Renault Kangoo E-Tech (2023 year). Manual in english

OPENING AND CLOSING THE DOORS (6/6)

For your safety, check that

all the vehicle’s doors are

properly closed before

starting the engine.

Driver’s responsibility

when parking or stopping

the vehicle

Never leave an animal,

child or adult who is not self-suffi-

cient alone on your vehicle, even for

a short time.

Tailgate

Opening manually from the inside

They may pose a risk to themselves

or to others by starting the engine,

If it is not possible to unlock the tail-

Opening

activating equipment such as the

gate, it can be unlocked manually from

electric windows or by locking the

Unlock the door, press button 13 and lift

the inside.

doors.

the tailgate. To unlock the doors, ➥ 1.25

Insert a pencil or similar object into

➥ 1.32.

Also, in hot and/or sunny weather,

cavity 15, slide the assembly as shown

please remember that the tempera-

in the diagram and push the tailgate to

Closing

ture inside the passenger compart-

open it.

ment increases very quickly.

Lower the tailgate using the closure

strap 14.

RISK OF DEATH OR SERIOUS

INJURY.

When the tailgate reaches shoulder

height, gently push it shut.

Before opening the tailgate, ensure

that there is sufficient space around

to allow the tailgate to open.

1.49

CarManuals2.co

LOCKING, UNLOCKING THE DOORS (1/3)

If the remote control or,

depending on the vehicle, the

card does not work

In some cases, the radio frequency

remote control or the card may not

work:

- card or radio frequency remote con-

trol battery worn or run flat, vehicle

battery flat etc;

- use of appliances operating on the

same frequency as the card (mobile

phone, etc.);

- vehicle located in a high electromag-

netic radiation zone.

It is then possible:

The card’s built-in key

- to use the radio frequency remote

control or the emergency key inte-

The 2 integrated key can be used to

grated in the card (depending on the

lock or unlock the driver’s door when

vehicle) to unlock the driver’s door;

the card is not working.

- to use the interior door locking/un-

locking control (refer to the following

Access with key 2

pages).

Slide the rear casing

1 downwards

while pressing on zone A.

1.50

CarManuals2.co

LOCKING, UNLOCKING THE DOORS (2/3)

Using the key integrated in

Vehicles with key/remote

Manually locking the front

the card

control

passenger door

- Pull handle 3;

Turn screw 6 with the door open (using

Using the key

the end of the key) and close the door.

- press the cover B on the driver’s

- Pull handle 3;

door down;

This means that the doors are then

- press the cover B on the driver’s

locked from the outside.

- insert the end of the key 2 in the

door down;

notch 4 at the bottom of the cover B;

The doors may then only be opened

- insert the end of the key 5 in the

from the inside or by using the key in

- rotate it upwards to remove the

notch 4 at the bottom of the cover B;

the driver’s door.

cover B;

- rotate it upwards to remove the

- insert the key 2 into the lock of the

cover B;

driver’s door, lock or unlock.

- insert the key 5 into the lock of the

Once you are inside the vehicle, put the

driver’s door, lock or unlock.

key back in its casing in the card.

1.51

CarManuals2.co

LOCKING, UNLOCKING THE DOORS (3/3)

Door and tailgate status

Locking the opening

indicator

elements without the card or

When the ignition is on, the 7 switch

the key

warning light indicates the locking

For example, in the event of a dis-

status of the opening elements:

charged battery or the card or key tem-

porarily not working etc.

- indicator light on, the doors and tail-

gate are locked;

With the engine switched off and a

- indicator light off, the doors and tail-

door or tailgate open, press and hold

gate are unlocked.

the 7 switch for more than five seconds.

When you lock the doors, the indicator

When the door is closed, all the doors

light remains lit and then goes out.

and the tailgate will be locked.

Note: unlocking the vehicle from the

outside is only possible with the card in

the vehicle’s access zone or using the

Interior locking/unlocking

key.

door control

Switch 7 simultaneously controls the

doors and the tailgate.

If a door or the tailgate is open or not

closed properly, the doors and tailgate

lock/unlock quickly.

If transporting an object with the tail-

gate open, you can still lock the doors:

with the engine stopped, press and

Driver’s responsibility

hold switch 7 to lock the other doors.

If you decide to keep the

doors locked when you are

driving, remember that it

may be more difficult for those as-

Never leave your vehicle

sisting you to gain access to the

with the key or card inside.

passenger compartment in the

event of an emergency.

1.52

CarManuals2.co

AUTOMATIC LOCKING WHEN DRIVING

NB: if a door is opened or closed, it

Operating faults

will automatically lock again when the

If you experience an operating fault

vehicle reaches a speed of 6 mph (10

(no central locking, the indicator light 1

km/h).

does not light up when trying to lock the

doors and luggage compartment etc.),

Activating/deactivating the

make sure that central locking has not

been deactivated by mistake and check

function

that the doors and luggage compart-

To activate it: with the vehicle sta-

ment are properly closed. If they are

tionary and the engine on, press the

properly closed, contact an approved

switch 1 until a beep sounds.

dealer.

To deactivate it: with the vehicle sta-

tionary and the engine on, press the

switch 1 until you hear two beeps.

The function can also be activated and

Operating principle

deactivated via the multimedia screen

(depending on the vehicle). ➥ 1.138.

After the vehicle is started, the system

automatically locks the doors when you

are driving at approximately 6 mph (10

km/h) and over.

The door can be unlocked:

- by pressing the central door unlock-

ing switch 1;

- at a standstill, by opening a front

door from inside the vehicle.

Driver’s responsibility

If you decide to keep the

doors locked when you are

driving, remember that it

may be more difficult for those as-

sisting you to gain access to the pas-

senger compartment in the event of

an emergency.

1.53

CarManuals2.co

FRONT HEADRESTS

To raise the headrest

Raise it to its highest position (tilt the

seatback backwards if necessary).

Press button 3 and lift the headrest to

release it.

To refit the headrest

Check that the headrest rods are

clean 2.

Insert the headrest rods into the holes 1

(tilt the seatback backwards if neces-

sary). Lower the headrest until it locks

and press button 3 to adjust to the de-

sired height. Check that each rod 2 on

To raise the headrest

the seatback is securely locked.

Pull the headrest upwards to the de-

sired height. Check that it is correctly

locked.

To lower the headrest

Press button 3 and guide the headrest

down to the desired height. Check that

The headrest is important

the bonnet is correctly locked.

for safety. Ensure that it is in

place and in the correct po-

sition: the top of the head-

rest should be as close as possible

to the top of the head and there must

be a minimal distance between the

head and the headrest A.

1.54

CarManuals2.co

FRONT SEATS (1/7)

To avoid all risk of injury,

ensure that nobody is in

the proximity of the moving

parts. When moving the

seat, make sure that nothing inter-

feres with the moving parts and their

locking.

