Lexus NX350h (2024 year). Manual in english

Chock the tires.

Wheel chock position

●

Flat tire: Front left
Place the wheel chock behind the rear right tire.

●

Flat tire: Front right
Place the wheel chock behind the rear left tire.

●

Flat tire: Rear left
Place the wheel chock in front of the front right tire.

●

Flat tire: Rear right
Place the wheel chock in front of the front left tire.

Using a wheel bolt wrench, slightly loosen the
wheel bolts (approximately one turn).

Turn the tire jack portion by hand until the
notch of the jack is in contact with the jack
point.

WARNING

Make sure the jack is positioned properly in the jack point.

8-5. Tire maintenance

599

Maintenance and car

Install the wheel bolt wrench to the jack han-
dle.

Raise the vehicle until the tire is slightly raised
off the ground.

WARNING

Observe the following precautions when using the jack.

●

Do not put any part of your body under the vehicle while it is supported by the
jack.

●

Do not start the hybrid system or drive the vehicle while the vehicle is supported
by the jack.

●

Do not raise the vehicle while someone is inside.

●

When raising the vehicle, do not put an object on or under the jack.

●

Do not raise the vehicle to a height greater than that required to replace the tire.

●

Use a jack stand if it is necessary to get under the vehicle.

Remove the uppermost wheel bolt and install
the guide pin by hand.

Turn the guide pin clockwise to tighten it until it
stops.

WARNING

When removing or installing a tire, make sure to use the guide pin.
Also, the guide pin is made of resin. It may be damaged if the wheel is placed
anywhere other than

or if a large amount of force is applied to the guide pin.

8-5. Tire maintenance

600

WARNING

Remove the remaining wheel bolts and the
tire.

When resting the tire on the ground, place the
tire so that the wheel design faces up, to avoid
scratching the wheel surface.

Installing the tire

Remove any dirt or foreign matter from the
wheel contact surfaces and wheel bolts.

If foreign matter is not removed, the wheel bolts
may loosen while the vehicle is in motion, and the
wheel may come off.

Align a wheel bolt hole on the spare tire with
the guide pin, and set the spare tire on the
guide pin.

Align the center hole of the wheel with the center
of the hub and securely set the spare tire so that
the wheel and hub contact surfaces are touching.

WARNING

When removing or installing a tire, make sure to use the guide pin.
Also, the guide pin is made of resin. It may be damaged if the wheel is placed
anywhere other than

or if a large amount of force is applied to the guide pin.

8-5. Tire maintenance

601

Maintenance and car

WARNING

Loosely tighten each wheel bolt by hand or
using a wheel bolt socket .

Do not use the wheel bolt socket for anything
other than loosely tightening the wheel bolts by
hand.

WARNING

Observe the following precautions. Failure to do so may lead to the wheel bolts
loosening and the tire falling off.

●

The contact surfaces of the wheel bolt and wheel are designed specifically to fit
together. When using wheels that were installed when the vehicle was shipped
from the factory, use specialized Lexus genuine wheel bolts. Do not use wheel
bolts designed for other models, model years or types even if they are Lexus
genuine parts.
If the vehicle does not have wheels that were installed to the vehicle when it was
shipped from the factory, the factory-installed wheel bolts may not be appropriate
for the wheel. Contact either the retailer where the wheels were purchased or the
manufacturer of the wheels for proper installation advice.

●

Never apply oil or grease to the wheel bolts or their contact surface on the wheel

Doing so may cause the wheel bolts to be tightened excessively, leading to
damage to the wheel bolts, the threaded portion the wheel bolts install to

, or

the wheel.
Remove any oil or grease that has adhered when installing the wheel bolts.

8-5. Tire maintenance

602

WARNING

●

If a wheel bolt hole in a wheel or the threads of a wheel bolt or the wheel hub are
deformed, cracked, rusty or otherwise damaged, have the vehicle inspected by
your Lexus dealer.

●

Do not install the wheel ornament if it is damaged, as it may fly off the wheel while
the vehicle is being driven.

Remove the guide pin and loosely tighten the
wheel bolt as in step

Lower the vehicle.

WARNING

When lowering the vehicle, make sure that no one is near the vehicle. If there are
people nearby, warn them vocally before lowering the vehicle.

8-5. Tire maintenance

603

Maintenance and car

Securely tighten the wheel bolts two or three
times in the order shown in the illustration
using a wheel bolt wrench.

Tightening torque: 103 ft•lbf (140 N•m, 14.3
kgf•m)

WARNING

When tightening the wheel bolts, do not tighten them excessively. Doing so may
cause the wheel bolts, the threads of the wheel hub, or the wheel to be damaged.

