Peugeot 208 (2017 year). Manual - part 18

Audio system / Bluetooth

Increase volume.

Decrease volume.

Mute on: cut the sound by
simultaneously pressing the volume
up and down buttons.
Mute off: press one of the two
volume buttons.

Radio

Presetting a station

Press SRC/TEL repeatedly to select
the FM1, FM2 or AM waveband.

Press and hold a button to preset
the station being listened to. The
name of the station is displayed and
an audible signal confirms that it has
been preset.

The external environment (hills, buildings,
tunnels, basement car parks, etc.) may
block reception, including in RDS tracking
mode. This is a normal effect of the way
in which radio waves are transmitted and
does not indicate any failure of the audio
equipment.

Selecting a station

Press a button to listen to the
corresponding preset station.

Managing a list

Press LIST to display the list of
stations received in alphabetical
order.

Select the desired radio station
using one of the buttons.

Confirm with "OK".

Briefly press one of the buttons to
change to the next or previous letter.

Press and hold LIST to build or
update the list of stations; audio
reception is cut momentarily.

Entering a frequency

Press MENU.

Audio system / Bluetooth

Select "Radio".

Select "Write freq.".

Press +,

press – to select the desired
frequency.

Confirm with "OK".

RDS

RDS, if activated, allows you to
continue listening to the same station
by automatically retuning to alternative
frequencies. However, in certain conditions,
coverage of an RDS station may not be
assured throughout the entire country as
radio stations do not cover 100% of the
territory. This explains the loss of reception
of a station that can occur during a journey.

With source FM1 or FM2, press
MENU.

Select "Radio".

Select or deselect "RDS" to switch
RDS on or off.

Confirm with "OK" to save the
setting.

Receiving TA messages

The TA (Traffic Announcement) function
gives priority to TA alert messages.
To operate, this function needs good
reception of a radio station transmitting
this type of message. When a traffic
report is transmitted, the current audio
source (radio, CD, USB, etc.) is interrupted
automatically to play the TA message.
Normal playback resumes at the end of
the transmission of the message.

Press MENU.

Select "Radio".

Select or deselect "TA" to activate
or deactivate the reception of traffic
messages.

Confirm with "OK" to save the
setting.

Displaying RADIO TEXT

Radio Text is information transmitted by
the radio station related to the current
programme or song.

With the radio displayed on the
screen, press MENU.

Select "Radio".

Audio system / Bluetooth

Select or deselect "TXT" to activate
or deactivate the display of Radio
Text.

Confirm with "OK" to save the
setting.

Media

USB player

This unit comprises a USB port and a jack
socket, depending on model.

The system builds playlists (in temporary
memory), an operation which can take
from a few seconds to several minutes at
the first connection.
Limiting the number of non-music files and
the number of folders reduces this waiting
time. The playlists are updated every
time the ignition is switched off or a USB
memory stick is connected.
The lists are memorised: if they are not
modified, the subsequent loading time will
be shorter.

At the first connection, the order
suggested is by folder. When connecting
again, the previously chosen order is
retained.

Insert the USB memory stick into the USB port
or connect the USB device to the USB port
using a suitable cable (not supplied).

Press SRC/TEL repeatedly to select
"USB".

Press one of these buttons to select
the previous or next track in the list.

Press one of these buttons to select
the previous or next folder according
to the category chosen.

Press and hold one of these buttons
for fast forward or rewind.

Press LIST to display the structure
of the folders in the compilation.

Audio system / Bluetooth

Select a line in the list.

Confirm with "OK".

Up a level in the menu.

Press MENU.

Select "Media".

Select or deselect "TA" to activate
or deactivate the reception of traffic
messages.

Select the play mode: "Normal",
"Random", "Random all" or
"Repeat".

Auxiliary socket (AUX)

Connect the portable device (MP3 player, etc.)
to the jack socket using an audio cable (not
supplied).

Press SRC/TEL repeatedly to select
"AUX".

First adjust the volume of your portable device
(to a high level). Then adjust the volume of your
audio system. The controls are operated from
the portable device.

Do not connect a device to both the jack
socket and the USB port at the same time.

CD player

Insert a CD in the player; play begins
automatically.
Insert an MP3 compilation in the CD player.
The audio system searches for all of the music
tracks, which may take anything between a few
seconds and several tens of seconds, before
play begins.

Press the SRC/TEL button
repeatedly to select "CD".

Press one of these buttons to go to
the previous / next track in the list.

Press one of these buttons to select
the previous or next folder in the
order chosen.

Press and hold one of these buttons
for fast forward or rewind.

Press LIST to display the folder
structure of the compilation.

Audio system / Bluetooth

Select a line in the list.

Confirm with "OK".

