Lexus LC500C (2024 year). Manual in english

347

6-3. Do-it-yourself maintenance

Mai
nte

e a

are



LC500



LC500h

The 12-volt battery is located in the
trunk.

■

Before recharging

When recharging, the 12-volt battery pro-

duces hydrogen gas which is flammable

and explosive. Therefore, observe the fol-

lowing precautions before recharging:

●

If recharging with the 12-volt battery

installed on the vehicle, be sure to dis-

connect the ground cable.

●

Make sure the power switch on the char-

ger is off when connecting and discon-

necting the charger cables to the 12-volt

battery.

■

After recharging/reconnecting the 12-

volt battery

●

Unlocking the doors using the smart

access system with push-button start may

not be possible immediately after recon-

necting the 12-volt battery. If this hap-

pens, use the wireless remote control or

the mechanical key to lock/unlock the

doors.

●

Start the engine <hybrid system> with the

engine switch <power switch> in ACC.

The engine <hybrid system> may not start

with the engine switch <power switch>

turned off. However, the engine <hybrid

system> will operate normally from the

second attempt.

●

The engine switch <power switch> mode

is recorded by the vehicle. If the 12-volt

WARNING

■

When adding washer fluid

Do not add washer fluid when the engine

<hybrid system> is hot or running <oper-

ating> as washer fluid contains alcohol

and may catch fire if spilled on the engine

etc.

NOTICE

■

Do not use any fluid other than

washer fluid

Do not use soapy water or engine anti-

freeze instead of washer fluid.

Doing so may cause streaking on the

vehicle’s painted surfaces, as well as

damaging the pump leading to problems

of the washer fluid not spraying.

■

Diluting washer fluid

Dilute washer fluid with water as neces-

sary.

Refer to the freezing temperatures listed

on the label of the washer fluid bottle.

12-volt battery

Location

348

6-3. Do-it-yourself maintenance

battery is reconnected, the vehicle will

return the engine switch <power switch>

mode to the status it was in before the 12-

volt battery was disconnected. Make

sure to turn off the engine switch <power

switch> before disconnect the 12-volt

battery. Take extra care when connect-

ing the 12-volt battery if the engine switch

<power switch> mode prior to discharge

is unknown.

If the engine <hybrid system> will not start

even after multiple attempts at all methods

above, contact your Lexus dealer.

Pull the strap upwards to lift up the lug-
gage mat.

WARNING

■

Chemicals in the 12-volt battery

The 12-volt battery contains poisonous

and corrosive sulfuric acid and may pro-

duce hydrogen gas which is flammable

and explosive. To reduce the risk of

death or serious injury, take the following

precautions while working on or near the

12-volt battery:

●

Do not cause sparks by touching the

12-volt battery terminals with tools.

●

Do not smoke or light a match near the

12-volt battery.

●

Avoid contact with eyes, skin and

clothes.

●

Never inhale or swallow electrolyte.

●

Wear protective safety glasses when

working near the 12-volt battery.

●

Keep children away from the 12-volt

battery.

■

Where to safely charge the 12-volt

battery

Always charge the 12-volt battery in an

open area. Do not charge the 12-volt

battery in a garage or closed room

where there is insufficient ventilation.

■

How to recharge the 12-volt battery

Recharge at a current of 5 A or less and

make sure that the recharging period

does not exceed a total of 12 hours.

■

Emergency measures regarding

electrolyte

●

If electrolyte gets in your eyes

Flush your eyes with clean water for at

least 15 minutes and get immediate

medical attention. If possible, continue

to apply water with a sponge or cloth

while traveling to the nearest medical

facility.

●

If electrolyte gets on your skin

Wash the affected area thoroughly. If

you feel pain or burning, get medical

attention immediately.

●

If electrolyte gets on your clothes

It can soak through clothing on to your

skin. Immediately take off the clothing

and follow the procedure above if nec-

essary.

●

If you accidentally swallow electrolyte

Drink a large quantity of water or milk.

Get emergency medical attention

immediately.

NOTICE

■

When recharging the 12-volt battery

Never recharge the 12-volt battery while

the engine is running <hybrid system is

operating>. Also, be sure all accessories

are turned off.

Removing the 12-volt battery
cover

349

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Make sure that the 12-volt battery ter-
minals are not corroded and that there
are no loose connections, cracks, or
loose clamps.

Terminals

Hold-down clamp

Check that the level is upper than the
center between the bottom of the bat-
tery lid and “LOWER LEVEL” line.

Bottom of the battery lid

“LOWER LEVEL” line

Center of

and

If the fluid level is below

, replace the

12-volt battery.

Check if the treadwear indicators are
showing on the tires. Also check the
tires for uneven wear, such as exces-
sive wear on one side of the tread.

New tread

Worn tread

Treadwear indicator

The location of treadwear indicators is
shown by a “TWI” or “

” mark, etc.,

molded into the sidewall of each tire.
Replace the tires if the treadwear indica-
tors are showing on a tire.

Exterior

Checking 12-volt battery fluid

A
B

A
B
C

Tires

Replace or rotate tires in accor-
dance with maintenance schedules
and treadwear.

Checking tires

A
B
C

350

6-3. Do-it-yourself maintenance

■

When to replace your vehicle’s tires

Tires should be replaced if:

●

The treadwear indicators are showing on

a tire.

●

You have tire damage such as cuts, splits,

cracks deep enough to expose the fabric,

and bulges indicating internal damage

●

A tire goes flat repeatedly or cannot be

properly repaired due to the size or loca-

tion of a cut or other damage

If you are not sure, consult your Lexus

dealer.

■

Tire life

Any tire over 6 years old must be checked

by a qualified technician even if it has sel-

dom or never been used or damage is not

obvious.