To move forwards or

To tilt the seatback

For safety reasons, carry

backwards

Depending on the seat, raise the lever 2

out any adjustments

Depending on the seat, lift the bar 1 or

and tilt the seatback until it reaches the

when the vehicle is not

handle 4 to release the seat. Release

position required.

being driven.

the handle at the desired position and

We would advise you not to recline

make sure that it is locked.

the seatbacks too far to ensure that

the effectiveness of the seat belts is

not reduced.

Adjusting the height of the

driver’s seat

Nothing should be placed on the

floor (area in front of driver) as such

Move lever 3 as many times as neces-

objects may slide under the pedal

sary:

during braking manoeuvres, thus

- upwards to raise the seat,

obstructing its use.

– downwards to lower the seat.

After making adjustments,

make sure that the seat-

backs are correctly locked

in place.

1.55

CarManuals2.co

FRONT SEATS (2/7)

Central armrest 5

To adjust the seat’s lumbar

Version with front bench seat

(depending on the vehicle)

position

for two

Lower handle 6 to increase the support

Depending on the vehicle, the central

and lift it to decrease it.

seatbacks may be folded down.

To fold down the seatback

Pull the 7 tab to unlock the seatback

and lower the seatback A.

When lowering, tilt the headrest so that

it is positioned under the centre con-

sole.

To raise the seatback

Lift the seat back and click it into place.

Check that the bonnet is correctly

locked.

1.56

CarManuals2.co

FRONT SEATS (3/7)

Estate version flat position

pull the lever 2 and pull the seatback

The label B on the seat base reminds

down and forwards. While lowering,

you of these instructions.

Depending on the vehicle, the seatback

tilt the headrest 8 to position it under

on the passenger side may be folded

the dashboard;

down onto the seat base to create a flat

press on the seat base to ensure that

position.

it is correctly positioned on the floor;

- Deactivate the front passenger

make sure that there is nothing which

airbag ➥ 1.110 ;

will prevent the seat from moving;

- hold handle 4 and move the seat as

the seat locks automatically. Check

far back as possible;

that the bonnet is correctly locked.

- hold the top of the seatback to lower

it;

Maximum weight on the seat in the

Be sure to hold the seat-

flat position: 80 kg, with the weight

back when placing it in the

evenly distributed.

flat position.

The label B on the seat base re-

Risk of injury.

minds you of these instructions.

1.57

CarManuals2.co

FRONT SEATS (4/7)

Put your hand on the front

Repositioning the seat

of the seat base when repo-

sitioning it.

Make sure that nothing prevents the

seat from moving.

Risk of trapping.

- Pull lever 2 and lift the seatback, en-

suring it is correctly locked;

- reposition the seat base, placing

When the front seatback is

your hand on the front of the seat

in the flat position, you must

base.

deactivate the front passen-

When the rear bench seat is folded

ger airbag.

down, move the front seats carefully.

Risk of serious injury if the airbag is

Remember to reactivate the front pas-

deployed while objects are resting

senger airbag before a passenger oc-

on the seatback in flat position.

cupies the seat ➥ 1.110.

1.58

CarManuals2.co

FRONT SEATS (5/7)

Van version flat position

press on the seat base to ensure

The label F on the side of the seat base

that it is correctly positioned on the

reminds you of these instructions.

The seatback on the passenger side

floor. There is a risk the seatback

may be folded down onto the seat base

being scratched if it is incorrectly po-

to create a flat position.

sitioned;

- Deactivate the front passenger

remove the headrest 9 from the seat;

airbag ➥ 1.110 ;

–

store the headrest 9 in its housing

- check that the floor is clear of any

under the seat base;

objects;

unlock the seatback by lifting

- unlock the seat base by lifting the

handle 10 again and position it hori-

handle 10 and move the seat for-

zontally (movement E).

wards, onto the floor (movement D)

by taking it by the rear section C;

Do not use the headrest

housing 9 to store any other

objects.

Risk of damage to the

seat wiring.

1.59

CarManuals2.co

FRONT SEATS (6/7)

To put the seat back in the comfort po-

sition, proceed in the reverse order.

Check that the headrest is positioned

correctly.

Remember to reactivate the front pas-

senger airbag before a passenger oc-

cupies the seat ➥ 1.110.

The 11 rings located on each side of

the front passenger seat can be used

to secure the load placed on the seat in

the flat-floor position.

When the front seatback is

in the flat position, you must

deactivate the front passen-

ger airbag.

Maximum weight on the seat in the

flat position: 80 kg, with the weight

Risk of serious injury if the airbag is

evenly distributed.

deployed while objects are resting

on the seatback in flat position.

Maximum height limit for objects on

the seat in flat-floor position: 50 cm.

The label F on the side of the seat

base reminds you of these instruc-

The label G on the side of the seat

For your safety, fasten

tions.

base reminds you of these instruc-

down any objects trans-

tions.

ported with the seat in flat-

floor position.

1.60

CarManuals2.co

FRONT SEATS (7/7)

Operating faults

When an operating fault is detected,

the warning light of the 12 switch for the

seat concerned switches-off after ap-

proximately five seconds.

Consult an approved dealer.

Heated seats

With the ignition on:

- pressing the switch 12 on the re-

quired seat for the first time activates

the heating system on high. Both in-

tegrated switch warning lights come

on;

- pressing the switch for the second

time changes the heating to low. One

integrated warning light comes on;

- pressing for the third time turns the

heating off.

1.61

CarManuals2.co

SWIVELLING PARTITION (1/2)

To rotate the partition

- pivot the moving section

90 de-

grees, lock it at point 3 and lower

- Deactivate the front passenger

the catch 2. Ensure that the catch is

airbag ➥ 1.110 ;

locked correctly 2.

- place the seat in the flat position

➥ 1.55 ;

The swivelling section must

- unlock the swivelling section of the

always be locked when the

partition by lifting catches 1 and 2;

vehicle is driven.

- before turning the mobile section,

Risk of injury.

ensure that the 1 and 2 catches are

in the unlocked position;

For your safety, fasten

down any objects trans-

When handling, ensure that the seat

ported with the seat in flat-

belt does not become damaged.

floor position.

1.62

CarManuals2.co

SWIVELLING PARTITION (2/2)

Note: before returning the swivelling

section to its initial position, check that

the locking points 5 are clean.

Before returning the partition to its initial

position, set catches 1 and 2 to the un-

locked position.

Reset the swivelling section to the ini-

tial position, lock the 2 catch and then,

the 1 catch. Make sure that catches 1

When using the pivoted

and 2 are locked correctly.

partition, the protective

net 4 must not be removed

or disassembled, even par-

tially.

Risk of injury due to the projec-

tion of objects from the rear load

area during braking.

