Skoda Citigo (2019 year). Instruction - part 5





Balance - Fader - Setting the sound focus between left and right, front and rear

(applies to equipment with four speakers)

Balance - Setting the sound focus between the left and right (applies to equip-

ment with two speakers)

Bass - Mid - Treble - setting the equaliser

Main menu settings

Press the button



.

Choose the desired menu item by turning the controller  .

Confirm menu item selection by pressing the controller  confirm.

Radio-Radiomenu settings

» page 74

Radio settings

Media-Mediamenu settings

» page 74

Media settings

Screen - Display settings

» page 74

Display settings

Language - Device language settings

» page 74

Device language settings

Remove source safely - Safe removal of external devices

» page 74

Safe re-

moval of the external device

Factory settings - Reset to factory settings

» page 75

Factory settings (to fac-

tory settings)

System information - System Information

» page 75

System information

Copyright - license information of the device

Radio settings

Press the button



Radio.

Arrow buttons: ... - Setting the station change function (buttons

 and

)

Presets- Change between stations stored under the preset buttons

Stations - Change between all available stations of the selected broadcasting

range

Traffic programme (TP) - Switches TP traffic programme on/off

Delete presets - Deletes the preset buttons

Sort: ... - Sort the channels in the list of available stations on the FM radio

range

Alphabetically - Sorting by name

By group - Sorting by PI code

Advanced FM settings - Additional FM broadcast range settings

RDS Reg.: ... - Setting the automatic change to a regional stations with a

stronger reception signal

Automatic - Switching on the automatic change function

Fix - Turn off the automatic change

Radio Data System (RDS) - enable/disable RDS function (receiving additional in-

formation from the station)

Frequency control (AF) - Search for alternative frequencies of the station cur-

rently being played to on/off

Advanced DAB settings - Additional DAB broadcast range settings

DAB traffic announcements - Switch on/off DAB traffic announcements

Other DAB announcements - Switch on/off other announcements (e.g., warn-

ings, regional weather, sports reports, financial news)

Station tracking DAB - Switch on/off automatic DAB station tracking on an-

other frequency or in other station groups

Aut. DAB - FM switching - Switch on/off automatic switching from DAB to the

FM frequency band if the DAB signal is lost

Media settings

Press the button



 → Media.

Mix/repeat including sub-folders - Switching the title display on/off including sub-

folders

Display settings

Press the button



Screen.

Screen off (in 10 seconds) - Enable / disable the automatic power off function

Brightness: ... - Adjusts the brightness of the display

Show time in standby - Time and date displayed on the screen when the ignition

is switched on and the unit is switched off

Device language settings

Press the button



 → Language.

Set the desired language.

By selecting the menu item Auto (= instrum. cluster) the device language is set ac-

cording to the language setting for the MAXI DOTdisplay

» page 36

.

Safe removal of the external device

Press the button



 → Remove source safely.

Select the external device to be removed.

74

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Factory settings (to factory settings)

Press the button



Factory settings.

Select the menu item to be reset to factory settings.

By selecting the menu item Reset all, all device menus are reset to factory set-

tings.

System information

Press the button



→ System information.

Displaying system information.

Part number: - Part number of the device

Software: - Version of the software used

Hardware: - Version of the hardware used

Radio

Introduction

Depending on the vehicle equipment, analogue radio reception of the FM and

AM frequency ranges as well as DAB digital radio reception is possible.

CAUTION

Car parks, tunnels, tall buildings or mountains can interfere with the radio sig-

nal even causing it to fail completely.

Main menu

Fig. 99

Main menu:

Swing/Blues

Read and observe   on page 75 first.

To display the main menu, press the



 button.

Main menu

» Fig. 99

Current selected broadcasting area and number of the station button on

the currently playing station is stored
The selected radio station (description or frequency)
Radio Text (FM) / Description of the group (DAB)

Changing the station

List of available stations
Instruction station search
Switches traffic programme on/off
Preset station buttons for favourite channels

Information symbol in the status line

Symbol

Meaning



Traffic signal is available



 

Traffic signal is not available



 

AF Alternative frequency is switched off (FM)

Signal is not available (DAB)

A

B
C

 



75

Radio Swing / Blues

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Select broadcasting range

Fig. 100

Choose broad-

casting range:

Swing/Blues

Read and observe   on page 75 first.

