WARNING LIGHTS (4/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Anti-lock braking warning

Preheating warning light

Low fuel level warning light

light

(Diesel version)

It lights up orange when the ig-

nition or the engine is switched on and

It lights up when the ignition or the

This should come on when the igni-

goes off after a few seconds.

engine is switched on and goes off after

tion is switched on. It indicates that the

If the light becomes orange while driv-

a few seconds.

heater plugs are in operation.

ing and a beep sounds, fill up with fuel

If it lights up when you are driving, it in-

It goes out when preheating is com-

as soon as possible. There is only ap-

dicates a fault in the anti-lock braking

plete. The engine can be started.

proximately 31 miles (50 km) worth of

system.

Toxic Fume Filter System

fuel left.

Braking will then be as normal, without

Warning Light

Coolant temperature warn-

the ABS. Contact an approved Dealer

ing light

as soon as possible.

On vehicles that are equipped, this light

comes on when the engine is started

This lights up blue when you switch on

Particle filter system warn-

and, depending on the vehicle, when

the ignition or start the engine.



ing light ➥ 2.12 ➥ 2.14

the ignition is switched off while the

If it turns red, stop and let the engine

Warning light for reagent

engine is in the standby phase ➥ 2.8



idle for a minute or two.

level and faults in the ex-

then it goes out.

haust gas reduction system ➥ 1.150

The temperature should lower and the

- If it lights up continuously, consult

warning light should return to a blue

Tyre pressure loss warning

your approved dealer as soon as



colour. If not, stop the engine. Let the

➥ 2.31

possible;

engine cool down before checking the

Tyre pressure monitoring

- If it flashes, reduce the engine speed

coolant.



system ➥ 2.37

until the light stops flashing. Contact

Contact an approved Dealer.

your approved Dealer as soon as

Door status warning light

possible ➥ 2.29.

Mode warning light ECO



It comes on when ECO mode

is active ➥ 2.21.

1.101

CarManuals2.co

WARNING LIGHTS (5/5)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Speed limiter warning light

Lane departure system

➥ 2.96



warning light ➥ 2.48

Cruise control warning light

Lane Keeping Assist system

➥ 2.100



warning light ➥ 2.53

Adaptive cruise control

(Depending on the vehi-





warning light ➥ 2.105

cle) Advanced Safety

warning light, fault light or not avail-

Engine standby warning



able ➥ 2.73

light ➥ 2.8

Hands off steering wheel de-

Unavailability of engine



tection warning light ➥ 2.53



standby warning light ➥ 2.8

“Lane Centring” function

Assisted parking brake fault



warning light ➥ 2.119



light ➥ 2.147

Overspeed warning light



➥ 1.103

On display D

Freewheel indicator light



Passenger Airbag ON

It activates when the parame-



➥ 1.90

ter “Free-wheel” is activated (ON) in the

Passenger Airbag OFF

user settings ➥ 1.119, ➥ 2.21.

➥ 1.90

This warning light is displayed when the

Seat belt reminder warning

function is activated:

lights ➥ 1.41.

- in grey when the vehicle is not in

freewheel mode;

- in green or, depending on the vehi-

cle, when the vehicle is in freewheel

mode (automatic neutral).

1.102

CarManuals2.co

DISPLAYS AND INDICATORS (1/6)

Vehicles fitted with a multimedia

screen.

Please refer to the multimedia instruc-

tions to select the audio system.

Note: in both cases, once the battery

is switched off, the on-board computer

automatically returns to the original unit

of measurement.

To return to the previous mode, repeat

the same operation.

Please refer to the multimedia instruc-

tions for more information.

Engine oil level low warning

Instrument panel in miles

(option to switch to km/h)

When the engine is started, the instru-

ment panel display alerts you if the min-

Vehicles not fitted with a multimedia

imum oil level is reached. ➥ 4.4.

screen

To use certain driving aid functions,

it is necessary to change the unit

The first time the warning appears, it

- With the ignition off, press the

of measurement on the instrument

can be cleared by pressing 1 "OK ".

switch as many times as required to

panel in order to obtain the correct

reach the vehicle tab 5;

Subsequent warnings will disappear

information when driving in a coun-

automatically after around 30 seconds.

- press 3 or 4 repeatedly to access

try where the speed units differ from

“Settings”, then press 1 “OK”;

those set as default on your vehicle.

- repeat the same operation to access

“DASHBOARD”, then “Units”.

For safety reasons, change

these settings while the ve-

hicle is stationary.

1.103

CarManuals2.co

DISPLAYS AND INDICATORS (2/6)

Instrument panel A

Coolant temperature indicator 6

Overspeed buzzer

Depending on the vehicle and coun-

It lights up when the ignition is switched

In normal use, indicator 6 should be

on. In some cases, the appearance of a

before area 7. Under “intensive” oper-

try, the



warning light is dis-

warning light is accompanied by a mes-

ating conditions, the needle may ap-

played and a beep sounds. This beep

sage.

proach this zone. This is not serious

sounds as soon as the vehicle is trav-

Depending on the vehicle, you can cus-

unless the warning light

comes

elling at over 75 mph (120 km/h). This

tomise your instrument panel with the

on accompanied by a message on the

warning light remains lit for as long as

content and colours of your choice.

instrument panel and a beep.

the vehicle is travelling at over 74 mph

For vehicles fitted with a multimedia

(120 km/h).

screen, refer to the multimedia instruc-

Speedometer 8

tions.

Depending on the style selected, the

Rev counter 9

For vehicles not fitted with a multimedia

display varies.

(graduations x 1000)

screen ➥ 1.119.

This is displayed differently according

to how the instrument panel is custom-

ised. Depending on the style selected,

it may not be displayed.

Driving style indicator 10 ➥ 2.21

1.104

CarManuals2.co

DISPLAYS AND INDICATORS (3/6)

Multimedia information 11

Fuel gauge 15

Depending on the vehicle, you can dis-

If the level is at the minimum, warn-

play information from the multimedia

screen (the compass, telephone, navi-

ing light M

integrated in the indica-

gation, etc.).

tor comes on orange, accompanied by

Please refer to the multimedia instruc-

a beep. Fill up as soon as possible.

tions for more information.

Estimated mileage with remaining

fuel 12

The value is displayed after driving 400

metres. ➥ 1.112.

Total mileage recorder 13 ➥ 1.112

Trip computer 14 ➥ 1.109

1.105

CarManuals2.co

DISPLAYS AND INDICATORS (4/6)

Instrument panel B

Rev counter 16

Trip computer 19

(graduations x 1000)

➥ 1.109

It lights up when the ignition is switched

on. In some cases, the appearance of a

Coolant temperature indicator 18

Estimated mileage with remaining

warning light is accompanied by a mes-

fuel 20

In normal use, the indicator 18 should

sage.

