Lexus NX350h (2024 year). Manual in english

Adding washer fluid

If washer fluid does not spray from any of the
washers or "Windshield Washer Fluid Low" is
displayed on the multi-information display, the
washer fluid bottle may be empty. Add washer
fluid.

WARNING

Do not add washer fluid when the hybrid system is hot or operating.
As washer fluid contains alcohol, it may catch fire if spilled on the engine, etc.

NOTICE

■

Do not use any fluid other than washer fluid

Do not use soapy water or engine antifreeze instead of washer fluid. Doing so may cause
streaking on the vehicle’s painted surfaces, as well as damaging the pump leading to
problems of the washer fluid not spraying.

■

Diluting washer fluid

Dilute washer fluid with water as necessary. Refer to the freezing temperatures listed on
the label of the washer fluid bottle.

8-4. Inspection of consumables

567

Maintenance and car

12-volt battery

12-volt battery location

WARNING

■

Chemicals in the 12-volt battery

The 12-volt battery contains poisonous and corrosive sulfuric acid and may produce
hydrogen gas which is flammable and explosive.
Observe the following precautions while working on or near the 12-volt battery:

●

Do not cause sparks by touching the 12-volt battery terminals with tools.

●

Do not smoke or light a match near the 12-volt battery.

●

Avoid contact with eyes, skin and clothes.

●

Never inhale or swallow electrolyte.

●

Wear protective safety glasses when working near the 12-volt battery.

●

Keep children away from the 12-volt battery.

■

Where to safely charge the 12-volt battery

Always charge the 12-volt battery in an open area. Do not charge the 12-volt battery in a
garage or closed room where there is insufficient ventilation.

■

Emergency measures regarding electrolyte

●

If electrolyte gets in your eyes, flush your eyes with clean water for at least 15 minutes
and get immediate medical attention. If possible, continue to apply water with a
sponge or cloth while traveling to the nearest medical facility.

●

If electrolyte gets on your skin, wash the affected area thoroughly. If you feel pain or
burning, get medical attention immediately.

●

If electrolyte gets on your clothes, it may soak through your clothing on to your skin.
Immediately take off the clothing and follow the procedure above if necessary.

●

If you accidentally swallow electrolyte, drink a large quantity of water or milk and get
emergency medical attention immediately.

■

When disconnecting the 12-volt battery

Never disconnect the negative (-) terminal. The disconnected body ground terminal may
touch the positive (+) terminal, which may cause a short, resulting in death or serious
injury.

8-4. Inspection of consumables

568

The 12-volt battery is located on the left side of
luggage compartment.

Removing the 12-volt battery cover

Open the deck board.

Remove the 12-volt battery cover.

Checking the 12-volt battery

■

12-volt battery exterior

Make sure that the 12-volt battery terminals are not corroded and that there are no
loose connections, cracks, or loose clamps.

Terminals

Hold-down clamp

Before recharging

When recharging, the 12-volt battery produces hydrogen gas which is flammable
and explosive. Therefore, observe the following precautions before recharging:

●

If recharging with the 12-volt battery installed on the vehicle, be sure to discon-
nect the ground cable.

●

Make sure the power switch on the charger is off when connecting and discon-
necting the charger cables to the 12-volt battery.

8-4. Inspection of consumables

569

Maintenance and car

NOTICE

When recharging the 12-volt battery, make sure that the hybrid system is operating and
all accessories are off.

After recharging or reconnecting the 12-volt battery

The hybrid system may not start. Follow the procedure below to initialize the
system.

Change the shift position to P.

Open and close any of the doors.

Restart the hybrid system.

INFORMATION

●

Unlocking the doors using the smart access system with push-button start may not
be possible immediately after reconnecting the 12-volt battery. If this happens, use
the wireless remote control or the mechanical key to lock/unlock the doors.

●

Start the hybrid system with the power switch in ACC. The hybrid system may not
start with the power switch turned off. However, the hybrid system will operate
normally from the second attempt.

●

The power switch mode is recorded by the vehicle. If the 12-volt battery is
disconnected and reconnected, the vehicle will return the power switch to the
mode it was in before the 12-volt battery was disconnected. Make sure to turn the
power switch off before disconnecting the 12-volt battery. Take extra care when
connecting the 12-volt battery if the power switch mode prior to the 12-volt battery
being disconnected is unknown.
If the hybrid system does not start even after multiple attempts at all methods
above, contact your Lexus dealer.