In the radiomain menu press the button



 and the corresponding function

button .  or  Press

» Fig. 100

Search for stations and select frequency

Read and observe   on page 75 first.

Find stations

Applies to Swing: in the Radio main menu, press function button  or  .

Applies to Blues: in the Radio main menu, press button

 or

 on the device.

Depending on the setting of the Arrow keys: menu item ... in radio settings will set

an available station from the Stations list or a station of the current broadcast

range on the Station buttons.

Select frequency

To display the value of the currently chosen frequency, press the function

button in the Radio main menu  .

To set the desired frequency value, press the function button in the radio

main menu  and then use one of the function buttons     .

Scan through the stations one after the other (SCAN)

The function scans through all the available stations in the current frequency

range in succession, for a few seconds each.

To start/finish automatic playback of the available stations, press the dial in

the Radio main menu  .

List of available stations

Fig. 101

List of available

stations:

Swing/Blues

Read and observe   on page 75 first.

To display the list of available stations of the currently selected broadcasting

area, press the function button in the Radio  .

To playback select the desired channel using the function buttons  and 

Or by turning the controller  . Call up the station  by pressing the control-

ler.

Station list

» Fig. 101

Station selection

 - Save the station to a station button

Information symbols

Symbol

Meaning

Currently played stations

Station is stored under one of the preset station buttons



Traffic information station

Signal reception is not available (DAB)

Signal reception is not secure (DAB)

(e.g.)  Type the regional broadcast (FM)

A
B

76

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Refresh list

In the FM radio area, the station list is updated automatically.
In the AM and DABradio area, the update takes place instructionly by pressing the

function button 

» Fig. 101

.

Preset buttons for your favourite channels

Fig. 102

Preset buttons

for favourite

stations:

Swing/Blues

Read and observe   on page 75 first.

to Display the preset buttons for preferred stations in the radiomain menu,

press the function button  .

To store channels, select the storage group with the function button

A

» Fig. 102

 and hold the desired station button.

Deactivation is confirmed by an acoustic signal.
If a station is saved on an already assigned station button, the assigned station

button will be overwritten.

Preset station buttons for favourite channels

» Fig. 102

Choice of storage group
Used space
The selected station is stored on this station key
Unused space
Return to Radio Main menu

A
B
C
D

There 12 (applies to Swing) Or 9 (applies to Blues) Station keys for storing

preferred stations available n each broadcast area respectively, that are split in

three storage groups e.g. FM1, FM2, FM3).

Media

Main menu

Fig. 103

Main menu:

Swing/Blues

To display the main menu, press button



.

Main menu

» Fig. 103

Information on playing track
Playback timeline with a slider
Selected audio source
Control of track playback
Playback time / Information for VBR
Folder/Title list

Note

Information concerning the given title appears on the display, if they are

stored as so-called ID3 Tags on the audio source. If no ID3 tag is available, only

the title name is displayed.

The remaining playback time indicated does not correspond to the actual re-

maining playback time for titles with variable bit rates (VBR).

A
B
C
D

E

77

Radio Swing / Blues

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Folder / track list

Fig. 104

Folder/track list:

Swing/Blues

Folder/track list

» Fig. 104

Audio source folder
Select the audio source
Change to the parent folder
Playback Options
Closing the current menu

Currently reproduced folder / title / Stopped folder / track playback

Folder
Playlist
Title playback is not possible

Note

The scanning speed of the folder / track list depends on the connection speed

and volume of data.

A
B

C

  

Playback control

Operation

Action - applies to Swing

Action - applies to Blues

Play / Pause the current album / folder

Pressing the function button  or 

Playback the current video from the start

Pressing the function button  (about 3 seconds af-

ter the start of the track playback)

Press

 (after 3 seconds after the start of the title

playback)

Fast-reverse within the title

Holding the function button  

Press and hold

Fast-forward within the track

Holding the function button  

Press and hold

Play the previous title

Pressing the function button  (within 3 seconds af-

ter the start of the track playback)

Press

 (within 3 seconds after the start of the

track playback)

Play the next title

Pressing the function button 

Press

Switch on/off the random playback from the current

album or folder

Pressing the function button 

Switch on/off the repeat playback from the current

album or folder

Pressing the function button 

Switch on/off repeat playback of specific track

Pressing the function button 

78

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Play and select audio source

Fig. 105

Selecting the

audio source in

the main menu:

Swing/Blues

Fig. 106

Select audio

source from

folder list:

Swing/Blues

To playback connect the audio and slide it into the machine.

