Peugeot 208 (2017 year). Manual - part 1





PEUGEOT 208

HANDBOOK

Access to the online Handbook

The Handbook is available on the PEUGEOT website, in
the "Personal space" section or at the following address:
http://public.servicebox.peugeot.com/ddb/

This symbol indicates the latest
information available.

Direct access to the Handbook.

Select:
-

the language,

-

the vehicle, its body style,

-

the print edition of your handbook appropriate for the date of 1

st



registration of your vehicle.

Welcome

Your vehicle will be fitted with only some of the equipment described in
this document, depending on its trim level, version and the specification
for the country in which it was sold.

This document presents the information and recommendations required
for you to be able to explore your vehicle in detail.

Thank you for choosing a Peugeot 208.

The descriptions and illustrations are given without any obligation.
Automobiles PEUGEOT reserves the right to modify the technical
specifications, equipment and accessories without having to update this
edition of the guide.

In this document, you will find all of the instructions and
recommendations on the use that will allow you to enjoy your vehicle
to the fullest. It is strongly recommended that you familiarise yourself
with it as well as the Warranty and Maintenance Record which will
provide you with information about warranties, servicing and roadside
assistance associated with your vehicle.

Key

If ownership of your vehicle is transferred, please ensure this Complete
Handbook is passed on to the new owner.

Safety warning

Additional information

Contributes to the protection of the environment

Left-hand drive vehicle

Right-hand drive vehicle

4

Overview

Instruments and controls

1

Door mirrors
Electric windows

2

Opening the bonnet

3

Dashboard fuses

4

Rear view mirror
Courtesy lamp
Ambient lighting
Emergency or assistance call
Active City Brake

5

Touch screen
Audio system
Bluetooth audio system
Adjusting the date/time

6

Ventilation
Heating
Manual air conditioning
Automatic air conditioning
Front demisting/defrosting
Rear screen demisting/defrosting

7

USB port / Auxiliary socket

8

Manual gearbox
Electronic gearbox
Automatic gearbox
Gear shift indicator

9

Parking brake

10

Glove box
Fuses

5

.

Overview

Instruments and controls
(continued)

Steering mounted controls

4

"-" Changing down gears
(with an electronic gearbox)

5

Steering wheel adjustment
Audible warning (horn)

6

Wiper control stalk
Trip computer

7

Steering mounted controls
for the touch screen

8

Steering mounted controls
for the audio system

9

"+" Changing up gears
(with an electronic gearbox)

1

Lighting control stalk
Direction indicators

2

Steering mounted controls
for the touch screen: volume, source change

3

Cruise control
Speed limiter
Memorising speeds

6

Overview

Central switch panel

Central locking

Hazard warning lamps

Side switch panel

(Depending on version.)

Activation of Park Assist

or

Deactivation of the rear parking
sensors

Deactivation of the DSC/ASR
system

Deactivation of Stop & Start

Reinitialisation of the tyre under-
inflation detection (without the
touch screen)

Deactivating the volumetric
monitoring

Turning on the electric child lock

Headlamp beam height adjustment

7

1

Dashboard instruments

Instrument panels

Rev counter

Rev counter (x 1,000 rpm),
graduation depends on the
engine.

Indicator

Engine coolant temperature
indicator.

Control button

Servicing reminder.

Setting the time.
Reset the function selected (service indicator
or trip recorder).
Depending on version:
-

Setting the time.

-

Digital speedometer.

Instrument panel lighting

Adjusting the intensity of the
general lighting.

Speedometer

Analogue speedometer (mph
or km/h).

Gauge

Fuel gauge.

8

Dashboard instruments

Displays

Cruise control settings.

Speed limiter settings.

Service indicator.

Total distance recorder
(miles or km).

Trip distance recorder (miles
or km).

Engine oil level indicator
(depending on version).

Gear shift indicator with a
manual gearbox.

Selector position and gear
with an electronic gearbox.
Selector position and gear
with an automatic gearbox.

Digital speedometer (mph
or km/h).

Display / hide the digital speedometer.
(Depending on version.)

Hold this button down.
"- -" or "0" is displayed.

Press this button to
display or hide the digital
speedometer.

Trip computer

Time counter of the Stop & Start.

Remaining driving range.

Current or average fuel consumption.

Average speed of the vehicle.

Distance travelled by the vehicle.

9

1

Dashboard instruments

Gearbox

Park position (Park).

Reverse gear (Rear).

Neutral.

Automatic mode (Drive).

Sequential mode.

Change up / Change down.

Sport programme.

Snow programme.

Trip recorder reset

With the trip distance displayed, press the
button for a few seconds.

10

Dashboard instruments

Warning and indicator
lamps

When the ignition is switched on

Certain warning lamps come on for a few
seconds when the vehicle's ignition is switched
on.
When the engine is started, these same
warning lamps should go off.
If they remain on, before driving refer to the
information on the warning lamp concerned.

Associated warnings

Certain warning lamps may come on in one of
two modes: fixed (continuous) or flashing.
Only by relating the type of lighting to the
operating status of the vehicle can it be
ascertained whether the situation is normal or
whether a fault has occurred.
In the event of a fault, the illumination of the
warning lamp may be accompanied by an
audible signal and/or a message.

