Lexus NX350h (2024 year). Manual in english

▶

Rear seats

Pull the head restraint up while pressing the
lock release button .

Installing the head restraints

▶

Front seats

Align the head restraint with the installation
holes and push it down to the lock position.
Press and hold the lock release button when
lowering the head restraint.

▶

Rear seats

Align the head restraint with the installation
holes and push it down to the lock position.
Press and hold the lock release button when
lowering the head restraint.

1-7. Obtaining the correct driving posture

119

Befor

e driving

Adjusting the rear seats

Reclining adjustments and folding the seat backs can be done with the levers.

Reclining adjustment

WARNING

Observe the following when adjusting the seatbacks.

●

Keep other passengers from being hit with the seatback.

●

Do not bring your hands close to the moving parts or between the seats, as well as do
not let any part of your body get caught.

●

Vehicles with power seat: Do not let children operate the seatback as other passen-
gers may get caught in seat.

●

Vehicles with power seat: Check that there are no passengers sitting in the seat before
folding that seat forward. Also, do let other passengers sit in the seat while the seat is
forward folding.

●

To reduce the risk of sliding under the lap belt during a collision, do not recline the seat
more than necessary.
If the seat is reclined excessively, in a collision, one may slide under the lap belt and it
may apply restraint forces directly to the abdomen, etc., or their neck may contact the
shoulder belt.

1-7. Obtaining the correct driving posture

120

Using the seat belts

●

Extend the shoulder belt so that it comes fully over the shoulder, but does not
come into contact with the neck or slide off the shoulder.

●

Position the lap belt as low as possible over the hips.

●

Adjust the position of the seatback. Sit up straight and well back in the seat.

●

Do not twist the seat belt.

WARNING

Observe the following precautions to reduce the risk of injury in the event of sudden
braking, sudden swerving or an accident. Failing to do so may cause death or serious
injury.

●

Ensure that all passengers wear a seat belt.

●

Always wear a seat belt properly.

●

Each seat belt should be used by one person only.
Do not use a seat belt for more than one person at once, including children.

●

Lexus recommends that children be seated in the rear seat and always use a seat belt
and/or an appropriate child restraint system.

●

To achieve a proper seating position, do not recline the seat more than necessary. The
seat belt is most effective when the occupants are sitting up straight and well back in
the seats.

●

Do not wear the shoulder belt under your arm.

●

Always wear your seat belt low and snug across your hips.

1-7. Obtaining the correct driving posture

121

Befor

e driving

WARNING

●

Women who are pregnant should consult their
doctor for any precautions for wearing the seat
belt correctly.
Position the lap belt as low as possible over the
hips in the same manner as other occupants, ex-
tending the shoulder belt completely over the
shoulder and avoiding belt contact with the round-
ing of the abdominal area.
If the seat belt is not worn properly, not only the
pregnant woman, but also the fetus could suffer
death or serious injury as a result of sudden brak-
ing or a collision.

●

Persons with a medical condition should consult their doctor for any precautions for
wearing the seat belt correctly.

●

Inspect the seat belt system periodically. Check for cuts, fraying, and loose parts. Do
not use a damaged seat belt until it is replaced. Damaged seat belts cannot protect an
occupant from death or serious injury.

●

Replace the seat assembly, including the belts, if your vehicle has been involved in a
serious accident, even if there’s no obvious damage.

●

Do not attempt to install, remove, modify, disassemble or dispose of the seat belts.
Have any necessary repairs carried out by your Lexus dealer. Inappropriate handling
may lead to incorrect operation.

●

Do not allow children to play with the seat belt.
If the seat belt becomes twisted around a child's neck, it may lead to choking or other
serious injuries that could result in death.
If this occurs and the buckle cannot be unfastened, scissors should be used to cut the
belt.

INFORMATION

■

Child seat belt usage

The seat belts of your vehicle were principally designed for persons of adult size.

●

Use a child restraint system appropriate for the child, until the child becomes large
enough to properly wear the vehicle’s seat belt.

●

When the child becomes large enough to properly wear the vehicle’s seat belt, follow
the instructions regarding seat belt usage.

1-7. Obtaining the correct driving posture

122

■

Seat belt extender

If your seat belts cannot be fastened securely be-
cause they are not long enough, a personalized seat
belt extender is available from your Lexus dealer free
of charge.

WARNING

●

Do not wear the seat belt extender if you can fasten the seat belt without the extender.