Stow the jack and all tools.

WARNING

●

After using the tools and jack, before driving, make sure that the tools and jack are
securely stored. Failure to do so may result in injury during a collision or sudden
braking.

●

After replacing a tire, check the tightening torque as soon as possible.
If you cannot confirm the tightening torque yourself, have the vehicle inspected at
your Lexus dealer.

NOTICE

When removing or fitting the wheels, tires or the tire pressure warning valves and
transmitters, contact your Lexus dealer as the tire pressure warning valves and
transmitters may be damaged if not handled correctly.

8-5. Tire maintenance

604

Headlight aim

Vertical movement adjusting bolts

▶

Type A

Adjustment bolt A

Adjustment bolt B

▶

Type B

Adjustment bolt A

Adjustment bolt B

Checking the headlight aim

Before checking the headlight aim, confirm the following.

●

The vehicle has a full tank of gasoline and the area around the headlight is not
deformed.

●

The vehicle is parked on level ground.

●

The tire inflation pressure is at the specified level.

●

Someone is sitting in the driver's seat.

●

The vehicle has been bounced several times after being parked.

8-5. Tire maintenance

605

Maintenance and car

Adjusting the headlight aim

Using a Phillips-head screwdriver, turn bolt A
in either direction. Remember the turning di-
rection and the number of turns.

Turn bolt B the same number of turns and in
the same direction as step 1.

If the headlight cannot be adjusted using this pro-
cedure, take the vehicle to your Lexus dealer to
adjust the headlight aim.

▶

Type A

▶

Type B

▶

Type A

▶

Type B

8-5. Tire maintenance

606

When trouble arises

9-1. What to do if a problem occurs

while driving

What to do if a problem oc-

curs while driving.................

609

9-2. If a warning is indicated on the

meter

If a warning light turns on/

flashes.........................................

612

If a warning message is dis-

played........................................

625

9-3. If the hybrid system will not start

When the hybrid system

cannot be started even
though the correct start-
ing procedure is being fol-
lowed .........................................

644

When the interior lights or

headlights are dim and the
hybrid system cannot be
started .......................................

647

When the interior lights or

headlights do not illumi-
nate and the hybrid system
cannot be started .................

653

When the horn sounds at a

low volume and the hybrid
system cannot be started ..

654

When the horn does not

sound and the hybrid sys-
tem cannot be started ........

655

9-4. If a tire is flat

Repairing a tire with the

emergency tire puncture
repair kit (vehicles with an

emergency tire puncture
repair kit)..................................

656

Precautions for when you

have a flat tire (vehicles
with run-flat tires)..................

678

9-5. If a door cannot be opened or

locked

If a key has been lost...............

679

When the doors/windows/

moon roof cannot be op-
erated using an electronic
key..............................................

680

If a door cannot be opened

using the door opener
switch........................................

689

If the rear doors cannot be

opened from the inside ......

692

If the back door cannot be

opened......................................

693

9-6. If the moon roof/sunshade mal-

functions

If the moon roof does not

operate correctly..................

695

If the panoramic moon roof/

electronic sunshade does
not operate correctly..........

696

9-7. If the rear seats does not oper-

ate correctly

Initialize rear seats (Vehi-

cles with power seat) ..........

697

9-8. If refueling cannot be per-

formed

If the fuel filler door cannot

be opened ..............................

698

607

When tr

ouble arises

What to do if a problem occurs while driving

Using the emergency flashers to warn other drivers

Use the emergency flashers to inform other drivers of the presence of your vehicle
when it is stopped on the road, such as if the vehicle has broke down.
Press the switch.

All the turn signal lights will flash. To turn them off,
press the switch once again.

INFORMATION

■

Emergency flashers

●

If the emergency flashers are used for a long time with the hybrid system stopped
(while the "READY" indicator is not illuminated), the 12-volt battery may become
discharged.

●

If any of the SRS airbags deploy (inflate) or in the event of a strong rear impact, the
emergency flashers will turn on automatically.
The emergency flashers will turn off automatically after operating for approximately
20 minutes. To manually turn the emergency flashers off, press the switch twice. (The
emergency flashers may not turn on automatically depending on the force of the
impact and conditions of the collision.)

Stopping the vehicle in an emergency

Stop the vehicle using the following procedure only in an emergency, such as if it
becomes impossible to stop the vehicle in the normal way:

WARNING

■

If the hybrid system has to be stopped while driving

Power assist for the steering wheel will be lost, making the steering wheel heavier to turn.
Decelerate as much as possible before stopping the hybrid system.

Steadily step on the brake pedal with both feet and firmly depress it.

