Renault Megane (2023 year). Manual in english

DRIVING ADVICE, ECO-DRIVING (7/8)

- High speeds significantly affect the

- Do not try to maintain the same

vehicle’s fuel consumption.

speed up a hill, accelerate no more

than you would on flat ground. Keep

Examples (at a steady speed):

your foot in the same position on the

- reducing the speed from 80 mph

accelerator pedal.

(130 km/h) to 68 mph (110 km/h)

- Double declutching and accelerating

approximately saves up to 20% of

before switching off are unnecessary

fuel approximately;

in modern vehicles.

- reducing the speed from 56 mph

- Bad weather, flooded roads:

(90 km/h) to 50 mph (80 km/h) ap-

proximately saves up to 10% of

fuel approximately.

- Dynamic driving with a lot of frequent

acceleration and braking is expen-

Do not drive through

sive on fuel in comparison to the time

floods if the water is

saved.

above the lower edge of

Driving advice and ECO

the wheel rims.

- Do not over rev the engine in the in-

driving

termediate gears. You should always

Behaviour

use the highest gear possible.

- Drive carefully for the first few miles

- Avoid sudden acceleration.

until the engine reaches its normal

- Brake as little as possible. If you an-

Obstructions to the driver

operating temperature, rather than

ticipate an obstacle or bend in ad-

let it warm up while the vehicle is sta-

On the driver’s side, only

vance, you may then simply release

tionary.

use mats suitable for the

the accelerator pedal.

vehicle, attached with the

pre-fitted components, and check

the fitting regularly. Do not lay one

mat on top of another.

There is a risk of wedging the

pedals.

2.28

CarManuals2.co

DRIVING ADVICE, ECO-DRIVING (8/8)

- In vehicles fitted with air condi-

tioning, it is normal to observe an

increase in fuel consumption (espe-

cially in urban conditions) when it is

used. For vehicles fitted with manual

air conditioning, switch off the system

when it is not required.

Recommendations for reducing

consumption and therefore help-

ing to preserve the environment:

If the vehicle has been parked in the

sun, open the doors for a few mo-

ments to let the hot air escape before

starting the engine.

- Do not leave an empty roof rack

Tyres

Advice on use

fitted to the vehicle.

– An underinflated tyre increases fuel

- Opt for ECO mode.

- It is better to fit a trailer for bulky ob-

consumption.

jects.

- Electricity consumes fuel - switch off

- To optimise fuel consumption, set the

all electrical components when they

- When towing a caravan, fit a wind

highest speed tyre pressure or the

are not genuinely needed in order

deflector and adjust it carefully.

recommended pressure indicated on

to save fuel. However (safety first),

- Avoid using the vehicle for door-to-

the edge of the driver’s door ➥ 4.13.

keep your lights on when the visibility

door calls (short journeys with long

is bad (“see and be seen”).

waits in between) because in such

– The use of non-recommended tyres

can increase fuel consumption.

- Use the air vents. Driving with the

conditions the engine never reaches

windows open at 60 mph (100 km/h)

its optimal operating temperature.

will increase fuel consumption by

4%.

- Never fill the fuel tank right to the

brim to avoid overflow.

2.29

CarManuals2.co

MAINTENANCE AND ANTIPOLLUTION ADVICE

Your vehicle complies with criteria for

In addition, replacing engine, fuel

- Air filter, fuel filter: a choked ele-

recycling and recovering vehicles at the

supply system and exhaust compo-

ment will reduce efficiency. It must

end of their service life, which entered

nents with parts other than those origi-

be replaced.

into force in 2015.

nally recommended by the manufac-

turer may alter your vehicle so that it

Some parts of your vehicle have there-

Exhaust gas monitoring

no longer complies with anti-pollution

fore been designed to facilitate future

regulations.

system

recycling.

Have your vehicle adjusted and

The exhaust gas monitoring system will

These parts are easy to remove so

checked by an authorised dealer, in ac-

detect any operating faults in the vehi-

that they can be recovered and repro-

cordance with the instructions given in

cle’s antipollution system.

cessed by recycling companies.

your maintenance schedule: they will

If this system malfunctions, toxic sub-

By virtue of its design, moderate fuel

have all the equipment necessary for

stances may be released into the at-

consumption and initial settings, your

ensuring that your vehicle is maintained

mosphere or damage may occur.

vehicle also conforms to current an-

to its original standard.

This warning light on the in-

tipollution regulations. The manufac-

strument panel will indicate if

turer is actively striving to reduce pol-

there are any faults in the system:

lutant exhaust gas emissions and to

Engine adjustments

This lights up when the ignition is

save energy. But the fuel consumption

- Spark plugs: for optimum condi-

switched on and goes out when the

of your vehicle and the level of pollutant

tions of use, output and performance

engine is started.

exhaust gas emissions are also your

the specifications laid down by our

- If it lights up continuously, consult an

responsibility. Ensure that it is main-

Design Department must be strictly

approved Dealer as soon as possi-

tained and used correctly.

applied.

ble;

If the spark plugs have to be changed,

- if it flashes, reduce the engine speed

use the make, type and gap specified

until the light stops flashing. Contact

Maintenance

for your vehicle’s engine. Contact an

an authorised dealer as soon as pos-

It is important to remember that fail-

authorised dealer for this.

sible.

ure to respect antipollution regulations

- Ignition and idle speed: no adjust-

could lead to legal action being taken

ment is needed.

 ^{➥ 1.119}

against the vehicle owner.

2.30

CarManuals2.co

ENVIRONMENT

Your vehicle has been designed with

Emissions

- At the end of the vehicle’s service

respect for the environment in mind for

life, it should be sent to approved

Your vehicle has been designed to

its entire service life: during production,

centres to ensure that it is recycled.

emit fewer greenhouse gases (CO2)

use and at the end of its life.

while in use, and therefore to consume

- In all cases, comply with local legis-

less fuel (e.g. 140 g/km, equivalent to

lation.

Manufacture

1494.6 mpg (5.3 l/100 km) for a diesel

vehicle).

Your vehicle has been manufactured at

Recycling

a factory which complies with a policy

Our vehicles are also equipped with a

Your vehicle is 85% recyclable and

to reduce the environmental impact

particle filter system including a cata-

95% recoverable.

on the surrounding areas (reduction of

lytic converter, an oxygen sensor and

water and energy consumption, visual

an active carbon filter (the latter pre-

To achieve these objectives, many of

and noise pollution, atmospheric emis-

vents vapour from the fuel tank being

the vehicle components have been de-

sions and waste water; sorting and re-

released into the open air).

signed to enable them to be recycled.

using waste).

The materials and structures have

On certain diesel vehicles, this system

been carefully designed to allow these

also includes a particle filter to reduce

components to be easily removed and

the volume of soot particles emitted.

reprocessed by specialist companies.

In order to preserve raw material re-

Please make your own

sources, this vehicle incorporates nu-

contribution towards

merous parts made from recycled plas-

protecting the environment

tics or renewable materials (vegetable

or animal-derived materials such as

too

cotton or wool).

- Worn parts replaced in the course of

routine vehicle maintenance (vehi-

cle battery, oil filter, air filter, batter-

ies, etc.) and oil containers (empty or

filled with used oil) must be disposed

of through specialist organisations.