The value is displayed after driving

be before the red zone 17. Under “in-

Depending on the vehicle, you can cus-

400 metres.

tensive” operating conditions, the

tomise your instrument panel with col-

➥ 000

needle may approach this zone. This

ours of your choice. For vehicles fitted

is not serious unless the warning light

Total mileage recorder 21

with a multimedia screen, refer to the

comes on accompanied by a

➥ 000

multimedia instructions.

message on the instrument panel and

For vehicle not fitted with a navigation

a beep.

system ➥ 1.119.

1.106

CarManuals2.co

DISPLAYS AND INDICATORS (5/6)

Driving style indicator 22 ➥ 2.21

Speedometers 23 and,

Overspeed buzzer

depending on the vehicle, 25

Depending on the vehicle and coun-

Fuel gauge 24

(km or miles per hour)

If the level is at the minimum, warn-

try, the



warning light is dis-

Control your speed according to the ap-

played and a beep sounds. This beep

proved speedometer only 23.

ing light M

integrated in the indica-

sounds as soon as the vehicle is trav-

tor comes on orange, accompanied by

The indicator 25 is provided as an in-

elling at over 75 mph (120 km/h). This

a beep. Fill up as soon as possible.

dication.

warning light remains lit for as long as

the vehicle is travelling at over 74 mph

(120 km/h).

1.107

CarManuals2.co

DISPLAYS AND INDICATORS (6/6)

Instrument panel C

Gear change indicator 28 ➥ 2.21

It lights up when the ignition is switched

Overspeed buzzer

on. In some cases, the appearance of a

Depending on the vehicle and coun-

warning light is accompanied by a mes-

sage.

try, the



warning light is dis-

played and a beep sounds. This beep

Rev counter 25

sounds as soon as the vehicle is trav-

(scale x 1,000)

elling at over 75 mph (120 km/h). This

warning light remains lit for as long as

Speedometers 26 and, depending

the vehicle is travelling at over 74 mph

on the vehicle, 27

(120 km/h).

(km or miles per hour)

Control your speed according to the ap-

Fuel gauge 29

proved speedometer only 26.

The number of squares lit shows the

fuel level. When it is at minimum, the

The indicator 27 is provided as an in-

squares disappear and the low fuel

dication.

level warning light comes on, depend-

ing on the vehicle.

1.108

CarManuals2.co

TRIP COMPUTER: general information (1/3)

Trip computer A, B or C

Depending on the vehicle, this includes

the following functions:

- distance travelled;

- journey settings;

- information messages;

- operating fault messages

(con-

- warning messages (connected to the

warning light);

– vehicle settings customisation menu

➥ 1.119.

All these functions are described on the

following pages.

1.109

CarManuals2.co

TRIP COMPUTER: general information (2/3)

Vehicle fitted with Ainstrument

Vehicle fitted with instrument

panel

panel B or C

The functions are distributed in

Press the 1switch as many times as re-

zones 5, 6, 7, and 8.

quired to reach the “Vehicle” tab.

Press the 1 switch to browse between

Press repeatedly using the 2 or 3 con-

menus and select functions by repeat-

trol, then if necessary use the 4 switch

edly pressing switch 2 or 3, then if nec-

to confirm “OK”.

essary use the 4 switch to confirm “OK”.

1.110

CarManuals2.co

TRIP COMPUTER: general information (3/3)

Selections

Interpreting some of the

(the display depends on the vehicle

values displayed after

equipment and country)

resetting

a) Trip log, operating faults and infor-

The values showing average fuel con-

mation message readout;

sumption, range and average speed

b) current fuel consumption and aver-

will become more stable and reliable

age fuel consumption;

the further you travel after pressing the

reset button.

c) trip mileage recorder and average

speed;

For the first few miles after pressing

the reset key you will notice that the

d) Reset the tyre pressure;

range increases as you travel. This

e) set the time;

range takes into account the average

f) distance before service;

fuel consumption since the last time the

reset button was pressed. Therefore,

- Distance before service;

the average fuel consumption may de-

Resetting the trip mileage

- Distance before oil change;

crease when:

recorder and journey

g) Estimated range with remaining rea-

- the vehicle stops accelerating;

parameters (reset button)

gent.

- the engine reaches its operating

With one of the trip parameters se-

temperature (if the engine was cold

lected as the display, press and hold

when the reset key was pressed);

the

4 switch “OK” until the display

- when driving from an urban area

resets to zero.

onto the open road.

Automatic resetting of the

journey parameters

Resetting occurs automatically when

the maximum value of any of the pa-

rameters is exceeded.

1.111

CarManuals2.co

TRIP COMPUTER AND WARNING SYSTEM: journey parameters (1/4)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

a) Trip log.

Successive display:

Vehicle Systems OK

- information messages (passenger airbag OFF etc.);

- operating fault messages (“Check injection” etc.).

b) Current fuel consumption.

This value is displayed after a speed of approximately 20 mph (30 km/h) is

7.4 L/100

reached.

Average fuel consumption since the last reset.

The value is displayed after having travelled at least 400 metres since the last

5.8 L/100

reset.

c) Mileage recorder: Distance travelled since the last reset.

112,4 km

Average speed since the last reset.

123.4 km/h

The value is displayed after driving 400 metres.

1.112

CarManuals2.co

TRIP COMPUTER AND WARNING SYSTEM: journey parameters (3/4)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

On-board computer with mileage-

before-service message

Mileage before service and oil change.

Mileage before service

Service Due in

With the ignition on and engine not running, access the “Mileage

30 000 km / 24 months

before service” information. When the distance value approaches its

limit, there are several possible scenarios:

- range less than 930 miles (1,500 km) or one month: the message

“Service Due in” is displayed accompanied by the nearest term (dis-

Service Due in

tance or time);

300 km / 24 days

- range equal to 0 miles (0 km) or date of service reached: the mes-

sage “Service Required” is displayed accompanied by the warning

The vehicle requires a service as soon as possible.

Service Required

Reset: to reset the distance before the next service, press and hold button OK for approximately 10 seconds until the display

shows the mileage before service permanently.

Note: If a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the

event of an oil change, both the distance before the next service and the next oil change should be reset.

1.114

CarManuals2.co

TRIP COMPUTER AND WARNING SYSTEM: journey parameters (4/4)

The display of information shown below DEPENDS ON THE VEHICLE EQUIPMENT AND COUNTRY.

Examples of selections

Interpreting the display selected

On-board computer with distance

before next service message (cntd.)

f) Mileage before service or oil change.

Oil Change in

Mileage before service

With the ignition on and the engine not running, access the mileage

30 000 km / 24 months

information to display the mileage before the next oil change.

