Peugeot 208 (2017 year). Manual - part 15

PEUGEOT Connect Nav

Select the name of the chosen
telephone in the list.

Connection sharing

The system offers to connect the telephone
with 3 profiles:
- "Telephone" (hands-free kit, telephone

only),

- "Streaming" (streaming: wireless playing of

the audio files on the telephone),

- "Mobile internet data".

Activation of the profile; "Mobile internet
data" is obligatory for connected
navigation having first activated sharing of
this connection on your smartphone.

Select one or more profiles.

Press "OK" to confirm.

Depending on the type of telephone, you
may be asked to accept or not the transfer
of your contacts and messages.

Automatic reconnection

On return to the vehicle, if the last
telephone connected is present again, it is
automatically recognised and within about
30 seconds of switching on the ignition,
the connection is established without any
action on your part (Bluetooth activated).

To modify the connection profile:

Press Telephone to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Bluetooth connection" to
display the list of paired devices.

Press the "details" button.

Select one or more profiles.

Press "OK" to confirm.

The ability of the system to connect to just
one profile depends on the telephone.
All three profiles may connect by default.

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used. Check the instructions for your
telephone and with your service provider
for the services to which you have access.

The profiles compatible with the system
are: HFP, OPP, PBAP, A2DP, AVRCP,
MAP and PAN.

Go to the Brand's website for more information
(compatibility, additional help, etc.).

PEUGEOT Connect Nav

Managing paired telephones

This function allows the connection or
disconnection of a peripheral device as
well as the deletion of a pairing.

Press Telephone to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Bluetooth connection" to
display the list of paired devices.

Press on the name of the telephone
chosen in the list to disconnect it.
Press again to connect it.

Deleting a telephone

Select the basket at top right of the
screen to display a basket alongside
the telephone chosen.

Press the basket alongside the
telephone chosen to delete it.

Receiving a call

An incoming call is announced by a ring and a
superimposed display in the screen.

Make a short press on the steering
mounted TEL button to accept an
incoming call.

And

Make a long press

on the steering mounted TEL button
to reject the call.

Select "End call".

Making a call

Using the telephone is not recommended
while driving.
Park the vehicle.
Make the call using the steering mounted
controls.

Calling a new number

Press Telephone to display the
primary page.

Enter the phone number using the
digital keypad.

Press "Call" to start the call.

PEUGEOT Connect Nav

Calling a contact

Press Telephone to display the
primary page.

Or make a long press

on the steering mounted TEL button.

Select "Contact".

Select the desired contact from the list offered.

Select "Call".

Calling a recently used
number

Press Telephone to display the
primary page.

Make a long press

on the steering mounted button.

Select "Calls".

Select the desired contact from the list offered.

It is always possible to make a call directly
from the telephone; as a safety measure,
first park the vehicle.

Managing contacts / entries

Press Telephone to display the
primary page.

Select "Contact".

Select "Create" to add a new
contact.

In the "Telephone" tab, enter the telephone
numbers for the contact.

In the "Address" tab, enter the addresses for
the contact.

In the "Email" tab, enter the email addresses
for the contact.

The "Email" function allows email
addresses to be entered for a contact, but
the system is not able to send emails.

PEUGEOT Connect Nav

Managing messages

Press Telephone to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Messages" to display the list
of messages.

Select the "All" or "Sent" or
"Incoming" tab.

Select the detail of the message
chosen in one of the lists.

Press "Answer" to send a quick
message stored in the system.

Press "Call" to start the call.

Press " Play" to hear the message.

Access to "Messages" depends on the
compatibility of the smartphone and the
integral system.
Depending on the smartphone, access to
your messages or email may be slow.

The services available depend on
the network, the SIM card and the
compatibility of the Bluetooth devices
used.
Check in the manual for your smartphone
and with your service provider for the
services available to you.

Managing quick messages

Press Telephone to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Quick messages" to display
the list of messages.

Select the "Delayed" or "My arrival"
or "Not available" or "Other" tab
with the possibility of creating new
messages.

