Peugeot Expert Dag (2006 year). Manual - part 5

Visibility -

When using a car wash,

switch off the ignition or

check that the windscreen

wipers stalk is in position

0-Off.

In winter, you are advised to wait un-

til the windscreen has been de-iced

fully before operating the windscreen

wipers stalk.

WINDSCREEN WIPER STALK

Front windscreen wiper

2 Fast wipe (heavy rain).

1 Normal wipe (moderate rain).

Intermittent wipe.

0 Off.


Single wipe (press downwards).

Operation

In position

1 or 2, when the vehicle

stops, the windscreen wiper chang-

es to a lower wiping speed, then

resumes its initial speed when the

vehicle starts again.

In the

Intermittent position, the wiping

speed is proportional to the speed of

the vehicle.

Windscreen and headlamp wash

Pull the windscreen wiper stalk to-

wards you. The windscreen wash

then the windscreen wipers operate

for a ﬁxed period.

The headlamp wash is also activated,

if the headlamps are on.

Visibility

64 -

ELECTRIC WINDOWS

1 - Driver's electric window

switch.

2 - Passenger's electric window

switch.

SLIDING SIDE WINDOW

To open the window, pull control

and push the window forwards.

To close the window, push it towards

the rear and press control

B to lock

it.

Always remove the key

from the ignition when leav-

ing the vehicle, even for a

short time.

If an obstacle is detected

when operating the electric windows,

you must reverse the movement of

the window. To do this, press the

control concerned.

When the driver operates the pas-

senger electric window controls, he

must ensure that no one is prevent-

ing correct closing of the windows.

The driver must ensure that passen-

gers use the electric windows cor-

rectly.

Be aware of children when operating

the windows.

Notes:

In the event of unwanted opening of

the window when closing (for exam-

ple, in the case of frost), press the

control until the window is fully open,

then pull it again until the window

closes. Continue to pull the control

for approximately one second after

closing.

Following reconnection of the battery,

in the event of a malfunction, release

the control and pull it again until the

window closes completely.

Continue to pull the control for ap-

proximately one second after closing.

Automatic operation

(driver's side):


press or pull the switch fully. One

touch completely opens the win-

dow.

You have two options:

Manual operation:


press or pull the switch gently.

The window stops as soon as the

switch is released.

Visibility -

MIRRORS

Electric exterior mirrors


Move switch

A to the right or to

the left to select the correspond-

ing mirror.



Move switch

A in all four direc-

tions to adjust.



Return switch

A to the centre po-

sition.

When parked, the mirrors can be

folded back manually.

Manual exterior mirrors

Move the lever in all four directions

to adjust.

When the vehicle is parked, the ex-

terior mirrors can be folded back

manually.

Manual interior mirror

The interior mirror has two positions:

- day (normal),

- night (anti-dazzle).

To change from one to the other,

push or pull the lever on the lower

edge of the mirror.

AREAS FOR TOLL CARDS/

CAR PARK TICKETS

The athermic windscreen has two

non-reﬂective zones located either

side of the base of the interior mirror.

They are intended for afﬁxing toll

cards and/or car park tickets.

Comfort and safety

66 -

HEADLAMP ADJUSTMENT

Depending on the load or the number

of people in your vehicle, it is recom-

mended that the headlamp beam is

adjusted.

0 - Empty/Driver only.

- - 2 or 3 people.

1 - Minimal load/5 or 6 people.

2 - Medium load/7 to 9 people.

3 - Maximum load/1 to 3 people

in the front + maximum

authorised loads.

Initial setting is position 0.

STEERING WHEEL HEIGHT

ADJUSTMENT

When stationary, push the handle

A fowards to unlock the steering

wheel.

Adjust it to the desired height.

Pull the handle

A towards you fully to

lock the steering wheel.

HAZARD WARNING LIGHTS

Press the button, the direction indica-

tors ﬂash.

They can operate with the ignition off.