8-4. Inspection of consumables

570

Air conditioning filter maintenance

The air conditioning filter must be changed regularly to maintain air conditioning
efficiency.

Checking interval

Inspect and replace the air conditioning filter according to the maintenance sched-
ule. In dusty areas or areas with heavy traffic flow, early replacement may be
required.

●

If air flow from the vents decreases dramatically, the air conditioning filter may
be clogged. Check the filter and replace it if necessary.
(For scheduled maintenance information, please refer to the "Owner’s Manual
Supplement" or "Scheduled Maintenance".)

●

If air fresheners, etc. are used inside the vehicle, the service life of the deo-
dorizing function of the air conditioning filter with deodorizing function may
be reduced significantly. If odors from the air conditioning system become a
concern, replace the filter.

Replacing the air conditioning filter

NOTICE

Observe the following precautions when using the air conditioning system.
Make sure that a filter is always installed. Using the air conditioning system without a filter
may cause damage to the system.

Turn the power switch off.

Open the glove box and disconnect the
damper stay from the pin.

8-4. Inspection of consumables

571

Maintenance and car

Push both the sides of the glove box inward
and disengage each claw on the upper side.
Then, pull the glove box to disengage the
claws on the lower side and remove the glove
box.

Unlock the filter cover ( ), pull the filter
cover out of the claws ( ), and remove the
filter cover.

Remove the filter case.

Remove the air conditioning filter from the
filter case and replace it with a new one.

The [

UP] marks shown on the filter should be

pointing up.

8-4. Inspection of consumables

572

Tire maintenance

Replace or rotate tires in accordance with maintenance schedules and treadwear.

NOTICE

Take particular care when driving on uneven rough roads with cracks and potholes.
These conditions may cause loss of tire inflation pressure, reducing the cushioning ability
of the tires. Driving on rough roads may also cause damage to the tires themselves, as
well as the vehicle’s wheels and body.

8-5. Tire maintenance

573

Maintenance and car

Tire inspection items

WARNING

■

When inspecting or replacing the tires

Observe the following precautions.
Failure to do so may lead to damage to the drivetrain or unstable handling.

●

Do not mix tires of different makes, models or tread patterns. Also, do not mix tires of
remarkably different treadwear.

●

Do not use tire sizes other than those recommended by Lexus.

●

Do not mix differently constructed tires (radial, bias-belted or bias-ply tires).

●

Do not mix summer, all season and snow tires.

●

Do not use tires that have been used on another vehicle.
Do not use tires if you do not know how they were used previously.

●

Vehicles with an emergency tire puncture repair kit: Do not tow anything if a tire that
has been repaired using the emergency tire puncture repair kit is installed. The load on
the tire may cause unexpected damage to the tire.

NOTICE

If tire inflation pressure becomes low while driving, do not continue driving. Otherwise
the tire or wheel may be damaged.

Check if the treadwear indicators are showing on the tires. Also check the tires for
uneven wear, such as excessive wear on one side of the tread.
Check the spare tire condition and pressure if not rotated.

New tread

Worn tread

Treadwear indicator
The location of treadwear indicators is
shown by a [TWI] or

mark, etc., molded

into the sidewall of each tire.
Replace the tires if the treadwear indicators
are showing on a tire.

8-5. Tire maintenance

574

INFORMATION

■

When to replace your vehicle’s tires

Tires should be replaced if:

●

The treadwear indicators are showing on a tire.

●

You have tire damage such as cuts, splits, cracks deep enough to expose the fabric,
and bulges indicating internal damage.

●

A tire goes flat repeatedly or cannot be properly repaired due to the size or location of
a cut or other damage.
If you are not sure, consult with your Lexus dealer.

■

Tire life

Any tire over 6 years old must be checked by a qualified technician even if it has seldom
or never been used or damage is not obvious.

■

Maximum load of tire

Check that the number given by dividing the maxi-
mum load by 1.10 of the replacement tire is greater
than 1/2 of the Gross Axle Weight Ratings (GAWR)
of either the front axle or the rear axle, whichever is
greater.
For the GAWR, see the Certification Label.
For the maximum load of the tire, see the load limit
at maximum cold tire inflation pressure mentioned on
the sidewall of the tire.

■

Tire types

●

Summer tires
Summer tires are high-speed performance tires best suited to highway driving under
dry conditions. Since summer tires do not have the same traction performance as
snow tires, summer tires are inadequate for driving on snow-covered or icy roads. For
driving on snow-covered roads or icy roads, the use of snow tires is recommended.
When installing snow tires, be sure to replace all four tires.

