Renault Clio (2023 year). Manual in english

PUNCTURE, EMERGENCY SPARE WHEEL (1/2)

In case of puncture

If the emergency spare wheel has been stored for several years, have it

Depending on the vehicle, a tyre infla-

checked by your Dealer to ensure that it is safe to use.

tion kit or emergency spare wheel is

Vehicle fitted with an emergency spare wheel that differs from the

provided (refer to the following pages).

other wheels:

Vehicle fitted with a tyre pressure

Never fit more than one emergency spare wheel to the same vehicle.

loss warning system

–

Replace the emergency spare wheel as soon as possible with a wheel identi-

In the event of under-inflation (punc-

cal to the original one.

tures, under-inflation etc.), the 

When this is fitted to the vehicle, which must only be a temporary measure, the

warning light appears on the instrument

driving speed must not exceed the speed indicated on the label on the wheel.

panel. ➥ 2.38.

Fitting an emergency spare wheel may alter the way the vehicle usually runs.

Avoid sudden acceleration or deceleration and reduce your speed when cor-

nering.

If you need to use snow chains, fit the emergency spare wheel to the rear axle

and check the tyre pressure.

If the vehicle is parked on the hard shoulder, you must warn other road

users of your vehicle’s presence with a warning triangle or with other de-

vices as per the legislation applying to the country you are in.

5.2

CarManuals2.co

PUNCTURE, EMERGENCY SPARE WHEEL (2/2)

Emergency spare wheel

- remove the tool kit 4;

To get to it:

- remove the emergency spare wheel

open the boot;

(A or B, depending on the vehicle).

–

depending on the vehicle, lift up the

movable floor and the luggage com-

partment mat 1;

depending on the vehicle, remove

the cover 2 from the tool kit 4 by slid-

ing it (movement C or D);

unscrew the central mounting 3 (lo-

On vehicles equipped with emer-

cated, depending on the vehicle,

gency spare wheel B, the punctured

under the jack) anti-clockwise;

wheel may not be stored in place

of the emergency spare wheel B.

The 4 tool kit must be attached

using the central attachment 3 and

the punctured tyre must be placed

in the luggage compartment.

5.3

CarManuals2.co

TYRE PRESSURE KIT (1/3)

Do not attempt to use the

The kit is only approved for

inflation kit if the tyre has

inflating the tyres of the ve-

been damaged as a result

hicle originally equipped

of driving with a puncture.

with the kit.

You should therefore carefully check

It must never be used to inflate

the condition of the tyre sidewalls

the tyres of another vehicle, or any

before any operation.

other inflatable object (rubber ring,

rubber boat, etc.).

Driving with underinflated, flat or

punctured tyres can be dangerous

Avoid spillage on skin when han-

and may make the tyre impossible

dling the repair product bottle. If

to repair.

droplets do leak out, rinse them off

with plenty of water.

This repair is temporary.

Keep the repair kit away from chil-

A tyre which has been punctured

dren.

should always be inspected (and re-

paired, where possible) as soon as

Do not dispose of the empty bottle

The kit repairs tyres when

possible by a specialist.

in the countryside. Return it to your

tread A has been dam-

approved dealer or to a recycling or-

aged by objects smaller

When taking a tyre which has been

ganisation.

than 4 mm. It cannot repair

repaired using this kit to be replaced,

all types of puncture, such as cuts

you must inform the specialist.

The bottle has a limited service

larger than 4 mm, or cuts in tyre

life which is indicated on its label.

When driving, vibration may be felt

sidewall B.

Check the expiry date.

due to the presence of the repair

Ensure also that the wheel rim is in

product injected into the tyre.

Contact an approved dealer to re-

good condition.

place the inflation tube and repair

product bottle.

Do not pull out the foreign body

causing the puncture if it is still in

the tyre.

5.4

CarManuals2.co

TYRE PRESSURE KIT (2/3)

With the engine running and the

If a minimum pressure of 1.8 bar is

parking brake applied,

not reached after 15 minutes, repair

- Disconnect any accessories previ-

is not possible; do not drive the ve-

ously connected to the vehicle’s ac-

hicle but contact an approved dealer.

cessories sockets;

- refer to the information on the in-

flation kit compressor located in

the luggage compartment of the ve-

hicle and follow the instructions;

- inflate the tyre to the recommended

pressure ➥ 4.11 ;

- after a maximum of 15 minutes, stop

inflating and read the pressure (on

Before using this kit, park

pressure gauge 2).

the vehicle at a sufficient

distance from traffic, switch

Note: while the bottle is emptying

on the hazard warning

(approximately

30 seconds), the

Depending on the vehicle, in the event

lights, apply the handbrake, ask all

pressure gauge 2 will briefly indicate

of a puncture, use the kit located in the

passengers to leave the vehicle and

a pressure of 6 bar, then the pres-

boot or underneath the luggage com-

keep them away from traffic.

sure drops;

partment carpet.

- Adjust the pressure: to increase it,

Vehicle fitted with a tyre pressure

continue inflation with the kit. To

loss warning system

reduce it, press the button 1.

In the event of under-inflation (punc-

If the vehicle is parked on

tures, under-inflation etc.), the 

the hard shoulder, you must

warning light appears on the instrument

warn other road users of

panel. ➥ 2.38.

your vehicle’s presence

with a warning triangle or with other

devices as per the legislation apply-

ing to the country you are in.

