Ambient lighting

Fig. 76

Setting the ambient lighting

The ambient lighting illuminates the dashboard and side door trim panels in

colour, and the footwell in white.
The switching on of the lighting takes place automatically after opening the

door, switching off occurs automatically after the locking of the vehicle or 30

seconds after the closing of the door with the ignition switched off.
The ambient lighting can be adjusted in Infotainment in the menu



/  → 

→ Background lighting.
Description of the function surfaces

» Fig. 76

Enable / disable the background lighting
Activating of the brightness setting for all areas at the same time
Activating of the brightness setting for the dashboard area
Activating the brightness controls for the door area
Activating the brightness setting for the footwell area
Choice of colour options / brightness adjustment
Function surfaces for selecting lighting colour / brightness adjustment

To display

B

C

D

 and

E

 tap on the function surface .

Vehicles by selecting the driving mode

For vehicles with driving mode selection

» page 244

 The lighting can be

switched on automatically or instructionly

A



» Fig. 76

. A change in the illumina-

tion colour occurs automatically due to the driving mode change or instructionly

by selecting one of the colour options. In individual mode, the last instructionly se-

lected colour is displayed.

A
B
C
D

E
F

G

Note

The adjustment of the ambient lighting is stored (depending on Infotainment

type) in the active user account personalisation

» page 55

.

Visibility

Introduction

WARNING

No objects should be attached to the sun visors, which could limit the view

or endanger the vehicle occupants during sudden braking or should the ve-

hicle collide.

Windscreen and rear window heater

Fig. 77  Buttons for the front and rear window heater: Climatronic /

instruction air conditioning

Read and observe   on page 77 first.

The heating for quick defrosting and ventilation of the front /and rear window.
The heating only works when the engine is running.
Buttons for the heating (depending on vehicle equipment)

» Fig. 77

Switching the windscreen heater on/off
Switch on/off the rear window heater

When the heating is switched on, a light illuminates inside or below the button.

The heating automatically switches off after ten minutes.

77

Lights and visibility

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If the engine is switched off when the heating is on and turned back on again

within 10 minutes, the heating is continued.

Note

If the on-board voltage decreases, the heating switches off automatically

» page 274

Automatic consumer shutdown - discharge protection of the vehi-

cle battery.

If the lighting inside or below the button flashes, the heater will not work be-

cause of the low charge of the battery.

If the Climatronic recognises that the windshield could fog up, the windshield

heating is automatically switched on. This function can be activated/deactiva-

ted on the Climatronic control panel in the menu



 → 

Front sun visors

Fig. 78  Fold down flap / flip up flap / make-up mirror and parking per-

mit holder

Read and observe   on page 77 first.

Operation and description of the sun visor

» Fig. 78

Swivel the visor towards the windscreen
Swivel cover towards the door
Make-up mirror with cover (the cover can be pushed in the direction of

the arrow)
Light (turns on when the cover of the make-up mirror is pushed to one

side)
Parking ticket holder

1

2

A

B

C

Sunshade

Fig. 79  Sun screen

Read and observe   on page 77 first.

The sun screen is located in a housing on the luggage compartment cover.

To roll down, pull the sunshade by the handle

A

 in direction of arrow

1

 and

suspend in the magnetic holder

B

 in the direction of arrow

2



» Fig. 79

.

To roll up, pull the sunshade by the handle

A

 out of the holder

B

 against

the direction of arrow

2

. Hold the sunshade so that this can slowly roll back

in without damaging.

78

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Sunshade in the rear doors

Fig. 80  Sun blind on the rear door

Read and observe   on page 77 first.

To roll down, pull out the sunshade by the handle

A

 in direction of arrow

1

and suspend in the holder

B

 on top edge of the door in the direction of ar-

row

2



» Fig. 80

.

To roll up, hold the sunshade by the handle

A

 and remove it from the holder

B

 against the direction of arrow

2

. Hold the sunshade so that this can

slowly roll back in without damaging.

Windscreen wipers and washers

Introduction

The windscreen wipers and the wash system operate if the ignition is switched

on and the bonnet and boot are closed.

WARNING

Do not use the windscreen washer system at low temperatures, without

heating the windscreen beforehand. The window washer fluid could other-

wise freeze on the windscreen and restrict the view to the front.