●

All season tires
All season tires are designed to provide better traction in snow and to be adequate
for driving in most winter conditions as well as for use year-round. All season tires,
however, do not have adequate traction performance compared with snow tires in
heavy or loose snow. Also, all season tires fall short in acceleration and handling
performance compared with summer tires in highway driving.

●

Snow tires

8-5. Tire maintenance

575

Maintenance and car

For driving on snow-covered roads or icy roads, we recommend using snow tires. If
you need snow tires, select tires of the same size, construction and load capacity as the
originally installed tires. Since your vehicle has radial tires as original equipment, make
sure your snow tires also have radial construction. Do not install studded tires without
first checking local regulations for possible restrictions.
Snow tires should be installed on all wheels.

■

If the tread on snow tires wears down below 0.16 in. (4 mm)

The effectiveness of the tires as snow tires is lost.

8-5. Tire maintenance

576

Run-flat tire features

When run-flat tires are installed, the vehicle can be driven for a maximum of
50 miles (80 km) at a speed below 50 mph (80 km/h) after any tire goes
flat. (However, the vehicle speed may not increase to near 50 mph [80 km/h]
depending on weather or driving conditions.)
Make sure to replace the flat tire before the vehicle has been driven for near 50
miles (80 km). Also, do not use a repaired tire.

A run-flat tire has a

mark on the side wall.

INFORMATION

■

Precautions for run-flat tires

●

The run-flat tires are for only this vehicle. Do not use the tires on other vehicles.

●

Do not mix run-flat tires and normal tires.

●

If non-genuine Lexus wheels are used, it may be impossible to sufficiently demonstrate
the performance of run-flat tires.

* :

If equipped

8-5. Tire maintenance

577

Maintenance and car

Operation of the tire pressure warning system

Your vehicle is equipped with a tire pressure warning system that uses tire pressure
warning valves and transmitters to detect low tire inflation pressure before serious
problems arise.
The tire pressure warning system of this vehicle adopts a 2-type warning system.

▶

Multi-information display (vehicles without a head-up display)

▶

Multi-information display (vehicles with a head-up display)

▶

Center display

●

When "Adjust Pressure" is displayed (Normal Warning)
A warning with the tire pressure warning light and warning buzzer when there
is an unknown level of low tire pressure with the appearance of the tire due
to natural air leakage as well as the pressure lowering due to changes in the
pressure according to the outside temperature.

8-5. Tire maintenance

578

●

When "Immediately Check tire when Safe" is displayed (Emergency Warning)
A warning with the tire pressure warning light and warning buzzer when there is
a known level of low tire pressure with the appearance of the tire due to pressure
suddenly lowering.
However, the system may not be able to detect sudden tire ruptures (bursting,
etc.).

●

The tire pressure detected by the tire pressure warning system can be displayed
on the center display.

INFORMATION

■

Routine tire inflation pressure checks

The tire pressure warning system does not replace routine tire inflation pressure checks.
Make sure to check tire inflation pressure as part of your routine of daily vehicle checks.

■

Tire inflation pressure

●

It may take a few minutes to display the tire inflation pressure after the power switch is
turned to ON.
It may also take a few minutes to display the tire inflation pressure after inflation
pressure has been adjusted.

●

Tire inflation pressure changes with temperature. The displayed values may also be
different from the values measured using a tire pressure gauge.

■

Situations in which the tire pressure warning system may not operate properly

●

In the following cases, the tire pressure warning system may not operate properly.

•

If non-genuine Lexus wheels are used.

•

A tire has been replaced with a tire that is not an OE (Original Equipment) tire.

•

A tire has been replaced with a tire that is not of the specified size.

•

Tire chains, etc. are equipped.

•

If a window tint that affects the radio wave signals is installed.

•

If there is a lot of snow or ice on the vehicle, particularly around the wheels or wheel
housings

•

If the tire inflation pressure is extremely higher than the specified level.

•

If tires not equipped with tire pressure warning valves and transmitters are used.

•

If the ID code on the tire pressure warning valves and transmitters is not registered
in the tire pressure warning computer.

●

Performance may be affected in the following situations.

8-5. Tire maintenance

579

Maintenance and car

•

Near a TV tower, electric power plant, gas station, radio station, large display,
airport or other facility that generates strong radio waves or electrical noise.

•

When carrying a portable radio, cellular phone, cordless phone or other wireless
communication device.