Depending on the vehicle, the mileage before an oil change varies according to the driving style (frequent driving at low speed,

door-to-door journeys, extensive use at idling speed, towing a trailer, etc.). The distance remaining until the next oil change can

therefore decrease more quickly in some cases than the actual distance travelled.

Reset: to reset the distance before the next service, press and hold button OK for approximately 10 seconds until the display

shows the mileage before oil change permanently.

Note: If a service is performed without changing the engine oil, only the mileage before the next service should be reset. In the

event of an oil change, both the distance before the next service and the next oil change should be reset.

Top Up AdBlue before 2400 km

g) Estimated range with remaining reagent.

1.115

CarManuals2.co

TRIP COMPUTER AND WARNING SYSTEM: information messages

These can help in the vehicle starting phase, or give information about a selection or a driving status.

Examples of information messages are given in the following pages.

Examples of messages

Interpreting the display selected

“Parking Brake ON”

Indicates that the parking brake has been applied.

Turn the steering wheel slightly whilst pressing the vehicle start button to unlock the steer-

“Turn Steering Wheel + START”

ing column.

“Vehicle Checks in Progress”

Displayed with the ignition on when the vehicle is running self-diagnostics.

1.116

CarManuals2.co

TRIP COMPUTER AND WARNING SYSTEM: operating fault messages

soon as possible. If you fail to follow this recommendation, you risk damaging your vehicle.

They disappear when the display selection key is pressed or after several seconds and are stored in the computer log. The

warning light stays on. Examples of operating fault messages are given in the following pages.

Examples of messages

Interpreting the display selected

“Clean Diesel Filter”

Indicates the presence of water in the diesel filter; contact an approved Dealer

as soon as possible.

“Check vehicle”

Indicates a fault in one of the pedal sensors, battery management system or oil

level sensor.

“WARNING: Check Airbag”

Indicates a fault in the restraint system in addition to the seat belts. In the event

of an accident, it is possible that they may not be triggered.

“Check Anti- Pollution System”

- Indicates a fault in the vehicle’s particle filter system.

- Indicates a fault in the emissions reduction system when it is accompanied

by the 

warning light. ➥ 1.150.

“WARNING: Check SOS Call”

Indicates a fault in the emergency call system.

1.117

CarManuals2.co

TRIP COMPUTER AND WARNING SYSTEM: warning message

These appear with the® warning light and require you to stop immediately, for your own safety, as soon as traf-

fic conditions allow. Stop your engine and do not restart it. Contact an approved Dealer.

Examples of warning messages are given in the following pages. Note: the messages appear on the display either individually

or alternately (when there are several messages to be displayed), and may be accompanied by a warning light and/or a beep.

Examples of messages

Interpreting the display selected

“WARNING: Engine Failure Risk”

Indicates an injection fault, the vehicle’s engine has overheated or there is a

serious engine fault.

“WARNING: Braking System”

Indicates a fault in the braking system.

“Electric System Failure”

Indicates a fault in the vehicle battery charging circuit (alternator etc.).

“Puncture”

Indicates that at least one wheel is punctured or severely underinflated.

“WARNING: Steering Fault”

Indicates a problem with the steering.

“WARNING: Gearbox Failure Risk”

Indicates an automatic gearbox fault.

1.118

CarManuals2.co

VEHICLE SETTINGS CUSTOMISATION MENU (1/3)

Adjusting the settings

d) “Welcome”:

- External welcome;

Select a menu then the function to be

- Automatic fold-out of mirrors;

modified (the display depends on the

- Interior welcome;

vehicle equipment and country):

- Courtesy light auto mode.

a) “Driving”:

Depending on the function, select:

- Indicator volume;

- “ON” or “OFF” to activate or deacti-

b) “Access”:

vate,

- Release driver’s door;

– Lock doors during driving;

- a duration to adjust the time the lights

– Opening/closing in “hands-free”

are switched on (for the “Follow-me-

mode;

home lighting” function for example).

– Remote locking/Approach

un-

Please refer to the multimedia instruc-

locking;

tions for further information.

- Distance locking sound;

- Silent mode;

Depending on the vehicle equipment,

- Automatic locking;

this function allows you to activate/de-

c) “Wiping and lighting”:

activate and adjust some of the vehi-

- Follow-me-home lighting;

cle’s functions.

- Wiping in reverse;

- Automatic front wiping;

Vehicles fitted with a

- Wiping after washing;

multimedia screen 1

Accessing the settings menu

Refer to the various multimedia instruc-

tions for information on accessing the

settings.

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

1.119

CarManuals2.co

VEHICLE SETTINGS CUSTOMISATION MENU (2/3)

Adjusting the settings

d) “DRIVING ASSIST”:

- Lane departure warning sound

Navigate using the 4 or 5 control to

volume;

select the function to be modified and

- Lane departure warning sensitiv-

press 6 “OK” to confirm (display may

ity;

vary according to vehicle equipment

- Lane departure warning vibration;

and country):

- Lane keeping assist sensitivity;

a) “DASHBOARD”:

- Blind spot warning;

- Language;

- Active braking sensitivity;

- Unit;

- Advanced safety;

- Style;

- Overspeed warning;

- Colour;

- Distance warning;

b) “VEHICLE”:

e) “LIGHTING”:

- Rear windscreen wiping in re-

- Courtesy light auto mode;

verse gear;

- Automatic follow-me-home light-

- Automatic windscreen wiping;

ing;

Vehicles not fitted with a

- Front/rear drip wiping function;

- Follow-me-home lighting: XX sec-

multimedia screen

- Free-wheel;

onds;

- External welcome;

“ACCESS”:

Accessing the settings menu on

- Lock doors during driving;

c) “PARKING ASSIST”:

display 2

- Opening/Closing in “hands-free”

- Beep sound volume;

With the vehicle stopped, press the 3

mode;

switch as many times as required to

- Unlock the driver’s door only;

reach the “Vehicle” tab; Press repeat-

- Automatic re-locking;

edly on the 4 or 5 switch to access the

- Silent locking;

“Settings” menu, then confirm by press-

- Automatic opening/closing;

ing 6 “OK”.

- Automatic fold-out of mirrors;

g) “RESET”.

function activated

function deactivated

1.120

CarManuals2.co

VEHICLE SETTINGS CUSTOMISATION MENU (3/3)

To exit the menu, press 4 or 5 to access

“BACK” and confirm by pressing 6

“OK”. It may be necessary to carry out

this operation more than once.

Once a line has been selected, press 6

“OK” to adjust the function.

If you select either “PARKING ASSIST”

then “VOLUME”, or “DASHBOARD”

then “LANGUAGE”, you will have to

make a further selection (sound volume

of the parking distance control or in-

strument panel language). In this case,

make your selection and confirm it by

pressing “6 OK”, the selected value is

shown by a =

in front of the line.

