A warning may be displayed on the information screen and the buzzer may sound in the following rare cases.
This is caused by the system picking up interference such as noise or strong electromagnetic waves, and is not a functional problem.

•

An extremely strong electromagnetic wave is received from a source such as an illegal radio set, a spark from a wire, or a radar station.

•

Abnormal voltage or a static electricity discharge is generated by the operation of installed electrical equipment (including after-market parts).

If the warning display appears many times, we recommend you to consult a MITSUBISHI MOTORS Authorized Service Point.

Warning display list (when the ignition switch or the operation mode is OFF)

E00524000983

Screen type 1

Screen type 2

Cause

Solution (Reference)

You have forgotten to turn off
the lamps.

Refer to “Lamps (headlamps,
fog lamp, etc.) auto-cutout
function” on page 5-50.

The security alarm system is
operating.

Refer to “Security alarm sys-
tem” on page 3-32.

Indication lamp, warning lamp, and information screen display list

5-28

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

Cause

Solution (Reference)

––

There is a fault in the keyless
operation system.

Refer to “Keyless operation
system” on page 3-07.

––

There is a fault in the elec-
tronic immobilizer (Anti-theft
starting system).

We recommend you to con-
sult

MITSUBISHI

MOTORS Authorized Service
Point.

Indication lamp, warning lamp, and information screen display list

5-29

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

Cause

Solution (Reference)

––

The keyless operation key is
not detected.

Insert the keyless operation
key into the key slot in the
glove box.
Refer to “If the keyless opera-
tion key is not operating prop-
erly” on page 3-20.

––

You have forgotten to remove
the keyless operation key
from the key slot in the glove
box.

Remove the keyless operation
key from the key slot in the
glove box.

––

The steering wheel is locked.

Press the engine switch.
Refer to “Steering wheel
lock” on page 3-16.

––

The engine is stopped and the
selector lever is in a position
other than the “P” (PARK)
position.

On vehicles with A/T or
CVT, move the selector lever
to the “P” (PARK) position to
put the operation mode in
OFF.

––

The driver’s door is opened
with the steering wheel un-
locked.

Refer to “Steering wheel
lock” on page 3-16.

Indication lamp, warning lamp, and information screen display list

5-30

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

Cause

Solution (Reference)

––

There is a fault in the electri-
cal system.

Immediately  stop  the  vehicle
in  a  safe  place.  We  recom-
mend  you  to  consult  a
MITSUBISHI  MOTORS  Au-
thorized Service Point.

Warning display list (when the ignition switch or the operation mode is ON)

E00524102441

Screen type 1

Screen type 2

Cause

Solution (Reference)

The washer fluid is running
low.

Replenish the container with
washer fluid.
Refer to “Washer fluid” on
page 10-08
Refer to “Refill capacities” on
page 11-15.

There is a fault in the EPS.

Have the vehicle inspected by
a  MITSUBISHI  MOTORS
Authorized  Service  Point  as
soon as possible.
Refer  to  “Electric  power
steering  system  (EPS)”  on
page 6-36.

Indication lamp, warning lamp, and information screen display list

5-31

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

Cause

Solution (Reference)

––

There is a fault in the keyless
operation system.

Refer to “Keyless operation
system” on page 3-07.

Indication lamp, warning lamp, and information screen display list

5-32

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

Cause

Solution (Reference)

The brake fluid level in the
reservoir has fallen to a low
level.

There is a fault in the brake
system.

Immediately stop the vehicle
in a safe place.
We recommend you to con-
sult

MITSUBISHI

MOTORS Authorized Service
Point.
Refer to “Brake warning dis-
play” on page 5-48.

There is a fault in the ABS.

Avoid  sudden  braking  and
high-speed  driving,  stop  the
vehicle  in  a  safe  place,  and
take  corrective  measures.  Re-
fer to “ABS warning” on page
6-49.

The tyre pressure in one of
the tyres is low.

Refer to “Tyre pressure moni-
toring system (TPMS)” on
page 6-71.

There is a fault in the tyre
pressure monitoring system.

Refer to “Tyre pressure moni-
toring system (TPMS)” on
page 6-71.