2.31

CarManuals2.co

TYRE PRESSURE LOSS WARNING (2/6)

Operating conditions

significant change in load or distribu-

Resetting the standard level

tion of load on one side of the vehi-

The system should be reset with a

for the tyre pressures

cle;

pressure equal to that stated on the tyre

This should be done:

sporty driving with strong accelera-

pressure label (refer to the information

tion;

- after each re-inflation or resetting of

on “Tyre Pressures” in section 4), other-

driving on snowy or slippery surface;

tyre pressure;

wise it may not give a reliable warning

–

driving with snow chains;

in the event of significant pressure loss.

- after changing a wheel;

–

fitting a single new tyre;

Resetting should always be carried

use of tyres not approved by the net-

- after changing wheels around.

out after checking the tyre pressure

work.

Tyre pressures must correspond to the

of all four tyres when cold.

current usage of the vehicle (empty,

In the following situations, the system

carrying a load, motorway driving, etc.).

risk coming into action late or not func-

tioning correctly:

- system not reset after reinflation or

any operation on the wheels;

- system badly reset: different inflation

pressures from the recommended

pressures;

This function is an addi-

tional driving aid.

The function does not take

the place of the driver. It

cannot, therefore, under any cir-

cumstances replace the vigilance

or the responsibility of the driver.

Check the tyre pressures, including

the emergency spare wheel, once a

The sudden loss of pressure in a

month.

tyre (burst tyre, etc.) cannot be de-

tected by the system.

2.33

CarManuals2.co

TYRE PRESSURE LOSS WARNING (3/6)

Hold down the

5 switch until the

“Operation completed” message ap-

pears. You can now drive.

Resetting procedure

Ignition on, vehicle stopped:

- repeatedly tap the 6 switch as many

times as necessary to reach the “ve-

hicle” tab

;

- briefly press the 3 or 4 switch to

reach the “Tyre pressure init. long

press” page;

- press and hold the 5 OK switch to

launch the reset.

If the vehicle is equipped with a nav-

igation system, the resetting proce-

dure may also be carried out using

the multimedia screen: please see

the equipment instructions.

2.34

CarManuals2.co

TYRE PRESSURE LOSS WARNING (4/6)

The table below shows the possible messages related to the tyre resetting procedure.

Steps

Messages

Readings

–

Tyre pressure init. at stop

The message is displayed during driving. If you want to reset the pressure of the

four tyres, stop the vehicle.

Tyre pressure init. long press

To reset the pressure of the four tyres, with the vehicle stopped, press and hold

the 5 OK switch to launch resetting until the “If pressure OK [hold on]” message

is displayed.

If pressure OK [hold on]

The message flashes to indicate that the system has registered the resetting

procedure. If all four tyres have been correctly adjusted to match the tyre pres-

sure values recommended on the tyre pressure label ➥ 4.13, press and hold

switch 5 OK until the message “Operation completed” appears.

Operation completed

The resetting procedure has been completed successfully. You can now drive.

2.35

CarManuals2.co

TYRE PRESSURE LOSS WARNING (5/6)

Readjustment of tyre

After each change of wheel/tyre, read-

just the tyre pressure and launch the

pressures

reset of the tyre pressure reference

The pressure of the four tyres must

value.

be set when cold (refer to the label lo-

cated on the edge of the driver’s door).

Emergency spare wheel

If tyre pressures cannot be checked

when the tyres are cold, the recom-

If fitted on the vehicle, readjust the tyre

mended pressures should be increased

pressure and launch the reinitialisation

by 0.2 to 0.3 bar (3 PSI).

of the tyre pressure reference value.

Never deflate a hot tyre.

After each reinflation or readjustment of

Tyre repair product and

the tyre pressure, launch the reinitiali-

inflation kit

sation of the tyre pressure reference

value.

Only use equipment approved by the

brand network, or the system risks

being activated late or not operating

Tyre pressure faults

Replacing wheels/tyres

correctly. ➥ 5.5. After using the tyre

The table on the following page lists

Only use equipment approved by the

inflation kit, readjust the tyre pressure

the warning messages which appear

network, otherwise the system risks

and launch the resetting of the tyre

on the instrument panel 7 when the

late activation or incorrect operation.

pressure reference value.

system detects a tyre pressure fault.

➥ 5.13.

2.36

CarManuals2.co

TYRE PRESSURE LOSS WARNING (6/6)

The information on the instrument panel signals any potential tyre pressure faults (e.g. deflated or punctured tyre).

Indicator

Messages

Readings

lights

This indicates that tyre under-inflation or puncture has been detected.

Inflate tyres and init.

Check and adjust the pressure of the four tyres when cold and reset the



system.

This indicates that the reset has been unsuccessful. Check and readjust

Check tyre press and init.



the tyre pressure before re-launching the resetting procedure.

This indicates that the last system reset was carried out over 6 months

Check tyre press and init.

ago or over approximately 6,214 miles (10,000 km). Check and readjust

the tyre pressure before re-launching another resetting procedure.

Check TPW

This indicates a fault in the system. Consult an approved dealer.



This indicates that an emergency spare wheel different in size to the other

four wheels has been fitted to the vehicle. The system remains unavail-

TPW not available



able until a wheel identical in size to the other wheels has been fitted and

the resetting procedure has been carried out.

2.37

CarManuals2.co

TYRE PRESSURE MONITOR (1/5)

Resetting the standard level

for the tyre pressures

This should be done:

- when the standard tyre pressure

needs to be changed to adapt to

usage conditions (empty, carrying a

load, motorway driving, etc.);

- after swapping a wheel (however

this practice is not recommended);

- after changing a wheel.

It should always be done after checking

the tyre pressure of all four tyres when

cold.

Tyre pressures must correspond to the

current usage of the vehicle (empty,

If the vehicle is equipped with the func-

carrying a load, motorway driving, etc.).

tion, this system monitors the tyre pres-

sure.

Operating principle

Each wheel (except for the emergency

spare wheel) has a sensor in the infla-

tion valve which periodically measures

the tyre pressure.

The system displays the current pres-

sures on the instrument panel 1 and

alerts the driver in the event of insuffi-

If the vehicle is equipped with a nav-

cient pressure.

igation system, the resetting proce-

dure may also be carried out using

the multimedia screen: please see

the equipment instructions.

2.38

CarManuals2.co

TYRE PRESSURE MONITOR (2/5)

- press and hold (around 3 seconds)

the button 4 to launch the reset. The

flashing tyres followed by the mes-

sages “Learning Tyre Pressures”

and then “Tyres location in progress”

indicates that the reset request for

the tyre pressure reference value

has been acknowledged.

Reset can take several minutes of driv-

ing.

If the resetting is followed by short

trips, the message “Tyres location in

progress” can remain displayed after

successive restarts.

Note: the standard tyre pressure

Resetting procedure

cannot be less than that recommended

Ignition on, vehicle stopped:

and indicated on the door frame.

- repeatedly tap the 5 switch as many

times as necessary to reach the “ve-

hicle” tab 

;

- briefly press the 2 or 3 switch to

reach the “Tyre Pressure” page;

For your safety, the warning

light

requires you

to stop immediately as soon

as traffic conditions allow.