HORN

Press the end of the lights

and direction indicators

stalk.

Comfort and safety -

COURTESY LIGHTS

1 - Front courtesy light

Horizontal position:

lighting on opening one of the front

doors.

Tilted position:

permanent lighting, key in the acces-

sories or ignition on position.

2 - Rear courtesy light (Combi)

Horizontal position:

off.

Tilted position:

on, key in the accessories or ignition

on position.

3 - Rear courtesy light (Van)

Horizontal position:

off.

Tilted position:

on, key in the accessories or ignition

on position.

Comfort and safety

68 -

1. Fittings in the doors

A. Armrest

B. Storage compartment.

C. Bottle holder/Can holder.

D. Storage compartment.

2. Overhead storage

Overhead storage maximum load:

5 kg.

3. Courtesy light

4. Sun visors

The sun visors are equipped with a ticket holder.

FRONT FITTINGS

Comfort and safety -

For greater safety, always

ensure that the loads trans-

ported are stowed securely.

5. Glove box or passenger

air bag*

This location is reserved either for a

glove box or for a passenger air bag

with a storage compartment.

6. Glove box

To open the glove box with cover,

push the handle towards the left.

It has two locations on the cover to

be used as can holders and an inter-

nal retaining strap.

LASHING RINGS

Use the 4 lashing rings on the lug-

gage compartment ﬂoor to secure

your loads.

7. Lighter

8. Removable ashtray

To open, lift the cover and release it;

the cover opens automatically.

To close, lift the cover to the stop and

fold it back.

To empty, after opening, press the

left edge of the cover then pull up-

wards to remove.

* According to destination.

Comfort and safety -

For greater safety, always

ensure that the loads trans-

ported are stowed securely.

5. Glove box or passenger

air bag*

This location is reserved either for a

glove box or for a passenger air bag

with a storage compartment.

6. Glove box

To open the glove box with cover,

push the handle towards the left.

It has two locations on the cover to

be used as can holders and an inter-

nal retaining strap.

LASHING RINGS

Use the 4 lashing rings on the lug-

gage compartment ﬂoor to secure

your loads.

7. Lighter

8. Removable ashtray

To open, lift the cover and release it;

the cover opens automatically.

To close, lift the cover to the stop and

fold it back.

To empty, after opening, press the

left edge of the cover then pull up-

wards to remove.

* According to destination.

Driving

72 -

If the battery is ﬂat and the

lever is in position

P, it will

be impossible to change to

another position.

"PORSCHE TIPTRONIC

SYSTEM" AUTOMATIC

GEARBOX

The four speed

automatic gearbox

offers a choice between the comfort

integral automatic operation, en-

hanced by a

snow program, or the

pleasure of

manual gear changing.

Gear selection gate



Move the lever in the gate to

select a position.

Once the position is selected, the

corresponding indicator light appears

on the instrument panel display.



: snow program

ark: to

immobilise the vehicle or

start the engine, with the handbrake

on or off.

everse: to

reverse (select this

position with the vehicle stationary,

engine at idle).

eutral: to

start the engine and to

park, with the handbrake on.

Note: if position N is engaged inad-

vertently while driving, allow the en-

gine to return to idle before engaging

position

D to accelerate.

rive: for

driving in automatic mode.

anual: for

driving in manual mode.

Moving off

With the engine running, to move off

from position



it is essential to press the brake

pedal to exit position P,



select position R, D or M, then

gradually release the pressure

on the brake pedal; the vehicle

moves off immediately.

You can also move off from position



with your foot on the brake, re-

lease the handbrake,



select position R, D or M, then

gradually release the pressure

on the brake pedal; the vehicle

moves off immediately.

WARNING
When the engine is at idle, brakes not

applied, if position

R, D or M is se-

lected the vehicle moves even with-

out the accelerator being pressed.

For this reason,

do not leave

children unsupervised inside the

vehicle, with the engine running.