■

Low profile tires (21-inch tires)

Generally, low profile tires will wear more

rapidly and tire grip performance will be

reduced on snowy and/or icy roads when

compared to standard tires. Be sure to use

snow tires on snowy and/or icy roads and

drive carefully at a speed appropriate for

road and weather conditions.

■

Maximum load of tire

Check that the maximum load of the

replacement tire is greater than 1/2 of the

Gross Axle Weight Ratings (GAWR) of

either the front axle or the rear axle, which-

ever is greater.
For the GAWR, see the Certification Label.

For the maximum load of the tire, see the

load limit at maximum cold tire inflation

pressure mentioned on the sidewall of the

tire. (



P.451)



Except Convertible



Convertible

■

Tire types

●

Summer tires

Summer tires are high-speed perfor-

mance tires best suited to highway driv-

ing under dry conditions. Since summer

tires do not have the same traction per-

formance as snow tires, summer tires are

inadequate for driving on snow-covered

or icy roads. For driving on snow-cov-

ered roads or icy roads, the use of snow

tires is recommended. When installing

snow tires, be sure to replace all four

tires.

●

All season tires

All season tires are designed to provide

better traction in snow and to be ade-

quate for driving in most winter condi-

tions as well as for use year-round. All

season tires, however, do not have ade-

quate traction performance compared

with snow tires in heavy or loose snow.

Also, all season tires fall short in accelera-

tion and handling performance com-

pared with summer tires in highway

driving.

●

Snow tires

For driving on snow-covered roads or icy

roads, we recommend using snow tires. If

you need snow tires, select tires of the

same size, construction and load capacity

as the originally installed tires. Since your

vehicle has radial tires as original equip-

ment, make sure your snow tires also

have radial construction. Do not install

studded tires without first checking local

regulations for possible restrictions.

Snow tires should be installed on all

wheels. (



P.287)

■

If the tread on snow tires wears down

below 0.16 in. (4 mm)

The effectiveness of the tires as snow tires is

351

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

lost.

Tires cannot be rotated.

Your vehicle is equipped with a tire
pressure warning system that uses tire
pressure warning valves and transmit-
ters to detect low tire inflation pressure
before serious problems arise.



If the tire pressure drops below a
predetermined level, the driver is
warned by a screen display and a
warning light. (



P.390)



The tire pressure detected by the
tire pressure warning system can be
displayed on the multi-information
display. (



P.110)

The illustration used is intended as an
example, and may differ from the image
that is actually displayed on the multi-infor-
mation display.

WARNING

■

When inspecting or replacing tires

Observe the following precautions to

prevent accidents.

Failure to do so may cause damage to

parts of the drivetrain as well as danger-

ous handling characteristics, which may

lead to an accident resulting in death or

serious injury.

●

Do not mix tires of different makes,

models or tread patterns.

Also, do not mix tires of remarkably

different treadwear.

●

Do not use tire sizes other than those

recommended by Lexus.

●

Do not mix differently constructed

tires (radial, bias-belted or bias-ply

tires).

●

Do not mix summer, all season and

snow tires.

●

Do not use tires that have been used

on another vehicle.

Do not use tires if you do not know

how they were used previously.

NOTICE

■

Driving on rough roads

Take particular care when driving on

roads with loose surfaces or potholes.

These conditions may cause losses in tire

inflation pressure, reducing the cushion-

ing ability of the tires. In addition, driving

on rough roads may cause damage to

the tires themselves, as well as the vehi-

cle’s wheels and body.

■

Low profile tires (21-inch tires)

Low profile tires may cause greater dam-

age than usual to the tire wheel when

sustaining impact from the road surface.

Therefore, pay attention to the following:

●

Be sure to use proper tire inflation

pressure. If tires are under-inflated,

they may be damaged more severely.

●

Avoid potholes, uneven pavement,

curbs and other road hazards. Failure

to do so may lead to severe tire and

wheel damage.

■

If tire inflation pressure of each tire

becomes low while driving

Do not continue driving, or your tires

and/or wheels may be ruined.

Tire rotation

Tire pressure warning system

352

6-3. Do-it-yourself maintenance



Except Convertible



Convertible

■

Routine tire inflation pressure checks

The tire pressure warning system does not

replace routine tire inflation pressure

checks. Make sure to check tire inflation

pressure as part of your routine of daily

vehicle checks.

■

Situations in which the tire pressure

warning system may not operate prop-

erly

●

In the following cases, the tire pressure

warning system may not operate prop-

erly.

• If non-genuine Lexus wheels are used.

• A tire has been replaced with a tire that is

not an OE (Original Equipment) tire.

• A tire has been replaced with a tire that is

not of the specified size.

• Tire chains etc. are equipped.

• An auxiliary-supported tire is equipped.

• If a window tint that affects the radio wave

signals is installed.

• If there is a lot of snow or ice on the vehi-

cle, particularly around the wheels or

wheel housings.

• If the tire inflation pressure is extremely

higher than the specified level.

• If wheel without tire pressure warning

valves and transmitters are used.

• If the ID code on the tire pressure warn-

ing valves and transmitters is not regis-

tered in the tire pressure warning

computer.

●

Performance may be affected in the fol-

lowing situations.

• Near a TV tower, electric power plant,

gas station, radio station, large display,

airport or other facility that generates

strong radio waves or electrical noise

• When carrying a portable radio, cellular

phone, cordless phone or other wireless

communication device

If tire position information is not correctly
displayed due to the radio wave conditions,
the display may be corrected by driving and
changing the radio wave conditions.

●

When the vehicle is parked, the time

taken for the warning to start or go off

could be extended.

●

When tire inflation pressure declines rap-

idly for example when a tire has burst, the

warning may not function.

