Skoda Superb (2019 year). Instruction - part 3







 illuminates

Message:

Gearbox in emergency mode. No reverse gear.

Error: gearbox. Speed is limited.

You can drive on, exercising appropriate caution. Seek assistance from a spe-

cialist garage immediately.

 Rear seat belt warning light

Read and observe   on page 40 first.

 illuminates – a rear seat belt is not fastened.

 illuminates - a rear seat belt is fastened.

When the seat belt is fastened/unfastened, the particular light lights up briefly

and indicates the current belt status!

 Generator

Read and observe   on page 40 first.

 illuminates - the battery is not being charged while the engine is running.

CAUTION

If in addition to the light  the light  lights up while driving,

 stop driving -

There is a risk of engine damage! Switch off the engine and seek assistance

from a specialist garage.

 Coolant

Read and observe   on page 40 first.

Coolant level too low



 illuminates

Message: Please check the coolant level. Log book!

Stop the vehicle, switch off the engine and let it cool.

Check the coolant level

» page 272

.

If the coolant level is within the specified range and the warning light  lights

up again, then there may be a malfunction of the cooling fan.

Switch off the ignition.

Check the fuse for the radiator fan, replace if necessary.

If the coolant level and fan fuse are both OK but the warning lightlights up

again,

 stop driving!

Seek help from a specialist garage.

Coolant temperature too high



 illuminates

Message: Engine overheat. Stop! Observe log book.

Stop the vehicle, switch off the engine and let it cool.

Continue your journey only after the warning light  has disappeared.

 Engine oil pressure

Read and observe   on page 40 first.



 flashes - the engine oil pressure is too low.

Stop the vehicle, switch off the engine, and check the engine oil level.

Even if the oil level is correct,

 do not drive any further if the warning light

is flashing! Also do not leave the engine running at an idling speed.

Seek help from a specialist garage.

CAUTION

If it is not possible to top up with engine oil,

 stop driving - there is a risk of

engine damage! Switch off the engine and seek assistance from a specialist

garage.

 Engine oil level

Read and observe   on page 40 first.

Engine oil level too low



 illuminates

Message: Please add engine oil.

Stop the vehicle, switch off the engine, and check the engine oil level, top up

if necessary.

45

Instruments and warning lights

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The warning light will go out if the bonnet is left open for more than 30 sec-

onds. If the engine oil is not replenished, the warning light will come on again

after driving about 100 km.

Engine oil level too high



 illuminates

Message: Please reduce oil level.

Stop the vehicle, switch off the engine, and check the engine oil level.

In the event of an oil level which is too high, you can drive on, exercising ap-

propriate caution. Seek assistance from a specialist garage immediately.

Fault on the engine oil level sensor



 illuminates

Message: Oil sensor: please visit workshop.

Immediately drive to the nearest specialist garage with appropriate caution.

CAUTION

If it is not possible to top up with engine oil,

 stop driving - there is a risk of

engine damage! Switch off the engine and seek assistance from a specialist

garage.

 AdBlue

®

level II low (diesel engine)

Read and observe   on page 40 first.

 Illuminates - AdBlue

®

level too low.

Replenish Add AdBlue

®



» page 267

.

 AdBlue

®

 error (diesel engine)

Read and observe   on page 40 first.

 illuminates – there is a fault in the AdBlue

®

 system.

Seek help from a specialist garage.

 Lamp failure

Read and observe   on page 40 first.



 illuminates - one of the lamps is faulty.

A message will appear in the display about the affected lamp.

 Display when the light is switched off

Read and observe   on page 40 first.

Applies to vehicles with the digital instrument cluster.

 lit - no light is on.

Message: Please turn on the light.

 Particulate filter

Read and observe   on page 40 first.

The particulate filter separates and burns the soot particles from the exhaust.



 illuminates - the filter is clogged with soot.

To clean the filter, if allowed by the traffic conditions

»

, you should drive at a

speed between 50-120 km/h in the recommended gear.
If the filter is properly cleaned, the warning light  extinguishes.
If the indicator light  does not go out within 30 minutes, the filter was not

cleaned.