Warning lamps

When the engine is running or the vehicle is
being driven, illumination of one of the following
warning lamps indicates a fault which requires
action on the part of the driver.
Any fault resulting in the illumination of a
warning lamp must be investigated further
using the associated message.
If you encounter any problems, contact a
PEUGEOT dealer or a qualified workshop.

Operation indicator lamps

The lighting of one of the following indicator
lamps confirms that the corresponding system
is on.

Deactivation indicator lamp

If this indicator lamp comes on, this confirms
that the corresponding system has been
switched off intentionally.
This may be accompanied by an audible signal
and a message being displayed.

Visual identifiers informing the driver that
a system is in operation, switched off (on/
off indicator lamps) or has developed a fault
(warning lamp).

11

1

Dashboard instruments

STOP

Fixed, associated with
another warning lamp,
accompanied by an
audible signal and a
message.

Illumination of this warning
lamp is related to a serious
fault detected with the engine,
the braking system, the power
steering, etc., or a major
electrical fault.

You must stop as soon as it is safe to do so.
Park, switch off the ignition and call a PEUGEOT
dealer or a qualified workshop.

Warning / indicator lamp

State

Cause

Action / Observations

Parking brake

Fixed.

The parking brake is applied or
not properly released.

Release the parking brake to extinguish the warning
lamp; keep your foot on the brake pedal.
Observe the safety recommendations.
For more information on the Parking brake, refer to
the corresponding section.

Braking

Fixed.

The brake fluid level has dropped
significantly.

You must stop as soon as it is safe to do so.
Top up with brake fluid approved by PEUGEOT.
If the problem persists, have the system checked by a
PEUGEOT dealer or a qualified workshop.

+

Fixed, associated with
the ABS warning lamp.

The electronic brake force
distribution (EBFD) system is
faulty.

You must stop as soon as it is safe to do so.
Have it checked by a PEUGEOT dealer or a qualified
workshop.

12

Dashboard instruments

Warning / indicator lamp

State

Cause

Action / Observations

Door(s) open

Fixed and associated
with a message
identifying the door.

Speed below 6 mph (10 km/h), a
door or the boot is not properly
closed.

Close the door or boot.

Fixed, associated with
a message identifying
the door, together with
an audible signal.

Speed above 6 mph (10 km/h), a
door or the boot is not properly
closed.

Seat belt(s) not
fastened/
unfastened

Fixed or flashing
accompanied by an
audible signal.

A belt has not been fastened or
has been unfastened.

Pull the strap then insert the tongue into the buckle.

Battery charge

Fixed.

The battery charging circuit has
a fault (dirty or loose terminals,
slack or cut alternator belt, etc.).

The warning lamp should go off when the engine is
started.
If it does not go off, contact a PEUGEOT dealer or a
qualified workshop.

Engine oil
pressure

Fixed.

The engine lubrication system
has a fault.

You must stop as soon as it is safe to do so.
Park, switch off the ignition and contact a PEUGEOT
dealer or a qualified workshop.

Maximum
coolant
temperature

Fixed, with the needle
in the red zone.

The temperature of the cooling
system is too high.

Stop as soon as it is safe to do so.
Wait until the engine has cooled down before topping
up to the required level, if necessary.
If the problem persists, contact a PEUGEOT dealer or
a qualified workshop.

13

1

Dashboard instruments

Warning / indicator lamp

State

Cause

Action / Observations

Engine self-
diagnosis
system

Fixed.

The emission control system has
a fault.

The warning lamp should go off when the engine is
started.
If it does not go off, contact a PEUGEOT dealer or a
qualified workshop without delay.

Flashing.

The engine management system
has a fault.

Risk of the catalytic converter being destroyed.
Have it checked by a PEUGEOT dealer or a qualified
workshop.

+

Fixed, associated with
the service warning
lamp.

A minor fault in the engine has
been detected.

Have it checked by a PEUGEOT dealer or a qualified
workshop.

+

Fixed, associated with
the STOP warning
lamp.

A major fault in the engine has
been detected.

You must stop as soon as it is safe to do so.
Park, switch off the ignition and contact a PEUGEOT
dealer or a qualified workshop.

14

Dashboard instruments

Warning / indicator lamp

State

Cause

Action / Observations

Foot on brake

Fixed.

The brake pedal must be
pressed.

With an electronic gearbox, selector in position N,
press the brake pedal to start the engine.
With an automatic gearbox, with the engine running,
press the brake pedal before releasing the parking
brake to unlock the lever and come out of position P.
If you wish to release the parking brake without
pressing the brake pedal, this warning lamp will
remain on.

Flashing.

With an electronic gearbox, if
you hold the vehicle on an incline
using the accelerator for too long,
the clutch overheats.

Use the brake pedal and/or the parking brake.

Anti-lock
Braking System
(ABS)

Fixed.

The anti-lock braking system has
a fault.

The vehicle retains conventional braking.
Drive carefully at reduced speed and contact a
PEUGEOT dealer or a qualified workshop without
delay.



















Content   ..  1  2  3   ..