Do not pump the brake pedal repeatedly as this will increase the effort required to slow
the vehicle.

9-1. What to do if a problem occurs while driving

609

When tr

ouble arises

Change the shift position to N.

●

If the shift position is changed to N:
After slowing down, stop the vehicle in a safe place by the road.
Stop the hybrid system.

●

If the shift position cannot be changed to N:
Keep depressing the brake pedal with both feet to reduce vehicle speed as much as
possible.
To stop the hybrid system, press and hold the power switch for 2 consecutive sec-
onds or more, or press it briefly 3 times or more in succession.

Stop the vehicle in a safe place by the road.

WARNING

To restart the hybrid system after performing an emergency shutdown, change the
shift position to N and then press the power switch.

If the vehicle is submerged or water on the road is rising

This vehicle is not designed to be able to drive on roads that are deeply flooded
with water. Do not drive on roads where the roads may be submerged or the water
may be rising. It is dangerous to remain in the vehicle, if it is anticipated that the
vehicle will be flooded or set adrift.
Remain calm and follow the following.

●

If the door can be opened, open the door and exit the vehicle.

●

If the door cannot be opened, open the window using the power window switch
and ensure an escape route.

●

If the window can be opened, exit the vehicle through the window.

●

If the door and window cannot be opened due to the rising water, remain calm,
wait until the water level inside the vehicle rises to the point that the water
pressure inside of the vehicle equals the water pressure outside of the vehicle
and then open the door after waiting for the rising water to enter the vehicle, and
exit the vehicle.

9-1. What to do if a problem occurs while driving

610

When the outside water level exceeds half the height of the door, the door cannot be
opened from the inside due to water pressure.

INFORMATION

■

Water level exceeds the floor

When the water level exceeds the floor and time has passed, the electrical equipment will
get damaged, the power windows will not operate, the engine and motor stop, and the
vehicle may not be able to get moving.

■

Using an emergency escape hammer

Laminated glass

is used in the windshield and the windows on this vehicle. Laminated

glass cannot be shattered with an emergency hammer

■

How to distinguish laminated glass

When looking from the cross-sectional view point, laminated glass is two sheets of glass
pasted together.

Laminated glass

Tempered glass

WARNING

■

Caution while driving

Do not drive on roads where the roads may be submerged or the water may be rising.
Otherwise the vehicle may be damaged and cannot move, as well as become flooded
and set adrift, which may lead to death.

Operation of emergency shut off system

When a certain level of impact is detected by an impact sensor, the emergency
shut off system blocks the high voltage current and stops the fuel pump to mini-
mize the risk of electrocution and fuel leakage. If the emergency shut off system
activates, your vehicle will not be able to be restarted. To restart the hybrid system,
contact your Lexus dealer.

* :

If equipped

*1 :

Contact your Lexus dealer or aftermarket accessory manufacturer for further infor-

mation about an emergency hammer.

9-1. What to do if a problem occurs while driving

611

When tr

ouble arises

If a warning is indicated on the meter

If a warning light turns on/flashes

Calmly perform the following actions if any of the warning lights comes on or
flashes. If a light comes on or flashes, but then goes off, this does not necessarily
indicate a malfunction in the system. However, if this continues to occur, have the
vehicle inspected by your Lexus dealer.

INFORMATION

■

Warning buzzer

In some cases, the buzzer may not be heard due to being in a noisy location or audio
sound.

Brake system warning light (warning buzzer)

Condition

Cause / Remedy

(U.S.A.) or

(red) (Canada)

Indicates that:

●

The brake fluid level is low; or

●

The brake system is malfunctioning

Immediately stop the vehicle and contact your Lexus dealer. Con-
tinuing to drive the vehicle may be dangerous.

WARNING

If both the ABS and the brake system warning lights remain on, stop your vehicle in a safe
place immediately and contact your Lexus dealer.
The vehicle will become extremely unstable during braking, and the ABS system may fail,
which could cause an accident resulting in death or serious injury.

Brake system warning light (warning buzzer)

Condition

Cause / Remedy

(yellow)

Indicates a malfunction in:

●

The regenerative braking system;

●

The electronically controlled brake system; or

●

The parking brake

Have the vehicle checked by your Lexus dealer immediately.

9-2. If a warning is indicated on the meter

612

WARNING

High coolant temperature warning light (warning buzzer)

Condition

Cause / Remedy

This light illuminates on the

multi-information display.

Indicates that the engine coolant temperature is too
high
Immediately stop the vehicle in a safe take the cor-
rective actions for overheating.

Related Links

If your vehicle overheats(P. 715)

Hybrid system overheat warning light (warning buzzer)

Condition

Cause / Remedy

This light illuminates on the

multi-information display.