When replacing tires or wheels, tire
pressure warning valves and transmit-
ters must also be installed.
When new tire pressure warning
valves and transmitters are installed,
new ID codes must be registered in the
tire pressure warning computer and
the tire pressure warning system must
be initialized. (



P.355)

■

When replacing the tires and wheels

If the ID code of the tire pressure warning

valve and transmitter is not registered, the

tire pressure warning system will not work

properly. After driving for about 20 min-

utes, the tire pressure warning light blinks

Installing tire pressure warning
valves and transmitters

353

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

for 1 minute and stays on to indicate a sys-

tem malfunction.

■

The tire pressure warning system
must be initialized in the following
circumstances:



When rotating the tires.



When the tire inflation pressure is
changed when changing traveling
speed.



When the tire inflation pressure is
changed such as when changing tire
size. (When there are multiple spec-
ified pressures)



After registering the ID codes.
(



P.355)

When the tire pressure warning sys-
tem is initialized, the current tire infla-
tion pressure is set as the benchmark

pressure.

■

How to initialize the tire pressure
warning system

Park the vehicle in a safe place and
turn the engine switch <power
switch> off.

Initialization cannot be performed while

the vehicle is moving.

Adjust the tire inflation pressure to
the specified cold tire inflation
pressure level.

Make sure to adjust the tire pressure to the

specified cold tire inflation pressure level.

The tire pressure warning system will oper-

ate based on this pressure level.

Turn the engine switch <power
switch> to ON.

Press

of the meter con-

trol switches and select

Press

of the meter con-

trol switches and select “Vehicle
Settings”, then press “OK”.

Press

of the meter con-

trol switches and select “TPWS
SET”, then press “OK”.

Press

of the meter con-

trol switches and select “Set tire
pressure”. Then press and hold
“OK” until the tire pressure warn-
ing light starts blinking.

A message is displayed on the multi-infor-

mation display. Also, “--” is displayed for

inflation pressure of each tire on the multi-

information display while the tire pressure

NOTICE

■

Repairing or replacing tires, wheels,

tire pressure warning valves, trans-

mitters and tire valve caps

●

When removing or fitting the wheels,

tires or the tire pressure warning

valves and transmitters, contact your

Lexus dealer as the tire pressure warn-

ing valves and transmitters may be

damaged if not handled correctly.

●

Make sure to install the tire valve caps.

If the tire valve caps are not installed,

water could enter the tire pressure

warning valves and the tire pressure

warning valves could be bound.

●

When replacing tire valve caps, do not

use tire valve caps other than those

specified. The cap may become stuck.

Initializing the tire pressure
warning system

354

6-3. Do-it-yourself maintenance

warning system determines the position.

Drive the vehicle at approximately
25mph (40 km/h) or more for
approximately 10 to 30 minutes.

When initialization is complete, the infla-

tion pressure of each tire will be displayed

on the multi-information display.
Depending on the vehicle and driving con-

ditions, initialization may take up to

approximately 1 hour to complete.

■

The initialization operation

●

Make sure to carry out initialization after

adjusting the tire inflation pressure.

Also, make sure the tires are cold before

carrying out initialization or tire inflation

pressure adjustment.

●

If you have accidentally turned the engine

switch <power switch> off during initial-

ization, it is not necessary to manually

restart the initialization again, as initializa-

tion will restart automatically the next

time the engine switch <power switch> is

turned to ON.

●

If you accidentally perform initialization

when initialization is not necessary, adjust

the tire inflation pressure to the specified

level when the tires are cold, and conduct

initialization again.

●

While the position of each tire is being

determined and the inflation pressures

are not being displayed on the multi-

information display, if the inflation pres-

sure of a tire drops, the tire pressure

warning light will come on.

■

When initialization of the tire pressure

warning system has failed

Initialization may take longer to complete if

the vehicle is driven on an unpaved road.

When performing initialization, drive on a

paved road if possible. Depending on the

driving environment and condition of the

tires, initialization will be completed in

approximately 10 to 30 minutes. If initializa-

tion is not complete after driving approxi-

mately 10 to 30 minutes, continue driving

for a while. If the inflation of each tire is not

displayed after driving for approximately 1

hour, perform the following procedure.

●

Park the vehicle in a safe place for

approximately 20 minutes. Then drive

straight (with occasional left and right

turns) at approximately 25 mph (40

km/h) or more for approximately 10 to

30 minutes.

However, in the following situations, the tire
inflation pressure will not be recorded and
the system will not operate properly. Per-
form initialization again.

●

When performing initialization, the tire

pressure warning light does not blink 3

times. (Initialization will not occur while

driving)

●

After performing initialization, the tire

pressure warning light blinks for 1 minute

then stays on after driving for about 20

minutes.

If the inflation pressure of each tire is still not
displayed, have the vehicle inspected by
your Lexus dealer.

■

When registering ID codes

●

Initialize the tire pressure warning system

after ID code registration. Initialization is

disabled if the system was initialized

before registration.

●

After ID code registration, the tires are

hot by driving. Initialize the tire pressure

warning system after the tires become

cold.

355

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

The tire pressure warning valve and
transmitter is equipped with a unique
ID code. When replacing a tire pres-
sure warning valve and transmitter, it is
necessary to register the ID code.
When registering the ID codes, per-
form the following procedure.

Turn the engine switch <power
switch> to ON.

Press

of the meter con-

trol switches and select

Press

of the meter con-

trol switches and select “Vehicle
Settings”, then press “OK”.

Press

of the meter con-

trol switches and select “TPWS
SET”, then press “OK”.

Press

of the meter con-

trol switches and select “Change
wheel set”. Then press and hold
“OK” until the tire pressure warn-
ing light starts blinking.