●

Do not use the seat belt extender when installing a child restraint system because the
belt will not securely hold the child restraint system, increasing the risk of death or
serious injury in the event of an accident.

●

The personalized extender may not be safe on another vehicle, when used by another
person, or at a different seating position other than the one originally intended.

NOTICE

When removing a seat belt extender, press the buckle release button on the extender, not
on the seat belt buckle. Then, remove the extender from the seat belt buckle.
This helps prevent damage to the vehicle interior and the extender itself.

Fastening and releasing the seat belts

To fasten the seat belt, push the plate into
the buckle until a click sound is heard.

To release the seat belt, press the release
button .

INFORMATION

■

Emergency locking retractor (ELR)

The retractor will lock the belt during a sudden stop or on impact. It may also lock if you
lean forward too quickly. When the seat belt locks, pull the belt strongly and then release
the belt, then a slow and easy pulling will allow the belt to extend.

1-7. Obtaining the correct driving posture

123

Befor

e driving

■

Automatic locking retractor (ALR)

When a passenger's shoulder belt is completely extended and then retracted even
slightly, the belt is locked in that position and cannot be extended. This feature is used to
hold the child restraint system (CRS) firmly. To free the belt again, fully retract the belt and
then pull the belt out once more.

WARNING

●

Do not damage the seat belts by allowing the belt, plate, or buckle to be jammed in the
door.

●

Ensure that the belt and plate are locked and the belt is not twisted.
If the seat belt does not function correctly, immediately contact your Lexus dealer.

Adjusting the height of the front seat belts

Push the seat belt shoulder anchor down
while pressing the release button .

Push the seat belt shoulder anchor up while
pressing the release button .

Move the height adjuster up and down as need-
ed until you hear a click.

WARNING

■

Adjustable shoulder anchor

Always make sure the shoulder belt is positioned across the center of your shoulder. The
belt should be kept away from your neck, but not falling off your shoulder. Failure to do so
could reduce the amount of protection in an accident and cause death or serious injuries
in the event of a sudden stop, sudden swerve or accident.

1-7. Obtaining the correct driving posture

124

Adjusting the position of the steering wheel and mirrors

Adjusting the position of the steering wheel horizontally/vertically
(Manual type)

WARNING

Do not adjust the steering wheel while driving.

Hold the steering wheel and push the lever
down.

Adjust to the ideal position by moving the
steering wheel horizontally and vertically.

After adjustment, pull the lever up to secure the
steering wheel.

INFORMATION

■

After adjusting the steering wheel

Make sure that the steering wheel is securely locked.
The horn may not sound if the steering wheel is not securely locked.

WARNING

After adjusting the steering wheel, make sure that the steering wheel is securely
locked.
Otherwise, the steering wheel may move suddenly.

1-7. Obtaining the correct driving posture

125

Befor

e driving

Adjusting the position of the steering wheel horizontally/vertically
(Power type)

INFORMATION

■

The steering wheel can be adjusted when

The power switch is in ACC or ON.

WARNING

Do not adjust the steering wheel while driving.

Operating the switch moves the steering wheel
in the following directions:

Down

Toward the driver

Away from the driver

INFORMATION

■

Automatic adjustment of the steering position

A desired steering position can be entered to memory and recalled automatically by the
driving position memory system.

■

Power easy access system

The steering wheel and driver’s seat move in accordance with power switch mode and
the driver’s seat belt condition.

Adjusting the position of the inside rear view mirror

WARNING

Do not adjust the position of the mirror while driving.

Adjust the position of the inside rear view mirror so that the correct driving posture
can be achieved.

*1 :

If the driver’s seat belt is fastened, the steering wheel can be adjusted regardless of

power switch mode.

1-7. Obtaining the correct driving posture

126

Adjust the inside rear view mirror vertically by
grasping and moving it.

Digital Rear-view mirror effort and caution

The Digital Rear-view Mirror is a system that uses the camera on the rear of the
vehicle and displays its image on the display of the Digital Rear-view Mirror.
The Digital Rear-view Mirror can be changed between optical mirror mode and
digital mirror mode by operating the lever.
The Digital Rear-view Mirror allows the driver to see the rear view despite obstruc-
tions, such as the head restraints or luggage, ensuring rear visibility. Also, the rear
seats are not displayed and privacy of the passengers is enhanced.

WARNING

Observe the following precautions. Failure to do so may result in death or serious injury.

■

Before using the Digital Rear-view Mirror

●

Make sure to adjust the mirror before driving.