1.63

CarManuals2.co

SEAT BELTS (1/6)

Always wear your seat belt when trav-

Adjusting your driving

elling in your vehicle. You must also

position

comply with the legislation of the par-

- Sit well back in your seat (having

ticular country you are in.

first removed your coat or jacket).

Before starting, first adjust your driv-

This is essential to ensure your back

ing position, then ask all occupants

is positioned correctly;

to adjust their seat belts to ensure

- adjust the distance between the

optimum protection.

seat and the pedals. Your seat

should be as far back as possible

while still allowing you to fully de-

press the pedals. The seatback

should be adjusted so that your arms

Make sure that the rear bench seat

are slightly bent when you hold the

is locked in position correctly so that

steering wheel;

the rear seat belts will operate cor-

- adjust the position of your head-

rectly. ➥ 3.35.

rest. For maximum safety, your head

must be as close as possible to the

headrest;

Incorrectly adjusted or

- adjust the height of the seat. This

twisted seat belts may

adjustment allows you to select the

cause injuries in the event

seat position which offers you the

of an accident.

best possible view;

- adjust the position of the steering

Use one seat belt per person,

wheel.

whether child or adult.

Even pregnant women should wear

a seat belt. In this case, ensure that

the lap belt is not exerting too much

pressure on the abdomen, but do

not allow any slack.

1.64

CarManuals2.co

SEAT BELTS (2/6)

Locking

Unwind the belt slowly and smoothly

and ensure that buckle 3 locks into

catch 5 (check that it is locked by pull-

ing on buckle 3).

If the belt jams, allow it to return slightly

before attempting to unwind it again.

If your seat belt is completely jammed,

pull slowly, but firmly, so that just over

3 cm unwinds. Allow it to return slightly

before attempting to unwind it again.

If there is still a problem, contact an ap-

proved dealer.

Unlocking

Adjusting the seat belts

Depending on the vehicle, if the seat is

Press button 4 and the seat belt will be

occupied and one of these seat belts is

Sit with your back firmly against the

rewound by the inertia reel. Guide the

not fastened or becomes unfastened

seatback.

belt.

while the vehicle is moving at a speed

Shoulder strap 1 should be as close as

over approximately 12 mph (20 km/h),

Driver’s seat belt reminder

possible to the base of the neck but not

and, depending on the vehi-

on it.

the ß

warning light flashes and

cle, front passengers’ seat belt re-

a beep sounds for approximately

Lap belt 2 should be worn flat over the

minder

120 seconds.

thighs and against the pelvis.

This appears on the central display A

Note: an object placed on the passen-

The belt should be worn so that it is

when the ignition is switched on and

ger seat may activate the warning light

as close as possible to your body, i.e.:

if the driver’s and/or front passenger’s

in some cases, depending on the ve-

avoid wearing heavy clothing or keep-

seat belt(s) (if the passenger seat is oc-

hicle.

ing bulky objects under the belts, etc.

cupied) is not fastened.

1.65

CarManuals2.co

SEAT BELTS (3/6)

Rear seat belt reminder

(depending on the vehicle)

The 6 or 7 graphic is displayed on the

instrument panel when the ignition is

switched on. This informs the driver of

the fastening status of each of the rear

seat belts every time:

- the ignition is switched on;

- opening a door;

- fastening or unfastening of a rear

seat belt.

Reading the 6 or 7 graphic,

depending on the vehicle:

- indicator green: seatbelt fastened;

When the vehicle speed is less than

When the vehicle speed exceeds

approximately 12 mph (20 km/h), the

12 mph (20 km/h), if one of the rear

- indicator red: seatbelt unfastened;

seat belts is or becomes unfastened

- indicator grey: seat not occupied.

warning light on the central dis-

during the journey:

play appears if a rear seat is occupied

Depending on the vehicle, the ß

and the seat belt is not fastened. It is ac-

- the ß

warning light flashes on

warning light on the central display also

companied by the 6 or 7 graphic which

the central display;

appears when the ignition is switched

appears for approximately 60 seconds

on, if a rear seat is occupied and the

each time one of the rear seat belts is

and

seat belt is not fastened.

fastened or unfastened.

- a beep sounds for approximately 30

or 120 seconds (depending on the

vehicle);

and

- the 6 or 7 graphic is displayed for ap-

proximately 60 or 180 seconds and

the symbol for the seat concerned

changes to red.

1.66

CarManuals2.co

SEAT BELTS (4/6)

Rear seat belt reminder

(continued)

Always make sure that the rear passen-

gers are properly fastened in and that

the number of seat belts indicated cor-

responds to the number of rear seats

occupied.

Note: in some cases, the warnings may

be triggered if an object is placed on

one of the rear seats.

Adjusting the height of the

“Open Sesame” version front

front seat belts

passenger seat belt

Use button 8 to adjust the seat belt

Slowly unwind belt 9.

height so that the shoulder strap is worn

Fasten the sliding buckle 10 into the

as shown previously. Press button 8

catch 11.

and raise or lower the seat belt. Make

sure that the seat belt is locked in posi-

tion correctly after you have adjusted it.

1.67

CarManuals2.co

SEAT BELTS (5/6)

Version with front bench seat

Rear side seat belts 12

Rear centre seat belt

for two

The belts are locked, unlocked and

Unwind belt 13 slowly from its hous-

In normal use conditions, fasten the

adjusted in the same way as the front

ing 14.

centre seat belt when no one is seated

belts.

Click buckle 16 into black catch 15.

there.

Insert the last buckle 17 into the red

catch 18.

To store the seat belt, guide it into the

housing 14 and attach the buckle 16 to

the magnet B.

Check that the rear seat

belts are positioned and

operating correctly each

time the rear bench seat is

moved.

1.68

CarManuals2.co

SEAT BELTS (6/6)

The following information applies to the vehicle’s front and rear seat belts.

- No modification may be made to the component parts of the originally fitted restraint system: seat belts, seats and

their mountings. For special operations (e.g. fitting child seats), contact an authorised dealer.

- Do not use devices which allow any slack in the belts (e.g. clothes pegs, clips, etc.): a seat belt which is worn too

loosely may cause injury in the event of an accident.

- Never wear the shoulder strap under your arm or behind your back.

- Never use the same belt for more than one person and never hold a baby or child on your lap with your seat belt around

them.

- The belt should never be twisted.

- Following an accident, have the seat belts checked and replaced if necessary. Always replace your seat belts as soon as

they show any signs of wear.

- When the rear bench seat is being put back, make sure that the seat belts and buckles are correctly positioned so that they

can be used properly.

- Make sure that the buckle is inserted into the appropriate catch.

- Ensure that no objects are placed in the area around the seat belt catch as they could prevent it from being properly secured.

- Make sure the seat belt catch is properly positioned (it should not be hidden away, crushed or flattened by people or ob-

jects).