Indicates the hybrid system has overheated
Stop the vehicle in a safe place and perform the
necessary actions.

Related Links

If your vehicle overheats(P. 715)

Charging system warning light (warning buzzer)

Condition

Cause / Remedy

This light illuminates on the

multi-information display.

Indicates a malfunction in the vehicle’s charging
system
Immediately stop the vehicle in a safe place and
contact your Lexus dealer.

9-2. If a warning is indicated on the meter

613

When tr

ouble arises

Low engine oil pressure warning light (warning buzzer)

Condition

Cause / Remedy

This light illuminates on the

multi-information display.

Indicates that the engine oil pressure is too low
Immediately stop the vehicle in a safe place and
contact your Lexus dealer.

Malfunction indicator lamp

Condition

Cause / Remedy

(U.S.A.) or

(Canada)

Indicates a malfunction in:

●

The hybrid system;

●

The electronic engine control system;

●

The electronic throttle control system; or

Immediately stop the vehicle in a safe place and contact your Lexus
dealer.

INFORMATION

■

If the malfunction indicator lamp comes on while driving

First check the following:

●

Is the fuel tank empty?
If it is, fill the fuel tank immediately.

●

Is the fuel tank cap loose?
If it is, tighten it securely.

The light will go off after several driving trips.
If the light does not go off even after several trips, contact your Lexus dealer as soon as
possible.

SRS warning light

Warning light

Details / Actions

●

The SRS airbag system is malfunctioning

●

The seat belt pretensioner system is malfunctioning

Have the vehicle checked by your Lexus dealer immediately.

9-2. If a warning is indicated on the meter

614

SRS warning light

This warning light indicates problems with the following:

●

Airbag sensor assembly

●

Front impact sensors

●

Side impact sensors (front door)

●

Side impact sensors (front)

●

Front passenger occupant classification sensors

●

Driver’s seat position sensor

●

Driver’s seat belt buckle switch

●

Front passenger’s seat belt buckle switch

●

"AIR BAG ON" indicator light

●

"AIR BAG OFF" indicator light

●

Seat belt pretensioners

●

Air bags

●

Interconnecting wiring and power sources.

Related Links

SRS airbags(P. 508)

ABS warning light (warning buzzer)

Condition

Cause / Remedy

(U.S.A.) or

(Canada)

Indicates a malfunction in:

●

The ABS; or

●

The brake assist system

Have the vehicle checked by your Lexus dealer immediately.

WARNING

9-2. If a warning is indicated on the meter

615

When tr

ouble arises

Inappropriate pedal operation warning light (warning buzzer)

Condition

Cause / Remedy

This light illuminates

on the multi-information

display.

When a buzzer sounds:
Indicates a malfunction in:

●

The Brake Override System

●

The Drive-Start Control

Have the vehicle checked by your Lexus dealer imme-
diately.

When a buzzer sounds:
Indicates that the shift position was changed and
Drive-Start Control was operated while depressing
the accelerator pedal.
Momentarily release the accelerator pedal.

When a buzzer sounds:
PKSB (Parking Support Brake)

has operated

Follow the instructions displayed on the multi-informa-
tion display.

When a buzzer does not sound:
Indicates that the accelerator and brake pedals are be-
ing depressed simultaneously, and the Brake Override
System is operating.
Release the accelerator pedal and depress the brake
pedal.

Electric power steering system warning light (warning buzzer)

Condition

Cause / Remedy

(red/yellow)

Indicates a malfunction in the EPS (Electric Power Steering) system
Have the vehicle checked by your Lexus dealer immediately.

* :

If equipped

9-2. If a warning is indicated on the meter

616

INFORMATION

■

Electric power steering system warning light (warning buzzer)

When the 12-volt battery charge becomes insufficient or the voltage temporarily drops,
the electric power steering system warning light may come on and the warning buzzer
may sound.

WARNING

When the electric power steering system warning light comes on yellow, the assist to
the power steering is restricted. When the light comes on red, the assist to the power
steering is lost and handling operations of the steering wheel become extremely heavy.
When steering wheel operations are heavier than usual, grip the steering wheel firmly
and operate it using more force than usual.

Low fuel level warning light

Condition

Cause / Remedy

Indicates that remaining fuel is approximately 2.3 gal. (8.5 L, 1.9 Imp.
gal.) or less
Refuel the vehicle.

Driver’s and front passenger’s seat belt reminder light (warning buzzer)

Condition

Cause / Remedy

Warns the driver and/or front passenger to fasten their seat belts
Fasten the seat belt.
If the front passenger’s seat is occupied, the front passenger’s seat
belt also needs to be fastened to make the warning light (warning
buzzer) turn off.

