AUTOMATIC LOCKING WHEN DRIVING

Operating faults

NB: if a door is opened or closed, it will

automatically lock again when the vehi-

If you experience an operating fault

cle reaches a speed of 6 mph (10 km/h).

(no central locking, the indicator light 1

does not light up when trying to lock the

1

Activating/deactivating the

doors and luggage compartment etc.),

make sure that central locking has not

function

been deactivated by mistake and check

To activate: with the vehicle station-

that the doors and luggage compart-

ary and the engine running, press the 1

ment are properly closed. If they are

switch until a beep sounds.

properly closed, contact an approved

To deactivate: with the vehicle station-

dealer.

ary and the engine running, press the

switch 1 until you hear two beeps.

The function can also be activated and

deactivated via the multimedia screen

Operating principle

(depending on the vehicle). ➥ 1.21

After the vehicle is started, the system

automatically locks the doors when

you are driving at approximately 6 mph

(10 km/h) and over.

The door can be unlocked:

- by pressing the central door unlock-

Driver’s responsibility

ing switch 1;

If you decide to keep the

- at a standstill, by opening a front

doors locked when you are

door from inside the vehicle.

driving, remember that it

may be more difficult for those as-

sisting you to gain access to the

passenger compartment in the

event of an emergency.

1.20

CarManuals2.co

VEHICLE SETTINGS CUSTOMISATION MENU (1/3)

Adjusting the settings

d) “Welcome”:

Select a menu then the function to be

- External welcome;

1

modified (the display depends on the

- Automatic fold-out of mirrors;

vehicle equipment and country):

- Interior welcome;

a) “Driving”:

- Courtesy light auto mode.

- Indicator volume;

Depending on the function, select:

- Free wheel in ECO mode.

- “ON” or “OFF” to activate or deacti-

b) “Access”:

vate,

- Unlock driver’s door only;

or

- Lock doors during driving;

- a duration to adjust the time the lights

- Opening/closing in hands-free

are switched on (for the “Follow-me

mode;

home lighting” function for example).

- Remote locking/Approach unlock-

Please refer to the multimedia instruc-

Depending on the vehicle equipment,

ing;

tions for further information.

this function allows you to activate/de-

activate and adjust some of the vehi-

- Silent mode;

cle’s functions.

- Automatic locking.

c) “Wiping and lighting”:

Vehicles fitted with a

- Wiping in reverse;

multimedia screen 1

- Automatic front wiping;

Accessing the settings menu

- Wiping after washing.

Refer to the various multimedia instruc-

tions for information on accessing the

settings.

For safety reasons, carry

out any adjustments when

the vehicle is not being

driven.

1.21

CarManuals2.co

VEHICLE SETTINGS CUSTOMISATION MENU (2/3)

Adjusting the settings

d) “DRIVING ASSIST”:

2

- Lane departure sensitivity;

Navigate using the 4 or 5 control to

- Lane departure vibration;

select the function to be modified and

- Lane keeping sensitivity;

press 6 “OK” to confirm (display may

- Blind spot warning;

vary according to vehicle equipment

- Active braking;

and country):

- Overspeed warning;

a) “DASHBOARD”:

- Distance warning.

- Language;

e) “LIGHTING”:

4

- Courtesy light auto mode.

3

- Unit;

- Style;

f)

“ACCESS”:

- Lock doors during driving;

- Colour.

- Opening/closing in hands-free

6

b) “VEHICLE”:

mode;

5

- Unlock the driver’s door only;

- Rear windscreen wiping in re-

- Automatic re-locking;

Vehicles not fitted with a

verse gear;

- Silent locking;

multimedia screen

- Automatic windscreen wiping;

- Automatic opening/closing;

Accessing the settings menu on

- Front/rear drip wiping function;

- Automatic fold-out of mirrors.

display 2

g) “RESET”.

- Free wheel in ECO mode;

With the vehicle stopped, press the 3

- External welcome.

switch as many times as required to

=

function activated

c) “PARKING ASSIST”:

reach the “Vehicle” tab; Press repeat-

edly on the 4 or 5 switch to access the

- Beep sound volume.

<

function deactivated

“Settings” menu, then confirm by press-

ing 6 “OK”.

1.22

CarManuals2.co

VEHICLE SETTINGS CUSTOMISATION MENU (3/3)

To exit the menu, press 4 or 5 to access

“BACK” and confirm by pressing 6

“OK”. It may be necessary to carry out

this operation more than once.