1.69

CarManuals2.co

METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (1/6)

Depending on the vehicle, they will con-

- Have the entire restraint

sist of:

system checked following

- seat belt inertia reel pretension-

an accident.

ers;

- No operation whatso-

- central seat belt pretensioners;

ever is permitted on any part

- chest-level load limiters;

of the system

(pretensioners,

airbags, computers, wiring) and

- airbags driver and passenger

the system components must not

front.

be reused on any other vehicle,

These systems are designed to act in-

even if identical.

dependently or together when the vehi-

Only qualified personnel from our

cle is subjected to a frontal impact.

Network may work on the airbags;

Depending on the severity of the

otherwise the system may trigger

impact, the system can trigger:

accidentally and cause injury.

seat belt locking;

Pretensioners

The electric trigger system may

only be tested by a specially

–

the seat belt inertia reel pretensioner

The pretensioners hold the seat belt

trained technician using special

(which engages to correct seat belt

against the body, holding the occupant

equipment.

slack);

more securely against the seat, thus in-

When the vehicle is scrapped,

lap seat belt pretensioners to hold

creasing the seat belt’s efficiency.

contact an approved dealer for

the occupant in their seat;

In the event of a severe frontal impact

disposal of the pretensioner and

the front airbag.

and if the ignition is switched on, the

airbags gas generators.

system may engage the following de-

pending on the force of the impact:

- the seat belt inertia reel preten-

sioner 1 which instantly retracts the

seat belt;

- the lap seat belt inertia reel preten-

sioner 2 on the front seats.

1.70

CarManuals2.co

METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (2/6)

Load limiter

driver and passenger front

Above a certain severity of impact, this

Airbags

mechanism is used to limit the force of

Fitted to the driver and passenger

the belt against the body so that it is at

sides.

an acceptable level.

A symbol on the lower section of the

windscreen indicates if this equipment

is present (depending on the vehicle).

Each airbag system consists of:

- an airbag and gas generator fitted on

the steering wheel for the driver and

in the dashboard for the passenger;

- an electronic unit for system monitor-

ing which controls the gas generator

electrical trigger system;

- remote sensors;

- a single warning light å

on the

instrument panel.

The airbag system uses py-

rotechnic principles. This

explains why, when the

airbag inflates, it will gener-

ate heat, produce smoke (this does

not mean that a fire is about to start)

and make a banging noise. In a situ-

ation where an airbag is required, it

will inflate immediately and this may

cause some minor, superficial graz-

ing to the skin or other problems.

1.71

CarManuals2.co

METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (3/6)

Operating faults

This warning light comes on

when the engine is started and then

goes out after approximately three sec-

onds.

If it does not come on when the ignition

is switched on or if it stays on, there is a

fault in the system.

Contact your approved Dealer as soon

as possible.

Your protection will be reduced until this

fault is rectified.

Operation

This system is only operational when

the ignition is switched on.

In a severe frontal impact, the airbags

inflate rapidly, cushioning the impact

of the driver's head and chest against

the steering wheel and of the front pas-

senger against the dashboard. The air

bags then deflate immediately so that

the passengers are not in any way hin-

dered from leaving the vehicle.

1.72

CarManuals2.co

METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (4/6)

The following conditions will trigger

In a frontal impact with another vehi-

In a side impact with another vehicle

the pretensioners or airbags.

cle of an equivalent or higher category,

of an equivalent or higher category, at

with an impact area equal to or greater

an impact speed equal to or greater

In a frontal impact against a rigid

than 40%, where the speed of both ve-

than 31 mph (50 km/h).

(non-deformable) surface at an impact

hicles is equal to or greater than

speed equal to or greater than 16 mph

25 mph (40 km/h).

(25 km/h).

1.73

CarManuals2.co

METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (5/6)

In the following examples, the pre-

In the following examples, there is a

- side impact, affecting the front of the

tensioners or the airbags could op-

risk that pretensioners orairbags may

vehicle;

erate:

not be triggered:

- frontal impact, under the tail of a

- impact under vehicle such as pave-

- rear impact, however severe;

lorry;

ment;

– the vehicle overturning;

- frontal impact against an obstacle

- potholes;

with a sharp angle;

- drop or hard landing;

- ...

- stones;

– ...

1.74

CarManuals2.co

METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (6/6)

All of the warnings below are given so that the airbag is not obstructed in any way when it is inflated and also to prevent

the risk of serious injuries caused by items which may be dislodged when it inflates.

Warnings concerning the driver’s airbag

- Do not modify the steering wheel or the steering wheel boss.

- Do not cover the steering wheel boss under any circumstances.

- Do not attach any objects (badge, logo, clock, telephone holder, etc.) to the steering wheel boss.

- The steering wheel must not be removed (except by qualified personnel from our Network).

- Do not sit too close to the steering wheel when driving: sit with your arms slightly bent (see “Adjusting your driving position”

➥ 1.64). This will allow sufficient space for the airbag to deploy correctly and be fully effective.

Warnings concerning the passenger airbag

- Do not attach or glue any objects (badge, logo, clock, telephone holder, etc.) to the dashboard on or near the airbag.

- Do not place anything between the dashboard and the passenger (pet, umbrella, walking stick, parcels, etc.).

- The passenger must not put his or her feet on the dashboard or seat as there is a risk that serious injuries may occur. In

general, parts of the body should be kept away from the dashboard (knees, hands, head, etc.).

- The devices in addition to the front passenger seat belt should be reactivated as soon as a child seat is removed, to ensure

the protection of the passenger in the event of an impact.

A REAR-FACING CHILD SEAT MUST NOT BE FITTED TO THE FRONT PASSENGER SEAT UNLESS THE

RESTRAINT SYSTEMS IN ADDITION TO THE FRONT PASSENGER SEATBELT ARE DEACTIVATED ➥ 1.110.

1.75

CarManuals2.co

METHODS OF RESTRAINT IN ADDITION TO THE REAR SEAT BELTS

Depending on the vehicle, they will con-

- Have the entire restraint

sist of:

system checked following

- side seat belt inertia reel preten-

an accident.

sioners;

- No operation whatso-

- chest force limiters.

ever is permitted on any part

These systems are designed to act in-

of the system

(pretensioners,

dependently or together when the vehi-

airbags, computers, wiring) and

cle is subjected to a frontal impact.

the system components must not

be reused on any other vehicle,

Depending on the severity of the

even if identical.

impact, the system can trigger:

Only qualified personnel from our

- seat belt locking;

Network may work on the airbags;

- the seat belt inertia reel pretensioner

otherwise the system may trigger

(which engages to correct seat belt

accidentally and cause injury.

slack).

Side seat belt pretensioners

The electric trigger system may

only be tested by a specially

The pretensioners hold the seat belt

Force limiter

trained technician using special

against the body, holding the occupant

equipment.