CAUTION

If the windscreen wipers are in rest position, they cannot be folded out from

the windscreen. The wipers must be set to the service position to raise them

off the windscreen

» page 294

.

In cold temperatures and during the winter, check before switching on the

ignition that the wiper blades are not frozen to the windscreen. If the wind-

screen wipers are switched on when the blades are frozen to the windscreen,

this may damage both the blades and windscreen wiper motor.

Carefully release the frozen-on windscreen wiper blades from the wind-

screen and remove snow and ice.

Handle the windscreen wipers with care - there is the risk of damaging the

windscreen with the windscreen wiper arms.

Do not switch on the ignition when the front windscreen wiper arms are fol-

ded down - there is the danger of damaging the bonnet by the windscreen

wiper arms.

If there is an obstacle on the windscreen, the wipers will try to push away the

obstacle five times. Thereafter, the wipers will stop to prevent them becoming

damaged. Turn on the wipers again only after the obstacle has been removed.

Note

Each time the ignition switches off for the third time, the position of the

windscreen wipers changes. This counteracts an early fatigue of the wiper

blades.

The windscreen washer nozzles for the windscreen are heated when the en-

gine is running and the outside temperature is less than +10 °C.

79

Lights and visibility

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Front wipers and washers

Fig. 81

Operating the windscreen wip-

ers and washing system at the

front

Read and observe   and   on page 79 first.

Fast disk wiping

Slow disk wiping

Depending on equipment fitted:

Intermittent wipe of the windscreen

Automatic windscreen wiping in the rain

Wipers and washers off
Single windscreen wipe (sprung position)

 Setting of windscreen wiper interval for the position  - by setting the

switch in the direction of the arrow, the windscreen wipers will wipe more

often
Spraying and wiping the windscreen (sprung position)

 Spraying and wiping the windscreen

After releasing the operating lever, the wipers will make from 2 to 3 wiper

strokes.
At a speed of more than 2 km/h, the wiper wipes once again 5 seconds after

the last wiper stroke in order to wipe the last drops from the windscreen. This

function can be activated/deactivated by a specialist garage.

Automatic windscreen wiping in the rain can be used in Infotainment in the

menu



/  →  → Mirrors and wipers (activated/deactivated).

WARNING

Automatic wiping during rain is only a support. The driver is not released

from the responsibility to set the function of the windscreen wipers man-

ually depending on the visibility conditions.











A

Note

If the wiping is carried out without interruption, the wiping speed varies de-

pending on the vehicle speed.

The setting (activation/deactivation) of the automatic windscreen wiping in

the rain is stored (depending on the Infotainment type) in the active user ac-

count personalisation

» page 55

.

Rear window wipers and washers

Fig. 82

Operating the windscreen wip-

ers and washing system

Read and observe   and   on page 79 first.

Spraying and wiping the windscreen (sprung position) - after releasing the

control stalk, the wipers perform another 2 to 3 wiper strokes
Windscreen wiping
Wipers and washers off

Automatic rear wiper

If the windscreen wiping is performed without interruption, then the automat-

ic regular intermittent wiping of the rear window takes place.
This function can be activated/deactivated in Infotainment in the menu



/ 

→  → Mirrors and wipers (activated/deactivated).

Note

The rear window is wiped automatically if the windscreen wipers are on

when reverse gear is selected.

The setting (activation/deactivation) of the automatic rear window wiping in

the rain is stored (depending on the Infotainment type) in the active user ac-

count personalisation

» page 55

.



80

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Headlight cleaning system

Read and observe   and   on page 79 first.

Headlights are cleaned under the following conditions.

The low beam is switched on.
The outside temperature is about -12° C to +39° C.

To clean the headlights, the headlamp is also sprayed after spraying the wind-

screen every first and tenth time. Setting the spray interval can be carried out

by a specialist garage.
To ensure the correct functioning of the system, even in winter, this needs to

be regularly cleared of snow and ice (e.g. using the de-icing spray).

Rear view mirror

Introduction

WARNING

Exterior mirrors increase the field of view, however, make objects appear

smaller and further away. Therefore, use the rear-view mirror to determine

the distances to the following vehicles.