2.39

CarManuals2.co

TYRE PRESSURE MONITOR (3/5)

The table below shows the possible messages related to the tyre resetting procedure.

Steps

Displays

Messages

Readings

(depending on

the vehicle)

Tyre pressure init. long press

With the ignition on and the vehicle stationary, start the

resetting the pressure of all four tyres by pressing and

holding the 4 OK switch.

Learning Tyre Pressures

The “---” quote marks in front of each wheel will flash to

indicate that the system has registered the tyre pressure

reset for all four wheels.

Tyres location in progress

The “---” quote marks in front of each wheel will remain

lit. This system resets the tyre pressure of all four tyres.

You can now drive. The message may remain displayed

during short journeys.

Note: during the reset, tyre pressure monitoring remains

in operation.

The pressure value of the four tyres is displayed: the re-

setting procedure is complete and successful.

2.40

CarManuals2.co

TYRE PRESSURE MONITOR (4/5)

Readjustment of tyre

Replacing wheels/tyres

pressures

This system requires specific equip-

The pressure of the four tyres must

ment (wheels, tyres, hubcaps, etc.).

be set when cold (refer to the label lo-

➥ 5.13.

cated on the edge of the driver’s door).

Contact an approved Dealer to fit new

If the tyre pressures cannot be checked

tyres and to find out about available ac-

when the tyres are cold, the recom-

cessories compatible with the system

mended pressures should be increased

and available from your dealer net-

by 0.2 to 0.3 bar (3 PSI).

work: the use of any other accessory

Never deflate a hot tyre.

could affect the correct operation of the

system or damage a sensor.

Emergency spare wheel

If the vehicle is equipped with an emer-

gency spare wheel, it will not have a

sensor.

Tyre repair product and

inflation kit

Because the valves are specially de-

signed, only use equipment approved

by the approved network. Please see

the section on ➥ 5.5.

This function is an addi-

tional driving aid.

The function does not take

Tyre pressure faults

the place of the driver. It

Changing a wheel

The table on the following page lists

cannot, therefore, under any cir-

The system may take sev-

the warning messages which appear

cumstances replace the vigilance

eral minutes depending on

on the instrument panel 1 when the

or the responsibility of the driver.

use for the new wheel po-

system detects a tyre pressure fault.

Check the tyre pressures, including

sitions and pressures to be recog-

the emergency spare wheel, once a

nised; check the tyre pressures after

month.

all operations.

2.41

CarManuals2.co

TYRE PRESSURE MONITOR (5/5)

The information on the instrument panel signals any potential tyre pressure faults (e.g. deflated or punctured tyre). For

your safety, the warning light® requires you to stop immediately as soon as traffic conditions allow.

Indicator

Messages

Displays

Readings

lights

(depending on

the vehicle)

The wheel and associated pressure value are dis-

played in yellow.

Adjust Tyre Pressure

This indicates that tyre under-inflation has been de-



tected. Check and adjust the pressure of the four

tyres then reset the system.

The wheel and associated pressure value are dis-

played in red.

This indicates that the tyre concerned is punctured

Puncture

or severely underinflated. Adjust the pressure of the



four tyres while cold and reset the system if the tyre

is deflated. Replace the tyre (or have it replaced) if

it is punctured.

A wheel is no longer displayed.

This indicates that at least one wheel is not fitted with

Check Tyre Pressure Sensors



a sensor (e.g. emergency spare wheel) or that the

sensor is faulty. Consult an approved dealer.

This indicates that the system has not been able to

determine the pressure of each tyre. This may be

Tyre Detection Failure

caused by the use of a sensor not recommended by



an approved dealer. The tyre pressure sensor moni-

toring system remains in operation.

2.42

CarManuals2.co

DRIVER CORRECTION DEVICES AND AIDS (1/6)

Depending on the vehicle, this is com-

ABS (anti-lock braking

posed of:

system)

– ABS (anti-lock braking system);

Under heavy braking, the ABS prevents

- ESC (electronic stability control)

the wheels from locking, allowing the

with understeer control and trac-

stopping distance to be managed and

In an emergency, apply firm and

tion control;

keeping control of the vehicle.

continuous pressure to the brake

pedal. There is no need to pump

- emergency brake assist;

Under these circumstances, the vehi-

it repeatedly. The ABS will modu-

cle can be steered to avoid an obstacle

- hill start assistance;

late the force applied in the braking

whilst braking. In addition, this system

system.

- rear wheel steering.

can increase stopping distances, par-

ticularly on roads with low surface grip

Other driving assistance systems are

(wet ground etc.).

detailed on the following pages.

You will feel a pulsation through the

These functions are an ad-

brake pedal each time the system is

ditional aid in the event of

activated. The ABS does not in any way

critical driving conditions,

improve the vehicle's physical perfor-

enabling the vehicle behav-

mance relating to the road surface and

iour to be adapted to suit the driving

roadholding. It is still essential to follow

conditions.

the rules of good driving practice (such

These functions do not take the

as driving at a safe distance from the

place of the driver. They do not

vehicle in front etc.).

increase the vehicle’s limits and

should not encourage you to

drive more quickly. Therefore,

they can under no circumstances

replace the vigilance or responsibil-

ity of the driver when manoeuvring

the vehicle (the driver must always

be ready for sudden incidents which

may occur when driving).

2.43

CarManuals2.co

DRIVER CORRECTION DEVICES AND AIDS (2/6)

Operating faults:

and x

lit up on the in-

strument panel accompanied by the

messages “Check ABS”, “Check

braking system” and “Check ESC”:

this indicates that the ABS, the ESC

and the emergency brake assist are

disabled. Braking is always ena-

bled;

- x

, D

and

lit on the instrument panel accom-

panied by the message “Braking

Warning light

re-

system fault”: this indicates a fault

quires you to stop immedi-

with the braking system.

ately, for your own safety,

In both cases, consult an approved

as soon as traffic conditions

dealer.

allow. Switch off the engine and do

not restart it. Contact an approved

Dealer.

Your braking systems

are partially operational.

However, it is dangerous

to brake suddenly and

it is essential to stop immediately,

as soon as traffic conditions allow.

Contact an approved dealer.

2.44

CarManuals2.co

DRIVER CORRECTION DEVICES AND AIDS (3/6)

Electronic stability control

Understeer control

In some situations (driving on very wet

ground: snow, mud, etc. or driving with

ESC with understeer control

This system optimises the action of the

snow chains fitted), the system may

and traction control

ESC in the case of pronounced under-

reduce the engine output to limit wheel-

steer (loss of front axle road holding).

spin.

Electronic stability control ESC

Traction control

This system helps you to keep control

Operating faults

of the vehicle in critical driving condi-

This system helps to limit wheelspin of

When the system detects an operating

tions (avoiding an obstacle, loss of grip

the drive wheels and to control the ve-

fault the message “Check ESC” and

on a bend, etc.).

hicle when pulling away accelerating or

decelerating.

appear

Operating principle

on the instrument panel.