To select audio from the main menu mediapress the button



 and select

the desired source using the function buttons

» Fig. 105

.

If no audio source is chosen within 5 seconds, then the main menu of the last

selected audio source is displayed.

To select the audio source in the folder / track list the function button 

repeatedly until the display on the position

B



» Fig. 104

 on page 78  is dis-

played.

Press the function key  . Use the dial  to select the audio source

» Fig. 106

and choose the desired folder/track.

Playback starts automatically (does not apply to AUX).
If AUX is selected as the audio source, the playback must be started on the

connected device.

CAUTION

Do not save any important data or that which has not been backed up on the

connected audio sources. ŠKODA assumes no responsibility for lost or dam-

aged files or connected audio sources.

When changing or connecting an audio source, this may cause sudden

changes in volume. Reduce the volume before changing or connecting an au-

dio source.

When connecting an external audio source, the external source information

messages can be displayed. These messages must be observed and if necessa-

ry confirmed (e.g. enabling data transfer etc).

Note

The national copyright laws that apply in your country must be observed.

SD-card

Fig. 107

Insert the SD card

Insert the SD card in the slot in the direction of the arrow (with the cut end

facing upwards), until it“locks”

» Fig. 107

.

Applies to Swing: to remove press button



 →  → Remove source safely → SD

card.

Applies to Blues: to remove press button



 → Remove source safely → SD card.

Press on the inserted SD memory card. The SD card “jumps” into the eject

position.

79

Radio Swing / Blues

-------------------------------------------------------------------------------------------------------------------------------------------------------------

CAUTION

Do not use an SD card with a broken write protection slide - there is a risk of

damage to the SD card reader!

When using an SD card with an adapter, vehicle vibrations might cause the

card to fall out of the adapter.

CD

Applies to Blues.

Toinsert a CD, with the labelled side facing up, into the CD slot until it is au-

tomatically drawn in.

Toeject, press the button

, the CD is manoeuvred to the eject position.

If the ejected CD is not removed within 10 seconds, it is retracted again for

safety reasons.

WARNING

The CD-player is a laser product.

On the manufacturing date, this unit was classified as a class 1 laser prod-

uct in accordance with the national/international standards

DIN EN 60825-1: 2008-05 and DHHS Rules 21 CFR, Subchapter J. The la-

ser used in this class 1 laser product is so weak that there is no risk of dan-

ger when operated correctly.

This product is designed such that the laser is restricted to the inside of

the unit. However, the installed laser could be classified in a higher class

were the housing to be removed. For this reason, never remove the unit

housing.

CAUTION

Be sure to remove the CD before you try to insert a new CD. Otherwise you

can damage the drive inside the unit.

Insert into the CD drive only original audio CDs or standardised CD-R/RWs.

Do not stick anything to the CDs!

If the ambient temperature is too high or too low, the CD playback may not

function properly.

Damp (condensation) may affect the device in cold weather or high humidity.

This can cause the CD to jump or impair the play function. Once the moisture

has dissipated, playback is fully functional again.

Note

After pressing the

 button , there is a delay of a few seconds before the

CD is ejected.

On uneven or unpaved roads, playback jumps may occur.

If the CD is damaged, is not readable or is inserted incorrectly, the following

message is displayed CD is unreadable.

It is possible that CDs protected by copyright cannot not be played back at

all or only in certain circumstances.

USB input

Fig. 108  USB input: in the front centre console/in the dashboard

The USB input (with  in) is located in the front centre console or in the dash-

board

» Fig. 108

.

The USB input audio source can be connected directly or via a connecting ca-

ble.

To connect, insert the USB audio source into the appropriate input.

Applies to Swing: to disconnect press button



 →  → Remove source safely

→ USB.

Applies to Blues: to disconnect press button



 → Remove source safely →

USB.

Disconnect the audio source from the corresponding USB input.