One of the doors or the tail-
gate is not completely closed.
The open door is displayed.

Close the door or tailgate.
Refer to “Door ajar warning
display screen (when the igni-
tion switch or the operation
mode is ON)” on page 5-18.

Indication lamp, warning lamp, and information screen display list

5-33

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

Cause

Solution (Reference)

The bonnet is open.

Close the bonnet.
Refer to “Bonnet” on page
10-03.

––

There is a fault in the elec-
tronic immobilizer (Anti-theft
starting system).

Put the operation mode in
OFF, and then start the engine
again.
If the warning is not cancel-
led,

please

contact

MITSUBISHI MOTORS Au-
thorized Service Point.

––

The driver’s door is open and
the operation mode is put in a
mode other than OFF.

Put the operation mode in
OFF.
Refer to “Changing the opera-
tion mode” on page 3-14.

––

There is a fault in the steering
wheel lock.

Immediately stop the vehicle
in a safe place.
We recommend you to con-
sult

MITSUBISHI

MOTORS Authorized Service
Point.

––

There is a fault in the electri-
cal system.

Immediately stop the vehicle
in a safe place.
We recommend you to con-
sult

MITSUBISHI

MOTORS Authorized Service
Point.

Indication lamp, warning lamp, and information screen display list

5-34

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

Cause

Solution (Reference)

The engine is overheated.

Stop  the  vehicle  in  a  safe
place  and  take  corrective
measures.
Refer  to  “Engine  overheat-
ing” on page 8-04.

The automatic transmission
(A/T or CVT) fluid tempera-
ture is too high.

Refer to “Automatic transmis-
sion INVECS-II Sports Mode
6A/T  (Intelligent  &  Innova-
tive  Vehicle  Electronic  Con-
trol  System  II)”  on  page
6-26.

Refer to “Automatic transmis-
sion

INVECS-III

Sports

Mode 6CVT (Intelligent &
Innovative Vehicle Electronic
Control System III)” on page
6-32.

You  turned  the  ignition
switch  to  the  “ON”  position
or  put  the  operation  mode  in
ON  without  fastening  your
seat belt.

Fasten your seat belt properly.
“Seat belt warning” on page
4-11.

There is a fault in the fuel
system.

We recommend you to con-
sult

MITSUBISHI

MOTORS Authorized Service
Point.

Indication lamp, warning lamp, and information screen display list

5-35

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

Cause

Solution (Reference)

You are driving with the
parking brake still applied.

Release the parking brake.
Refer to “Brake warning dis-
play” on page 5-48.

There is a fault in the engine
oil circulation system.

Immediately  stop  the  vehicle
in  a  safe  place.  We  recom-
mend you to have it checked.
Refer  to  “Oil  pressure  warn-
ing display” on page 5-50.

There is a fault in the charg-
ing system.

Immediately  stop  the  vehicle
in  a  safe  place.  We  recom-
mend  you  to  consult  a
MITSUBISHI  MOTORS  Au-
thorized Service Point.
Refer to “Charge warning dis-
play” on page 5-49.

There is a fault in the SRS
airbag or the pretensioner sys-
tem.

We recommend you to have it
checked, immediately.
Refer to “Supplemental re-
straint System (SRS) warning
lamp” on page 4-36.

There is an automatic head-
lamp levelling fault.

We recommend you to have it
checked.
Refer to “Automatic head-
lamp levelling” on page
5-56.

Indication lamp, warning lamp, and information screen display list

5-36

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

Cause

Solution (Reference)

There is a fault in the Active
Stability Control (ASC).

We recommend you to have it
checked.
Refer to “Active Stability
Control (ASC)” on page
6-51.

There is a fault in the hill start
assist.

Have the vehicle checked at a
MITSUBISHI MOTORS Au-
thorized Service Point.
Refer to “Hill start assist” on
page 6-46.

There is a fault in the elec-
tronically controlled 4WD
system.

We recommend you to have it
checked.
Refer to “Electronically con-
trolled 4WD system” on page
6-39.

There is a fault in the A/T or
CVT.