INFORMATION

■

Driver’s and front passenger’s seat belt warning buzzer

●

Driver’s seat belt warning buzzer:
The driver’s seat belt warning buzzer sounds to alert the driver that his or her seat
belt is not fastened. Once the power switch is turned to ON, the buzzer sounds. If the
seat belt is still unfastened, the buzzer sounds intermittently for a certain period of time
after the vehicle reaches a certain speed.

●

Front passenger’s seat belt warning buzzer:

9-2. If a warning is indicated on the meter

617

When tr

ouble arises

The front passenger’s seat belt warning buzzer sounds to alert the front passenger that
his or her seat belt is not fastened. If the seat belt is unfastened, the buzzer sounds
intermittently for a certain period of time after the vehicle reaches a certain speed.

■

Front passenger detection sensor, seat belt reminder and warning buzzer

●

If luggage is placed on the front passenger seat, the front passenger detection sensor
may cause the warning light to flash and the warning buzzer to sound even if a
passenger is not sitting in the seat.

●

If a cushion is placed on the seat, the sensor may not detect a passenger, and the
warning light may not operate properly.

Rear passengers’ seat belt reminder light (warning buzzer)

Condition

Cause / Remedy

(Vehicles without a head-up display)

(Vehicles with a head-up display)

Warns the rear passengers to fasten their
seat belts
Fasten the seat belt.

INFORMATION

■

Rear passengers’ seat belt warning buzzer

The rear passengers’ seat belt warning buzzer sounds to alert the rear passenger that
his or her seat belt is not fastened. If the seat belt is unfastened, the buzzer sounds
intermittently for a certain period of time, after the seat belt is fastened and unfastened
and the vehicle reaches a certain speed.

Tire pressure warning light (warning buzzer)

Condition

Cause / Remedy

When the light comes on after blinking for approximately 1 minute (a
buzzer does not sounds):
Malfunction in the tire pressure warning system
Have the system checked by your Lexus dealer.

9-2. If a warning is indicated on the meter

618

Condition

Cause / Remedy

When the light comes on (a buzzer sounds):
Low tire inflation pressure from natural causes
After the temperature of the tires has lowered sufficiently, check the
inflation pressure of each tire and adjust them to the specified level.

When the light comes on (a buzzer sounds):
Low tire inflation pressure from flat tire
Immediately stop the vehicle in a safe place and perform the necessa-
ry actions

INFORMATION

■

If the tire pressure warning light comes on

Inspect the tires to check if a tire is punctured.

●

If a tire is punctured:

→

P.656

●

If none of the tires are punctured: Turn the power switch off then turn it to ON. Check
if the tire pressure warning light comes on or blinks.

•

If the tire pressure warning light blinks for approximately 1 minute then stays on
There may be a malfunction in the tire pressure warning system. Have the vehicle
inspected by your Lexus dealer immediately.

•

If the tire pressure warning light comes on
After the temperature of the tires has lowered sufficiently, check the inflation
pressure of each tire and adjust them to the specified level.
If the warning light does not turn off even after several minutes have elapsed, check
that the inflation pressure of each tire is at the specified level and perform the tire
inflation pressure setting procedure.
If the warning light does not turn off even after several minutes have elapsed since
performing the tire inflation pressure setting procedure, have the vehicle inspected
by your Lexus dealer immediately.

■

The tire pressure warning light may come on due to natural causes

The tire pressure warning light may come on due to natural causes such as natural air
leaks and tire inflation pressure changes caused by temperature. In this case, adjusting
the tire inflation pressure will turn off the warning light (after a few minutes).

9-2. If a warning is indicated on the meter

619

When tr

ouble arises

WARNING

■

If the tire pressure warning light comes on

Be sure to observe the following precautions. Failure to do so could cause a loss of
vehicle control and result in death or serious injury.

●

Vehicles with run-flat tires:
Decelerate to the lowest appropriate speed as soon as possible. Do not drive over 50
mph (80 km/h).

●

Stop your vehicle in a safe place as soon as possible. Adjust the tire inflation pressure
immediately.

●

If the tire pressure warning light comes on even after tire inflation pressure adjustment,
it is probable that you have a flat tire. Have the flat tire replaced by the nearest Lexus
dealer.

●

Avoid abrupt maneuvering and braking. If the vehicle tires deteriorate, you could lose
control of the steering wheel or the brakes.

■

If a blowout or sudden air leakage should occur

The tire pressure warning system may not activate immediately.