3

4

6

5

Once a line has been selected, press 6

“OK” to adjust the function.

If you select either “PARKING ASSIST”

then “VOLUME”, or “DASHBOARD”

then “LANGUAGE”, you will have to

make a further selection (sound volume

of the parking distance control or in-

strument panel language). In this case,

make your selection and confirm it by

pressing “6 OK”, the selected value is

The vehicle settings personalisation

shown by a =

in front of the line.

menu cannot be used when driv-

ing. At a speed exceeding 12 mph

(20 km/h), the instrument panel dis-

play switches automatically back to

trip computer and warning system

mode.

1.23

CarManuals2.co

FRONT HEADRESTS

To raise the headrest

Raise it to its highest position (tilt the

seatback backwards if necessary).

A

Press button 2 and lift the headrest to

release it.

3

1

To refit the headrest

Check that the headrest rods are

clean 3.

2

Insert the headrest rods into the holes 1

(tilt the seatback backwards if neces-

sary). Lower the headrest until it locks

and press button 2 to adjust to the de-

sired height. Check that each rod 3 on

To raise the headrest

the seatback is securely locked.

Pull the headrest upwards to the de-

sired height. Check that it is correctly

locked.

To lower the headrest

Press button 2 and guide the headrest

down to the desired height. Check that

The headrest is important

the bonnet is correctly locked.

for safety. Ensure that it is in

place and in the correct po-

sition: the top of the head-

rest should be as close as possible

to the top of the head and there must

be a minimal distance between the

head and the headrest A.

1.24

CarManuals2.co

FRONT SEATS (1/3)

Release the handle at the desired posi-

tion and make sure that it is locked.

To adjust the seat’s lumbar

position

2

3

1

6

Push left or right of the button 3 to in-

5

crease or decrease the support.

4

Adjusting the seat position

To raise or lower the seat base

To move the seat forwards or back

Move the 1 switch up or down or, de-

For safety reasons, carry

pending on the vehicle, move the 5

Move the 1 switch forwards or back-

out any adjustments

lever as many times as necessary up-

wards or, depending on the vehicle,

when the vehicle is not

wards or downwards to the desired po-

lift and hold the 4 handle to unlock the

being driven.

sition.

seat. Release the handle once the seat

We would advise you not to recline

is in the correct position and ensure

the seatbacks too far to ensure that

that the seat is locked.

Adjusting the seatback

the effectiveness of the seat belts is

To tilt the seatback

not reduced.

Activate the 2 switch forwards or back-

Nothing should be placed on the

wards, or depending on the vehicle, lift

floor (area in front of driver) as such

the 6 handle and tilt the seatback to the

objects may slide under the pedal

desired position.

during braking manoeuvres, thus

obstructing its use.

1.25

CarManuals2.co

FRONT SEATS (2/3)

7

9

10

8

Central armrest 7

- pressing the switch for the second

Pressing 8 again turns the heated seat

(depending on the vehicle)

time changes the heating to low. One

off. Its warning lights go off.

integrated warning light comes on;

To adjust the position of the central arm-

Operating faults

rest 7, slide it forwards or backwards.

- pressing for the third time turns the

heating off.

When an operating fault is detected,

the warning light of the 8 switch for the

Heated seats

Vehicles fitted with heated and

seat concerned switches-off after ap-

(depending on the vehicle)

ventilated seats

proximately five seconds. Consult an

approved dealer.

While the engine is running, pressing 8

Vehicles fitted only with heated

displays setting on multimedia screen.

seats

Pressing 9 activates drivers or passen-

With the ignition on:

gers heated seat.

– Pressing the switch 8 on the required

Pressing 10 once or twice activates

seat for the first time activates the

the heated seat at low or high level.

heating system on high. Both inte-

Warning lights come on.

grated switch warning lights come

on;

1.26

CarManuals2.co

FRONT SEATS (3/3)

Operating faults

When an operating fault is detected,

the warning light of the 8 switch for the

9

seat concerned switches-off after ap-

proximately five seconds. Consult an

approved dealer.