A sensor in the steering wheel detects

Using the wheel sensors, the system

In this case, the ESC and traction con-

the direction selected by the driver.

measures and compares the speed of

trol system are deactivated. Consult an

Other sensors throughout the vehicle

the drive wheels at all times and slows

authorised dealer.

measure the actual direction.

down their over-rotation. If a wheel is

starting to slip, the system brakes au-

The system compares driver input to

tomatically until the drive supplied be-

the actual trajectory of the vehicle and

comes compatible with the level of grip

corrects the trajectory if necessary by

under the wheel again.

controlling the braking of certain wheels

and/or engine power. In the event that

The system also adjusts the engine

the system is engaged, indicator light

speed to the grip available under the

wheels, independently of the pressure



flashes on the instrument panel.

exerted on the accelerator pedal.

2.45

CarManuals2.co

DRIVER CORRECTION DEVICES AND AIDS (4/6)

Emergency brake assist

Braking anticipation

This system supplements the ABS

Depending on the vehicle, when you

and helps reduce vehicle stopping dis-

rapidly release the accelerator, the

tances.

system anticipates the braking ma-

noeuvre in order to reduce stopping

Operating principle

distances.

The system is for detecting an emer-

Special cases

gency braking situation. In this case,

When using the cruise control:

the braking assistance immediately de-

velops maximum power and may trig-

- if you use the accelerator, when you

ger ABS regulation.

release it, the system may be trig-

gered;

ABS braking is maintained as long as

the brake pedal is applied.

- if you do not use the accelerator, the

These functions are an ad-

system will not be triggered.

ditional aid in the event of

Brake lights come on

Operating faults

critical driving conditions,

Depending on the vehicle, these may

enabling the vehicle behav-

flash in the event of sudden decelera-

When the system detects an operat-

iour to be adapted to suit the driving

tion.

ing fault the message “Check braking

conditions.

system” appears on the instrument

These functions do not take the

panel along with the

warning

place of the driver. They do not

light.

increase the vehicle’s limits and

Consult an approved dealer.

should not encourage you to

drive more quickly. Therefore,

they can under no circumstances

replace the vigilance or responsibil-

ity of the driver when manoeuvring

the vehicle (the driver must always

be ready for sudden incidents which

may occur when driving).

2.46

CarManuals2.co

DRIVER CORRECTION DEVICES AND AIDS (5/6)

Hill start assistance

Depending on the gradient of the in-

cline, this system assists the driver

when starting on a hill. It prevents the

vehicle from rolling backwards by au-

The hill start assistance

tomatically applying the brakes when

system cannot completely

the driver lifts his/her foot off the brake

prevent the vehicle from

pedal to depress the accelerator pedal.

rolling backwards in all sit-

System operation

uations (extremely steep gradients,

etc.).

It only operates when the gear lever is

in a position other than neutral (other

In all cases, the driver may depress

than N or P for automatic transmis-

the brake pedal to prevent the vehi-

sions) and the vehicle is completely

cle from rolling backwards.

stationary (brake pedal depressed)

The hill start assistance function

The system holds the vehicle for ap-

should not be used for prolonged

proximately 2 seconds. The brakes are

stops: use the brake pedal.

then released (the vehicle will move ac-

This function is not designed to im-

cording to the slope).

mobilise the vehicle permanently.

If necessary, use the brake pedal to

stop the vehicle.

The driver must remain particularly

vigilant when driving on slippery or

low-grip surfaces.

Risk of serious injury.

2.47

CarManuals2.co

DRIVER CORRECTION DEVICES AND AIDS (6/6)

Operating faults

- If the

warning light, together

with the message “Check power

steering”, is displayed on the instru-

ment panel: please contact an au-

thorised dealer.

- If the warning light

, together

with the message

“WARNING:

Steering Fault”, is displayed on the

instrument panel, this indicates a

fault in the system.

requires you to stop

Rear wheel steering

When driving at higher speeds, the rear

as soon as traffic conditions

wheels steer in the same direction as

allow. Contact an approved

On equipped vehicles, this system,

the front wheels (figure B) to optimise

Dealer.

when the vehicle is being driven, steers

the vehicle’s stability. This is useful

the rear wheels according to driving

An impact to the underside of the

when changing lanes or when corner-

conditions: at low speed this system

vehicle (e.g.: striking a post, raised

ing etc.

offers manoeuvrability, at higher speeds

kerb or other street furniture) may

it optimises stability.

Note: the system configuration (re-

result in damage to the vehicle (e.g.:

sponsiveness etc.) depends on the

When driving at low speeds, the rear

deformation of an axle).

mode selected in the “MULTI-SENSE”

wheels steer in the opposite direction to

To avoid any risk of accident, have

menu ➥ 3.2.

the front wheels (figure A) to increase

your vehicle checked by an ap-

the vehicle’s manoeuvrability. This is

proved Dealer.

used when driving in towns, on winding

roads, during parking manoeuvres, etc.

2.48

CarManuals2.co

LANE DEPARTURE WARNING (1/5)

Using information from the 1 camera,

the function warns the driver when a

continuous or broken line is crossed

or when approaching the roadside (di-

vider, barrier, pavement, embankment,

etc.) without the direction indicator

lights being activated.

This function is an addi-

Note: make sure the windscreen is not

tional driving aid. This func-

obscured (dirt, mud, snow, condensa-

tion is not under any cir-

tion etc.).

cumstances intended to

replace the due care and attention

of the driver, who should at all times

be in control of the vehicle.

The lane departure warning func-

tion does not correct the vehi-

cle’s trajectory.

2.49

CarManuals2.co

LANE DEPARTURE WARNING (2/5)

To disable the function, press the 2

switch as many times as required to

select

“Lane departure warning off”

(or, depending on the vehicle “Lane

Keeping deactivated”) on the instru-

ment panel. Warning light 

goes

out on the instrument panel.

Operation

When the function is activated, the



warning light and the left and

right lines 3 are displayed in grey on the

instrument panel.

The function is set to notify the

Activation/deactivation

The function alerts the driver:

driver if:

- by a vibration in the steering wheel;

To activate the function, press the 2

- speed is between approximately

and

switch as many times as required to

43 mph (70 km/h) and 112 mph

select “Lane Departure Warning” on

(180 km/h);

- the 

warning light and 3 the in-

the instrument panel. The “Lane depar-

and

dicator for the crossed line turn red.

ture warning on” message and “”

- the 

warning light and left/right

warning light are displayed on the in-

line indicators 3 are coloured white.

strument panel.

The warning function is triggered

if the vehicle breaches a line or ap-

proaches a roadside (divider, barrier,

pavement, embankment, etc.) without

the direction indicator lights being ac-

tivated.

Each time the vehicle is started,

the function continues the mode

saved the last time the engine was

stopped.

2.50

CarManuals2.co

LANE DEPARTURE WARNING (3/5)

Temporarily not available

Conditions for non-activation

- Very fast lane departure;

of the system

- driving continuously on a line;

The system cannot be activated when:

- four seconds approximately after

- reverse gear is engaged;

changing lanes;

- the field of vision of the camera is ob-

- tight bends;

structed;

- impaired visibility;

- the® warning light is displayed.

- activation of one of the direction indi-

The 

warning light and the left/

cator lights;

right line indicators turn to grey on the

- strong acceleration;

instrument panel.