5.5

CarManuals2.co

TYRE PRESSURE KIT (3/3)

- Start immediately and drive at a

speed between 12 to 37 mph (20 to

60 km/h) in order to distribute the

product evenly in the tyre; after driv-

ing a distance of 2 miles (3 km), stop

and check the pressure.

- If the pressure is higher than 1.3 bar

Please be aware that a

but lower than the recommended

poorly tightened or miss-

pressure (refer to the label affixed to

ing valve cap can make the

the edge of the driver’s door), adjust

tyres less airtight and may

it. Otherwise, contact an approved

lead to pressure loss.

dealer: the tyre cannot be repaired.

Always use valve caps identical to

those fitted originally and tighten

them fully.

Precautions when using the

kit

Once

the

tyre is

correctly inflated,

The kit should not be operated for more

remove the kit: unscrew the inflation

than 15 consecutive minutes.

adapter slowly from the container 3 to

The container must be replaced after

Following repair with the kit,

prevent any product spatter and store

the first use even if liquid remains

do not travel further than

the container in plastic packaging to

inside.

120 miles (200 km). In addi-

prevent product leaks.

tion, reduce your speed and

- Affix the driving recommendation

under no circumstances exceed

label (located under the container) to

48 mph (80 km/h). The sticker,

the dashboard where the driver can

which you must affix in a prominent

see it.

position on the dashboard, reminds

- Put the kit away.

you of this.

Nothing should be placed

- At the end of this initial inflation op-

Depending on the country or local

around the driver’s feet

eration, air will still escape from the

legislation, a tyre repaired with the

as such objects may slide

tyre. You must drive a short distance

inflation kit may need to be replaced.

under the pedals during

in order to seal the hole.

sudden braking manoeuvres and

obstruct their use.

5.6

CarManuals2.co

TOOLS

Jack 2

Fold it correctly before refitting it in its

housing (ensure that the wheelbrace is

correctly positioned).

Hubcap tool 3

This tool is used to remove the wheel

trims.

Wheel bolt guide 4

To finish loosening or starting to tighten

the wheel bolts.

Tow eye 5

The tools included in the tool kit depend

Wheelbrace 1

➥ 5.35

on the vehicle.

Locks or unlocks the wheel bolts and

Tool kit A is located in the tray under

tow eye 5.

the luggage compartment carpet.

Depending on the vehicle, remove the

cover B from the tool kit A by sliding it

(movement C or D). After use, ensure

the tools are correctly stored.

Ensure correct positioning and locking

Do not leave the tools unsecured inside the vehicle as they may come

(movement C or D) of cover B.

loose under braking. After use, check that all the tools are correctly

clipped into the tool kit, then position it correctly in its housing: risk of

injury.

If bolts are supplied with the emergency spare wheel, you must use these bolts

only for the emergency spare wheel.

The jack is designed for wheel changing purposes only. Under no circumstances

should it be used for carrying out repairs underneath the vehicle or to gain access

to the underside of the vehicle.

5.7

CarManuals2.co

WHEEL TRIM, WHEEL

Remove the wheel trim using hubcap

tool 1 (located in the tool kit) by en-

gaging the hook in the opening near

valve 2.

To refit it, align it with valve 2. Push the

retaining hooks in fully, starting with

side A near the valve, followed by B

and C, finishing at D opposite the valve.

Do not leave the tools un-

secured inside the vehicle

as they may come loose

under braking. After use,

check that all the tools are correctly

clipped into the tool kit, then posi-

tion it correctly in its housing: risk of

injury.

5.8

CarManuals2.co

CHANGING A WHEEL (1/2)

Vehicles equipped with a jack

Start cranking the jack by hand, posi-

tioning the 4 jack support plate in the

and wheelbrace

slightly indented groove underneath

If necessary, remove the wheel trim.

the vehicle, located between the two

Use the wheelbrace 1 to slacken off the

notches 5 and in the direction of the

wheel bolts. Position it so as to be able

arrow 3.

to push from above.

Continue to crank the jack so that the

Place the jack 2 horizontally. The jack

baseplate is correctly positioned

(it

head must be lined up with the sill clos-

should be underneath the vehicle and

est to the wheel concerned and indi-

aligned with the jack head).

cated by the arrow 3.

Turn it a few times to lift the wheel off

the ground.

Switch on the hazard warn-

ing lights.

Keep the vehicle away from

traffic and on a level surface

where it will not slip.

Apply the parking brake and engage

a gear (first or reverse, or P for auto-

If the vehicle is parked on

matic transmissions).

the hard shoulder, you must

Ask all the passengers to leave the

warn other road users of

vehicle and keep them away from

your vehicle’s presence

traffic.

with a warning triangle or with other

devices as per the legislation apply-

ing to the country you are in.

5.9

CarManuals2.co

CHANGING A WHEEL (2/2)

Undo the bolts and take off the wheel.

Vehicle fitted with a tyre pressure

loss warning system

Fit the emergency spare wheel on the

central hub and turn it to locate the

In the event of under-inflation (punc-

mounting holes in the wheel and the

tures, under-inflation etc.), the 

hub.

warning light appears on the instrument

Tighten the bolts, checking that the

panel. ➥ 2.38.

wheel is correctly positioned on its hub.