PEUGEOT Connect Nav

Press "Create" to write a new
message.

Select the message chosen in one
of the lists.

Press "Transfer" to select the
addressee(s).

Press " Play" to start playing the
message.

Managing email

Press Telephone to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Email" to display the list of
messages.

Select the "Incoming" or "Sent" or
"Not read" tab.

Select the message chosen in one of the lists.

Press " Play" to start playing the
message.

Access to "Email" depends on the
compatibility of the smartphone and the
integral system.

Configuration

Audio settings

Press Settings to display the
primary page.

Select "Audio settings".

Select "Ambience".

"Position".

"Sound".

"Voice".

"Ringtone".

Press "OK" to save the settings.

PEUGEOT Connect Nav

The sound distribution (or spatialisation
with the Arkamys

system) is audio

processing that allows the quality of the
sound to be adapted according to the
number of passengers in the vehicle.
Available only with the front and rear
speakers configuration.

The audio settings Ambience (6 optional
ambiences) and Bass, Medium and
Treble are different and independent for
each audio source.
Activate or Deactivate "Loudness".
The settings for "Position" (All
passengers, Driver and Front only) are
common to all sources.
Activate or Deactivate "Touch tones",
"Volume linked to speed" and "Auxiliary
input".

Onboard audio: Arkamys

Sound Staging

optimises the distribution of sound in the
passenger compartment.

Profile settings

As a safety measure and because it
requires the sustained attention of the
driver, changes to settings must only be
done with the vehicle stationary.

Press Settings to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Setting of the profiles".

Select "Profile 1" or "Profile 2" or "Profile 3"
or "Common profile".

Press this button to enter a name for
the profile using the virtual keypad.

Press "OK" to confirm.

Press this button to add a
photograph to the profile.

Insert a USB memory stick
containing the photograph in the
USB port.
Select the photograph.

Press "OK" to accept the transfer of
the photograph.

Press "OK" again to save the
settings.

The location for the photograph is
square; the system reshapes the original
photograph if in another format.

Press this button to initialise the
profile selected.

PEUGEOT Connect Nav

Select "Ambience".

"Position".

"Sound".

"Voice".

"Ringtone".

Press "OK" to save the settings.

Modifying system settings

Press Settings to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Screen configuration".

Select "Animation".

Activate or deactivate: "Automatic
scrolling".

Select "Brightness".

Move the cursor to adjust the
brightness of the screen and/or of
the instrument panel.

Press Settings to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "System settings".

Initialisation of the profile selected
activates the English language by default.

Select a "Profile" (1 or 2 or 3) to associate the
"Audio settings" with it.

Select "Audio settings".

Select "Units" to change the units of distance,
fuel consumption and temperature.

Select "Factory settings" to return to the initial
settings.

Returning the system to factory settings
activates the English language by default.

Select "System info" to display the versions of
the different modules installed in the system.

PEUGEOT Connect Nav

Select the language

Press Settings to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Languages" to change the
language.

Setting the date

Press Settings to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Setting the time-date".

Select "Date".

Press on this button to define the
date.

Press "OK" to confirm.

Select the display format of the date.

Adjustment of the time and date is only
available if "GPS synchronisation" is
deactivated.
The change between winter and summer
time is done by changing the time zone.

Setting the time

Press Settings to display the
primary page.

Press the "OPTIONS" button to go to the
secondary page.

Select "Setting the time-date".

Select "Time".

Press this button to adjust the time
using the virtual keypad.

Press "OK" to confirm.

Press this button to define the time
zone.

PEUGEOT Connect Nav

Press "OK" to confirm.

The system does not automatically
manage the change between winter and
summer time (depending on country).

Colour schemes

As a safety measure, the procedure
for changing the colour scheme is only
possible when the vehicle is stationary.

Press Settings to display the
primary page.

Select "Colour schemes".

Select a colour scheme in the list
then press "OK" to confirm.

Every time the colour scheme is changed,
the system restarts, temporarily displaying
a black screen.

Select the display format for the time
(12h / 24h).

Activate or deactivate
synchronisation with GPS (UTC).