– ...

When the function is not available, the

Settings

- “Alert”: adjust the line detection sen-



warning light and the left/right in-

Vehicles fitted with a multimedia

sitivity level. To do this, select:

dicators turn to grey on the instrument

screen.

panel.

- “Late”: line detected when cross-

To access the multimedia screen func-

ing;

tion settings 4, refer to the multimedia

instructions:

- “Standard”: line detected on ap-

proach;

- “Vibration”: adjust the steering wheel

vibration level;

- “Early”: line detected nearby.

2.51

CarManuals2.co

LANE DEPARTURE WARNING (4/5)

- press the 6 or 7 control repeatedly to

Operating faults

reach the “DRIVING ASSIST” menu.

In the event of a malfunction, the left

Press the switch 8 OK;

and right line indicators (and, depend-

- press the 6 or 7 control repeatedly to

reach the “Lane Departure Vibration”

ing on display style, the 

warning

“Lane Departure Sensitivity”

light) disappear or stay grey on the in-

menu. Press the switch 8 OK;

strument panel.

- press the 6 or 7 control repeatedly to

In some cases, they are accompa-

adjust the setting. Press 8 OK.

nied by the message “Front camera to

check” or the

warning light on

the instrument panel.

Consult an approved dealer.

Adjustments (continued)

Vehicles not fitted with a multimedia

screen

- With the vehicle stopped, press the

switch 5 as many times as required

to reach the “Vehicle” tab;

- press the 6 or 7 control repeatedly to

reach the “Settings” menu. Press the

switch 8 OK;

2.52

CarManuals2.co

LANE DEPARTURE WARNING (5/5)

This function is an additional driving aid. This function is not under any circumstances intended to replace the due care

and attention of the driver, who should at all times be in control of the vehicle.

System servicing/repairs

- In the event of an impact, the camera alignment may be changed, and its operation may consequently be affected. Deactivate

the function, then consult an authorised dealer.

- Any work in the area where the camera is located (repairs, replacements, windscreen modifications etc.) must be carried

out by a qualified professional.

Only an authorised dealer is qualified to service the system.

In the event of system disturbance

Some conditions can disrupt or damage the operation of the system, for example:

- windscreen obscured (by dirt, ice, snow, condensation etc.);

- a complex environment (tunnel etc.);

- poor weather conditions (snow, hail, black ice etc.);

- poor visibility (night, fog etc.);

- the road markings are irregular or difficult to distinguish (e.g. partially erased, excessive spacing, distorted road surface) ;

- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);

- the road is narrow, winding or undulating (tight bends etc.);

- closely following a vehicle travelling in the same lane.

Risk of false alarms or absence of warnings

2.53

CarManuals2.co

LANE KEEPING ASSIST (1/6)

Note: make sure the windscreen is not

obscured (dirt, mud, snow, condensa-

tion etc.).

Using information from the 1 camera,

the function triggers corrective action

on the vehicle steering system when

a continuous or broken line is crossed

or when approaching the roadside (di-

vider, barrier, pavement, embankment,

etc.) without the direction indicator

lights being activated.

This function is an addi-

tional driving aid. This func-

tion is not under any circum-

stances intended to replace

the due care and attention of the

driver, who should at all times be

in control of the vehicle.

You can retake control of the ve-

hicle at any time by operating the

steering wheel.

2.54

CarManuals2.co

LANE KEEPING ASSIST (2/6)

To disable the function, press the 2

switch as many times as required to

select “Lane Keeping deactivated” on

the instrument panel.

Warning light



goes out on the in-

strument panel.

Note: deactivating the “Lane Keeping

Assist” function causes deactivation of

the “Lane Departure Warning” function.

Activation/deactivation

To activate the function, press the 2

switch as many times as required to

select “Lane Keeping Assist” on the in-

strument panel.

The “Lane Keeping activated” message

and “

” warning light are displayed

on the instrument panel.

When Lane Keeping Assist is activated,

the “Lane Departure Warning” function

is automatically activated. ➥ 2.49.

Each time the vehicle is started,

the function continues the mode

saved the last time the engine was

stopped.

2.55

CarManuals2.co

LANE KEEPING ASSIST (3/6)

In these cases:

Special cases

- the function triggers an action on the

When using the function:

vehicle’s steering system to correct

If the system can no longer detect

the vehicle trajectory;

any action by the driver on the steer-

- the warning light 

and the indi-

ing wheel, the 

warning light

cator 3 on the side of the breached

appears in yellow on the instrument

line turns to yellow on the instrument

panel, accompanied by the message

panel.

“Keep hands on steering wheel” and

an audible warning.

Note: on bends, the function allows for

slightly cutting the bend.

The audible warning is emitted along

with the warning light and message

If the corrective action on the steer-

until the driver takes control;

ing system is not sufficient, the 

if the system is active for too long,

warning light and 3 indicator on the side

an audible warning is emitted along

Operation

of the breached line turn to red on the

with flashing of the side indicators 3

When the function is activated, the

instrument panel, accompanied by a vi-

on the side of the vehicle concerned

bration on the steering wheel.

until the driver takes control.



warning light and the left and

right lines 3 are displayed in grey on the

instrument panel.

The function is set to operate when

the vehicle speed is between approxi-

mately 43 mph (70 km/h) and 112 mph

(180 km/h) and if the 

warning

light and 3 correction indicators are col-

oured white.

The function operates if the vehicle

breaches a line or if the vehicle ap-

proaches the roadside (divider, barrier,

You can interrupt the trajectory cor-

pavement, embankment, etc.) without

rection at any time by moving the

the direction indicator lights being ac-

steering wheel.

tivated.

2.56

CarManuals2.co

LANE KEEPING ASSIST (4/6)

Temporarily not available

Conditions for non-activation

of the system

- Very fast lane departure;

- driving continuously on a line;

The system cannot be activated when:

– four seconds approximately after

- reverse gear is engaged;

changing lanes;

- the field of vision of the camera is ob-

– tight bends;

structed;

– impaired visibility;

- the® warning light is displayed.

– activation of one of the direction indi-

cator lights;

The 

warning light and the left/

– strong acceleration;

right line warning lights are displayed in

– emergency braking;

grey on the instrument panel.

– ...

Adjustment

If the function is unavailable, the 

warning light and the left/right correc-

Vehicles fitted with a multimedia

tion warning lights 3 appear in grey on

screen.

“Alert”: adjust the line detection sen-

the instrument panel.

sitivity level. To do this, select:

To access the function settings from the

multimedia screen 4 please refer to the

- “Late”: line detected when cross-

multimedia instructions:

ing;

- “Vibration”: adjust the steering wheel

- “Standard”: line detected on ap-

vibration level;

proach;

- “Early”: line detected nearby.

Please refer to the multimedia instruc-

tions for further information.

2.57

CarManuals2.co

LANE KEEPING ASSIST (5/6)

- press the 6 or 7 control repeatedly to

Operating faults

reach the “DRIVING ASSIST” menu.

When the system detects an operating

Press the switch 8 OK;

fault, the

warning light appears

– press the 6 or 7 control repeatedly

on the instrument panel along with the

to reach the “Lane Keeping sensitiv-

message “Front camera to check”.

ity=#” menu. Press the switch 8 OK;

Consult an approved dealer.

