Peugeot 208 (2017 year). Manual

PEUGEOT Connect Radio

Multimedia audio system –
Applications – Bluetooth

telephone

Contents

First steps

Steering mounted controls

Menus 4
Applications 6
Radio 7
DAB radio (Digital Audio Broadcasting)

Media 10
Telephone 12
Configuration 18
Frequently asked questions

The different functions and settings
described vary according to the version
and configuration of your vehicle.

As a safety measure and because it
requires sustained attention by the
driver, the pairing of a Bluetooth mobile
telephone with the Bluetooth hands-free
system of your audio system must be
done with the vehicle stationary and the
ignition on.

The system is protected in such a way that
it will only operate in your vehicle.
The display of the Energy Economy
Mode message signals that a change to
standby is imminent.

The link below gives access to OSS (Open
Source Software) codes for the system.
https://www.groupe-psa.com/fr/oss/
https://www.groupe-psa.com/en/oss/

PEUGEOT Connect Radio

First steps

With the engine running, a press
mutes the sound.
With the ignition off, a press turns
the system on.

Adjustment of the volume.

Use the buttons either side of or below the
touch screen for access to the menus, then
press the virtual buttons in the touch screen.

Depending on the model, use the "Source" or
"Menu" buttons either side of the touch screen
for access to the menus, then press the virtual
buttons in the touch screen.

You can display the menu at any time by
pressing the screen briefly with three fingers.

All of the touch areas of the screen are white.
Press in the grey zone to go back a level or
confirm.
Press the back arrow to go back a level or
confirm.

The touch screen is of the "capacitive"
type.
To clean the screen, use a soft, non-
abrasive cloth (spectacles cloth) with no
additional product.
Do not use sharp objects on the screen.
Do not touch the screen with wet hands.

* Depending on equipment.

Certain information is displayed permanently in
the upper band of the touch screen:
- Repeat of the air conditioning information

(depending on version), and direct access to
the corresponding menu.

- Reminder of the Radio Media and

Telephone menu information.

- Access to the Settings of the touch screen

and digital instrument panel.

Selecting the audio source (depending on
version):
- FM / DAB radio stations* / AM*.
- Telephone connected via Bluetooth

and multimedia broadcast Bluetooth*
(streaming).

-  CD player (depending on model).
-  USB key.
-  Media player connected via the auxiliary

socket (depending on model).

In the "Settings" menu you can create
a profile for just one person or a group
of people with common points, with the
possibility of entering a multitude of
settings (radio presets, audio settings,
ambiences, etc.); these settings are taken
into account automatically.

PEUGEOT Connect Radio

In very hot conditions, the volume may
be limited to protect the system. It may go
into standby (screen and sound off) for at
least 5 minutes
The return to normal takes place when
the temperature in the passenger
compartment has dropped.

Steering mounted controls

Steering mounted controls
– Type 1

Radio:
Select the previous / next preset
radio station.
Select the previous / next item in a
menu or a list.
Media:
Select the previous / next track.
Select the previous / next item in a
menu or a list.

Radio:
Short press: display the list of radio
stations.
Long press: update the list.
Media:
Short press: display the list of
folders.
Long press: display the available
sorting options.

Change audio source (radio; USB;
AUX if equipment connected; CD;
streaming).

Confirm a selection.

Increase volume.

Decrease volume.

Mute / Restore sound by
simultaneously pressing the
increase and decrease volume
buttons.

Steering mounted controls
– Type 2

Depending on model.

Voice commands:
This control is located on the
steering wheel or at the end of the
lighting control stalk (depending on
model).
Short press, smartphone voice
commands via the system.

21,5

18,5

PEUGEOT Connect Radio

Increase volume.

Mute / Restore the sound.
Or
Mute by pressing the volume
increase and decrease buttons
simultaneously.
Restore the sound by pressing one
of the two volume buttons.

Decrease volume.

Media (short press): change the
multimedia source.
Telephone (short press): start
telephone call.
Call in progress (short press):
access telephone menu.
Telephone (long press): reject an
incoming call, end call; when no call
is in progress, access telephone
menu.

Radio (rotate): previous / next
preset.
Media (rotate): previous / next track,
move in a list.
Short press: confirm a selection; if
nothing selected, access to presets.