Frequently asked
questions

The following information groups together the
answers to the most frequently asked questions
concerning your audio system.

PEUGEOT Connect Nav

Navigation

QUESTION

RESPONSE

SOLUTION

The route calculation is not
successful.

The guidance criteria may be in conflict with the current
location (exclusion of toll roads on a toll road).

Check the route settings in the "Navigation" menu.

The POIs do not appear.

The POIs have not been selected.

Select the POIs in the list of POIs.

The audible warning of "Danger
areas" does not work.

The audible warning is not active or the volume is too
low.

Activate the audible warning in the "Navigation" menu
and check the voice volume in the audio settings.

The system does not suggest
a detour around an incident on
the route.

The guidance criteria do not take account of TMC
messages.

Select setting for the "Traffic info " function in the list of
route settings (Without, Manual or Automatic).

I receive a "Danger zone" alert
which is not on my route.

Other than guidance, the system announces all "Danger
zones" positioned in a cone located in front of the
vehicle. It may provide an alert for "Danger zones"
located on nearby or parallel roads.

Zoom in on the map to see the exact position of the
"Danger zone". Select "On the route" to no longer
receive alerts other than navigation instructions or to
reduce the time for the announcement.

Certain traffic jams along the
route are not indicated in real
time.

On starting, it is several minutes before the system
begins to receive the traffic information.

Wait until the traffic information is being received correctly
(display of the traffic information icons on the map).

In certain countries, only major routes (motorways, etc.)
are listed for the traffic information.

This is perfectly normal. The system is dependent on
the traffic information available.

The altitude is not displayed.

On starting, the initialisation of the GPS may take up to
3 minutes to receive more than 4 satellites correctly.

Wait until the system has started up completely so that
there is GPS coverage by at least 4 satellites.

Depending on the geographical environment (tunnel,
etc.) or the weather, the conditions of reception of the
GPS signal may vary.

This behaviour is normal. The system is dependent on
the GPS signal reception conditions.

My navigation is no longer
connected.

During start-up and in certain geographical areas, the
connection may be unavailable.

Check that the connected services are activated
(settings, contract).

PEUGEOT Connect Nav

Radio

QUESTION

RESPONSE

SOLUTION

The reception quality of the tuned radio station
gradually deteriorates or the stored stations are
not working (no sound, 87.5 MHz is displayed,
etc.).

The vehicle is too far from the transmitter of
the station or no transmitter is present in the
geographical area.

Activate the "RDS" function by means of the
short-cut menu to enable the system to check
whether there is a more powerful transmitter in
the geographical area.

The environment (hills, buildings, tunnels,
basement car parks, etc.) block reception,
including in RDS mode.

This phenomenon is normal and does not
indicate a failure of the audio equipment.

The aerial is absent or has been damaged (for
example when going through a car wash or into
an underground car park).

Have the aerial checked by a franchised dealer.

I cannot find some radio stations in the list of
stations received.
The name of the radio station changes.

The station is not received or has changed its
name in the list.
Some radio stations send other information
in place of their name (the title of the song for
example).
The system interprets these details as the
station name.

Press on the "Update list" button in the "Radio
stations" secondary menu.

PEUGEOT Connect Nav

Media

QUESTION

RESPONSE

SOLUTION

Playback of my USB memory stick starts only
after a very long wait (around 2 to 3 minutes).

Some files supplied with the memory stick
may greatly slow down access to reading
the memory stick (multiplication by 10 of the
catalogue time).

Delete the files supplied with the memory stick
and limit the number of sub-folders in the file
structure on the memory stick.

The CD is ejected every time or is not played.

The CD is upside down, cannot be read, does
not contain audio files or contains audio files of
a format not recognised by the audio system.
The CD has been recorded in a format that is
not compatible with the player (udf, etc.).
The CD is protected by an anti-pirating system
not recognised by the audio system.

Check that the CD is inserted in the player the
right way up.
Check the condition of the CD: the CD cannot
be played if it is too badly damaged.
Check the content in the case of a recorded CD:
consult the advice in the "AUDIO" section.
The audio system CD does not read DVDs.
Due to insufficient quality, certain burned CDs
will not be read by the audio system.