If tire position information is not correctly displayed due to the radio wave conditions,
the display may be corrected by changing the location of the vehicle as the radio wave
conditions may change.

●

When the vehicle is parked, the time taken for the warning to start or go off could be
extended.

●

When tire inflation pressure declines rapidly for example when a tire has burst, the
warning may not operate.

Installing tire pressure warning valves and transmitters

NOTICE

■

Repairing or replacing tires, wheels, tire pressure warning valves, transmitters and
tire valve caps

●

When removing or fitting the wheels, tires or the tire pressure warning valves and
transmitters, contact your Lexus dealer as the tire pressure warning valves and trans-
mitters may be damaged if not handled correctly.

●

Make sure to install the tire valve caps. If the tire valve caps are not installed, water
could enter the tire pressure warning valves, corrode the valve, and cause sticking and
air leaks.

●

When replacing tire valve caps, do not use tire valve caps other than those specified.
The cap may become stuck.

■

To avoid damage to the tire pressure warning valves and transmitters

When a tire is repaired with liquid sealants, the tire pressure warning valve and transmit-
ter may not operate properly. If a liquid sealant is used, contact your Lexus dealer or
other qualified service shop as soon as possible. Make sure to replace the tire pressure
warning valve and transmitter when replacing the tire.

When replacing tires or wheels, tire pressure warning valves and transmitters must
also be installed.
When new tire pressure warning valves and transmitters are installed, new ID
codes must be registered in the tire pressure warning computer

8-5. Tire maintenance

580

INFORMATION

■

When replacing the tires and wheels

If the ID code of the tire pressure warning valve and transmitter is not registered, the tire
pressure warning system will not work properly.
In this case, after driving for about 20 minutes, the tire pressure warning light blinks for 1
minute and stays on to indicate a system malfunction.

Registration of the position of each wheel after performing a tire rota-
tion

It is necessary to register the position of each wheel after performing a tire
rotation.
Wheel position registration can be performed by oneself. Wheel position registra-
tion is performed by driving forward with moderate left and right turns. However,
depending on the driving conditions and driving environment, registration may
take some time to complete.

Park the vehicle in a safe place, turn the power switch off and wait 15 minutes or
more.

Start the hybrid system.

The wheel position registration procedure cannot be performed while the vehicle is
moving.

Select

on the center display.

Select [Vehicle customize].

Select [Tire pressure].

Select [Tire rotation].

Select [Continue].

A message indicating that wheel position registration is being performed will be
displayed on the multi-information display. "---" will be displayed for the tire inflation
pressure of each tire and wheel position registration will begin.

Drive straight (with occasional left and right turns) at approximately 25 mph
(40 km/h) or more for approximately 10 to 30 minutes.

When wheel position registration is complete, a message indicating that registration
has been completed and the inflation pressure of each tire will be displayed on the
multi-information display.
Even if it is not possible to drive continuously at approximately 25 mph (40 km/h) or
more, registration can be completed by driving for a long time. However, if registration

8-5. Tire maintenance

581

Maintenance and car

does not complete after driving for 1 hour or more, park the vehicle in a safe place and
leave it with the power switch in ON for approximately 15 minutes or more, and then
perform the driving procedure again.

INFORMATION

■

When performing wheel position registration

●

Normally, wheel position registration can be completed within approximately 30
minutes.

●

Wheel position registration is performed while driving at a vehicle speed of
approximately 25 mph (40 km/h) or more.

■

Wheel position registration procedure

●

If the power switch is turned off while registering the wheel position, the next time
the power switch is turned to ON, the wheel position registration will resume and
it will not be necessary to restart the procedure.

●

While the position of each wheel is being determined and the inflation pressures
are not being displayed, if the inflation pressure of a tire drops, the tire pressure
warning light will come on.

■

If the wheel position cannot be registered easily

●

In the following situations, wheel position registration may take longer than usual
to be completed or may not be possible.

•

Vehicle is not driven at approximately 25 mph (40 km/h) or more

•

Vehicle is driven on unpaved roads

•

If wheel position registration does not complete after driving for 1 hour or more,
park the vehicle in a safe place for approximately 15 minutes and then drive the
vehicle again.

●

If the vehicle is reversed during wheel position registration, all data collected until
then will be cleared. Perform driving again.

Setting the tire pressure

In the following situations, it will be necessary to perform the tire inflation pressure
setting procedure of the tire pressure warning system.