The vehicle settings personalisation

menu cannot be used when driv-

ing. At a speed exceeding 12 mph

(20 km/h), the instrument panel dis-

play switches automatically back to

trip computer and warning system

mode.

1.121

CarManuals2.co

CLOCK AND EXTERIOR TEMPERATURE (1/2)

Vehicles fitted with a multimedia

Vehicles not fitted with a multimedia

Set the clock using control 3 or 4, then

screen

press switch 5 “OK” to confirm.

The time and exterior temperature are

Press the 2 switch as many times as re-

Set the minutes using control 3 or 4,

displayed on the multimedia screen 1.

quired to reach the “Vehicle” tab.

then press switch 5 “OK” to confirm.

Refer to the multimedia instructions.

Repeatedly press control 3 or 4 to set

the 6 clock.

Press and hold switch 5 “OK” until the

time display flashes.

Depending on the vehicle, If the

electrical supply is cut (battery dis-

connected, broken supply wire,

etc.), the clock will automatically

go back to the right time after a few

minutes once the system is capable

of receiving information GPS.

1.122

CarManuals2.co

STEERING WHEEL, POWER-ASSISTED STEERING

Power-assisted steering

Never drive with an inadequately

charged battery.

Variable power-assisted steering

The variable power assisted steering

system is equipped with an electronic

control system which alters the level of

assistance to suit the vehicle speed.

Steering is made easier during parking

manoeuvres (for added comfort) while

the force needed to steer increases

progressively as the speed rises (for

enhanced safety at high speeds).

Never leave the steering wheel on

Adjusting the steering wheel

Special feature of Stop and Start

full lock when the vehicle is station-

height and depth

With the engine on standby, power-

ary.

assisted steering is no longer opera-

Lower the lever 1 and position the

tional. In this case, it returns to its origi-

steering wheel in the required position.

nal state when the engine is restarted

Then, raise the lever fully, beyond the

or when the speed exceeds 1 mph

point of resistance to lock the steering

(1 km/h) (hill, slope etc.).

With the engine switched off, or if

wheel.

there is a system fault, it is still pos-

sible to turn the steering wheel. The

Make sure that the steering wheel is

force required will be greater.

correctly locked.

Never switch off the igni-

tion when travelling down-

For safety reasons, only

hill, and avoid doing so in

adjust the steering wheel

normal driving (assistance

when the vehicle is station-

is not provided).

ary.

1.124

CarManuals2.co

REAR VIEW MIRRORS (1/4)

Folding rear view mirrors

Welcome and goodbye function

(depending on the vehicle)

The door mirrors automatically fold in

Refer to the multimedia instructions to

when the vehicle is locked (switch 3 in

access the welcome and goodbye func-

position B).

tion.

In any case, you can make the door

Activate or deactivate the function by

mirrors fold in (switch 3 in position C) or

selecting (ON or OFF).

fold out (switch 3 in position A).

Depending on the selected choice, the

Automatic mode is then deactivated.

door mirrors will fold out:

To reactivate it, set the switch 3 to po-

- when the ignition is next switched on

sition B.

(function deactivated);

- when the card is detected or the ve-

hicle is unlocked (function activated).

B C

Exterior rear view mirrors

Adjustment

Select the rear view mirror using

switch 2, then use button 1 to adjust it

to the desired position.

Heated door mirrors

Mirror de-icing is carried out at the

Objects observed in the

The driver’s exterior rear

same time as rear screen de-icing.

door mirror glass are ac-

view mirror may have two

➥ 3.5 ➥ 3.9.

tually closer than they

clearly defined zones.

appear. For your safety,

Zone E shows what can

take this into account in order to

normally be seen in an ordinary rear

correctly assess the distance before

view mirror. Zone D increases rear

any manoeuvre.

side visibility.

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

1.125

CarManuals2.co

REAR VIEW MIRRORS (2/4)

Manually folding door mirrors

Special case

Interior rear view mirror

When the rear view mirror has been

Its position can be adjusted.

To fold down the door mirror, pull it to-

manually deployed or folded back, it is

wards the door window until you hear a

possible to reset it to a usage position.

Rear view mirror with lever 4

mechanical click.

When driving at night, to avoid being

To do this, press the 3 switch. A me-

To return the door mirror to its operating

dazzled by the headlights of the vehicle

chanical tapping noise can be heard

position, proceed in the reverse order.

behind, depress the little lever located

from the door mirror.

Ensure that it is correctly locked in po-

behind rear view mirror 4.

sition.

If a tapping noise cannot be heard,

press once again on 3 switch until the

Rear view mirror without lever 4

tapping noise can be heard from the

The rear view mirror automatically dark-

door mirror.

ens when you are being followed by a

vehicle which illuminates you or in very

bright lighting.

1.126

CarManuals2.co

CAMERA REAR VIEW (1/4)

When the ignition is switched on, the 2

De-icing the rear camera

This function is an additional

screen on the roof centre console dis-

In cold weather, this function enables

aid. It cannot, therefore,

plays the view behind the vehicle that is

rapid electrical de-icing of the camera.

under any circumstances

transmitted by the camera 1.

replace the vigilance or the

De-icing is carried out simultaneously

Note: the screen 2 can be positioned

responsibility of the driver.

with electrical rear view mirror de-icing

left to right or top to bottom.

➥ 3.5 ➥ 3.9.

The driver should always be ready

for sudden incidents while driv-

Make sure that the 1 camera is not ob-

ing: always ensure that there are

scured (by dirt, mud, snow, condensa-

no small, narrow moving obstacles

tion etc.).

(such as a child, animal, pushchair,

bicycle, stone, post, etc.) in the blind

spot when manoeuvring.

1.129

CarManuals2.co

CAMERA REAR VIEW (2/4)

Operation

Switching off the function

Special features related to

The camera’s field of vision does not

The display switches of:

the reverse gear

cover the entire area behind the vehi-

- at least two minutes after the ignition

When the reverse gear is engaged, the

cle, particularly the blind spot area A.

is switched off;

camera located on the rear-end door

- immediately after locking the vehicle.

displays the area to the rear of the ve-

On vehicles equipped with the Stop

and Start function, the display remains

hicle. ➥ 2.143.

active when the engine is in standby.

Vehicles fitted with a multimedia

➥ 2.8.

screen 3

When the vehicle is reversing, consider

the images transmitted by the rear view

camera (multimedia screen) in addition

to the information available through the

Objects which appear on the edge of screen 2 may be deformed.

rear view mirror as there remains a rear

In very bright light (snow, vehicle in sunshine, etc.), the camera view may be par-

view blind spot A ➥ 2.143.

tially disturbed.