Immediately drive to the nearest specialist garage with appropriate caution.

WARNING

Always adjust the speed and driving style to the actual weather, road, ter-

rain and traffic conditions.

The particulate filter reaches very high temperatures - there is a fire haz-

ard and serious injury could be caused. Therefore, never stop the vehicle at

places where the underside of your vehicle can come into contact with

flammable materials, such as dry grass, undergrowth, leaves, spilled fuel or

the like.

CAUTION

As long as the warning light  illuminates, one must take into account an

increased fuel consumption and a power reduction of the engine.

As long as the indicator light  is lit, the START-STOPfunction is not availa-

ble.

46

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Note

We encourage you to avoid constant short journeys. This supports the correct

function of the particulate filter.

 Windscreen washer fluid level

Read and observe   on page 40 first.



 illuminates - the windscreen washer fluid level is too low.

Top up the windscreen washer fluid

» page 271

.

 Headlight assistant

Read and observe   on page 40 first.

 Illuminates – the headlight assistant is activated

» page 74

Headlight As-

sist (Light Assist / Dynamic Light Assist).

  START-STOPsystem

Read and observe   on page 40 first.

The warning lights   indicates the state of the START STOP system

» page 206

.

Display of a low temperature

Read and observe   on page 40 first.

 illuminates - the outside temperature is below +4 °C.

WARNING

Even at temperatures around +4 °C, black ice may still be on the road sur-

face! Do not only rely upon the information given on the outside tempera-

ture display that there is no ice on the road.

 Water in the fuel filter (diesel engine)

Read and observe   on page 40 first.

The fuel filter with water separator, filters out dirt and water from the fuel.

If too much water is present in the separator, the following information ap-

pears on the instrument cluster display.



 illuminates

Message: Water in fuel filter. Log book!

You can drive on, exercising appropriate caution. Seek assistance from a spe-

cialist garage immediately.

   Adaptive Cruise Control (ACC)

Read and observe   on page 40 first.

The warning lights    indicate the condition of the ACC system

» page 236

.

Front Assist

Read and observe   on page 40 first.

 illuminates – the safe distance to the vehicle in front is below the mini-

mum.
Information on the Front Assist system

» page 242

.

 front Assist

Read and observe   on page 40 first.



 illuminates

Front Assist has recognised the risk of a collision or automatically triggered

an emergency braking manoeuvre

» page 242

.

An automatic deactivation of Front Assist took place when activating ESC

Sport

» page 217

 and when deactivating the ASR

» page 218

.

Front Assist is not available

» page 244

.

 Illuminates with the lettering 

 - Front Assist is deactivated

» page 243

.

 emergency call

Read and observe   on page 40 first.



 lights up – there is a fault in the emergency call system.

Seek help from a specialist garage.

47

Instruments and warning lights

-------------------------------------------------------------------------------------------------------------------------------------------------------------

 Economy mode

Read and observe   on page 40 first.

 illuminates - the vehicle is in economy mode due to the intervention of the

active cylinder management or due to the neutral position of the automatic

gearbox.

 Adaptive chassis (DCC)

Read and observe   on page 40 first.



 illuminates – there is a DCC fault.

It is possible to continue driving with due caution. Seek assistance from a

specialist garage immediately.

 Service

Read and observe   on page 40 first.

 illuminates – note regarding a due service appointment

» page 55

Display-

ing the distance and days until the next service interval.

Information system

Driver information system

Display in the instrument cluster

Fig. 38

Display overview

Depending on the vehicle's equipment, the information system uses the dis-

play in the instrument cluster to provide the following information

» Fig. 38

.

Time / symbols of the Infotainment voice control
Engaged gear / gear recommendation

Selector lever positions for the automatic gearbox

Warning lights of the START-STOP system

Compass display

Detected traffic signs
Driving data (multifunction display)

Warning lights

Information messages

Door alarm

Eco tips

Service interval display
Outside temperature
Cruise control / speed limiter

Total distance travelled
Distance travelled by resetting the memory (trip)

Door, luggage compartment and bonnet alarm

When the door or luggage compartment / bonnet is open, a graphic warning

appears in the display.