- press the 6 or 7 control repeatedly to

adjust the setting. Press 8 OK.

Adjustments (continued)

Vehicles not fitted with a multimedia

screen

- With the vehicle stopped, press the

switch 5 as many times as required

to reach the “Vehicle” tab;

- press the 6 or 7 control repeatedly to

reach the “Settings” menu. Press the

switch 8 OK;

2.58

CarManuals2.co

LANE KEEPING ASSIST (6/6)

This function is an additional driving aid. This function is not under any circumstances intended to replace the due care

and attention of the driver, who should at all times be in control of the vehicle.

System servicing/repairs

- In the event of an impact, the camera alignment may be changed, and its operation may consequently be affected. Deactivate

the function and consult an authorised dealer.

- Any work in the area where the camera is located (repairs, replacements, windscreen modifications etc.) must be carried

out by a qualified professional.

Only an authorised dealer is qualified to service the system.

In the event of system disturbance

Some conditions can disrupt or damage the operation of the system, for example:

- windscreen obscured (by dirt, ice, snow, condensation etc.);

- a complex environment (tunnel etc.);

- poor weather conditions (snow, rain, hail, black ice etc.);

- poor visibility (night, fog etc.);

- the road markings are irregular or difficult to distinguish (e.g. partially erased, excessive spacing, distorted road surface);

- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);

- the road is narrow, winding or undulating (tight bends etc.);

- closely following a vehicle travelling in the same lane.

In this case, the “Lane Keeping Assist” may react incorrectly or not at all.

Risk of unwanted, incorrect correction or no correction of trajectory.

Deactivating the function

You must disable the function if:

- the area of the camera has been damaged (on the windscreen side or the interior rear-view mirror side);

- the road is slippery (snow, black ice, aquaplaning, gravel etc.) ;

- poor visibility (night, fog etc.);

- the windscreen is cracked or distorted (do not carry out windscreen repairs in this area; have it changed by an Authorised

Dealer);

- the vehicle is towing a trailer or a caravan;

- the vehicle is entering an area with several surface markings (an area with road works etc.).

2.59

CarManuals2.co

BLIND SPOT WARNING (1/7)

Using information from the sensors in-

Special feature

stalled on each side of the rear bumper

Make sure that the radar area C is not

(area C), the function warns the driver:

obscured (by stickers, mud, snow etc.).

- when another vehicle appears in the

If a radar is obscured, the message

detection area A;

“Side radars no visibility” will appear on

and/or

the instrument panel. Clean the area

where the sensors are located.

- when there is a risk of collision with

a vehicle that is in area B, driving

faster than you.

This function is an addi-

tional driving aid. This func-

The function warns you when the ve-

tion is not under any cir-

hicle is travelling at a speed above ap-

cumstances intended to

proximately 9 mph (15 km/h).

replace the due care and attention

of the driver, who should at all times

be in control of the vehicle.

2.60

CarManuals2.co

BLIND SPOT WARNING (2/7)

- press the switch 5 OK again to acti-

vate or deactivate the function:

function activated

function deactivated

Activation/deactivation

- press the 3 or 4 control repeatedly to

reach the “Settings” menu. Press the

Vehicles fitted with a multimedia

switch 5 OK;

screen 1

- press the 3 or 4 control repeatedly to

To activate or deactivate the function,

reach the “DRIVING ASSIST” menu.

refer to the multimedia instructions.

Press the switch 5 OK;

Select “ON” or “OFF”.

- press the 3 or 4 control repeatedly to

reach the “Blind spot alert” menu and

Vehicles not fitted with a multimedia

press 5 OK;

screen

- With the vehicle stopped, press the

switch 2 as many times as required

The system’s detection range oper-

to reach the “Vehicle” tab;

ates according to a standard lane

width. When driving in a narrow

lane, the function may warn you

when a vehicle is detected further

away than the nearest lane.

2.61

CarManuals2.co

BLIND SPOT WARNING (3/7)

Indicator 6

Operation

An indicator light 6 is located on each

The function warns you when the speed

rear view mirror 7.

of your vehicle exceeds approximately

9 mph (15 km/h):

Note: clean the rear view mirrors 7 reg-

- when another vehicle is in the blind

ularly so that the indicators 6 can be

spot area A and travelling in the

seen.

same direction as your vehicle;

- when a vehicle approaches quickly

from the rear in an adjacent lane

within the range of detection area B.

If you overtake another vehicle, the in-

dicator 6 will only come on if that vehi-

cle remains for a long enough period in

your vehicle’s blind spot A.

The function does not notify the

driver if the other vehicles are not

moving.

2.62

CarManuals2.co

BLIND SPOT WARNING (4/7)

Display E

Conditions for non-function

Direction indicator activated, the 6

- When driving on a road with tight

warning light flashes when the func-

bends;

tion detects a vehicle in the blind spot

- in reverse.

warning area and/or a vehicle is rapidly

approaching from the rear on the side

If the vehicle is equipped with a towbar

towards which you will turn the wheel.

recognised by the system, the “Trailer:

If you cancel the direction indicator, the

blind spot alert off” message displayed

function will return to the initial warning

on the instrument panel informs you

(display D).

that the function is not operational. For

information on the range of equipment

adapted to your vehicle, we advise you

to consult an approved Dealer.

Display D

First warning: direction indicator not

activated, the 6 warning light indicates

that a vehicle is detected in the blind

spot area and/or that a vehicle is rap-

idly approaching from the rear in an ad-

jacent lane.

When the engine is started, the

system adopts the last status saved

before the ignition was switched off

(refer to the previous pages).

2.63

CarManuals2.co

BLIND SPOT WARNING (5/7)

Operating faults

If the system detects a fault, the mes-

sage “Side radars to check” is displayed

on the instrument panel. Consult an ap-

proved dealer.

- The system’s detection

range operates according

to a standard lane width. If

you are driving in wide traf-

fic lanes, the system might not

be able to detect a vehicle in the

blind spot.

- The system might be disrupted

momentarily if it is exposed to

strong electromagnetic waves

(as beneath high-tension power

lines) or to very poor weather

conditions

(heavy rain, snow

etc.). Remain aware of driving

Due to the presence of sensors

conditions.

behind the bumper, it is advisable to

entrust any operation on the bumper

There is a risk of accidents.

(repair, replacement, paintwork,

etc.) to a qualified professional.

2.64

CarManuals2.co

BLIND SPOT WARNING (6/7)

This function is an additional driving aid. This function is not under any circumstances intended to replace the due care

and attention of the driver, who should at all times be in control of the vehicle.

The driver should always adapt their speed to the traffic conditions, regardless of the system indications.

The system should under no circumstances be taken to be an obstacle detector or an anti-collision system.

System servicing/repairs

- In the event of an impact, radar alignment may be changed, and its operation will consequently be affected. Deactivate the

function and consult an authorised dealer.

- Any work in the area where the radars are located (repairs, replacements, etc.) must be carried out by a qualified profes-

sional.

Only an authorised dealer is qualified to service the system.