Above a certain severity of impact, this

more securely against the seat, thus in-

When the vehicle is scrapped,

mechanism is used to limit the force of

creasing the seat belt’s efficiency.

contact an approved dealer for

the belt against the body so that it is at

With the ignition on, following a signif-

disposal of the pretensioner and

an acceptable level.

icant frontal impact and depending on

airbags gas generators.

the severity of the impact, the system

may trigger the seat belt inertia reel

pretensioner 1, which instantly retracts

the seat belt.

1.76

CarManuals2.co

SIDE PROTECTION DEVICES

Side Airbag

This airbag may be fitted to each of the

front seats and is activated at the sides

of the seats (door side) to protect the

occupants in the event of a severe side

impact.

Curtain Airbag

This is an airbag fitted (depending on

the vehicle) along the upper sides of

the vehicle - they inflate along the front

and rear door side windows to protect

the passengers in the event of a severe

side impact.

Warning relating to the side airbag

- Fitting seat covers: seats equipped with an airbag require covers spe-

cifically designed for your vehicle. Contact an approved dealer to find

out if these covers are available. The use of any covers other than those

designed for your vehicle (including those designed for another vehicle) may

affect the operation of the airbag and reduce your protection.

Do not place any accessories, objects or even pets between the seatback, the

door and the internal fittings. Do not cover the seatback with any items such as

clothes or accessories. This may prevent the air bag from operating correctly

or cause injury when the airbag is deployed.

No work or modification whatsoever may be carried out on the seat or internal

fittings, except by qualified personnel from an approved Dealer.

This airbag operates through slits in the front seatbacks (door side): never

insert any objects in these slits.

1.77

CarManuals2.co

ADDITIONAL METHODS OF RESTRAINT

All of the warnings below are given so that the airbag is not obstructed in any way when it is inflated and also to prevent

the risk of serious injuries caused by items which may be dislodged when it inflates.

The airbag is designed to complement the action of the seat belt. Both the airbag and the seat belt are integral parts

of the same protection system. It is therefore essential to wear seat belts at all times. If seat belts are not worn, the oc-

cupants are exposed to the risk of serious injury in the event of an accident. It may also increase the risk of minor su-

perficial injuries occurring when the airbag is deployed, although such minor injuries are always possible with airbags.

If the vehicle should overturn or in the event of a rear impact, however severe, the pretensioners and airbags are not always

triggered. Impacts to the underside of the vehicle, e.g. from pavements, potholes or stones, can all trigger these systems.

- No work or modification whatsoever may be carried out on any part of the airbag system (airbags, pretensioners, computer,

wiring harness, etc.), except by qualified Network personnel.

- To ensure that the system is in good working order and to avoid accidental triggering of the system which may cause injury,

only qualified Network personnel may work on the airbag system.

- As a safety precaution, have the airbag system checked if your vehicle has been involved in an accident, or is stolen or

broken into.

- When selling or lending the vehicle, inform the user of these points and hand over this handbook with the vehicle.

- When scrapping your vehicle, contact your approved Dealer for disposal of the gas generator(s).

1.78

CarManuals2.co

CHILD SAFETY: General information (1/2)

Carrying children

Please ensure that you comply with the

legislation of your country.

Children, and adults, must be correctly

seated and strapped in for all journeys.

The children being carried in your vehi-

cle are your responsibility.

Driver’s responsibility

A child is not a miniature adult. Children

when parking or stopping

are at risk of specific injuries as their

the vehicle

muscles and bones have not yet fin-

ished growing. The seat belt alone

Never leave an animal,

would not provide suitable protection.

child or adult who is not self-suffi-

Use an approved child seat and ensure

cient alone on your vehicle, even for

you use it correctly.

a short time.

A collision at 30 mph (50

They may pose a risk to themselves

km/h) is the same as fall-

or to others by starting the engine,

ing a distance of 10 metres.

activating equipment such as the

Transporting a child without

electric windows or by locking the

a restraint is the equivalent of allow-

doors.

ing him or her to play on a fourth-

floor balcony without railings.

Also, in hot and/or sunny weather,

please remember that the tempera-

Never travel with a child held in your

ture inside the passenger compart-

arms. In the event of an accident,

ment increases very quickly.

you will not be able to keep hold of

the child, even if you yourself are

RISK OF DEATH OR SERIOUS

wearing a seat belt.

INJURY.

If your vehicle has been involved in

a road accident, replace the child

To prevent the sliding side

seat and have the seat belts and

doors from being opened,

ISOFIX anchorage points checked.

use the “Child lock” feature

➥ 1.44.

1.79

CarManuals2.co

CHILD SAFETY: General information (2/2)

Using a child seat

Before fitting a child seat, read the

manual and respect its instructions. If

The level of protection offered by the

you experience any difficulties during

child seat depends on its ability to re-

installation, contact the manufacturer

strain your child and on its installation.

of the equipment. Keep the instructions

Incorrect installation compromises the

with the seat.

protection it offers the child in the event

of harsh braking or an impact.

Before purchasing a child seat, check

that it complies with the regulations for

the country you are in and that it can

be fitted in your vehicle. Consult an ap-

proved dealer to find out which seats

are recommended for your vehicle.

The regulations on transporting chil-

dren are specific to each country.

Never leave a child unat-

tended in the vehicle.

The use of a child seat during transport

depends on the age and/or the size

Check that your child is

and/or weight of the child.

always strapped in and that

the belt or safety harness used is

For children who do not need to be

Set a good example by always fas-

correctly set and adjusted. Avoid

transported to a child seat, make sure

tening your seat belt and teaching

wearing bulky clothing which could

that the seat belt is correctly adjusted

your child:

cause the belts to slacken.

and fastened.

- to strap themselves in correctly;

Never let your child put their head or

In all cases, you must comply with the

- to always get in and out of the car

arms out of the window.

regulations of the particular country you

at the kerb, away from busy traf-

are in.

fic.

Check that the child is in the correct

position for the entire journey, espe-

Do not use a second-hand child

cially if asleep.

seat or one without an instruction

manual.

Check that there are no objects in

the vicinity of the child seat which

could impede its operation.

1.80

CarManuals2.co

CHILD SAFETY: choosing a child seat

Rear-facing child seats

Forward-facing child seats

Booster cushions

A baby’s head is, proportionally, heavier

Up to 18 kg or 4 years, the child may

From 15 kg or 4 years, the child can

than that of an adult and its neck is very

travel on a forward-facing seat.

travel using a booster seat, which will

fragile. Transport the child in this po-

enable the seat belt to be adapted to

Choose your seat according the child’s

sition for as long as possible (until the

suit his size and shape. The booster

size: their head and abdomen are the

age of 2 at the very least). It supports

seat cushion must be fitted with guides

areas which must be most protected. A

both the head and the neck.

to position the seat belt on the child’s

forward-facing child seat which is firmly

thighs rather than the stomach. It is

Choose a bucket type seat for best side

attached to the vehicle will reduce the

recommended that you use a seat-

protection and change it as soon as the

risk of impact to the head. Ensure your

back which can be adjusted in terms

child’s head is higher than the shell.

child travels in a forward-facing seat

of height to position the seat belt in the

with a harness for as long as their size

centre of the shoulder. It must never

permits.

rest on the neck or on the arm.