1

2

3

4
5

6

48

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

An acoustic signal will also sound if you drive the vehicle above 6 km/h when a

door is open.

Reset counter for distance travelled (trip)

Press button

A



» Fig. 39

 on page 49.

Setting the time

Fig. 39

Button in the instrument cluster

Set the time using the button in the instrument cluster

Switch on the ignition.

Press and hold the button

A



» Fig. 39

until thetime is shown in the display.

Release the button

A

 and the system switches to the hour setting function.

Press the button

A

 again and set the hours.

Wait 4 seconds, the system switches to the minutes setting.

Press the button

A

 again and set the minutes.

Wait 4 seconds, the system switches to the initial setting.

Gear recommendation

Fig. 40

Information on the selected

gear / Gear recommendation

A suitable engaged gear or, where appropriate, a recommended gear is dis-

played, with the aim of conserving the life of the engine and increasing driving

efficiency.

Display

» Fig. 40

Optimal gear engaged
Gear recommendation (e.g.    means that it is advantageous to switch

from 3rd to 4th gear)

For vehicles with automatic transmission the recommended gear will be

shown provided the mode for instruction switching (Tiptronic) is selected.

WARNING

The driver is always responsible for selecting the correct gear in different

driving situations, such as overtaking.

Vehicle condition

Fig. 41

Vehicle condition

Certain functions and conditions of individual vehicle systems are checked

continuously when the ignition is switched on. If there is a fault in the system,

the following message will appear in the display of the instrument cluster.
While the operational faults remain unrectified, the messages are always indi-

cated again. After the message is displayed for the first time, the warning

lights

 (danger) or

 (warning) continue to be displayed.

The vehicle condition can be displayed in Infotainment in the menu



/  →

 → Vehicle status.

In the screen, information regarding vehicle condition or function of the tyre

pressure monitor is displayed.

Using the function surfaces  select the menu item Vehicle status.

49

Information system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Function surfaces and screen display

» Fig. 41

A

Vehicle representation (the zones of the vehicle are shown in different

colours, corresponding to any warning messages that occur. The warn-

ing messages are displayed once you touch the “vehicle”)



No message/warning messages relating to vehicle status and the num-

ber (if there is only one message, one warning message text is dis-

played)

Display information about the status of the START-STOP system





Activation / deactivation of notes relating to START-STOP-Sys-

tem messages in another screen display

Display information on sporty driving in Infotainment

Fig. 42

Infotainment display

The display of data on sporty driving is used to evaluate current motor values.

To display in the Infotainment menu



/  tap on function surface  →

Sports.

Using the functional surfaces   the Information sports the menu item is

chosen.

A swipe of the finger vertically across the screen allows three of the following

displays

A

 to be shown

» Fig. 42

.

Boost pressure display

Acceleration display

Power display

Coolant temperature display

Oil temperature display

laptimer Show (stopwatch) in the infotainment

Fig. 43

Infotainment display

To display tap in the Infotainment menu



/  tap on function surface 

→ Sports.

Using the functional surfaces choose   the laptimer menu item.

Function surfaces and screen display

» Fig. 43

Total time, display of intermediate time for 5 s
Start/stop the time measurement
Current lap time
Statistics - Evaluation / Reset of measured times
New lap - start measuring the next lap time
interim

Stop timing

After the termination of the time measurement, the following functional areas

for the completion of the measurement are displayed on the screen.

The current lap time is saved
The current lap time is not saved

WARNING

Concentrate fully at all times on your driving! As the driver you are fully

responsible for the operation of your vehicle.

Only use the Lap timer when you are in any traffic situation where you have

full control of the vehicle.

Note

If the measured times are not reset, then these are stored even after turning

off the ignition.