•

Change to optical mirror mode and adjust the position of the Digital Rear-view
Mirror so that the area behind your vehicle can be viewed properly.

•

Change to digital mirror mode and adjust the display settings.

●

As the range of the image displayed by the Digital Rear-view Mirror is different from
that of the optical mirror, make sure to check this difference before driving.

System components of the Digital Rear-view Mirror

Camera indicator
Indicates that the camera is operating nor-
mally.

Icon display area
Displays icons, adjusting gauge, etc.

Select/adjust button
Press to change the setting of the item you
want to adjust.

* :

If equipped

1-7. Obtaining the correct driving posture

127

Befor

e driving

Menu button
Press to display the icon display area and
select the item you want to adjust.

Lever
Operate to change between digital mirror
mode and optical mirror mode.

Digital mirror anti-glare function indicator
Displayed in digital mirror mode when the
anti-glare function of the digital mirror is
enabled.

Changing modes of the Digital Rear-view Mirror

Operate the lever to change between digital mirror mode and optical mirror
mode.

Digital mirror mode
Displays an image of the area behind the
vehicle.

[

] will illuminate in this mode.

Optical mirror mode
Turns off the display of the Digital Rearview
Mirror allows it to be used as an optical
mirror.

Digital mirror mode operating condition

The power switch is turned to ON.
When the power switch is changed from ON to OFF or ACC, the image will
disappear after several seconds.

Precautions about digital mirror mode

If it is difficult to see the displayed image due to light reflected off the Digital
Rear-view Mirror, the camera being dirty or covered with water droplets, dust, etc.,
or if lights of a vehicle behind your vehicle or the displayed image are bothering
you, change to optical mirror mode.
When it is raining, if the image is unclear due to water on the rear window, operate
the rear wiper.

1-7. Obtaining the correct driving posture

128

●

When the back door is open, the Digital Rear-view Mirror image may not
display properly. Before driving, make sure the back door is closed.

●

If the display is difficult to see due to reflected light, close the sunshade.

●

Any of the following conditions may occur when driving in the dark, such as at
night. None of them indicates that a malfunction has occurred.

•

Colors of objects in the displayed image may differ from their actual color.

•

Depending on the height of the lights of the vehicle behind, the area around the
vehicle may appear white and blurry.

•

Automatic image adjustment for brighter surrounding image may cause flickering.
If it is difficult to see the displayed image or flickering bothers you, change to optical
mirror mode.

●

The Digital Rear-view Mirror may become hot while it is in digital mirror mode.
This is not a malfunction.

●

Depending on your physical condition or age, it may take longer than usual to
focus on the displayed image. In this case, change to optical mirror mode.

●

Do not let passengers stare at the displayed image when the vehicle is being
driven, as doing so may cause motion sickness.

■

When the system malfunctions

If the symbol shown in the illustration is displayed
when using the Digital Rear-view Mirror in digital
mirror mode, the system may be malfunctioning.
The symbol will disappear in a few seconds.
Operate the lever, change to optical mirror
mode and have the vehicle inspected by your
Lexus dealer.

Adjusting the Digital Rear-view Mirror

Settings of the display in the digital mirror mode, on/off operation of the automatic
anti-glare function, etc. can be changed.

Press the menu button.

The icons will be displayed.

1-7. Obtaining the correct driving posture

129

Befor

e driving

Press the menu button repeatedly and select the item you want to adjust.

Press [

] or [

]to change the setting.

The icons will disappear if a button is not operated for approximately 5 seconds or
more.

Icons

Settings

Select to adjust the brightness of the dis-
play.

Select to adjust the area displayed up/
down.

Select to adjust the area displayed to the
left/right.

Select to adjust the angle of the displayed
image.

Select to zoom in/out the displayed im-
age.

Select to enable/disable the automatic
anti-glare function.

Responding to the brightness of the
headlights of vehicles behind, the reflect-
ed light is automatically adjusted.
The automatic anti-glare function is en-
abled each time the power switch is
changed to ON.

The anti-glare function of the digital mir-
ror can be enabled/disabled. When ena-
bled, image on the digital mirror at night-
time will be displayed at a reduced bright-
ness level, reducing the headlight glare of
the following vehicle.

Select to display HomeLink

Training Tu-

torial to assist customers to train their
Garage Door Opener System.

Select to change the language of the
HomeLink

Training Tutorial.

*2 :

This is a function for the optical mirror mode, however, the setting can also be changed

while using the digital mirror mode.