The change wheel set mode is activated

and registration is started.
A message is displayed on the multi-infor-

mation display, and “--” is displayed for

inflation pressure of each tire. Then, the tire

pressure warning light blinks rapidly for

approximately 1 minute and stays on.

Drive the vehicle at 25mph (40
km/h) or more for approximately
10 to 30 minutes.

When registration is completed, the tire

pressure warning light will go off and the

inflation pressure of each tire will be dis-

played on the multi-information display.
The time elapsed before registration is

completed differs according to the driving

condition and environment.

■

Canceling the change wheel set mode

●

If turning the engine switch <power

switch> off when in the change wheel set

mode before driving, the change wheel

set mode is canceled.

●

After driving when in the change wheel

set mode, the change wheel set mode

cannot be canceled. To cancel the mode,

perform the procedure for ID code regis-

tration again and turn the engine switch

<power switch> off before driving.

●

If the change wheel set mode is canceled,

the ID codes that have already been reg-

istered are communicated. When com-

munication is finished, the tire pressure

warning light will turn off.

■

When ID code registration may not

operate properly

●

Do not move the vehicle backward

during registration. Registration is started

again from the beginning and it may take

longer than usual.

WARNING

■

When initializing the tire pressure

warning system

Do not initialize tire inflation pressure

without first adjusting the tire inflation

pressure to the specified level. Other-

wise, the tire pressure warning light may

not come on even if the tire inflation

pressure is low, or it may come on when

the tire inflation pressure is actually nor-

mal.

Registering ID codes

356

6-3. Do-it-yourself maintenance

●

When another vehicle is running the side

of the vehicle such as in heavy traffic, it

may take longer to detect the vehicle’s

tire pressure warning valves and trans-

mitters.

●

If tire pressure warning valves and trans-

mitters are in the vehicle, the ID codes

may not be registered.

If registration takes long time, perform the
procedure for ID code registration again
after parking the vehicle for 20 minutes.
If the ID codes cannot be registered even
when performing the above procedure,
contact your Lexus dealer.



Stop the vehicle in a safe place on a
hard, flat surface.



Set the parking brake.



Shift the shift position to P.



Stop the engine <hybrid system>.

■

Tools

The following tools for replacing a tire are

not included with your vehicle. They can be

purchased at your Lexus dealer.

●

Wheel bolt wrench

●

Jack

●

Jack handle

●

Guide pin

●

Wheel bolt socket

Replacing the tire

When replacing the tires yourself,
prepare the necessary tools and a
jack.
This vehicle uses wheel bolts.
When using wheels that were
installed when the vehicle was
shipped from the factory, special-
ized Lexus genuine wheel bolts
must be used.
If necessary tire replacement
seems difficult to perform, contact
your Lexus dealer.

Before jacking up the vehicle

357

6-3. Do-it-yourself maintenance

Mai
nte

e a

are



Except Convertible

Wheel bolt socket

Screwdriver

Wheel bolt wrench

Guide pin

Jack

Jack handle

Towing eyelet

Location of the tools

A
B
C
D

E
F

358

6-3. Do-it-yourself maintenance



Convertible

Wheel bolt socket

Screwdriver

Wheel bolt wrench

Guide pin

Jack

Jack handle

Towing eyelet

: They can be purchased at your Lexus dealer.

A
B
C
D

E
F

WARNING

■

Using the tire jack

Observe the following precautions.

Improper use of the tire jack may cause

the vehicle to suddenly fall off the jack,

leading to death or serious injury.

●

Do not use the tire jack for any pur-

pose other than replacing tires.

●

Do not use other tire jacks for replac-

ing tires on this vehicle.

●

Put the jack properly in its jack point.

●

Do not put any part of your body under

the vehicle while it is supported by the

jack.

●

Do not start the engine <hybrid sys-

tem> or drive the vehicle while the

vehicle is supported by the jack.

●

Do not raise the vehicle while some-

one is inside.

●

When raising the vehicle, do not put an

object on or under the jack.

359

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Chock the tires.

Using a wheel bolt wrench, slightly
loosen the wheel bolts (approxi-
mately one turn).

Turn the tire jack portion

hand until the notch of the jack is in
contact with the jack point.

The jack point guides are located under

the rocker panel. They indicate the jack

point positions.

Raise the vehicle until the tire is
slightly raised off the ground.

Remove the uppermost wheel bolt
and install the guide pin

hand.

WARNING

●

Do not raise the vehicle to a height

greater than that required to replace

the tire.

●

Use a jack stand if it is necessary to get

under the vehicle.

●

When lowering the vehicle, make sure

that there is no-one near the vehicle. If

there are people nearby, warn them

vocally before lowering.

Removing a tire

Tire

Wheel chock posi-

tions

Front left-hand side

Behind the rear
right-hand side tire

Front right-hand
side

Behind the rear left-
hand side tire

Rear left-hand side

In front of the front
right-hand side tire

Rear right-hand side

In front of the front
left-hand side tire

360

6-3. Do-it-yourself maintenance

Turn the guide pin clockwise to tighten it

until it stops.

Remove all the wheel bolts and the
tire.

When resting the tire on the ground, place

the tire so that the wheel design faces up to

avoid scratching the wheel surface.

WARNING

■

Replacing a tire

●

Do not touch the disc wheels or the

area around the brakes immediately

after the vehicle has been driven.

After the vehicle has been driven the disc

wheels and the area around the brakes

will be extremely hot. Touching these

areas with hands, feet or other body

parts while changing a tire, etc. may

result in burns.

●

When removing or installing a tire,

make sure to use the guide pin. Also,

the guide pin is made of resin. It may

be damaged if the wheel is placed any-
where other than

or if a large

amount of force is applied to the guide

pin.