11

8

Ventilated seats

While the engine is running:

(depending on the vehicle)

- pressing 8 displays setting on multi-

Ventilation seats work on the princi-

media screen. Pressing 9 activates

ple of absorbing and exporting the air

drivers or passengers ventilated

in the passenger compartment with-

seat.

out using the vehicle’s air conditioning

- pressing 11 once or twice activates

and heating functions. For the best per-

the ventilated seat at low or high

formance, you are advised to use this

level. Warning lights come on.

function with air conditioning switched

- pressing 8 again turns the heated

on.

seat off. Its warning lights go off.

Note: this function is deactivated when

the engine is off and on.

1.27

CarManuals2.co

SEAT BELTS (2/5)

Locking

Driver’s seat belt reminder

ß

and, depending on the vehi-

Unwind the belt slowly and smoothly

cle, front passenger seat belt re-

and ensure that buckle 3 locks into

minder

catch 5 (check that it is locked by pull-

ing on buckle 3).

This appears on the central display

when the ignition is switched on and if

If the belt jams, allow it to return slightly

the driver’s or front passenger’s seat

before attempting to unwind it again.

1

belt (as long as the passenger seat is

If your seat belt is completely jammed,

occupied) is not fastened.

pull slowly, but firmly, so that just over

Depending on the vehicle, if the seat is

3 cm unwinds. Allow it to return slightly

3

occupied and one of these seat belts is

before attempting to unwind it again.

not fastened or becomes unfastened

4

If there is still a problem, contact an ap-

while the vehicle is moving at a speed

5

5

proved dealer.

over approximately 12 mph (20 km/h),

2

the ß

warning light flashes and

Adjusting the seat belts

Unlocking

a beep sounds for approximately

Sit with your back firmly against the

Press button 4 and the seat belt will be

120 seconds.

seatback.

rewound by the inertia reel. Guide the

Note: an object placed on the passen-

Shoulder strap 1 should be as close as

belt.

ger seat may activate the warning light

possible to the base of the neck but not

in some cases, depending on the ve-

on it.

hicle.

Lap belt 2 should be worn flat over the

thighs and against the pelvis.

The belt should be worn so that it is

as close as possible to your body, i.e.:

avoid wearing heavy clothing or keep-

ing bulky objects under the belts, etc.

1.29

CarManuals2.co

SEAT BELTS (3/5)

Rear seat belt reminder (depending

It is accompanied by the 6 symbol which

on vehicle)

appears for approximately 60 seconds

each time one of the rear seat belts is

The 6 graphic is displayed on the in-

fastened or unfastened.

strument panel when the ignition is

switched on. This informs the driver of

When the vehicle speed exceeds ap-

the fastening status of each of the rear

proximately 12 mph (20 km/h), if one of

seat belts every time:

the rear seat belts is or becomes unfas-

tened during the journey:

- the ignition is switched on;

- a door is opened;

- the ß

warning light flashes on

- fastening or unfastening of a rear

the central display;

seat belt.

6

and

Understanding the graphic 6:

- a beep sounds for around 120 sec-

- indicator green: seatbelt fastened;

onds;

- indicator red: the seat is occupied

and

and the seat belt is not fastened;

- the 6 symbol is displayed for approxi-

The ß

warning light on the central

– indicator grey: seat not occupied.

mately 180 seconds and the symbol

display also appears when the ignition

for the seat concerned changes to

is switched on, If a rear seat is occupied

red.

and the seat belt is not fastened.

Always make sure that the rear passen-

When the vehicle speed is less than

gers are properly fastened and that the

approximately 12 mph (20 km/h), the

number of fastened seat belts indicated

ß

warning light on the central dis-

corresponds to the number of rear seat

play appears if a rear seat is occupied

occupied.

and the seat belt is not fastened.

Note: in some cases that alerts may be

activated if an object is placed on one

of the rear seats, depending on the ve-

hicle.

1.30

CarManuals2.co

SEAT BELTS (4/5)

7

9

8

10

Adjusting the height of the

Rear side seat belts 8

Rear centre seat belt

front seat belts

The belts are locked, unlocked and

Slowly unwind belt 9.

Use button 7 to adjust the seat belt

adjusted in the same way as the front

Click buckle into black catch 10.

height so that the shoulder strap is worn

belts.

as shown previously. Press the button 7

and raise or lower the seat belt. Make

sure that the seat belt is locked in posi-

tion correctly after you have adjusted it.

Check that the rear seat

belts are positioned and

operating correctly each

time the rear bench seat is

moved.