System disturbance

Some conditions can disturb or damage the operation of the system, such as:

- complex surroundings (metal bridges, tunnels, roads with barriers at the edge, etc.);

- poor weather conditions (snow, hail, black ice, etc.).

Risk of false alarms or absence of warnings

In the event of the system behaving abnormally, deactivate it and consult an authorised dealer.

2.65

CarManuals2.co

BLIND SPOT WARNING (7/7)

Limitation of the system operation

- The radar area should be kept clean and free of any modifications in order to ensure the proper operation of the

system.

- Small objects moving close to the vehicle (motorcycles, bicycles, pedestrians, etc.) may not be recognised by the system.

- When turning into a bend, the radars may temporarily cease to detect vehicles in adjacent lanes.

- The function may warn you late when two other vehicles are approaching from the rear, side by side in the adjacent lanes

(driving on a 3-lane road) and at a much higher speed than your vehicle.

- The system may not provide a warning when the other vehicles are travelling at a significantly different speed.

- If the vehicle is being overtaken by a long vehicle (e.g. heavy goods vehicle overtaking at a similar speed to the vehicle) the

system may interrupt the warning before the end of the manoeuvre.

- The vehicle is travelling on a winding road.

Deactivating the function

You must disable the function if:

- the radar area has been damaged (rear bumper);

- the vehicle is fitted with a towbar that is not recognised by the system.

2.66

CarManuals2.co

SAFE DISTANCE ALERT (1/4)

The function is activated when the vehi-

cle speed is between about 19 and

124 mph (30 and 200 km/h).

Location of the camera 1

Make sure the windscreen is not ob-

scured (by dirt, mud, snow, condensa-

tion etc.).

Location of the radar 2

Ensure that the radar area is not ob-

structed (by dirt, mud, snow, a badly

fitted front number plate), impacted,

modified (including painting) or hidden

by any accessory fitted on the front of

the vehicle (on the grille or logo etc.).

Using the information from the radar 2

and camera 1, this function informs the

driver of the time interval between their

vehicle and the vehicle in front so that a

safe stopping distance between the two

vehicles can be maintained.

This function is an addi-

tional driving aid. This func-

tion is not under any cir-

cumstances intended to

replace the due care and attention

of the driver, who should at all times

be in control of the vehicle.

2.67

CarManuals2.co

SAFE DISTANCE ALERT (2/4)

- press the 5 or 6 control repeatedly to

reach the “Distance warning” menu.

Press the switch 7 OK;

- press the switch 7 OK again to acti-

vate or deactivate the function:

function activated

function deactivated

Activating/deactivating the

Vehicles not fitted with a multimedia

screen

function

- With the vehicle stopped, press the

Vehicles fitted with a multimedia

switch 4 as many times as required

screen 3

to reach the “Vehicle” tab;

To activate or deactivate the function,

- press the 5 or 6 control repeatedly to

refer to the multimedia instructions.

reach the “Settings” menu. Press the

Select “ON” or “OFF”.

switch 7 OK;

- press the 5 or 6 control repeatedly to

reach the “DRIVING ASSIST” menu.

Press the switch 7 OK;

Each time the vehicle is started,

the function continues the mode

saved the last time the engine was

stopped.

2.68

CarManuals2.co

SAFE DISTANCE ALERT (3/4)

- C (orange): the time interval falls be-

tween around 1 and 2 seconds (in-

sufficient distance between the two

vehicles);

- D (red): the time interval is less than

or equal to around one second (very

insufficient distance between the two

The measurement is dis-

vehicles).

played for information: the

If the interval between the two vehi-

system does not carry out

cles is less than approximately 0.5 sec-

any action on the vehicle.

onds, the 8 indicator and the D display

This function is not designed for use

will flash in red on the instrument panel

in urban conditions or for a dynamic

along with “-.- s”.

driving style (sudden cornering, ac-

Under certain conditions, the time inter-

celeration, braking, etc.), but rather

val may not be displayed:

for stable driving conditions.

Operation

- while cornering;

The function does not interact with

With the function activated, the 8 in-

the braking system.

- when changing lane;

dicator is displayed on the instrument

The radar and camera zones must

panel and informs the driver of the dis-

- if the vehicle in front is sufficiently far

be kept clean and free of any tam-

tance between their vehicle and the ve-

or outside the range of the radar or

pering in order to ensure the proper

hicle in front.

camera.

operation of the system.

- A (grey): function not operational;

Any work carried out in the area

- A (green): no vehicle detected;

where the radar or camera is lo-

cated (repairs, replacements, wind-

- B (green): the time interval is greater

screen and/or bumper modifica-

than or equal to around two seconds

tions, etc.) must be carried out by a

(distance between the two vehicles

qualified professional.

adapted to your speed);

2.69

CarManuals2.co

SAFE DISTANCE ALERT (4/4)

This function is an additional driving aid. This function is not under any circumstances intended to replace the due care

and attention of the driver, who should at all times be in control of the vehicle.

System servicing/repairs

- In the event of an impact, the radar and/or camera alignment may be changed and its operation may consequently be af-

fected. Deactivate the function and consult an authorised dealer.

- Any work carried out in the area where the radar and/or camera is located (replacements, repairs, windscreen and/or

bumper modifications, etc.) must be carried out by a qualified professional.

Only an authorised dealer is qualified to service the system.

In the event of system disturbance

- obstruction of the windscreen or the bumper (by dirt, glass, snow, condensation, etc.);

- a complex environment (metal bridge, tunnel etc.);

- poor weather conditions (snow, hail, black ice etc.);

- poor visibility (night, fog etc.);

- poor contrast between the vehicle preceding it and the surrounding area (e.g. white vehicle in a snowy area etc.) ;

- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);

- the road is narrow, winding and undulating (tight bends etc.)

Risk of erroneous false alarms.

2.70

CarManuals2.co

ACTIVE EMERGENCY BRAKING (1/8)

Depending on the reactivity of the

driver, the system can assist with brak-

ing in order to limit damage or prevent

a collision.

Location of the camera 1

Make sure the windscreen is not ob-

scured (by dirt, mud, snow, condensa-

tion etc.).

Location of the radar 2

Ensure that the radar area is not ob-

structed (by dirt, mud, snow, a badly

This system can apply maximum

fitted front number plate), impacted,

braking to the vehicle until it is

modified (including painting) or hidden

completely stationary if necessary.

by any accessory fitted on the front of

For safety reasons, always wear

The system uses information from the

the vehicle (on the grille or logo etc.).

your seat belt when travelling in

radar 2 and the camera 1 to determine

your vehicle and make sure that it

the distance from your vehicle:

is loaded so that no items can be

- from the vehicle ahead in the same

thrown forward and hit the occu-

lane;

pants.

- surrounding pedestrians and cyclists.

The system informs the driver if there

is a risk of head-on collision to enable

appropriate emergency manoeuvres

This function is an addi-

(pressing the brake pedal and/or turn-

tional driving aid. This func-

ing the steering wheel).

tion is not under any circum-

stances intended to replace

the due care and attention of the

driver, who should at all times be

in control of the vehicle.

