Section 6: Technical Specifications
Vehicle identification plate
6.2
Technical Information for the emergency services
6.3
Engine identification
6.4
Dimensions
6.5
Engine specifications
6.6
Weights
6.9
Towing weights
6.9
Replacement parts and repairs
6.10
Service sheets
6.11
Anticorrosion check
6.17
6.1
CarManuals2.co
VEHICLE IDENTIFICATION PLATES
A
1
2
3
4
5
10
6
A
9
7
8
The information shown on the ve-
4
MMAC (Maximum permissible
hicle identification plate should be
all-up weight).
quoted on all correspondence or
5
MTR (Gross train weight: vehicle
orders.
fully loaded, with trailer).
6
MMTA (Maximum Permissible
The presence and location of the in-
Weight) front axle.
formation depends on the vehicle.
7
MMTA rear axle.
8
Reserved for related or additional
Vehicle identification plate A
entries.
1
Manufacturer name.
9
Diesel exhaust emissions.
2
EC design number or approval
Depending on the vehicle, this
number.
B
information is not indicated on
3
Identification number.
the manufacturer’s plate but on
Depending on the vehicle, this
the engine smoke opacity label
information is also given on
➥ 2.16.
marking B.
10
Paint reference (colour code).
6.2
CarManuals2.co
TECHNICAL INFORMATION FOR THE EMERGENCY SERVICES
A
A
The QR Code on the A label allows
emergency workers using a tablet or
smartphone to immediately access the
technical information useful for working
on the vehicle in the event of an acci-
dent.
Ensure that the A label is always visible
and present on the windscreen as well
as the rear screen.
Any modification or damage would
prevent access to the information.
6.3
CarManuals2.co
ENGINE IDENTIFICATION
A
1
2
3
A
A
Please quote the engine identifica-
tion information in area A in all cor-
respondence or orders.
(Location varies depending on engine)
1
Engine type.
2
Engine suffix.
3
Engine serial number.
A
A
6.4
CarManuals2.co
DIMENSIONS (in metres)
0,831
2,583
0,633
1 ,518
4,047
1,440*
1,506
1,988
* unladen
6.5
CarManuals2.co
ENGINE SPECIFICATIONS (1/3)
Versions
1.0 SCe
1.0 TCe
1.3 TCe
1.5 dCi
Engine type
B4D
H4D Turbo
H5H Turbo
K9K Turbo
(see engine plate)
Cubic capacity (cc)
999
999
1 333
1461
Type of fuel
Petrol
Diesel
Octane rating
You must use unleaded petrol with the octane
The label located in the fuel filler flap indicates
rating stated on the label inside the fuel filler
the authorised fuels.
flap. ➥ 1.114.
6.6
CarManuals2.co
ENGINE SPECIFICATIONS (2/3)
Versions
1.0 SCe
1.0 TCe
1.3 TCe
1.5 dCi
Engine type
B4D
H4D Turbo
H5H Turbo
K9K Turbo
(see engine plate)
Cubic capacity (cc)
999
999
1 333
1461
Fuel types that meet
European standards and are
compatible with the engines
Unleaded petrol compliant with
Diesel fuel compliant with stand-
of vehicles sold in Europe
standard EN 228 contains up
ard EN 590 contains up to 7%
(in any other case, contact an
to 5% ethanol in volume.
fatty acid methyl ester in volume.
Approved Dealer).
Unleaded petrol compliant with
Diesel fuel compliant with stand-
standard EN 228 contains up
ard EN 16734 contains up to 10%
to 10% ethanol in volume.
fatty acid methyl ester in volume.
Diesel fuel compliant with stand-
ard EN 15940 contains up to 7%
acid methyl ester in volume.
6.7
CarManuals2.co
ENGINE SPECIFICATIONS (3/3)
Versions
1.0 SCe
1.0 TCe
1.3 TCe
1.5 dCi
Engine type
B4D
H4D Turbo
H5H Turbo
K9K Turbo
(see engine plate)
Cubic capacity (cc)
999
999
1 333
1461
Spark plugs
Only use the spark plugs specified for your vehicle’s
engine.
The type should be marked on a label affixed inside
the engine compartment. If it is not then contact an
approved Dealer.
Fitting spark plugs other than those specified may
-
damage the engine.