●

Failure to follow these precautions

could cause the wheel bolts to loosen

and the tire to fall off, resulting in death

or serious injury.

• The contact surfaces of the wheel bolt

and wheel are designed specifically to

fit together. When using wheels that

were installed when the vehicle was

shipped from the factory, use special-

ized Lexus genuine wheel bolts. Do

not use wheel bolts designed for other

models, model years or types even if

they are Lexus genuine parts. If the

vehicle does not have wheels that

were installed to the vehicle when it

was shipped from the factory, the fac-

tory-installed wheel bolts may not be

appropriate for the wheel. Contact

either the retailer where the wheels

were purchased or the manufacturer

of the wheels for proper installation

advice.

361

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Remove any dirt or foreign matter
from the wheel contact surface.

If foreign matter is not removed, the wheel

bolts may loosen while the vehicle is in

motion, and the wheel may come off.

Align a wheel bolt hole on the tire
with the guide pin, and set the tire
on the guide pin.

Align the center hole of the wheel with the

center of the hub and securely set the tire

so that the wheel and hub contact surfaces

Loosely tighten each wheel bolt by
hand or using a wheel bolt socket

Do not use the wheel bolt socket for any-

thing other than loosely tightening the

wheel bolts by hand.

WARNING

• Never apply oil or grease to the wheel

bolts or their contact surface on the
wheel .

Doing so may cause the wheel bolts to
be tightened excessively, leading to
damage to the wheel bolts, the threaded
portion the wheel bolts install to

, or

the wheel.
Remove any oil or grease that has
adhered when installing the wheel bolts.

• After replacing a tire, check the tight-

ening torque as soon as possible. If you

cannot confirm the tightening torque

yourself, have the vehicle inspected at

your Lexus dealer.

• If a wheel bolt hole in a wheel or the

threads of a wheel bolt or the wheel

hub are deformed, cracked, rusty or

otherwise damaged, have the vehicle

inspected by your Lexus dealer.

●

When tightening the wheel bolts, do

not tighten them excessively. Doing so

may cause the wheel bolts, the threads

of the wheel hub, or the wheel to be

damaged.

Installing the tire

362

6-3. Do-it-yourself maintenance

Remove the guide pin and loosely
tighten the wheel bolt as in step

Lower the vehicle.

Securely tighten the wheel bolts
two or three times in the order
shown in the illustration using a
wheel bolt wrench.

Tightening torque:

103.3 ft•lbf (140 N•m, 14.3 kgf•m)

Stow all the tools.

WARNING

■

When installing the tire

Failure to follow these precautions could

cause the wheel bolts to loosen and the

tire to fall off, resulting in death or serious

injury.

●

Never use oil or grease on the wheel

bolts.

Oil and grease may cause the wheel

bolts to be excessively tightened, lead-

ing to bolt or disc wheel damage. In

addition, the oil or grease can cause

the wheel bolts to loosen and the

wheel may fall off, causing a serious

accident. Remove any oil or grease

from the wheel bolts.

●

Have the wheel bolts tightened with a

torque wrench to 103.3 ft•lbf (140

N•m, 14.3 kgf•m) soon as possible

after changing wheels.

●

Do not attach a heavily damaged

wheel ornament, as it may fly off the

wheel while the vehicle is moving.

●

When installing a tire, only use wheel

bolts that have been specifically

designed for that wheel.

●

If there are any cracks or deformations

in the bolt screws, bolt threads or bolt

holes of the wheel, have the vehicle

inspected by your Lexus dealer.

■

After using the tools

Before driving, make sure all the tools

are stored securely in place. Failure to do

so may cause injury in case of a collision

or sudden braking.

NOTICE

■

Repairing or replacing tires, wheels,

tire pressure warning valves, trans-

mitters and tire valve caps



P.353

363

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

The recommended cold tire inflation
pressure and tire size are displayed on
the tire and loading information label.
(



P.448)

Tire valve

Tire pressure gauge

Remove the tire valve cap.

Press the tip of the tire pressure
gauge onto the tire valve.

Read the pressure using the gauge
gradations.

If the tire inflation pressure is not at
the recommended level, adjust the
pressure.
If you add too much air, press the
center of the valve to deflate.

After completing the tire inflation
pressure measurement and adjust-
ment, apply soapy water to the
valve and check for leakage.

Put the tire valve cap back on.

■

Tire inflation pressure check interval

You should check tire inflation pressure

every two weeks, or at least once a month.

Do not forget to check the spare.

■

Effects of incorrect tire inflation pres-

sure

Driving with incorrect tire inflation pressure

may result in the following:

●

Reduced fuel economy

●

Reduced driving comfort and poor han-

dling

●

Reduced tire life due to wear

●

Reduced safety

●

Damage to the drivetrain

If a tire needs frequent inflating, have it

checked by your Lexus dealer.

■

Instructions for checking tire inflation

pressure

When checking tire inflation pressure,

observe the following:

●

Check only when the tires are cold.

If your vehicle has been parked for at

least 3 hours or has not been driven for

Tire inflation pressure

Checking the specified tire infla-
tion pressure

Inspection and adjustment pro-
cedure

364

6-3. Do-it-yourself maintenance

more than 1 mile or 1.5 km, you will get an

accurate cold tire inflation pressure read-

ing.

●

Always use a tire pressure gauge.

It is difficult to judge if a tire is properly

inflated based only on its appearance.

●

It is normal for the tire inflation pressure

to be higher after driving as heat is gener-

ated in the tire. Do not reduce tire infla-

tion pressure after driving.

●

Never exceed the vehicle capacity

weight.

Passengers and luggage weight should

be placed so that the vehicle is balanced.

WARNING

■

Proper inflation is critical to save tire

performance

Keep your tires properly inflated.