In low brightness or poor weather, the image on the screen may be distorted.

1.130

CarManuals2.co

CAMERA REAR VIEW (3/4)

Selecting the settings:

a) adjusting the brightness;

b) adjusting the vertical viewing angle;

c) adjusting the horizontal viewing

angle;

d) activating/deactivating automatic ad-

justment of the vertical angle accord-

ing to the vehicle speed;

e) depending on the vehicle, activating/

deactivating the reversing camera

display;

f) reset, to reset the default settings.

Exit the settings menu:

Adjusting the display and the

- automatically after approximately

camera

five seconds and without pressing

Each time the vehicle is started,

any buttons;

the function returns to the settings

Press the 4 button once to access the

saved at the last engine stop.

settings menu.

Repeatedly press the 4 button to scroll

- by pressing the 5 “-” or 6 “+” buttons

through the setting options until you

on the “X” tab.

reach the desired setting option.

Note: the vertical angle will not be auto-

For safety reasons, carry

Use the 5 “-” and 6 “+” buttons to adjust

matically adjusted according to the ve-

out any adjustments

or activate/deactivate the desired set-

hicle speed if the vertical viewing angle

while the vehicle is sta-

ting.

has been set to the maximum.

tionary.

Adjust the field of vision for the

system and the door mirrors before

driving the vehicle (especially after

changing the vehicle load).

1.131

CarManuals2.co

CAMERA REAR VIEW (4/4)

Special feature

Operating faults

If the warning light C continues to

appear on a black background, please

When the vehicle is reversing, on vehi-

If the system detects an operating fault,

consult an approved dealer.

cles not equipped with the multimedia

the warning light C appears on a black

system, when the rear door is opened

background on the screen 2 or, de-

or incorrectly closed the warning light B

pending on the vehicle, on the display 7

appears on the display 7.

for the reversing camera. This may be

caused by a fault affecting the camera

or screen (clearness, fixed image, de-

layed communication etc.).

1.132

CarManuals2.co

EXTERIOR LIGHTING AND SIGNALS (1/6)

Depending on the vehicle, the dipped

beam headlights will appear automati-

cally after several sweeps of the wind-

screen wiper blades.

Side lights

Dipped beam

headlights

Turn ring 2 until the symbol is

Manual operation

opposite mark 3.

This indicator light on the instrument

Turn ring 2 until the symbol is opposite

panel comes on.

mark 3. This indicator light on the in-

strument panel comes on.

Before driving at night,

check that the electrical

Daytime running lights

Automatic operation

equipment is operating cor-

function

(depending on the vehicle)

rectly and adjust the head-

The daytime running lights come on

Turn ring 2 until the AUTO symbol is op-

light beams (if your vehicle is not

automatically with no action on stalk 1

posite mark 3: with the engine running,

carrying its normal load).➥ 1.139. As

when the engine is started, and they go

the dipped beam headlights switch on

a general precaution, check that

off once the engine is switched off.

or off automatically depending on the

the lights are not obscured (by dirt,

brightness of the light outside, without

mud, snow or objects being trans-

any action on stalk 1.

ported).

1.133

CarManuals2.co

EXTERIOR LIGHTING AND SIGNALS (2/6)

During deactivation of the main beam

The main beam headlights come on au-

headlights, the dipped beam headlights

tomatically if:

return to their original position.

- exterior light is weak;

- no other vehicles or lighting are de-

tected;

Automatic main beam



- the vehicle speed is above approxi-

headlights

mately 25 mph (40 km/h).

Depending on the vehicle, this system

If any of the above conditions are not

switches the main beam headlights on

fulfilled, the system switches to dipped

and off automatically. It uses a camera

beam headlights.

located behind the interior rear-view

Note: make sure the windscreen is not

mirror to detect vehicles that are being

obscured (dirt, mud, snow, condensa-

followed and those coming in the oppo-

tion etc.).

site direction.

To activate automatic main beam

headlights:

Main beam headlights

- turn the ring 2 until the AUTO symbol

With the engine running and

is opposite the mark 3;

the dipped beam headlights lit, push

- push the stalk 1.

stalk 1. This indicator light on the instru-

ment panel comes on.

Warning light 

comes on the in-

The system may encounter difficul-

To return to the dipped headlight posi-

strument panel.

ties under certain conditions, inclu-

tion, pull stalk 1 towards you again.

ding:

- extreme weather conditions (rain,

“Raise lights during driving”

snow, fog, etc.);

function

- obstruction in front of the wind-

(depending on the vehicle)

screen or camera;

When the main beam headlights are

- when a following or oncoming ve-

activated, the “Raise lights during driv-

hicle has weak or hidden lighting;

ing” function improves driver visibil-

- incorrect settings for the front

ity by automatically raising the dipped

headlights;

beam headlight and the main beam

- reflective systems;

headlights.

- ...

1.134

CarManuals2.co

EXTERIOR LIGHTING AND SIGNALS (3/6)

Operating faults

When the message “Check Automatic

Lighting” appears on the instrument

panel, the system is deactivated.

Consult an approved dealer.

Using the portable naviga-

tion system at night in the

windscreen area below the

Automatic main beam

camera may disturb the op-



headlights (continued)

eration of the “automatic main beam

headlights” system (risk of reflection

To deactivate automatic main beam

on the windscreen).

headlights:

- turn ring 2 to a position other than

AUTO;

- pull the stalk 1.

The “automatic main beam

headlights” system should

Warning light 

goes out on the in-

under no circumstances be

strument panel.

used to replace driver atten-

Note: the main beam headlights will be

tion and responsibility with regard

activated upon deactivation of the au-

to vehicle lighting and adapting to

tomatic main beam headlights function.

light, visibility and traffic conditions.

1.135

CarManuals2.co

EXTERIOR LIGHTING AND SIGNALS (4/6)

Welcome and goodbye

Lights-on reminder buzzer

function

If the lights are on after the engine is

(depending on the vehicle)

switched off, a warning beep sounds

Once the function is activated, the day-

when the driver’s door is opened to

time running lights and the rear side

warn you that the lights are still on.

lights will light up automatically upon

detection of the card or when the vehi-

Operating faults

cle is unlocked.

When the message “WARNING: Check

They switch off automatically:

Lighting” with warning light

– approximately one minute after light-

ing up;

is displayed and warning light k

flashes on the instrument panel, this in-

- when starting the engine based on

dicates that there is a lighting fault.

the position of the lighting stalk;

Consult an authorised dealer.

Switching off the lights

- upon locking the vehicle.

The lights will go out automatically

when the engine is switched off, the

Activating/deactivating the function

driver’s door is opened or the vehicle

For activation or deactivation of the ex-

is locked. In this case, the next time

ternal reception, refer to the multimedia

the engine is started the lights will be

manual.

switched back on according to the posi-

tion of the ring 2.

