Peugeot 208 (2017 year). Manual - part 19

Audio system

Mute on: cut the sound by
simultaneously pressing the volume
up and down buttons.
Mute off: press one of the two
volume buttons.

Radio

Presetting a station

Press the SRC/BAND button
repeatedly to select the FM1, FM2 or
AM waveband.

Press and hold a button to preset
the station being listened to. The
name of the station is displayed and
an audible signal confirms that it has
been preset.

The external environment (hills, buildings,
tunnels, basement car parks, etc.) may
block reception, including in RDS tracking
mode. This is a normal effect of the way
in which radio waves are transmitted and
does not indicate any failure of the audio
equipment.

Selecting a station

Press a button to listen to the
corresponding preset station.

Managing the list

Press LIST to display the list of
stations received in alphabetical
order.

Select the desired radio station by
pressing one of the buttons.

Confirm with OK.

Briefly press one of the buttons to
change to the next or previous letter.

Press and hold LIST to build or
update the list of stations; audio
reception is cut momentarily.

Audio system

Press MENU.

Select "Radio".

Confirm with OK.

Select "RDS".

Confirm with OK.

Select "On" or "Off" to switch RDS
on or off.

Confirm with OK.

Receiving TA messages

The TA (Traffic Announcement) function
gives priority to TA alert messages.
To operate, this function needs good
reception of a radio station transmitting
this type of message. When a traffic
report is transmitted, the current audio
source (radio, CD, etc.) is interrupted
automatically to play the TA message.
Normal playback resumes at the end of
the transmission of the message.

Press MENU.

Select "Radio".

RDS

RDS, if displayed, allows you to
continue listening to the same station
by automatically retuning to alternative
frequencies. However, in certain
conditions, coverage of an RDS station
may not be assured throughout the entire
country as radio stations do not cover
100% of the territory. This explains the
loss of reception of a station during a
journey.

Confirm with OK.

Select "Traffic TA".

Confirm with OK.

Select "On" or "Off" to activate or
deactivate the reception of traffic
messages.

Confirm with OK.

Displaying RADIO TEXT

Radio Text is information transmitted by
the radio station related to the current
programme or song.

Audio system

Press MENU.

Select "Radio".

Confirm with OK.

Select "INFO TEXT".

Confirm with OK.

Select "On" or "Off" to switch Radio
Text on or off.

Confirm with OK.

Media

Auxiliary socket (AUX)

Connect the portable device (MP3 player, etc.)
to the jack socket using an audio cable (not
supplied).

Press the SRC/BAND button
repeatedly until the "AUX" source is
displayed.

First adjust the volume of your portable device
(to a high level). Then adjust the volume of your
audio system. The controls are operated from
the portable device.

CD player

Insert a CD in the player; play begins
automatically.
Insert an MP3 compilation in the CD player.
The audio system searches for all of the music
tracks, which may take anything between a few
seconds and several tens of seconds, before
play begins.

Press the SRC/BAND button
repeatedly to select "CD".

Press one of these buttons to go to
the previous / next track in the list.

Press one of these buttons to select
the previous or next folder in the
order chosen.

Press and hold one of these buttons
for fast forward or rewind.

Audio system

Playing a compilation

Press LIST to display the folder
structure of the compilation.

Select a line in the list.

Confirm with "OK".

Jump a page.

Select a folder / Playlist.

Start play of the chosen track.

Go up one level.

Go back to the first level to select the track
classification:
- By

Folders: all folders containing audio

files recognised on the peripheral device,
in alphabetical order, ignoring the folder
structure.

- By

Playlist: depending on the playlists

saved.

Play mode

Press MENU.

Select "Media".

Confirm with OK.

Select the desired play mode.

Confirm with OK to save the
changes.

The play modes available are:
- Normal: the tracks are played in order,

depending on the classification of the
selected files.

- Random: the tracks in an album or

folder are played in a random order.

- Random all: all of the tracks saved in

the media are played in random order.

- Repeat: the tracks played are only

those from the current album or folder.

Information and advice

The audio system can only play files with
".mp3", ".wma" or ".wav" extensions.

To avoid any playback or display issues, it is
advisable to create file names that have less
than 20 characters and without using any
special characters (e.g. «?.; ù).