6.8
CarManuals2.co
WEIGHTS (in kg)
The weights indicated for a basic vehicle without options: they vary depending on your vehicle’s equipment. Consult
your approved Dealer.
Maximum Authorised Mass (MMAC)
Maximum Permissible Weight (MMTA)
Weights indicated on the vehicle identification plate ➥ 6.2
Gross Train Weight (MTR)
Braked Trailer Weight*
found by calculating: MTR - MMAC
Unbraked Trailer Weight*
550 kg
Permissible nose weight*
63 kg
Maximum permissible load on roof
80 kg (including carrying device)
* Towing weight (towing a caravan, boat, etc.)
Towing is prohibited when the MTR - MMAC calculation is equal to zero, or when the MTR is equal to zero (or is not listed) on
the identification plate.
- It is important to comply with the towing weights, governed by local legislation in each country and, in particular, laid down in
the Road Traffic Regulations. Contact an approved Dealer about any towing equipment.
- When towing, under no circumstances may the total train weight (vehicle + trailer) be exceeded. However the following is
permitted:
- rear MMTA exceeded by no more than 15%;
- maximum MMAC exceeded by no more than 10% or 100 kg (whichever is reached first).
In either case, the maximum speed of the vehicle and trailer must not exceed 60 mph (100 km/h) and the tyre pressures must
be increased by 0.2 bar (3 PSI).
- The engine output and climbing capability are reduced with altitude. We recommend that the maximum load be reduced by 10%
at an altitude of 1,000 metres and by an additional 10% for each 1,000 metres thereafter.
6.9
CarManuals2.co
REPLACEMENT PARTS AND REPAIRS
Original parts are based on strict specifications and are subject to highly-specialised tests. Therefore, they are of at least the same
level of quality as the parts fitted originally.
If you always fit genuine replacement parts to your vehicle, you will ensure that it performs well. Furthermore, repairs carried out
within the manufacturer’s Network using original parts are guaranteed according to the conditions set out on the reverse of the
repair order.
6.10
CarManuals2.co
SERVICE SHEETS (1/6)
VIN:
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
6.11
CarManuals2.co
SERVICE SHEETS (2/6)
VIN:
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
6.12
CarManuals2.co
SERVICE SHEETS (3/6)
VIN:
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
6.13
CarManuals2.co
SERVICE SHEETS (4/6)
VIN:
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
6.14
CarManuals2.co
SERVICE SHEETS (5/6)
VIN:
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
6.15
CarManuals2.co
SERVICE SHEETS (6/6)
VIN:
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
Date:
Miles (Km):
Invoice number:
Comments/miscellaneous
Type of operation:
Stamp
Service
□
□
Anti-corrosion check:
OK □ Not OK* □
*See specific page
6.16
CarManuals2.co
ANTICORROSION CHECK (1/5)
If the continuation of the warranty is subject to repair, it is indicated below.
VIN:
Corrosion repair operation to be carried
Stamp
out:
Date of repair:
Repair to be carried out:
Stamp
Date of repair:
Repair to be carried out:
Stamp
Date of repair:
6.17
CarManuals2.co
ANTICORROSION CHECK (2/5)
If the continuation of the warranty is subject to repair, it is indicated below.
VIN:
Corrosion repair operation to be carried
Stamp
out:
Date of repair:
Repair to be carried out:
Stamp
Date of repair:
Repair to be carried out:
Stamp
Date of repair:
6.18
CarManuals2.co
ANTICORROSION CHECK (3/5)
If the continuation of the warranty is subject to repair, it is indicated below.
VIN:
Corrosion repair operation to be carried
Stamp
out:
Date of repair:
Repair to be carried out:
Stamp
Date of repair:
Repair to be carried out:
Stamp
Date of repair:
6.19
CarManuals2.co
ANTICORROSION CHECK (4/5)
If the continuation of the warranty is subject to repair, it is indicated below.
VIN:
Corrosion repair operation to be carried
Stamp
out:
Date of repair:
Repair to be carried out:
Stamp
Date of repair:
Repair to be carried out:
Stamp
Date of repair:
6.20
CarManuals2.co
ANTICORROSION CHECK (5/5)
If the continuation of the warranty is subject to repair, it is indicated below.
VIN:
Corrosion repair operation to be carried
Stamp
out:
Date of repair:
Repair to be carried out:
Stamp
Date of repair:
Repair to be carried out:
Stamp
Date of repair:
6.21