WARNING

The mirrors with automatic dimming contain electrolyte fluid which may

leak if the mirror glass is broken - this can irritate skin, eyes and the respira-

tory system.

If your eyes or skin come into contact with the electrolyte fluid, immedi-

ately wash the affected area for a few minutes with plenty of water. Seek

medical assistance if required.

Interior mirror dimming

Fig. 83

Rear-view mirrors with instruction

dimming

Fig. 84  Rear-view mirrors with automatic dimming: Version 1/version 2

Read and observe   on page 81 first.

Mirrors with instruction dimming

» Fig. 83

Basic position of the mirror (not dimmed)
Mirror blackout

Mirror with automatic dimming

The mirror dimming

» Fig. 84

 is automatically controlled after the engine start.

When the interior lights are switched on or the reverse gear is engaged, the

mirror moves back into the basic position (not dimmed).

1

2

81

Lights and visibility

-------------------------------------------------------------------------------------------------------------------------------------------------------------

WARNING

Attach external devices (e.g. navigation system) not in the vicinity of the

mirror with automatic dimming. The illuminated display of an external de-

vice can affect the function of the rear-view mirror - it could cause an acci-

dent.

The automatic dimming mirror only functions smoothly if the light falling

on the sensors is not compromised (e.g. by the sunshade at the back). The

sensors are located on the front and back of the mirror.

Exterior mirrors

Fig. 85

Exterior mirror operation

Read and observe   on page 81 first.

The exterior mirrors can (depending on vehicle equipment) have a instruction or

electric fold-in function, automatic dimming and memory function.
The rotary knob can be moved into the following positions (depending on

vehicle equipment)

Adjusting the left-hand mirror area
Switch off mirror control
Adjusting the right-hand mirror area
Mirror heating (only works when the engine is running)
Folding in the mirrors electrically (to fold back, move the rotary knob to

another position)

»

Setting the mirror area

Move the rotary knob in the direction of arrows

» Fig. 85

.

If the mirror setting fails at any time, the mirrors can be adjusted instructionly by

pressing on the edge of the mirror area.

Setting the mirror surfaces synchronously

This function allows the simultaneous adjustment of the two mirror areas. The

function can be activated/deactivated in Infotainment in the menu



/  → 

→ Mirrors and wipers (activated/deactivated).

Turn the knob for the mirror control to the position for the driver mirror ad-

justment.

Adjust the mirror areas to the desired position.

Instruction folding mirrors

The mirror can be instructionly folded towards the side windows. To put it back to

its original position, it should be folded back from the side window until it audi-

bly clicks into place.

Automatic folding in/back of both mirrors

The exterior mirrors are automatically collapsed after locking the vehicle in the

park position. After unlocking the vehicle, the mirrors are folded back to the

driving position

»

.

This function can be activated/deactivated in Infotainment in the menu



/ 

→  → Mirrors and wipers (activated/deactivated).

Mirror with automatic dimming

The exterior mirror dimming is controlled together with the automatic rear-

view mirror dimming

» page 81

.

Memory function for mirror (vehicles with electrically adjustable driver's

seat)

It is possible to save the current setting of the exterior mirror when saving the

driver's seat position with

» page 85

Memory Function of the electrically ad-

justable seat or

» page 85

Memory function of the remote control key.

Tilting the mirror area of the front passenger mirror (vehicles with

electrically adjustable driver's seat)

The front passenger mirror area can be tilted to the stored position to improve

the view to the curb when reversing.
Operating conditions

The function can be activated in Infotainment in the menu



/  →  →

Mirrors and wipers.
The setting of the mirror area has been previously stored

» page 85

,

Memory Function of the electrically adjustable seat or.

» page 85

Memo-

ry function of the remote control key.

82

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The reverse gear is engaged.
The knob for the mirror control is in the position for the passenger mirror

adjustment.

The mirror area returns to its initial position after the rotary knob is set to an-

other position or if the speed is greater than 15 km/h.

WARNING

Do not touch the exterior mirror surfaces, if the exterior mirror heating is

switched on - hazard of burning.

CAUTION

Never instructionly fold in/out the electrically folding exterior mirrors - there is a

risk of damage to the mirror!

When the mirror is swung by external influences (due to impact during ma-

noeuvring, for example), then first fold-in the mirror by turning the knob and

wait for a loud clapping noise.