There is a long waiting period following the
insertion of a CD or connection of a USB
memory stick.

Upon insertion of a new key, the system reads
a certain amount of data (directory, title, artist,
etc.). This may take from a few seconds to a few
minutes.

This is perfectly normal.

The CD sound is of poor quality.

The CD used in scratched or of poor quality.

Insert good quality CDs and store them in
suitable conditions.

The audio settings (bass, treble, ambience) are
unsuitable.

Return bass and treble settings to 0, without
selecting an ambience.

Some information characters in the currently
playing media are not displayed correctly.

The audio system does not display some types
of characters.

Use standard characters to name tracks and
folders.

Playback of streaming files does not start.

The connected device does not automatically
launch playback.

To start playback from the device.

Names of tracks and playing time are not
displayed on the audio streaming screen.

The Bluetooth profile does not allow the transfer
of this information.

PEUGEOT Connect Nav

Telephone

QUESTION

RESPONSE

SOLUTION

I cannot connect my Bluetooth telephone.

The telephone's Bluetooth function may be
switched off or the telephone may not be visible.

Check that your telephone has Bluetooth
switched on.
Check in the telephone settings that it is "visible
to all".

The Bluetooth telephone is not compatible with
the system.

You can check the compatibility of your
telephone at the Brand's website (services).

The volume of the telephone connected in
Bluetooth mode is inaudible.

The sound depends on both the system and the
telephone.

Increase the volume of the audio system, to
maximum if required, and increase the volume
of the telephone if necessary.

Ambient noise affects the quality of the
telephone call.

Reduce the ambient noise level (close the
windows, reduce the booster fan speed, slow
down, etc.).

Some contacts are duplicated in the list.

The options for synchronising contacts are
synchronising the contacts on the SIM card, the
contacts on the telephone, or both. When both
synchronisations are selected, some contacts
may be duplicated.

Select "Display SIM card contacts" or "Display
telephone contacts".

The contacts are listed in alphabetical order.

Some telephones offer display options.
Depending on the settings chosen, contacts can
be transferred in a specific order.

Modify the telephone directory display settings.

The system does not receive SMS.

The Bluetooth mode does not permit sending
SMS text messages to the system.

PEUGEOT Connect Nav

Settings

QUESTION

RESPONSE

SOLUTION

When changing the setting of treble and bass
the equalizer setting is deselected.
When changing the equalizer setting, the treble
and bass settings are reset.

The selection of an equalizer setting imposes
the settings for treble and bass and vice-versa.

Modify the treble and bass or equalizer settings
to obtain the desired musical ambience.

When changing the balance setting, distribution
is deselected.
When changing the distribution setting, the
balance setting is deselected.

The selection of a distribution setting imposes
the balance settings and vice-versa.

Modify the balance setting or the distribution
setting to obtain the desired sound quality.

There is a difference in sound quality between
the different audio sources.

To allow for optimal listening quality, the
audio settings can be tailored to different
sound sources, which can generate audible
differences when changing source.

Check that the audio settings are adapted to
the sources listened to. It is recommended that
the audio settings (Bass:, Treble:, Balance)
be adjusted to the middle position, select the
"None" musical ambience and set the loudness
correction to the "Active" position in CD mode or
to the "Inactive" position in radio mode.

When the engine is off, the system stops after
several minutes of use.

When the engine is switched off, the system's
operating time depends on the state of charge
of the battery.
In normal off state, the system automatically
goes into energy economy mode to maintain an
adequate charge in the battery.

Turn the ignition on to increase the charge of
the battery.

The date and time cannot be set.

Setting of the date and time is only available
if the synchronisation with the satellites is
deactivated.

Settings menu / Options / Time-Date setting.
Select the "Time" tab and deactivate the "GPS
synchronisation" (UTC).

PEUGEOT Connect Nav

PEUGEOT Connect Nav

Content .. 13 14 15 16 ..