In order to be able to play a recorded CDR or
CDRW, it is preferable to select the ISO 9660
level 1, 2 or Joliet standard when recording the
CD.
If the disc is burned in another format, it may
not be played correctly.

Audio system

It is recommended that the same recording
standard is always used for a given disc, with
as low a speed as possible (4x maximum) for
optimum sound quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

Playlists accepted are ".m3u" and ".pls" types.
The system can recognise up to 5,000 files in
500 folders on 8 levels.

On a given disc, the CD player can read up to
255 MP3 files spread over 8 levels. However,
it is recommended that this be kept to 2 levels
so as to limit the time taken to access and play
the CD.
The folder structure is not observed during
playback.

Audio settings

Press ¯ to display the audio
settings menu.

The settings available are:
- AMBIANCE,
- BASS,
- TREBLE,
- LOUDNESS,
- BALANCE,
- AUTO VOLUME.

Select the setting to adjust.

Confirm with OK.

Adjust the setting.

Confirm with OK.

The AMBIANCE, TREBLE and BASS
audio settings are different and
independent for each sound source.

Frequently asked
questions

The following information groups together the
answers to the most frequently asked questions
concerning your audio system.

Audio system

QUESTION

RESPONSE

SOLUTION

There is a difference in sound quality between
the different audio sources (radio, CD, etc.).

To allow for optimal listening quality, the audio
settings (Volume, Bass, Treble, Ambience,
Loudness) can be tailored to different
sound sources, which can generate audible
differences when changing source (radio, CD,
etc.).

Check that the audio settings (Volume, Bass,
Treble, Ambience, Loudness) are adapted to
the sources listened to. It is advisable to set
the AUDIO functions (Bass, Treble, Front-
Rear Fader, Left-Right Balance) to the middle
position, select the musical ambience "None"
and set the loudness correction to the "Active"
position in CD mode or to the "Inactive" position
in radio mode.

When changing the settings for treble and bass,
the ambiance setting is deselected.
When changing the ambience setting, treble
and bass are reset to zero.

Choosing an ambience imposes settings for
treble and bass. Modifying one without the other
is not possible.

Modify the treble and bass settings or the
ambience setting to obtain the desired sound
quality.

The reception quality of the tuned radio station
gradually deteriorates or the stored stations are
not working (no sound, 87.5 MHz is displayed,
etc.).

The vehicle is too far from the transmitter of
the station or no transmitter is present in the
geographical area.

Activate the RDS mode and start a new search
for the station so that the system can check
whether a stronger transmitter is available in the
geographic area.

The environment (hills, buildings, tunnels,
basement car parks, etc.) block reception,
including in RDS tracking mode.

This phenomenon is normal and does not
indicate a failure of the audio equipment.

The aerial is missing or has been damaged (for
example when going through a car wash or into
an underground car park).

Have the aerial checked by a PEUGEOT dealer.

Audio system

Sound cut-outs of 1 to 2 seconds in radio mode.

During this brief sound cut-out, the RDS
searches for any frequency permitting better
reception of the station.

Switch off the RDS function if the phenomenon
is too frequent and always on the same route.

The traffic announcement (TA) is displayed. I do
not receive any traffic information.

The radio station does not broadcast traffic
information.

Tune to a radio station which broadcasts traffic
information.

The stored stations are not found (no sound,
87.5 MHz is displayed, etc.).

An incorrect waveband is selected.

Press the SRC button to return to the waveband
(AM, FM1, FM2) on which the stations are
stored.

The CD is ejected every time or is not played.

The CD is upside down, cannot be read, does
not contain audio files or contains audio files
of a format that cannot be played by the audio
system.
The CD is protected by an anti-pirating system
not recognised by the audio system.

- Check that the CD is inserted in the player

the right way up.

- Check the condition of the CD: the CD

cannot be played if it is too badly damaged.

- Check the content in the case of a recorded

CD: consult the advice in the "Audio"
section.

- The audio system’s CD player does not play

DVDs.

- Because of low quality, certain burned CDs

will not be read by the audio system.

The CD sound is of poor quality.

The CD used is scratched or of poor quality.

Insert good quality CDs and store them in
suitable conditions.