Charge USB audio source

After connecting the USB audio source to the device, charging starts automat-

ically (applies to audio sources with which charging via the USB connector can

be carried out).
The charging efficiency can differ compared to the charging from the usual

mains power supply.

80

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Some connected audio sources may not be recognised and cannot be charged.

CAUTION

USB extension cords, or reducers may impair the function of the connected

audio source.

Note

We recommend that you use extension cords from ŠKODA Original Accesso-

ries.

AUX - input

To connect, insert the plug of the AUX audio source into the appropriate

connector.

To disconnect, pull the plug out of the AUX audio source.

CAUTION

The AUX input must only be used for audio devices!

If an external audio source is connected to the AUX input, which is equipped

with an adapter for external power supply, the sound may be impaired.

Note

The 3.5 mm stereo jack plug is used for the AUX input.

We recommend that you use extension cords from ŠKODA Original Acces-

sories.

Bluetooth

®

player

Applies to Swing.

The unit allows audio files of a connected Bluetooth

®

player to play using the

A2DP and AVRCP audio profile.

To Connect the player to the device - follow the same instructions as for

pairing the device with a phone

» page 82

.

To Separate, end the connection by pressing the button



 →  → Bluetooth

→ Bluetooth audio (A2DP / AVRCP).

Supported audio sources and file formats

Supported audio sources

Source

Interface

Type

Specification

File sys-

tem

SD card

SD reader

Standard size

SD, SDHC, SDXC

FAT16

FAT32

exFAT

USB-

devices

USB 1.x; 2.x

and 3.x or

higher with

support of

USB 2.x

MSC

USB stick;

HDD (without any

special software);

USB devices that

support MSC opera-

tion

MTP

Devices with the

Android operating

system or Windows

mobile (mobile

phone, tablet)

Apple

Devices with the

iOS operating sys-

tem (iPhone, iPod,

iPad)

CD

(Applies to

blues)

CD

-Drive

Audio CD (Up to

80 min);

CD-R / RW (Up to

700 MB);

ISO9660;

Joliet (Level 1,2,3);

UDF 1.x;

UDF 2.x

-

Supported audio file formats

Codec type

(File formats)

File suffix

Max. bit rate

Maximum

sampling

rate

Playlists

Windows Media

Audio

9 and 10

wma

384 kbit / s

48 kHz

m3u

pls

wpl

m3u8

asx

MPEG-1 and 2

layer 3

mp3

320 kbit / s

The audio sources divided into areas using GPT standards (GUID partition ta-

ble) are not supported by the device.

81

Radio Swing / Blues

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Files that are protected by Digital Rights Management (DRM) technology can-

not be played back by the device.

Phone

Introduction

Applies to Swing.

This chapter covers the operation of a Bluetooth

®

 device connected to the tel-

ephone.
To pair a telephone with the device using Bluetooth

®

, it is necessary to pair the

two devices.
The range of the connection to the hands-free system is limited to the passen-

ger compartment.
With the device, a phone can be connected. The telephone can also be a Blue-

tooth

®

player at the same time.

Up to 20 external devices can be paired with the device. After reaching the

maximum number, the pairing of the next external device will replace that of

the device that has not been used for the longest period of time.
A connection with a telephone that is already paired does not require pairing. It

is enough to find the telephone that has been paired in the list of paired

phones and make the connection.
For phones with multiple SIM cards,calls can be answered using any SIM card

from the connected phone depending on the model of the connected phone.

For outgoing calls, it depends on the type of connected telephone, either only

the primary SIM card or one of the other SIM cards can be selected.
Information on the compatibility of phones can be found on the following

ŠKODAInternet sites.

http://go.skoda.eu/compatibility

Conditions for pairing

The telephone can be paired with the device under the following conditions.

The ignition is switched on.
The Bluetooth

®

 function of the device and the telephone is switched on.

The visibility of the device and the telephone is switched on.
The telephone is within range of the Bluetooth

®

 signal of the device.

The telephone is compatible with the device.
The telephone is connected to an external Bluetooth

®

 device (e.g. “head-

set”).

Pairing and connection process

Fig. 109

No phone con-

nected

Fig. 110

List of Blue-

tooth® devices

found / list of

paired phones

Pairing and connecting a phone to the device

Search available Bluetooth

®

 devices in your telephone.