A
B
C
D

E
F

50

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Operation of the information system

Operation using the control lever

Fig. 44

Buttons on the operating lever

Operating the multifunction display

Press (up or down) - select data / set values
Press - display / confirm indication

Operation of the display menus

Press (up or down) - move to the selected menu

Hold (up or down) - display main menu
Press - confirm selected menu item

Operation using the multifunctional steering wheel

Fig. 45  Buttons/dials: on the multifunction steering wheel

Buttons/dials on the multifunction steering wheel

Switch on/off voice control
Turn - sets the volume

Press - sound on / off

A
B

A

B

A

Skip to next track/station
Switch to previous track/station
Display the assistance systems menu

Depending on equipment:

Operating a digital instrument cluster

» page 38

Show previous menu (if one has been selected) / display Telephone

menu

Operating the multifunction display

Turn - select data / set values

Press - display / confirm indication

Operation of the display menus

Hold - display main menu

Press - return to a previous level in the menu
Turn - move in the selected menu

Press - confirm selected menu item

Driving data (Multifunction display)

Introduction

The driving data display is only possible with the ignition switched on.
The units can be adjusted in Infotainment in the menu



/  →  → Units.

The journey data can be set/reset in Infotainment in the menu



/  →  →

Instrument cluster.

Note

The setting of the information display is stored in the active user account per-

sonalisation

» page 55

.

Information Overview

Overview of driving data (depending on the vehicle equipment).
Range - drive distance in km which can be covered with the existing tank ca-

pacity and with the same driving style. If you drive more efficiently this value

can increase.



B

B

51

Information system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

AdBlue

®

 range - drive distance in km which can be covered with the existing

AdBlue

®

tank capacity and with the same driving style. If you drive more effi-

ciently this value can increase. When the system detects that AdBlue

®

 can be

refilled, an indication of the minimum and maximum AdBlue

®

 refilling quantity

appears.
Average fuel consumption - is calculated continuously since the last time the

memory was deleted. After erasing the memory, no data will appear for the

first 100 m driven.
Current fuel consumption - when the vehicle is stationary or slowly moving,

the fuel consumption is displayed in l/h (--,- km/l appears on models for some

countries).
Oil temperature - if the temperature is lower than 50 °C or if there is a fault in

the system for checking the oil temperature, the  symbols are displayed.
Warning when the preset speed is exceeded - allows the setting of a speed

limit where, if exceeded, an acoustic warning signal and a warning message ap-

pears on the display of the instrument cluster.
Dynamic Road Sign Display - traffic signs display

» page 250

Traffic sign rec-

ognition.
Current speed - digital speedometer.
Average speed - is calculated continuously since the last time the memory

was deleted. After erasing the memory, no data will appear for the first 300 m

driven.
Driving route - distance driven since the last time the memory was deleted.
Driving time - driving time since the last time the memory was deleted.
Conv. consumers - information about the total consumption of the comfort

consumers in l/h and a list of three consumers (e.g. air conditioning etc.), which

have the largest share of fuel consumption.

Infotainment display

Fig. 46

Journey data

In Infotainment in the menu



/  tap on function surface  → Tap Journey

data.

Screen display

» Fig. 46

Distance travelled
Driving time
Average speed
Average fuel consumption
Transit point rating (DriveGreenFunction)
Graphic fuel level display (if the estimated range is less than 300 km, the

vehicle starts to approach the symbol )
Approximate range

Use the function surfaces   to select one of the following presets.

Since start - Driving data for the individual trip

Long-term - Long-term driving data

Since refuel - Data since refuelling

Warning when exceeding the set speed

The system offers the possibility to set a speed limit beyond which an acoustic

warning signal will sound and the following warning message appears in the

display of the instrument cluster.

Adjust the speed limit while the vehicle is stationary

Select the menu item Warning at and confirm.

Set the desired speed limit is 5 km/h steps.

Confirm the set value, or wait several seconds; your settings will be saved

automatically.

A
B
C
D

E
F

G

52

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Adjusting the speed limit while the vehicle is moving

Select the menu item Warning at and confirm.

Drive at the desired speed.

Confirm the current speed as the speed limit.

The set speed limit can be manually adjusted later if needed.

Reset the speed limit

Select the menu item Warning at and confirm.

By confirming the stored value, the speed limit is reset.

The speed limit set mode is stored even after the ignition is switched off and

on. After a gap between driving exceeding 2 hours, the pre-set speed limit is

deactivated.