Choose a bucket type seat for optimum

side protection.

1.81

CarManuals2.co

CHILD SAFETY: choosing a child seat mounting (1/3)

There are two ways of attaching child

Attachment via the seat belt

seats: via the seat belt or using the

The seat belt must be adjusted to

ISOFIX system.

ensure that it is effective in the event of

harsh braking or an impact.

Ensure that the strap paths indicated

by the child seat manufacturer are re-

spected.

Always check that the seat belt is cor-

rectly fastened by pulling it up, then

pulling it out fully whilst pressing on the

child seat.

Check that the seat is correctly held by

moving it from side to side and back

to front: the seat should remain firmly

fixed.

Check that the child seat has not been

installed at an angle and that it is not

The seat belt must never

resting against a window.

be twisted or the tension

relieved. Never pass the

shoulder strap under the

arm or behind the back.

Check that the seat belt has not

been damaged by sharp edges.

If the seat belt does not operate nor-

mally, it will not protect the child.

Do not use the child seat

Consult an approved dealer. Do not

if it may unfasten the seat

use this seat until the seat belt has

belt restraining it: the base

been repaired.

of the seat must not rest on

the buckle and/or catch of the seat

belt.

1.82

CarManuals2.co

CHILD SAFETY: choosing a child seat mounting (2/3)

Attachment using the ISOFIX

Attach the child seat with the ISOFIX

system

locks, if these are provided. The ISOFIX

system allows quick, easy, safe fitting.

Approved child seats ISOFIX are stand-

ardised in accordance with current reg-

The ISOFIX system consists of 2 rings

ulations if any of the four cases below

and, in some cases, a third ring.

applies:

- ISOFIXuniversal 3-point forward-fac-

ing seat;

- ISOFIXsemi-universal 2-point seat;

- specific;

- i-Size which has either:

- a strap which attaches to the third

ring of the seat concerned;

The ISOFIX anchorage

- or a strut that rests on the vehi-

points have been exclu-

cle floor, compatible with the ap-

sively designed for child

proved seat i-Size, the role of

seats with the ISOFIX

The two rings 1 are located between the

which is to prevent the child seat

system. Never fit a different type of

seatback and the seat base of the seat

from moving in the event of a col-

child seat, seat belt or other objects

lision.

and are identified by a 

symbol.

to these anchorage points.

In the latter three cases check that your

Check that nothing is obstructing

child seat can be installed by consulting

the anchorage points.

the list of compatible vehicles.

If your vehicle has been involved in

a road accident, have the ISOFIX

anchorage points checked and re-

place your child seat.

No modifications may be

made to the component

Before using an ISOFIX child seat that you purchased for another vehi-

parts of the restraint system

cle, check that its installation is authorised. Consult the list of vehicles

(seat belts, ISOFIX and

which can be fitted with the seat from the equipment manufacturer.

seats and their mountings) originally

fitted.

1.83

CarManuals2.co

CHILD SAFETY: choosing a child seat mounting (3/3)

The ISOFIX anchorage

points have been exclu-

sively designed for child

seats with the ISOFIX

system. Never fit a different type of

child seat, seat belt or other objects

to these anchorage points.

Check that nothing is obstructing

the anchorage points.

Attachment using the ISOFIX

Front passenger seat

If your vehicle has been involved in

system (continued)

a road accident, have the ISOFIX

If the front passenger seat is equipped,

The third ring 4 is used to attach the

attach the hook 3 of the upper strap 2

anchorage points checked and re-

upper strap 2 on some child seats.

on the ring 4 marked by the  symbol.

place your child seat.

Rear seats

All seats

The upper strap 2 should be positioned

Pull the upper strap 2 so that the back

between the seatback and the rear

of the child seat comes into contact with

parcel shelf. To do so, remove the rear

the back of the vehicle seat.

parcel shelf ➥ 3.38.

Check that the seatback

Attach the 3 hook on one of the 4 rings

of the forward-facing child

marked with the 

symbol.

seat is in contact with the

back of the vehicle seat.

In this case, the child seat may not

always rest on the base of the vehi-

cle seat.

1.84

CarManuals2.co

CHILD SAFETY: fitting a child seat: general information (1/2)

Some seats are not suitable for fitting

The types of child seat indicated may

After installing the child seat, when this

child seats. The diagram on the follow-

not be available. Before using a differ-

is possible, you can move the vehi-

ing page shows you how to attach a

ent child seat, check with the manufac-

cle seat forward if necessary (so as to

child seat.

turer that it can be fitted.

leave enough space in the rear seats

for passengers or other child seats).

In the front seat

For a rear-facing child seat, do not let

The laws concerning children travel-

it touch the dashboard or move it to the

ling in the front passenger seat differ in

furthest forward position.

every country. Consult the legislation in

Do not change other settings after in-

Fit the child seat in a rear

force and follow the indications on the

stalling the child seat.

seat wherever possible.

diagram on the following page.

Make sure the child seat or

Before fitting a child seat in this seat (if

the child’s feet do not pre-

authorised):

vent the front seat from locking cor-

- lower the seat belt as far as possible;

rectly ➥ 1.55.

- move the seat as far back as possi-

Check that when installing the child

ble;

seat in the vehicle it is not at risk of

- gently tilt the seatback away from

coming loose from its base.

vertical (approximately 25°);

If you have to remove the headrest,

- on equipped vehicles, raise the seat

check that it is correctly stored so

base as far as possible.

that it does not come loose under

harsh braking or impact.

Always fully raise the seat headrest so

that it does not interfere with the child

Always attach the child seat to the

seat ➥ 1.54.

vehicle even if it is not in use so that

it does not come loose under harsh

braking or impact.

RISK

DEATH

SERIOUS INJURY: before

fitting a rear-facing child

seat in this seat, make sure

that the front passenger airbag has

been deactivated. ➥ 1.110.

1.85

CarManuals2.co

CHILD SAFETY: fitting a child seat: general information (2/2)

In the rear side seat

Always remove the headrest from the

In rear centre seat

rear seat on which the child seat is

A carrycot can be installed across the

Check that the belt is suitable for se-

positioned. ➥ 3.34. If necessary, posi-

vehicle and will take up at least two

curing your child seat. Consult an ap-

tion the rear seat as far back as pos-

seats. Position the child with his or her

proved dealer.

sible. This must be done before fitting

feet nearest the door.

the child seat. Check that the child seat

Move the front seat as far forward as

is resting against the back of the rear

possible to install a rear-facing child

seat.

seat, then move back the seat in front

as far as it will go, although without al-

lowing it to come into contact with the

child seat.