■

Maintenance of the tires

Each tire, including the spare (if provided), should be checked monthly when cold and
inflated to the inflation pressure recommended by the vehicle manufacturer on the
vehicle placard or tire inflation pressure label (tire and load information label). (If your
vehicle has tires of a different size than the size indicated on the vehicle placard or tire
inflation pressure label [tire and load information label], you should determine the proper
tire inflation pressure for those tires.)
As an added safety feature, your vehicle has been equipped with a tire pressure moni-
toring system (TPMS-tire pressure warning system) that illuminates a low tire pressure
telltale (tire pressure warning light) when one or more of your tires is significantly
under-inflated. Accordingly, when the low tire pressure telltale (tire pressure warning
light) illuminates, you should stop and check your tires as soon as possible, and inflate
them to the proper pressure. Driving on a significantly under-inflated tire causes the tire
to overheat and can lead to tire failure. Under-inflation also reduces fuel efficiency and
tire tread life, and may affect the vehicle’s handling and stopping ability.
Please note that the TPMS (tire pressure warning system) is not a substitute for proper
tire maintenance, and it is the driver’s responsibility to maintain correct tire pressure, even
if under-inflation has not reached the level to trigger illumination of the TPMS low tire
pressure telltale (tire pressure warning light).
Your vehicle has also been equipped with a TPMS (tire pressure warning system) mal-
function indicator to indicate when the system is not operating properly. The TPMS (tire
pressure warning system) malfunction indicator is combined with the low tire pressure
telltale (tire pressure warning light). When the system detects a malfunction, the telltale

9-2. If a warning is indicated on the meter

620

WARNING

will flash for approximately one minute and then remain continuously illuminated. This
sequence will continue upon subsequent vehicle start-ups as long as the malfunction
exists. When the malfunction indicator is illuminated, the system may not be able to
detect or signal low tire pressure as intended.
TPMS (tire pressure warning system) malfunctions may occur for a variety of reasons,
including the installation of replacement or alternate tires or wheels on the vehicle that
prevent the TPMS (tire pressure warning system) from functioning properly. Always
check the TPMS (tire pressure warning system) malfunction telltale after replacing one or
more tires or wheels on your vehicle to ensure that the replacement or alternate tires and
wheels allow the TPMS (tire pressure warning system) to continue to function properly.

NOTICE

■

To ensure the tire pressure warning system operates properly

Do not install tires with different specifications or makers, as the tire pressure warning
system may not operate properly.

Intuitive parking assist OFF indicator (warning buzzer)

Condition

Cause / Remedy

Indicates a malfunction in the intuitive parking assist function
Have the vehicle checked by your Lexus dealer immediately.

Indicates that the system is temporarily unavailable, possibly due to a
sensor being dirty or covered with ice, etc.
Follow the instructions displayed on the multi-information display.

PCS warning light (warning buzzer)

Condition

Cause / Remedy

Indicates a malfunction in the PCS (Pre-Collision System).
Follow the instructions displayed on the display.

●

If the PCS (Pre-Collision System) or VSC (Vehicle Stability Con-
trol) system is disabled, the PCS warning light will illuminate.

9-2. If a warning is indicated on the meter

621

When tr

ouble arises

LTA indicator (warning buzzer)

Condition

Cause / Remedy

(Yellow)

Indicates a malfunction in the LTA (Lane Tracing Assist).

●

Follow the instructions displayed on the display.

LDA indicator (warning buzzer)

Condition

Cause / Remedy

(Yellow)

Indicates a malfunction in the LDA (Lane Departure Alert).

●

Follow the instructions displayed on the display.

Dynamic radar cruise control indicator (warning buzzer)

Condition

Cause / Remedy

(Yellow)

Indicates a malfunction in the dynamic radar cruise control system.

●

Follow the instructions displayed on the display.

Cruise control indicator (warning buzzer)

Condition

Cause / Remedy

(Yellow)

Indicates a malfunction in the cruise control system.

●

Follow the instructions displayed on the display.

PDA indicator (warning buzzer)

Condition

Cause / Remedy

(Yellow)

Indicates a malfunction in the PDA (Proactive Driving Assist)
Follow the instructions displayed on the display.

9-2. If a warning is indicated on the meter

622

Driving assist information indicator

Condition

Cause / Remedy

Indicates one of the following systems is malfunctioning.

●

PCS (Pre-Collision System)

●

LDA (Lane Departure Alert)

●

Follow the instructions displayed on the display.

Indicates one of the following systems is malfunctioning or disabled.

●

PKSB (Parking Support Brake)

●

RCD (Rear Camera Detection)

●

BSM (Blind Spot Monitor)

●

RCTA(Rear Cross Traffic Alert)

●

Safe Exit Assist

●

Follow the instructions displayed on the display.