Memory

Fig. 47

Memory display

The system saves the data in the three memories described below which are

displayed at the position

A

» Fig. 47

.

Since start

In the memory, driving data is saved for the time between switching on and

switching off the ignition. New data will also flow into the calculation of the

current driving information if the trip is continued within 2 hours after switch-

ing off the ignition.
If the trip is interrupted for more than 2 hours, the memory is automatically

erased.

Long-term

The memory gathers driving data from any number of individual journeys up to

a total of 99 hours and 59 minutes driving time or 9999 kilometres driven.

The indicator is automatically set back to zero if one of the indicated values is

exceeded.

Since refuel

The driving data is stored in the memory since the last fuel refuelling.
The memory is erased automatically the next time you fill up.

For the Storage choice, repeatedly confirm the selected indication and se-

lect the desired memory.

For Deleting the memory for the selected information, hold down the but-

ton confirming the specification.

The following driving data are stored.

Average fuel consumption

Distance travelled

Average speed

Driving time

Note

Disconnecting the vehicle battery will delete all memory data.

Menus in the display of the instrument cluster

Introduction

The instrument cluster display is a user interface which, depending on the

equipment configuration, provides information about the Infotainment, the

multifunction display, the assistance systems etc.
The menus with details can be operated and displayed using the buttons on

the operating lever or the multifunction steering wheel

» page 51

.

Main menu items (depending on vehicle equipment)

Driving data

» page 51

Assist systems

» page 54

Navigation

» page 54

Audio

» page 54

Telephone

» page 54

;

Vehicle

» page 49

53

Information system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Note

If warning messages are displayed, these messages must first be confirmed

to access the main menu.

The display language can also be set in Infotainment

» page 137

Setting the

Infotainment language and

» page 144

Setting the Infotainment language.

Navigation menu item

The following information is displayed in the Navigation menu item.

Driving recommendations

Compass

Last destinations

audio menu item

E.g. the following information is displayed in the Audio menu item.

Radio

Currently playing station (name/frequency).

The selected frequency range (e.g. FM) optionally with the number of the

station button (e.g. FM3), if the station is stored in the memory list.

List of available stations (if more than 5 stations can be received).

TP traffic announcements.

Media

Name of the track being played, if necessary, further information regarding

title (e.g. artist, album name), if this information is stored as a so called ID3

tag on the audio source.

Telephone menu item

The call list with the following symbols is displayed in the Telephone menu item.

Incoming call
Outgoing call
Missed call

Symbols in the display

Telephone battery charge (this function is only supported by some mobile

phones)

Signal strength (this function is only supported by some mobile phones)

A telephone connected to the Infotainment system

Missed calls (if there are several missed calls, the number of calls is shown

next to the symbol)
Switch-off microphone

Apple CarPlay

An external device connected to the Infotainment system via Apple CarPlay

can be operated via the multifunction steering wheel as well as via menus in

the instrument cluster display.
The following symbols are displayed in the Telephone menu option.

Answer the incoming call
Reject incoming call / end call
Activate / deactivate microphone (applies for the infotainment Swing)

Assist systems menu item

The following systems are activated/deactivated in the Assist systems menu

item.

Lane Assist

Front Assist

Assist system for blind spot monitoring

Rear Traffic Alert

Service intervals

Introduction

Compliance with the service intervals is of crucial importance for the serv-

ice life and value retention of the vehicle. Never exceed the service date.
The specialist garage will inform you about the type of service interval, the op-

tion to change it, and the service scope.
The service interval display in the display of the instrument cluster will notify

you when a service is due.

Proof of service

A specialist garage will confirm the corresponding service record in the service

information system called Digital Service Plan.
We recommend that you always print out the respective service record.



54

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Note

The customer is responsible for covering the cost of all services including

changing or replenishing the oil, even during the warranty period, unless stated

otherwise in the ŠKODA AUTO warranty terms or other binding agreements.

Displaying the distance and days until the next service interval

Fig. 48

Button in the instrument cluster

The details regarding the remaining kilometres or days until the next scheduled

service can be displayed in Infotainment in the menu



/  →  → Events or

with the button in the instrument cluster.

Use the key to display

Switch on the ignition.