Radio: display the list of stations.
Media: display the list of tracks.
Radio (press and hold): update the
list of stations received.

Menus

Depending on model / Depending on version

Air conditioning

Manage the different temperature
and air flow settings.

PEUGEOT Connect Radio

Applications

Access configurable equipment.

Radio Media

Select an audio source or radio
station.

Telephone

Connect a telephone by Bluetooth

Operate certain applications on
a smartphone connected via
MirrorLink

, CarPlay

or Android

Auto.

Settings

Configure a personal profile and/
or configure the sound (balance,
ambience, etc.) and the display
(language, units, date, time, etc.).

Driving

Activate, deactivate or configure
certain vehicle functions.

PEUGEOT Connect Radio

Applications

Viewing photos

Insert a USB memory stick in the USB port.

To protect the system, do not use a USB
hub.

The system can read folders and image files in
the formats: .tiff;.gif;.jpg/jpeg;.bmp;.png.

Press Applications to display the
primary page.

Press "Photos".

Select a folder.

Select an image to view.

Press this button to display the
details of the photo.

Press the back arrow to go back a
level.

Managing messages

Press Applications to display the
primary page.

Press "SMS".

Select the "SMS" tab.

Press this button to select the
display settings for messages.

Press this button to search for a
contact.

Select the "Quick messages" tab.

Navigation

Configure the guidance and select
your destination via MirrorLink

CarPlay

or Android Auto.

Press this button to select the
display settings for messages.

PEUGEOT Connect Radio

Radio

Selecting a station

Press Radio Media to display the
primary page.

Press one of the buttons for an
automatic search for radio stations.

Move the cursor for a manual search
for frequencies up or down.

Press the frequency.

Enter the FM and AM waveband
values using the virtual keypad.

Press "OK" to confirm.

Radio reception may be affected by the
use of electrical equipment not approved
by the Brand, such as a USB charger
connected to the 12 V socket.
The external environment (hills, buildings,
tunnels, basement car parks, etc.) may
block reception, including in RDS mode.
This is a normal effect of the way in
which radio waves are transmitted and
does not indicate any failure of the audio
equipment.

Changing waveband

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Press "Band" to change waveband.

Press in the grey zone to confirm.

Presetting a station

Select a radio station or frequency.

Make a short press on the star
outline. If the star is solid, the radio
station is already preset.

Select a radio station or frequency.

Press "Preset".

Make a long press on one of the
buttons to preset the station.

Activating / Deactivating
RDS

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Activate / Deactivate "RDS".

Press in the grey zone to confirm.

PEUGEOT Connect Radio

The RDS, if activated, enables you to
continue listening to the same station
by automatically retuning to alternative
frequencies. However, in certain
conditions, coverage of this RDS station
may not be assured throughout the entire
country as radio stations do not cover
100% of the territory. This explains the
loss of reception of the station during a
journey.

Display text information

The "Radio Text" function allows
information transmitted by the radio
station and related to the station or the
song playing to be displayed.

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Activate / Deactivate "News".

Press in the grey zone to confirm.

Play TA messages

The TA (Traffic Announcement) function
gives priority to TA alert messages.
To operate, this function needs good
reception of a radio station that carries
this type of message. While traffic
information is being broadcast, the current
media is automatically interrupted so that
the TA message can be heard. Normal
play of the media previously playing is
resumed at the end of the message.

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Activate / Deactivate "TA".

Press in the grey zone to confirm.

Audio settings

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Press "Audio settings".

Select the "Tone" or "Balance"
or "Ringtones" or "Sound" tab to
configure the audio settings.

Press the back arrow to confirm.

In the tab "Tone", the Ambience audio
settings, as well as Bass, Medium and
Treble are different and independent for
each audio source.
On the "Balance" tab, the All
passengers, Driver and Front only
settings are common to all sources.
On the "Sound" tab, activate or deactivate
"Volume linked to speed", "Auxiliary
input" and "Touch tones".

PEUGEOT Connect Radio

The sound distribution (or spatialisation
with the Arkamys

system) is audio

processing that allows the quality of the
sound to be adapted according to the
number of passengers in the vehicle.

Onboard audio: the Sound Staging of
Arkamys

optimises the distribution of

sound in the passenger compartment.