Lower the jack.

With the wheel on the ground, tighten

the bolts fully and have the tightness of

the bolts checked and the emergency

Do not leave the tools un-

spare wheel pressure checked as soon

secured inside the vehicle

as possible.

as they may come loose

under braking. After use,

check that all the tools are correctly

clipped into the tool kit, then posi-

tion it correctly in its housing: risk of

injury.

If bolts are supplied with the emer-

gency spare wheel, you must use

these bolts only for the emergency

spare wheel.

The jack is designed for wheel

changing purposes only. Under no

If you have a puncture, re-

circumstances should it be used for

place the wheel as soon as

carrying out repairs underneath the

possible.

vehicle or to gain access to the un-

A tyre which has been punc-

derside of the vehicle.

tured should always be inspected

(and repaired, where possible) by a

specialist.

5.10

CarManuals2.co

TYRES (1/3)

Tyre and wheel safety

When the tyre tread has been worn

to the level of the warning strips, they

The tyres are the only contact between

become visible 2: it is then neces-

the vehicle and the road, so it is essen-

sary to replace your tyres because the

tial to keep them in good condition.

tread rubber is now only 1.6 mm deep

You must make sure that your tyres

at most, resulting in poor road hold-

con- form to local road traffic regula-

ing on wet roads.

tions.

An overloaded vehicle, long journeys

by motorway, particularly in very hot

weather, or continual driving on poorly

surfaced minor roads will lead to more

rapid tyre wear and affect safety.

Maintaining the tyres

The tyres must be in good condition

and the tread form must have sufficient

depth; tyres approved by our Technical

Department have wear warning strips 1

which are indicators moulded into

the tread at several points.

Incidents which occur when

driving, such as striking the

kerb, may damage the tyres

and wheel rims, and could

also lead to misalignment of the

front or rear axle geometry. In this

case, have the condition of these

checked by an approved dealer.

5.11

CarManuals2.co

TYRES (2/3)

Tyre pressures

Pressures should be checked when the

Vehicle fitted with a tyre pressure

tyres are cold; ignore higher pressures

loss warning system

Adhere to the tyre pressures (including

which may be reached in hot weather

the emergency spare wheel). The tyre

In the event of under-inflation (punc-

or following a fast journey.

pressures should be checked at least

tures, under-inflation etc.), the 

once a month and additionally before

If tyre pressures cannot be checked

warning light appears on the instrument

any long journey (refer to the label af-

when the tyres are cold, assume an in-

panel. ➥ 2.38.

fixed to the edge of the driver’s door).

crease of 0.2 to 0.3 bar (or 3 PSI).

Never deflate a hot tyre.

Emergency spare wheel

➥ 5.2, ➥ 5.9.

Changing wheels around

Incorrect tyre pressures

This practice is not recommended.

lead to abnormal tyre wear

and unusually hot running.

These are factors which

may seriously affect safety and lead

to:

- poor road holding;

- risk of bursting or tread separa-

tion.

Please be aware that a

The pressure depends on the load

poorly tightened or miss-

and the speed of use. Adjust the

ing valve cap can make the

pressure according to the condi-

tyres less airtight and lead

tions of use (refer to the label affixed

to pressure loss.

to the edge of the driver’s door).

Always use valve caps identical to

those fitted originally and tighten

them fully.

5.12

CarManuals2.co

TYRES (3/3)

Fitting new tyres

Use in winter

Snow or Winter tyres

We would recommend that these be

Chains

fitted to all four wheels to ensure that

For safety reasons, fitting snow

your vehicle retains maximum adhe-

chains to the rear axle is strictly for-

sion.

bidden.

Warning: These tyres sometimes have

Chains cannot be fitted to tyres which

a specific direction of rotation and a

are larger than those originally fitted to

maximum speed index which may be

the vehicle.

lower than the maximum speed of your

For your safety, please re-

vehicle.

spect the speed limit.

One-way tyres

Studded tyres

When they need to be re-

An one-way tyre must only be fitted in

placed, only tyres of the

one direction. You must observe this di-

This type of equipment may only be

same make, size, type and profile

rection.

used for a limited period and as laid

should be used on a single axle.

down by local legislation. It is neces-

If an one-way tyre must be fitted in the

sary to observe the speed specified by

They must either have a load ca-

opposite to its direction of rotation fol-

current legislation.

pacity and speed rating at least

lowing a puncture, drive with caution,

equal to those of the original

particularly on a wet road, because the

These tyres must, at a minimum, be

tyres, or be recommended by an

tyre specifications will not be adapted.

fitted to the two front wheels.

authorised dealer.

Failure to heed these instructions

could endanger your safety and

affect your vehicle’s roadworthi-

ness.

Risk of loss of control of the ve-

hicle.

Chains may only be fitted

In all cases, we would recommend

to tyres of the same size

that you contact an approved Dealer

as those originally fitted to

who will be able to advise you on

your vehicle.

the choice of equipment which is

most suitable for your vehicle.

5.13

CarManuals2.co

FRONT HEADLIGHTS: replacing the bulbs

LED front fog lights/

cornering lights 3

(depending on the vehicle)

Consult an authorised dealer.

Additional lights

If you wish to fit fog lights to your ve-

hicle, please see an authorised dealer.