1-7. Obtaining the correct driving posture

130

Precautions when adjusting the Digital Rear-view Mirror

■

Adjusting the display (digital mirror mode)

●

The icons will disappear if a button is not operated for approximately 5 seconds
or more.

●

If the displayed image is adjusted, it may appear distorted. This is not a malfunc-
tion.

●

If the brightness of the Digital Rear-view Mirror is set too high, it may cause eye
strain. Adjust the Digital Rear-view Mirror to an appropriate brightness. If your
eyes become tired, change to optical mirror mode.

●

The brightness of the Digital Rear-view Mirror will change automatically accord-
ing to the brightness of the area in front of your vehicle.

●

The digital anti-glare mode operates only in locations where the surroundings
are dark. Depending on the surrounding illumination environment, the image
may not darken and it may not be possible to reduce headlight glare from
vehicles to the rear.

■

To prevent the light sensors from malfunctioning

To prevent the light sensors from malfunctioning,
do not touch or cover them.

WARNING

Observe the following precautions. Failure to do so may result in death or serious injury.

■

While driving

●

Do not adjust the position of the Digital Rear-view Mirror or adjust the display settings
while driving.
Stop the vehicle and operate the Digital Rear-view Mirror control switches. Failure
to do so may cause a steering wheel operation error, resulting in an unexpected
accident.

●

Always pay attention to the vehicle’s surroundings.
The size of the vehicles and other objects may look different when in digital mirror
mode and optical mirror mode. When backing up, make sure to directly check the
safety of the area around your vehicle, especially behind the vehicle. Additionally, if a

1-7. Obtaining the correct driving posture

131

Befor

e driving

WARNING

vehicle approaches from the rear in the dark, such as at night, the surrounding area
may appear dim.

Cleaning the Digital Rear-view Mirror

■

Cleaning the mirror surface

If the mirror surface is dirty, the image on the display may be difficult to see. Clean
the mirror surface gently using a soft dry cloth.

INFORMATION

■

The camera

The camera for the Digital Rear-view Mirror is locat-
ed as shown.

NOTICE

■

To prevent the camera from malfunctioning

●

Observe the following precautions, otherwise the Digital Rear-view Mirror may not
operate properly.

•

Do not strike or hit the camera or subject it to a strong impact, as the camera
installation position and angle may be changed.

•

Do not remove, disassemble or modify the camera.

•

Do not allow an organic solvent, car wax, window cleaner or glass coating to
adhere to the camera. If this happens, wipe it off as soon as possible.

•

When applying colored film (including transparent film) to the rear window glass,
do not apply it to the area in front of the camera. If film is applied to the area in front
of the camera, the image from the camera may not display properly.

●

Do not subject the camera to a strong impact as this could cause a malfunction. If this
happens, have the vehicle inspected by your Lexus dealer as soon as possible.

1-7. Obtaining the correct driving posture

132

NOTICE

●

Do not block the vent holes of the mirror. Other-
wise, the mirror may be hot, leading to a malfunc-
tion or a fire.

If you notice any symptoms about the Digital Rear-view Mirror

If you notice any of the following symptoms, refer to the following table for the likely
cause and the solution.
If the symptom is not resolved by the solution, have the vehicle inspected by your
Lexus dealer.

Symptom

Likely cause

Solution

The image is
difficult to see.

The mirror surface is dirty.

Clean the mirror surface gently, using
a soft dry cloth.

Sunlight or headlights are shin-
ing directly into the Digital
Rear-view Mirror.

Change to optical mirror mode. (If
the light is coming through the moon
roof

or panoramic moon roof

, close

the sunshade or electronic sunshade.)

* :

If equipped

1-7. Obtaining the correct driving posture

133

Befor

e driving

Symptom

Likely cause

Solution

The image is
difficult to see.

●

The vehicle is in a dark area.

●

The vehicle is near a TV
tower, broadcasting station,
electric power plant, or oth-
er location where strong ra-
dio waves or electrical noise
may be present.

●

The temperature around the
camera is extremely high/
low.

●

The ambient temperature is
extremely low.

●

It is raining or humid.

●

Sunlight or headlights are
shining directly into the cam-
era lens.

●

The vehicle is under fluores-
cent lights, sodium lights,
mercury lights, etc.

●

Exhaust gas is obstructing
the camera.

Change to optical mirror mode.
(Change back to digital mirror mode
when the conditions have improved.)

Foreign matters such as water
droplets or dust is on the cam-
era lens.

Have the vehicle inspected by your
Lexus dealer.