The audio settings (bass, treble, ambiences) are
unsuitable.

Return bass and treble settings to 0, without
selecting an ambience.

Audio system

In "Random all" play, not all of the tracks are
played.

In "Random all" play, the system can only take
into account up to 999 tracks.

With the engine off, the audio system switches
off after a few minutes of use.

When the engine is switched off, the audio
system operating time depends on the battery
charge.
The switch-off is normal: the audio system
switches to economy mode and switches off to
prevent discharging the vehicle's battery.

Start the vehicle’s engine to increase the battery
charge.

The message "the audio system is overheated"
appears on the display.

In order to protect the installation if the
surrounding temperature is too high, the audio
system switches to an automatic thermal
protection mode leading to a reduction of the
volume or stopping of the playing of the CD.

Switch the audio system off for a few minutes to
allow the system to cool.

195

Alphabetical index

Accessories ....................................................75
Access to rear seats ................................. 50-52
Active City Brake .................................... 127-128
AdBlue

additive ........................ 17, 27, 152 -154

Adjusting headlamps ...................................... 71
Adjusting head restraints ................................49
Adjusting seats .................................... 48, 50-52
Adjusting the air distribution ..................... 57-60
Adjusting the air flow ................................. 57-60
Adjusting the date .............................. 33 , 36, 20
Adjusting the height and reach

of the steering wheel ....................................46

Adjusting the seat belt height ................... 81-82
Adjusting the temperature ........................ 57-60
Adjusting the time .........................33-34 , 36, 20
Advice on driving ...................................105-107
Airbags ................................................15 , 84, 89
Airbags, curtain ......................................... 86-87
Airbags, front.......................................85, 87 , 90
Airbags, lateral .......................................... 86-87
Air conditioning .............................................104
Air conditioning, automatic ................. 55, 57-60
Air conditioning, digital ............................. 57-60
Air conditioning, manual ..................... 55-57, 60
Air intake ................................................... 57-60
Alarm ......................................................... 41-43
Anti-lock braking system (ABS) ......................78
Anti-slip regulation (ASR) ...............................78
Anti-theft .......................................................109
Armrest ............................................................63
Armrest, front ..................................................52
Assistance, emergency braking .....................78
Assistance call .......................................... 76 -77
Audio streaming (Bluetooth) ................. 27 , 11, 7
Auxiliary ..........................................26-2 7 , 10 -11

Battery ............................143, 150, 178, 180 -181
Battery, charging ....................................179-180
Battery, remote control ............................. 38-39
Blind, panoramic roof ......................................63
BlueHDi ........................................... 27 , 152 , 157
Bluetooth (hands-free) ............... 28-2 9, 15-1 6, 8
Bluetooth (telephone) ..................... 28-30, 15-17
Bonnet ....................................................145-146
Boot ........................................................... 40-41
Brake discs ..................................... 110, 151 -152
Brake lamps ........................................... 170-171
Brakes .......................................11, 110, 151 -152
Braking, automatic emergency .............. 127 -128
Brightness .......................................................19
Bulbs (changing) ............................ 167, 170-171

Cable, audio ..............................................26, 10
Cable, jack ................................................26, 10
Cap, fuel filler ................................................139
Capacity, fuel tank .................................138 -139
CarPlay connection................................... 18, 13
CD ........................................................26-2 7 , 11
CD, MP3 ........................................26-2 7, 11 , 5 -7
Central locking .......................................... 37 , 40
Changing a bulb ............................. 167, 170-171
Changing a fuse ..................... 172 , 174 , 176-177
Changing a wheel ..................................162-163
Changing a wiper blade ................................144
Changing the remote control battery ........ 38-39
Checking the engine oil level ..........................26
Checking the levels ................................148-150
Checking tyre pressures (using the kit) ...... 158 -160
Checks ................................... 110, 147, 150 -152
Child lock .......................................................103
Children ..............................................95, 97-100