Direction indicators/dipped

beam headlights/LED main

beam headlights 1

Please see an authorised dealer.

Any operation on (or modi-

LED daytime running lights/

fication to) the electrical

side lights 2

system must be performed

(depending on the vehicle)

by an approved dealer

Please see an authorised dealer.

since an incorrect connection might

damage the electrical equipment

(harness, components and in par-

ticular the alternator). In addition,

your Dealer has all the parts re-

quired for fitting these units.

5.14

CarManuals2.co

REAR LIGHTS AND SIDE LIGHTS: replacing the bulbs (1/3)

LED side light/brake light 1

– release the light assembly from out-

Refitting

side the vehicle by pulling towards

Consult an approved dealer

To refit, proceed in the reverse order,

the rear;

taking care not to damage the wiring.

- remove the 4 bulb holder by un-

Direction indicators 5

screwing it a quarter of a turn, then

- Open the boot;

replace the bulb.

- remove the trim 2;

Bulb type: WY16W.

- unscrew the nut 3;

The bulbs are under pres-

To comply with current legislation, or

sure and can break when

as a precaution, you can obtain an

replaced.

emergency kit from your approved

Risk of injury.

dealer containing a set of spare

bulbs and fuses.

5.15

CarManuals2.co

INTERIOR LIGHTING: changing bulbs (2/2)

Luggage compartment light

Glovebox light

Courtesy mirror lights 5

Unclip the light 3 by pressing the tab on

Unclip the light 4 by pressing the tab on

Please consult an authorised dealer.

its left side (using a flat-bladed screw-

driver or similar).

Ambient lighting

Remove the bulb concerned.

Please consult an authorised dealer.

Bulb type: W5W.

5.19

CarManuals2.co

REMOTE CONTROL KEY: BATTERY: battery (1/2)

Replacing the battery

Note: It is not advisable to touch the

electronic circuit in the key cover when

Open the case at slot 1 using a flat-

replacing the battery.

blade screwdriver or similar, and re-

place the battery 2, observing the type

When refitting, ensure that the cover is

and polarity shown on the back of the

correctly clipped on and the screw tight-

cover.

ened.

When they need to be re-

placed, be sure to use

The batteries are available from ap-

the same or equivalent

proved Dealers, and their service

type of battery (consult an

life approximately two years.

Approved Dealer).

Check that there is no dye on the

battery: risk of an incorrect electri-

cal contact.

5.20

CarManuals2.co

REMOTE CONTROL KEY: BATTERY: battery (2/2)

Operating faults

If the battery is too weak to ensure cor-

rect operation, you will still be able to

start and lock/unlock the vehicle

➥ 1.14.

Do not throw away your used bat-

Precautions relating to

teries; give them to an organisation

batteries:

responsible for collecting and recy-

- keep (new or used) bat-

cling batteries.

teries out of reach of chil-

dren;

- do not swallow batteries;

When replacing:

Risk of chemical burns which

- make sure that the batter-

may lead to death.

ies are correctly inserted.

- if ingested or inserted into any

part of the body, consult a doctor

Risk of explosion.

as soon as possible.

- if the flap does not close cor-

rectly, do not use and keep out of

reach of children.

5.21

CarManuals2.co

CARD: battery (1/2)

The batteries are available from ap-

proved Dealers, and their service

life approximately two years. Check

that there is no dye on the battery:

risk of an incorrect electrical con-

tact.

When they need to be re-

Replacing the battery

When refitting, proceed in the reverse

placed, be sure to use

order, then press one of the buttons on

When the message “Keycard Battery

the same or equivalent

the card four times, close to the vehicle:

Low” appears on the instrument panel,

type of battery (consult an

the next time the vehicle is started, the

replace the battery in the card:

Approved Dealer).

message will disappear.

- slide the rear casing 1 downwards

while pressing on zone A;

Check that the cover is clipped shut.

- remove the battery cover 2;

Note: Do not touch the electronic circuit

- remove the battery by pressing on

or contacts on the card when replacing

one side and lifting the other;

the battery.

When replacing:

- replace it according to the direc-

tion and template shown inside the

- make sure that the batter-

cover.

ies are correctly inserted.

Risk of explosion.

- if the flap does not close cor-

rectly, do not use and keep out of

reach of children.

5.22

CarManuals2.co

CARD: battery (2/2)

Operating faults

If the battery is too weak to ensure cor-

rect operation, you will still be able to

start and lock/unlock the vehicle

➥ 1.14.

Precautions relating to

batteries:

- keep (new or used) bat-

teries out of reach of chil-

dren;

- do not swallow batteries;

Risk of chemical burns which

may lead to death.

- if ingested or inserted into any

part of the body, consult a doctor

as soon as possible.

Do not throw away your used bat-

teries; give them to an organisation

responsible for collecting and recy-

cling batteries.