The luggage in the luggage
compartment is reflected off
the rear window glass and ob-
structing the camera.

●

Change to optical mirror mode.

●

Move the luggage to a position
where it does not obstruct the
camera or cover it with a black
cloth to reduce the amount it is
reflected off the rear window glass.

The rear window glass is fog-
ged up.

Change to optical mirror mode. After
defogging the rear window using the
rear window defogger, use the digital
mirror mode again.

The outside of the rear window
glass is dirty.

Use the rear window wiper to remove
dirt.

1-7. Obtaining the correct driving posture

134

Symptom

Likely cause

Solution

The image is
difficult to see.

The inside of the rear window
glass is dirty.

Have the vehicle inspected by your
Lexus dealer.

The image is
out of align-
ment.

The back door is not fully
closed.

Fully close the back door.

The camera or its surrounding
area has received a strong im-
pact.

Change to optical mirror mode and
have the vehicle inspected by your
Lexus dealer.

The display is
dim and [

]

is displayed.

The system may be malfunc-
tioning.

Change to optical mirror mode and
have the vehicle inspected by your
Lexus dealer.

[

] goes off.

[

] is dis-

played.

The Digital Rear-view Mirror is
extremely hot. (The display will
gradually become more dim. If
the temperature continues to
increase, the Digital Rear-view
Mirror will turn off.)

Reducing the cabin temperature is
recommended to reduce the temper-
ature of the mirror. ([

] will disap-

pear when the mirror becomes cool.)

If [

] does not disappear even

though the mirror is cool, have the
vehicle inspected by your Lexus deal-
er.

The lever can-
not be operat-
ed properly.

The lever may be malfunction-
ing.

Change to optical mirror mode and
have the vehicle inspected by your
Lexus dealer.
To change to optical mirror mode,
press and hold the menu button for
approximately 10 seconds.

Adjusting the angle of the outside rear view mirrors

INFORMATION

■

When using the outside rear view mirrors in a cold weather

When it is cold and the outside rear view mirrors are frozen, it may not be possible to
fold/extend them or adjust the mirror surface. Remove the ice, snow, etc. covering the
outside rear view mirrors.

1-7. Obtaining the correct driving posture

135

Befor

e driving

WARNING

Do not adjust the position of the mirror while driving.

To select a mirror to adjust, press the switch.

Select the left mirror

Select the right mirror

To adjust the mirror, press the switch.

Adjust the mirror surface up

Adjust the mirror surface right

Adjust the mirror surface down

Adjust the mirror surface left

INFORMATION

■

Mirror angle can be adjusted when

The power switch is in ACC or ON.

■

Automatic adjustment of the mirror angle (vehicles with driving position memo-
ry)

A desired mirror face angle can be entered to memory and recalled automatically by
the driving position memory.

■

Linked mirror function when reversing (vehicles with driving position memory)

When the mirror select switch is in the “L” or “R” position, the outside rear view
mirrors will automatically angle downwards when the vehicle is reversing in order to
give a better view of the ground.
To disable this function, move the mirror select switch to the neutral position (be-
tween “L” and “R”)
With the shift position in R, adjust the mirror angle at a desired position to set the
mirror angle used when the vehicle is reversing.
The adjusted angle will be memorized and the mirror will automatically tilt to the
memorized angle whenever the shift position is shifted to R from next time.

1-7. Obtaining the correct driving posture

136

The memorized downward tilt position of the mirror is linked to the normal position
(angle adjusted with the shift position in other than R). Therefore, if the normal
position is changed after adjustment, the tilt position will also change.
When the normal position is changed, readjust the angle in reversing.

■

Using the reverse-linked function when it is cold

When reverse-linked function used in cold weather, the door mirror could be frozen
and may not automatically point the mirror surface downward. In this event, remove
any ice and snow from the mirror surface.

Related Links

Customizable features(P. 751)

Folding/extending the outside rear view mirrors

▶

Using the switch

Press the switch to fold the mirrors.

Press it again to extend them to the original position.

▶

Setting automatic mode

Automatic mode allows the folding or extend-
ing of the mirrors to be linked to locking/un-
locking of the doors.
Press the switch to set automatic mode.

The indicator

will come on.

Pressing the switch once more will return to manual
mode.

WARNING

Observe the following precautions.

●

Do not drive with the mirrors folded.

●

Do not touch an outside rear view mirror when it is moving. Failure to do so may lead
to your finger being pinched or the mirror being damaged.