When maintenance operations need

to be carried out with the engine run-

ning, apply the handbrake and select

position

Driving -

Automatic operation

Automatic changing of the

four

gears:


select position

D in the gate.

The gearbox always selects the most

suitable gear according to the follow-

ing parameters:

- the style of driving,

- the road proﬁle,

- the vehicle load.

The gearbox is then operating in

auto-adaptive mode, without any

action on your part.

WARNING

Never select position

N when the

vehicle is moving.

Never select positions

P or R unless

the vehicle is stationary.

Never change between positions

to optimise braking on a slippery

surface.

If you take your foot off the accel-

erator suddenly, the gearbox will not

change to a higher gear for reasons

of safety.

Snow program

In addition to the auto-adaptive pro-

gram, there is a special program.

The program is displayed on the

instrument panel screen.

The Snow program improves starting

and drive when traction is poor.


Press button  once the vehicle

has been started and position

selected.

The gearbox adapts to driving on

slippery roads.

Note: you can return to the auto-

adaptive program at any time.


Press button



again to switch off

the program you are in.

Manual operation

Manual changing of the

four gears:



select position

M in the gate,



push the lever to the

+ sign to

change to a higher gear,



pull the lever to the

- sign to

change to a lower gear.

You can change from position

(driving in automatic mode) to posi-

tion

M (driving in manual mode) at

any time.

Operating abnormality

Any operating abnormality is indicated

by an audible signal, accompanied by

ﬂashing of the Snow warning light on

the instrument panel.

In this situation the gearbox oper-

ates in downgrade mode (locked in

3rd gear). You may feel a substan-

tial knock when changing from

P to

R and from N to R (this will not cause

any damage to the gearbox).

Do not exceed 60 mph (100 km/h),

keeping within the limit of local speed

restrictions.

Contact a PEUGEOT dealer as soon

as possible.

Notes:

For immediate maximum accelera-

tion without touching the gear lever,

press the accelerator pedal down as

far as it will go (kick down). The gear-

box will automatically change down

or maintain the gear selected until

maximum engine speed is reached.

When braking, the gearbox will auto-

matically change down in order to

provide efﬁcient engine braking.

Notes:

It is only possible to change from one

gear to another if the vehicle speed

and engine speed permit. If they do

not, the vehicle will operate tempo-

rarily in automatic mode.

When the vehicle is stationary or

moving very slowly, the gearbox

automatically selects gear

M1.

The



(snow) program does not

operate in manual mode.

Driving

74 -

MANUAL GEARBOX

Reverse*

To change to reverse gear, lift the

ring under the gear lever knob and

push the gear lever to the left then to

the front.

Reverse gear can only be engaged

when the vehicle is stationary with

the engine idling.

* According to engine.

AIR BAGS

The air bags have

been designed to

maximise the safety of the occupants

in the event of serious collisions.

They work in conjunction with the

pretensioning seat belts with force

limiter.

The electronic detectors register and

analyse any abrupt deceleration of

the vehicle: if the triggering thresh-

old is reached, the air bags inﬂate in-

stantly and protect the occupants of

the vehicle.

Immediately after the impact, the air

bags deﬂate rapidly so that they do

not hinder the visibility of the occu-

pants nor their exit if necessary from

the vehicle.

The air bags are not deployed in the

case of minor collisions, for which the

seat belt is sufﬁcient to ensure maxi-

mum protection. The seriousness of

a collision depends on the nature of

the obstacle and the speed of the ve-

hicle at the moment of impact.

Air bags only operate when the

ignition is switched on.

Note: the gas escaping from the air

bags can be a minor irritant.

FRONT AIR BAGS

These are folded in the centre of the

steering wheel for the driver and in

the fascia for the front passenger

(one seat). They are deployed simul-

taneously.

If this warning light comes

on on the instrument panel,

accompanied by an audible

signal, contact a PEUGEOT

dealer to have the system

checked.

Front air bag fault

Driving

70 -

HANDBRAKE

Lighting of this warning light,

while the vehicle is moving,

indicates that the handbrake

is still applied or has not been

released correctly.