5.23

CarManuals2.co

BATTERY: troubleshooting (1/3)

To avoid all risk of sparks:

Connecting a battery charger

Ensure that any power consumers

The battery charger must be com-

(courtesy lights, etc.) are switched

patible with a battery with nominal

off before disconnecting or recon-

voltage of 12 volts.

necting a battery;

Do not disconnect the battery when the

when charging, stop the charger

engine is running. Follow the instruc-

before connecting or disconnecting

tions given by the manufacturer of

the battery;

the battery charger you are using.

do not place metal objects on the

Handle the battery with care

battery as this could create a short

as it contains sulphuric acid,

circuit between the terminals;

which must not come into

contact with eyes or skin. If

always wait at least five minutes

it does, wash the affected area with

after the engine has been switched

plenty of cold water. If necessary,

off before disconnecting a battery;

consult a doctor.

make sure that you reconnect the

Keep naked flames, red hot objects

battery terminals after refitting.

and sparks away from the battery

components as there is a risk of

explosion.

Special procedures may be

Please note when working close to

required to charge some

the engine that it may be hot. In ad-

batteries. Contact your ap-

dition, the engine cooling fan may

proved dealer.

Avoid all risk of sparks which may

start at any moment. The 

cause an immediate explosion, and

warning light in the engine compart-

charge the battery in a well venti-

ment reminds you of this.

lated area.

Risk of injury.

Before carrying out any

Risk of serious injury.

action in the engine com-

partment, you must switch

off the ignition.

➥ 2.4

➥ 2.6.

5.24

CarManuals2.co

BATTERY: troubleshooting (2/3)

Starting the vehicle using the

battery from another vehicle

If you have to use the battery from an-

other vehicle to start, obtain suitable

jump leads (with a large cross section)

from an approved dealer or, if you al-

ready have jump leads, ensure that

they are in perfect condition.

The two batteries must have an iden-

tical nominal voltage of 12 volts. The

battery supplying the current should

have a capacity (amp-hours, Ah) which

is at least the same as that of the dis-

charged battery.

Ensure that there is no risk of contact

Battery in engine compartment

between the two vehicles (risk of short

circuiting when the positive terminals

The battery is not directly accessible.

are connected) and that the discharged

Use the terminal 1 (+) and the termi-

battery is properly connected. Switch

nal 2 (-) in the engine compartment.

off your vehicle ignition.

Raise the cover 3 of the terminal 1 (+).

5.25

CarManuals2.co

BATTERY: troubleshooting (3/3)

Start the engine of the vehicle supply-

ing the current and run it at an interme-

diate engine speed.

If your vehicle’s engine does not start

immediately, switch off the ignition and

wait a few seconds before repeating

the operation.

With the engine running, disconnect

the A and B cables in the reverse order

(2 - 4 - 5 - 1).

Reposition the cover 3 of the terminal 1

(+).

Attach the positive cable A to the ter-

minal 1 (+) then to the terminal 5 (+) of

the battery supplying the current.

Connect the negative cable B to the

terminal 4 (-) of the battery supplying

the current and then to the terminal 2

(-).

Check that there is no con-

tact between leads A and B

and that the positive lead A

is not touching any metal

parts on the vehicle supplying the

current.

Risk of injury and/or damage to

the vehicle.

5.26

CarManuals2.co

FITTING A RADIO

In all cases, it is very important to

follow the manufacturer’s instruc-

tions carefully.

The specifications of the brack-

Radio location 1

Front door speakers 2

ets and wires (available from our

Unclip the blanking cover. The aerial, +

To install any equipment, please con-

network) vary depending on the

and - supply and speaker wire connec-

sult an authorised dealer.

equipment level of your vehicle

tions are located behind it.

and the type of radio.

Consult an approved Dealer to

find out the correct part number.

No work may be carried out on

the vehicle’s electrical or radio

circuits, except by approved

dealers: an incorrectly connected

system may result in damage

being caused to the electrical

equipment and/or the compo-

nents connected to it.

5.27

CarManuals2.co

ACCESSORIES

Electrical and electronic accessories

Before installing this type of accessory (particularly for transmitters/receivers: frequency bandwidth, power level, po-

sition of the aerial, etc.), make sure it is compatible with your vehicle. You can get advice from an authorised dealer.

Before connecting an accessory to a socket, please ensure that you do not exceed the maximum power authorised for

the socket. ➥ 3.32, ➥ 3.18. Fire hazard.

No work may be carried out on the vehicle’s electrical or radio circuits, except by authorised dealers: an incorrectly connected

system may result in damage being caused to the electrical equipment and/or the components connected to it.

If the vehicle is fitted with any aftermarket electrical equipment, make sure that the installation is correctly protected by a fuse.

Establish the rating and position of this fuse.

Using the diagnostic socket

The use of electronic accessories on the diagnostic socket may cause serious disturbance to the vehicle’s electronic systems.

For your safety we recommend that you use only electronic accessories approved by the manufacturer, consult an Approved

Dealer. Serious accident risk.

Use of transmitting/receiving devices (telephones, CB equipment etc.).

Telephones and CB equipment with integrated aerials may cause interference to the electronic systems originally fitted to the

vehicle: it is advisable only to use equipment with an external aerial. Furthermore, we remind you of the need to conform

to the legislation in force concerning the use of such equipment.

Fitting aftermarket accessories

If you wish to install accessories on the vehicle: please contact an authorised dealer. Also, to ensure the correct operation of

your vehicle, and to avoid any risk to your safety, we recommend that you use only accessories specifically designed for your

vehicle, which are the only accessories for which the manufacturer will provide a warranty.

If you are using an anti-theft device, only attach it to the brake pedal.

