

 / )

09917–68221

09917–98221

Camshaft pulley holder

Valve guide stem
attachment

)

 / )

)

09918–08210

09919–28610

Vacuum gauge hose joint

Protector sleeve

)

)

 / )

09924–17810

09926–58010

Flywheel holder (drive plate
stopper)

Bearing remover attachment

)

 / )

)

1D-132 Engine Mechanical: For J20 Engine

09944–36011
Steering wheel remover
)

Engine Mechanical: For F9Q Engine 1D-133

For F9Q Engine

Diagnostic Information and Procedures

Compression Check

S6JB0A1434001

Check compression pressure on all 4 cylinders as
follows:

1) Warm up engine to normal operating temperature.
2) Stop engine after warming up.

NOTE
After warming up engine, place transmission
gear shift lever in “Neutral”, and set parking
brake and block drive wheels.



3) Disconnect negative (–) cable at battery.
4) Disconnect ECM connectors (1) and pre-heating unit

connector (2).

5) Remove all glow plugs referring to “Glow Plug

Removal and Installation: For Diesel Engine Model
in Section 1C”.

6) Connect negative (–) cable at battery.
7) Install special tools into glow plug hole.

Special tool
(A):  09912–56540
(B):  09912–57821
(C):  09918–26510

8) Disengage clutch (1) (to lighten starting load on

engine) for M/T vehicle.

1

2

I5JB0B140001-01

(A)

(C)

(B)

I5JB0B140002-01

I4RH0A140057-01