Select the device (the device name is Skoda BT XXXXThe characters XXXX

represent the last four digits of the vehicle identification number).

Confirm or enter the PIN code to confirm the pairing and the connection.

82

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

If the device connected to another phone, then the phone to be paired is only

paired with the device.

Pairing and connecting the device to a phone

If there is no phone connected to the device, then press the button



 → 

Press

» Fig. 109

If a phone is connected to the device, press button



 →  → Bluetooth →

Search for devices.

Select the desired phone from the list of selected external Bluetooth

®

 devi-

ces

» Fig. 110

-.

Confirm or enter the PIN code to confirm the pairing.

To display information to connect to an external Bluetooth

®

device, press the

function button 

» Fig. 110

 - .

The device connects to a phone which is already paired

If there is no phone connected to the device, press button



 →  Press

» Fig. 109

If a phone is connected to the device, press button



 →  → Select phone.

or: Press the button



 →  → Bluetooth → Paired devices.

Select the phone

» Fig. 110

 -  or an external Bluetooth

®

-Device

» Fig. 118

 on

page 86 -  in the list shown.

Telephone

Fig. 111

Main menu

The Telephone main menu appears when a telephone is connected to the de-

vice.

To display, press the



 button.

Main menu

Name of the telephone service provider (with active roaming, the symbol

appears before the name )
Possible symbols in the status bar

 - A phone is connected to the device

A

B

 - Charge status of the phone battery

 - Signal strength of the phone service network

 - Current call

 - Missed call

Enter the telephone number
Display the telephone contact list
Display of call list (missed calls is displayed beside the function key icon 

with the number of missed calls)
Dial the mailbox number
Dialling the emergency number (valid only in certain countries)
Display of favourite contacts (favourites)

Enter and select phone number

Fig. 112

Entering the

phone number:

no entered num-

ber/input

Enter a telephone number and dial

Press in the main menu the Telephone function button 

» Fig. 111

 on

page 83 .

Enter the phone number using the  controller.

Pressing the function key  to select the number entered.

Function buttons

Enter the last dialled number / dial the telephone number entered
Termination of the phone call (during a phone call)

83

Radio Swing / Blues

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Dialling the emergency number (valid only in certain countries)
Dial the breakdown number in case of breakdown
Dial the info number (for information regarding the products and serv-

ices of the ŠKODA brand)
Dial the mailbox number
Movement of the cursor in the input line
Delete the last number entered

Breakdown and information call

The breakdown and info call is free of charge. Charges are only made for a tel-

ephone call in accordance with the tariff conditions of your telephone service

provider.
The phone numbers are already set at the factory. If you want to change the

numbers, then consult a ŠKODA service partner.
If no breakdown or Info calls can be made then consult a ŠKODA service part-

ner.

List of telephone contacts

Fig. 113

List of contacts

To display, from the Phone main menu, press the function button 

» Fig. 111

on page 83 .

Use the controller  to select the desired telephone contact.

If a contact contains several telephone numbers, the system displays a menu

containing additional telephone numbers after selecting the contact.

Pressing the function key 

» Fig. 113

 displays a menu for storing the prefer-

red contact

» page 84

Preferred contacts (favourites).

import list

After the first connection of your telephone with the device, then telephone

contacts begin importing to the device memory. The import can take several

minutes.

 

The device telephone book contains 2000 memory locations for imported tel-

ephone contacts. Each contact can contain up to 5 telephone numbers.
The number of imported contacts can be determined in the menu item



 →

 → User profile → Import contacts: ….

If an error occurs during the import, an appropriate message appears on the

display.

Refresh list

When the telephone reconnects with the device the list is automatically upda-

ted.
The update can be performed manually as follows.

Press the key



 →  → User profile → Import contacts: ….

During updating, the number of imported contacts to the device memory/the

number of contacts in the telephone is displayed.
After updating the number of contacts imported / 2000 (max. permitted num-

ber) is displayed.

Preferred contacts (favourites)

Fig. 114

List of preferred

contacts (fa-

vourites): Save

Fig. 115

List of preferred

contacts (fa-

vourites): Select

The function allows for storage and the choice of the number of the preferred

contact.