When parking on a slope,

direct your wheels towards

the pavement and apply the

handbrake.

Only apply the handbrake

when the vehicle is stationary.

Illumination of this warning

light, accompanied by an

audible signal, indicates a

malfunction of the electron-

ic brake force distribution,

which can cause a loss of control of

the vehicle when braking.

Stop immediately.

Contact a PEUGEOT dealer.

Applying

When parking, pull the handbrake to

immobilise your vehicle.

Releasing

Pull the handle and press the button

to release the handbrake.

ANTI-LOCK BRAKING

SYSTEM (ABS)

The ABS with Electronic Brake Force

Distribution (EBFD) increases the

stability and manoeuvrability of your

vehicle, particularly on poor or slip-

pery road surfaces.

Note: when changing wheels (tyres

and rims), make sure that these are

approved.

The anti-lock braking system comes

into operation automatically when

there is a risk of wheel lock.

Normal operation of the ABS may

make itself felt by slight vibrations

of the brake pedal.

In emergency braking, press very

ﬁrmly without releasing the pres-

sure.

Driving -

On a steep slope, the cruise

control will not be able to

prevent the vehicle from

exceeding the programmed

speed.

The cruise control cannot, in any cir-

cumstances, replace the need to re-

spect speed limits nor can it replace

the need for vigilance and responsi-

bility on the part of the driver.

Do not use cruise control on slippery

roads or in heavy trafﬁc.

CRUISE CONTROL

Cruise control enables the vehicle

to maintain a steady speed pro-

grammed by the driver.

In order for it to be memorised,

the vehicle speed must be greater

than 25 mph (40 km/h) or 40 mph

(60 km/h), (according to engine), with

at least 4th gear engaged (second

for the automatic gearbox).

Operation



Press switch

A. The indicator light

will come on.

A speed can be memorised.


Press switch

A again to cancel.

The indicator light will switch off.

Memorising a speed

As soon as you reach the chosen

speed, push stalk

B upwards or

downwards. This memorises the

speed, which will be maintained

automatically.

Note: it is possible to accelerate

momentarily without disarming the

cruise control.

Cancelling the memorised

speed



Pull stalk

B towards you or press

the brake or clutch pedal.

Recalling the memorised

speed

After cancellation, push stalk

B up-

wards or downwards. Your vehicle

will return to the last memorised

speed.

Changing the memorised

speed

To memorise a speed higher than the

previous one:


keep stalk

B pressed upwards;



release it when you have reached

the required speed.

To memorise a speed lower than the

previous one:


keep stalk

B pressed downwards;



release it when you have reached

the required speed.

Disarming the cruise control



Press switch

A to switch the sys-

tem off or switch off the ignition.

Driving

74 -

MANUAL GEARBOX

Reverse*

To change to reverse gear, lift the

ring under the gear lever knob and

push the gear lever to the left then to

the front.

Reverse gear can only be engaged

when the vehicle is stationary with

the engine idling.

* According to engine.

AIR BAGS

The air bags have

been designed to

maximise the safety of the occupants

in the event of serious collisions.

They work in conjunction with the

pretensioning seat belts with force

limiter.

The electronic detectors register and

analyse any abrupt deceleration of

the vehicle: if the triggering thresh-

old is reached, the air bags inﬂate in-

stantly and protect the occupants of

the vehicle.

Immediately after the impact, the air

bags deﬂate rapidly so that they do

not hinder the visibility of the occu-

pants nor their exit if necessary from

the vehicle.

The air bags are not deployed in the

case of minor collisions, for which the

seat belt is sufﬁcient to ensure maxi-

mum protection. The seriousness of

a collision depends on the nature of

the obstacle and the speed of the ve-

hicle at the moment of impact.

Air bags only operate when the

ignition is switched on.

Note: the gas escaping from the air

bags can be a minor irritant.