Obstructions to the driver

On the driver’s side, only use mats suitable for the vehicle, attached with the pre-fitted components, and check the fitting regu-

larly. Do not lay one mat on top of another. There is a risk of wedging the pedals.

5.28

CarManuals2.co

FUSES (1/4)

Fuse boxes

Passenger compartment fuses B

Fuses located in the passenger

compartment behind a flap in the C

If any electrical component does not

Unclip the access flap 2.

glovebox

work, check the condition of the fuses.

Open and tilt the 2 flap completely then

Unclip the access flap 3.

pull it downwards to move it in order to

Passenger compartment fuses A

access the fuses.

Unclip the access flap 1.

Check the fuse in question and replace it, if necessary, by a fuse of the

same rating.

To comply with current legislation, or

If a fuse is fitted with too high a rating, it may cause the electrical circuit

as a precaution, you can obtain an

to overheat (risk of fire) in the event of an item of equipment using an ex-

emergency kit from your approved

cessive amount of current.

dealer containing a set of spare

bulbs and fuses.

5.29

CarManuals2.co

FUSES (2/4)

To comply with current legislation, or

Tweezers 4

as a precaution, you can obtain an

emergency kit from your approved

Remove the fuse using the tweezers 4

dealer containing a set of spare

on the back of the flap.

bulbs and fuses.

To remove the fuse from the tweezers,

slide the fuse to the side.

It is not advisable to use the free fuse

Check the fuse in question

locations.

and replace it, if neces-

sary, by a fuse of the same

rating.

If a fuse is fitted with too high a

rating, it may cause the electrical

circuit to overheat (risk of fire) in the

event of an item of equipment using

an excessive amount of current.

5.30

CarManuals2.co

FUSES (3/4)

Allocation of fuses

(the presence of certain fuse depends on the vehicle equipment level)

Symbol

Allocation

Windscreen washer

Multimedia accessories socket, multimedia

screen

Front and rear second row accessories socket

Horn

Towbar socket



Heated rear view mirrors

Use the fuse allocation label in the

Brake lights, passenger compartment central unit

storage compartment to identify the

fuses.

Passenger compartment centre unit, rear wiper,

Certain fuses should only be re-



rear fog light

placed by a qualified professional.

These fuses are not listed on the

label.

Direction indicator lights, hazard warning lights,

high level brake lights

Only change the fuses represented

on the label.

5.31

CarManuals2.co

FUSES (4/4)

Fuses in engine compartment D

LPG fuse in the front

Please note when work-

Some functions are protected by fuses

compartment

ing close to the engine that

it may be hot. In addition,

located in the engine compartment

5 fuse: LPG circuit shut-off.

the engine cooling fan may

(unit D).

However, because of their reduced

start at any moment. The 

accessibility, we advise you to have

warning light in the engine compart-

your fuses replaced by an approved

ment reminds you of this.

Dealer.

Risk of injury.

Before carrying out any

action in the engine com-

partment, you must switch

off the ignition.

➥ 2.4 or

➥ 2.6.

5.32

CarManuals2.co

WIPER BLADES: replacement (1/2)

Replacing the windscreen

To refit

wiper blades 2

To refit the wiper blade 2, insert it in its

To replace the wipers, first put them in

housing in the arm 3, then clip it until

the service positionB.

you hear a click. Make sure that the

With the engine running or the igni-

blade is correctly locked in position.

tion on:

To return the blades to lowered posi-

Check the condition of the wiper

- set the stalk 1 to position A twice in

tion, make sure that the blades are

blades. You are responsible for their

succession (single sweep): the wiper

folded down onto the windscreen then

service life:

blades will stop in position B away

set the 1 stalk to position A (single

- clean the blades, windscreen and

from the bonnet;

sweep): the windscreen wiper blades

rear screen regularly with soapy

- lift the wiper arm 3;

will fold into the bonnet when the igni-

water;

- lower the 4 tab then remove the

tion is switched on.

- do not use them when the wind-

blade 2.

screen or rear screen are dry;

- free them from the windscreen or

rear screen when they have not

been used for a long time.

5.33

CarManuals2.co

WIPER BLADES: replacement (2/2)

To refit

To refit the wiper blade, proceed in re-

verse order to removal. Make sure that

the blade is correctly locked in position.

- In frosty weather, make

sure that the wiper blades

are not stuck by ice

(to

avoid the risk of the motor

overheating).

- Check the condition of the wiper

blades. Replace the wiper blades

Rear screen wiper blade 5

as soon as they begin to lose ef-

Stalk in stop position (deactivated):

ficiency

(approximately once a

- lift the wiper arm 6;

year).

- turn the blade horizontally 5 (move-

When changing the blade, when it

ment B) until it unclips;

has been removed, do not let the

Check the condition of the wiper

- remove the blade by pulling it.

wiper arm fall against the window:

blades.

risk of breaking the window.

- clean the blades, windscreen and

rear screen regularly with soapy

water;

- do not use them when the wind-

screen or rear screen are dry;

Before changing the rear

wiper blade, make sure the

- free them from the windscreen or

stalk is in the stop position

rear screen when they have not

(deactivated).

been used for a long time.

Risk of injury.