84

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

The favourites are available in three storage groups, each with four contacts.

Save favourite

Show the contact list

» page 84

 or call history

» page 85

 .

Select the phone contact or number and the function button  with the con-

troller  .

Select the location for favourite storage

» Fig. 114

.

If the selected position is already occupied, its contents will be overwritten by

confirming.

Select favorites

Press in the main menu the Telephone function button 

» Fig. 111

 on

page 83 .

Press the function button

A



» Fig. 115

 repeatedly to select the desired

group.

To start connection establishment press the function button of the desired

contact

B



» Fig. 115

.

To close the favourites list, press the function button  .

Delete favourite

Press the button



 →  → User profile → Delete favourites.

Use the controller  to select the contact and to confirm the delete process.

All preferred contacts can be deleted by pressing the function buttonClear all

and confirm the deletion.

Call list

Fig. 116

Call list

To display, from thephonemain menu, the function button 

» Fig. 111

 on

page 83 .

The calls in the call list can be filtered according to the type.
Contacts or numbers can be stored in the favourites list

» page 84

Preferred

contacts (favourites).

Function buttons

All calls
Received calls
Outgoing Calls
Missed calls
Storing the contact / the number in the favourites list

The symbol of the currently selected call type is shown in colour.

Phone call

Fig. 117

Telephone con-

versation: Dis-

play example

The device makes it possible to take another incoming call during an ongoing

call. The existing telephone call is put on hold. You can switch between calls.
Using the function keys located below the display, the following functions can

be carried out depending on the context.

Answer incoming call / accept another incoming call / Return to call on

hold

Switch on/off ringer

End dialling / reject incoming call / end call
Enter call number
Switch between the calls
Keep talking

Activate / deactivate microphone / device speakerphone

Speakerphone on / off (switch call to phone / device)

To turn off the speakerphone, press



 →  → Hands-free during a call.

To switch on the hands-free device, tap on the function button  during a

call.



  

    

85

Radio Swing / Blues

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Managing paired Bluetooth devices

Fig. 118

Paired devices

list / Delete

paired devices

To display the list of paired external devices, press the function button



 →

 → Bluetooth → Paired devices.

In the list of paired external devices, the following Bluetooth

®

 profile symbols

are displayed when the phone is connected

» Fig. 118

 - .

Symbol

Operation

white

External device can be connected as a telephone

In colour External device is connected as a telephone

white

External device can be connected as a Bluetooth

®

player

In colour External device is connected as a Bluetooth

®

 player

Establishing connections

See list of paired external devices.

With the controller  select the external device

» Fig. 118

 - .

The external device is connected to the device as a phone, and as a Blue-

tooth

®

Player at the same time (if the connected external device enables this).

If another external device is connected to the device when establishing con-

nection, then the external device will be replaced by the new device to be con-

nected.

Delete the coupled external device

Show list of paired external devices.

Press the function key 

» Fig. 118

 - .

Use the controller  select the external device

» Fig. 118

 - .

Confirm the deletion by pressing the function button Delete.

All connected external devices are erased by selecting the menu item Delete all

and confirming.

Application operationŠKODA Move & Fun

Introductory information

Applies to Swing.

Using the ŠKODA Move & Fun application it is possible e.g. to navigate, to dis-

play vehicle information, to control media playback.
Using the device, it is possible to control the menu display to the ŠKODA Move

& Fun application in the connected external device.
After entering the following address into the web browser, the website is

opened with information on the ŠKODA mobile applications.
http://go.skoda.eu/service-app
The application ŠKODA Move & Fun is available for download in the Apple

Store For iOS and in Google Play For Android.

Connection

Connect the external device with the device in thephone menu

» page 82

.

Release data transfer to external applications in the device

» page 72

.

 Start the ŠKODA Move & Funapplication in the external device.

Confirm the on-screen registration code in the device and the external de-

vice.

Once connected, the main menu appears

» Fig. 119

 on page 87.

Note

Confirmation of the registration code may not be necessary during the next

connection.

86

Infotainment

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Main menu

Fig. 119

Main menu

To display, press the



 button 

» page 71

 .