Return to the top level of the folder structure to
select the type of tracks.
- By

Folders (CD or USB): all folders

containing audio files recognised on the
peripheral device, in alphabetical order
without following the folder structure.

- By

Artist (USB only): all of the artist names

defined in the ID3 Tags, in alphabetical
order.

- By

Genre (USB only): all of the genres

defined in the ID3 Tags.

- By

Playlist (CD or USB): if playlists have

been saved.

Information and advice

The audio system will only play files with
".mp3", ".wma" and ".wav" extensions on a CD
and can play files with ".ogg" extension only on
USB.

To avoid any playback or display issues, it is
advisable to create file names that have less
than 20 characters and without using any
special characters (e.g. «?.; ù).

In order to be able to play a recorded CDR or
CDRW, it is preferable to select the ISO 9660
level 1, 2 or Joliet standard when recording the
CD.
If the disc is burned in another format, it may
not be played correctly.
It is recommended that the same recording
standard is always used for a given disc, with
as low a speed as possible (4x maximum) for
optimum sound quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

The playlists accepted on CD, MP3, iPod and
USB connection are types ".m3u" and ".wpl".
The system can recognise up to 5,000 files in
500 folders on 8 levels.

On a single disc, the CD player can read up
to 255 MP3 files spread over 8 folder levels
with a maximum of 192 folders. However, it
is recommended that the number of levels is
limited to 2 so as to reduce the time taken to
access and play the CD.
The folder structure is not observed during
playback.

Do not connect a hard disk or USB device other
than audio players to the USB port. This may
cause damage to your installation.

Use only USB memory sticks formatted FAT32
(File Allocation Table).

It is recommended that you use genuine
Apple

USB cables for correct operation.

Bluetooth

audio streaming

Streaming allows music files on the telephone
to be played through the vehicle's speakers.

Connect the telephone: see the "Telephone"
section.

In the "Bluetooth: Audio" menu, select the
telephone to be connected.
The audio system connects to a newly paired
telephone automatically.

Audio system / Bluetooth

Activate the streaming source by
pressing the SRC/TEL* button.

The control of common tracks is possible
via the audio system control buttons and the
steering mounted controls**. The contextual
information can be displayed in the screen.

The audio quality depends on the quality of the
transmission from the telephone.

Connecting Apple

players

Connect the Apple

player to the USB port

using a suitable cable (not supplied).
Play starts automatically.

Management of the device is via the audio
system controls.

The classifications available are those of the
portable device connected (artists / albums /
genres / playlists / audio books / podcasts).

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

* In certain cases, play of the audio files must

be initiated from the keypad.

** If the telephone supports the function.

Telephone

Pairing a Bluetooth

telephone

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-free
system of your audio system must be done
with the vehicle stationary and the ignition
on.

Visit www.peugeot.co.uk for more information
(compatibility, more help, etc.).

Activate the telephone's Bluetooth function and
ensure that it is set as visible to all (refer to the
telephone user guide).

Press the MENU button.

Audio system / Bluetooth

Select "Bluetooth".

Select "Search".

A window is displayed with "Searching
device".

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth telephone
used.
Check the instructions for your telephone
and with your service provider for the
services to which you have access.

In the list, select a telephone to pair.

Confirm with "OK".

Only one telephone can be paired at a time.

In some cases, the Bluetooth address of the
telephone may appear instead of the name of
the telephone.

A virtual keypad is displayed on the
screen: choose a 4-digit code.

Confirm with "OK".

A message is displayed on the screen of the
telephone: enter the same code and confirm.

If pairing fails, the number of attempts is not
restricted.

A message appears in the screen to confirm
the result of the connection.

Pairing can also be initiated from the
telephone by searching for detected
Bluetooth devices.

The directory and the call list can
be accessed after the necessary
synchronisation period (if the telephone is
compatible).
Automatic connection must be configured
in the telephone to allow the connection
each time the vehicle is started.

Managing connections

Press the MENU button.

Select "Bluetooth".

Select "BT management"
and confirm. The list of paired
telephones is displayed.

Indicates connection of the audio
profile.

Indicates the hands-free telephone
profile.

In the list, select a telephone to pair.

Confirm with "OK".

Audio system / Bluetooth

"Delete" to delete the pairing.

It is not possible to pair more than 5
telephones, Press MENU and select
"Bluetooth". Select "BT management". If
5 telephones are already paired, select the
telephone to delete by pressing "OK" and
selecting "Delete" (refer to the "Managing
connections" section).

Making a call

From the directory

Press the MENU button.

Select "Telephone".

Select "Call".

Select "Directory".

Select the desired number.

Confirm with "OK" to start the call.