●

When the specified tire inflation pressure has changed, such as due to carried
load, etc.

●

When the tire inflation pressure is changed such as when the tire size is
changed.

If the tire inflation pressure has been adjusted to the specified level, perform the tire
inflation setting procedure by selecting specified inflation pressure on the center
display.

8-5. Tire maintenance

582

When the tire inflation pressure is to be other than specified, such as when tires
other than the specified size are used, etc., set the tire inflation pressure using
the current pressure. Make sure to adjust the tire inflation pressure of each tire
to the appropriate level before performing tire pressure setting. The tire pressure
warning system operates based on this tire inflation pressure.

Setting by selecting a specified tire inflation pressure

Start the hybrid system.

The tire inflation pressure cannot be set while the vehicle is moving.

Select

on the center display.

Select [Vehicle customize].

Select [Tire pressure].

Select [Set indicated air pressure] and then select the desired front and rear
tire pressures.

Select [OK].

The tire pressure warning light will slowly blink 3
times.
After setting the tire inflation pressure, a message
indicating that setting has been completed will be
displayed on the multi-information display.

INFORMATION

■

If the tire inflation pressure cannot be set easily

●

If the tire pressure warning light does not blink 3 times when starting the tire
inflation pressure setting procedure, the procedure may not have started. Perform
the procedure again from the beginning.

●

If tire inflation pressure setting procedure cannot be completed after performing
the above procedure, contact your Lexus dealer.

8-5. Tire maintenance

583

Maintenance and car

Setting using the current tire inflation pressure

WARNING

Make sure to adjust the tire inflation pressure of each tire to the appropriate level before
performing tire pressure setting. Otherwise, the tire pressure warning light may not
illuminate even if the tire inflation pressure drops or may illuminate even though the tire
inflation pressure is normal.

INFORMATION

■

Warning performance of the tire pressure warning system

●

When performing the tire pressure setting using the current tire inflation pressure,
the warning timing of the tire pressure warning system will vary according to the
conditions under which tire pressure setting was performed. Therefore, a warning may
be output even if the tire inflation pressure drops slightly or if the tire inflation pressure
increases above that when the tire inflation pressure was set.

●

Make sure to perform the tire pressure setting procedure after adjusting the tire
inflation pressure. Also, make sure the tires are cold before performing the tire
pressure setting procedure or adjusting the tire inflation pressure.

Adjust the tire inflation pressure of each tire to the appropriate level.

Make sure to adjust the tire inflation pressure with the tires cold.

Start the hybrid system.

The tire inflation pressure cannot be set while the vehicle is moving.

Select

on the center display.

Select [Vehicle customize].

Select [Tire pressure].

Select [Set current air pressure].

Select [Continue].

The tire pressure warning light will slowly blink 3
times and a message indicating that tire inflation
pressure is being set will be displayed on the mul-
ti-information display.
After setting the tire inflation pressure, a message
indicating that setting has been completed will be
displayed on the multi-information display.

8-5. Tire maintenance

584

INFORMATION

■

Tire inflation pressure setting procedure

●

If the power switch is turned off while setting the tire inflation pressure, the next
time the power switch is turned to ON, the setting procedure will resume and it
will not be necessary to restart the procedure.

●

If the tire inflation pressure setting procedure is started unnecessarily, adjust the
tire inflation pressure to the specified level with the tires cold and then perform
setting by selecting a specified tire inflation pressure, or perform the tire inflation
pressure setting procedure with the current tire inflation pressure.

■

If the tire inflation pressure cannot be set easily

●

Normally, the tire inflation pressure setting procedure can be completed in 2 or 3
minutes.

●

If tire inflation pressure setting procedure cannot be completed after performing
the above procedure, contact your Lexus dealer.

Registering ID codes

The tire pressure warning valve and transmitter is equipped with a unique ID code.
When new tire pressure warning valves and transmitters are installed, new ID
codes must be registered in the tire pressure warning computer.

INFORMATION

●

ID codes can be registered by yourself, but depending on the driving conditions and
driving environment, registration may take some time to complete.

●

When using a wheel set which all of the ID codes have already been registered, the
wheel set can be changed in a short amount of time.

Before performing ID code registration, make sure that no wheels with tire pres-
sure warning valve and transmitters installed are near the vehicle.

Park the vehicle in a safe place, turn the power switch off and wait 15 minutes or
more.

Start the hybrid system.

The ID code registration procedure cannot be performed while the vehicle is moving.

Select

on the center display.

Select [Vehicle customize].