Function buttons

Navigation
Drive Green (Driving economy)
Vehicle information
Virtual instrument cluster
Search within the ŠKODA Move & Funapplication (e.g. Contacts, naviga-

tion destinations)
Close the App operationmain menu

87

Radio Swing / Blues

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Driving

Starting-off and Driving

Starting and stopping the engine

Introduction

It is possible, with the key in the ignition, to switch the ignition off and on and

start/stop the engine.

WARNING

Never switch off the engine before the vehicle is stationary – risk of acci-

dent!

While driving with the engine stopped the ignition must always be

switched on. Otherwise, the steering may lock - danger of an accident!

Do not withdraw the ignition key from the ignition lock until the vehicle

has come to a stop

» page 92

Parking. Otherwise, the steering may lock -

danger of an accident!

Never leave the vehicle unattended with the engine running - risk of acci-

dent, theft or similar.

Never (e.g. in garages) run the engine in a closed place - there is the dan-

ger of poisoning and death!

CAUTION

Only start the engine when the engine and the vehicle are stationary - there

is a danger of starter and engine damage!

Do not push-start the engine – risk of damaging the engine and the catalytic

converter. The battery from another vehicle can be used as a jump-start aid.

Note

Do not warm up the engine while the vehicle is stationary. If possible, start

your journey as soon as the engine has started. Through this, the engine rea-

ches its operating temperature faster.

Electronic immobiliser and steering lock

Read and observe   and   on page 88 first.

The electronic immobiliser (hereinafter referred to as immobiliser) makes the

theft or unauthorised use of your vehicle more difficult.

Immobiliser

The immobilizer allows the engine to be started only with the original car key.

Malfunction of the immobiliser

If the immobiliser in the key fails, it is not possible to start the engine.
Use the other vehicle key to start the engine; if necessary, seek help from a

specialist garage.

Steering lock - lock

Remove the key and turn the steering wheel until the steering lock engages.

Steering lock - unlock

Insert the key into the ignition and turn on the ignition. If this is not possible,

then move the steering wheel slightly back and forth, as a result of which the

steering lock should unlock.

WARNING

Never let the vehicle roll with locked steering lock - danger of accident!

88

Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------

Ignition on / off

Fig. 120

Positions of the vehicle key in the ignition lock

Read and observe   and   on page 88 first.

Positions of the vehicle key in the ignition lock

» Fig. 120

Ignition switched off, engine switched off
Ignition switched on
Starting engine

Starting / Stopping the engine

Read and observe   and   on page 88 first.

Before starting the engine

Firmly apply the handbrake.

For vehicles with manual transmission, shift gear stick to neutral, depress

the clutch pedal and hold it there until the engine starts.

On vehicles with automatic gearbox, place the selector lever in position N

and depress the brake pedal until the engine starts.

Starting the engine

Turn the key to position

3



» Fig. 120

 on page 89, the start-up process will

begin. Then release the key, the engine will start automatically.

If the engine does not start within 10 seconds, turn the key to position

1

. Re-

peat the start-up process after 30 s.

Switching the engine off

Stop the vehicle.

Turn key to position

1



» Fig. 120

 on page 89.

1

2
3

Do not switch the engine off immediately at the end of your journey if the en-

gine has been working at high revs over a prolonged period, but leave it to run

at an idling speed for about 1 minute. This prevents any possible accumulation

of heat when the engine is switched off.

Note

After switching off the ignition, the radiator fan may (also intermittently) con-

tinue to operate for approx. 10 minutes.

START-STOP system

Introduction

The START-STOP system (hereinafter referred to as: the system) reduces

CO

2

emissions and harmful emissions, and saves fuel.

If the system determine that the engine is not needed when the vehicle stops

(e.g. at the traffic lights), it turns off the engine and starts it again when mov-

ing off.
The system function depends on many factors. Some of them are down to the

driver, the others are systemic and can neither be influenced nor identified.
Therefore the system may react differently in situations which seem identi-

cal from the driver's perspective.
The system is automatically activated every time the ignition is switched on

(even where this has previously been manually deactivated with the button

).

Note

If the engine has stopped due to the system, the ignition remains on.

89

Starting-off and Driving

-------------------------------------------------------------------------------------------------------------------------------------------------------------















Content      ..     3      4      5      6     ..