●

As the mirror surface will be hot, do not touch an outside rear view mirror when the
mirror heater is operating.

1-7. Obtaining the correct driving posture

137

Befor

e driving

Starting and stopping the hybrid system

Starting the hybrid system

WARNING

Always start the hybrid system while sitting in the driver’s seat. Do not depress the
accelerator pedal while starting the hybrid system under any circumstances.

NOTICE

■

When starting the hybrid system

If the hybrid system becomes difficult to start, have your vehicle checked by your Lexus
dealer immediately.

■

Operation of the power switch

If the power switch seems to be operating somewhat differently than usual, such as
the switch sticking slightly, there may be a malfunction. Contact your Lexus dealer
immediately.

Check that the parking brake is set.

The parking brake indicator will come on.

Firmly depress the brake pedal.

and a message will be displayed on the multi-information display. If it is not

displayed, the hybrid system cannot be started.
When the shift position is N, the hybrid system cannot start. Shift the shift position to P
when starting the hybrid system.

Press the power switch shortly and firmly.

When operating the power switch, one short, firm
press is enough. It is not necessary to press and
hold the switch.
If the "READY" indicator turns on, the hybrid sys-
tem will operate normally.
Continue depressing the brake pedal until the
"READY" indicator is illuminated.
The hybrid system can be started from any power switch mode.

Check that the "READY" indicator is illuminated.

The vehicle will not move when the "READY" indicator is off.

2-1. Starting and stopping the hybrid system

140

INFORMATION

■

Power switch illumination

According to the situation, the power switch illumination operates as follows.

●

If a door is open or the power switch is turned from ACC or ON to OFF, the
power switch light will illuminate dimly.

●

If the brake pedal is depressed while carrying an electronic key, the power switch
light will illuminate brightly.

●

When the power switch is in ACC or ON, the power switch illumination illumi-
nates.

■

If the hybrid system does not start

●

The immobilizer system may not have been deactivated. Contact your Lexus
dealer.

●

If a message related to start-up is shown on the multi-information display, read the
message and follow the instructions.

■

When the ambient temperature is low, such as during winter driving conditions

●

When starting the hybrid system, the flashing time of the "READY" indicator may
be long. Leave the vehicle as it is until the "READY" indicator is steady on, as
steady means the vehicle is able to move.

●

When the hybrid battery (traction battery) is extremely cold (below approximately
-22°F [-30°C]) under the influence of the outside temperature, it may not be
possible to start the hybrid system. In this case, try to start the hybrid system
again after the temperature of the hybrid battery increases due to the outside
temperature increase etc.

■

If the "READY" indicator does not come on

In the event that the "READY" indicator does not come on even after performing the
proper procedures for starting the vehicle, contact your Lexus dealer immediately.

■

Operation of the power switch

●

If the switch is not pressed shortly and firmly, the power switch mode may not
change or the hybrid system may not start.

●

If attempting to restart the hybrid system immediately after turning the power
switch off, the hybrid system may not start in some cases. After turning the power
switch off, please wait a few seconds before restarting the hybrid system.

2-1. Starting and stopping the hybrid system

141

Driving the v

ehicle

Changing the power switch mode

Modes can be changed by pressing the power switch with brake pedal released.
(The mode changes each time the switch is pressed.)

OFF

The emergency flashers can be used.

ACC

Some electrical components such as the
audio system can be used. "ACCESSORY"
will be displayed on the multi-information
display.

ON
All electrical components can be used.
"IGNITION ON" will be displayed on the
multi-information display.

INFORMATION

■

When ACC customization is in off

●

With the power switch is turned off, the center display can still be used for a certain
time until the battery saving function starts operating.

●

When the safe exit assist is operating, a buzzer will sound and a voice guidance will be
given.

■

Auto power off function

●

If the vehicle is left in ACC or ON (the hybrid system is not operating) for more than
20 minutes with the shift position in P, the power switch will automatically turn to OFF.

●

If the 12-volt battery is low with the shift position is in P and the power switch is in ACC
or ON (the hybrid system is not operating). The power switch is automatically turn to
OFF.

However, this function cannot entirely prevent the 12-volt battery discharge. Do not leave
the vehicle with the power switch in ACC or ON for long periods of time when the
hybrid system is not operating.

*1 :

The power switch will remain ON when a shift position other than P is selected.

*2 :

ACC mode can be enabled/disabled through a customize setting.