For the safety of the child in the for-

ward-facing position:

- move the relevant seat backwards

as far as possible;

Fitting a seat ISOFIX in

An ISOFIX or a child seat

- move the seat in front of the child

the rear-left seat means

with a floor support must

forwards, and set the position of the

the middle seat cannot be

never be installed on the

seatback to avoid contact between

used. The central seat belt

rear centre seat.

the seat and the child’s legs.

will no longer be either accessible or

RISK OF DEATH OR SERIOUS

useable.

INJURY.

When fitting a child seat

Fit the child seat in a rear

(Group 2 or 3 booster seat),

seat wherever possible.

check that the seat belts

To install an ISOFIX seat in

Ensure that the child seat

operate

(wind) correctly

this seat, unbuckle the seat

or the child’s feet do not

➥ 1.64. If necessary, adjust the posi-

belt by hand before engaging the

prevent the front seat from

tion of the vehicle seat.

bolts.

locking correctly. ➥ 3.35.

1.86

CarManuals2.co

CHILD SEATS: attachment by seat belt (1/14)

"Open Sesame” van version

Using a child safety system

which is not approved for

this vehicle will not correctly

protect the baby or child.

Child seat attached using the belt

They risk serious or even fatal injury.



Seat enabling only a forward-facing seat with “Universal” approval to be

fitted.

Seat not suitable for fitting child seats.

Check the status of the airbag before fitting a child seat or allowing a passen-

RISK OF DEATH OR

ger to use the seat.

SERIOUS INJURY: never

install a rear-facing child

seat on the front passenger

seat.

1.87

CarManuals2.co

CHILD SEATS: attachment by seat belt (2/14)

The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-

tions in force are respected.

“Open Sesame” van version

Front passenger seat

Type of child seat

Weight of the child

airbag activated on

without passenger airbag

passenger side (1)

or with it deactivated (1)

Carrycot fitted across the ve-

hicle

< 10 kg

Group 0

Rear-facing shell seat

< 13 kg

Groups 0 or 0 +

Shell seat/rear-facing seat

< 13 kg

Groups 0+ and 1

9 to 18 kg

Forward-facing seat

9 to 18 kg

UF (2)

Group 1

Booster seat

15 to 25 kg

UF (2)

Groups 2 and 3

22 to 36 kg

Refer to the “Child safety equipment” booklet (available from the network) to choose a seat suited to your child and rec-

ommended for your vehicle.

X = Seat not suitable for fitting child seats of this type.

UF = Seat which enables only a forward-facing seat with "Universal" approval to be fitted: check if it can be fitted.

(2) Depending on the vehicle, raise the seat to the maximum and position it as far back as possible, tilting the seatback slightly

(approximately 25°).

(1) RISK OF DEATH OR SERIOUS INJURY: never install a rear-facing child seat on the front passenger seat.

1.88

CarManuals2.co

CHILD SEATS: attachment by seat belt (3/14)

Van version with foldable passenger seat

Using a child safety system

which is not approved for

this vehicle will not correctly

Child seat attached using the belt

protect the baby or child.

They risk serious or even fatal injury.

Seat which allows a child seat with “Universal” approval to be attached by a

seat belt.

Seat not suitable for fitting child seats.

Check the status of the airbag before fitting a child seat or allowing a passen-

RISK OF DEATH OR

ger to use the seat.

SERIOUS INJURY: before

fitting a rear-facing child

seat in this seat, make sure

that the front passenger airbag has

been deactivated. ➥ 000.

1.89

CarManuals2.co

CHILD SEATS: attachment by seat belt (4/14)

The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-

tions in force are respected.

Van version with foldable passenger seat

Front passenger seat

Type of child seat

Weight of the child

airbag activated on

without passenger airbag or

passenger side (1)

with it deactivated (2)

Carrycot fitted across the ve-

hicle

< 10 kg

Group 0

Rear-facing shell seat

< 13 kg

U (2)

Groups 0 or 0 +

Shell seat/rear-facing seat

< 13 kg

U (2)

Groups 0+ and 1

9 to 18 kg

Forward-facing seat

9 to 18 kg

U (1)

Group 1

Booster seat

15 to 25 kg

U (1)

Groups 2 and 3

22 to 36 kg

Refer to the “Child safety equipment” booklet (available from the network) to choose a seat suited to your child and rec-

ommended for your vehicle.

X = Seat not suitable for fitting child seats of this type.

U = Seat allowing a child seat with “Universal” approval to be attached by the seat belt; check that it can be fitted.

(1) RISK OF DEATH OR SERIOUS INJURY: never install a rear-facing child seat on the front passenger seat if the

vehicle is equipped with a passenger airbag that cannot be deactivated.

(2) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat on the front passenger seat, ensure

that the airbag has been deactivated ➥ 1.110.

1.90

CarManuals2.co

CHILD SEATS: attachment by seat belt (5/14)

Van version with unfoldable passenger seat

Using a child safety system

which is not approved for

this vehicle will not correctly

protect the baby or child.

Child seat attached using the belt

They risk serious or even fatal injury.

Seat which allows a child seat with “Universal” approval to be attached by a

seat belt.

Seat not suitable for fitting child seats.

Check the status of the airbag before fitting a child seat or allowing a passen-

RISK OF DEATH OR

ger to use the seat.

SERIOUS INJURY: before

fitting a rear-facing child

seat in this seat, make sure

that the front passenger airbag has

been deactivated. ➥ 000.

1.91

CarManuals2.co

CHILD SEATS: attachment by seat belt (6/14)

The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-

tions in force are respected.

Van version with unfoldable passenger seat

Front passenger seat

Type of child seat

Weight of the child

airbag activated on

without passenger airbag

passenger side (1)

or with it deactivated

Carrycot fitted across the ve-

hicle

< 10 kg

Group 0

Rear-facing shell seat

< 13 kg

U (2) (3)

Groups 0 or 0 +

Shell seat/rear-facing seat

< 13 kg

U (2) (3)

Groups 0+ and 1

9 to 18 kg

Forward-facing seat

9 to 18 kg

U (3)

Group 1

Booster seat

15 to 25 kg

U (3)

Groups 2 and 3

22 to 36 kg

Refer to the “Child safety equipment” booklet (available from the network) to choose a seat suited to your child and rec-

ommended for your vehicle.

X = Seat not suitable for fitting child seats of this type.

U = Seat allowing a child seat with “Universal” approval to be attached by the seat belt; check that it can be fitted.