Making a call

Recently called numbers

(Depending on the compatibility of the phone)

Press and hold SRC/TEL to display
the calls list.

For access to the call list, it is also
possible to press MENU, select
"Telephone", then select "Call" and finally
select "Calls list".

In the list of calls, select from:
"Missed calls", "Dialled calls" or
"Answered calls".

Scroll through the calls list.

Confirm with "OK".

Press one of these buttons to go to
the previous or next page in the list.

"OK" starts the call.

Select or deselect:
- "Tel.": hands-free connection
- "Audio": play audio files

"OK" to confirm the choice.

Audio system / Bluetooth

The calls list includes calls sent and
received in the vehicle using the
connected telephone.
It is possible to make a call directly from
the telephone; park the vehicle first as a
safety measure.

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Press SRC/TEL.

select "YES" to accept the call,

select "NO" to reject the call.

Pressing and holding the back
button,

SRC/TEL also rejects an incoming
call.

Managing calls

Hang up

In the contextual menu, select
"Hang up" to end the call.

Pressing and holding SRC/TEL also
ends the call.

Secret – Mute

(so that the caller cannot hear)

In the contextual menu:

Select "Micro OFF" to switch off the
microphone.

Select "Micro OFF" to switch the
microphone on again.

Combined mode

(to leave the vehicle without ending the call)

In the contextual menu:

Select "Combined mode" to
transfer the call to the telephone.

Select "Combined mode" to
transfer the call to the vehicle.

In some cases, the combined mode has to
be activated from the telephone.
The Bluetooth connection will be restored
automatically if the ignition has been
switched off, then on again (depending on
the compatibility of the telephone).

Audio system / Bluetooth

Audio settings

Press ¯ to display the audio
settings menu.
Press ¯ to go to the next setting.

The settings available are:
- AMBIANCE: BASS, TREBLE and

LOUDNESS.

- BALANCE (left/right balance), FADER

(front/rear balance)

- SOUND DIST. (driver or passenger).
- AUTO VOLUME.

The distribution, or spatialisation of sound,
is an audio process which allows the
sound quality to be improved according to
the setting chosen, corresponding to the
position of the listeners in the vehicle.

The AMBIANCE, TREBLE and BASS
audio settings are different and
independent for each sound source.

Configuration

Display and language settings

Press the MENU button.

Select "Config.".

Select "Displaying" to activate or
deactivate scrolling text.

Select "Language" to modify the
display language.

Select "Version" for information on
the software.

Select "System" when you want to
install an update. Information can be
obtained from a PEUGEOT dealer.

Select "Unit" to modify the units for
temperature (Celsius, Fahrenheit).

Frequently asked
questions

The following information groups together the
answers to the most frequently asked questions
concerning your audio system.

Audio system / Bluetooth

QUESTION

RESPONSE

SOLUTION

There is a difference in sound quality between
the different audio sources (radio, CD, etc.).

For optimum sound quality, the audio settings
(volume, bass, treble, ambience, loudness)
can be adapted to the different sound sources,
which may result in audible differences when
changing source (radio, CD, etc.).

Check that the audio settings (volume, bass,
treble, ambience, loudness) are adapted to
the sources being listened to. It is advisable to
set the AUDIO functions (bass, treble, front-
rear balance, left-right balance) to the middle
position, select the musical ambience and set
the loudness correction to the "Active" position
in CD mode or to the "Inactive" position in radio
mode.

When changing the settings for treble and bass,
the ambience setting is deselected.
When changing the ambience setting, treble
and bass are reset to zero.

Choosing an ambience imposes settings for
treble and bass. Modifying one without the other
is only possible with a personalised ambience.

Modify the treble and bass settings or the
ambience setting to obtain the desired sound
quality.

When changing the balance setting, distribution
is deselected.

Choosing the "driver" distribution setting
imposes a balance setting.

Modify the balance or distribution settings to
obtain the desired sound quality.

The reception quality of the tuned radio station
gradually deteriorates or the stored stations are
not working (no sound, 87.5 MHz is displayed,
etc.).

The vehicle is too far from the transmitter of
the station or no transmitter is present in the
geographical area.

Activate the RDS function to enable the system
to check whether there is a more powerful
transmitter in the geographical area.

The surroundings (hills, buildings, tunnels,
underground parking, etc.) are blocking
reception, including in RDS tracking mode.

This phenomenon is normal and does not
indicate a failure of the audio equipment.

The aerial is missing or has been damaged (for
example when going through a car wash or into
an underground car park).

Have the aerial checked by a PEUGEOT dealer.

Audio system / Bluetooth

Sound cut-outs of 1 to 2 seconds in radio mode.

During this brief sound cut-out, the RDS
searches for any frequency permitting better
reception of the station.