8-5. Tire maintenance

585

Maintenance and car

Select [Tire pressure].

Check if the desired wheel set ([Set 1] or [Set
2]) is displayed.

ID codes will be registered to the displayed wheel
set.
To change the wheel set to be registered, select
the displayed set, and then select the wheel set
you wish to register.
If ID codes have already been registered for that
wheel set, the tire pressure warning light will slowly blink 3 times, and a message
indicating that change is occurring will be displayed on the multi-information display.

Select [New tire registration].

Select [Continue].

The tire pressure warning light will slowly blink 3
times and a message indicating that ID code reg-
istration is being performed will be displayed on
the multi-information display. Wheel set changing
will be canceled and registration will begin.
When registration is being performed, the tire
pressure warning light will blink for approximately
1 minute then illuminate and "---" will be displayed for the inflation pressure of each tire
on the multi-information display.

INFORMATION

If the tire pressure warning light does not blink 3 times when starting ID code
registration procedure, the procedure may not have started. Perform the procedure
again from the beginning.

Drive straight (with occasional left and right turns) at approximately 25 mph
(40 km/h) or more for approximately 10 to 30 minutes.

When registration is complete, the tire pressure warning light will turn off and a
message indicating that registration has been completed will be displayed on the
multi-information display.
Registration may take longer than normal to complete if the vehicle speed cannot be
maintained at approximately 25 mph (40 km/h) or more. If registration cannot be
completed after driving for 1 hour or more, perform the registration procedure again
from the beginning.

8-5. Tire maintenance

586

INFORMATION

■

When registering ID codes

●

Normally, wheel position registration can be completed within approximately 30
minutes.

●

ID code registration is performed while driving at a vehicle speed of approximate-
ly 25 mph (40 km/h) or more.

■

If ID codes are not registered easily

●

In the following situations, ID code registration may take longer than usual to be
completed or may not be possible.

•

When the vehicle has not been parked for approximately 15 minutes or more
before being driven

•

Vehicle is not driven at approximately 25 mph (40 km/h) or more

•

Vehicle is driven on unpaved roads

•

Vehicle is driven near other vehicles and system cannot recognize tire pressure
warning valve and transmitters of your vehicle over those of other vehicles

•

Wheel with tire pressure warning valve and transmitter installed is inside or
near the vehicle

●

If the vehicle is reversed during registration, all data collected until then will be
cleared. Perform driving again.

●

If registration does not complete after driving for 1 hour or more, perform the ID
code registration procedure again from the beginning.

●

If the ID codes cannot be registered even when performing the above procedure,
contact your Lexus dealer.

If the tire inflation pressure of the wheel set installed differs from that of the
previous set, it will be necessary to perform the tire inflation pressure setting
procedure of the tire pressure warning system.

If the specified tire inflation pressure is the same, it will not be necessary to perform the
tire inflation pressure setting procedure.

Related Links

Setting the tire pressure(P. 582)

Canceling ID code registration

To cancel ID code registration after it has been started, select [New tire registra-
tion] again on the center display.

If ID code registration has been canceled, the tire pressure warning light will turn off.

8-5. Tire maintenance

587

Maintenance and car

If the warning light does not turn off, ID code registration may not have been cancelled
correctly. To cancel registration, select [New tire registration] again on the center display.

Selecting wheel set

Your vehicle is equipped with a tire pressure warning system with a function to
register two sets of ID codes. This allows for registration of a second wheel set, for
example a winter set.

●

The wheel set can be changed only if a second wheel set has been registered to
the system. If a second wheel set has not been registered, "Set 2(Unregistered)"
will be displayed and it will not be possible to change to the selected wheel set.
ID codes can be registered by yourself.

●

Only a change between both registered wheel set is possible, mixing between
these wheel sets is not supported.

●

While registering ID codes, it may not be possible to change between wheel
sets normally. Cancel registration before changing between wheel sets.

Install the desired wheel set.

Select

on the center display.

Select [Vehicle customize].

Select [Tire pressure].

Select the wheel set ([Set 1] or [Set 2]) displayed for the set selection setting.

Select the wheel set you wish to register, and then select [OK].