2.71

CarManuals2.co

ACTIVE EMERGENCY BRAKING (2/8)

Operation

Special features of warnings

Depending on the speed, the warning

Detection of vehicles

and braking may be activated simulta-

When driving, in the event of a risk of

neously.

collision with the vehicle in front the

system will:

Special features of stationary

vehicles

- warn of the risk of collision: when

the vehicle speed is between 4 mph

Stationary vehicles are detected when

(7 km/h) and 106 mph (170 km/h),

your vehicle is being driven at a speed

the message “Brake” is displayed

between approximately 4 mph (7 km/h)

in red on the instrument panel 3 ac-

and 50 mph (80 km/h). The system is

companied by an audible warning.

not active and does not emit a warning

for stationary vehicles when you exceed

If the driver presses the brake pedal

approximately 50 mph (80 km/h).

and the system still detects a risk

of collision, the brake force is in-

creased;

If the vehicle stopped as a result of

active emergency braking, the driver

- braking may be triggered: when

must keep the vehicle stationary by ap-

the vehicle is moving slower than ap-

plying the brake pedal.

proximately 75 mph (120 km/h), if the

driver does not respond to the warn-

Note: if the driver uses the vehicle con-

ing and a collision becomes immi-

trols (steering wheel, pedals, etc.) the

nent.

system may delay certain operations or

not activate.

In the event of emergency manoeu-

vre, you can stop braking at any

moment by:

- tapping the accelerator pedal;

- turning the steering wheel as a

collision avoidance manoeuvre.

2.72

CarManuals2.co

ACTIVE EMERGENCY BRAKING (3/8)

Detection of pedestrians and

Special features of warnings

cyclists

Depending on the speed, the warning

(depending on the vehicle)

and braking may be activated simulta-

When there is a risk of collision with a

neously.

cyclist or pedestrian while the vehicle is

moving, the system will:

- warn of the risk of collision: when

the vehicle speed is between 4 mph

(7 km/h) and 50 mph (80 km/h),

the message “Brake” is displayed

in red on the instrument panel 3 ac-

companied by an audible warning.

If the driver presses the brake pedal

and the system still detects a risk

of collision, the brake force is in-

creased;

If the vehicle stopped as a result of

active emergency braking, the driver

- trigger braking: if the driver does

must keep the vehicle stationary by ap-

not respond to the warning and the

plying the brake pedal.

collision becomes imminent.

Note: if the driver uses the vehicle con-

trols (steering wheel, pedals, etc.) the

system may delay certain operations or

not activate.

In the event of emergency manoeu-

vre, you can stop braking at any

moment by:

- tapping the accelerator pedal;

- turning the steering wheel as a

collision avoidance manoeuvre.

2.73

CarManuals2.co

ACTIVE EMERGENCY BRAKING (4/8)

- press the 6 or 7 control repeatedly to

reach the “Active braking” menu and

press the 8 OK switch.

Press the switch 8 OK again to activate

or deactivate the function:

function activated

function deactivated

Upon deactivation of the system, the



warning light illuminates or, de-

pending on the vehicle, the



warning light illuminates on the instru-

ment panel.

Activating or deactivating the

For vehicles not fitted with a

multimedia screen

system

- With the vehicle stopped, press the

Vehicles fitted with a multimedia

switch 5 as many times as required

screen 4

to reach the “Vehicle” tab;

To activate or deactivate the function,

- press the 6 or 7 control repeatedly to

please refer to the multimedia instruc-

reach the “Settings” menu. Press the

tions.

switch 8 OK;

- press the 6 or 7 control repeatedly to

Select “ON” or “OFF”.

reach the “DRIVING ASSIST” menu.

Press the switch 8 OK;

This system is reactivated each time

the ignition is switched on.

2.74

CarManuals2.co

ACTIVE EMERGENCY BRAKING (5/8)

Temporarily not available

Operating faults

If the system detects a temporary

and 

or, depending on the

fault the



warning light illumi-

vehicle, 

illuminated on the instru-

nates, or depending on the vehicle the

ment panel indicate that the system has



warning light illuminates on the

detected an operating fault. Consult an

instrument panel.

approved dealer.

The possible causes are:

- the system is temporarily blinded

(glare from the sun, dipped beam

headlights, bad weather conditions

etc.). The system will be operational

again when visibility conditions are

better;

- the system is temporarily interrupted

(e.g. the windscreen or the front or

rear bumper is obscured by dirt,

mud, snow, condensation, etc.). In

this case, park the vehicle and switch

off the engine. Clean the windscreen

and front bumper. When you next

start the engine, the warning light

and the message go out.

If this is not the case, this may arise from

another cause; contact an Approved

Dealer.

2.75

CarManuals2.co

ACTIVE EMERGENCY BRAKING (6/8)

Active emergency braking

This function is an additional driving aid. This function is not under any circumstances intended to replace the due care

and attention of the driver, who should at all times be in control of the vehicle. The triggering of this function may be

delayed or prevented when the system detects clear signs of control of the vehicle by the driver (action on the steer-

ing wheel, pedals etc.).

The system cannot be activated:

- when the gearbox lever is in neutral or the clutch pedal has been depressed during approximately ten seconds;

- when the parking brake is activated;

- when the Electronic Stability Program (ESC) has started.

System servicing/repairs

- In the event of an impact, the radar and/or camera alignment may be changed and its operation may consequently be af-

fected. Deactivate the function and consult an authorised dealer.

- Any work in the area where the radar and/or camera is located (repairs, replacements, windscreen modifications, etc.) must

be carried out by a qualified professional.

Only an authorised dealer is qualified to service the system.

2.76

CarManuals2.co

ACTIVE EMERGENCY BRAKING (7/8)

System disturbance

Some conditions can disturb or damage the operation of the system, such as:

- a complex environment (metal bridge, tunnel etc.);

- poor weather conditions (snow, hail, black ice etc.);

- poor visibility (night, fog etc.);

- poor contrast between an object (vehicle, pedestrian etc.) and the surrounding area (e.g. pedestrian dressed in white lo-

cated in a snowy area);

- being dazzled (glaring sun, lights of vehicles travelling in the opposite direction etc.);

- obstruction of the windscreen or the radar area (by dirt, ice, snow, condensation etc.);

- ...

In these conditions, the system may not react, may warn the driver or may brake inadvertently.

Limitation of the system operation

- Each time the vehicle is started, the system carries out a calibration according to the vehicle surroundings and may be inac-

tive for a length of time between approximately two and five minutes;

- a vehicle moving in the opposite direction will not trigger any alert or affect operation of the system;

- the radar and camera zones must be kept clean and free of any modifications in order to ensure the proper operation of the

system;

- the system may not respond to small vehicles such as motorbikes as effectively as to other vehicles;

- the system may not operate properly when the road surface is slippery (rain, snow, black ice, etc.);

- to ensure correct operation, the system needs to distinguish the complete outline of the pedestrian. So the system cannot

detect:

- pedestrians in the darkness or in poor lighting conditions;

- partially visible pedestrians:

- pedestrians less than approximately 80 cm tall;

- pedestrians carrying large objects;

- ...

In these conditions, the system may not react, may warn the driver or may brake inadvertently.

2.77

CarManuals2.co

Renault Megane (2023 year). Manual in english - page 4