We recommend you to have it
checked.
Refer to “Automatic transmis-
sion INVECS-II Sports Mode
6A/T  (Intelligent  &  Innova-
tive  Vehicle  Electronic  Con-
trol  System  II)”  on  page
6-26.
Refer to “Automatic transmis-
sion

INVECS-III

Sports

Mode 6CVT (Intelligent &
Innovative Vehicle Electronic
Control System III)” on page
6-32.

Indication lamp, warning lamp, and information screen display list

5-37

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

Cause

Solution (Reference)

The electronically controlled
4WD system is hot.

Refer to “Electronically con-
trolled 4WD system” on page
6-39.

The fuel additives are running
low.

Refill the fuel additives at a
MITSUBISHI MOTORS Au-
thorized Service Point.

The fuel is running low.

Refuel  as  soon  as  possible.
Refer  to  “Fuel  remaining
warning  display”  on  page
5-16.

An excessive amount of par-
ticulate matter (PM) accumu-
lates inside the diesel particu-
late filter (DPF).

Refer to “Diesel particulate
filter (DPF)” on page 6-17.

It is suspected that the engine
oil level has increased exces-
sively.

Immediately have your vehi-
cle

checked

MITSUBISHI  MOTORS  Au-
thorized Service Point.
Refer  to  “Engine  oil  level
warning  display”  on  page
5-50.

Indication lamp, warning lamp, and information screen display list

5-38

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

Cause

Solution (Reference)

More than specified limit wa-
ter has accumulated in the
fuel filter.

We recommend you to have it
checked.
Refer to “Fuel filter indicator
display” on page 5-48 .

The outside temperature is
3 °C (37 °F) or less.

Be careful of ice on the road.

The road can be icy even
when this warning is not dis-
played, so drive carefully.

—

There is a fault in the Forward
Collision Mitigation system
(FCM).

We recommend you to have it
checked. Refer to “FCM
braking function” on page
6-60.

—

The FCM braking function of
the Forward Collision Mitiga-
tion system (FCM) has been
activated.

Refer to “FCM braking function”
on page 6-60.

—

The  Forward  Collision  Miti-
gation  system  (FCM)  is  tem-
porarily  unavailable  for  some
reason. This is not a malfunc-
tion.

Indication lamp, warning lamp, and information screen display list

5-39

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

Cause

Solution (Reference)

—

(flashing in yellow)

The Lane Departure Warning
(LDW) has detected that your
vehicle is about to leave or
has left the lane.

Refer to “Lane Departure Warning
(LDW)” on page 6-68.

—

There is a fault in the Lane
Departure Warning (LDW).

We recommend you to have it
checked. Refer to “LDW de-
activation due to fault” on
page 6-70.

—

There is a fault in the sensor.

We recommend you to con-
sult

MITSUBISHI

MOTORS Authorized Service
Point.
Refer  to  “Forward  Collision
Mitigation  system  (FCM):
System  problem  warning”  on
page 6-65.
Refer  to  “Lane  Departure
Warning  (LDW):  System
problem  warning”  on  page
6-69.

Indication lamp, warning lamp, and information screen display list

5-40

OGAE18E1

Instruments and controls

Screen type 1

Screen type 2

Cause

Solution (Reference)

—

The  Forward  Collision  Miti-
gation  system  (FCM)  and
Lane  Departure  Warning
(LDW)  is  temporarily  un-
available  due  to  the  high  or
low temperature of the sensor.

After  the  temperature  of  the
sensor  has  been  in  range,  the
system  will  automatically  re-
turn to operation.
Refer  to  “Forward  Collision
Mitigation  system  (FCM):
System  problem  warning”  on
page 6-65.
Refer  to  “Lane  Departure
Warning  (LDW):  System
problem  warning”  on  page
6-69.

—

The sensor is temporarily un-
available  due  to  conditions
such  as  the  adhesion  of  con-
taminants  to  the  sensor  or
windscreen.
This is not a malfunction.

Refer to “Forward Collision Miti-
gation system (FCM): System
problem warning” on page 6-65.
Refer to “Lane Departure Warning
(LDW): System problem warning”
on page 6-69.

Indication lamp, warning lamp, and information screen display list

5-41

OGAE18E1

Instruments and controls

Content .. 7 8 9 10 ..