Press and hold the button

A



» Fig. 48

 until theService menu item is shown in

the display.

Release the button

A

.

In the display, the symbol  appears for 4 seconds along with the following

message for the kilometres or days to the next service appointment.

Service messages

Before the next service date has been reached, the symbol  as well as a

message about the mileage or days until the next service event appears in the

display after the ignition is switched on.
Once the service interval is reached, the symbol  appears in the display after

the ignition is switched on, together with the message:

Resetting the service interval display

Have the display reset by a specialist garage.

We recommend that you do not reset the service interval display yourself. In-

correctly setting the service interval display can cause problems to the vehicle.

Variable service interval

For vehicles with variable service intervals, after resetting the oil change serv-

ice display in a specialist garage, the values of the new service interval are dis-

played, which are based on the previous operating conditions of the vehicle.
These values are then continuously matched according to the actual operating

conditions of the vehicle.

Personalization

Introduction

Thanks to the personalisation, more drivers have the opportunity to use a vehi-

cle with individually set system functions by means of a user account which is

assigned to the respective vehicle key.

WARNING

Make all adjustments when the vehicle is stationary - otherwise there is the

risk of accident!

55

Information system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Operating principle

Fig. 49

Switching to a different user account

Read and observe   on page 55 first.

After unlocking the vehicle and opening the driver's door, all the personalised

functions are adjusted according to the user account that is assigned to the

key which was used to unlock the vehicle.
Any change to the set personalised functions is automatically stored in the ac-

tive user account.
As part of the personalisation, three default user accounts as well as a

Guestaccount are provided.

Switch to a different user account

You can switch to a different user account in the instrument cluster display

» Fig. 49

 within 10 seconds after turning on the ignition.

An account can be changed at a later time in Infotainment in the menu



/ 

→  →Vehicle status →  (if the Tyre Pressure Monitoring System is displayed first of

all, then use the arrow  or  switch to Vehicle status).
If an account is selected in which not all of the points required by the system

are set, a configuration wizard can be automatically displayed on the Infotain-

ment screen

» page 132

.

Electrically adjustable driver's seat (referred to only as seat in the

following)

The seated position adjustment is carried out in the following cases.

After unlocking the vehicle and opening the driver's door (in this case: before

the vehicle was locked, an account with a certain seat setting was selected.

After vehicle unlocking, an account is activated to which a different seat set-

ting is assigned).

After switching to a different user account and at a speed less than 5 km/h.

The seat adjustment can be terminated as follows.

By tapping on the function surface Cancel on the Infotainment screen.

By pressing any key on the seat

» page 85

.

Note

Vehicles with the personalisation function are provided with three vehicle

keys.

Overview of some personalized functions

Read and observe   on page 55 first.

Setting the electrically adjustable driver's seat.

Exterior mirror adjustment.

Driving mode - setting the individual mode

Assistance systems - Lane Assist, parking aid (Park Pilot).

Light - ambient lighting, convenience turn signal, COMING HOME / LEAVING

HOME.

Climatronic - temperature in each individual area, fan speed, recirculation

mode.

Infotainment settings - brightness level of the screen, keyboard arrange-

ment.

Radio - sound settings, station sorting.

Media - shuffle / repeat title, selected video format.

Voice control - acoustic signals.

Navigation - home address, alternative routes, recommended route, reminder

of the lack of fuel.

Note

The scope of the personalisation functions is dependent on the type of Info-

tainment package.

Setting the personalization

Read and observe   on page 55 first.

In Infotainment in the menu



/  tap on function surface  → Personalisa-

tion.

The following menu items are displayed.

56

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Personalisation

Active - activate/deactivate the personalisation

Select a user account

A list of user accounts with the option to manage user accounts and to switch

to another account.