Children (safety) ............................................103
Child seats ...................... 83, 88-89, 93-95, 102
Child seats, conventional ................................94
Child seats, ISOFIX .................................97-100
Closing the boot ........................................ 40-41
Closing the doors ............................................37
Connection, Bluetooth ........21-22, 28-30 , 15 -17
Connection, MirrorLink ........................ 19, 12 -14
Connection, Wi-Fi network .............................22
Control, electric windows .......................... 43-44
Control, emergency boot release ................... 41
Control, heated seats ...................................... 51
Controls, at steering..........................................2
Control stalk, lighting .......................... 22, 67, 70
Control stalk, wipers ..................................72-74
Courtesy lamp ........................................... 61-62
Cruise control .........................................123-126
Cup holder .......................................................63

DAB (Digital Audio

Broadcasting) – Digital radio ....................25 , 9

Date (setting) ...................................... 33, 36, 20
Daytime running lamps .................... 71, 167 -169
Deactivating the passenger airbag .....85, 89-90
Deadlocking ....................................................38
Demisting - defrosting ...................56-57 , 60-61
Dials and gauges ...........................................7-8
Dimensions ................................................... 191
Dipstick ............................................ 26 , 148-149
Direction indicators ..... 22, 68-7 0, 167-168, 170-171
Display screen, instrument panel ..........7-8, 116
Door pockets ...................................................63
Driving ....................................................... 45-46
Driving economically.....................................104
Dynamic stability control (DSC) .......... 15 , 78-80

196

Alphabetical index

Earth point, remote ....................................... 147
Eco-driving (advice) ......................................104
Economy mode .............................................143
Electronic brake force distribution (EBFD) .....78
Electronic stability control (ESC) ....................78
Emergency braking assistance (EBA) ............78
Emergency call ......................................... 76 -77
Energy economy mode .................................143
Engine, Diesel ................................. 21, 140, 157
Engine, petrol ........................................ 140, 147
Engine compartment .................................... 147
Engines ................................. 184 -185, 188 , 190
Environment ............................................39 , 104

Filling the fuel tank .................................138 -140
Filter, air ........................................................ 151
Filter, Diesel fuel ........................................... 147
Filter, oil ......................................................... 151
Filter, particle .........................................150 -151
Filter, passenger compartment ..................... 151
Fitting a wheel ....................................... 164 -166
Fitting roof bars ......................................144 -145
Fittings, boot ...................................................65
Fittings, interior ...............................................63
Flap, fuel filler .........................................138 -139
Foglamp, rear ........................21 , 67-68 , 170-171
Foglamps ...............................................167 -168
Foglamps, front ........ 22, 67-68, 71-72 , 170, 172
Frequency (radio) ...................................... 24-25
Fuel........................................................104, 140
Fuel consumption ....................................32 , 104
Fuel tank.................................................138 -139
Fusebox, dashboard .............. 172, 174, 176-177
Fusebox, engine

compartment ....................... 172, 174, 176-177

Fuses ...................................... 172, 174, 176-177

Gauge, fuel.............................................138 -139
Gearbox, automatic ............... 104 , 114-115, 151
Gearbox, electronic ......104, 112 -113, 118 -121, 151
Gearbox, manual ............104, 111, 118 -121, 151
Gear lever .....................................................104
Gear lever, electronic gearbox ..................... 151
Gear lever, manual gearbox ......................... 111
Gear shift indicator ~ Gear

efficiency indicator ..................................... 116

GPS. ................................................................14
Grab handles ............................................ 50-52
Guide-me-home ..............................................69

Hazard warning lamps ............................76 , 157
Hazard warning lamps, automatic operation.......76
Headlamps, automatic illumination .......... 67, 69
Headlamps, dipped beam .......... 22, 67, 167-169
Headlamps, halogen ..............................167-168
Headlamps, main beam ............. 22, 67, 167-169
Head restraints, front ......................................49
Head restraints, rear .......................................54
Heating .............................................. 56-57, 104
Hill start assist .........................................117-118

Identification, vehicle ....................................192
Ignition .....................................................109, 31
Ignition switch ....................................... 108-109
Immobiliser, electronic ............................39, 109
Indicator, AdBlue

range .................................27

Indicator, coolant temperature ........................23
Indicator, engine oil level ................................26
Indicator lamps, operation ..............................10

Indicators, direction .......................... 68-69, 168
Inflating tyres ........................................104, 193
Inflating tyres (using the kit) .................. 158 -160
Input, auxiliary ...................................................5
Instrument panels ..........................................7-8
Internet browser ..............................................18
ISOFIX ...................................................... 98-99
Isofix mountings ..............................................97