1.31

CarManuals2.co

METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (1/5)

Depending on the vehicle, they will con-

sist of:

- seat belt inertia reel pretension-

ers;

- central seat belt pretensioners;

- chest-level load limiters;

- Have the entire restraint

- airbags driver and passenger

system checked following

front.

an accident.

These systems are designed to act in-

- No operation whatso-

dependently or together when the vehi-

ever is permitted on any part

cle is subjected to a frontal impact.

2

of the system

(pretensioners,

airbags, computers, wiring) and

Depending on the severity of the

1

the system components must not

impact, the system can trigger:

be reused on any other vehicle,

-

seat belt locking;

Pretensioners

even if identical.

–

the seat belt inertia reel pretensioner

The pretensioners hold the seat belt

-

Only qualified personnel from our

(which engages to correct seat belt

against the body, holding the occupant

Network may work on the airbags;

slack);

more securely against the seat, thus in-

otherwise the system may trigger

creasing the seat belt’s efficiency.

accidentally and cause injury.

-

lap seat belt pretensioners to hold

the occupant in their seat;

In the event of a severe frontal impact

-

The electric trigger system may

and if the ignition is switched on, the

only be tested by a specially

–

the front airbag.

system may engage the following de-

trained technician using special

pending on the force of the impact:

equipment.

- the seat belt inertia reel preten-

-

When the vehicle is scrapped,

sioner 1 which instantly retracts the

contact an approved dealer for

seat belt;

disposal of the pretensioner and

airbags gas generators.

- the lap seat belt inertia reel preten-

sioner 2 on the front seats.

1.33

CarManuals2.co

METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (2/5)

Load limiter

Operating faults

Above a certain severity of impact, this

å

This warning light comes on

mechanism is used to limit the force of

when the engine is started and then

the belt against the body so that it is at

goes out after approximately three sec-

an acceptable level.

onds.

If it does not come on when the ignition

Driver and passenger front

is switched on or if it stays on, there is a

Airbags

fault in the system.

Fitted to the driver and passenger

Contact your approved Dealer as soon

sides.

as possible.

A symbol on the lower section of the

Your protection will be reduced until this

windscreen indicates if this equipment

fault is rectified.

is present (depending on the vehicle).

Each airbag system consists of:

Operation

-

an airbag and gas generator fitted on

This system is only operational when

the steering wheel for the driver and

the ignition is switched on.

in the dashboard for the passenger;

In a severe frontal impact, the airbags

-

an electronic unit for system monitor-

inflate rapidly, cushioning the impact

The airbag system uses py-

ing which controls the gas generator

of the driver's head and chest against

rotechnic principles. This

electrical trigger system;

the steering wheel and of the front pas-

explains why, when the

-

remote sensors;

senger against the dashboard. The air

airbag inflates, it will gener-

bags then deflate immediately so that

ate heat, produce smoke (this does

-

a single warning light å

on the

the passengers are not in any way hin-

not mean that a fire is about to start)

instrument panel.

dered from leaving the vehicle.

and make a banging noise. In a situ-

ation where an airbag is required, it

will inflate immediately and this may

cause some minor, superficial graz-

ing to the skin or other problems.

1.34

CarManuals2.co

METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (3/5)

The following conditions will trigger

In a frontal impact with another vehi-

In a side impact with another vehicle

the pretensioners or airbags.

cle of an equivalent or higher category,

of an equivalent or higher category, at

with an impact area equal to or greater

an impact speed equal to or greater

In a frontal impact against a rigid

than 40%, where the speed of both ve-

than 31 mph (50 km/h).

(non-deformable) surface at an impact

hicles is equal to or greater than

speed equal to or greater than 16 mph

25 mph (40 km/h).

(25 km/h).

1.35

CarManuals2.co

METHODS OF RESTRAINT IN ADDITION TO THE FRONT SEAT BELTS (4/5)

In the following examples, the pre-

In the following examples, there is a

- side impact, affecting the front of the

tensioners or the airbags could op-

risk that pretensioners orairbags may

vehicle;

erate:

not be triggered:

- frontal impact, under the tail of a

- impact under vehicle such as pave-

- rear impact, however severe;

lorry;

ment;

– the vehicle overturning;

- frontal impact against an obstacle

- potholes;

with a sharp angle;

- drop or hard landing;

- ...

- stones;

– ...