If the tires are not properly inflated, the

following conditions may occur which

could lead to an accident resulting in

death or serious injury:

●

Excessive wear

●

Uneven wear

●

Poor handling

●

Possibility of blowouts resulting from

overheated tires

●

Air leaking from between tire and

wheel

●

Wheel deformation and/or tire dam-

age

●

Greater possibility of tire damage

while driving (due to road hazards,

expansion joints, sharp edges in the

road, etc.)

NOTICE

■

When inspecting and adjusting tire

inflation pressure

Be sure to put the tire valve caps back

on.

If a valve cap is not installed, dirt or mois-

ture may get into the valve and cause an

air leak, resulting in decreased tire infla-

tion pressure.

365

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

When replacing wheels, care should
be taken to ensure that they are equiv-
alent to those removed in load capac-
ity, diameter, rim width and inset

Replacement wheels are available at
your Lexus dealer.

: Conventionally referred to as offset.

Lexus does not recommend using the
following:



Wheels of different sizes or types



Used wheels



Bent wheels that have been
straightened

■

When replacing wheels

The wheels of your vehicle are equipped

with tire pressure warning valves and trans-

mitters that allow the tire pressure warning

system to provide advance warning in the

event of a loss in tire inflation pressure.

Whenever wheels are replaced, tire pres-

sure warning valves and transmitters must

be installed. (



P.352)

Wheels

If a wheel is bent, cracked or heav-
ily corroded, it should be replaced.
Otherwise, the tire may separate
from the wheel or cause a loss of
handling control.

Wheel selection

WARNING

■

When replacing wheels

●

Do not use wheels that are a different

size from those recommended in the

Owner’s Manual, as this may result in a

loss of handling control.

●

Never use an inner tube in a leaking

wheel which is designed for a tubeless

tire. Doing so may result in an acci-

dent, causing death or serious injury.

●

Use the correct wheel bolts for the

wheels to be installed. For details, con-

tact your Lexus dealer.

■

Wheel bolts

●

Do not over tighten.

●

Never use oil or grease on the wheel

bolts. Oil and grease may cause the

wheel bolts to be excessively tight-

ened, leading to bolt or disc wheel

damage. In addition, the oil or grease

can cause the wheel bolts to loosen

and the wheel may fall off, causing a

serious accident. Remove any oil or

grease from the wheel bolts.

●

If there are any cracks or deformations

in the wheel bolts, or if the surface

treatment becomes worn, have the

wheel bolts replaced at your Lexus

dealer. Failure to follow these precau-

tions could cause the wheel bolts to

loosen and the tire to fall off, resulting

in death or serious injury.

■

Use of defective wheels prohibited

Do not use cracked or deformed wheels.

Doing so could cause the tire to leak air

during driving, possibly causing an acci-

dent.

NOTICE

■

Replacing tire pressure warning

valves and transmitters

●

Because tire repair or replacement

may affect the tire pressure warning

valves and transmitters, make sure to

have tires serviced by your Lexus

dealer or other qualified service shop.

In addition, make sure to purchase

your tire pressure warning valves and

transmitters at your Lexus dealer.

366

6-3. Do-it-yourself maintenance



Use only Lexus wheel bolts and
wrenches designed for use with
your aluminum wheels.



When rotating, repairing or chang-
ing your tires, check that the wheel
bolts are still tight after driving 621
miles (1000 km).



Use only Lexus genuine balance
weights or equivalent and a plastic
or rubber hammer when balancing
your wheels.

Turn the engine switch <power
switch> off.

Open the glove box.

Remove the panel.

Unlock the filter cover (

), pull

the filter cover out of the claws
(

), and remove the filter cover.

NOTICE

●

Ensure that only genuine Lexus wheels

are used on your vehicle.

Tire pressure warning valves and

transmitters may not work properly

with non-genuine wheels.

Aluminum wheel precautions

Air conditioning filter

The air conditioning filter must be
changed regularly to maintain air
conditioning efficiency.

Removing the air conditioning
filter

367

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Remove the filter case.

Remove the air conditioning filter
from the filter case and replace it
with a new one.

The “

UP” marks shown on the filter and

the filter case should be pointing up.

■

Checking interval

Inspect and replace the air conditioning fil-

ter according to the maintenance schedule.

In dusty areas or areas with heavy traffic

flow, early replacement may be required.

(For scheduled maintenance information,

please refer to the “Owner’s Manual Sup-

plement” or “Scheduled Maintenance”.)

■

If air flow from the vents decreases dra-

matically

The filter may be clogged. Check the filter

and replace if necessary.

■

Air conditioning filter with deodorizing

function

When fragrances are placed in your vehi-

cle, the deodorizing effect may become sig-

nificantly weakened in a short period.

When an air conditioning odor comes out

continuously, replace the air conditioning

filter.

NOTICE

■

When using the air conditioning sys-

tem

Make sure that a filter is always installed.

Using the air conditioning system with-

out a filter may cause damage to the sys-

tem.

■

To prevent damage to the filter cover

When moving the filter cover in the

direction of arrow to release the fitting,

pay attention not to apply excessive

force to the claws. Otherwise, the claws

may be damaged.

368

6-3. Do-it-yourself maintenance

■

If the electronic key battery is depleted

The following symptoms may occur:

●

The smart access system with push-but-

ton start and wireless remote control will

not function properly.

●

The operational range will be reduced.

■

When the card key battery needs to be

replaced (if equipped)

The battery for the card key is available only

at Lexus dealers. Your Lexus dealer can

replace the battery for you.

Prepare the following before replacing
the battery:



Flathead screwdriver



Small flathead screwdriver



Lithium battery CR2032

■

Use a CR2032 lithium battery

●

Batteries can be purchased at your Lexus

dealer, local electrical appliance shops or

camera stores.