Jack ............................................162 -163, 26 , 10
Jump starting ................................................ 178

Key ............................................................ 36-37
Key with remote control ..........................39, 109
Kit, hands-free ........................... 28 -29 , 15 -16 , 8
Kit, temporary puncture repair .............. 158 -160

Labels, identification .....................................192
Lamps, parking ...............................................70
LEDs – light-emitting diodes ................. 169, 171
Level, brake fluid ...........................................149
Level, Diesel additive ....................................150
Level, engine coolant ..............................23, 149
Level, engine oil .............................. 26 , 148-149
Level, screenwash fluid ................................150
Levels and checks ................................. 147-150
Light-emitting diodes – LEDs ................. 71, 171
Lighting, ambient.............................................62

197

Alphabetical index

Lighting, cornering .....................................71-72
Lighting, guide-me home .................... 36, 69 -70
Lighting, interior ........................................ 61-62
Lighting dimmer ........................................ 34-35
Loading .................................................104, 144
Load reduction mode ....................................143
Locating your vehicle ......................................36
Locking from the inside ...................................40
Locking the boot........................................ 40-41
Low fuel level .........................................138 -139

Maintenance, routine ....................................104
Map reading lamps ................................... 61-62
Markings, identification .................................192
Mat ............................................................ 63-64
Menu ............................................................... 13
Menus (audio) ........................................4-5, 4-6
Messages ........................................................32
Messages, quick .............................................32
Mirror, rear view .........................................47-48
Mirrors, door.............................................. 46-47
Misfuel prevention .........................................139
Mountings, Isofix .............................................97
MP3 CD ......................................................... 5-7

Number plate lamps ...................................... 172

Oil, engine ..............................................148 -149
Oil change ..............................................148 -149
Oil consumption .....................................148 -149
Opening the bonnet ...............................145-146
Opening the boot ...................................... 40-41
Opening the doors ..........................................36
Opening the fuel filler flap .............................138
Opening the panoramic roof blind ..................63

Pads, brake .................................... 110, 151 -152
Paint colour code ..........................................192
Parcel shelf, rear .............................................65
Park Assist .................................................... 131
Parking brake ............................11, 110, 151 -152
PEUGEOT Connect Nav ...................................1
PEUGEOT Connect Radio ...............................1
Plates, identification......................................192
Player, Apple

........................................... 27 , 11

Player, MP3 CD ....................................... 26 , 5 -7
Player, USB .......................................26 , 10, 5, 5
Port, USB ................................64, 26, 10 , 5, 7, 5
Pre-heater, Diesel ...........................................21
Pressures, tyres ............................. 161, 192-193
Pre-tensioning seat belts ................................83
Priming the fuel system ................................157
Profiles ......................................................34, 18
Protecting children .....85, 88-90, 93 , 95, 97-100
Puncture ................................................ 158-160

Radio .................................. 23-24 , 27 , 7, 11, 3 , 3
Radio, digital (Digital Audio

Broadcasting – DAB) ................................25 , 9

Range ..............................................................32
Range, AdBlue ...........................................27-29
RDS ....................................................... 24 -25 , 7
Rear screen, demisting - defrosting ...............61
Recharging the battery ..........................179 -180
Recirculation, air ....................................... 57-60
Reduction of electrical load ..........................143
Regeneration of the particle filter ................. 151
Reinitialisation of the under-

inflation detection system ...........................136

Reinitialising the remote control ............... 38-39
Reminder, key in ignition ...............................109
Reminder, lighting on ......................................68
Remote control .................................... 36-37, 39
Removing a wheel ................................ 164 -166
Removing the mat ..................................... 63-64
Replacing bulbs ............................. 167, 170 -171
Replacing fuses ..................... 172, 174, 176-177
Replacing the air filter ................................... 151
Replacing the oil filter ................................... 151
Replacing the passenger compartment filter ......151
Reservoir, screenwash .................................150
Resetting the service indicator .......................26
Reversing camera .........................................130
Reversing lamp ............................................. 170
Reversing lamps ........................................... 171
Roof, panoramic ..............................................63
Roof bars ................................................144-145
Running out of fuel (Diesel) ..........................157