Slip indicator

Condition

Cause / Remedy

(illuminates)

Indicates a malfunction in:

●

The VSC system;

●

The Trailer Sway Control system;

●

The TRAC system;

●

The Trail Mode function; or

●

The hill-start assist control system

Have the vehicle checked by your Lexus dealer immediately.

* :

If equipped

9-2. If a warning is indicated on the meter

623

When tr

ouble arises

Parking brake indicator

Condition

Cause / Remedy

(U.S.A.) (flashes)

(Canada) (flashes)

It is possible that the parking brake is not fully engaged or
released
Operate the parking brake switch once again.
This light comes on when the parking brake is not released. If
the light turns off after the parking brake is fully released, the
system is operating normally.

Indicates a malfunction in the parking brake system
Have the vehicle checked by your Lexus dealer immediately.

Brake hold operated indicator (warning buzzer)

Condition

Cause / Remedy

(flashes)

Indicates a malfunction in the brake hold system
Have the vehicle checked by your Lexus dealer immediately.

9-2. If a warning is indicated on the meter

624

If a warning message is displayed

The multi-information display shows warnings for system malfunctions and incor-
rectly performed operations, and messages that indicate a need for maintenance.
When a message is displayed, perform the appropriate corrective action for the
message.
If a warning message is displayed again after the appropriate actions have been
performed, contact your Lexus dealer.
Additionally, if a warning light comes on or flashes at the same time that a warning
message is displayed, take the appropriate corrective action for the warning light.

INFORMATION

■

Warning messages

The warning messages explained below may differ from the actual messages according
to operation conditions and vehicle specifications.

■

Warning buzzer

In some cases, the buzzer may not be heard due to being in a noisy location or audio
sound.

"Engine Oil Level Low Add or Replace"

Cause

Remedy

The engine oil
level may be
low.

Check the level of the engine oil, and add engine oil if necessa-
ry.
This message may be displayed if the vehicle is stopped on
a slope. Move the vehicle to a level surface and check if the
message disappears.

"Hybrid System Stopped Steering Power Low"

Cause

Remedy

This message is displayed if the
hybrid system is stopped while
driving.

When steering wheel operations are heavier
than usual, grip the steering wheel firmly and
operate it using more force than usual.

9-2. If a warning is indicated on the meter

625

When tr

ouble arises

"Auto Power OFF to Conserve Battery"

Cause

Remedy

Power was turned off due
to the automatic power off
function.

Next time when starting the hybrid system, operate
the hybrid system for approximately 5 minutes to
recharge the 12-volt battery.

Related Links

Changing the power switch mode(P. 142)

"Shift is in N Release Accelerator Before Shifting"

Cause

Remedy

The accelerator pedal has been de-
pressed when the shift position is in N.

Release the accelerator pedal and
change the shift position to D or R.

"Press brake when vehicle is stopped Hybrid system may overheat"

Cause

Remedy

The message may be displayed when the ac-
celerator pedal is depressed to hold the vehi-
cle while the vehicle is stopped on an incline,
etc.

The hybrid system may over-
heat. Release the accelerator
pedal and depress the brake
pedal.

"12-Volt Battery Charging System Malfunction Stop in a Safe Place See
Owner's Manual"

Cause

Remedy

It may indicate a mal-
function.

Immediately stop the vehicle and contact your Lexus
dealer. Continuing to drive the vehicle may be danger-
ous.

"Traction battery needs to be protected. Shift into P to restart."

Cause

Remedy

This message is displayed when the hybrid battery
(traction battery) charge has become extremely low
because the vehicle has been left with the N shift
position selected for a certain amount of time.

When operating the ve-
hicle, shift to P and restart
the hybrid system.

9-2. If a warning is indicated on the meter

626

"Traction battery needs to be protected. Refrain from the use of N
position."

Cause

Remedy

This message may be dis-
played when the shift po-
sition is in N.

As the hybrid battery (traction battery) cannot be
charged when the shift position is in N, shift the shift
position to P when the vehicle is stopped.

"Hybrid System Overheated Output Power Reduced"

Cause

Remedy

This message may be
displayed when driving
under severe operating
conditions. (For exam-
ple, when driving up a
long steep hill.)

Stop the vehicle in a safe place.

Stop the hybrid system and carefully lift the hood.

After the hybrid system has cooled down, inspect
the hoses and radiator core (radiator) for any leaks.

If a large amount of coolant has leaked, immediately
contact your Lexus dealer.

Radiator

Cooling fan

Check that the coolant level is between the [FULL]
and [LOW] lines on the reservoir.