5.34

CarManuals2.co

TOWING: breakdown recovery (1/2)

Before carrying out any towing, posi-

The speed specified by current legis-

tion the gearbox in neutral position (po-

lation for towing must always be ob-

sition N on vehicles equipped with an

served. If you are driving the towing

automatic gearbox), unlock the steering

vehicle, do not exceed the permissible

column then release the parking brake.

towing weight for your vehicle. ➥ 6.9.

Steering column unlocking

Towing a vehicle with an

Insert the key into the ignition, set to ON

automatic gearbox

2 position or, depending on the vehicle,

Transport the vehicle on a trailer or tow

with the card in the passenger compart-

it with the front wheels off the ground.

ment, press the engine start button for

In exceptional circumstances, you

approximately two seconds.

may tow it with all four wheels on the

Reposition the lever to neutral (position

ground, only in a forward gear, with the

N for vehicles fitted with an automatic

gear lever in neutral position N over a

gearbox).

maximum distance of 50 miles (80 km)

When setting off, if the lever is locked in

and at a maximum speed of 16 mph

The steering column unlocks and the

position P even though you are press-

(25 km/h).

accessory functions are powered: you

ing the brake pedal, the lever can be re-

can use the vehicle’s lights (direction

leased manually in order to unlock the

indicators, brake lights etc.). At night

drive wheels.

the vehicle must have its lights on.

To do this, unclip the base of the gaiter

Depending on the vehicle, once you

and press the 2 push button while si-

have finished towing, press the engine

Ensure that the towing eye

multaneously pressing the 1 button on

start button twice (risk of running down

is bolted correctly.

the lever to unlock the lever and shift to

the battery).

Risk of losing the towed

position N.

object.

Contact an authorised dealer as soon

as possible.

Leave the card in the vehi-

cle during towing.

Risk of the steering

column locking.

5.35

CarManuals2.co

TOWING: breakdown recovery (2/2)

Tighten the towing hitch 5 fully: first

by hand until it stops, then finish by

locking it with the wheel brace or, de-

pending on the vehicle, the lever.

Only use the towing hitch 5 and the

wheelbrace or lever provided with the

tools. ➥ 5.7.

- Use a rigid towing bar.

If a rope or cable is used

(where the law allows this),

the vehicle being towed

Only use the front 3 and rear 7 towing

Access to towing points

must be able to brake.

points (never use the driveshafts or any

- A vehicle must not be towed if it is

other part of the vehicle). These towing

Front towing point

not fit to be driven.

points may only be used for pulling.

Press zone A and keep depressed

- Avoid accelerating or braking

They must never be used for lifting the

while pulling zone B to open flap 4.

suddenly when towing, as this

vehicle directly or indirectly.

may result in damage being

Rear towing point

caused to the vehicle.

Press zone C and keep depressed

- In all cases, it is advisable not to

while pulling zone D to open flap 6.

exceed 15.5 mph (25 km/h).

When the engine is

Ensure that the towing eye

Do not leave the tools unse-

stopped, steering and brak-

is bolted correctly.

cured inside the vehicle as

ing assistance are not oper-

they may come loose under

Risk of losing the towed

ational.

braking.

object.

5.36

CarManuals2.co

OPERATING FAULTS (1/7)

Using the card

POSSIBLE CAUSES

WHAT TO DO

The card does not lock or unlock the

Card battery is flat.

Replace the battery. You will still be able to

doors.

lock/unlock and start your vehicle. ➥ 1.14

and ➥ 2.3 or ➥ 2.6.

Use of appliances operating on the

Stop using the devices or use the key pro-

same frequency as the card (mobile

vided. ➥ 1.14.

phone, etc.).

Vehicle located in a high electromag-

Use the key that is built into the card

netic radiation zone.

➥ 1.14.

Vehicle battery flat.

The message “Place card on zone +

Place the card in the placement area

START” appears on the instrument

➥ 2.6 then press the START button.

panel.

The vehicle is started.

With the engine running, the card’s locking/

unlocking device is blocked. Turn off the ig-

nition.

Desynchronisation of the card

Unlock the driver’s door by inserting the

key integrated in the card into the door lock

➥ 1.14 then place the card in the placement

area ➥ 2.6 and press the START button to

synchronise the card.

5.37

CarManuals2.co

OPERATING FAULTS (2/7)

The following advice will enable you to carry out quick, temporary repairs. For safety reasons you should always contact

an approved dealer as soon as possible.

Using the remote control

POSSIBLE CAUSES

ACTION REQUIRED

The remote control does not lock or The remote control battery is flat.

Use the emergency key.

unlock the doors.

Use of appliances operating on the same

Stop using the devices or use the key.

frequency as the remote control (mobile

phone, etc.).

Vehicle located in a high electromagnetic

Replace the battery. You will still be able to

radiation zone.

lock/unlock and start your vehicle. ➥ 1.14

Discharged battery.

and ➥ 2.3 or ➥ 2.6.

The vehicle is started.

With the engine running, the key’s locking/

unlocking device is blocked. Turn off the

ignition.

Desynchronisation of the remote control

Unlock the driver’s door by inserting the

key into the door lock ➥ 1.14, then start the

engine to synchronise the remote control

➥ 2.4 or ➥ 2.6.

5.38

CarManuals2.co

OPERATING FAULTS (3/7)

The starter is activated

POSSIBLE CAUSES

ACTION REQUIRED

The instrument panel indicator lights are

Battery terminals not tight, bat-

Retighten or reconnect the terminals, or clean them if

weak or fail to light up and the starter

tery terminals disconnected or

they are oxidised.

does not turn.

oxidised.