198

Alphabetical index

Safety, children ..........85, 88-90, 93, 95, 97-100
SCR (Selective Catalytic Reduction) system .....152
Screen, instrument panel .......................... 30-31
Screen menu map ........................................... 13
Screenwash .................................................... 74
Screenwash, rear ............................................ 74
Seat, rear bench .............................................53
Seat belts ............................................ 81-83 , 94
Seats, front .......................................... 48, 50-52
Seats, heated .................................................. 51
Seats, rear ................................................. 53-54
Serial number, vehicle ..................................192
Service indicator .............................................24
Servicing .................................................24 , 104
Settings, system ........................................35, 19
Sidelamps ............................. 67 , 70 -71, 167 -171
Side repeater ................................................ 170
Snow chains .................................................. 141
Socket, 12 V accessory ..................................64
Socket, auxiliary ........................................26, 10
Socket, JACK ......................................64, 26, 10
Sockets, audio ............................................64, 5
Sockets, auxiliary ..............................................5
Speed limiter .................................. 121 -123, 126
Stability control (ESC).....................................78
Starting a Diesel engine ...............................140
Starting the engine ......... 105, 108-109, 112-115
Starting using another battery ...................... 178
Station, radio ................................. 23-2 5, 7 , 3, 3
Stay, bonnet ...........................................145 -146
Steering mounted controls, audio ................3, 3
Steering wheel, adjustment ............................46
Stop (warning lamp) ........................................ 11
Stop & Start .....................21, 33 , 55, 60 , 118-121,

131 , 138 , 145, 150, 181

Storage ......................................................52, 63
Stowing rings ..................................................65
Switching off the engine ............... 105, 108-109
Synchronising the remote control ............. 38-39

Tables of fuses ....................... 172 , 174 , 176-177
Tank, fuel ................................................138 -139
Telephone ...................................... 28-33, 15 -18
Temperature, coolant ......................................23
Textured Paint ...............................................156
Third brake lamp ........................................... 171
Three flashes (direction indicators) .......... 68-69
Time (setting) ................................33-34, 36 , 20
TMC (Traffic info) ............................................14
Tools ....... 162, 162 -163, 172, 174 , 176-177, 182-183
Touch screen.........................................136, 1, 1
Towbar ............................................ 106 -107, 142
Towed loads ..................................................184
Towing ....................................................181-183
Traction control (ASR) ........................ 15, 78-80
Traffic information (TA) .....................................4
Traffic information (TMC) ................................ 14
Trailer ............................................. 106 -107, 142
Triangle, warning...........................................157
Trip computer ............................................ 30-33
Tyres ......................................................104 , 193
Tyre under-inflation detection ......15 , 135-136, 161

Under-inflation (detection) ............................135
Unlocking ........................................................36
Unlocking from the inside ...............................40
Unlocking the boot .................................... 40-41
Updating the date ............................... 33, 36 , 20
Updating the time ..........................33-34, 36 , 20
USB .........................................26 -27, 10 -11, 5, 5

Ventilation ................................... 55-57 , 60, 104
Voice commands .........................................5-1 0

Warning and indicator lamps ..........................10
Warning lamp, braking system ....................... 11
Warning lamp, Diesel engine pre-heater .......21
Warning lamp, Service....................................20
Warning lamp, Stop ........................................ 11
Warning lamps ................................................10
Weights ................................. 184-185, 188, 190
Wheel, spare ..................................162-163, 193
Window controls ....................................... 43-44
Wiper, rear....................................................... 74
Wiper blades (changing) ...............................144
Wipers ................................................. 22, 72 -73
Wipers, automatic rain sensitive .....................73

3-17

Automobiles PEUGEOT declares, by application
of the provisions of the European legislation
(Directive 2000/53) relating to End of Life
Vehicles, that it achieves the objectives set by
this legislation and that recycled materials are
used in the manufacture of the products that it
sells.

Reproduction or translation of all or part of
this document is prohibited without written
authorisation from Automobiles PEUGEOT.

Printed in the EU

Anglais

www.peugeot.com

ANG. 17208.0040

*17208.0040*

Content .. 17 18 19