2-1. Starting and stopping the hybrid system

142

■

When the shift control system malfunctions

If the shift control system is malfunctioning, when attempting to turn the power switch off,
it may not be able to be turned off. In this situation, it may be possible to turn the power
switch off by applying the parking brake and then operating the power switch.
If there is a malfunction in the system, have the vehicle inspected by your Lexus dealer
immediately.

NOTICE

Do not leave the vehicle with the power switch in ACC or ON for long periods of time
when the hybrid system is not operating.
If "ACCESSORY" or "IGNITION ON" is displayed on the meters while the hybrid
system is not operating, the power switch is not off. Exit the vehicle after turning the
power switch off.

Related Links

Customizable features(P. 751)

2-1. Starting and stopping the hybrid system

143

Driving the v

ehicle

Stopping the hybrid system

WARNING

If you want to stop the hybrid system in an emergency while driving the vehicle, press
and hold the power switch for more than 2 seconds, or press it briefly 3 times or more in
succession.
However, do not touch the power switch while driving, except in an emergency. Turning
the hybrid system off while driving will not cause loss of steering or braking control,
however power assist to the steering will be lost. This will make it more difficult to steer.
Pull over and stop the vehicle as soon as it is safe to do so.

Stop the vehicle completely.

Set the parking brake.

Press the P position switch.

Check that the shift position indicator shows P and the parking brake indicator is
illuminated.

Press the power switch.

The hybrid system will stop, and the meter display will be extinguished (the shift position
indicator will be extinguished a few seconds after the meter display).

Release the brake pedal and check that the display on the instrument cluster is
off.

INFORMATION

■

Automatic hybrid system shut off feature

●

The vehicle is equipped with a feature that automatically shuts off the hybrid
system when the shift position is in P with the hybrid system operating for an
extended period.

●

The hybrid system will automatically shut off after approximately 1 hour if it has
been left running while the shift position is in P.

●

The timer for the automatic hybrid system shut off feature will reset if the brake
pedal is depressed or if the shift position is in a position other than P.

●

After the vehicle is parked, if the door is locked with the door lock switch from the
inside or the mechanical key from the outside, the automatic hybrid system shut off
feature will be disabled. The timer for the automatic hybrid system shut off feature
will be re-enabled if the driver’s door is opened.

2-1. Starting and stopping the hybrid system

144

Driving procedures

Driving procedure

WARNING

■

When driving the vehicle

●

When backing up, you may twist your body around, leading to difficulty in operating
the pedals.
Make sure to operate the pedals properly.

●

Make sure to keep a correct driving posture even when moving the vehicle only
slightly. This allows you to depress the brake and accelerator pedals properly.

●

Depress the brake pedal using your right foot.
Depressing the brake pedal using your left foot may delay response in an emergency,
resulting in an accident.

●

Do not drive the vehicle over or stop the vehicle near flammable materials. The
exhaust system and exhaust gases can be extremely hot. These hot parts may cause a
fire if there is any flammable material nearby.

●

Never turn the power switch off during normal driving. If the hybrid system is stopped
while driving, steering and brake operations will still be possible, however, power assist
will no longer be provided and the steering wheel will become difficult to operate.
After checking the safety of the area around your vehicle, stop the vehicle on the side
of the road. In an emergency, if the vehicle cannot be stopped normally, perform an
emergency stop.

●

Use engine braking (downshift) to maintain a safe speed when driving down a steep
hill. Using the brakes continuously may cause the brakes to overheat and lose effec-
tiveness.

●

Do not adjust the positions of the steering wheel, the seat, or the inside or outside rear
view mirrors while driving. Doing so may result in a loss of vehicle control.

●

Always check that all passengers’ arms, heads or other parts of their body are not
outside the vehicle.

●

This vehicle is not designed for extreme off-roading.

•

When driving in sand or mud is unavoidable, drive carefully and avoid continuous
driving on sand or mud.

•

Do not drive on extremely rocky roads or extremely uneven roads.

●

Do not drive across a river or through other bodies of water. This may cause elec-
tric/electronic components to short circuit, damage the hybrid system or cause other
serious damage to the vehicle.

●

Do not drive in excess of the speed limit. Even if the legal speed limit permits it, do
not drive over 85 mph (140 km/h) unless your vehicle has high-speed capability tires.
Driving over 85 mph (140 km/h) may result in tire failure, loss of control and possible

2-2. Driving procedures

146

WARNING

injury. Be sure to consult a tire dealer to determine whether the tires on your vehicle
are high-speed capability tires or not before driving at such speeds.