Reservoir

[FULL] line

[LOW] line

Add coolant if necessary.

Water can be used in an emer-
gency if coolant is unavailable.

After stopping the hybrid system and waiting for 5
minutes or more, start the hybrid system again and
check for the multi-information display.

9-2. If a warning is indicated on the meter

627

When tr

ouble arises

Cause

Remedy

This message may be
displayed when driving
under severe operating
conditions. (For exam-
ple, when driving up a
long steep hill.)

If the message does not disappear: Stop the hybrid sys-
tem and contact your Lexus dealer.
If the message is not displayed: The hybrid system tem-
perature has dropped and the vehicle may be driven
normally.
However, if the message appears again frequently, con-
tact your Lexus dealer.

WARNING

When opening the hood, observe the following precautions.

●

If steam is seen coming from under the hood, do not open the hood until the steam has
subsided. The engine compartment may be very hot.

●

After turning the hybrid system off, check that the "READY" indicator is off.
When the hybrid system is operating, the gasoline engine may automatically start, or
the cooling fan may suddenly operate even if the gasoline engine is stopped.
Also, it may operate for several minutes even after the power switch is turned off.
Do not touch or approach rotating parts such as the fan, which may lead to fingers or
clothing (especially a tie, a scarf or a muffler) getting caught, resulting in serious injury.

●

Do not loosen the coolant reservoir cap while the hybrid system and radiator are hot.
High temperature steam or coolant could spray out.

NOTICE

■

When adding engine/power control unit coolant

Add coolant slowly after the hybrid system has cooled down sufficiently.
Adding cool coolant to a hot hybrid system too quickly can cause damage to the hybrid
system.

■

To prevent damage to the cooling system

Observe the following precautions:

●

Avoid contaminating the coolant with foreign matter (such as sand, dust, etc.).

●

Do not use coolant additives.

9-2. If a warning is indicated on the meter

628

"Tire Set Switching Incomplete Try Tire Set Registration Again See
Owner's Manual"

Cause

Remedy

The wheel set change
could not be completed.

Check which wheel set is installed and perform the
change procedure again from the beginning.

Related Links

Selecting wheel set(P. 588)

"Maintenance Required For Traction Battery At Your Dealer"

Cause

Remedy

The hybrid battery
(traction battery) is
scheduled to be in-
spected or replaced.

Have the vehicle inspected by your Lexus dealer immedi-
ately.

●

Continuing to drive the vehicle without having the hy-
brid battery (traction battery) inspected will cause the
hybrid system not to start.

●

If the hybrid system does not start, contact your Lexus
dealer immediately.

"Headlight System Malfunction Visit Your Dealer"

Cause

Remedy

The system may be malfunction-
ing.

Have the vehicle checked by your Lexus
dealer.

"AWD System Overheated Switching to 2WD Mode"

Cause

Remedy

AWD system
is overheated.

●

Stop the vehicle in a safe place with the hybrid system operat-
ing.

If the message disappears after a while, there is no problem. If the
message remains, have the vehicle inspected by your Lexus dealer
immediately.

*1 :

When stopping the vehicle, do not stop the hybrid system until the display message

has turned off.

9-2. If a warning is indicated on the meter

629

When tr

ouble arises

"AWD System Overheated 2WD Mode Engaged"

Cause

Remedy

AWD system has been
temporarily released
and switched to front-
wheel drive due to over-
heating.

●

Stop the vehicle in a safe place with the hybrid
system operating.

If the message disappears after a while, AWD system will
automatically recover. If the message remains, have the
vehicle inspected by your Lexus dealer immediately.

"AWD System Malfunction 2WD Mode Engaged Visit Your Dealer"

Cause

Remedy

A malfunction occurs in the
AWD system.

●

Have the vehicle inspected by your Lexus
dealer immediately.

"Engine Coolant Temp High Stop in a Safe Place See Owner's Manual"

Remedy

Take the corrective actions for overheating.

Related Links

If your vehicle overheats(P. 715)

"Access System with Elec.Key malfunction See owner's manual"

Cause

Remedy

It may indicate a malfunction.

Have the vehicle checked by your Lexus dealer
immediately.

"Braking Power Low Stop in a Safe Place See Owner's Manual"

Cause

Remedy

It may indicate a mal-
function.

Immediately stop the vehicle and contact your Lexus
dealer. Continuing to drive the vehicle may be danger-
ous.

*2 :

When stopping the vehicle, do not stop the hybrid system until the display message

has turned off.

9-2. If a warning is indicated on the meter

630

Lexus NX350h (2024 year). Manual in english - page 19