Select “ON” or “OFF”.

Note: if the fog lights are lit, the lights

are not switched off automatically.

1.136

CarManuals2.co

EXTERIOR LIGHTING AND SIGNALS (5/6)

With the engine lights switched off,

the 2 ring in AUTO, pull the lever 1 to-

wards you: the side lights and dipped

beam headlights will switch on for ap-

proximately 30 seconds along with the

and k

warning lights on the

instrument panel.

To increase this duration, you may pull

the stalk up to four times (total time re-

stricted to approximately two minutes).

The message “Follow-me Home for

_ _ _” along with the time the lights will

be on for is displayed on the instrument

panel to confirm this action. You can

then lock your vehicle.

“See-me-home lighting”

To switch off the lights before they go

function

out automatically, turn ring 2 to any po-

sition, then return it to position AUTO.

This function enables you to briefly

switch on the side lights and dipped

beam headlights (e.g. to provide light

when opening a gate).

1.137

CarManuals2.co

EXTERIOR LIGHTING AND SIGNALS (6/6)

Rear fog lights

Cornering lights



(depending on vehicle)

Turn centre ring 4 on the stalk

until the symbol faces mark 3, then re-

When driving in forward gear, with

lease it.

the vehicle speed below approxi-

mately 25 mph (40 km/h), whenever

Operation of the fog lights depends on

the dipped beam headlights are on:

the exterior lighting selected, and an in-

under certain conditions (the steering

dicator light will light up on the instru-

wheel at an angle, the indicator lights

ment panel.

on etc.), when turning a corner one of

Do not forget to switch off the fog lights

the front fog lights will switch on to light

when they are no longer needed, to

the inside of the bend.

avoid inconveniencing other road

When reverse gear is engaged and

users.

the dipped beam headlights are on the

two front fog lights illuminate automati-

Switching off the lights

cally.

Front fog lights

Turn the centre ring 4again until the 3

Note: when shifting from reverse gear

(depending on the vehicle)

symbol is opposite the symbol for the

into forward gear (for example during a

Turn

centre ring

4 on the

fog lights. The corresponding indicator

parking manoeuvre), the two fog lights

stalk 1 until the symbol faces mark 3,

light on the instrument panel goes out.

are activated until the vehicle exceeds

then release it.

approximately 6 mph (10 km/h).

The rear fog lights switch off when the

Operation of the fog lights depends on

exterior lights are switched off.

the exterior lighting position selected,

and an indicator light will light up on the

instrument panel.

When driving in fog or snow, or when transporting objects which are higher than the roof, the headlights do not come on au-

tomatically.

Switching on the fog lights remains the responsibility of the driver: the indicator lights on the instrument panel inform you

whether the fog lights are lit (indicator light on) or not (indicator light not on).

1.138

CarManuals2.co

HEADLIGHT BEAM ADJUSTMENT (1/2)

Examples of positions for adjusting

control A according to the load

Van version

Estate versions

Standard

Long

Standard

chassis

Driver alone or with front

passenger

All seats occupied

Switch A is used to adjust the height of

Driver with passengers and

the headlight beams according to the

luggage (or load) reaching

load.

the maximum permissible

With the dipped beam headlights lit,

all-up weight

press or lift switch A as many times as

is necessary to select the required po-

Driver without passengers

sition on the instrument panel.

and luggage (or load)

Note: depending on the vehicle, when

reaching the maximum

the engine is started, the position se-

permissible all-up weight

lected is displayed on the instrument

panel for approximately 30 seconds

and for 5 seconds each time switch A

The table below gives some examples. In all cases, adjust control A according to

is pressed.

the vehicle load so that the road can be seen and other drivers are not dazzled.

1.139

CarManuals2.co

HEADLIGHT BEAM ADJUSTMENT (2/2)

When driving on the left in a left-

hand drive vehicle (or vice versa),

you must adjust your lights tempo-

rarily during your stay.

Temporary adjustment

Open the bonnet and identify the mark-

ing B next to one of the front headlight

projectors.

Operating principle

Using a screwdriver or similar, turn the

bolt 1 a half turn towards the - symbol to

lower the beams.

Return to the original position once

your trip is over: turn the bolt 1 by a half

turn towards the + symbol to raise the

beams.

1.140

CarManuals2.co

WINDSCREEN WASH, WIPE (1/4)

When activating automatic wiping or

when increasing sensitivity, one sweep

of the blades is performed.

Note:

- the rain sensor is only intended as a

driving aid. In the event of reduced

visibility, the driver should manually

activate the wipers. In foggy weather

or during snowfalls, wiping is not au-

tomatically triggered and remains

under the driver’s control;

- in the event of temperatures below

zero, automatic wiping is not acti-

vated when the vehicle is started. It

is automatically activated as soon as

Your vehicle is fitted with

automatic wiper function

the vehicle exceeds a certain speed

When this position is selected, the

a front windscreen wiper

(approximately 5 mph (8 km/h));

system detects water on the wind-

equipped with a rain sensor

screen and triggers the wipers at a

- do not activate automatic wiping in

The rain sensor is located on the winds-

suitable wiping speed. It is possi-

dry weather;

creen, in front of the interior rear-view

ble to change the triggering thresh-

- fully de-ice the windscreen before

mirror.

old and the time sweeps by turn-

activating automatic wiping;

ing ring 2:

A single sweep

F: minimum sensitivity;

- when washing the vehicle under a

A short push will trigger one sweep

–

G: maximum sensitivity.

roller type car wash, return the ring 1

of the wipers.

to the B position to deactivate auto-

The higher the sensitivity, the quicker

B stop

matic wiping.

the wipers will react and the faster

the wipe.

1.141

CarManuals2.co

WINDSCREEN WASH, WIPE (2/4)

Operating faults

Special note

In the event of a malfunction of the au-

When driving the vehicle, the wiping

tomatic wiping, the wiper is set to inter-

speed slows down whenever the vehi-

mittent wiping. Contact an authorised

cle stops. For example, fast wiping

dealer.

speed will slow to normal wiping speed.

As soon as the vehicle moves off,

The operation of the rain sensor can be

wiping will return to the speed originally

disturbed in the event of:

selected.

- damaged wiper blades; a screen

If stalk 1 is operated, it overrides and

of water or traces left by a blade in

cancels the automatic function.

the sensor’s detection zone may

increase the response time of the

Precautions

automatic wiper, or increase the

wiping frequency;

- In the event of ice, check whether the

- a windscreen with any chip or

blades are stuck to the windscreen

crack level with the sensor, or a

before operating the wiping mecha-

windscreen covered in dust, dirt,

nism. If you activate the wipers while

slow continuous wiping

insects, ice, the use of washing

the blades are stuck down with ice,

wax and water-repellent chemi-

fast continuous wiping

you may risk damaging both the

cals; the automatic wiping will be

blade and the wiper motor.

less sensitive, or even unrespon-

- Do not activate the wipers on a dry

sive.

screen. This will lead to premature

wear or damage to the blades.