(3) Depending on the vehicle, raise the seat to the maximum and position it as far back as possible, tilting the seatback slightly

(approximately 25°).

(1) RISK OF DEATH OR SERIOUS INJURY: never install a rear-facing child seat on the front passenger seat if the

vehicle is equipped with a passenger airbag that cannot be deactivated.

(2) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat on the front passenger seat, ensure

that the airbag has been deactivated ➥ 1.110.

1.92

CarManuals2.co

CHILD SEATS: attachment by seat belt (7/14)

Van version with three front seats

Using a child safety system

which is not approved for

this vehicle will not correctly

protect the baby or child.

They risk serious or even fatal injury.

Child seat attached using the belt

Seat which allows a child seat with “Universal” approval to be attached by a

seat belt.

Seat not suitable for fitting child seats.

Check the status of the airbag before fitting a child seat or allowing a passen-

RISK OF DEATH OR

ger to use the seat.

SERIOUS INJURY: before

fitting a rear-facing child

seat in this seat, make sure

that the front passenger airbag has

been deactivated. ➥ 000.

1.93

CarManuals2.co

CHILD SEATS: attachment by seat belt (8/14)

The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-

tions in force are respected.

Van version with three front seats

Side front passenger seat

airbag activated

Central front

Type of child seat

Weight of the child

without passenger airbag

on passenger

passenger seat

or with it deactivated

side (1)

Carrycot fitted across the ve-

hicle

< 10 kg

Group 0

Rear-facing shell seat

< 13 kg

U (2)

Groups 0 or 0 +

Shell seat/rear-facing seat

< 13 kg

U (2)

Groups 0+ and 1

9 to 18 kg

Forward-facing seat

9 to 18 kg

Group 1

Booster seat

15 to 25 kg

Groups 2 and 3

22 to 36 kg

Refer to the “Child safety equipment” booklet (available from the network) to choose a seat suited to your child and rec-

ommended for your vehicle.

X = Seat not suitable for fitting child seats of this type.

U = Seat allowing a child seat with “Universal” approval to be attached by the seat belt; check that it can be fitted.

(1) RISK OF DEATH OR SERIOUS INJURY: never install a rear-facing child seat on the front passenger seat if the

vehicle is equipped with a passenger airbag that cannot be deactivated.

(2) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat on the front passenger seat, ensure

that the airbag has been deactivated ➥ 1.110.

1.94

CarManuals2.co

CHILD SEATS: attachment by seat belt (9/14)

Estate version with unfoldable front passenger seat

Using a child safety system

which is not approved for

this vehicle will not correctly

Child seat attached using the belt

protect the baby or child.

They risk serious or even fatal injury.

Seat which allows a child seat with “Universal” approval to be attached by a

seat belt.

Seat not suitable for fitting child seats.

Check the status of the airbag before fitting a child seat or allowing a passen-

RISK OF DEATH OR

ger to use the seat.

SERIOUS INJURY: before

fitting a rear-facing child

seat in this seat, make sure

that the front passenger airbag has

been deactivated. ➥ 000.

1.95

CarManuals2.co

CHILD SEATS: attachment by seat belt (10/14)

The table below summarises the information already shown on the diagram on the previous page, to ensure the regula-

tions in force are respected.

Estate version with unfoldable front passenger seat

Front passenger seat

Rear seats

Weight of

Type of child seat

without passenger

the child

airbag activated on

airbag or with it

Side seats

Centre seat

passenger side (1)

deactivated (2) (3)

Carrycot

fitted

across the vehicle

< 10 kg

U (4)

Group 0

Rear-facing shell

seat

< 13 kg

U (5)

U (5) (7)

Groups 0 or 0 +

Shell seat/rear-facing

< 13 kg

seat

U (5)

U (5) (7)

9 to 18 kg

Groups 0+ and 1

Forward-facing seat

9 to 18 kg

U (3)

U (6)

U (6) (7)

Group 1

Booster seat

15 to 25 kg

U (3)

U (6)

Groups 2 and 3

22 to 36 kg

(1) RISK OF DEATH OR SERIOUS INJURY: never install a rear-facing child seat on the front passenger seat if the

vehicle is equipped with a passenger airbag that cannot be deactivated.

(2) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat on the front passenger seat, ensure

that the airbag has been deactivated ➥ 1.110.

1.96

CarManuals2.co

CHILD SEATS: attachment by seat belt (11/14)

Refer to the “Child safety equipment” booklet (available from the network) to choose a seat suited to your child and rec-

ommended for your vehicle.

X = Seat not suitable for fitting child seats of this type.

U = Seat allowing a child seat with “Universal” approval to be attached by the seat belt; check that it can be fitted.

(3) Raise the seat to the maximum and position it as far back as possible, tilting the seatback slightly (approximately 25°).

(4) A carrycot can be installed across the vehicle and will take up at least two seats. Position the child with his or her feet nearest

the door.

(5) In order to install a rear-facing child seat, move the front seat as far forward as possible, then move the front seat back as far

as it will go, without allowing it to come into contact with the child seat.

(6) In all situations, remove the rear headrest of the seat on which the child seat is positioned. This must be done before fitting the

child seat. ➥ 3.34. Move the seat in front of the child forwards, move the seatback forward to avoid contact between the seat

and the child’s legs.

(7) RISK OF DEATH OR SERIOUS INJURY: a child seat with a floor support must never be fitted on the rear centre

seat.

1.97

CarManuals2.co

CHILD SEATS: attachment by seat belt (12/14)

The table below summarises the information already shown on the diagram on the next page, to ensure the regulations

in force are respected.

Estate version with foldable front passenger seat

Front passenger seat

Rear seats

Weight of

Type of child seat

without passenger

the child

airbag activated on

airbag or with it

Side seats (8)

Centre seat

passenger side (1)

deactivated (2) (3)

Carrycot

fitted

across the vehicle

< 10 kg

U (4)

Group 0

Rear-facing shell

seat

< 13 kg

U (5)

U (5) (7)

Groups 0 or 0 +

Shell seat/rear-facing

< 13 kg

seat

U (5)

U (5) (7)

9 to 18 kg

Groups 0+ and 1

Forward-facing seat

9 to 18 kg

U (3)

U (6)

U (6) (7)

Group 1

Booster seat

15 to 25 kg

U (3)

U (6)

Groups 2 and 3

22 to 36 kg

(1) RISK OF DEATH OR SERIOUS INJURY: never install a rear-facing child seat on the front passenger seat if the

vehicle is equipped with a passenger airbag that cannot be deactivated.

(2) RISK OF DEATH OR SERIOUS INJURY: before fitting a rear-facing child seat on the front passenger seat, ensure

that the airbag has been deactivated ➥ 1.110.

1.98

CarManuals2.co

Renault Kangoo E-Tech (2023 year). Manual in english - page 2