The tire pressure warning light will slowly blink 3 times, a message indicating that
change is occurring will be displayed, and the wheel set change will begin.
Wheel set change will begin and the tire pressure warning light will blink for 1 minute
and then illuminate. Also, while the change is being performed, "---" will be displayed
for the tire inflation pressure of each tire on the multi-information display.
After approximately 2 minutes, the wheel set
change will complete, the tire pressure warning
light will turn off, and a completion message will
be displayed on the multi-information display.
If changing does not complete after approximate-
ly 4 minutes, a message indicating that the change
could not be completed will be displayed.
Check which wheel set is installed and perform
the change procedure again from the beginning.

8-5. Tire maintenance

588

If the specified tire inflation pressure of the wheel set installed differs from that
of the previous set, it will be necessary to perform the tire inflation pressure
setting procedure of the tire pressure warning system.

If the specified tire inflation pressure is the same, it will not be necessary to perform the
tire inflation pressure setting procedure.

8-5. Tire maintenance

589

Maintenance and car

Checking tire inflation pressure

You should check tire inflation pressure every two weeks, or at least once a
month.Do not forget to check the spare.

WARNING

In order to ensure the performance of the tires, maintain proper tire inflation pressure.
If the tires are not properly inflated, the following may occur:

●

Excessive wear

●

Uneven wear

●

Poor handling

●

Possibility of blowouts resulting from overheated tires

●

Air leaking from between tire and wheel

●

Wheel deformation and/or tire damage

●

Greater possibility of tire damage while driving (due to road hazards, expansion joints,
sharp edges in the road, etc.)

NOTICE

After inspecting and adjusting tire inflation pressure, make sure to install the tire valve
caps.
If a valve cap is not installed, dirt or moisture may get into the valve and cause an air leak,
resulting in decreased tire inflation pressure.

Driving with incorrect tire inflation pressure may result in the following:

●

Reduced fuel economy

●

Reduced driving comfort and poor handling

●

Reduced tire life due to wear

●

Reduced safety

●

Damage to the drive train

If a tire needs frequent inflating, have it checked by your Lexus dealer.

■

Instructions for checking tire inflation pressure

When checking tire inflation pressure, observe the following:

●

Check only when the tires are cold.
If your vehicle has been parked for at least 3 hours or has not been driven for
more than 1 mile or 1.5 km, you will get an accurate cold tire inflation pressure
reading.

8-5. Tire maintenance

590

●

Always use a tire pressure gauge.
It is difficult to judge if a tire is properly inflated based only on its appearance.

●

It is normal for the tire inflation pressure to be higher after driving as heat is
generated in the tire. Do not reduce tire inflation pressure after driving.

●

Never exceed the vehicle capacity weight.
Passengers and luggage weight should be placed so that the vehicle is balanced.

Checking the specified tire inflation pressure

The recommended cold tire inflation pressure
and tire size are displayed on the tire and loading
information label.

Tire inflation pressure inspection and adjustment procedure

Tire valve

Tire pressure gauge

Remove the tire valve cap.

Press the tip of the tire pressure gauge onto
the tire valve.

Read the pressure using the gauge gradations.

If the tire inflation pressure is not at the recom-
mended level, adjust the pressure.

If you add too much air, press the center of the
valve to deflate.

After completing the tire inflation pressure measurement and adjustment, apply
soapy water to the valve and check for leakage.

Put the tire valve cap back on.

8-5. Tire maintenance

591

Maintenance and car

Rotating the tires

To equalize tire wear and extend tire life, Lexus recommends that tire rotation be
performed at the same interval as tire inspection.
Rotate the tires as shown in the illustration.
Make sure to perform wheel position registration procedure after rotating the tires.

Front

8-5. Tire maintenance

593

Maintenance and car

Wheels

If a wheel is bent, cracked or heavily corroded, it should be replaced. Otherwise,
the tire may separate from the wheel, causing a loss of handling control.

Wheel selection

When replacing wheels, care should be taken to ensure that they are equivalent to
those removed in load capacity, diameter, rim width and inset

Replacement wheels are available at your Lexus dealer.
Lexus does not recommend using the following:

●

Wheels of different sizes or types

●

Used wheels

●

Bent wheels that have been straightened

INFORMATION

■

When replacing wheels

The wheels of your vehicle are equipped with tire pressure warning valves and transmit-
ters that allow the tire pressure warning system to provide advance warning in the event
of a loss in tire inflation pressure.
Whenever wheels are replaced, tire pressure warning valves and transmitters must be
installed.

WARNING

■

When replacing wheels

●

Do not use wheels that are a different size from those recommended in the Owner’s
Manual, as this may result in a loss of handling control.

●

Never use an inner tube in a leaking wheel which is designed for a tubeless tire. Doing
so may result in an accident, causing death or serious injury.