1.142

CarManuals2.co

WINDSCREEN WASH, WIPE (3/4)

Specific front wiper position

(service position)

This position enables the blades to be

lifted to remove them from the winds-

creen.

This can be useful:

- to clean the blades;

- to release the blades from the winds-

creen in winter;

- replace the blades ➥ 5.38.

With the ignition on and the engine off,

lift the stalk 1 twice to position A (single

sweep). The blades stop slightly away

from the bonnet.

To return the blades to the lowered po-

sition, with the ignition on, ensure that

the wipers have folded down onto the

windscreen, then move the stalk 1 to

position A (single sweep).

Before switching on the ignition,

In the event of obstacles on the

place the wipers on the windscreen.

windscreen (dirt, snow, ice etc.),

Otherwise, there may a risk of damage

clean the windscreen (including the

to the bonnet or the wipers when they

central area located behind the inte-

are switched on.

rior rear view mirror) before starting

Before any action involving

the wipers (risk of motor overheat-

the windscreen

(washing

ing).

the vehicle,

de-icing,

If an object is preventing a blade

cleaning the windscreen,

from moving, it may stop functio-

etc.) return stalk

1 to position B

ning. Remove the obstacle and

(stop).

reactivate the wiper using the wiper

Risk of injury and/or damage.

stalk.

1.143

CarManuals2.co

WINDSCREEN WASH, WIPE (4/4)

Note: in temperatures below zero, the

washer liquid may freeze on the wind-

screen, reducing visibility. Heat the

windscreen using the demister control

before cleaning.

Efficiency of a wiper blade

Check the condition of the wiper

blades. How long they last depends

on you:

- it must remain clean: clean the

blade and the screen regularly

with soapy water;

- do not use it when the screen is

dry;

Windscreen washer

- free it from the screen when it has

With the ignition on, pull stalk 1 then

not been used for a long time.

release.

In all cases, replace it as soon as

A longer pull will trigger, in addition to

it begins to lose efficiency: approxi-

the windscreen washer, two sweeps

mately once a year. ➥ 5.38.

of the wipers followed, a few seconds

later, by a third.

Precaution for using the

On vehicles fitted with a multimedia

wipers

screen, you can choose to activate or

disable the third sweep of the blades.

- In freezing or snowy weather

➥ 1.119

conditions, clear the screen

When working in the engine

before starting the wipers (risk of

compartment, ensure that

motor overheating);

the windscreen wiper stalk

- ensure that no objects are ob-

is in position B (stop).

structing the travel of the blade.

Risk of injury.

1.144

CarManuals2.co

REAR SCREEN WASHER, WIPER (1/2)

To stop the operation, pivot ring 3 again.

Note:

When washing using a roller type car

wash, return the ring 3 on the stalk 1

to the stop position to deactivate auto-

matic wiping.

Follow usage recommendations.

Efficiency of a wiper blade

Check the condition of the wiper

blades. How long they last depends

on you:

- it must remain clean: clean the

blade and the screen regularly

with soapy water;

- do not use it when the screen is

dry;

Rear screen wiper

- free it from the screen when it has

With the ignition on, rotate the

not been used for a long time.

ring 3 on the lever 1 until the symbol is

In all cases, replace it as soon as

opposite the reference point 2:

it begins to lose efficiency: approxi-

- stop;

mately once a year. ➥ 5.38.

Do not use the wiper arm to open or

- intermittent wiping;

close the tailgate.

The wipers will pause for several

Precaution for using the

seconds between sweeps. Wiping

wipers

frequency varies with vehicle

speed;

Before any action involving

- In freezing or snowy weather

conditions, clear the screen

the rear screen (washing

– slow continuous wiping.

before starting the wipers (risk of

the vehicle, de-icing, clean-

motor overheating);

ing, etc.) return stalk 1 to

- ensure that no objects are ob-

the stop position.

structing the travel of the blade.

Risk of injury and/or damage.

1.145

CarManuals2.co

REAR SCREEN WASHER, WIPER (2/2)

Activation/deactivation of the rear

In the event of obstacles present on the

screen wiper

rear window (dirt, snow, etc.), the wiper

will try to sweep away all the obstacles.

Engaging reverse gear triggers inter-

If an obstacle prevents the blade from

mittent wiping (if the front wipers are in

moving, it can be stopped. Remove the

operation). If your vehicle is equipped

obstacle, wait for around 30 seconds

with a vehicle settings customisation

and reactivate the wiper using the wiper

menu, you can opt to activate or deacti-

stalk.

vate this function. ➥ 1.119.

Precautions

- In the event of ice, check that the

blades are not stuck to the wind-

screen before operating the wipers.

If you activate the wiper while the

blade is blocked by ice, you risk dam-

aging both the blade and the wiping

motor.

Rear screen wash/wipe

- Do not operate the wipers on a dry

With the ignition on, push and

screen. This will lead to the prema-

hold stalk 1, then release.

ture wear or damage to the blades.

Holding the stalk for longer will trigger

(in addition to the windscreen washer)

two sweeps of the wipers followed,

a few seconds later, by a third (drip

wiping function).

When the stalk is released, it returns to

the rear wipe position.

1.146

CarManuals2.co

TANK (1/3)

Filler cap: this is specific.

If you have to replace it,

make sure it is identical to

the original cap. Contact an

approved Dealer.

Never place the cap near a source

of heat or flame.

Do not wash the filler area with a

high-pressure washer.

Useable capacity of the tank: 12 gal

Fuel grade

(54 litres) approximately.

Use a high-grade fuel that complies

with the legislation in force in each

Do not mix even small

With the vehicle unlocked, to open

country and which must comply with

amounts of petrol

(un-

cover 1, press area A then release. The

the specifications given on the label on

leaded or E85) with diesel.

cover 1 opens.

the cover 1. ➥ 6.7.

Do not use ethanol-based

Use the cap holder 2 on the flap 1

fuel if your vehicle is not compatible

during filling to hold the cap 3 in place.

with this fuel.

For details on filling the fuel tank, refer

Do not add reagent to the fuel -

to the information on “Filling with fuel”.

To fill up with fuel, the

otherwise you risk damaging the

To close it, press on the fuel filler flap by

engine must be off

(and

engine ➥ 1.150.

hand, as far as it will go.

not only on standby in the

If you wish to add an additive to the

case of vehicles equipped

fuel, use a product approved by our

with the STOP and START func-

Technical Department. Consult an

tion): you must switch off the ignition

approved dealer.