Note

The setting of the mirror functions is stored in Infotainment (depending on the

Infotainment type) in the active user account personalisation

» page 55

.

Seats and head restraints

Front seats

Introduction

WARNING

Only adjust the driver's seat when the vehicle is stationary – risk of acci-

dent!

Caution when adjusting the seat! You may suffer injuries or bruises as a

result of adjusting the seat without paying proper attention.

Instruction adjustment

Fig. 86

Control elements on the seat

Read and observe   on page 83 first.

Adjusting the seat in the longitudinal direction (after releasing the control

lever must lock audibly)
Adjusting height of seat
Adjust the tilt of the backrest (do not lean on the backrest when adjusting)
Setting the extent of the curvature of the lumbar support

Note

After a certain time, play can develop within the adjustment mechanism of the

backrest angle.

A

B
C
D

83

Seats and head restraints

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Electrical adjustment

Fig. 87  Control elements on the seat

Read and observe   on page 83 first.

seat adjustment

1 - Move in the longitudinal direction

2 - Change in inclination

3 - Change in height

Adjusting the seat backrest

4 - Change in inclination

Adjusting lumbar support

5 - Change curvature

6 - The degree of curvature change

WARNING

The electric front seat adjustment is functional even with the ignition off.

Therefore, when leaving the vehicle, never leave people who are not com-

pletely independent, such as children, unattended in the vehicle - there is a

danger of injury!

Note

If the inclination angle of the seat backrest relative to the seat surface is

greater than approx. 110°, then it is not possible for safety reasons to save this

setting in the memory of the electrically adjustable seats or the remote control

key.

On vehicles with personalisation, the driver's seat setting is stored in the ac-

tive user account personalisation

» page 55

.

A

B

C

Driver's seat with massage function

Fig. 88

Button for the massage function

Read and observe   on page 83 first.

The massage function is used to massage the lumbar area of the back.

To switch on/off, press the  button

» Fig. 88

.

WARNING

Only switch the massage function on and off when the vehicle is stationary

- otherwise there is risk of an accident.

Note

The massage function switches off automatically after approximately 10 mi-

nutes.

84

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Convenience operation of the front passenger seat

Fig. 89

Operating elements on the front

passenger's seat

Read and observe   on page 83 first.

The front passenger seat can also be operated from the rear seats, by pressing

the respective operating element in the direction of the arrows

» Fig. 89

.

Adjusting the angle of the seat backrest
Adjusting a seat in a forward/back direction

Memory Function of the electrically adjustable seat

Fig. 90

SET button and memory but-

tons

Read and observe   on page 83 first.

Among the memory buttons

B

 on the driver's seat, a setting for the driver´s

seat and exterior mirror position can be saved

» Fig. 90

.

Storing seat and exterior mirror settings for driving forward

Switch on the ignition, adjust the seat and the exterior mirrors, as required.

Press the 

A



» Fig. 90

 button and then, within 10 seconds, press the de-

sired memory button

B

. Storing is confirmed by an acoustic signal.

A
B

Storing front passenger´s exterior mirror settings for reversing

The function for lowering the front passenger's mirror area during reversing

can be activated in Infotainment in the menu



/  →  → Mirrors and wipers.

Turn on the ignition and press the desired memory button

B



» Fig. 90

.

Turn the rotary knob for the exterior mirror control to the position for the

front passenger mirror area

» page 82

.

Engage reverse gear.

Adjust the front passenger's mirror to the desired position.

Disengage reverse gear. The set position of the exterior mirror is stored.

Retrieving the saved setting

With the ignition off and the driver’s door open-press- the desired memory

button B.

In other cases (e.g. if the ignition is switched on or the driver's door closed),

hold the button.

Stopping the ongoing adjustment

Press any button on the seat that is to be set. The driver's seat can also be

stopped by pressing the  button on the radio-operated key.

Note

Every time you save new seat and exterior mirror settings for driving forwards,

you must also save the front passenger mirror setting for reversing again.

Memory function of the remote control key

Applies to vehicles that do not have the personalisation function.

Read and observe   on page 83 first.