 - Account management with the following options:

Rename user account - rename the user account (not applicable to the Guest

account)

Copy settings to another account - copy the settings of an active user account

to another user account

Reset user account - reset the selected user account to factory settings

Adjusting

Key assignment: - options for assigning the vehicle key to the user account:

Manual - detected vehicle key must be assigned to the active user account

manually

Automatic - detected vehicle key automatically assigned to a different ac-

count of the active user account

Assign vehicle key to current user account - manual assignment of the detected ve-

hicle key to the active user account - follow the instructions on the Infotain-

ment screen

Reset all - reset the personalisation and the user accounts to factory settings

Unlocking and opening

Unlocking and locking

Introduction

The vehicle is equipped with a central locking system which makes it possible

to unlock / lock all the doors, the fuel filler flap and boot lid simultaneously.
The door unlocking can be adjusted individually

» page 60

.

The unlocking of the vehicle is displayed by the turn signal lights flashing

twice.
If you unlock the vehicle and do not open a door or the boot lid within the next

45 seconds, the vehicle will lock again automatically.
The locking of the vehicle is displayed by the turn signal lights flashing once.
If the driver's door has been opened, the vehicle cannot be locked.
If the doors or the boot lid remain open after the vehicle has been locked, the

turn signal lights do not flash until they have been closed.

WARNING

Never leave the key in the vehicle when you exit the vehicle. Unauthorized

persons (e.g. children) could lock the car, turn on the ignition or start the

engine - there is a danger of injury and accidents!

When leaving the vehicle, never leave people who are not completely in-

dependent, such as children, unattended in the vehicle. These individuals

might not be able to leave the vehicle on their own or to help themselves.

Can be fatal at very high or very low temperatures!

CAUTION

Each key contains electronic components; therefore it must be protected

against moisture and severe shocks.

Keep the keyway clean. Impurities (textile fibres, dust etc.) have a negative

effect on the functionality of the locking cylinder and ignition lock.

57

Unlocking and opening

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Unlocking/locking with the remote control key

Fig. 50  Key with fold/out key bit/KESSY key

Read and observe   and   on page 57 first.

Description of the key

» Fig. 50

Unlock button
Lock button
Depending on equipment fitted:

Unlock/unlatch the boot lid (vehicles fitted with manual folding opera-

tion)

Open/close/ the boot lid Stop movement of the boot lid (vehicles with

electric folding operation)

Locking button for folding the key bit in/out
Warning light for the battery charge - if the warning light does not flash

when a button on the key is pressed, the battery is discharged.

Unlock/unlatch the boot lid (vehicles fitted with manual folding operation)

By pressing the button , the lid is unlocked.
By holding the button , the lid is unlocked and unlatched (partially open).
If the lid is unlocked or unlatched using the  button, then the lid is automati-

cally locked after closing. The period after which the lid is locked can be set

» page 63

.

A
B

CAUTION

The remote control may be affected by signal superposition of transmitters

that are in the vicinity of the vehicle.

The range of the remote control key is about 30 m. The battery must be re-

placed if the central locking only reacts to the remote control at a distance of

less than approximately 3 m away

» page 291

.

Remove KESSY emergency key

Fig. 51  KESSY key

Read and observe   and   on page 57 first.

The emergency key is, for example, intended for the operation of the child

safety, and for switching off/on the front passenger airbag.

Remove retainer tabs

A

 in the direction of arrow

1



» Fig. 51

.

Remove the emergency key

B

 in the direction of the arrow

2

.

58

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Locking / unlocking - KESSY

Fig. 52  Vehicle unlocking / vehicle locking

Read and observe   and   on page 57 first.

The KESSY system (Keyless Entry Start Exit System) enables unlocking and

locking of the vehicle without actively using the remote control key.

Grip the door handle to unlock the vehicle

» Fig. 52

 - .

Touch the sensor on the door handle with your finger to lock

» Fig. 52

 - 

the vehicle.

When unlocking/locking the vehicle, the key must be at a maximum distance

of approximately 1.5 m from the front door handle.

Information on locking

On vehicles fitted with automatic gearbox, the selector lever must be moved

into the position P before unlocking.
After locking the vehicle, it is not possible to unlock within the next 2 seconds

by touching the door handle. This can be used to check whether the vehicle is

locked.

Protection against inadvertently locking the key in the vehicle

If one of the doors is closed after the vehicle has been locked and the key with

which the vehicle was locked remains in the passenger compartment, the vehi-

cle will be automatically unlocked. After automatically unlocking, the turn sig-

nal lights will flash four times. If no door is opened within 45 seconds, the vehi-

cle is automatically locked again.