DAB (Digital Audio
Broadcasting) radio

Terrestrial Digital Radio

Digital radio provides higher quality
reception.
The different multiplexes offer a choice
of radio stations arranged in alphabetical
order.

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Press "Waveband" to select the
"DAB band".

Press in the grey zone to confirm.

FM-DAB Follow-up

"DAB" does not cover 100% of the
territory.
When the digital radio signal is poor,
the "FM-DAB Follow-up" allows you to
continue listening to the same station,
by automatically switching to the
corresponding "FM" analogue station (if
there is one).

Press Radio Media to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Activate / Deactivate "FM-DAB
Follow-up".

Press in the grey zone to confirm.

PEUGEOT Connect Radio

Media

USB port

Insert the USB memory stick in the USB port or
connect the USB device to the USB port using
a suitable cable (not supplied).

To protect the system, do not use a USB
hub.

The system builds playlists (in temporary
memory), an operation which can take from
a few seconds to several minutes at the first
connection.
Reduce the number of non-music files and the
number of folders to reduce the waiting time.
The playlists are updated every time the
ignition is switched off or a USB memory stick
is connected. The lists are memorised: if they
are not modified, the subsequent loading time
will be shorter.

Auxiliary socket (AUX)

(depending on model / depending on
equipment)

This source is only available if "Auxiliary input"
has been checked in the audio settings.

Connect the portable device (MP3 player, etc.)
to the auxiliary jack socket using an audio
cable (not supplied).

First, adjust the volume on your portable device
(to a high level). Then adjust the volume of your
audio system.
Display and management of the controls are
via the portable device.

If "FM-DAB Follow-up" is activated, there
is a difference of a few seconds when the
system switches to "FM" analogue radio
with sometimes a variation in volume.
When the digital signal quality becomes
good, the system automatically switches
back to "DAB".

If the "DAB" station being listened to is
not available on "FM", or if the "FM-DAB
Follow-up" is not activated, the sound will
cut out while the digital signal is too weak.

PEUGEOT Connect Radio

Selecting the source

Press Radio Media to display the
primary page.

Press the "SOURCES" button.

Choose the source.

Bluetooth

streaming

Streaming allows you to listen to music from
your smartphone.

The Bluetooth profile must be activated, first
adjust the volume on your portable device (to a
high level).
Then adjust the volume of your system.

If play does not start automatically, it may be
necessary to start the audio playback from the
smartphone.
Control is from the portable device or by using
the system's touch buttons.

Once connected in Streaming mode, the
smartphone is considered to be a media
source.

Connecting Apple

players

Connect the Apple

player to the USB port

using a suitable cable (not supplied).
Play starts automatically.

Control is via the audio system.

The classifications available are those
of the portable device connected
(artists / albums / genres / playlists /
audiobooks / podcasts), you can also use
a classification structured in the form of a
library.
The default classification used is by artist.
To modify the classification used, return
to the first level of the menu then select
the desired classification (playlists for
example) and confirm to go down through
the menu to the desired track.

The version of software in the audio system
may not be compatible with the generation of
your Apple

player.

Information and advice

The system supports USB Mass Storage
devices, BlackBerry

devices or Apple

players via USB ports. The adapter cable
is not supplied.
Device management is done by the audio
system controls.
Other peripherals, not recognised on
connection, must be connected to the
auxiliary socket using a Jack cable (not
supplied) or via Bluetooth streaming,
depending on compatibility.

To protect the system, do not use a USB
hub.

The audio equipment will only play audio files
with ".wav", ".wma", ".aac", ".ogg and ".mp3"
file extensions and with a bit rate of between
32 Kbps and 320 Kbps.
It also supports VBR (Variable Bit Rate) mode.
No other file types (.mp4, etc.) can be read.
".wma" files must be of the standard wma 9
type.
Sampling frequencies supported are 11, 22, 44
and 48 kHz.

PEUGEOT Connect Radio

It is advisable to restrict file names to
20 characters, without using special characters
(e.g. " "?.; ù) so as to avoid any reading or
display problems.

Use only USB keys in FAT32 format (File
Allocation Table).

It is recommended that the original USB
cable for the portable device is used.