Every time the vehicle is locked, the driver´s seat and exterior mirror settings

are saved and assigned to the key with which the vehicle was locked.
After the following unlocking of the vehicle with the same key and opening the

driver’s door, the driver´s seat and exterior mirrors that are saved to this key

will be adopted.
This function can be used in Infotainment in the menu



/  →  → Seats acti-

vated/deactivated.

Storing front passenger´s exterior mirror settings for reversing

The function for lowering the front passenger's mirror area during reversing

can be activated in Infotainment in the menu



/  →  → Mirrors and wipers.

85

Seats and head restraints

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Unlock the vehicle with the remote control key and switch on the ignition.

Turn the rotary knob for the exterior mirror control to the position for the

front passenger mirror area

» page 82

.

Engage reverse gear.

Adjust the front passenger's mirror to the desired position.

Disengage reverse gear. The adjusted position of the exterior mirror is stored

in the remote control key memory.

Stopping the ongoing adjustment

Press any button on the driver's seat or the  button on the remote control

key.

Folding front passenger seat

Fig. 91

Folding the front passenger seat

forward

Read and observe   on page 83 first.

The front passenger seat can, (depending on equipment fitted), be folded for-

ward into a horizontal position.

To fold down, pull the lever in direction of arrow

1

, fold the seat backrest in

the direction of arrow

2



» Fig. 91

. The locking mechanism must audibly snap

into place.

To fold up, pull the lever in direction of arrow

1

, fold back the seat backrest

against the direction of arrow

2

. The locking mechanism must audibly snap

into place.

Check this by pulling on the seat and on the backrest.

WARNING

If the seat backrest is folded down, only the seat behind the driver´s seat

can be used to transport passengers.

When transporting objects on the folded seat backrest, the front passen-

ger airbag should be deactivated

» page 28

.

WARNING (Continued)

Do not adjust the seat backrest while driving - it can cause injury and ac-

cidents!

When moving the seat backrest, keep limbs out of the area between the

seat and seat backrest – risk of injury!

Never transport the following items on the seat backrest when folded

forwards.

Objects that could restrict the driver's view.

Objects which make it impossible for the driver to control the vehicle,

e.g. if they roll under the pedals, or could protrude into the driver's zone.

Objects which could lead to injury to passengers due to a change of di-

rection or braking manoeuvre when accelerating sharply.

Armrest setting

Fig. 92

Adjust armrest

Read and observe   on page 83 first.

To adjust the height, lift the armrest in the direction of the arrow

A

 into one

of the locking positions

» Fig. 92

.

To close, lift the armrest in the direction of arrow

A

past the stop and then

fold down again.

86

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Rear seats

Seat backrests

Fig. 93  Folding down the seat backrests from the forward from the

passenger compartment

Fig. 94

Fold the backrest forward from

the luggage compartment

Before folding the seat backrests forwards, adjust the position of the front

seats in such a way that they are not damaged by the seat backrests. Remove

the rear headrests if required

» page 89

.

Folding forwards from the passenger compartment

Place the outer seat belt behind the raised edge

A

» Fig. 93

.

Push the release lever

B

 in the direction of arrow

1

 and fold down the seat

backrest in the direction of arrow

2

.

Fold forward from the luggage compartment

On vehicles with a net partition, the left and then the right and middle rear seat

backrest must first be unlocked. The net partition must be rolled up in the

housing.

Pull the corresponding lever in the direction of the arrow

» Fig. 94

. The re-

spective seat backrest is unlocked or folded forward.

Folding backwards

Place the outer seat belt behind the raised edge

A

» Fig. 93

.

Lift the seat backrest against the direction of arrow

2

 until the release lever

B

 audibly locks. Check this by pulling on the seat backrest.

Make sure that the red pin

C

 is hidden.

WARNING

The seat backrests in the occupied rear seats must be properly engaged.

When transporting objects in the luggage compartment that has been en-

larged by folding the backrest forward, ensure the safety of the passengers

transported on the other rear seats.

The seat backrests must be securely latched in position so that no objects

from the luggage compartment can slip into the passenger compartment

under sudden braking – risk of injury.

CAUTION

When operating the seat backrests, the seat belts must not be pinched - there

is a risk of damage to the seat belts.

Fold down armrest

Fig. 95

Fold down armrest

The armrest can be folded down in the direction of the arrow

» Fig. 95

.

The folded-down armrest can be used as a side table.