FRONT AIR BAGS

These are folded in the centre of the

steering wheel for the driver and in

the fascia for the front passenger

(one seat). They are deployed simul-

taneously.

If this warning light comes

on on the instrument panel,

accompanied by an audible

signal, contact a PEUGEOT

dealer to have the system

checked.

Front air bag fault

Driving -

SIDE AIRBAGS*

These are incorporated into the

frame of the driver and front passen-

ger (one seat) seat back, on the door

side.

They are deployed independently

of each other depending on which

side the collision occurs, in collisions

which could cause injury to the chest,

the abdomen or the head.

This is conﬁrmed by an

indicator light on the instru-

ment panel.

It comes on for six sec-

onds, each time the ignition

is switched on.

Operating check

If the indicator light:

- does not light up when the ignition

is switched on, or

- does not go out after six seconds,

- ﬂashes for ﬁve minutes then stays

on,

contact a PEUGEOT dealer.

For the front and side* air

bags to be fully effective,

observe the following

safety rules:

• Wear a correctly adjusted seat

belt.

• Sit in a normal upright position.

• Do not leave anything between the

occupants and the air bags (child,

animal, object...).

This could hamper the operation of

the air bags or injure the occupants.

• All work on the air bag systems is

strictly prohibited unless it is car-

ried out by qualiﬁed personnel of

the PEUGEOT network.

• After an accident or if the vehicle

has been stolen or broken into,

have the air bag systems checked.

Front air bags

• Do not drive holding the steering

wheel by its spokes or resting your

hands on the centre part of the

wheel.

• Passengers must not place their

feet on the fascia.

• Smoke as little as possible; deploy-

ment of the air bags can cause

burns or the risk of injury from a

cigarette or pipe.

• Never remove or pierce the steer-

ing wheel or hit it violently.

* According to country.

Side air bags*

• Only put approved covers on the

front seats. Contact your PEUGEOT

dealer.

• Do not ﬁx or glue anything to the

front seat backs. This could cause

injury to the chest or arms when the

side air bag inﬂates.

• Do not sit with the upper part of the

body any nearer to the door than

necessary.

Driving -

SIDE AIRBAGS*

These are incorporated into the

frame of the driver and front passen-

ger (one seat) seat back, on the door

side.

They are deployed independently

of each other depending on which

side the collision occurs, in collisions

which could cause injury to the chest,

the abdomen or the head.

This is conﬁrmed by an

indicator light on the instru-

ment panel.

It comes on for six sec-

onds, each time the ignition

is switched on.

Operating check

If the indicator light:

- does not light up when the ignition

is switched on, or

- does not go out after six seconds,

- ﬂashes for ﬁve minutes then stays

on,

contact a PEUGEOT dealer.

For the front and side* air

bags to be fully effective,

observe the following

safety rules:

• Wear a correctly adjusted seat

belt.

• Sit in a normal upright position.

• Do not leave anything between the

occupants and the air bags (child,

animal, object...).

This could hamper the operation of

the air bags or injure the occupants.

• All work on the air bag systems is

strictly prohibited unless it is car-

ried out by qualiﬁed personnel of

the PEUGEOT network.

• After an accident or if the vehicle

has been stolen or broken into,

have the air bag systems checked.

Front air bags

• Do not drive holding the steering

wheel by its spokes or resting your

hands on the centre part of the

wheel.

• Passengers must not place their

feet on the fascia.

• Smoke as little as possible; deploy-

ment of the air bags can cause

burns or the risk of injury from a

cigarette or pipe.

• Never remove or pierce the steer-

ing wheel or hit it violently.

* According to country.

Side air bags*

• Only put approved covers on the

front seats. Contact your PEUGEOT

dealer.

• Do not ﬁx or glue anything to the

front seat backs. This could cause

injury to the chest or arms when the

side air bag inﬂates.

• Do not sit with the upper part of the

body any nearer to the door than

necessary.

Content .. 3 4 5 6 ..