➥ 2.4, ➥ 2.5.

Fire hazard.

1.147

CarManuals2.co

TANK (2/3)

Filling with fuel

If it is not possible to add at least

1.10 gallons (5 litres) of fuel due to the

With the ignition off, insert the nozzle

fuel level in the tank, drive the vehicle

and insert it fully before turning it on to

until the tank has capacity.

fill the fuel tank (risk of splashing).

Keep the nozzle in this position through-

Petrol version

out the entire filling operation.

Using leaded petrol will damage the

antipollution system and may lead to a

When the pump cuts out automatically

at the end of the filling procedure, a

loss of warranty.

maximum of two further filling attempts

To ensure that the fuel tank is not filled

may be made, as there must be suffi-

with leaded petrol, the fuel tank filler

cient space in the fuel tank to allow for

neck contains a restrictor fitted with a

expansion.

foolproof system which only allows

Make sure that no water enters the fuel

the nozzle for unleaded petrol to be

tank during filling. The cover 1 and its

used (at the pump).

surround must remain clean.

Diesel version

Special case

It is essential to use diesel fuel that

When the vehicle has been stopped for

conforms with the information given on

around three months, you must add

the label inside cover 1.

fuel to prevent damage to the fuel

Petrol version

pump.

It is essential to use unleaded petrol.

To do this, with the ignition off, top-up

The octane rating (RON) must comply

at least 1.10 gallons (5 litres) then start

with the information given on the label

the engine to operate the pump and

on the cover 1. ➥ 6.7.

renew the fuel in the circuit.

After filling, check that the cap and

cover are closed.

Fuel types that conform to European

standards with which the engines of

vehicles sold in Europe are compat-

ible: refer to the table ➥ 6.7.

1.148

CarManuals2.co

TANK (3/3)

No modifications what-

soever are permitted on

any part of the fuel supply

system

(electronic units,

wiring, fuel circuit, injectors, pro-

tective covers, etc.) as this may be

dangerous (unless undertaken by

qualified Network personnel).

Running out of fuel on diesel

Vehicles with card

Persistent fuel odour

versions

With the card in the passenger com-

If you notice a persistent

partment, press the start button 5 with-

Vehicles with key/remote control

fuel odour you should:

out pressing any of the pedals. Wait a

- Turn the ignition key 4 to the “On”

few minutes before starting.

- stop the vehicle as soon as traf-

position ON 2 and wait a few min-

fic conditions allow and switch off

This will enable the fuel circuit to be

utes before starting to allow the fuel

the ignition;

primed. If the engine does not start,

circuit to be primed;

repeat the procedure.

- switch on the hazard warning

- turn the key to position START 3. If

lights and ask your passengers to

If the engine does not start after several

the engine does not start, repeat the

leave the vehicle and stay clear

attempts, please contact an authorised

procedure;

of the traffic;

dealer.

- If the engine does not start after sev-

- contact an approved Dealer.

eral attempts, contact an approved

dealer.

1.149

CarManuals2.co

REAGENT TANK (1/4)

Please ensure that you comply with the

legislation of your country. It is impor-

tant to remember that failure to respect

regulations in force could lead to legal

To fill up with reagent, the engine

action being taken against the vehicle

must be stopped (and not only on

owner.

standby in the case of vehicles

equipped with the function) STOP

Operating principle

and START: you must switch off the

The reagent is intended for diesel en-

ignition ➥ 2.4 ➥ 2.5.

gines fitted with the SCR (selective cat-

alytic reduction) system.

The use of reagents reduces exhaust

emissions by transforming the pollut-

If the “XXX miles (XXX km)

ants into water vapour and nitrogen.

lockout refill AdBlue" mes-

Reagent consumption in real time de-

sage appears, fill the rea-

pends on vehicle usage conditions, the

Filling

gent tank and refer to the

equipment fitted, and driving style.

filling instructions.

Useable capacity of the tank: 3.74

gallons (17 litres) approximately.

Risk of immobilisation of the ve-

Reagent quality

hicle.

With the ignition switched off, open the

Use only reagents which conform

cover A, then unscrew the cap 1.

to standard ISO 22241 and in accord-

ance with the mark on the tank filler

Note: ammonium hydroxide vapour

cap.

may escape from the cap opening

Fuel filler cap: this is a

when the tank temperature is high.

specific type.

If you have to replace it,

make sure it is identical

to the original cap. Contact an ap-

proved Dealer. Do not wash the filler

area with a high pressure washer.

The reagent must not come into contact with eyes or skin. If it does, wash

the affected area with plenty of cold water. If necessary, consult a doctor.

1.150

CarManuals2.co

REAGENT TANK (2/4)

Filling (continued)

If the reagent overflows, or contami-

nates any paintwork, clean the affected

The tank can be filled at the pump. With

area quickly with plenty of cold water

the ignition off, insert the nozzle fully

and a soft cloth.

before activating it to fill the fuel tank

(risk of splashing). Keep the nozzle in

Note: if the reagent crystallises, use a

this position throughout the entire filling

soft sponge.

operation.

In extreme cold weather conditions

After filling the reagent tank, check

When the pump cuts out automatically

that the cap and cover are closed,

In frosty weather conditions, the rea-

at the end of the filling procedure, a

start the engine and WAIT 10 sec-

gent tank should be refilled when the

maximum of two further filling attempts

onds with the vehicle stationary,

may be made, as there must be suffi-



indicator and the message “TOP

engine running before setting off

cient space in the fuel tank to allow for

UP AdBlue before 1200 km” appear on

again.

expansion.

the instrument panel.

If this operation is not carried out,

the filling of the tank will not be

In other filling cases, it is essential to

Special cases

taken into account automatically

read the information shown on the rea-

The reagent fluid freezes below about

until after several dozens of minutes

gent container (e.g. the can or bottle).

-10°C.

of driving.

The message “--- TOP UP AdBlue”

In these conditions, do not attempt filling

Precautions for use

and/or the warning lights will con-

when the fluid is frozen. In the event of

tinue to appear until the filling has

When filling:

needing to top up or fill the tank with re-

been registered by the system.

- handle the reagent with care. They

agent (

on), park the vehicle in a

can damage clothes, shoes, body-

hotter location if possible so that the re-

work components etc.;

agent becomes liquid again. Otherwise,

have a qualified professional top up or

- make sure that no water enters the

fill up with reagent fluid.

fuel tank.

No work whatsoever is

permitted on any part of

the system. To prevent

damage, only qualified per-

sonnel from our network may work

on the system.

1.151

CarManuals2.co

Renault Kangoo (2023 year). Manual in english - page 3