In order to be able to play a burned CDR or
CDRW, select standards ISO 9660 level 1, 2 or
Joliet if possible when burning the CD.
If the disc is burned in another format, it may
not be played correctly.
It is recommended that the same burning
standard is always used on an individual disc,
with the lowest speed possible (4x maximum)
for the best acoustic quality.
In the particular case of a multi-session CD, the
Joliet standard is recommended.

Telephone

MirrorLink

smartphone

connection

As a safety measure and because it
requires sustained attention by the driver,
using a smartphone when driving is
prohibited.
All operations must be done with the
vehicle stationary.

The synchronisation of a personal
smartphone allows users to display
applications adapted for the smartphone's
MirrorLink

technology on the vehicle

screen.
The principles and standards
are constantly changing, for the
communication process between the
smartphone and the system to operate,
it is essential that the smartphone is
unlocked; update the operating system of
the smartphone as well as the date and
time of the smartphone and the system.
For the list of eligible smartphones, go
to the Brand's internet website in your
country.

As a safety measure, applications can
only be viewed with the vehicle stationary;
display is interrupted once the vehicle is
moving.

The "MirrorLink

" function requires a

compatible smartphone and applications.

Telephone not connected by
Bluetooth

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press
"Telephone" to display the primary
page.

Press "MirrorLink

" to start the

application in the system.

Depending on the smartphone, it may be
necessary to activate the "MirrorLink

function.

PEUGEOT Connect Radio

During the procedure, several
screen pages relating to certain
functions are displayed.
Accept to start and complete the
connection.

When connecting a smartphone
to the system, it is recommended
that Bluetooth

be started on the

smartphone.

Telephone connected by
Bluetooth

From the system, press
"Telephone" to display the primary
page.

Press the "PHONE" button to display the
secondary page.

Press "MirrorLink

" to start the

application in the system.

Once the connection is established, a page
is displayed with the applications already
downloaded to your smartphone and adapted
to MirrorLink

technology.

Access to the different audio sources remains
accessible in the margin of the MirrorLink

display, using touch buttons in the upper bar.
Access to the menus for the system is possible
at any time using the dedicated buttons.

There may be a wait for the availability of
applications, depending on the quality of
your network.

CarPlay

smartphone

connection

As a safety measure and because it
requires sustained attention by the driver,
using a smartphone when driving is
prohibited.
All operations must be done with the
vehicle stationary.

The synchronisation of a personal
smartphone allows users to display
applications adapted for the smartphone's
CarPlay

technology on the vehicle screen

when the smartphone's CarPlay

function

has been previously activated.
As the principles and standards are
constantly changing, it is recommended
that you keep your smartphone's
operating system updated.
For the list of eligible smartphones, go
to the Brand's internet website in your
country.

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press CarPlay

display the Telephone interface.

If the smartphone is already
connected by Bluetooth

PEUGEOT Connect Radio

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press
"Telephone" to display the primary
page.

Press the "PHONE" button to go to the
secondary page.

Press on "CarPlay" to display the
CarPlay

interface.

On connecting the USB cable, the
CarPlay

function deactivates the

system's Bluetooth

mode.

You can go to the CarPlay

navigation at any time by pressing
the system's Navigation button.

Android Auto smartphone
connection

As a safety measure and because it
requires sustained attention by the driver,
using a smartphone when driving is
prohibited.
All operations must be done with the
vehicle stationary.

On your smartphone, download the
Android Auto application.

The synchronisation of a personal
smartphone allows users to display
applications adapted for the smartphone's
Android Auto technology on the vehicle
screen.
The principles and standards
are constantly changing, for the
communication process between the
smartphone and the system to operate,
it is essential that the smartphone is
unlocked; update the operating system
of the smartphone as well as the date
and time of the smartphone and the
system.
For the list of eligible smartphones, go
to the Brand's internet website in your
country.

As a safety measure, applications can
only be viewed with the vehicle stationary;
display is interrupted once the vehicle is
moving.

The "Android Auto" function requires the
use of a compatible smartphone and
applications.

Telephone not connected by
Bluetooth

Connect a USB cable. The
smartphone charges when
connected by a USB cable.

From the system, press
"Telephone" to display the primary
page.

Press "Android Auto" to start the
application in the system.

Depending on the smartphone, it may be
necessary to activate the "Android Auto"
function.

Peugeot 208 (2017 year). Manual - part 16