Discharged battery or not op- Connect another battery to the faulty battery. ➥ 5.24 or

erational.

replace the battery if necessary.

Do not push the vehicle if the steering column is

locked.

Faulty circuit.

Consult an approved dealer.

The engine will not start.

Starting conditions are not ful- ➥ 2.3 or ➥ 2.6.

filled.

The card does not work.

Place the card in the recess provided for this purpose

on the centre console.

➥ 2.3 or ➥ 2.6.

With the vehicle stationary, engine cold, Petrol version, this is not nec-

The engine’s idle speed should decrease after about

the engine’s idle speed is high.

essarily a fault. This may be

one minute. Otherwise, this may be caused by an-

caused by the increase in the

other fault. Call an approved Dealer.

engine temperature.

The engine cannot be switched off.

Card not detected.

Place the card in the recess provided for this purpose

on the centre console.

Press and hold the start button.

Electronic fault.

Press the start button 3 times quickly or press and

hold.

The steering column remains locked. Steering wheel locked.

Move the steering wheel while pressing the engine

start button (or, depending on the vehicle, operating

the ignition key) ➥ 2.3.

Faulty electrical circuit.

Consult an approved dealer.

5.39

CarManuals2.co

OPERATING FAULTS (4/7)

On the road

POSSIBLE CAUSES

WHAT TO DO

Vibrations.

Tyres not inflated to correct pres-

Check the tyre pressures: if this is not the

sures, incorrectly balanced or dam-

problem, have them checked by an ap-

aged.

proved Dealer.

White smoke from the exhaust.

In the diesel version, this is not neces-

➥ 2.16.

sarily a fault. Smoke may be caused

by particle filter regeneration.

Petrol version, this is not necessarily

Reduce the engine speed and avoid

a fault. Depending on the climate con-

sudden acceleration to gradually make the

ditions (cold, humidity etc.), smoke

smoke disappear. Otherwise, this may be

may be produced under hard vehicle

caused by another fault. Consult an ap-

acceleration.

proved dealer.

Smoke under the bonnet.

Short-circuit or cooling system leak.

Stop, switch off the ignition, stand away

from the vehicle and contact an approved

dealer.

The oil pressure warning light comes

on:

while cornering or braking

The level is too low.

Top up the engine oil ➥ 4.5.

is slow to go out or remains lit

Loss of oil pressure.

Stop the vehicle and contact an approved

under acceleration

Dealer.

5.40

CarManuals2.co

OPERATING FAULTS (5/7)

On the road

POSSIBLE CAUSES

WHAT TO DO

Steering becomes heavy.

Assistance overheating.

Drive carefully at reduced speed, be aware

of the level of force in the steering wheel

needed to turn the wheels.

Fault with the electric assistance

Consult an authorised dealer.

motor.

Fault in the assistance system

The engine is overheating. The

Engine cooling fan not working.

Stop the vehicle, switch off the engine and

coolant temperature indicator is in

contact an approved dealer.

the warning zone and warning light

comes on.

Coolant leaks.

Check the coolant reservoir: it should con-

tain fluid. If there is no coolant, consult an

authorised dealer as soon as possible.

Coolant boiling in the coolant reser-

Mechanical fault: damaged cylinder

Stop the engine.

voir.

head gasket.

Contact an approved dealer.

Radiator: In the event of a significant lack of coolant, remember that you must never top up using cold coolant while

the engine is very hot. After any procedure on the vehicle which has involved even partial draining of the cooling

system, it must be refilled with a new mixture prepared in the correct proportions. Reminder: only products approved

by our Technical Department may be used for this purpose.

5.41

CarManuals2.co

OPERATING FAULTS (6/7)

Electrical equipment

POSSIBLE CAUSES

WHAT TO DO

The wipers do not work.

Wiper blades stuck.

Free the blades before using the wipers.

Faulty electrical circuit.

Consult an approved dealer.

Fuse damaged.

Replace the fuse or have it replaced

➥ 5.29.

The wiper does not stop.

Faulty electrical controls.

Consult an approved dealer.

Direction indicators flashing more

Blown rear bulb.

➥ 5.15

quickly.

The direction indicators do not work.

Faulty electrical circuit or control.

Consult an approved dealer.

Fuse damaged.

Replace the fuse or have it replaced

➥ 5.29.

The lights do not come on or go off.

Faulty electrical circuit or control.

Consult an approved dealer.

Fuse damaged.

Replace the fuse or have it replaced

➥ 5.29.

5.42

CarManuals2.co

OPERATING FAULTS (7/7)

Electrical equipment

POSSIBLE CAUSES

WHAT TO DO

Traces of condensation in the head-

Traces of condensation may be a nat-

lights or rear lights.

ural phenomenon caused by varia-

tions in temperature and humidity.

In this case, the traces will disappear

slowly once the lights are switched

on.

The front seat belt reminder light

An object is stuck between the floor

Remove all objects from underneath the

comes on when the seat belts are

and the seat and is disrupting the op-

front seats.

fastened.

eration of the sensor.

5.43

CarManuals2.co

Renault Clio (2023 year). Manual in english - page 9