●

Replace only with the same or equivalent

type recommended by the manufacturer.

●

Dispose of used batteries according to

the local laws.

Take out the mechanical key.

Remove the cover.

To prevent damage to the key, wrap the tip

of the screwdriver with tape.

Remove the depleted battery using
a small flathead screwdriver.

Insert a new battery with the “+” terminal

facing up.

Electronic key battery

Replace the battery with a new one
if it is depleted.

Items to prepare

Replacing the battery

369

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

WARNING

■

Battery precautions

Observe the following precautions.
Failure to do so may result in death or

serious injury.

●

Do not swallow the battery. Doing so

may cause chemical burns.

●

A coin battery or button battery is

used in the electronic key. If a battery

is swallowed, it may cause severe

chemical burns in as little as 2 hours

and may result in death or serious

injury.

●

Keep away new and removed batter-

ies from children.

●

If the cover cannot be firmly closed,

stop using the electronic key and stow

the key in the place where children

cannot reach, and then contact your

Lexus dealer.

●

If you accidentally swallow a battery or

put a battery into a part of your body,

get emergency medical attention

immediately.

■

To prevent battery explosion or leak-

age of flammable liquid or gas

●

Replace the battery with a new battery

of the same type. If a wrong type of

battery is used, it may explode.

●

Do not expose batteries to extremely

low pressure due to high altitude or

extremely high temperatures.

●

Do not burn, break or cut a battery.

NOTICE

■

When replacing the battery

Use a screwdriver of appropriate size.

Applying excessive force may deform or

damage the cover.

■

For normal operation after replacing

the battery

Observe the following precautions to

prevent accidents:

●

Always work with dry hands.

Moisture may cause the battery to

rust.

●

Do not touch or move any other com-

ponent inside the remote control.

●

Do not bend either of the battery ter-

minals.

370

6-3. Do-it-yourself maintenance

Turn the engine switch <power
switch> off.

Open the Fuse box cover.



Engine compartment: type A fuse
box (LC500)

Push the tab in and lift the lid off.



Engine compartment: type B fuse
box (LC500h)

Push the tab in and lift the lid off.



Engine compartment: type C fuse
box (LC500h)

Push the tab in and lift the lid off.



Trunk

Remove the luggage mat.

Push the tab in and lift the lid off.



Driver’s side instrument panel

Push the tab in and remove the lid.
Make sure to push the tab in during

Checking and replacing
fuses

If any of the electrical components
do not operate, a fuse may have
blown. If this happens, check and
replace the fuses as necessary.

Checking and replacing fuses

371

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

removal or installation.



Front passenger’s side instrument
panel

Remove the cover, and then remove the
footwell light connector.

Push the tab in and remove the lid.
Make sure to push the tab in during
removal or installation.

Remove the fuse with the pullout
tool.

Only type A fuses can be removed using

the pullout tool.



LC500



LC500h

Check if the fuse is blown.

Type A and B:

Replace the blown fuse with a new fuse of

an appropriate amperage rating. The

amperage rating can be found on the fuse

box lid.
Type C and D:

Contact your Lexus dealer.

372

6-3. Do-it-yourself maintenance



Type A

Normal fuse

Blown fuse



Type B

Normal fuse

Blown fuse



Type C

Normal fuse

Blown fuse



Type D

Normal fuse

Blown fuse

■

After a fuse is replaced

●

When installing the lid, make sure that the

tab is installed securely.

●

If the lights do not turn on even after the

fuse has been replaced, a bulb may need

replacement. (



P.374)

●

If the replaced fuse blows again, have the

vehicle inspected by your Lexus dealer.

■

If there is an overload in a circuit

The fuses are designed to blow, protecting

the wiring harness from damage.

■

When replacing light bulbs

Lexus recommends that you use genuine

Lexus products designed for this vehicle.

Because certain bulbs are connected to cir-

cuits designed to prevent overload, non-

genuine parts or parts not designed for this

vehicle may be unusable.

A
B

WARNING

■

To prevent system breakdowns and

vehicle fire

Observe the following precautions.

Failure to do so may cause damage to

the vehicle, and possibly a fire or injury.

●

Never use a fuse of a higher amperage

rating than that indicated, or use any

other object in place of a fuse.

A
B

373

6-3. Do-it-yourself maintenance

Mai
nte

e a

are

Adjustment bolt A

Adjustment bolt B



Make sure the vehicle has a full tank
of gasoline and the area around the
headlight is not deformed.



Park the vehicle on level ground.



Make sure the tire inflation pressure
is at the specified level.



Have someone sit in the driver’s
seat.



Bounce the vehicle several times.

WARNING

●

Always use a genuine Lexus fuse or

equivalent.

Never replace a fuse with a wire, even

as a temporary fix.

●

Do not modify the fuses or fuse boxes.

NOTICE

■

Before replacing fuses

Have the cause of electrical overload

determined and repaired by your Lexus

dealer as soon as possible.

Headlight aim

Vertical movement adjusting
bolts

Before checking the headlight
aim

A
B

374

6-3. Do-it-yourself maintenance

Using a Phillips-head screwdriver,
turn bolt A in either direction.

Turn bolt B in either direction as
step

If the headlight cannot be adjusted using

this procedure, take the vehicle to your

Lexus dealer to adjust the headlight aim.

■

LED lights

The following lights consist of a number of

LEDs. If any of the LEDs burn out, take your

vehicle to your Lexus dealer to have the

light replaced.