1.36

CarManuals2.co

METHODS OF RESTRAINT IN ADDITION TO THE REAR SEAT BELTS

Depending on the vehicle, they will con-

- Have the entire restraint

sist of:

system checked following

- side seat belt inertia reel preten-

an accident.

sioners;

- No operation whatso-

- chest force limiters.

ever is permitted on any part

These systems are designed to act in-

of the system

(pretensioners,

dependently or together when the vehi-

airbags, computers, wiring) and

cle is subjected to a frontal impact.

the system components must not

be reused on any other vehicle,

Depending on the severity of the

even if identical.

impact, the system can trigger:

1

-

Only qualified personnel from our

- seat belt locking;

Network may work on the airbags;

- the seat belt inertia reel pretensioner

otherwise the system may trigger

(which engages to correct seat belt

accidentally and cause injury.

slack).

Side seat belt pretensioners

-

The electric trigger system may

only be tested by a specially

The pretensioners hold the seat belt

Force limiter

trained technician using special

against the body, holding the occupant

equipment.

Above a certain severity of impact, this

more securely against the seat, thus in-

-

When the vehicle is scrapped,

mechanism is used to limit the force of

creasing the seat belt’s efficiency.

contact an approved dealer for

the belt against the body so that it is at

With the ignition on, following a signif-

disposal of the pretensioner and

an acceptable level.

icant frontal impact and depending on

airbags gas generators.

the severity of the impact, the system

may trigger the seat belt inertia reel

pretensioner 1, which instantly retracts

the seat belt.

1.38

CarManuals2.co

CHILD SAFETY: General information (1/2)

Carrying children

Please ensure that you comply with the

legislation of your country.

Children, and adults, must be correctly

seated and strapped in for all journeys.

The children being carried in your vehi-

cle are your responsibility.

A child is not a miniature adult. Children

are at risk of specific injuries as their

muscles and bones have not yet fin-

ished growing. The seat belt alone

would not provide suitable protection.

A collision at

30 mph

Driver’s responsibility

Use an approved child seat and ensure

(50 km/h) is the same as fall-

when parking or stopping

you use it correctly.

ing a distance of 10 metres.

the vehicle

Transporting a child without

Never leave an animal,

a restraint is the equivalent of allow-

child or adult who is not self-suffi-

ing him or her to play on a fourth-

cient alone on your vehicle, even for

floor balcony without railings.

a short time.

Never travel with a child held in your

They may pose a risk to themselves

arms. In the event of an accident,

or to others by starting the engine,

you will not be able to keep hold of

activating equipment such as the

the child, even if you yourself are

electric windows or by locking the

wearing a seat belt.

doors.

If your vehicle has been involved in

Also, in hot and/or sunny weather,

a road accident, replace the child

please remember that the tempera-

seat and have the seat belts and

ture inside the passenger compart-

ISOFIX anchorage points checked.

ment increases very quickly.

RISK OF DEATH OR SERIOUS

To prevent the doors being

INJURY.

opened, use the “Child lock”

feature. ➥ 1.14

1.41

CarManuals2.co

CHILD SAFETY: choosing a child seat

Rear-facing child seats

Forward-facing child seats

Booster cushions

A baby’s head is, proportionally, heavier

The child’s head and abdomen need to

From 15 kg or 4 years, the child can

than that of an adult and its neck is very

be protected as a priority. A forward-fac-

travel using a booster seat, which will

fragile. Transport the child in this po-

ing child seat which is firmly attached to

enable the seat belt to be adapted

sition for as long as possible (until the

the vehicle will reduce the risk of impact

to suit his/her size and shape. The

age of 2 at the very least). It supports

to the head. Ensure your child travels in

booster seat cushion must be fitted with

both the head and the neck.

a forward-facing seat with a harness for

guides to position the seat belt on the

as long as their size permits.

child’s thighs rather than the stomach.

Choose a bucket type seat for best side

It is recommended that you use a seat-

protection and change it as soon as the

Choose a bucket type seat for optimum

back fitted with a belt strap guide which

child’s head is higher than the shell.

side protection.

can be adjusted in terms of height to

position the seat belt in the centre of the

shoulder. It must never rest on the neck

or on the arm.

Choose a bucket type seat for optimum

side protection.

1.43

CarManuals2.co

CHILD SAFETY: choosing a child seat mounting (2/3)

No modifications may be

made to the component

parts of the restraint system

(seat belts, ISOFIX and

seats and their mountings) originally

fitted.