87

Seats and head restraints

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Headrests

Introduction

Note

In sports seats, the headrests are integrated into the seat backrests and can-

not be adjusted in height.

Adjust height of front head restraint

Fig. 96

Setting the height of the front

headrest

To adjust the height, hold the locking button

A

 and move the rest in the de-

sired direction

» Fig. 96

.

CAUTION

If the tablet holder adapter is secured to the guide rods of the headrests

» page 103

, do not push the headrests down to the stop – risk of damaging the

headrests.

Adjusting the rear headrests

Fig. 97  Setting the height of the rear headrest

Fig. 98

Fold down side bolsters of the

comfortable headrests

Setting the height

Grasp the headrest and move upwards in the direction of

1



» Fig. 97

.

To move the restraint down, hold the locking button

A

 in the direction of

arrow

2

 and push the rest in the direction of arrow

3

.

Comfortable headrests

The rear headrests can be equipped with side bolsters. These reduce uncon-

trolled movement of the head sideways (e.g. when sleeping).

Adjust the headrest to the initial pulled out position

» page 88

Adjusting the

rear headrests.

Fold down the sides of the head restraint in the direction of arrow

» Fig. 98

.

88

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Removing/inserting the rear headrests

Fig. 99  Removing/inserting the rear headrest

To remove, pull the rest out of the seat backrest up to the stop.

Hold the locking button

A

 in the direction of arrow

1

, at the same time us-

ing a flat screwdriver with a max. width of 5 mm to press the locking button

in the opening

B

 in the direction of arrow

2

 and pull out the rest in the di-

rection of arrow

3

» Fig. 99

.

To insert, push the rest into the seat backrest in the direction of arrow

4

until the locking button clicks into place.

Seat heating and ventilation

Introduction

Fig. 100  Button arrangement: Heated front seats (and ventilation) /

heated rear seats

Depending on the equipment, the front seats can be heated or heated and

ventilated. The outer rear seats can only be heated.

Buttons for the seat heating and ventilation

» Fig. 100

Left seat heating
Right seat heating
Seat heating and ventilation left
Seat heating and ventilation right

The seat heating / ventilation only works when the engine is running.
When the ignition is switched off, the seat heating / ventilation is also switch-

ed off. if the engine is started again within 10 minutes, then the driver's seat

heating / ventilation is switched on again automatically according to the set-

ting before switching off the ignition.

WARNING

If you have a limited pain and / or temperature sensitivity, e.g. due to medi-

cation, paralysis or because of chronic illness (e.g. diabetes), we recom-

mend that you do not use the seat heating. If the seat heating is used, we

recommend to make regular breaks in your journey when driving long dis-

tances, so that the body can recuperate from the stress of the journey.

Please consult your doctor, who can evaluate your specific condition.

CAUTION

The following instructions must be observed to avoid damage to the seats.

Do not kneel on the seats or otherwise apply concentrated pressure to them.

Do not heat seats that do not contain occupants.

Do not heat seats in which objects are secured or resting (e.g. children´s

seat, a bag etc.).

Do not heat seats on which additional slipcovers or protective covers are fit-

ted.

89

Seats and head restraints

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Front and rear seats with seat heating

Fig. 101  The seat heating is switched on at maximum heat: Front

seats/rear seats

Read and observe   and   on page 89 first.

To turn on the heating with maximum heat

» Fig. 101

, press button  or  .

With repeated pressing of the button, the level is down-regulated until it

switches off . The level of the seat heating is indicated by the number of illu-

minated warning lights underneath / in the button.
Increase in heating power of the rear seat heating can be locked/unlocked.

To do this, press button  on the Climatronic → Tap the function surfaces

/ on the Infotainment screen (applies to vehicles with Climatronic controls

in the rear). In the locked heating power increase, the heating power can only

be adjusted down to turn off.

Front seats with heating and ventilation

Fig. 102  Heating switched on / ventilation switched on / heating and

ventilation are switched on simultaneously

Fig. 103  Infotainment screen: Front seat heating and ventilation with

maximum heating / ventilation level switched on

Read and observe   and   on page 89 first.

Press the button  or  on the control panel of the air conditioner, a menu

for operating the front seat heating and ventilation is displayed on the Info-

tainment screen

» Fig. 103

.