●

Use the correct wheel bolts for the wheels to be installed.
For details, contact your Lexus dealer.

■

Wheel bolts

Observe the following precautions to reduce the risk of death or serious injury:

●

Do not over tighten.

●

Never use oil or grease on the wheel bolts. Oil and grease may cause the wheel bolts
to be excessively tightened, leading to bolt or disc wheel damage. In addition, the oil

*1 :

Conventionally referred to as offset.

8-5. Tire maintenance

594

WARNING

or grease can cause the wheel bolts to loosen and the wheel may fall off, causing a
serious accident. Remove any oil or grease from the wheel bolts.

●

If there are any cracks or deformations in the wheel bolts, or if the surface treatment
becomes worn, have the wheel bolts replaced at your Lexus dealer. Failure to follow
these precautions could cause the wheel bolts to loosen and the tire to fall off, resulting
in death or serious injury.

■

Use of defective wheels prohibited

Do not use cracked or deformed wheels.
Doing so could cause the tire to leak air during driving, possibly causing an accident.

NOTICE

■

Replacing tire pressure warning valves and transmitters

●

Because tire repair or replacement may affect the tire pressure warning valves and
transmitters, make sure to have tires serviced by your Lexus dealer or other qualified
service shop. In addition, make sure to purchase your tire pressure warning valves and
transmitters at your Lexus dealer.

●

Ensure that only genuine Lexus wheels are used on your vehicle.
Tire pressure warning valves and transmitters may not work properly with non-genuine
wheels.

Aluminum wheel precautions

Observe the following precautions when handling the aluminum wheels.

●

Use only Lexus wheel bolts and wrenches designed for use with your aluminum
wheels.

●

When rotating, repairing or changing your tires, check that the wheel bolts are
still tight after driving 621 miles (1000 km).

●

Be careful not to damage the aluminum wheels when using tire chains.

●

Use only Lexus genuine balance weights or equivalent and a plastic or rubber
hammer when balancing your wheels.

8-5. Tire maintenance

595

Maintenance and car

Replacing the tire

When replacing the tires yourself, prepare the necessary tools and a jack.
This vehicle uses wheel bolts. When using wheels that were installed when the
vehicle was shipped from the factory, specialized Lexus genuine wheel bolts must
be used.
If necessary tire replacement seems difficult to perform, contact your Lexus dealer.

Preparation for lifting the vehicle with a jack

INFORMATION

■

Jack and tools

As your vehicle is equipped with run-flat tires or an emergency tire puncture repair kit,
the following tools for replacing a tire are not included with your vehicle. They can be
purchased at your Lexus dealer.

●

Jack

●

Jack handle

●

Wheel bolt socket

●

Guide pin

●

Wheel bolt wrench

Before lifting the vehicle with a jack, perform the following.

●

Stop the vehicle in a safe place on a hard, flat surface.

●

Set the parking brake.

●

Change the shift position to P.

●

Stop the hybrid system.

8-5. Tire maintenance

596

Storage position of the tools and jack

Jack

WARNING

Improper use of the tire jack may cause the vehicle to fall. Therefore, observe the
following precautions.

●

Do not use the tire jack for any purpose other than replacing tires or installing and
removing tire chains.

●

Only use the tire jack that comes with this vehicle for replacing a flat tire. Do not
use it on other vehicles, and do not use other tire jacks for replacing tires on this
vehicle.

Jack handle

Wheel bolt socket

Towing eyelet

Guide pin

Wheel bolt wrench

Screwdriver

* :

If equipped

8-5. Tire maintenance

597

Maintenance and car

Taking out the jack

Remove the deck board.

Take out the jack.

Disengage the tightening strap.

Removing a tire

WARNING

■

Precautions for replacing a tire

●

Do not try to remove the wheel ornament by hand.
Take due care in handling the ornament to avoid unexpected personal injury.

●

Do not touch the disc wheels or the area around the brakes immediately after the
vehicle has been driven.
After the vehicle has been driven the disc wheels and the area around the brakes
will be extremely hot. Touching these areas with hands, feet or other body parts while
changing a tire, etc., may result in burns.

■

Setting the power back door

when replacing the tires

When replacing a tire, make sure to disable the power back door. If not disabled, the
power back door may operate unintentionally, and hands or fingers may be caught and
injured.

* :

If equipped

8-5. Tire maintenance

598

Lexus NX350h (2024 year). Manual in english - page 18