●

Headlights

●

Parking lights and daytime running lights

●

Front side marker lights

●

Front turn signal lights

●

Cornering lights

●

Side turn signal lights

●

Tail lights

●

Stop lights

●

Rear side marker lights

●

Rear turn signal lights

●

Back-up lights

●

High mounted stoplight

●

License plate lights

■

Condensation build-up on the inside of

the lens

Temporary condensation build-up on the

inside of the headlight lens does not indi-

cate a malfunction. Contact your Lexus

dealer for more information in the following

situations:

●

Large drops of water have built up on the

inside of the lens.

●

Water has built up inside the headlight.

Adjusting the headlight aim

Light bulbs

If any lights burn out, have it
replaced by your Lexus dealer.

WARNING

■

Handling lights

Do not touch the lights while they are on

or immediately after they have been

turned off. Doing so may result in burns.

375

When trouble

ari

ses

When trouble arises

7-1. Essential information

Emergency flashers..................

376

If your vehicle has to be stopped

in an emergency.....................

376

If the vehicle is submerged or

water on the road is rising ..

377

7-2. Steps to take in an emergency

If your vehicle needs to be towed

........................................................

379

If you think something is wrong

........................................................

383

Fuel pump shut off system

(LC500)....................................

384

If a warning light turns on or a

warning buzzer sounds .......

385

If a warning message is displayed

........................................................

394

If you have a flat tire..................

400

If the engine will not start

(LC500).....................................

410

If the hybrid system will not start

(LC500h)...................................

411

If you lose your keys..................

413

If the fuel filler door cannot be

opened.........................................

413

If the electronic key does not

operate properly .....................

415

If the 12-volt battery is discharged

.........................................................

417

If the soft top roof cannot be

closed (Convertible).............

424

If your vehicle overheats

(LC500) ....................................

431

If your vehicle overheats

(LC500h).................................

433

If the vehicle becomes stuck

437

376

7-1. Essential information

7-1.Essential information

Press the switch to flash all of the turn
signal lights.

To turn them off, press the switch once
again.

■

Emergency flashers

●

LC500: If the emergency flashers are

used for a long time while the engine is

not running, the 12-volt battery may dis-

charge.

LC500h: If the emergency flashers are

used for a long time while the hybrid sys-

tem is not operating (while the “READY”

indicator is not illuminated), the 12-volt

battery may discharge.

●

If any of the SRS airbags deploy (inflate)

or in the event of a strong rear impact, the

emergency flashers will turn on automati-

cally. The emergency flashers will turn off

automatically after operating for approxi-

mately 20 minutes. To manually turn the

emergency flashers off, press the switch

twice. (The emergency flashers may not

turn on automatically depending on the

force of the impact and conditions of the

collision.)

Steadily step on the brake pedal
with both feet and firmly depress it.

Do not pump the brake pedal repeatedly

as this will increase the effort required to

slow the vehicle.

Shift the shift position to N.



If the shift position is shifted to N

After slowing down, stop the vehi-
cle in a safe place by the road.

Stop the engine <hybrid system>.



If the shift position cannot be shifted
to N

Keep depressing the brake pedal
with both feet to reduce vehicle
speed as much as possible.

To stop the engine <hybrid system>,
press and hold the engine switch
<power switch> for 2 consecutive

Emergency flashers

The emergency flashers are used to
warn other drivers when the vehi-
cle has to be stopped in the road
due to a breakdown, etc.

Operating instructions

If your vehicle has to be
stopped in an emergency

Only in an emergency, such as if it
becomes impossible to stop the
vehicle in the normal way, stop the
vehicle using the following proce-
dure:

Stopping the vehicle

377

7-1. Essential information

n t

ris

seconds or more, or press it briefly
3 times or more in succession.

Stop the vehicle in a safe place by
the road.



If the door can be opened, open the
door and exit the vehicle.



If the door cannot be opened, open
the window using the power win-
dow switch and ensure an escape
route.



If the window can be opened, exit
the vehicle through the window.



If the door and window cannot be
opened due to the rising water,
remain calm, wait until the water
level inside the vehicle rises to the
point that the water pressure inside
of the vehicle equals the water pres-
sure outside of the vehicle and then
open the door after waiting for the
rising water to enter the vehicle, and
exit the vehicle.

When the outside water level exceeds half
the height of the door, the door cannot be
opened from the inside due to water pres-
sure.

■

Water level exceeds the floor

LC500: When the water level exceeds the

floor and time has passed, the electrical

WARNING

■

If the engine <hybrid system> has to

be turned off while driving

Power assist for the steering wheel will

be lost, making the steering wheel

heavier to turn. Decelerate as much as

possible before turning off the engine

<hybrid system>.

If the vehicle is submerged
or water on the road is rising

This vehicle is not designed to be
able to drive on roads that are
deeply flooded with water. Do not
drive on roads where the roads may
be submerged or the water may be
rising. It is dangerous to remain in
the vehicle, if it is anticipated that
the vehicle will be flooded or set
adrift. Remain calm and follow the
following.

378

7-1. Essential information

equipment will get damaged, the power

windows will not operate, the engine stop,

and the vehicle may not be able to get mov-

ing.
LC500h: When the water level exceeds

the floor and time has passed, the electrical

equipment will get damaged, the power

windows will not operate, the engine and

motor stop, and the vehicle may not be able

to get moving.

■

Using an emergency escape hammer

Laminated glass is used in the windshield on

this vehicle. Laminated glass cannot be
shattered with an emergency hammer

Tempered glass is used in the windows on

this vehicle.

: Contact your Lexus dealer or aftermar-

ket accessory manufacturer for further
information about an emergency ham-
mer.

WARNING

■

Caution while driving

Do not drive on roads where the roads

may be submerged or the water may be

rising. Otherwise the vehicle may be

damaged and cannot move, as well as

become flooded and set adrift, which

may lead to death.

Lexus LC500C (2024 year). Manual in english - page 11