1

The ISOFIX anchorage

points have been exclu-

sively designed for child

seats with the ISOFIX

system. Never fit a different type of

child seat, seat belt or other objects

to these anchorage points.

Attach the child seat with the ISOFIX

locks, if these are provided. The ISOFIX

Check that nothing is obstructing

system allows quick, easy, safe fitting.

the anchorage points.

The ISOFIX system consists of 2 rings

If your vehicle has been involved in

and, in some cases, a third ring.

a road accident, have the ISOFIX

anchorage points checked and re-

The two rings are located behind the

place your child seat.

zip fasteners 1 between the seat back

and seat base and are identified by a

Before using an ISOFIX

child seat that you pur-



marking.

chased for another vehicle,

check that its installation is

authorised. Consult the list of ve-

hicles which can be fitted with the

seat from the equipment manufac-

turer.

1.45

CarManuals2.co

CHILD SAFETY: choosing a child seat mounting (3/3)

2

3

4

Attachment using the ISOFIX

The ISOFIX anchorage

system (continued)

points have been exclu-

The third ring 4 is used to attach the

sively designed for child

upper strap 2 on some child seats.

seats with the ISOFIX

system. Never fit a different type of

Rear side seats

child seat, seat belt or other objects

The upper strap 2 should be positioned

to these anchorage points.

between the seatback and the rear

Check that nothing is obstructing

parcel shelf. To do so, remove the rear

the anchorage points.

parcel shelf. ➥ 3.34

If your vehicle has been involved in

Check that the seatback

Attach the 3 hook on one of the 4 rings

a road accident, have the ISOFIX

of the forward-facing child

marked with the 

symbol.

anchorage points checked and re-

seat is in contact with the

place your child seat.

back of the vehicle seat.

In this case, the child seat may not

always rest on the base of the vehi-

cle seat.

1.46

CarManuals2.co

CHILD SAFETY: fitting a child seat, general information (2/2)

In the rear side seat

Always remove the headrest from the

rear seat on which the child seat is po-

A carrycot can be installed across the

sitioned. ➥ 3.31. If necessary, posi-

vehicle and will take up at least two

tion the rear seat as far back as pos-

seats. Position the child with his or her

sible. This must be done before fitting

feet nearest the door.

the child seat. Check that the child seat

Move the front seat as far forward as

is resting against the back of the rear

possible to install a rear-facing child

seat.

seat, then move back the seat in front

as far as it will go, although without al-

lowing it to come into contact with the

child seat.

For the safety of the child in the for-

ward-facing position:

- move the relevant seat backwards

as far as possible;

- move the seat in front of the child

A child seat with floor sup-

forwards, and set the position of the

ports must never be in-

Fit the child seat in a rear

seatback to avoid contact between

stalled on the rear centre

seat wherever possible.

the seat and the child’s legs.

seat.

To install an ISOFIX seat in

RISK OF DEATH OR SERIOUS

this seat, unbuckle the seat

INJURY.

belt by hand before engaging the

bolts.

When fitting a child seat

(Group 2 or 3 booster seat),

Fitting a seat ISOFIX in

check that the seat belts

the rear-left seat means

Ensure that the child seat

operate

(wind) correctly

the middle seat cannot be

or the child’s feet do not

➥ 1.28. If necessary, adjust the po-

used. The central seat belt

prevent the front seat from

sition of the vehicle seat.

will no longer be either accessible or

locking correctly. ➥ 3.32.

useable.

1.48

CarManuals2.co

CHILD SEATS: attachment by seat belt (1/3)

Fitting diagram

³

Check the status of the airbag

before fitting a child seat or allowing a

passenger to use the seat.

Seat not suitable for fitting

²

child seats.

Child seat attached using the belt

¬

Seat which allows a child seat

with “Universal” approval to be attached

by a seat belt.

RISK OF DEATH OR

SERIOUS INJURY: before

Using a child safety system

fitting a rear-facing child

which is not approved for

seat in this seat, make sure

this vehicle will not correctly

that the front passenger airbag has

protect the baby or child.

been deactivated. ➥ 1.55

For the rear central seat, the use of

They risk serious or even fatal injury.

a child seat without a floor support

leg is recommended.

1.49

CarManuals2.co

Content      ..      1      2      3      ..