Function surfaces for setting the ventilation level
Function surfaces for setting the heating power
Functional surfaces for switching off the ventilation (in addition to the

function surfaces

A

) or for switching off the heating (in addition to the

function surfaces

B

)

A
B



90

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If the seat heating was switched on before the ignition was switched off, then

pressing the buttons  and  will switch the seat heating

» Fig. 102

 on with

maximum output .
If the seat ventilation was switched on before the ignition was switched off,

then pressing the buttons  and , will switch the seat ventilation

» Fig. 102

 on

with maximum ventilation output .
By repeatedly pressing the button  or. , the heating or ventilation output is

controlled down to off. The power of the seat heating is indicated by the num-

ber of illuminated warning lights underneath the switch.
Only the heating or ventilation can be operated using the buttons  or. .
If ventilation and heating are switched on simultaneously on the Infotainment

screen, under each button  or.  the blue and red warning light illuminates

» Fig. 102

 - , the button or.  is not functioning (as long as the ventilation

and the heating are switched on simultaneously).

Heated steering wheel

Fig. 104  Steering wheel heating: Manual air conditioning/Climatronic

Switching heating on/off (applies to the manual air conditioning)

In the Infotainment system, in menu



/  tap the function surface

A

» Fig. 104

.

Switching heating on/off (applies to Climatronic)

Press the button  on the Climatronic, then tap the function surface

B

1)

on the Infotainment screen

» Fig. 104

.

When the heating is switched on, the symbol in the function surface

B

 is or-

ange.
The heated steering wheel only works when the engine is running.

Setting the heating power (applies to the Climatronic)

Press the button  on the Climatronic, then tap the function surface  →

Steering wheel heating on the Infotainment screen.

Setting the heating power.

The heating power is displayed by the number of segments in the indicator

light

C



» Fig. 104

.

Steering wheel heating together with the driver's seat heating (applies to

the Climatronic)

To activate / deactivate the heated steering wheel with the driver's seat

heating, press the button  on the Climatronic, then tap the function sur-

face  → Link seat/steering wheel heating in the Infotainment screen.

To switch on / off the heated steering wheel, press the button for the driver

seat heating.

If the heated steering wheel is turned on together with the driver's seat heat-

ing, then the function surface  is displayed on the Infotainment screen. This

can be used to switch the heated steering wheel off/on.

1)

Depending on the equipment, one of the function surface versions is displayed.

91

Seats and head restraints

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Practical features

Passenger compartment features

Introduction

WARNING

Do not place anything on the dashboard. These objects might slide or fall

down when driving and may distract you from concentrating on the traffic

– risk of accident!

Make sure that while driving no objects can enter the driver's footwell -

cause an accident!

Do not carry any objects on the front passenger seat except objects de-

signed for this purpose (e.g. child seats) – risk of accident!

No objects should be placed in the storage compartments nor in the

drinks holders; the vehicle occupants could be endangered if there is sud-

den braking or the vehicle collides with something.

For safety reasons, lockable storage compartments must be closed while

driving - there is a risk of injury from the opened cover or from the items in

the compartment.

Make sure that no objects protrude from the compartments - there is

danger of injury!

Do not exceed the permissible load for the storage compartments and

pockets - it may cause injury or there is the risk of damaging the compart-

ments and pockets!

Ash, cigarettes, cigars and the like may only be placed in the ashtray - risk

of fire!

The storage compartments and the waste containers are not a substitute

for the ashtray and must also not be used for such purposes – risk of fire!

CAUTION

No not place large or sharp objects in the storage compartments and pockets

- there is a risk of damage to the compartments and pockets.

Parking ticket holder

Fig. 105

Parking ticket holder

Read and observe   and   on page 92 first.

The ticket holder is provided for the attachment of e.g. parking tickets.

Storage compartment on the driver's side

Fig. 106  Opening the storage compartment / card holder

Read and observe   and   on page 92 first.

To open, lift the handle and fold out the compartment

» Fig. 106

 .

To close, swing the lid against the direction of the arrow until it audibly clicks

into place.

A card holder is located in the storage compartment

» Fig. 106

 .

The maximum permissible load of the storage compartment is 0.5 kg.

92

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     3      4      5      6     ..