●

Avoid sudden braking, acceleration, and steering inputs when driving on slick road
surfaces. Doing so may cause the tires to lose traction, leading to loss of control of the
vehicle.

●

Avoid sudden accelerator pedal operations and shift operations when driving on slick
road surfaces. Doing so may cause engine braking or changes in engine speed may
cause the vehicle to slide sideways.

●

After driving through a puddle, lightly depress the brake pedal to make sure that
the brakes are functioning properly. Wet brake pads may prevent the brakes from
functioning properly. If the brakes on only one side are wet and not functioning
properly, steering control may be affected.

●

Avoid spinning the wheels and depressing the accelerator pedal more than necessary.
Doing so may damage the transmission and other components.

■

If you hear a squealing or scraping noise (brake pad wear limit indicators)

Have the brake pads checked and replaced by your Lexus dealer as soon as possible.
Rotor damage may result if the pads are not replaced when needed.
It is dangerous to drive the vehicle when the wear limits of the brake pads and/or those of
the brake discs are exceeded.

NOTICE

■

Avoiding damage to vehicle parts

●

Do not turn and hold the steering wheel at either fully turned position for an extended
period of time. Doing so may damage the power steering.

●

When driving over bumps or areas where the road height changes, drive as slowly as
possible. Otherwise the wheels, etc. may be damaged.

■

If you get a flat tire while driving

In the following situations, firmly hold the steering wheel and gradually apply the brakes
to decrease the vehicle’s speed, as a tire may be flat or damaged:

●

When the steering wheel pulls either direction

●

When there are abnormal sounds or vibrations

●

When the vehicle leans abnormally

■

When encountering flooded roads

Do not drive on roads which have become flooded due to heavy rain, etc. Doing so may
cause serious damage to the vehicle, such as the following:

2-2. Driving procedures

147

Driving the v

ehicle

NOTICE

●

Engine stalling

●

Shorts in electrical components

●

Engine damage caused by water immersion

In the event that you drive on a flooded road and the vehicle is flooded, be sure to have
your Lexus dealer check the following:

●

Brake function

●

Changes in quantity and quality of oil and fluid used for the engine, hybrid transmis-
sion, etc.

●

Lubricant condition for the bearings and suspension joints (where possible), and the
function of all joints, bearings, etc.

If the shift control system is damaged by flooding, it may not be possible to change the
shift position to P, or from P to other positions.
In this case, contact your Lexus dealer.

■

Operating your vehicle in a foreign country

Comply with the relevant vehicle registration laws and confirm the availability of
the correct fuel.

2-2. Driving procedures

148

Breaking in your new Lexus

To extend the life of the vehicle, observing the following precautions is recom-
mended:

●

For the first 200 miles (300 km):
Avoid sudden stops.

●

For the first 1000 miles (1600 km):

•

Do not drive at extremely high speeds.

•

Avoid sudden acceleration.

•

Do not drive continuously in low gears.

•

Do not drive at a constant speed for extended periods.

●

For the first 500 miles (800 km):
Do not tow a trailer. (vehicles with towing package)

2-2. Driving procedures

149

Driving the v

ehicle

Intended use of each shift position

Select the shift position depending on your purpose and situation.

Shift position

Objective or function

Parking the vehicle/starting the hybrid sys-
tem

Reversing

Neutral

Normal driving

(1)

S mode driving

(2)

(1)

To improve fuel efficiency and reduce noise, set the shift position in D for normal

driving. You can choose gear range suitable for your driving situation by operating the

paddle shift switches.

(2)

By selecting shift ranges using S mode, you can control accelerating force and engine

braking force.

INFORMATION

■

When engine braking is not performed

When the vehicle is being driven with the dynamic radar cruise control operating, engine
braking will not be performed even if the following operations are performed.

●

While driving in D or S position, downshifting to 5 or 4.

●

When Sport mode is selected while driving in D position.

■

If a message about a shift operation is shown

To prevent the shift position from being selected incorrectly or the vehicle from moving
unexpectedly, the shift position may be changed automatically or operating the shift lever
may be required. In this case, change the shift position following the messages on the
multi-information display.

WARNING

Avoid sudden accelerator pedal operations and shift operations when driving on slick
road surfaces. Engine braking or changes in engine speed may cause the vehicle to slide
sideways.

NOTICE

■

Situations where shift control system malfunctions are possible

If any of the following situations occurs, shift control system malfunctions are possible.

2-2. Driving procedures

150

Lexus NX350h (2024 year). Manual in english - page 4