Deactivate the RDS function if the phenomenon
is too frequent and always on the same route.

Traffic announcement TA is displayed. I do not
receive any traffic information.

The radio station does not broadcast traffic
information.

Tune to a radio station which broadcasts traffic
information.

The stored stations are not found (no sound,
87.5 MHz is displayed, etc.).

An incorrect waveband is selected.

Press the SRC/TEL button to return to the
waveband (FM1 or FM2) on which the stations
are stored.

The CD is ejected every time or is not played.

The CD is upside down, cannot be read, does
not contain audio files or contains audio files
of a format that cannot be played by the audio
system.
The CD is protected by an anti-pirating system
not recognised by the audio system.

- Check that the CD is inserted in the player

the right way up.

- Check the condition of the CD: the CD

cannot be played if it is too badly damaged.

- Check the content in the case of a recorded

CD: consult the advice in the "Audio"
section.

- The audio system’s CD player does not play

DVDs.

- Because of low quality, certain burned CDs

will not be read by the audio system.

The CD sound is of poor quality.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in
suitable conditions.

The audio settings (bass, treble, ambiences) are
unsuitable.

Return bass and treble settings to 0, without
selecting an ambience.

The Bluetooth connection is cut.

The battery of the peripheral may not be
sufficiently charged.

Charge the battery of the peripheral device.

Audio system / Bluetooth

The "USB peripheral error" or "Peripheral not
recognised" message appears on the screen.

The USB memory stick is not recognised.

Use only USB memory sticks formatted to FAT
32 (28-bit file allocation table).

A telephone connects automatically,
disconnecting another telephone.

Automatic connection overrides manual
connection.

Modify the telephone settings to remove
automatic connection.

The iPod is not recognised when connecting to
the USB port.

The iPod is of a generation that is not
compatible with the USB.

The hard disk or device is not recognised when
connecting to the USB socket.

Some hard disks and devices need a power
supply greater than is provided by the audio
system.

Connect the peripheral to the 230 V socket, the
12 V socket or an external power supply.
Caution: ensure that the device does not
transmit a voltage greater than 5 V (risk of
destruction of the system).

When streaming, the sound cuts momentarily.

Some telephones prioritise connection of the
"hands-free" profile.

Delete the "hands-free" connection profile to
improve streaming.

In "Random all" play, not all of the tracks are
played.

In "Random all" play, the system can only take
into account up to 999 tracks.

With the engine off, the audio system switches
off after a few minutes of use.

When the engine is switched off, the audio
system operating time depends on the battery
charge.
The switch-off is normal: the audio system
switches to economy mode and switches off to
prevent discharging the vehicle's battery.

Start the vehicle’s engine to increase the battery
charge.

The message "the audio system is overheated"
appears on the display.

In order to protect the installation if the
surrounding temperature is too high, the audio
system switches to an automatic thermal
protection mode leading to a reduction of the
volume or stopping of the playing of the CD.

Switch the audio system off for a few minutes to
allow the system to cool.

Audio system

Contents

First steps

Steering mounted controls

Radio 3
Media 5
Audio settings

Frequently asked questions

For safety reasons, the vehicle must
always be stationary for the driver to
perform operations that require close
attention.
When the engine is switched off and to
prevent discharging of the battery, the
system switches off after activation of
energy economy mode.

Audio system

First steps

On/Off, volume adjustment.

Select the source:
FM1, FM2, AM, CD, AUX.

Adjust audio settings:
sound ambience, treble, bass,
loudness, left/right balance,
automatic volume.

Automatic search for a lower radio
frequency.
Select the previous CD track.
Scroll in a list.
Press and hold: rewind.

Display the list of stations received,
the CD/MP3 tracks or folders.
Press and hold: update the list of
stations received.

Manual search step by step for a
higher radio frequency.
Select the next MP3 folder.
Scroll in a list.

Manual search step by step for a
lower radio frequency.
Select the previous MP3 folder.
Scroll in a list.

Cancel the current operation.
Go up one level (menu or folder).

Automatic search for a higher radio
frequency.
Select the next CD track.
Scroll in a list.
Press and hold: fast forward.

Access to the main menu.

Select a preset radio station.
Radio, press and hold: store a
station.

Eject CD.

Steering mounted controls

Radio: select the previous / next
preset radio station.
Select the previous / next item in a
menu.

Radio: automatic search for a higher
frequency.
CD / MP3: select the next track.
CD: press and hold: fast forward.

Change the audio source.
Confirm a selection.

Radio: automatic search for a lower
frequency.
CD / MP3: select the previous track.
CD: press and hold: rewind.

Increase volume.

Decrease volume.

Content .. 16 17 18 19 ..