If the boot lid is closed after locking the vehicle and the key with which the

vehicle was locked remains in the luggage compartment, the lid is automatical-

ly unlatched (partially opened). After automatically unlocking, the turn signal

lights will flash four times. The boot lid remains unlatched (partially opened);

the other doors remain locked.

CAUTION

Some types of gloves can affect the unlocking or locking device via the sen-

sors in the door handle.

Deactivating KESSY

Read and observe   and   on page 57 first.

Lock the vehicle with the button  on the key.

Within 5 s, touch the sensor on the door handle with your finger

» Fig. 52

 on

page 59 - . Deactivation is confirmed by a single flash of the direction indi-

cators.

To check the deactivation, wait at least 10 seconds and then pull the door

handle. The door must remain locked.

The KESSY system is activated again automatically after the vehicle is un-

locked.

Locking/unlocking the vehicle with the central locking button

Fig. 53

Central locking button

Read and observe   and   on page 57 first.

Conditions for the locking/unlocking using the central locking button.

The vehicle is not locked from the outside.
All doors are closed.

59

Unlocking and opening

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Tolock, press the button  Press

» Fig. 53

Locking is displayed in the button by the illumination of the

 symbol.

The following applies after locking.

Opening the doors and the boot lid from the outside is not possible.

The doors can be unlocked and opened from the inside by a single pull on the

opening lever of the respective door.

WARNING

Doors locked from the inside make it difficult for rescuers to get into the

vehicle in an emergency – risk to life!

SafeLock

Read and observe   and   on page 57 first.

SafeLock prevents the doors from behind opened from inside as well as win-

dow operation. This makes it more difficult for anyone to break into the vehi-

cle.

Switching on

SafeLock switches on when the vehicle is locked.
This function is enabled after switching off the ignition with the message Check

safe lock.! Log book! In the instrument cluster display.

Switch-on display

With the activated SafeLock, the warning light in the driver´s door flashes for

2 seconds in rapid succession, this then starts to flash at longer intervals.

Switching off

By locking twice within 2 seconds.

or: by deactivating the interior monitor and the towing protection

» page 62

.

The warning light in the driver´s door flashes fast for about 2 seconds, goes

out and starts to flash at longer intervals after about 30 seconds.
If the vehicle is locked and the safe securing system is switched off, the door

can be opened separately from the inside by a single pull on opening lever.
The safelock switches on the next time the vehicle is locked.

WARNING

If the car is locked and the safe securing system activated, no people must

remain in the car as it will then not be possible to either unlock a door or

open a window from the inside. The locked doors make it more difficult for

rescuers to get into the vehicle in an emergency – risk to life!

Individual settings

Read and observe   and   on page 57 first.

The following central locking functions can be set individually in Infotainment

in the menu



/  →  → Opening and closing.

All doors

The function allows you to unlock all doors, the boot lid and the fuel filler flap.

Single door

The function allows you to unlock only the driver's door and the fuel filler flap

with the radio remote control. KESSY allows the unlocking of a single door

which is in the vicinity of the key, as well as the fuel filler flap. The other doors

and the boot lid are only unlocked once the door handle is unlocked or

touched.

Doors on a vehicle side

This function enables you to unlock both doors on the driver's side and the fuel

filler flap with the radio remote control unit. KESSY allows the unlocking of

both doors which are in the vicinity of the key, as well as the fuel filler flap. The

other doors and the boot lid are only unlocked once the door handle is un-

locked or touched.

Automatic locking/unlocking

This function enables the locking of all doors and the boot lid from a speed of

15 km/h. Opening the doors and the boot lid from the outside is not possible.
The renewed unlocking of the doors and the boot lid is carried out when the

ignition key is removed or when the door is opened from inside (depending on

the individual setting for the central locking system).

Note

The individual adjustment of the central locking system is stored (depending

on the Infotainment type) in the active user account personalisation

» page 55

.

60

Using the system

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     1      2      3      4      ..
